Covalent Immobilization of Human Placental 17β-Hydroxysteroid Dehydrogenase Type 1 onto Glutaraldehyde Activated Silica Coupled with LC-TOF/MS for Anti-Cancer Drug Screening Applications

Article abstract of DOI:10.1007/s12010-016-2339-6

Human 17β-hydroxysteroid dehydrogenase type 1 (17β-HSD1), a potential target in breast cancer prevention and therapy, was extracted from human placenta and immobilized on nonporous silica (～5?μm) with a covalent method for the first time. The optimum initial enzyme concentration and immobilization time during the immobilization process were 0.42?mg?mL^?1 and 12?h, repectively. The binding was confirmed by scanning electron microscope (SEM) and infrared spectroscopy (FT-IR). It could improve the pH, thermal and storage stability compared to free enzyme. Moreover, the immobilized enzyme could be reused at least four times. A screening method based on it coupled with liquid chromatography–time-of-flight mass spectrometer (LC-TOF/MS) was established, and the half-maximal inhibitory concentration (IC 50) of apigenin for the immobilized enzyme was 291?nM. Subsequently, 10 natural products were evaluated leading to inhibition of the activity of 17β-HSD1 at the concentration of 25?μM, and six of them inhibit the activity over 50%.

Full text of DOI:10.1007/s12010-016-2339-6

Appl Biochem Biotechnol
DOI 10.1007/s12010-016-2339-6
Covalent Immobilization of Human Placental
17β-Hydroxysteroid Dehydrogenase Type 1
onto Glutaraldehyde Activated Silica Coupled
with LC-TOF/MS for Anti-Cancer Drug
Screening Applications
Yin Bai1,2 & Wen-Di Zhou1,2 & Xian-Min Mu3
&
Qian Zhang1,2 & Chen Yu1,2 & Bin Di1,2
&
Meng-Xiang Su1,2
Received: 25 July 2016 /Accepted: 22 November 2016
#
Springer Science+Business Media New York 2016
Abstract Human 17β-hydroxysteroid dehydrogenase type 1 (17β-HSD1), a potential
target in breast cancer prevention and therapy, was extracted from human placenta and
immobilized on nonporous silica (∼5 μm) with a covalent method for the first time. The
optimum initial enzyme concentration and immobilization time during the immobiliza-
tion process were 0.42 mg mL−1 and 12 h, repectively. The binding was confirmed by
scanning electron microscope (SEM) and infrared spectroscopy (FT-IR). It could im-
prove the pH, thermal and storage stability compared to free enzyme. Moreover, the
immobilized enzyme could be reused at least four times. A screening method based on it
coupled with liquid chromatography–time-of-flight mass spectrometer (LC-TOF/MS)
was established, and the half-maximal inhibitory concentration (IC 50) of apigenin for
the immobilized enzyme was 291 nM. Subsequently, 10 natural products were evaluated
leading to inhibition of the activity of 17β-HSD1 at the concentration of 25 μM, and six
of them inhibit the activity over 50%.
* Bin Di
dibin@cpu.edu.cn
* Meng-Xiang Su
sumengxiang@cpu.edu.cn
1
Department of Pharmaceutical Analysis, China Pharmaceutical University, Nanjing 210009, People’s
Republic of China
2
Key Laboratory on Protein Chemistry and Structural Biology, China Pharmaceutical University,
Nanjing 210009, People’s Republic of China
3
The Second Affiliated Hospital of Nanjing Medical University, Nanjing, China

