An efficient protocol for the synthesis of brominated norbornene, norbornadiene,
and benzonorbornadiene
Selçuk EŞSİZ∗,
Department of Chemistry, Faculty of Science, Atatürk University, Erzurum, Turkey
Received: 05.09.2018
•
Accepted/Published Online: 28.11.2018
•
Final Version: 05.02.2019
Abstract: An efficient protocol for the synthesis of 2-bromonorbornene, 2-bromonorbornadiene, 2-bromoben- zonor-
bornadiene, 2,3-dibromonorbornene, 2,3-dibromonorbornadiene, and 2,3-dibromobenzonorbornadiene in good yields has
been developed. 1,2-Dibromotetrachloroethane is used as the brominating agent for these reactions. The results are
discussed in comparison with alternative methods in the literature.
Key words: 2,3-Dibromonorbornene, 2,3-dibromonorbornadiene, 2,3-dibromobenzonorbornadiene, 1,2-dibromotetrach-
loroethane
1. Introduction
The reactivity of bicyclo[2.2.1]alkenes is higher than that of other alkenes because they have a unique geometry,
and they are important compounds in synthetic organic chemistry (Figure). The photoisomerization reaction of
norbornadiene derivatives to quadricyclanes is reported to be of potential use for molecular solar-thermal energy
1−3
storage systems and molecular photoswitches.
The traditional method for forming substituted bicycles in-
volves the Diels–Alder reaction, but this method is limited. Therefore, many groups have investigated alternative
4−6
methods for the synthesis of substituted bicyclo[2.2.1]alkenes.
of applications in science.
Bicyclo[2.2.1]alkenes have found a wide range
7−14
One of the easiest ways to derivatize bicyclo[2.2.1]alkenes is to use their bromi-
nated derivatives. Therefore, in this work, we aimed to efficiently synthesize 2-bromobicyclo[2.2.1]alkenes using a
mixture of t-BuOK/n-BuLi and 1,2-dibromotetrachloroethane (DBTCE) and 2,3-dibromobicyclo[2.2.1]alkenes
using lithium diisopropylamide (LDA) and DBTCE.
Figure. Structure of bicyclics.
∗Correspondence: sessiz@atauni.edu.tr
319
This work is licensed under a Creative Commons Attribution 4.0 International License.

EŞSİZ/Turk J Chem
2. Results and discussion
Our strategy, which involves trapping of metallated bicyclics with DBTCE, leads to the formation of 2-bromo or
2,3-dibromobicyclics (Scheme 1). In the first step, a synthetic procedure modified from that reported by Szeimies
15
14,16
15−17
was used. To obtain monobromides 2,
5,
and 8,16,18n-BuLi was added to a solution of the alkene
and t-BuOK in THF, followed by trapping with DBTCE. In a further step, to deprotonate monobromides, LDA
was added to a solution of monobromide in THF and the solution was treated with DBTCE to give dibromides
14,16
15−17,19
16
3,
6,
and 9 (Scheme 1).
Scheme 1. Synthesis of 2- and 2,3-brominated bicyclo[2.2.1]alkenes.
To deprotonate the alkenes (Scheme 2), in the first step, n-butyl lithium was slowly added to a solution
of alkenes and potassium tert-butoxide in THF to give a yellow solution of the potassium coordinated bicyclic
alkenes 10. When the solution of 10 was reacted with DBTCE in THF, the desired monobromides 2, 5,
and 8 were successfully obtained in 52%, 56%, and 45% yields, respectively. Similarly, in the second step,
monobromoalkenes were added to the solution of LDA, which is easily prepared by addition of n-BuLi to the
solution of diisopropylamine in THF, and to the obtained solution of the lithium coordinated deprotonated
bicyclic alkenes 11 was added a solution of DBTCE in THF. Dibromides 3, 6, and 9 were obtained in 75%,
77%, and 85% yields, respectively.
Scheme 2. Reaction steps.
Tam et al. and Moth-Poulsen et al. reported that the yield of 2,3-dibromonorbornadiene (6) based
17
19
17
19
on t-BuOK was 65%
and 37%
and based on norbornadiene (4) was 16%
and 15%,
respectively.
In this study, the yield of 2,3-dibromonorbornadiene (6) is 43% for two steps. In a previous study, the
starting material, norbornadiene (4), was also used over stoichiometric amounts. The bromination reaction
of norbornadiene (4) to obtained 2,3-dibromonorbornadiene resulted in formation of 2-bromonorbornadiene (5)
17
and 2,3-dibromonorbornadiene (6). The synthesis of brominated norbornene and benzonorbornadiene was
limited via this strategy in the literature. Ryu et al. also reported that DBTCE was an excellent brominating
20
agent compared to Br2 and NBS and employed it as an electrophile for α-bromination reaction of ketones.
In conclusion, in the present study, the yield of products is high compared to the previously published
procedure. The advantages of this methodology are that it has prevented the use of overstoichiometric amounts
320

