APryticrleidine‐2,6‐Dithiocarboxylic Acid and Its Metal
Complexes: New Inhibitors of New Delhi Metallo
β‐Lactamase‐1
1
1
2
1
Chris S. Thomas , Doug R. Braun , Jose Luis Olmos, Jr. , Scott R. Rajski ,
2,3
4
1,
George N. Phillips, Jr. , David Andes and Tim S. Bugni *
1
Pharmaceutical Sciences Division, University of Wisconsin–Madison, Madison, WI 53705, USA;
csthomas4@wisc.edu (C.S.T.); drbraun1@wisc.edu (D.R.B.); scott.rajski@wisc.edu (S.R.R.)
Department of Biosciences, Rice University, Houston, TX 77005, USA; olmos@rice.edu (J.L.O.J.);
2
georgep@rice.edu (G.N.P.J.)
Department of Chemistry, Rice University, Houston, TX 77005, USA
Department of Medicine, University of Wisconsin School of Medicine and Public Health, Madison, WI
3
4
53705, USA; dra@medicine.wisc.edu
* Correspondence:tim.bugni@wisc.edu; Tel.: +1‐608‐263‐2519
Received: 23 April 2020; Accepted: 25 May 2020; Published: 2 June 2020
Abstract: Carbapenem‐resistant Enterobacteriaceae continue to threaten human health worldwide
with few effective treatment options. New Delhi metallo‐β‐lactamase (NDM) enzymes are a
contributing element that drive resistance to many β‐lactam‐ and carbapenem‐based antimicrobials.
Many NDM inhibitors are known, yet none are clinically viable. In this study, we present and
characterize a new class of NDM‐1 inhibitors based on a pyridine‐2,6‐dithiocarboxylic acid metal
complex scaffold. These complexes display varied and unique activity profiles against NDM‐1 in
kinetic assays and serve to increase the effectiveness of meropenem, an established antibacterial, in
assays using clinical Enterobacteriaceae isolates.
Keywords: NDM‐1 inhibitors; marine‐derived Streptomyces sp.; carbapenem‐resistant
Enterobacteriaceae; metal chelators
1. Introduction
Carbapenem‐resistant Enterobacteriaceae (CRE) infections are acknowledged by the Centers for
Disease Control and Prevention (CDC) and the World Health Organization (WHO) as a growing,
high priority health concern [1,2]. In addition to carbapenems, infections of this type harbor resistance
mechanisms to numerous antibiotics, leaving few effective treatment options. Studies conducted
worldwide have found that the mortality rates for CRE infections often exceed 40% [3–7]. At present,
formerly shelved antibiotics such as colistin (polymyxin E) are being reevaluated as treatment options
for CRE [8]. Although colistin can offer relief, there is often associated nephrotoxicity with the use of
this drug [9], and outbreaks of colistin‐resistant CRE have been documented [10,11]. Thus, CRE
infections make clear the desperate need for new, safe, and effective treatment options.
Carbapenem resistance in CRE can take several forms, including decreased porin expression
[12,13] and upregulated efflux pumps [14,15]. Additionally, β‐lactamases capable of hydrolyzing
carbapenems (carbapenemases) as well as the other classes of β‐lactams have also been a prominent
resistance factor found in CRE. Carbapenemases such as Klebsiella pneumonieae carbapenemases
(KPC) and oxacillinases (OXA) are serine β‐lactamases (SBLs, Ambler class A and D, respectively)
that employ active site serine residues to hydrolyze the β‐lactam pharmacophore [16,17]. Metallo‐β‐
lactamases (MBLS, Ambler class B) also function as carbapenemases, but instead utilize zinc ions in
the active site to facilitate lactam hydrolysis. Enzymes in this class include the Verona integron‐borne
Mar. Drugs 2020, 18, 295; doi:10.3390/md18060295
www.mdpi.com/journal/marinedrugs

Mar. Drugs 2020, 18, 295
2 of 13
metallo‐β‐lactamases (VIMs), imipenemases (IMPs), and the New Delhi metallo‐β‐lactamases
(NDMs) [18].
The New Delhi metallo‐β‐lactamase‐1 (NDM‐1) was discovered in 2008 from an infection
present in a Swedish patient admitted in New Delhi, India [19]. Isolates collected from this patient
harbored a plasmid that encoded the new metallo‐β‐lactamase (NDM‐1). Furthermore, the NDM‐1‐
containing plasmid harbored additional resistance elements and an efflux pump that conferred
resistance to rifampicin, erythromycin, and gentamycin, thereby compounding the difficulties
associated with achieving effective patient treatments. At present, NDM‐1 is the most prevalent MBL
expressed in CRE infections reported to the CDC in the United States [20]. New and effective
treatment options are needed in order to effectively combat clinical infections expressing NDM‐1
resistance.
The co‐administration of β‐lactamase inhibitors alongside β‐lactam antibiotics has proven to be
an effective treatment option that helps to circumvent β‐lactamase resistance mechanisms. In
particular, recent FDA‐approved treatments featuring inhibitors such as tazobactam, avibactam, and
vaborbactam continue to demonstrate clinical success in targeting SBL‐dependent β‐lactam resistance
[21]. Many inhibitors that target MBLs, NDM‐1 in particular, have also been reported in recent years
[22]. These agents display a vast diversity of pharmacophores (Figure 1) and mechanisms of enzyme
inhibition. Many of these compounds, such as captopril, feature a thiol group that coordinates with
2+
the active site Zn in NDM‐1, thus interfering with nucleophilic hydroxide production [23–25]. In
addition, boronic acids, both cyclic (depicted) and noncyclic, inhibit NDM‐1 by mimicking the
transition state of hydrolyzed β‐lactams [26,27] and have shown recent promise, currently in late‐
stage clinical development [28]. Metal chelators such as dipicolinic acid and the natural product
2+
aspergillomarasmine A knock out NDM‐1 activity by stripping the active site of Zn [29,30]. The
covalent inhibition of NDM‐1 has also been documented in a few cases with compounds such as
ebselen and cefaclor, compounds that target cysteine and/or lysine residues in the active site [31,32].
Despite these advances and expanding insights into the mechanisms of NDM‐1 inhibition, there
remain no FDA‐approved inhibitors of NDM‐1. The absence of approved agents necessitates
continued investigations for new sources of drug leads.
Figure 1. Select New Delhi metallo‐β‐lactamase‐1 (NDM‐1) inhibitors from the literature.