Appl Biochem Biotechnol
.
.
Keywords Human 17β-hydroxysteroid dehydrogenase type 1 Covalent immobilization
Enzyme stability Inhibitor screening LC-TOF/MS
.
.
Introduction
Breast cancer is the most prevalent type of cancer in women and the main disease in
cancer related to deaths [1]. It represents about one third of all cases according to both
the American Cancer Society and the National Cancer Institute of Canada [2]. 17β-
Hydroxysteroid dehydrogenase (17β-HSDs) play a key role in the activation of estrogen
in breast cancer cells and in which 17β-hydroxysteroid dehydrogenase type 1 (17β-
HSD1) is the most active of all known types. Based on the experiments of MCF-7 and
T47D in breast cancer cells, it is confirmed that activated estrogens obviously decreased
and then cell growth slowed down as a consequence of inhibition of expression of 17β-
HSD1 [3]. 17β-HSD1 is also expressed in ovaries, placenta and ectopic endometrium
[4]. Many further researches on the enzyme extracted from placenta have been done,
such as the description of its biological characteristics [5, 6] and the research of its
function [7, 8]. Some reports have described the structure of the complex of 17β-HSD1–
estradiol–NADP+ [9] or 17β-HSD1–androstanedione–NADP+ [10] through X-ray dif-
fraction, thus providing an important basis for inhibitor screening.
The common catalytic substrates of 17β-HSD1 include estrone, estradiol, androstenedione,
dehydroepiandrosterone and dihydrotestosterone [11, 12]. Aiming at its active site, many
active compounds have been screened from nature products [13]. And phytoestrogens,
including flavonoids, coumestans and lignans, are known inhibitors of the human 17β-HSD
types 1 [14, 15]; flavonoids are plant-derived secondary metabolites, and most of them usually
have a similar structure with natural human steroid hormones. Some flavonoids and their
structural analogues could interfere with the process of estrogen biosynthesis by binding to
ERs and key enzymes [16, 17].
Current inhibitor-screening methods mostly employ 3H-labelled estrone as substrate using
free enzymes [18], with the following disadvantages: firstly, radioactivity exists in the detec-
tion method; secondly, free enzymes have some obvious flaws such as poor stability and
difficulties in recycling from the reaction system, resulting in high cost and waste of enzyme.
In view of the problems above, establishment of a novel screening method becomes a pressing
demand.
In the present study, we extracted 17β-HSD1 from human placenta and then it was
covalently immobilized onto silica particles with the help of glutaraldehyde [19]. First of
all, immobilized conditions including initial concentration of enzyme and reaction time
were optimized. Secondly, the properties including pH, thermal and storage stability of
immobilized enzymes were compared with those of free enzymes. The reusability of
immobilized enzymes was also evaluated. Finally, we employed androstenedione as the
substrate to analyse the changes of testosterone concentration before and after adding an
inhibitor, thereby screening inhibitors from potential active compounds based on LC-
TOF/MS. Apigenin was used for screening method validation since it was a known
inhibitor. Subsequently, we evaluated the inhibitory activities of seven flavonoids
(baicalin, hyperoside, isorhamnetin, kaempferol, puerarin, quercetin, wogonin), one
dihydroflavonoid (naringenin) and two structural analogues of flavonoids (bergenin,
resveratrol).

Appl Biochem Biotechnol
Materials and Methods
Materials
Human placenta was supplied by the Second Affiliated Hospital of Nanjing Medical
University (with the approval of the ethics committee in the Second Affiliated
Hospital of Nanjing Medical University). 3-Aminopropyltriethoxysilane (APTES),
androstenedione, estrone, testosterone, baicalin, hyperoside, naringenin and wogonin
were purchased from Aladdin Chemistry Co. (Shanghai, China). Bergenin,
isorhamnetin, kaempferol, puerarin, quercetin and resveratrol were obtained from the
National Institute for the Control of Pharmaceutical and Biological Products (Beijing,
China). Triphosphopyridine nucleotide (NADPH) was obtained from BioSharp Corpo-
ration (Hefei, China). Glutaraldehyde (GA, 25%, w/v, aqueous solution) was pur-
chased from Sinopharm Chemical Reagent Co., Ltd. (Shanghai, China). Deionized
water was purified through a PL5242 Purelab Classic UV (Pall Co., Ltd., USA).
Uniform nonporous silica (5 μm in diameter) was purchased from Kromasil Co.
(Sweden). Other chemicals were obtained from common commercial sources without
further purification.
Preparation of Human Placental 17β-HSD1
Placental microsomes were prepared using the method according to a previously
described procedure [7, 20]. The placenta was obtained directly after normal vaginal
delivery at local hospitals and immediately placed on ice. The cotyledon tissue was
severed from the chorionic plate, cut into pieces and rinsed thoroughly with sodium
phosphate buffer (50 mM, pH 7.4, 1% potassium chloride), then homogenized in a
Waring blender with three volumes of sodium phosphate buffer (50 mM, pH 7.4,
0.25 M sucrose) and centrifuged at 2500×g (30 min, 4 °C), and the supernatant was
subsequently centrifuged at 60,000×g (1 h, 4 °C). The washed microsomes (human
placental 17β-HSD1) were collected by the addition of ammonium sulphate to the
resulting supernatant, suspended in sodium phosphate buffer (50 mM, pH 7.4, 1 mM
ethylenediaminetetraacetic acid, 1 mM cysteine hydrochloride) and then stored at
−80 °C. The concentration of enzyme was determined by the Bradford method [21]
with bovine serum albumin (BSA) as standard protein.
Surface Modification of Nonporous Silica
Nonporous silica particles as carriers were silanized with APTES and activated using
GA before enzyme immobilization. Briefly, 1 mL APTES was added dropwise to an
emulsion of silica particles (2 g) in toluene (200 mL) under gentle stirring and the
mixture was refluxed at 90 °C for 24 h. The obtained precipitate was filtered, washed
thoroughly with toluene and acetone and dried at 105 °C overnight. Thereafter,
500 mg of amine-functionalized silica particles was dispersed in 45 mL of sodium
phosphate buffer (50 mM, pH 7.4), then 5 mL GA (25%, v/v) was added to the
mixture and the reaction was allowed to continue for 12 h at room temperature.
Afterwards, the obtained GA-activated silica particles were thoroughly washed with
deionized water and finally dried at 70 °C overnight.

