Four new cyclometalated phenylisoquinoline-based Ir(III) complexes:
Syntheses, structures, properties and DFT calculations
Zhi-Gang Niu a, Dong Liu a, Da-Chao Li a, Jing Zuo a, Jian-Ming Yang a, You-Hui Su a,
Yi-Ding Yang a, Gao-Nan Li a,b,
⁎
a
College of Chemistry and Chemical Engineering, Hainan Normal University, Haikou 571158, PR China
State Key Laboratory of Coordination Chemistry, School of Chemistry and Chemical Engineering, Nanjing University, Nanjing 210093, PR China
b
a r t i c l e i n f o
a b s t r a c t
Four new cyclometalated phenylisoquinoline-based iridium(III) complexes [Ir(C∧N)2(bipy)]PF6 (5a–5d) (bipy =
2,2′-bipyridine) have been synthesized and fully characterized, where the C∧N ligands are 1-(4-(trifluoromethyl)
phenyl)isoquinoline, 4-(isoquinolin-1-yl)benzaldehyde, 4-(isoquinolin-1-yl)benzonitrile and 1-(3-fluoro-4-
methylphenyl)isoquinoline, respectively. The crystal structures of 5a and 5c have been determined. The
photophysical and electrochemical properties of these new complexes 5a–5d have been studied. All Ir(III) com-
plexes exhibit orange phosphorescence in dichloromethane solution at room temperature with a maximum at
593–618 nm, quantum yield of 0.046–0.16. The frontier molecular orbital diagrams and the lowest-energy
electronic transitions of 5a–5d have been calculated with density functional theory (DFT) and time-dependent
DFT (TD-DFT).
Article history:
Received 8 October 2013
Accepted 20 February 2014
Available online 1 March 2014
Keywords:
Iridium(III) complex
Phenylisoquinoline
Syntheses
Crystal structures
Photoluminescence
DFT calculation
© 2014 Elsevier B.V. All rights reserved.
Currently, a considerable amount of interests have been drawn to
the application of iridium(III) complexes in organic light-emitting de-
vices (OLEDs), as they have high phosphorescence quantum efficiency,
long excited-state lifetime and excellent color tunability [1–3]. In gener-
al, the structure and even the position of the substituents on the ligand
framework play important roles in tuning the photophysical properties
of Ir(III) complexes [4,5]. Meanwhile, substantial researches on iridium
complexes have showed that the introduction of a strongly electron-
withdrawing group in the cyclometalating ligand could eventually
cause a great increase of the luminescence efficiency [6,7]. These results
prompted us to systematically study the effects on emissive colors and
quantum efficiencies of different electron-withdrawing substituents
on cyclometalating ligand. Therefore, we chose 1-phenylisoquinoline
(piq) as the cyclometalated ligand with electron-withdrawing substitu-
ents (\CF3, \CHO, \CN and \F) to synthesize a series of ionic
iridium(III) complexes 5a–5d. The photophysical and electrochemical
properties of these complexes were investigated, and the lowest-
energy electronic transitions were analyzed based on density functional
theory (DFT) and time-dependent DFT (TDDFT).
The C^N ligands 4-(isoquinolin-1-yl)benzaldehyde (3b) and 1-(3-
fluoro-4-methylphenyl)isoquinoline (3d) were both synthesized by
the suzuki reaction between 1-chloroisoquinoline and 1.1 equivalents
of substituted phenylboronic acids [8]. The other two C^N ligands
1-(4-(trifluoromethyl)phenyl)isoquinoline (3a) and 4-(isoquinolin-1-
yl)benzonitrile (3c) were prepared according to the literature proce-
dure [9,10]. The reaction of 3a–3d with iridium trichloride hydrate
yielded four new precursors [(C^N)2Ir(μ-Cl)]2 (4a–4d). The correspond-
ing iridium(III) complexes (5a–5d, Scheme 1) were then produced by
the reaction of 4a–4d with the N^N ligand 2,2′-bipyridine [11]. Charac-
terization of all these new compounds has been accomplished by 1H
NMR and mass spectroscopies. In 1H NMR spectra of 5a–5d, the ratio
of the C^N to N^N ligands is 2:1, which suggests that the chemical
formula of each Ir(III) complex is [(C^N)2Ir(N^N)](PF6).