In the marine environment, iron is a growth‐limiting nutrient owing to its essential role in
numerous microbiological functions and sub‐nanomolar concentrations in oceanic surface waters
[33]. Marine microorganisms sequester iron predominantly through chelating compounds termed
siderophores. The structural diversity of marine siderophores is vast and has been reviewed recently
[34]. However, despite this breadth of study, new metal‐chelating compounds continue to be

Mar. Drugs 2020, 18, 295
3 of 13
discovered from the marine environment [35,36]. While many siderophores have been studied for
their propensity to bind iron, studies with other metals are limited [37,38]. Additionally, the natural
proclivity for the microbial uptake of these metal‐bound species favors their potential development
as antibiotic drug leads [39]. Taken together, the marine environment represents a unique niche for
the discovery of new metal‐binding inactivators of NDM‐1.
During mass spectrometry (MS)‐ and NMR‐guided investigations of marine‐derived
actinomycete extracts for the discovery of new bioactive natural products, we found iron‐bound
pyridine‐2,6‐dithiocarboxylic acid (PDTC2‐Fe) from the culture extract of marine Streptomyces strain
WMMB‐314. PDTC is a known metal chelator that was originally discovered from a then‐unidentified
3+
Pseudomonas species. Following the addition of Fe to the Pseudomonas culture medium, PDTC bound
to iron (PDTC2‐Fe) was isolated [40]. PDTC has since been identified and studied in several
Pseudomonas spp. and has been associated with the transport of iron and zinc in these organisms [41–
43]. Previous studies showed that the PDTC ligand alone effectively inhibited the growth of non‐
pseudomonas bacterial spp. but lost antimicrobial activity in the presence of certain transition metals
such as iron or cobalt. Notably, zinc enhanced the antimicrobial activity of PDTC [44]. In a separate
study, the metal binding and antimicrobial properties of PDTC with a wider array of transition metals
were investigated, demonstrating that many other PDTC–metal complexes enhanced antimicrobial
activity compared to PDTC alone [45].
Given the structural relatedness between PDTC and the NDM‐1 inhibitor dipicolinic acid, we
hypothesized that PDTC would also demonstrate similar inhibitory behavior towards this enzyme.
In fact, Roll and co‐workers found that several analogs of dipicolinic acid, including PDTC, inhibited
a variety of bacterial MBLs and mammalian metallo‐enzymes that contain zinc [46]. In this
investigation, we examined PDTC activity against NDM‐1‐harboring CRE pathogens in conjugation
with meropenem, and also against NDM‐1 in kinetic assays. Importantly, the unique activity
observed in the kinetic assays encouraged us to examine several metal‐bound PDTC complexes as
potential inhibitors of NDM‐1 as well. PDTC–metal complexes displayed different NDM‐1 inhibition
activity depending on the metal bound. Additionally, complexes were also able to rescue
meropenem’s efficacy against clinical NDM‐1 CRE isolates.
2. Results
2.1. Identification, Synthesis and Evaluation of PDTC against Clinical CRE Isolates with Meropenem
We isolated PDTC2‐Fe from an extract of marine‐derived Streptomyces sp. (strain WMMB‐314).
A chloroform partition from a 10 L culture extract was fractionated using Sephadex LH‐20, and
subsequent purification via HPLC yielded a black‐brown solid. Mass spectrometry revealed a
molecular ion with a unique isotope pattern suggesting the presence of iron (ESI(−) m/z 449.8431 [M
−
− H] , Figure 2a), and this was consistent with the broad resonances observed in the NMR spectrum.
Using the accurate mass measurements for an Antibase [47] database search, we confirmed the
identity as PDTC2‐Fe.
As previously discussed, we hypothesized that metal‐free PDTC would be sufficient to
2+
inactivate NDM‐1. Specifically, we reasoned that PDTC could extract Zn from the NDM‐1 active
site in a fashion similar to that established for dipicolinic acid (Figure 1), which features carboxylic
acids instead of the thiocarboxylic acids on PDTC [30]. Using conventional bench‐top chemistry and
simple reagents/conditions, we readily generated ample amounts of PDTC to support initial NDM‐1
inhibition studies (Figure 2 and S1).

Mar. Drugs 2020, 18, 295
4 of 13
Figure 2. (a) Structure of iron‐bound pyridine‐2,6‐dithiocarboxylic acid (PDTC2‐Fe) assembly and
accompanying negative mode ESI MS analysis. (b) Synthesis of PDTC. (c) Mass spectrum of PDTC
collected using negative mode ESI.
We began by testing PDTC against three clinical Enterobacteriaceae isolates harboring the NDM‐
1 gene in the presence of the carbapenem antibiotic and the NDM‐1 substrate meropenem. Since
PDTC has documented antimicrobial activity, we first collected minimum inhibitory concentration
(MIC) data for PDTC against each of the clinical isolates (Table S1) [44]. Meropenem MICs were
subsequently collected against these isolates, both in the absence and presence of PDTC at 0.25× its
individual MIC. PDTC rescued the antimicrobial activity of meropenem, reducing its MIC against
each strain by 4‐fold or greater (Figure 3), providing some support for our hypothesis.
Figure 3. Meropenem MICs in the presence and absence of the PDTC ligand when incubated with
clinical pathogens expressing NDM‐1. The PDTC concentrations in the relevant samples were 0.25×
the PDTC MIC (100 μM for all isolates). All the data represent an average of four replicates with
standard deviation error bars.
2.2. Kinetic Evaluation of PDTC against Recombinant NDM‐1
To confirm that the reduced meropenem MICs were the result of NDM‐1 inhibition by PDTC,
we conducted a kinetic analysis of PDTC with isolated enzyme. Recombinant, soluble NDM‐1 was
expressed and purified from E. coli BL21‐DE3 cells [48]. CENTA ((6R,7R)‐3‐[(3‐carboxy‐4‐
nitrophenyl)sulfanylmethyl]‐8‐oxo‐7‐[(2‐thiophen‐2‐ylacetyl)amino]‐5‐thia‐1‐azabicyclo [4.2.0]‐oct‐
2‐ene‐2‐carboxylic acid), a colorimetric cephalosporin substrate for NDM‐1, was used to monitor the
2+
5
reaction rate of the NDM‐1 kinetic assays. Zn was also supplied to the enzyme in excess (10 x or
greater) prior to the assay to support a saturated metallo‐enzyme binding site. Using this approach,
we first investigated the NDM‐1 hydrolysis of CENTA in the presence of PDTC.