Appl Biochem Biotechnol
17β-HSD1 Immobilization
Immobilization was achieved by the following procedures: Briefly, different volumes (20–
200 μL) of placenta microsomes (4.67 mg mL−1) were added to an emulsion of GA-activated
silica (50 mg) in 1 mL sodium phosphate buffer (50 mM, pH 7.4). Following stirring for 12 h
at 25 °C, the precipitate was washed with the immobilization buffer for three times to remove
nonbonded enzymes. Finally, the dry immobilized enzyme was recovered by rotation vacuum
concentrators at room tempurature. The loading amount (mg/g) was determined by subtracting
the residual protein content in the solution from the initial protein content before immobiliza-
tion using the Bradford assay.
The loading amount ðmg=gÞ ¼ ½ðC0V0–CtVtÞ=MŠ  100%
Herein, C0 is the initial concentration of enzyme (mg mL−1), V0 is the initial volume of
enzyme solution (mL), Ct is the concentration of enzyme in the total supernatant (mg mL−1)
and Vt is the total supernatant volume (mL). M is the weight of support (g).
Enzyme Activity and Inhibitory Assay
Catalytic activity of free and immobilized 17β-HSD1 was determined by the reduction of
androstenedione to testosterone with the assistance of the co-factor NADPH [11]. The
reaction was carried out at 37 °C in a final volume of 180 μL containing 10 μL placenta
enzyme solution, 150 μL androstenedione (35 μM) and 20 μL of NAPDH (25 mg mL−1)
for 10 h, then quenched with 50 μL acetonitrile and centrifuged at 8000×g for 5 min.
Twenty microlitres of the supernatant was injected into the Agilent 1100 series HPLC
system. The activity of immobilized 17β-HSD1 was measured at the same conditions,
except that 10 μL free enzyme solution was replaced by 10 μL buffer and 5 mg of
immobilized enzyme. The immobilized enzyme was collected by centrifugation at
8000×g for 5 min, washed three times and then stored at 4 °C for further use. Andro-
stenedione and testosterone were separated by a Zorbax Eclipse XDB-C18 column
(4.6 mm, 150 mm, 5 μm) and eluted isocratically at 30 °C with a mobile phase of
acetonitrile/water (60/40, v/v), containing 0.1% formic acid. The flow rate was
1 mL min−1. The wavelength for detection was 240 nm, and the recording time was
8 min. One unit of enzyme activity was defined as the amount of enzyme that reduced
1 pmol substrate per min at pH 8 and 37 °C.
For inhibitory assay, the procedure of experiment is the same as the immobilized
enzyme activity assay except for 10 μL of potential inhibitor at certain concentrations
instead of 10 μL buffer. Finally, after centrifugation, 20 μL of the supernatant was
injected into HPLC-TOF/MS. The peak area of testosterone could be obtained from
extracted ion chromatography (EIC, m/z 289.2162). The LC-MS analysis of degenerated
samples was performed on an Agilent 1260 series HPLC system connected to 6224 TOF
via ESI source. A Phenomenex Gemini-C18 column (2 mm, 50 mm, 5 μm) was used for
separation. The mobile phase was methanol/water (60/40, v/v) containing 0.1% formic
acid, and the analysis time was 2 min. The flow rate was 1 mL min−1, and the column
temperature was set at 30 °C. The MS signals were acquired in positive ionization mode.
The instrument settings were as follows: capillary temperature, 350 °C; drying gas,
10 L min−1; nebulizer, 35 psig; Vcap, 3500 V; fragmentor, 135 V; skimmer, 65 V; and