EŞSİZ/Turk J Chem
of alkene, it represented relatively good yields, and it obtained a single product for dibromides compared to
previous methods. An alternative method has been developed for the synthesis of brominated norbornenes and
benzonorbornadienes. This method can be also applied for bromination of other bicyclics to their corresponding
bromides.
3. Experimental
All reactions were carried out under argon using Schlenk techniques. The reaction flask was heated at reduced
pressure with a heat gun and flushed with argon. All solvents were dried and distilled before use. Column
chromatography was performed using silica gel 60 (Merck) and chromatography was carried out using petroleum
ether as eluent. All analytical data were consistent with those of previous reports.
3.1. General method for monobromides
A 50-mL well-dried Schlenk flask was charged with argon through a Schlenk line. To a solution of alkenes (20.0
mmol) and KOt-Bu (2.5 g, 22.3 mmol) in THF (20 mL), n−BuLi in hexane (2.5 M, 8.8 mL, 22.0 mmol) was
added dropwise at –78 °C over 1 h. The mixture was stirred at –40 °C for 1 h and cooled again to –78 °C. A
solution of DBTCE (6.51 g, 20.0 mmol) was added over 15 min and the mixture was stirred at –60 °C for 1 h.
The reaction mixture was allowed to come to RT and stirred for 2 h. The reaction mixture was quenched with
saturated ammonium chloride (20 mL), the aqueous layer was extracted with diethyl ether (3 ×20 mL), and the
combined organic layers were washed with brine (25 mL), dried over Na2 SO4 , and concentrated under vacuum.
The residue was purified by column chromatography (silica gel, 50 g, petroleum ether) to give the product.
1
2-Bromonorbornene (2): H NMR (400 MHz, CDCl3)δ = 6.01 (d, J = 3.0 Hz, 1H), 2.87–2.91 (m, 2H),
13
1.65–1.69 (m, 2H), 1.60 (m, 1H), 1.10–1.20 (m, 3H). C NMR (100 MHz, CDCl3)δ = 134.8, 125.6, 50.4, 48.1,
44.0, 25.9, 24.3.
1
2-Bromonorbornadiene (5): H NMR (400 MHz, CDCl3)δ = 6.89 (dd, J = 5.2 and 2.9 Hz, A part of
AB system, 1H), 6.77 (dd, J = 5.2 and 2.9 Hz, A part of AB system, 1H), 6.64 (d, J = 3.3 Hz, 1H), 3.61 (m,
1H), 3.48 (m, 1H), 2.26 (dt, J = 6.0 and 1.5 Hz, A part of AB system, 1H), 2.07 (dt, J = 6.0 and 1.8 Hz, A
13
part of AB system, 1H). C NMR (100 MHz, CDCl3)δ = 143.1, 142.0, 139.8, 136.9, 74.1, 58.5, 51.8.
1
2-Bromobenzonorbornadiene (8): H NMR (400 MHz, CDCl3) δ = 7.33 (dd, J = 6.0 and 2.0 Hz, 1H),
7.22 (dd, J = 6.0 and 2.0 Hz, 1H), 7.04–6.91 (m, 2H), 6.48 (d, J = 3.5 Hz, 1H), 3.92 (s, 1H), 3.71 (s, 1H),
13
2.57 (d, J = 6.5 Hz, 1H), 2.32 (d, J = 6.5 Hz, 1H). C NMR (100 MHz, CDCl3)δ 150.3, 149.5, 148.4, 135.6,
125.2, 124.6, 122.1, 121.6, 68.8, 56.7, 50.7.
3.2. General method for dibromides
A 50-mL well-dried Schlenk flask was charged with argon through a Schlenk line. A solution of n-BuLi in hexane
(2.5 M, 4.4 mL, 11.0 mmol) was added to a solution of dry diisopropylamine (1.55 mL, 11.1 mmol) in dry THF
(10 mL) at 0 °C and cooled at –78 °C. A solution of monobromides (10.0 mmol) in dry THF (10 mL) was added
over 15 min and the mixture was stirred at the same temperature for 1 h. A solution of DBTCE (3.3 g, 10.1
mmol) in dry THF (10 mL) was added dropwise and the temperature was left to rise to RT overnight. The
reaction mixture was quenched with saturated ammonium chloride (20 mL), the aqueous layer was extracted
with diethyl ether (3 ×20 mL), and the combined organic layers were washed with brine (25 mL), dried over
321

EŞSİZ/Turk J Chem
Na2 SO4 , and concentrated under vacuum. The residue was purified by column chromatography (silica gel, 50
g, petroleum ether).
1
2,3-Dibromonorbornene (3): H NMR (400 MHz, CDCl3) δ = 2.98–3.03 (m, 2H), 1.78 (dt, J = 8.2 and
1.6 Hz, A part of AB system, 1H), 1.69 (AA’ part of AA’BB’ system, 2H), 1.32 (BB’ part of AA’BB’ system,
13
2H), 1.21 (dt, J = 8.2 and 1.8 Hz, A part of AB system, 1H). C NMR (100 MHz, CDCl3)δ = 125.4, 51.6,
47.0, 25.7.
1
2,3-Dibromonorbornadiene (6): H NMR (400 MHz, CDCl3) δ = 6.89 (t, J = 1.9 Hz, 2H), 3.63 (p,
J = 1.8 Hz, 2H), 2.46 (dt, J = 6.3 and 1.8 Hz, A part of AB system, 1H), 2.17 (dt, J = 6.3 and 1.8 Hz, A
13
part of AB system, 1H). C NMR (100 MHz, CDCl3)δ = 143.3, 135.1, 60.7, 28.9.
1
2,3-Dibromobenzonorbornadiene (9): H NMR (400 MHz, CDCl3)δ = 7.36–7.30 (AA’ part of AA’BB’
system, 2H), 7.27–6.99 (BB’ part of AA’BB’ system, 2H), 3.92–3.95 (m, 2H), 2.77 (dt, J = 7.4 and 1.6 Hz,
13
A part of AB system, 1H), 2.40 (dt, J = 7.4 and 1.8 Hz, A part of AB system, 1H). C NMR (100 MHz,
CDCl3)δ = 149.9, 135.8, 127.5, 124.1, 69.2, 60.8.
