structure. In Figure 1(b), the preheated film shows only a weak
Raman band of Ge–C bond at 537 cmꢂ1 accompanying the
disappearance of the bands attributed to C–C bonds. This must be
due to the conversion of tert-butyl group to Ge–C network
structure because the cross section of the vibration of Ge–C
network is very small.9 The Ge–C structure is expected to be a
cross-link structure where carbon enters the germanium network.
The laser-induced pyrolysis converted the Ge–C structure to
amorphous carbon. Contrary to this, the organic substituent is
effectively eliminated and the crystallization of Ge is observed in
the case of the laser-induced pyrolysis of unheated OGE film. The
Ge–C network structure is the reason why the elimination of the
carbon from the preheated precursor film is more difficult than
that from the unheated precursor film.
Figure 2(a) and (b) show the optical micrographs of films
obtained by laser-induced pyrolysis using unheated and preheated
precursor films, respectively. Although the formation of the large
grains which correspond to ꢀc-Ge is observed in both cases, the
size of the grain is different. The unheated OGE gives lager grain
than that of the preheated OGE. This difference is due to the cross-
linkage of preheated OGE. The cross-linkage of Ge–C network
structure reduces the melting of the precursor film during laser
irradiation and then decreases the grain size.
Figure 3. Raman spectra of the film obtained by Ar
ion laser-induced pyrolysis of OGE after preheating at
200 ꢁC. (a) unirradiated region, (b) irradiatted region.
film. The width of the line corresponds to the diameter of the
focused laser beam. Grains are formed symmetrically around the
centerline where the energy density is maximum. The Raman
spectra of irradiated and unirradiated regions are shown in Figure
3. In the measurements, the excitation energy density of laser
beam was lowered enough to inhibit the laser-induced structural
change. The sharp band at 300 cmꢂ1 of irradiated region [Figure
3(b)] is assigned to ꢀc-Ge, while broad band at 280cm ꢂ1 of
unirradiated region [Figure 3(a)] is assigned to a-Ge. This result
suggests that spatially selective formation of ꢀc-Ge can be
achieved by laser-induced pyrolysis of OGE film. In this
preliminarily experiment, a preheated OGE film was used as a
precursor because the unheated OGE film (0.27 ꢀm in thickness)
has low absorbance at 514.5 nm. The optical densities of the
unheated and the preheated OGE films in this study are 0.045 and
0.079 at 514.5 nm, respectively. The optimization of the
wavelength of the CW laser beam and the optical instruments
enables to depict the micropattern of ꢀc-Ge by scanning the laser
beam on the OGE precursor film.
The laser-induced pyrolysis of OGE film is also caused by
focusing the CW (continuous wave) laser beam. Figure 2(c)
shows the optical micrograph of preheated OGE film irradiated at
514.5 nm line of an Ar ion laser, where the laser beam was focused
on the film using an objective lens (ꢃ100) with the energy density
of ca. 1 MW/cm2. The horizontal line in the micrograph was
drawn by scanning the focused laser beam on the flat precursor
In conclusion, the spatially selective formation of ꢀc-Ge by
laser-induced pyrolysis of OGE film is demonstrated. This is a
new method to form a micropattern of ꢀc-Ge, and the formation
of a micropattern of Si–Ge alloy is expected by laser-induced
pyrolysis of spin-coated OGE on Si substrate.
This work was supported by a Grant-in-Aid for Scientific
Research (Nos. 1155900, 13650942) from the Ministry of
Education, Science and Culture of Japan.
References and Notes
1
2
F. Schaffler, Semicond. Sci. Technol., 12, 1515 (1997).
A. Watanabe, M. Unno, F. Hojo, and T. Miwa, J. Mater. Sci. Lett., 20,
491 (2001).
3
A. Watanabe, M. Unno, F. Hojo, and T. Miwa, Mater. Lett., 47, 89
(2001).
4
5
A. Watanabe, M. Unno, F. Hojo, and T. Miwa, Chem. Lett., 2001, 1092.
A. Watanabe, M. Fujitsuka, O. Ito, and T. Miwa, Jpn. J. Appl. Phys., 36,
L1265 (1997).
6
A. Watanabe, M. Fujitsuka, O. Ito, and T. Miwa, Mol. Cryst. Liq. Cryst.,
316, 363 (1998).
Figure 2. Optical micrographs of films obtained by