Appl Biochem Biotechnol
mass range recorded, m/z 110–1000. The enzyme inhibitory activity was calculated by
integrating the area values as follows:
Inhibition ð%Þ ¼ 100−½100  ðAiþ−Ai−Þ=ðA0þ−A0−ފ
where A0+, A0− ,Ai+ and Ai− are defined as the peak areas of 100% enzyme activity (only
the solvent with the enzyme), 0% enzyme activity (only the solvent without the enzyme),
a potential inhibitor (with the enzyme) and a blank (a potential inhibitor without the
enzyme).
Characterization
Scan electron microscopy (Hitachi SU8010, Japan) was used for determination of the mor-
phology of silica particles before and after immobilization, and the IR spectra was recorded by
Fourier transform infrared spectrometer (JASCO FT/IR-4100, Japan).
Results and Discussion
Characterization of Immobilized 17β-HSD1
17β-HSD1 was immobilized onto silica with a covalent method. The morphology of silica
particles before and after immobilization by SEM is shown in Fig. 1. The SEM micrographs
suggested a spherical shape and smooth surface of the GA-function silica (a3), which became
quite rough after immobilization because of the enzyme aggregates (b3), so the binding of enzyme
and carriers was examined [22]. Moreover, the placenta enzyme immobilized onto silica particles
was further confirmed by FT-IR spectroscopy (Fig. 2). The sharp adsorption bonds at 1107 cm−1
could clearly be seen in all spectra, which were contributed to the Si–O–Si stretching vibration
[23]. Compared with GA-activated silica particles, the adsorption bands (in the spectrum of
immobilized 17β-HSD1) at 3285 cm−1 could be assigned to N–H and O–H stretching vibration
[24], while bands occurring at 1654 and 1534 cm−1 in the spectrum were attributed to –CONH–
(amide I) and amide II, which arose from the peptide bonds that link the amino acid together [25],
indicating the existence of enzymes immobilized on the surface of silica particles.
Fig. 1 SEM image of GA-activated silica and immobilized 17β-HSD1 in different scales: a1 10 μm, a2 5 μm
and a3 1 μm of GA-activated silica; b1 10 μm, b2 5 μm and b3 1 μm of immobilized 17β-HSD1

Appl Biochem Biotechnol
Fig. 2 FT-IR spectra of silica,
GA-activated silica and
immobilized 17β-HSD1
Selection of Substrate and Incubation Time
As a key enzyme for regulating intracellular level of androgens and estrogens, the most
common catalytic substrates are estrone and androstenedione. Compared to androstenedione
as substrate, more additional products were produced according to the results of HPLC and
LC-TOF/MS when estrone was used as the substrate. It might be because estrone is also the
substrate of other enzymes in microsomes. In order to obtain accurate results, we chose
androstenedione as the substrate by adjusting the pH of enzymatic reaction to 8 to avoid the
competition of substrates among enzymes. It was proved that the environment was specific to
17β-HSD1. In addition, a very good response could be obtained when we used androstene-
dione as substrate compared to the pool mass response of estrogen, even EIC, as product peak
area signal. So, in order to develop a novel method to screen for inhibitors, androstenedione
was selected as an ideal substrate. The experimental data showed that the amount of testos-
terone tended to reach a plateau at 10 h as incubation time increased (Fig. 3). Therefore, 10 h
was selected as an optimal incubation time.
Fig. 3 The effect of incubation
time on 17β-HSD1 activity. All
assays were performed in triplicate