Two key findings came out of this study. First, two equivalents of PDTC relative to the amount
2+
of excess Zn included in the NDM‐1 assay led to the elimination of NDM‐1 activity, followed by

Mar. Drugs 2020, 18, 295
5 of 13
some hydrolysis of CENTA due to high concentrations of PDTC (Figure S2). The incubation of PDTC
with ZnSO4, the metal salt used for the assay, afforded a 2:1 PDTC/Zn complex (PDTC2‐Zn) as
2−
revealed by MS analysis (ESI(−) m/z 228.90 [M − 2H] , molecular formula C14H6O4S4N2Zn), along with
2+
several 1:1 complexes containing different anionic ligands (Figure S3). When the Zn concentrations
in the colorimetric CENTA cleavage assay were increased, more PDTC was required to eliminate
activity, maintaining a stoichiometric 2:1 PDTC/Zn ratio for NDM‐1 inactivation. These data clearly
2+
support the notion that PDTC inactivates NDM‐1 by sequestering Zn from the active site (Figure 4).
The second main finding from these kinetic assays was that PDTC concentrations lower than
2+
2+
twice the amount of Zn present (i.e., fewer than two equivalents of PDTC relative to Zn ) led to
slightly enhanced rates of NDM‐1‐catalyzed hydrolysis. In other words, NDM‐1 hydrolyzed CENTA
at a faster rate than without any PDTC present (Figure 4). Importantly, although NDM‐1 was found
to be most active between 20 and 40 μM ZnSO4 (Figure S4), there was a clear enhancement of NDM‐
1 activity with PDTC at 10 μM ZnSO4 (Figure 4a), suggesting that PDTC does not simply tune the
ZnSO4 concentration for optimal NDM‐1 catalytic efficiency. Additionally, experiments with EDTA
could not reproduce the rate enhancement observed with sub‐stoichiometric concentrations of PDTC
(Figure S5). Taken together, the two findings suggest that a PDTC‐Zn complex formed in solution
during the assay enhanced NDM‐1 activity, presumably via allosteric associations. Once all the excess
2+
Zn was sequestered by exogenous PDTC, NDM‐1 activity was abolished. We posit that en route to
the generation of the PDTC2‐Zn complex, intermediate 1:1 complexes transiently increased NDM‐1
2+
activity until all the available Zn was sequestered.
Figure 4. Initial rates of CENTA hydrolysis by NDM‐1 vs. PDTC concentration with (a) 10 μM ZnSO4,
(b) 50 μM ZnSO4 or (c) 100 μM ZnSO4 supplementing the reaction buffer. In each case, NDM‐1 activity
was reduced as the PDTC concentration exceeded two equivalents of the ZnSO4 in the reaction,
denoted by bold type on the x‐axis.
2.3. Synthesis and Kinetic Evaluation of PDTC Complexes against Recombinant NDM‐1
Intrigued by the rate enhancement activity observed in the kinetic assay, we next sought to study
the effect of individual PDTC metal complexes on NDM‐1 kinetics. In particular, we sought to
determine whether or not a PDTC‐Zn complex prepared in situ before CENTA hydrolysis reactions
could enhance NDM‐1 activity. We also wished to study how other PDTC complexes might impact
NDM‐1 activity. To answer those questions, chloride salts of iron, cobalt, nickel and zinc were all
combined with the PDTC ligand and characterized via mass spectrometry (Figure S6). The iron and
cobalt chloride salts formed 2:1 PDTC/metal complexes, whereas the exposure of PDTC to nickel
chloride resulted in a 1:1 complex. Interestingly, although a mixture of 2:1 and 1:1 PDTC‐Zn
complexes were generated using ZnSO4 as a starting material for complex synthesis, the use of ZnCl2
as the metal source gave rise only to 1:1 complexes. Accordingly, we generated PDTC complexes
using ZnCl2 with a 1:1 stoichiometry (Figure 5a).
Each complex was independently titrated into a kinetic assay at different concentrations, and
the initial rates of CENTA hydrolysis were determined (Figure 5b). As anticipated, the 1:1 PDTC‐Zn
complex enhanced the rate of CENTA hydrolysis by NDM‐1 by as much as 34%, before beginning to
inhibit the enzyme at concentrations around 100 μM. By contrast, the other 1:1 metal complex, PDTC‐

Mar. Drugs 2020, 18, 295
6 of 13
Ni, potently inhibited NDM‐1. For the 2:1 complexes, PDTC
2
‐Fe was more inhibitory towards NDM‐
1 than PDTC ‐Co; both complexes failed to enhance NDM‐1 activity.
2
Figure 5. (a) General synthesis scheme and stoichiometry for the PDTC–metal complexes as
confirmed by mass spectrometry (Figure S6). (b) Dose response curves for each of the PDTC–metal
complexes against the initial NDM‐1 hydrolysis rates of CENTA. PDTC‐Zn data were fit using a bi‐
phasic model to afford a better fit.
2.4. Evaluation of PDTC Complexes against Clincal CRE Isolates with Meropenem
Having established NDM‐1 inhibitory trends with the PDTC–metal complexes, each complex
was then tested in combination with meropenem using the previously studied clinical isolates (Figure
3). We hypothesized that the PDTC complexes might also enhance the susceptibility of these isolates
as had been observed with metal‐free PDTC. We also proposed, based on earlier findings, that the
inclusion of PDTC‐Zn may counteractively increase meropenem MICs, given this complex’s ability
to slightly improve the NDM‐1 used for in vitro studies. As before, MICs were first determined for
each PDTC complex against each of the three clinical Enterobacteriaceae strains (Table S1). The
meropenem MICs were then also determined in the presence of the different metal–PDTC complexes
where again, each metal agent concentration was set to 0.25× its MIC (in the absence of meropenem).
Table 1 lists the meropenem MICs in the presence and absence of each metal–PDTC complex, as well
as the previous data obtained with the free PDTC ligand.
Table 1. Meropenem MIC (μg/mL) data with each PDTC complex and PDTC alone at the
concentrations listed. The MICs shown are average of four replicates.
E. coli
K. pneumonieae
Complex
E. coli 2692
BAA‐2452
BAA‐2146
No PDTC or Complex
64a
16 a
28 a
16 a
64 c
8 b
20 a
2 a
64 a
PDTC
2
‐Fe
20 a
PDTC
2
‐Co
4 a
32 a
PDTC‐Ni
PDTC‐Zn
PDTC (no metal)
2 a
32 a
12 c
1 b
64 b
8 b
PDTC complex or PDTC screened at 0.25× its previously determined MIC―a 400 μM, b 100 μM,
c 50 μM. The metal salts used to generate these complexes were also studied against these organisms
in an identical manner (Tables S2 and S3).
In general, PDTC–metal complexes rescued meropenem activity, at times reducing the MIC by
as much as 10‐fold. The PDTC ligand alone demonstrated the greatest enhancement of meropenem

Mar. Drugs 2020, 18, 295
7 of 13
activity. In contrast to expectations, we found no evidence that the PDTC‐Zn complex enhanced
meropenem resistance, although, in two cases, the meropenem MIC was not reduced at all.
