Title: Ring-restricted N-nitrosated rhodamine as a green-light
triggered, orange-emission calibrated and fast-releasing nitric
oxide donor
Authors: Haihong He, Tingting He, Ziqian Zhang, Xiu Xu,
Huibin Yang, Xuhong Qian, Youjun Yang
PII:
DOI:
Reference:
S1001-8417(18)30345-0
https://doi.org/10.1016/j.cclet.2018.08.019
CCLET 4640
To appear in:
Chinese Chemical Letters
Please cite this article as: He H, He T, Zhang Z, Xu X, Yang H, Qian X, Yang Y,
Ring-restricted N-nitrosated rhodamine as a green-light triggered, orange-emission
calibrated and fast-releasing nitric oxide donor, Chinese Chemical Letters (2018),
https://doi.org/10.1016/j.cclet.2018.08.019
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Communication
Ring-restricted N-nitrosated rhodamine as a green-light triggered, orange-emission calibrated and
fast-releasing nitric oxide donor
b
b
c
b
d
a,b
a,b,*
Haihong He , Tingting He , Ziqian Zhang , Xiu Xu , Huibin Yang , Xuhong Qian , Youjun Yang
a
State Key Laboratory of Bioreactor Engineering, East China University of Science and Technology, Shanghai 200237, China
b
Shanghai Key Laboratory of Chemical Biology, School of Pharmacy, East China University of Science and Technology, Shanghai 200237, China
Guangxi Scientific Research Center of Traditional Chinese Medicine, Guangxi University of Chinese Medicine, Nanning 530200, China
c
d
State Key Laboratory of the Discovery and Development of Novel Pesticide, Shenyang Sinochem Agrochemicals R&D Co., Ltd., Shenyang 110021, China
*
Corresponding author.
E-mail address: youjunyang@ecust.edu.cn (Y. Yang).
Graphical abstract
Locking the N-nitrosamine coplanar with the fluorophore facilitates photo-triggered NO release.
ARTICLE INFO
ABSTRACT
Article history:
Received
Received in revised form
Accepted
Nitric oxide (NO) donors are versatile tools for nitric oxide biology. The biological
response of NO is dependent on the transient concentration and the sustained duration.
N-nitrosated rhodamines are photo-triggered and photo-calibrated NO donors. We
recently discovered that suppression of the dihedral angle between the N-nitroso
fragment with the rhodamine scaffold facilitates NO release. Inspired by this discovery,
Available online
we developed
a fast-releasing NO donor (NOD575) suitable for biological
Keywords: NO donor
Photo-trigger
applications, e.g., the pulmonary arterial smooth muscle cells (PASMCs).
Photo-calibrate
Platelet aggregation inhibition
Antimicrobial
Release of nitric oxide (NO) in a spatially or temporally controlled fashion facilitates investigation of the mechanism of NO in
biological processes [1] and can also be harnessed as therapeutic or biomanipulative applications [2,3]. Compared to various chemo-
triggers, e.g., enzymes [4], reducing agents [5], oxidative species [6] and nucleophiles [7], light is particularly desirable due to its
versatility, non-invasiveness, and feasibility for biological settings. The flux and the dose of NO are critical to its biological outcome [8].
Modulating the intensity of the photo-irradiation may offer a convenient way to adjust the photo-decomposition rate of our photo-
triggered and photo-calibrated NO donors. However, in cases where the light intensity is not readily adjusted, NO donors of varying
releasing kinetics could be a desirable alternative.
The existing photo-triggered NO donors include photo-caged spontaneous NO donors [9], ortho-substituted nitrobenzene [10], and
metal-nitroso complexes [11]. One limitation of the aforementioned photo-triggered NO donors is the lack of a mechanism to calibrate
the dose and kinetics of NO release. Commercial NO probes were employed to monitor the NO generation characteristics. However,
they detect NO by scavenging NO and therefore prevent NO from eliciting its biological functions. We have recently devised a series of
NO donors, which are N-nitrosated push-pull fluorophores (Fig. 1) and addressed this dilemma [12-14]. Their release of NO is not only
triggered by light, but also calibrated by simultaneous release of a fluorophore, whose fluorescence signifies the release of NO in a real-
time fashion. In particular, NOD560 is interesting because it can be photo-activated by a wide-selection of laser lines, in the spectral
range of 375-556 nm and the resulting rhodamine dye is a superior fluorophore for imaging-based applications [14-19]. The only
drawback is its relatively slow kinetics. Therefore, development of such NO donors with accelerated NO release rate is an important
research topic.
N-Nitrosated secondary amines have been sketched in its N-nitroso form (a, Fig. 1) following the convention. However, we note that
the diazonium oxide (b, Fig. 1) is in fact the major contributing resonance structure for N-nitrosamine. Upon photoexcitation of the
structure b, the intramolecular charge transfer occurs and the molecule adopts the structure a. The single bond between the two nitrogen

atoms (highlighted in blue) in the form a homolyzes to release NO and an anilinyl radical. Based on the above analysis, it becomes
obvious that a weak N-N bond is the key to high homolysis tendency. In NOD545 [12], NOD550 [13], and NOD560 [14], the nitrosamine
moiety and the chromophore are nearly orthogonal to each. Reducing the dihedral angle in between is expected to effectively promote
the electronic delocalization from the nitrogen atom to the dye scaffold, weaken the N-N bond and hence enhance NO release kinetics.