Appl Biochem Biotechnol
Effects of Silica Particle Size and Reaction Temperature
Different sizes of nonporous silica particles with diameters of 5, 15 and 30 μm were used as
supports. Immobilization on 5-μm silica particles resulted in the highest loading amount and
maximum enzyme activity compared to others (data not shown), mostly due to the increased
surface area per unit weight of support [26]. The immobilization temperature was carried out at
4, 10, 25 and 37 °C. The activity of the immobilized enzyme increased with the rise of
temperature and reached an activity maximum at 25 °C. As the temperature further increased,
the activity decreased because of inactivation of the enzyme at high temperature. According to
this observation (data not shown), 25 °C was chosen as an optimal temperature.
Effects of Initial Enzyme Concentration and Immobilization Time on Enzyme
Loading
The effects of initial enzyme concentration and immobilization time on the immobilization
process were investigated. The loading amount increased greatly with the enzyme concentra-
tion from 0.00 to 0.42 mg mL−1 then levelled off in the range of 0.42–0.78 mg mL−1. And then
the immobilization time was also investigated over 24 h. The loading amount initially
increased rapidly from 0 to 12 h and then reached a plateau up to 24 h, indicating that the
amount of enzyme on the support reaches a maximum value when the enzyme concentration
was 0.42 mg mL−1 (Fig. 4), and the immobilization time was more than 12 h (Fig. 5). After
immobilization, the amount of 17β-HSD1 immobilized onto the support was determined to be
96.25% of initial enzyme, which was giving a loading amount of 8.99 mg in 1 g carrier under
optimal conditions. At the same time, the immobilized enzyme could maintain about 96.77%
of the activity of initial enzyme.
Effects of pH and Temperature on Enzyme Activity
The optimal pH of free enzyme was 7.4; immobilization on GA-activated silica particles did
not alter the optimum pH (Fig. 6). There was no significant difference between the
Fig. 4 Effect of initial enzyme
concentration on enzyme loading.
Immobilization conditions: 20–
200 μL 17β-HSD1, 5 mg GA-
activated silica in 1 mL phosphate
buffer (50 mM, pH 7.4, t = 25 °C).
All assays were performed in
triplicate

Appl Biochem Biotechnol
Fig. 5 Effect of immobilization
time on enzyme loading.
Immobilization conditions: 100 μL
17β-HSD1, 5 mg GA-activated
silica in 1 mL phosphate buffer
(50 mM, pH 7.4, t = 25 °C). All
assays were performed in triplicate
immobilized and free enzyme in terms of pH range. Both of them were active in the pH range
of 5–9, but immobilized enzyme had better activity than free one at pH 5 and 9, indicating that
the immobilized enzymes increased resistance against denaturation after immobilization.
However, another product was produced during incubation besides testosterone at pH 7.4.
This is because placenta microsomes are a mixture of different proteins, and the neutral
environment is closely mimicking that of the human body; some enzymes in microsomes
remain active and catalyse different reactions. Given all this, further study was carried out at
pH 8 because of the specific environment to 17β-HSD1 and good activity.
The maximal activity of free and immobilized enzyme was observed to be the same at
37 °C (Fig. 7). However, the immobilized enzyme exhibited greater activity at higher
temperatures compared to free enzyme, and the activity of free enzyme declined significantly
over 45 °C and lost approximately 70% at 65 °C. In contrast, the activity of immobilized
enzyme remained stable from 45 to 55 °C and lost 58% at 70 °C, indicating that immobilized
enzyme could be used in a wider temperature range for practical application.
Fig. 6 Effect of pH on enzyme
activity. The pH stability of free
and immobilized enzymes was
compared by immersing them in
buffers of varying pH for 1 h at
37 °C. The pH was adjusted using
50 mM citrate buffer (pH 3–5),
50 mM sodium phosphate buffer
(pH 6–8), 50 mM Tris–HCl buffer
(pH 9) and NaHCO3/NaOH buffer
(pH 10–11). All assays were
performed in triplicate