Interestingly, the meropenem MICs with PDTC2‐Fe were comparable to those with PDTC‐Ni against
Enterobacteriaceae despite the ~10‐fold difference in kinetic efficacy in favor of PDTC‐Ni. Overall,
our studies demonstrate that, in addition to the PDTC ligand, metal‐bound PDTC complexes are able
to interfere with NDM‐1 activity.
3. Discussion
In summary, a new class of NDM‐1 inhibitors has been characterized. PDTC rescued the efficacy
of the β‐lactam antibiotic meropenem against NDM‐1‐harboring clinical isolates and furthermore
demonstrated NDM‐1 inhibition in kinetic assays. Secondary studies with PDTC–metal complexes in
kinetic investigations revealed varying inhibitory activities against NDM‐1. PDTC‐Ni showed the
most potent inhibitory activity against NDM‐1 kinetically, whereas PDTC2‐Fe and PDTC2‐Co showed
progressively reduced inhibitory activities. Interestingly, PDTC‐Zn enhanced NDM‐1 activity, we
suspect by enabling allosteric associations that translated into slightly improved NDM‐1 function.
PDTC appeared to provide optimal reductions in meropenem MIC values against clinical isolates
expressing NDM‐1, although meropenem MIC values were reduced in the presence of PDTC–metal
complexes as well.
During our investigations of transition metal drugs and metal complexes for new inhibitors of
NDM‐1 and other MBLs, Chen and colleagues identified cisplatin and Pd complexes as potent
inhibitors of MBL activity [49]. From their data, they posit that the metal or ligand‐bound metal
species replaces one of the zinc ions in the active site. In this way, metal chelators with bound metals
2+
appear not to strip NDM‐1 of active site Zn so much as to simply swap out the vital metal–amino
acid associations necessary for optimal enzyme function. We have yet to conduct analogous
investigations with our metal‐bound PDTC species to determine if similar interactions are taking
place. Nevertheless, both of our studies corroborate the notion that metal‐bound chelator compounds
are capable of reducing NDM‐1 enzymatic activity; clinically speaking, it is this realization that bears
the greatest significance.
4. Materials and Methods
4.1. Reagents, Chemicals and Instrumentation
Clinical Enterobacteriaceae isolates containing NDM‐1 were provided by Dr. David Andes’ lab
at the University of Wisconsin–Madison. All other solvents, reagents and media components were
obtained from commercial sources. NMR datasets were collected with a Varian 500 MHz instrument.
Mass spectrometry data were collected on a Bruker MaXis 4G qTof. Protein quantification was
conducted using a Thermo Scientific Nanodrop 2000c Spectrophotometer unless otherwise noted.
Kinetic assays were read in Costar® polystyrene 96‐well plates using a BioTek H1 plate reader.
4.2. Purification and Identification of PDTC2‐Fe
Pyridine‐2,6‐dithiocarboxylic acid bound to iron (PDTC2‐Fe) was purified from 10 × 1 L cultures
of Streptomyces strain WMMB 314 in ASW‐A medium (20 g of soluble starch, 10 g of glucose, 5 g of
peptone, 5 g of yeast extract and 5 g of CaCO3 per 1 L ASW) supplemented with 50 μM FeCl3 and 70
g of HP‐20 resin. Following 1 week of growth at 28 °C with 200 rpm shaking, cells and resin were
collected in Miracloth, washed with DI water, and extracted in acetone. The crude extract (27.29 g)
was liquid–liquid partitioned between 90% MeOH in water and hexanes (480 mg). Water was added
to the aqueous fraction to make the solution 70% MeOH, and then the solution was partitioned with
CHCl3 (2.8 g). Then, 800 mg of the CHCl3 partition was dissolved in 1:1 MeOH/CHCl3 and fractioned
using Sephadex LH‐20 into four fractions. Fraction 3 contained PDTC2‐Fe, and 19 mg was injected on
a Phenomenex C18 Gemini preparatory HPLC column (250 × 30 mm, 5 μm) using a gradient of MeOH
and 10 mM ammonium acetate in water: 0–0.7 min with 40% MeOH, a linear gradient at 0.7–35.2 min
to 100% MeOH, and a hold at 100% MeOH at 35.2–42 min. Fractions were collected every 0.5 min

Mar. Drugs 2020, 18, 295
8 of 13
beginning at 5 min; Fractions 14–18 contained PDTC2‐Fe (8.1 mg). Direct infusion MS data collected
in (−)‐ESI mode revealed a single signal with a unique isotope pattern denoting the presence of iron
(m/z [M − H] = 449.8431). The MS data were parsed on the natural product database Antibase [47],
which suggested PDTC2‐Fe as the metabolite. The compound was confirmed through later synthesis
and subsequent MS analysis of PDTC2‐Fe.
4.3. PDTC Synthesis
PDTC was synthesized using methodology adapted from previous work by Chatterjee and
Crans [50]. Briefly, 417 mg (2.04 mmol) of 2,6‐pyridine dicarbonyl dichloride was added to 10 mL of
saturated NaHS in water and stirred for 2 h. HCl [aq, 2N] was then added dropwise to reduce the pH
to 1.6, and the solution was stirred for an additional 50 min. Pyridine‐2,6‐dithiocarboxylic acid
precipitated and was collected by partition with dichloromethane (DCM) and dried under a gentle
stream of argon to afford 232 mg of a white solid. The sample was loaded onto a 5 g silica gel column
(1.75 cm diameter). An unidentified product was washed away with 1:9 dichloromethane
(DCM)/hexanes. Elution with 100% CH2Cl2 then afforded PDTC as a white solid. Notably, a brown
color formed on the column as PDTC eluted, likely signaling the formation of PDTC2‐Fe; silica is a
known iron source. Despite this concern, the suspected PDTC2‐Fe complex was retained on the silica
gel column. PDTC was then dried and stored under argon at −20 °C until use. The final yield of pure
1
PDTC was 203 mg (1.09 mmol, 49.9%). H NMR (CD2Cl2) δ 8.19 (AB2 d, 2H, J = 7.8 Hz), δ 8.11 (AB2 t,
1H, J = 7.8 Hz), δ 5.72 (br, 2H). The AB2 (Pople nomenclature) exhibited second order effects. The
chemical shifts and the coupling constant in this system were calculated and confirmed using the
WinDNMR simulation software[51].
4.4. Mass Spectrometry of PDTC Complexes
PDTC was dissolved in Ar‐purged N,N‐dimethyl formamide (DMF) and then combined with
solutions of ZnCl2, FeCl3, NiCl2 and CoCl2 to form PDTC complexes at 100 μM. For Co and Fe
complexes, a 2:1 PDTC/metal salt stoichiometry was used; 1:1, for Ni and Zn complexes. PDTC was
also prepared at 100 μM. These solutions were further diluted to 1 μM in CH3CN for direct infusion.