Therefore, we designed a novel NO donor with the nitrosamine moiety locked coplanar with the dye scaffold.
2
-(4-(Diethylamino)-2-hydroxybenzoyl)benzoic acid (1) was condensed with 1,2,3,4-tetrahydroquinolin-7-ol (2) in concentrated
o
2 4
H SO at 100 C for 24 h to furnish the desired rhodamine dye (3) in a 91% yield. Compound 3 was then nitrosated to afford NOD575
in a 94% yield. X-ray diffraction reveals that NOD575 is in its lactone form in solid state. The dihedral angle between the nitrosamine
o
and the rhodamine dye scaffold was measured to be of 12.66 .
The UV-vis absorption and fluorescence properties of both NO575 and 3 were acquired in neutral phosphate buffer with 1% DMSO
as co-solvent. The maximal absorption of NOD575 is at 510 nm with two shoulder peaks at 480 nm and 545 nm, respectively, suggesting
NOD575 exists predominantly in its ring-open form (Fig. 2). NOD575 is not fluorescent. In comparison, the potential decomposition
product is highly absorbing at 545 nm and strongly fluorescent with an emission maximum at 575 nm ( = 0.58).
The solution of NOD575 (10 μmol/L) in phosphate buffer (50 mmol/L, pH 7.4) with 1% DMSO was photoirradiated with a laser at
5
32 nm. The UV-vis absorption and fluorescence emission spectra were recorded intermittently. The absorbance band of NOD575
gradually decreases with respect to duration of photo-irradiation, the absorption and emission of the product increases concomitantly.
The decomposition product was unambiguously confirmed to be 3, by NMR and MS. It took ca. 100 s for its decomposition to complete,
compared to ca. 2300 s of NOD560. NOD575 expectedly exhibits a much improved decomposition kinetics compared to NOD560. This
confirms our original hypothesis that reducing dihedral angle can weaken N-N single bond and facilitates homolysis.
Denitrosation of N-nitrosamines may occur in reductive environment [20]. We have also previously discovered that reducing agents
may accelerate the decomposition of NO donors. Therefore, the chemostability of NOD575 (10 μmol/L) was tested by incubation with
biological thiols and bio-relevant reducing agents, i.e., cysteine, glutathione, and ascorbic acid, in phosphate buffer (50 mmol/L at pH
7
.4) with 1% DMSO in the dark at room temperature. The absorbance of each solution at 545 nm remained unchanged in 24 h, suggesting
NOD575 are sufficiently chemostable for practical biological applications (Fig. S3 in Supporting information). Photodecomposition of
NOD575 was then tested in the presence of these three biological relevant reducing agents, e.g., resveratrol, cysteine, and ascorbic acid.
Fluorescence turn-on was dramatically improved and completed in as short as 20 s (Fig. 5).
The potentials of NOD575 for in vitro applications were tested. Pulmonary artery smooth muscle cells (PASMCs) were incubated
with NOD575 (20 μmol/L) for 20 min in dark. PASMCs were then washed with phosphate buffer for 3 times. The fluorescence image
before and after photolysis by green laser was acquired by a confocal microscopy. Fig. 6 indicated that cells showed no fluorescence
without irradiation. After exposure to green light for 60 s, there existed strong red fluorescence from cells. These results showed that
NOD575 could diffuse into PASMCs and it could release NO in vitro and the rhodamine dye generated in situ could be harnessed for
imaging purposes.
In conclusion, we have designed and synthesized a novel NO donor (NOD575) following the principle of N-nitroso
push-pull dyes. It has exhibited photo-triggered release of NO upon irradiation by a green laser line at 532 nm. Also,
the release of NO is accompanied by the liberation of a rhodamine fluorophore, whose fluorescence emission (em
=
o
5
75 nm) can be used as a self-calibration mechanism for the NO release. NOD575 has a small dihedral angle of 12.67
between the N-nitroso moiety and the rhodamine scaffold by ring-closure. Such a rational design is engineered into
the molecule to weaken the N-N bond and facilitate its hemolysis upon photo-irradiation. Therefore, a short exposure
of ca. 100 s is sufficient to allow complete photolysis, compared to 2300 s of NOD560, a similar analog with a dihedral
o
angle of 82 . Presence of biological thiols or reducing agents does not induce the decomposition of NOD575 in dark,
but can greatly accelerate its photodecomposition. Last, NOD575 is membrane-permeable and compatible for in vitro
biological studies.
Acknowledgments
The work is financially supported by the National Natural Science Foundation of China (No. 21572061) and the Fundamental Research
Funds for the Central Universities (No. WY1516017).