Appl Biochem Biotechnol
Fig. 7 Effect of temperature on
enzyme activity. The activity of
free and immobilized enzymes was
investigated at various
temperatures from 20 to 70 °C. All
assays were performed in triplicate
Reusability and Storage Stability of Immobilized Enzyme
In order to investigate the reusability of immobilized enzyme, the activities were evaluated in
several cycles. After each cycle, the immobilized enzyme was removed by centrifugation,
washed with sodium phosphate buffer (50 mM, pH 8.0) for three times and then used for the
next assay. It could remain around 36% of the initial activity after four consecutive operations.
The repeated washing and conformational changes of enzyme after each catalytic reaction
probably lead to the loss of its activity. The immobilized enzyme also exhibited improved
storage stability (37% activity retained) at room temperature after 4 days while the free enzyme
almost completely lost its activity under the same conditions. When stored at 4 °C, the
immobilized enzyme nearly retained its initial activity within 30 days while the free enzyme
lost about 48% of its activity (Fig. 8).
Fig. 8 Storage stability of free
enzyme and immobilized enzyme
at room temperature and 4 °C. All
assays were performed in triplicate

Appl Biochem Biotechnol
Fig. 9 Graphical representation of
the IC50 values of apigenin. The
initial enzyme activity
(immobilized 17β-HSD1,
685.8 U/g; free enzyme, 78.83 U/
mg) is taken as 100%. All assays
were performed in triplicate
Screening of 17β-HSD1 Inhibitors
Apigenin, as an active inhibitor towards 17β-HSD1, was reported by literatures [15, 27] and
employed to evaluate the inhibitor-screening method. As is seen in Fig. 9, various concentrations
of apigenin solution from 50 nM to 2 μM were used to study the efficiency of inhibition, and the
IC 50 value was 291 nM, which was close to the reported datum of 300 nM in literature [15].
(1)baicalin[Root of Scutellaria
(2)bergenin[Bergenia
purpurascens;B.crassifoloa;Astilbe
macroflora;etc]
(3)hyperoside[Hypericum
(4)isorhamnetin[Fruit of
baicalensis]
perforatum L.]
Hippophae fhamnoides L.]
(5)kaempferol[Rhizome of
(6)naringenin[The core of the fruit of
(7)puerarin[Root of Pueraria
(8) quercetin[Bark and leaf of
Kaempferia galangal L.]
Amacardi-um occidentale L.]
lobata Willd. Ohwi]
Quercus iberica]
(9)resveratrol[Root and Rhizome
of Polygonum cuspidatum Sieb. et
Zucc.]
(10)wogonin[Root of Scutellaria
baicalensis Georgi]
Fig. 10 The structure of 10 compounds for inhibitor screening. Relative plants are included in square brackets

Appl Biochem Biotechnol
Fig. 11 Inhibition efficiency of
different compounds at a
concentration of 25 μM. The initial
activity of immobilized 17β-
HSD1, 685.8 U/g, is taken as
100%. All assays were performed
in triplicate
In this study, we have evaluated the inhibitory activities of seven flavonoids (baicalin,
hyperoside, isorhamnetin, kaempferol, puerarin, quercetin, wogonin), one dihydroflavonoid
(naringenin) and two structural analogues of flavonoids (bergenin, resveratrol) using the
inhibitor-screening method. The structures of these compounds and relative plants are shown
in Fig. 10. After incubation, Fig. 11 shows that 10 compounds could inhibit the activity of 17β-
HSD1 at a concentration of 25 μM and 6 of them inhibit the activity over 50%. The peak area of
testosterone from EIC with wogonin (25 μM) and without any inhibitors is shown in Fig. 12.
Fig. 12 The EIC (289.2162) of product testosterone. a1 no inhibitor; a2 with inhibitor (wogonin at 25 μM); a3
the spectrum of background subtraction