The structures of complexes 5a and 5c were determined at room
temperature [12]. As shown in Fig. 1, the Ir(III) ion in each cationic com-
plex is in a distorted octahedral [(C∧N)2Ir(N∧N)]+ coordination geome-
try with the C and N atoms of two phenylisoquinoline-based (C∧N)
ligands and the N atoms of bipyridine (N∧N) ligand. The average dis-
tances of Ir\N (2.108 Å for 5a, 2.097 Å for 5c) and Ir\C (2.003 Å for
5a, 2.000 Å for 5c) are typical for this type of complexes [13,14]. In par-
ticular, the Ir\N bond lengths from N∧N ligands are shorter than those
from C∧N ligands. Also, the two N atoms of the C∧N ligands are trans-
position to each other. The X-ray data show a large torsion angle for
complex 5a [C8–C9–C10–C16, −14.70°], which suggest that the \CF3
⁎
Corresponding author at: College of Chemistry and Chemical Engineering,
Hainan Normal University, Haikou 571158, PR China. Tel.: +86 898 31381637;
fax: +86 898 65889422.
E-mail address: ligaonan2008@163.com (G.-N. Li).
http://dx.doi.org/10.1016/j.inoche.2014.02.031
1387-7003/© 2014 Elsevier B.V. All rights reserved.

Z.-G. Niu et al. / Inorganic Chemistry Communications 43 (2014) 146–150
147
Scheme 1. Synthetic routes of C^N ligands 3a–3d and Ir(III) complexes 5a–5d.
group can cause larger molecular deformation. However, the torsion
angle [C8–C9–C11–C12] of complex 5c with \CN group is only 0.63°,
indicating that the 4-(isoquinolin-1-yl)benzonitrile ligand is
almost coplanar.
spectra of 5a–5d display the vibronically structured emission bands
3
3
3
3
⁎
arose from a mixture of LC ( π–π ) and CT ( MLCT) excited states.
Phosphorescence relative quantum yields (Φ) of 5a–5d in dichloro-
methane solution were measured to be 0.046–0.16 (Table 1) at
room temperature by using typical phosphorescent fac-Ir(ppy)3 as a
standard (Φ = 0.40) [4,23]. Compared with the parent complex
[Ir(piq)2(bpy)](PF6) (Φ = 0.089) [24], the introduction of the C\F
bond or \CF3 group in complexes 5b and 5d results in the increase of
the luminescence quantum yield dramatically. This is probably due to
the presence of the C\F bonds that could reduce the radiationless deac-
tivation rate in comparison with C\H bonds [6,25]. Additionally, the
electron-withdrawing substituents (\CHO and \CN) in the same site
of the ligand lead to a decrease in the phosphorescence quantum yield
for complexes 5a and 5c.
The electrochemical properties of the complexes 5a–5d were
studied by cyclic voltammetry (Fig. 5). All complexes show a pair of
reversible redox peaks, with potentials of 1.27–1.65 V. The positive
oxidation potential is attributed to the metal-centered Ir3+/Ir4+ oxida-
tion couple [26,27], because the higher oxidation potentials are ascribed
to the stronger electron-withdrawing ability of the substituent on
phenylisoquinoline ligands. Based on the electrochemical data, the
complexes can be arranged in the increasing order as follows:
5c N 5a N 5b N 5d, which is consistent with the actual electron-with-
drawing ability of \CN N \CF3 N \CHO N \F. The HOMO energy
deduced by the equation EHOMO = −(Eox + 4.8 eV) [28] is listed in
Table 1, as well as compared with the theoretical calculation results.
From the results, it can be seen that the HOMO orbital energy also
reveals the order as 5c N 5a N 5b N 5d.
The absorption spectra of complexes 5a–5d in CH2Cl2 solution are
presented in Fig. 2 and the spectral data are summarized in Table 1. In
common with most Ir(III) complexes [15–17], the absorption spectra
of 5a–5d are dominated by multiple bands originating from ligand-
⁎
centered π–π transitions and MLCT transitions. The strong absorption
bands of the higher energies (below 350 nm) are mainly assigned to
the spin-allowed intraligand 1(π–π ) transitions [18]. The moderate
⁎
absorption peaks of lower-energies (350–550 nm) are likely due to
charge-transfer (CT) transitions, with their nature being both spin-
allowed (singlet-to-singlet metal-to-ligand charge transfer, 1MLCT)
[19] and spin-forbidden (singlet-to-triplet metal-to-ligand charge
3
3
⁎
transfer, MLCT and ligand-centered π–π transition) [20].
Density functional theory (DFT) and time-dependent DFT (TDDFT)
calculations have been performed for complexes 5a–5d to gain insights
into the lowest-energy electronic transition (435 nm for 5a, 456 nm for
5b, 442 nm for 5c, 434 nm for 5d). The representative molecular frontier
orbital diagrams have been presented in Fig. 3 and the calculated spin-
allowed electronic transitions and electron density distributions are
listed in Tables S1 and S2. The electron density in the HOMO/HOMO-1
of all the complexes 5a–5d resides significantly on the cyclometalating
ligands and the core Ir(III) atom. The electron density in LUMO + 1
(5a) and LUMO + 2 (5c) locates mainly on the cyclometalating ligand
and ancillary ligand, while the electron density in LUMO (5b) and
LUMO + 2 (5d) locates primarily on the cyclometalating ligand.