The complexes were analyzed by ESI in negative mode at a flow rate of 180 μL/h, a capillary voltage
of 2500V, a nebulizer at 0.3 bar, dry gas at 4 L/min, dry temp at 180 °C, and a mass range of 50–1700
m/z.
PDTC was also analyzed in the presence of ZnSO4 using MS. PDTC ligand (50 μM) was
combined with 1 mM ZnSO4 in LCMS‐grade H2O and reacted at room temperature for 1.5 h. The
sample was diluted 1:10 in LCMS‐grade acetonitrile for direct infusion under conditions identical to
those noted above.
4.5. NDM‐1 Purification
The pNic28‐Bsa4 plasmid containing the NDM‐1 construct (pNic‐NDM1) was generated as
follows. The coding DNA sequence for NDM‐1 was ordered from Integrated DNA Technologies
(Coralville, IA) as a double‐stranded DNA fragment comprising residues 29–270, excluding the
signaling peptide coding region, residues 1–28. This DNA fragment was then cloned into pNIC28‐
Bsa4 via Gibson Assembly using reagents from New England Biolabs (Ipswich, MA, USA). This
necessitated the generation of overlapping regions through PCR amplification using the primers
provided in Table 2 (below), which were also purchased from IDT. These primers were designed to
incorporate the NDM‐1 coding DNA sequence just after the TEV protease sequence site on the vector
backbone. The pNIC28‐Bsa4 empty backbone was obtained from Addgene, plasmid #26103
(Cambridge, MA), where it was deposited by Opher Gileadi on behalf of the Structural Genomics
Consortium. Details of the pNic‐NDM1 plasmid are available for viewing at the following link:
https://benchling.com/s/seq‐ZvaWkjSHai7TZYdm8xyH/edit.

Mar. Drugs 2020, 18, 295
9 of 13
Table 2. pNIC‐NDM1 cloning primers.
Primer
Sequence
pNIC‐Fwd
pNIC‐Rev
NDM1‐Fwd
NDM1‐Rev
CGCATGGCCGATAAGTTACGTTAAacggtctccagtaaaggt
CCCGATAGTTGGACGAATTTCACCggattggaagtacaggttctc
accgagaacctgtacttccaatccGGTGAAATTCGTCCAACTATC
gtatccacctttactggagaccgtTTAACGTAACTTATCGGCCA
BL21‐(DE3) E. coli cells were transformed with pNic‐NDM1 and plated onto kanamycin (34
μg/mL) selective media. An overnight starter culture of pNic‐NDM1 E. coli was diluted into a 500 mL
culture of LB media. After 4 h (OD600 = 0.741), the culture was induced with 0.1 mM isopropyl‐β‐D‐
thiogalactopyranoside. The culture was shaken at room temperature for just over 24 h to induce
expression. The cells were pelleted and frozen until use; the cell pellets (wet) weighed approx. 4 g.
Cells (2 g) were combined with 10 mL of Bug Buster® HT Protein Extraction Reagent (EMD
Millipore) cell lysis reagent and incubated with gentle mixing at room temperature for 20 min. Cell
debris was pelleted and the 10 mL supernatant was combined with 10 mL of wash buffer (50 mM
NaH2PO4, 300 mM NaCl, pH 7.4) and loaded in multiple batches onto a single HisPur™ Cobalt Spin
Column (1 mL, Thermo Scientific). Each batch was gently mixed for 30 min before centrifugation for
2 min at 700 g. The column was then washed with wash buffer four times (2 mL at 700 g). The His‐
tagged NDM‐1 was then eluted with elution buffer (50 mM NaH2PO4, 300 mM NaCl, 150 mM
imidazole pH 7.4) four times with 2 mL at 700 g. The elution fraction was spin‐concentrated
(Amicon® Ultra‐15 10K Centrifugal Filter, EMD Millipore) into TEV reaction buffer (20 mM Tris, 0.01
mM ZnCl2, 200 mM NaCl, 5 mM sodium citrate, 5 mM 2‐mercaptoehtanol, pH 7.4) for TEV cleavage
of the His‐tag.
His‐tagged NDM‐1 was quantified using a Coomassie (Bradford) Protein Assay kit (Thermo
Scientific). The His‐tagged TEV protease was generated as previously described [52].
Protease was added at 1/20 the mass of NDM‐1 and incubated with shaking at room temperature
overnight (~18 h). The reaction mixture containing His‐tagged TEV, cleaved NDM‐1 and the removed
NDM‐1 His‐tags was spin concentrated into wash buffer with 10% glycerol. The mixture was loaded
onto a HisPur™ spin column and gently mixed for 30 min. The column was spun for 2 min at 700 g
to collect the unbound NDM‐1 and was washed three times with wash buffer containing 10% glycerol
to collect any remaining NDM‐1. The column was also separately washed with elution buffer to
remove bound proteins. Fractions of pure NDM‐1 were combined, spin concentrated and quantified
using a Nanodrop and the calculated extinction coefficient for NDM‐1 based on its amino acid
sequence [53]. The calculated yield of NDM‐1 was 11 mg per liter of culture. Aliquots were frozen at
−80 °C until further use.
4.6. Kinetic Data Collection
PDTC was dissolved in Ar‐purged DMF and combined with solutions of ZnCl2, FeCl3, NiCl2 and
CoCl2 to make concentrated stock solutions of 20 mM in 1:1 water/DMF solutions. The solutions were
diluted in assay buffer (HEPES 50 mM, 1 μg/mL of bovine serum albumin (BSA), 0.01% Triton X‐100,
pH 7.2) to the final testing concentrations through serial dilutions in 96‐well flat‐bottom plates. NDM‐
1 was diluted from frozen stocks to a final testing concentration of 100 pM in assay buffer
supplemented with 10 μM ZnSO4 and aliquoted into the 96 well plates. A larger concentration of
NDM‐1 (250 pM) was used for PDTC2‐Co to better establish an initial rate above the noise generated
at high concentrations of the complex. CENTA was prepared and added at a final concentration of
50 μM. The plates were analyzed using a kinetic method monitoring the hydrolysis of CENTA at 410
nm over 10 minutes. The initial rates were calculated and used in the generation of dose–response
plots in the Origin 9.1 software. The model used was dose–response, under non‐linear curve fitting.