Appl Biochem Biotechnol
The results herein reported demonstrate that the screening method based on LC-TOF/MS
could be a useful tool for the screening of 17β-HSD1 inhibitors.
Conclusions
In this study, 17β-HSD1 was successfully immobilized onto GA-activated silica and the
immobilized conditions were optimized. Moreover, the increased pH, thermal, storage and
operational stability indicated the great promise of nonporous silica particles for 17β-HSD1
immobilization. In conclusion, the immobilized enzyme based on LC-TOF/MS, coupled with
future experiments, is expected to facilitate the setting up of a low-cost high-throughput
system.
Acknowledgements The authors gratefully acknowledge the financial support for this work from the Natural
Science Foundation of Jiangsu Province (No. BK20130654) and the National Natural Science Foundation of PR
China (No. 81402900).
Compliance with Ethical Standards
Conflict of Interest The authors declare that they have no conflict of interest.
References
1. Yan, L., Liu, J., Liu, X., Xing, K., Yun, W., Li, F., & Yao, L. (2006). Resveratrol-induced cell inhibition of
growth and apoptosis in MCF7 human breast cancer cells are associated with modulation of phosphorylated
akt and caspase-9. Applied Biochemistry & Biotechnology, 135, 181–192.
2. Fournier, D., Poirier, D., Mazumdar, M., & Lin, S. X. (2008). Design and synthesis of bisubstrate inhibitors
of type 1 17β-hydroxysteroid dehydrogenase: overview and perspectives. European Journal of Medicinal
Chemistry, 43, 2298–2306.
3. Aka, J. A., Mazumdar, M., Chen, C. Q., Poirier, D., & Lin, S. X. (2010). 17beta-hydroxysteroid dehydro-
genase type 1 stimulates breast cancer by dihydrotestosterone inactivation in addition to estradiol produc-
tion. Molecular Endocrinology, 24, 832–845.
4. Kasai, T., Shozu, M., Murakami, K., Segawa, T., Shinohara, K., Nomura, K., & Inoue, M. (2004). Increased
expression of type I 17beta-hydroxysteroid dehydrogenase enhances in situ production of estradiol in
uterine leiomyoma. Journal of Clinical Endocrinology & Metabolism, 89, 5661–5668.
5. Jarabak, J., Adams, J. A., Williamsashman, H. G., & Talalay, P. (1962). Purification of a 17beta-
hydroxysteroid dehydrogenase of human placenta and studies on its transhydrogenase function. Journal
of Biological Chemistry, 237, 345–357.
6. Adams, J. A., Jarabak, J., & Talalay, P. (1962). The steroid specificity of the 17β-hydroxysteroid dehydro-
genase of human placenta. Journal of Biological Chemistry, 237, 3069–3073.
7. Langer, L. J., & Engel, L. L. (1958). Human placental estradiol-17 beta dehydrogenase. I. Concentration,
characterization and assay. Journal of Biological Chemistry, 233, 583–588.
8. Zhu, S. J., Li, Y., Li, H., Wang, Y. L., Xiao, Z. J., Vihko, P., & Piao, Y. S. (2002). Retinoic acids promote the
action of aromatase and 17beta-hydroxysteroid dehydrogenase type 1 on the biosynthesis of 17beta-
estradiol in placental cells. Journal of Endocrinology, 172, 31–43.
9. Breton, R., Housset, D., Mazza, C., & Fontecilla-Camps, J. C. (1996). The structure of a complex of human
17β-hydroxysteroid dehydrogenase with estradiol and NADP + identifies two principal targets for the
design of inhibitors. Structure, 4, 905–915.
10. Shi, R., & Lin, S. X. (2004). Cofactor hydrogen bonding onto the protein main chain is conserved in the
short chain dehydrogenase/reductase family and contributes to nicotinamide orientation. Journal of
Biological Chemistry, 279, 16778–16785.