⁎
All these electronic transitions are ascribed as LLCT and MLCT π → π
In conclusion, four new cyclometalated phenylisoquinoline-based
iridium(III) complexes [Ir(C∧N)2(N∧N)]PF6 (5a–5d) with the N∧N li-
gand 2,2′-bipyridine and four different C∧N cyclometalating ligands
have been synthesized. The photophysical properties, electrochemical
behaviors and theoretical calculations have been investigated. X-ray dif-
fraction studies of complexes 5a and 5c indicate that the coordinations
of the iridium atoms are both distorted octahedral. Analyses of DFT and
TDDFT calculations for 5a–5d indicate that the lowest-energy electronic
transition, which are consistent with the actual absorptions.
All complexes are luminescent at room temperature in CH2Cl2 solu-
tion (Fig. 4). Upon photoexcitation at ca. 360 nm, the complexes 5a–5d
show intense orange luminescence with the emission peak appeared at
593–618 nm, and display the wavelength order as 5b N 5c N 5a N 5d
(Table 1). The results are in good agreement with those of the lowest-
energy electronic transition in UV–Vis spectra and DFT calculations
(Table S1). As compared with 5b and 5c, 5a and 5d exhibit the blue-
shifted emission spectra, which can be explained by steric hindrance
of 4-CF3, 4-Me and 3-F group. According to analogous iridium(III)
cyclometalates reported in references [21,22], the photoluminescence
⁎
transitions are attributed to MLCT and LLCT π → π transition. Each
Ir(III) complex shows orange emission with a maximum main peak
and a shoulder peak, which is suggested to be a mixture of 3LC
3
( π–π ) and 3CT (3MLCT) excited states. The results will facilitate the
⁎

148
Z.-G. Niu et al. / Inorganic Chemistry Communications 43 (2014) 146–150
Table 1
Photophysical and electrochemical data for complexes 5a–5d.
a
Complex Absorption
abs (nm)
Emission Φem
em (nm)
Eox
(eV) (eV)
HOMOb HOMOc
λ
λ
(eV)
5a
5b
5c
5d
285, 341, 356, 379, 435 594
294, 345, 360, 398, 456 618
288, 343, 359, 384, 442 604
293, 345, 357, 374, 434 593
0.14
1.63 −6.43
−6.044
−6.043
−6.177
−5.266
0.046 1.54 −6.34
0.074 1.65 −6.45
0.16
1.37 −6.17
a
fac-Ir(ppy)3 as referenced standard (0.4) [4,23].
HOMO = −(Eox + 4.8 eV).
Obtained from theoretical calculations.
b
c
design of new phenylisoquinoline-based ligands for light-emitting
iridium complexes.
Acknowledgments
This work was supported by the Science and Research Project of
Education Department of Hainan Province (No. Hjkj2013-25), the
Natural Science Foundation of Hainan Province (No. 21401), (The
research of novel ionic iridium(III) complexes: syntheses, struc-
tures and optoelectronic properties) and the National Innovation
Experiment Program for University Students (Nos. 201311658021,
201311658023).
Appendix A. Supplementary material
CCDC 962809 and 962810 contain the supplementary crystallo-
graphic data of 5a and 5c. These data can be obtained free of charge
from the Cambridge Crystallographic Data Centre via www.ccdc.cam.
ac.uk/data_request/cif. Other supplementary data associated with this
article: Crystallographic data for 5a and 5c in CIF format. Calculated
spin-allowed electronic transitions and electron density distributions
for 5a–5d. Supplementary data associated with this article can be
found, in the online version, at http://dx.doi.org/10.1016/j.inoche.
2014.02.031.
References
[1] K.R.J. Thomas, M. Velusamy, J.T. Lin, C.H. Chien, Y.T. Tao, Y.S. Wen, Y.H. Hu, P.T. Chou,
Efficient red-emitting cyclometalated iridium(III) complexes containing lepidine-
based ligands, Inorg. Chem. 44 (2005) 5677–5685.
[2] M.A. Baldo, C. Adachi, S.R. Forrest, Transient analysis of organic electrophosphorescence.
II. Transient analysis of triplet–triplet annihilation, Phys. Rev. B 62 (2000)
10967–10977.
[3] J.M. Lupton, I.D.W. Samuel, M.J. Frampton, R. Beavington, P.L. Burn, Control of
electrophosphorescence in conjugated dendrimer light-emitting diodes, Adv.
Funct. Mater. 11 (2001) 287–294.
[4] Q.L. Xu, C.C. Wang, T.Y. Li, M.Y. Teng, S. Zhang, Y.M. Jing, X. Yang, W.N. Li, C. Lin, Y.X.