PDTC‐Zn was fit using a bi‐phasic dose–response model, in order to better fit the curve and calculate
the IC50 more accurately. The A1 (bottom) asymptote was held constant at zero for all models to afford
a better fit. The kinetic data recorded in the Supporting Information were collected using the same

Mar. Drugs 2020, 18, 295
10 of 13
assay buffer as above, with the concentrations of ZnSO4 noted. Working solutions of EDTA were
prepared from a 0.5 M stock solution (pH = 8).
4.7. MIC Determinations
The minimum inhibitory concentrations for PDTC, the PDTC–metal complexes, and the metal
salts were determined against three different Enterobacteriaceae isolates that house NDM‐1
resistance genes (E. coli 2692, E. coli BAA‐2452 and K. pneumonieae BAA‐2146) following the Clinical
Laboratory Standards Institute (CLSI) guidelines [54]. For the meropenem MICs collected in the
presence of PDTC or PDTC metal complexes, methods were adapted from the CSLI guidelines for
determining MICs. PDTC and complexes were prepared in DMF as described above and
subsequently diluted in cation‐adjusted Mueller Hinton Broth (MHB) to the final concentrations
shown in the footnote of Table 1. Medium solutions containing these compounds were aliquoted into
96‐well plates. Meropenem was added and serially diluted from Columns 12 to 3 in the 96‐well plates.
5
The strains were grown overnight in LB media and then diluted to approximately 5 × 10 CFU/mL.
The MICs were determined between Columns 3 to 12; Column 2 was a growth control, and Column
1 was a medium control. The DMF was kept at or below 2% in screening conditions. The meropenem
MICs collected with metal salts were collected in a similar manner; the metal salts were initially
dissolved in DI H2O instead of DMF.
Supplementary Materials: The following are available online at www.mdpi.com/1660‐3397/18/6/295/s1, Figure
S1: 1H NMR spectrum of synthetic PDTC, Figure S2: Rate of CENTA hydrolysis in the presence of PDTC alone,
Figure S3: Mass spectra of PDTC with ZnSO4, Figure S4: Rate of CENTA hydrolysis by NDM‐1 in assay buffer
with ZnSO4, Figure S5: Rate of CENTA hydrolysis by NDM‐1 in ZnSO4 with EDTA, Figure S6: Mass spectra of
PDTC complexes collected in ESI (−) mode, Table S1: PDTC complex and PDTC MIC data with CRE isolates,
Table S2: Metal salt MIC data with CRE isolates, Table S3: Meropenem MIC data with metal salts.
Author Contributions: Conceptualization, C.S.T. and T.S.B.; methodology, C.S.T. and D.R.B.; validation, C.S.T.
and D.R.B.; formal analysis, C.S.T.; investigation, C.S.T. and D.R.B.; resources, C.S.T., D.R.B., J.L.O., G.N.P. and
D.A.; data curation, C.S.T.; writing—original draft preparation, C.S.T.; writing—review and editing, S.R.R. and
T.S.B.; visualization, C.S.T.; supervision, T.S.B.; project administration, T.S.B.; funding acquisition, T.S.B. and
G.N.P. All authors have read and agreed to the published version of the manuscript.
Funding: This project was funded by University of Wisconsin‐Madison School of Pharmacy, the NIH (NIGMS)
grants R01 GM104192 and R01 GM107557, the NSF Science and Technology Center, BioXFEL, STC‐1231306.
Acknowledgments: This work was supported by funding from the University of Wisconsin‐Madison School of
Pharmacy and the Graduate School at the University of Wisconsin. This work was also funded by the NIH
(NIGMS) via grants R01 GM104192 and R01 GM107557. JLO and GNP were supported by the NSF Science and
Technology Center, BioXFEL, STC‐1231306. In addition, we also thank the Analytical Instrumentation Center at
the School of Pharmacy, University of Wisconsin‐Madison for enabling the acquisition of spectroscopic data.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
World Health Organization. Global Priority List of Antibiotic‐Resistant Bacteria to Guide Research, Discovery,
and Development of New Antibiotics; World Health Organization: Geneva, Switzerland, 2017.
CDC. Antibiotic Resistance Threats in the United States; Centers for Disease Control and Prevention: Atlanta,
GA, USA, 2019.
Li, X.; Ye, H. Clinical and mortality risk factors in bloodstream infections with carbapenem‐resistant
enterobacteriaceae. Can. J. Infect. Dis. Med. Microbiol. 2017, 2017, 6212910.
Daikos, G.L.; Tsaousi, S.; Tzouvelekis, L.S.; Anyfantis, I.; Psichogiou, M.; Argyropoulou, A.; Stefanou, I.;
Sypsa, V.; Miriagou, V.; Nepka, M.; et al. Carbapenemase‐producing klebsiella pneumoniae bloodstream
infections: Lowering mortality by antibiotic combination schemes and the role of carbapenems. Antimicrob.
Agents Chemother. 2014, 58, 2322–2328.
5.
Fraenkel‐Wandel, Y.; Raveh‐Brawer, D.; Wiener‐Well, Y.; Yinnon, A.M.; Assous, M.V. Mortality due to
blakpc klebsiella pneumoniae bacteraemia. J. Antimicrob. Chemother. 2016, 71, 1083–1087.

Mar. Drugs 2020, 18, 295
11 of 13
6.
Villegas, M.V.; Pallares, C.J.; Escandón‐Vargas, K.; Hernández‐Gómez, C.; Correa, A.; Álvarez, C.; Rosso,
F.; Matta, L.; Luna, C.; Zurita, J.; et al. Characterization and clinical impact of bloodstream infection caused
by carbapenemase‐producing enterobacteriaceae in seven latin american countries. PLoS ONE 2016, 11,
e0154092.
7.
Papadimitriou‐Olivgeris, M.; Marangos, M.; Christofidou, M.; Fligou, F.; Bartzavali, C.; Panteli, E.S.;
Vamvakopoulou, S.; Filos, K.S.; Anastassiou, E.D. Risk factors for infection and predictors of mortality
among patients with kpc‐producing klebsiella pneumoniae bloodstream infections in the intensive care
unit. Scand. J. Infect. Dis. 2014, 46, 642–648.
8.
9.
Morrill, H.J.; Pogue, J.M.; Kaye, K.S.; LaPlante, K.L. Treatment options for carbapenem‐resistant
enterobacteriaceae infections. Open Forum Infect. Dis. 2015, 2, ofv050.
Akajagbor, D.S.; Wilson, S.L.; Shere‐Wolfe, K.D.; Dakum, P.; Charurat, M.E.; Gilliam, B.L. Higher incidence
of acute kidney injury with intravenous colistimethate sodium compared with polymyxin b in critically ill
patients at a tertiary care medical center. Clin. Infect. Dis. 2013, 57, 1300–1303.
