Functionally Versatile and Highly Stable Chelator for 111In and 177Lu:
Proof-of-principle Prostate Specific Membrane Antigen Targeting
LILY LI, María de Guadalupe Jaraquemada-Peláez, Hsiou-Ting Kuo, Helen Merkens,
Neha Choudhary, Katrin Gitschalter, Una Jermilova, Nadine Colpo, Carlos Uribe-Munoz,
Valery Radchenko, Paul Schaffer, Kuo-Shyan Lin, Francois Benard, and Chris Orvig
Bioconjugate Chem., Just Accepted Manuscript • DOI: 10.1021/acs.bioconjchem.9b00225 • Publication Date (Web): 22 Apr 2019
Downloaded from http://pubs.acs.org on April 23, 2019
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a service to the research community to expedite the dissemination
of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts appear in
full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been fully
peer reviewed, but should not be considered the official version of record. They are citable by the
Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered to authors. Therefore,
the “Just Accepted” Web site may not include all articles that will be published in the journal. After
a manuscript is technically edited and formatted, it will be removed from the “Just Accepted” Web
site and published as an ASAP article. Note that technical editing may introduce minor changes
to the manuscript text and/or graphics which could affect content, and all legal disclaimers and
ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors or
consequences arising from the use of information contained in these “Just Accepted” manuscripts.
is published by the American Chemical Society. 1155 Sixteenth Street N.W.,
Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 37
Bioconjugate Chemistry
1
2
3
4
5
6
Functionally Versatile and Highly Stable Chelator for 111In and 177Lu: Proof-of-principle Prostate
Specific Membrane Antigen Targeting
7
8
9
Lily Lia,c, María de Guadalupe Jaraquemada-Peláeza, Hsiou-Ting Kuod, Helen Merkensd Neha
,
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Choudharya,c, Katrin Gitschtalerd, Una Jermilovaa, Nadine Colpod, Carlos Uribe-Munozd, Valery
Radchenkob,c, Paul Schafferc, Kuo-Shyan Lind, François Bénardd*, Chris Orviga*
a Medicinal Inorganic Chemistry Group, Department of Chemistry, University of British
Columbia, 2036 Main Mall, Vancouver, British Columbia V6T 1Z1, Canada
b Department of Chemistry, University of British Columbia, 2036 Main Mall, Vancouver, British
Columbia V6T 1Z1, Canada
c Life Sciences Division, TRIUMF, 4004 Wesbrook Mall, Vancouver, British Columbia V6T
2A3, Canada
d Department of Molecular Oncology, BC Cancer, 675 West 10th Ave, Vancouver, British
Columbia V5Z 1L3, Canada
Abstract
Here, we present the synthesis and characterization of a new potentially nonadentate chelator,
t
H4pypa and its bifunctional analog Bu4pypa-C7-NHS conjugated to PSMA (prostate-specific
membrane antigen) - targeting peptidomimetic (Glu-urea-Lys). H4pypa is very functionally
versatile and biologically stable. Compared to the conventional chelators (e.g. DOTA, DTPA),
H4pypa has outstanding affinities for both 111In (EC, t1/2 ~2.8 d) and 177Lu (-, t1/2~6.64 d). Its
radiolabeled complexes were achieved at >98% radiochemical yield, RT within 10 minutes, at
ligand concentration as low as 10-6 M, with excellent stability in human serum over at least 5-7
days (<1% transchelation). The thermodynamic stabilities of the [M(pypa)]- complexes (M3+
=
In3+, Lu3+, La3+) were dependent on the ionic radii, where the smaller In3+ has the highest pM value
(30.5), followed by Lu3+ (22.6) and La3+ (19.9). All pM values are remarkably higher than those
with DOTA, DTPA, H4octapa, H4octox and H4neunpa. Moreover, the facile and versatile
bifunctionalization enabled by the p-OH group in the central pyridyl bridge of the pypa scaffold
(compound 14) allows incorporation of a variety of linkers for bioconjugation through easy
nucleophilic substitution. In this work, an alkyl linker was selected to couple H4pypa to a PSMA-
targeting pharmacophore, proving that the bioconjugation sacrifices neither the tumor-targeting
1
ACS Paragon Plus Environment

Bioconjugate Chemistry
Page 2 of 37
1
2
3
4
5
6
nor the chelation properties. The biodistribution profiles of 111In- and 177Lu-labeled tracers are
different, but promising, with the 177Lu analog particularly outstanding.