References
[
[
[
[
[
[
[
[
[
[
[
[
[
[
1] P.G. Wang, M. Xian, X. Tang, et al., Chem. Rev. 102 (2002) 1091-1134.
2] P.G. Wang, T.B. Cai, N. Taniguchi, Nitric Oxide Donors: For Pharmaceutical and Biological Applications, Wiley-VCH, New York, 2005.
3] M.R. Miller, I.L. Megson, Br. J. Pharmacol. 151 (2007) 305-321.
4] K. Sharma, A. Iyer, K. Sengupta, H. Chakrapani, Org. Lett. 15 (2013) 2636-2639.
5] H. Chakrapani, A.E. Maciag, M.L. Citro, L.K. Keefer, J.E. Saavedra, Org. Lett. 10 (2008) 5155-5158.
6] A.T. Dharmaraja, G. Ravikumar, H. Charkrapani, Org. Lett. 16 (2014) 2610-2613.
7] P.J. Shami, J.E. Saavedra, L.Y. Wang, et al., Mol. Cancer Ther. 2 (2003) 409-417.
8] V. Calabrese, C. Mancuso, M. Calcani, et al., Nat. Rev. Neurosci. 8 (2007) 766-775.
9] M. Blangetti, A. Fraix, L. Lazzarato, et al., Chem.-Eur. J. 23 (2017) 9026-9029.
10] K. Kitamura, M. Kawaguchi, N. Ieda, N. Miyata, H. Nakagawa, ACS Chem. Biol. 11 (2016) 1271-1278.
11] A.C. Roveda, H. de Fazio Aguiar, K.M. Miranda,C.C. Tadini, D.W. Franco, J. Mater. Chem. B 2 (2014) 7232-7242.
12] Z. Zhang, J. Wu, Z. Shang, et al., Anal. Chem. 88 (2016) 7274-7280.
13] H. He, Z. Ye, Y. Xiao, et al., Anal. Chem. 90 (2018) 2164-2169.
14] H. He, Y. Liu, Z. Zhou, et al., Free Radic. Biol. Med. 123 (2018) 1-7.

[
[
[
[
[
[
15] P. Ning, W. Wang, M. Chen, Y. Feng, X. Meng. Chin. Chem. Lett. 28 (2017) 1943-1951.
16] S. Ma, L. Li, M. She, Y. Mo, J. Li, Chin. Chem. Lett. 28 (2017) 2014-2018.
17] S. Leng, Q.L. Qiao, Y. Gao, L. Miao, Z.C. Xu, Chin. Chem. Lett. 28 (2017) 1911-1915.
18] X.M. Li, R.R. Zhao, Y. Yang, X.W. Lv, Y. Zhou, Chin. Chem. Lett. 28 (2017) 1258-1261.
19] D. Wang, Z. Wang, Q. Zhan, et al. Engineering 3(2017) 402-408.
20] D.A. Wink, J.A. Cook, S.Y. Kim, et al., J. Biol. Chem. 272 (1997) 11147-11151.
Fig. 1. (A) The resonance structures and NO-releasing mechanism of N-nitrosated push-pull dyes. (B) Three representative NO donors of this class.
Fig. 2. (A) Dihedral angles between the nitrosamine (orange) and the dye scaffold (green). (B) The synthesis and photo-decomposition of NOD575.
Fig. 3. The two different views of the crystal structure of NOD575.

A1.00 Spectral changes of NOD575
6
6
6
5
6
6
6
5
3.2x10
2.4x10
1.6x10
8.0x10
0.0
B 3.2x10
2.4x10
Photolysis kinetics of NOD575
Absorption Emission
ex= 545 nm, em= 575 nm
0
0
0
0
.75
.50
.25
.00
1.6x10
8.0x10
0.0
3
00 400 500 600 700
0
100
200
300
400
Wavelength (nm)
Time (s)
Fig. 4. (A) UV-vis absorption spectral and fluorescence emission spectral changes of NOD575 solutions upon photo-irradiation by 532 nm. (B) The enhancement
of emission intensity at 575 nm of NOD575 solution with respect to the duration of photo-irradiation.
6
Changes of fluorescence intensity with
reductant NOD575 (10 mol/L) at pH 7.4
3
2
1
7
.0x10
.3x10
.5x10
.5x10
(ex= 545 nm, em= 570 nm)
6
6
5
NOD575 + None
+ Resveratrol
+
+
Cysteine
Ascorbic acid
0
.0
0
50
100
Time (s)
150
200
Fig. 5. Spectral monitoring of the photolysis of NOD575 with 532 nm in phosphate buffer (50 mmol/L, pH 7.4) with 1% DMSO in the presence of various
indicated reducing agents.
A
B
C
Fig. 6. Confocal fluorescence imaging of PASMCs incubated with 20 μmol/L NOD575 for 20 min. (A) Bright-field image. (B) Fluorescence image before
irradiation. (C) Fluorescence image after 60 s’ photo-irradiation. Scale bar: 10 μm. λex = 488 nm, λem =555-650 nm.