10. Giani, T.; Arena, F.; Vaggelli, G.; Conte, V.; Chiarelli, A.; Henrici De Angelis, L.; Fornaini, R.; Grazzini, M.;
Niccolini, F.; Pecile, P.; et al. Large nosocomial outbreak of colistin‐resistant, carbapenemase‐producing
klebsiella pneumoniae traced to clonal expansion of an mgrb deletion mutant. J. Clin. Microbiol. 2015, 53,
3341–3344.
11. Rossi Gonçalves, I.; Ferreira, M.L.; Araujo, B.F.; Campos, P.A.; Royer, S.; Batistão, D.W.; Souza, L.P.; Brito,
C.S.; Urzedo, J.E.; Gontijo‐Filho, P.P.; et al. Outbreaks of colistin‐resistant and colistin‐susceptible kpc‐
producing klebsiella pneumoniae in a brazilian intensive care unit. J. Hosp. Infect. 2016, 94, 322–329.
12. Mena, A.; Plasencia, V.; García, L.; Hidalgo, O.; Ayestarán, J.I.; Alberti, S.; Borrell, N.; Pérez, J.L.; Oliver, A.
Characterization of a large outbreak by ctx‐m‐1‐producing klebsiella pneumoniae and mechanisms leading
to in vivo carbapenem resistance development. J. Clin. Microbiol. 2006, 44, 2831–2837.
13. Rodríguez‐Martínez, J.M.; Poirel, L.; Nordmann, P. Molecular epidemiology and mechanisms of
carbapenem resistance in pseudomonas aeruginosa. Antimicrob. Agents Chemother. 2009, 53, 4783–4788.
14. Zhang, Y.; Li, Z.; He, X.; Ding, F.; Wu, W.; Luo, Y.; Fan, B.; Cao, H. Overproduction of efflux pumps caused
reduced susceptibility to carbapenem under consecutive imipenem‐selected stress in. Infect. Drug Resist.
2017, 11, 457–467.
15. Pan, Y.P.; Xu, Y.H.; Wang, Z.X.; Fang, Y.P.; Shen, J.L. Overexpression of mexab‐oprm efflux pump in
carbapenem‐resistant pseudomonas aeruginosa. Arch. Microbiol. 2016, 198, 565–571.
16. Naas, T.; Dortet, L.; Iorga, B.I. Structural and functional aspects of class a carbapenemases. Curr. Drug
Targets 2016, 17, 1006–1028.
17. Docquier, J.D.; Mangani, S. Structure‐function relationships of class d carbapenemases. Curr. Drug Targets
2016, 17, 1061–1071.
18. Palzkill, T. Metallo‐β‐lactamase structure and function. Ann. N. Y. Acad. Sci. 2013, 1277, 91–104.
19. Yong, D.; Toleman, M.A.; Giske, C.G.; Cho, H.S.; Sundman, K.; Lee, K.; Walsh, T.R. Characterization of a
new metallo‐β‐lactamase gene, blandm‐1, and a novel erythromycin esterase gene carried on a unique
genetic structure in klebsiella pneumoniae sequence type 14 from india. Antimicrob. Agents Chemother. 2009,
53, 5046–5054.
20. Tracking Cre. Available online: https://www.cdc.gov/hai/organisms/cre/trackingcre.html (accessed on 12
October 2019).
21. Tehrani, K.H.M.E.; Martin, N.I. Β‐lactam/β‐lactamase inhibitor combinations: An update. Medchemcomm
2018, 9, 1439–1456.
22. Linciano, P.; Cendron, L.; Gianquinto, E.; Spyrakis, F.; Tondi, D. Ten years with new delhi metallo‐β‐
lactamase‐1 (ndm‐1): From structural insights to inhibitor design. ACS Infect. Dis. 2019, 5, 9–34.
23. Li, N.; Xu, Y.; Xia, Q.; Bai, C.; Wang, T.; Wang, L.; He, D.; Xie, N.; Li, L.; Wang, J.; et al. Simplified captopril
analogues as ndm‐1 inhibitors. Bioorganic med. chem. lett. 2014, 24, 386–389.
24. Meng, Z.; Tang, M.L.; Yu, L.; Liang, Y.; Han, J.; Zhang, C.; Hu, F.; Yu, J.M.; Sun, X. Novel mercapto
propionamide derivatives with potent new delhi metallo‐β‐lactamase‐1 inhibitory activity and low toxicity.
ACS Infect. Dis. 2019, 5, 903–916.
25. Brem, J.; van Berkel, S.S.; Zollman, D.; Lee, S.Y.; Gileadi, O.; McHugh, P.J.; Walsh, T.R.; McDonough, M.A.;
Schofield, C.J. Structural basis of metallo‐β‐lactamase inhibition by captopril stereoisomers. Antimicrob.
Agents Chemother. 2016, 60, 142–150.

Mar. Drugs 2020, 18, 295
12 of 13
26. Brem, J.; Cain, R.; Cahill, S.; McDonough, M.A.; Clifton, I.J.; Jiménez‐Castellanos, J.C.; Avison, M.B.;
Spencer, J.; Fishwick, C.W.; Schofield, C.J. Structural basis of metallo‐β‐lactamase, serine‐β‐lactamase and
penicillin‐binding protein inhibition by cyclic boronates. Nat. Commun. 2016, 7, 12406.
27. Cendron, L.; Quotadamo, A.; Maso, L.; Bellio, P.; Montanari, M.; Celenza, G.; Venturelli, A.; Costi, M.P.;
Tondi, D. X‐ray crystallography deciphers the activity of broad‐spectrum boronic acid β‐lactamase
inhibitors. ACS Med. Chem. Lett. 2019, 10, 650–655.
28. Krajnc, A.; Brem, J.; Hinchliffe, P.; Calvopiña, K.; Panduwawala, T.D.; Lang, P.A.; Kamps, J.J.A.G.; Tyrrell,
J.M.; Widlake, E.; Saward, B.G.; et al. Bicyclic boronate vnrx‐5133 inhibits metallo‐ and serine‐β‐lactamases.
J. Med. Chem. 2019, 62, 8544–8556.
29. King, A.M.; Reid‐Yu, S.A.; Wang, W.; King, D.T.; De Pascale, G.; Strynadka, N.C.; Walsh, T.R.; Coombes,
B.K.; Wright, G.D. Aspergillomarasmine a overcomes metallo‐β‐lactamase antibiotic resistance. Nature
2014, 510, 503–506.