Appl Biochem Biotechnol
11. Puranen, T., Poutanen, M., Ghosh, D., Vihko, R., & Vihko, P. (1997). Origin of substrate specificity of
human and rat 17β-hydroxysteroid dehydrogenase type 1, using chimeric enzymes and site-directed
substitutions 1. Endocrinology, 138, 3532–3539.
12. Lin, S.-X., Shi, R., Qiu, W., Azzi, A., Zhu, D.-W., Al Dabbagh, H., & Zhou, M. (2006). Structural basis of
the multispecificity demonstrated by 17β-hydroxysteroid dehydrogenase types 1 and 5. Molecular &
Cellular Endocrinology, 248, 38–46.
13. Fournier, D., Poirier, D., Mazumdar, M., & Lin, S. X. (2008). Design and synthesis of bisubstrate inhibitors
of type 1 17beta-hydroxysteroid dehydrogenase: overview and perspectives. European Journal of Medicinal
Chemistry, 43, 2298–2306.
14. Bail, J. C. L., Champavier, Y., Chulia, A. J., & Habrioux, G. (2000). Effects of phytoestrogens on
aromatase, 3β and 17β-hydroxysteroid dehydrogenase activities and human breast cancer cells. Life
Sciences, 66, 1281–1291.
15. Poirier, D. (2003). Inhibitors of 17β-hydroxysteroid dehydrogenases. Current Medicinal Chemistry, 10,
453–477.
16. Michiels, P. J., & Cstephan, L. (2009). Ligand-based NMR spectra demonstrate an additional phytoestrogen
binding site for 17beta-hydroxysteroid dehydrogenase type 1. Journal of Steroid Biochemistry & Molecular
Biology, 117, 93–98.
17. Deluca, D., Krazeisen, A., Breitling, R., Prehn, C., Möller, G., & Adamski, J. (2005). Inhibition of 17beta-
hydroxysteroid dehydrogenases by phytoestrogens: comparison with other steroid metabolizing enzymes.
Journal of Steroid Biochemistry & Molecular Biology, 93, 285–292.
18. Starčević, Š., Turk, S., Brus, B., Cesar, J., Rižner, T. L., & Gobec, S. (2011). Discovery of highly potent,
nonsteroidal 17β-hydroxysteroid dehydrogenase type 1 inhibitors by virtual high-throughput screening. The
Journal of Steroid Biochemistry and Molecular Biology, 127, 255–261.
19. Zanin, G. M., & Moraes, F. F. D. (1998). Thermal stability and energy of deactivation of free and
immobilized amyloglucosidase in the saccharification of liquefied cassava starch. Applied Biochemistry &
Biotechnology, 70-72, 383–394.
20. Villee, C. A., & Gordon, E. E. (1955). Further studies on the action of estradiol in vitro. Journal of
Biological Chemistry, 216, 203–214.
21. Kruger, N. J. (1994) In Basic protein and peptide protocols (pp. 9–15) Springer.
22. Mohamad, N. R., Marzuki, N. H., Buang, N. A., Huyop, F., & Wahab, R. A. (2015). An overview of
technologies for immobilization of enzymes and surface analysis techniques for immobilized enzymes.
Biotechnology Biotechnological Equipment, 29, 205–220.
23. Petkova, G. A., Záruba, K., & Král, V. (2012). Synthesis of silica particles and their application as supports
for alcohol dehydrogenases and cofactor immobilizations: conformational changes that lead to switch in
enzyme stereoselectivity. Biochimica et Biophysica Acta (BBA)-Proteins and Proteomics, 1824, 792–801.
24. Shen, H., Pan, S., Zhang, Y., Huang, X., & Gong, H. (2012). A new insight on the adsorption mechanism of
amino-functionalized nano-Fe 3 O 4 magnetic polymers in Cu (II), Cr (VI) co-existing water system.
Chemical Engineering Journal, 183, 180–191.
25. Chang, Q., & Tang, H. (2014). Immobilization of horseradish peroxidase on NH2-modified magnetic
Fe3O4/SiO2 particles and its application in removal of 2, 4-dichlorophenol. Molecules, 19, 15768–15782.
26. Klein, M. P., Nunes, M. R., Rodrigues, R. C., Benvenutti, E. V., Costa, T. M., Hertz, P. F., & Ninow, J. L.
(2012). Effect of the support size on the properties of β-galactosidase immobilized on chitosan: advantages
and disadvantages of macro and nanoparticles. Biomacromolecules, 13, 2456–2464.
27. Le Bail, J., Laroche, T., Marre-Fournier, F., & Habrioux, G. (1998). Aromatase and 17β-hydroxysteroid
dehydrogenase inhibition by flavonoids. Cancer Letters, 133, 101–106.