7
8
Introduction
9
The potential of radionuclides in cancer diagnosis and therapy has been recognized for decades
since the discovery of radioactivity in 1901.1 The specificity and minimal invasiveness of targeted
radionuclide therapy compared to chemotherapy has poised the field for further growth, stimulated
by the technological advancements in production of both radionuclides and biological targeting
vectors (e.g. peptides and monoclonal antibodies). The biological safety of the radiometal is
ensured by a stably bound chelator coupled to a bio-targeting vector via a covalent linkage, which
also modulates the pharmacokinetics of the whole. 2-4
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
An ideal chelator should possess rapid complexation kinetics and strong affinity for the radiometal
ion at mild conditions (RT, <15 minutes complexation), as well as high versatility of linker
incorporation (i.e. bifunctionalization) without sacrificing the coordination integrity. Although a
small peptidomimetic conjugate usually has higher tolerance to the harsh radiolabeling conditions
(e.g. 60-90 oC for 1,4,7,10-tetraazacyclododecane-1,4,7,10-tetraacetic acid, DOTA, Chart 1), fast
and quantitative radiolabeling at room temperature facilitate handling and avoid potential
degradation of the product. One of the benefits is that instead of relying on central manufacturing,
clinicians can conveniently prepare the radioactive tracer in a local hospital, which mimics the
existing practice for 99mTc kits.5 In terms of bifunctionalization, most of the commercial chelators
including DOTA and diethylenetriamine-pentaacetic acid (DTPA), lack a convenient spot for
adding a linker. The cumbersome functionalization on the polyamine backbone or the sacrifice of
a pendant arm can complicate the synthesis while restricting the linker variety, or even reduce the
complex stability.6-8 Additionally, a practically and clinically useful chelator should accommodate
(a pair of) theranostic isotopes (e.g. 177Lu, 111In, 86/90Y, 44/47Sc) for an accurate study of dosimetry
to achieve optimal therapeutic effects. In this regard, 177Lu (t1/2 ~ 6.64 days) is well-recognized for
treating small and metastatic tumors with its low-energy - particles (maximum 498 keV),9 along
with two useful  emissions (208 keV and 113 keV) for SPECT imaging, rendering it an excellent
theranostic isotope with a favorable half-life.10 The high thermal neutron capture cross section of
176Lu also allows direct production of 177Lu [176Lu(n,γ)177Lu] with high specific activity at multi-
Curie activity levels to meet the impending demand for targeted cancer therapy.11, 12 Of course,
2
ACS Paragon Plus Environment

Page 3 of 37
Bioconjugate Chemistry
1
2
3
4
no-carrier-added (n.c.a.) 177Lu can also be produced through an indirect route (176Yb(n,)177Yb→
5
6
7
8
177Lu).12, 13 Another potential theranostic radioisotope is the -ray and Auger-electron-emitting
111In (t1/2 ~ 2.8 days), which has proved induction of cytocidal double-strand break (DSBs) upon
internalization and translocation to the nucleus of the tumor cells, besides its widespread
applications in SPECT imaging. 2, 14-17
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
To overcome the practical concerns on the radiolabeling conditions and the complex stability
encountered with the current commercial chelators, we report herein the synthesis and
characterization of a new potentially nonadentate pyridinecarboxylate-based ligand, H4pypa and a
bifunctional H4pypa conjugated to glutamate-urea-lysine-based PSMA (prostate-specific
membrane antigen)-targeting pharmacophore for prostate cancer (PCa) targeting. PCa is the most
common cancer in men in the United States accounting for around 26,730 deaths in 2017.18 PSMA
is primarily expressed in normal human prostate epithelium, but is up-regulated in prostate cancer
cells, even more in de-differentiated, metastatic and hormone-refractory carcinomas, rendering it
an attractive target in PCa.19 The current FDA-approved 111In-capromab pendetide scan
(ProstaScint® scan) has several drawbacks such as inducing the formation of human anti-mouse
antibody (HAMA) and targeting the intracellular epitope of PSMA, which somewhat limit its
applications.20, 21 The Glu-urea-Lys PSMA inhibitor adopted in this study was developed by
Maresca et al.,22 and the lipophilic spacer was suggested to improve the pharmacokinetics by
Benešová et al. who conjugated the whole moiety to DOTA (a.k.a. PSMA617) for 68Ga and 177Lu
radiolabels.23 In this paper, we show that both H4pypa and its PSMA-targeting counterpart
radiolabel 111In and 177Lu in excellent yield and stability with the LNCaP-tumor targeting ability
preserved. Moreover, the thermodynamic stabilities of M-pypa systems (M=In3+, Lu3+, La3+)
measured as pM are considerably higher than those with DOTA, DTPA, H4octapa, H4octox and
H4neunpa. In addition to chelation, a significant advantage of the pyridyl bridge is the facile and
versatile linker attachment via the central hydroxyl group. Undeniably, linkages play a pivotal role
in the biological behavior of the radiochelate, particularly the small peptide conjugates.23-27
Therefore, this versatility provides flexibility in not only the chemical properties of the whole (e.g.
hydrophilic, hydrophobic), but also the targeting vectors associated (e.g. peptide, antibody,
antibody fragment, nanoparticles).3 The combination renders H4pypa a promising theranostic
chelating agent for many different cancer treatments, despite the focus here on prostate cancer.