30. Chen, A.Y.; Thomas, P.W.; Stewart, A.C.; Bergstrom, A.; Cheng, Z.; Miller, C.; Bethel, C.R.; Marshall, S.H.;
Credille, C.V.; Riley, C.L.; et al. Dipicolinic acid derivatives as inhibitors of new delhi metallo‐β‐lactamase‐
1. J. Med. Chem. 2017, 60, 7267–7283.
31. Thomas, P.W.; Cammarata, M.; Brodbelt, J.S.; Fast, W. Covalent inhibition of new delhi metallo‐β‐
lactamase‐1 (ndm‐1) by cefaclor. Chembiochem 2014, 15, 2541–2548.
32. Chiou, J.; Wan, S.; Chan, K.F.; So, P.K.; He, D.; Chan, E.W.; Chan, T.H.; Wong, K.Y.; Tao, J.; Chen, S. Ebselen
as a potent covalent inhibitor of new delhi metallo‐β‐lactamase (ndm‐1). Chem. Commun. 2015, 51, 9543–
9546.
33. Vraspir, J.M.; Butler, A. Chemistry of marine ligands and siderophores. Annu. Rev. Mar. Sci. 2009, 1, 43–63.
34. Chen, J.; Guo, Y.; Lu, Y.; Wang, B.; Sun, J.; Zhang, H.; Wang, H. Chemistry and biology of siderophores
from marine microbes. Mar. Drugs 2019, 17, 562.
35. Carmichael, J.R.; Zhou, H.; Butler, A. A suite of asymmetric citrate siderophores isolated from a marine
shewanella species. J. Inorg. Biochem. 2019, 198, 110736.
36. Hardy, C.D.; Butler, A. Ambiguity of nrps structure predictions: Four bidentate chelating groups in the
siderophore pacifibactin. J. Nat. Prod. 2019, 82, 990–997.
37. Johnstone, T.C.; Nolan, E.M. Beyond iron: Non‐classical biological functions of bacterial siderophores.
Dalton Trans. 2015, 44, 6320–6339.
38. Schalk, I.J.; Hannauer, M.; Braud, A. New roles for bacterial siderophores in metal transport and tolerance.
Environ. Microbiol. 2011, 13, 2844–2854.
39. Li, K.; Chen, W.H.; Bruner, S.D. Microbial siderophore‐based iron assimilation and therapeutic
applications. Biometals 2016, 29, 377–388.
40. Ockels, W.; Römer, A.; Budzikiewicz, H. An fe(ii) complex of pyridine‐2,6‐di‐(monothiocarboxylic acid) ‐ a
novel bacterial metabolic product‐sciencedirect. Tetrahedron Lett. 1978, 19, 3341–3342.
41. Lewis, T.A.; Paszczynski, A.; Gordon‐Wylie, S.W.; Jeedigunta, S.; Lee, C.H.; Crawford, R.L. Carbon
tetrachloride dechlorination by the bacterial transition metal chelator pyridine‐2,6‐bis(thiocarboxylic acid).
Environ. Sci. Technol. 2001, 35, 552–559.
42. Lewis, T.A.; Leach, L.; Morales, S.; Austin, P.R.; Hartwell, H.J.; Kaplan, B.; Forker, C.; Meyer, J.M.
Physiological and molecular genetic evaluation of the dechlorination agent, pyridine‐2,6‐
bis(monothiocarboxylic acid) (pdtc) as a secondary siderophore of pseudomonas. Environ. Microbiol. 2004,
6, 159–169.
43. Leach, L.H.; Morris, J.C.; Lewis, T.A. The role of the siderophore pyridine‐2,6‐bis (thiocarboxylic acid)
(pdtc) in zinc utilization by pseudomonas putida dsm 3601. Biometals 2007, 20, 717–726.
44. Sebat, J.L.; Paszczynski, A.J.; Cortese, M.S.; Crawford, R.L. Antimicrobial properties of pyridine‐2,6‐
dithiocarboxylic acid, a metal chelator produced by pseudomonas spp. Appl. Environ. Microbiol. 2001, 67,
3934–3942.
45. Cortese, M.S.; Paszczynski, A.; Lewis, T.A.; Sebat, J.L.; Borek, V.; Crawford, R.L. Metal chelating properties
of pyridine‐2,6‐bis(thiocarboxylic acid) produced by pseudomonas spp. And the biological activities of the
formed complexes. Biometals 2002, 15, 103–120.
46. Roll, D.M.; Yang, Y.; Wildey, M.J.; Bush, K.; Lee, M.D. Inhibition of metallo‐beta‐lactamases by pyridine
monothiocarboxylic acid analogs. J. Antibiot. 2010, 63, 255–257.
47. Laatsch, H. Antibase; Wiley‐VCH: Hoboken, NJ, USA, 2012.

Mar. Drugs 2020, 18, 295
13 of 13
48. Thomas, P.W.; Zheng, M.; Wu, S.; Guo, H.; Liu, D.; Xu, D.; Fast, W. Characterization of purified new delhi
metallo‐beta‐lactamase‐1. Biochemistry 2011, 50, 10102–10113.
49. Chen, C.; Sun, L.Y.; Gao, H.; Kang, P.W.; Li, J.Q.; Zhen, J.B.; Yang, K.W. Identification of cisplatin and
palladium(ii) complexes as potent metallo‐β‐lactamase inhibitors for targeting carbapenem‐resistant. ACS
Infect. Dis. 2020. doi:10.1021/acsinfecdis.9b00385.
50. Chatterjee, P.B.; Crans, D.C. Solid‐to‐solid oxidation of a vanadium (iv) to a vanadium (v) compound:
Chemisty of a sulfur‐containing siderophore. Inorg. Chem. 2012, 51, 9144–9146.
51. Reich, H.J. Windnmr: Dynamic nmr spectra for windows. J. Chem. Educ. 1995, 72, 1086.
52. Tropea, J.E.; Cherry, S.; Waugh, D.S. Expression and purification of soluble his ‐tagged tev protease. In
6
Methods in Molecular Biology: High Throughput Protein Expression; Doyle, S.A., Ed.; Humana Press: Totowa,
NJ, USA, 2009; Volume 498.
53. Gasteiger, E.; Hoogland, C.; Gattiker, A.; Duvaund, S.; Wilkins, M.R.; Appel, R.D.; Bairoch, A. Protein
identification and analysis tools on the expasy server. In The Proteomics Protocols Handbook; Walker, J.M.,
Ed.; Humana Press: Totowa, NJ, USA, 2005; pp. 571–607.
54. Cockerill, F., III.; Wikler, M.; Alder, J.; Dudley, M.; Eliopoulos, G.; Ferraro, M.J.; Hardy, D.; Hecht, D.;
Hindler, J.; Patel, J.; et al. Methods for Dilution Antimicrobial Susceptibility Tests for Bacteria that Grow
Aerobically, 9th ed.; Clinical Laboratory Standards Institute: Wayne, PA, USA, 2012; Volume 32.
© 2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