Zhen, J.L. Zuo, X.Z. You, Syntheses, photoluminescence, and electroluminescence of a
series of iridium complexes with trifluoromethyl-substituted 2-phenylpyridine as
the main ligands and tetraphenylimidodiphosphinate as the ancillary ligand,
Inorg. Chem. 52 (2013) 4916–4925.
Fig. 1. ORTEP view of complexes 5a (top) and 5c (bottom) with an atom-numbering
scheme at the 50% probability level. Hydrogen atoms, solvent molecules and PF6 anion
are omitted for clarity.
[5] S. Lamansky, P. Djurovich, D. Murphy, F. Abdel-Razzaq, H.E. Lee, C. Adachi, P.E.
Burrows, S.R. Forrest, M.E. Thompson, Highly phosphorescent bis-cyclometalated
iridium complexes: synthesis, photophysical characterization, and use in organic
light emitting diodes, J. Am. Chem. Soc. 123 (2001) 4304–4312.
[6] C.L. Ho, W.Y. Wong, Q. Wang, D. Ma, L. Wang, Z. Lin, A multifunctional iridium–
carbazolyl orange phosphor for high-performance two-element WOLED exploiting
exciton-managed fluorescence/phosphorescence, Adv. Funct. Mater. 18 (2008)
928–937.
[7] F. Babudri, G.M. Farinola, F. Naso, R. Ragni, Fluorinated organic materials for elec-
tronic and optoelectronic applications: the role of the fluorine atom, Chem.
Commun. (2007) 1003–1022.
[8] Synthesis of 3b: A mixture of 1 (2.0 mmol), 2b (2.2 mmol), Pd(dppf)2Cl2 (5 10 mg)
and potassium acetate (4.0 mmol) were dissolved in anhydrous 1,4-dioxane (10
mL) and heated at 90 °C under nitrogen for 10 h. After cooled to room temperature,
the mixture was poured into water (20 mL) and extracted with dichloromethane.
The combined organic layers were dried with anhydrous Na2SO4 and concentrated
in vacuum. The crude product was purified by column chromatography with petro-
leum ether/ethyl acetate (50:1) eluent to afford pure product 3b as a white solid.
Yield: 92%. 1H NMR (400 MHz, CDCl3) δ 10.15 (s, 1H), 8.64 (d, J = 5.2 Hz, 1H),
8.02 8.07 (m, 3H), 7.93 (d, J = 8.0 Hz, 1H), 7.89 (d, J = 7.6 Hz, 2H), 7.71 7.75
(m, 2H), 7.58 (t, J = 7.6 Hz, 1H). MS-ESI: m/z calculated: 233.1; found: 234.1
Fig. 2. Electronic absorption spectra of 5a–5d in CH2Cl2 at room temperature.

Z.-G. Niu et al. / Inorganic Chemistry Communications 43 (2014) 146–150
149
5a
HOMO (-6.044 eV)
LUMO+1 (-2.620 eV)
5b
5c
5d
HOMO (-6.043 eV)
HOMO (-6.177 eV)
HOMO-1 (-5.959 eV)
LUMO (-2.881 eV)
LUMO+2 (-2.752 eV)
LUMO+2 (-2.541 eV)
Fig. 3. The frontier molecular orbital diagrams of complexes 5a–5d from DFT calculations.
(M + 1); Synthesis of 3d: 3d was obtained by a method similar to the preparation
of 3b. Yield: 86%. 1H NMR (400 MHz, CDCl3) δ 8.59 (d, J = 5.2 Hz, 1H), 8.11
(d, J = 8.4 Hz, 1H), 7.87 (d, J = 8.4 Hz, 1H), 7.63 7.69 (m, 2H), 7.54 (t, J = 7.6 Hz,
1H), 7.32 7.39 (m, 3H), 2.38 (s, 3H). MS-ESI: m/z calculated: 237.1.2; found: 238.1
(M+).
[11] Synthesis of 5a: A mixture of IrCl3·3H2O (1.0 mmol) and the ligand 3a in 9 mL of
ethoxyethanol and H2O (v:v = 2:1) was refluxed for 12 h. Upon cooling to room
temperature, the orange precipitate was collected by filtration and washed with
cooled MeOH. After drying, the crude product of cholorobridged dimer complex
4a was used directly in next step without further purification. A mixture of the
above dimer complex 4a and 2,2′-bipyridine (2.0 equiv.) was dissolved in 8 mL of
DCM and MeOH (v:v = 3:1) was refluxed for 6 h under nitrogen. The orange-red
solution was then cooled to room temperature, and NH4PF6 (2.5 equiv.) was
added to the solution. The mixture was stirred at room temperature for 3 h,
and then evaporated to dryness. The solid was purified by column chromatography
[9] H.H. Rhoa, Y.H. Parkb, Y.H. Leeb, N.G. Parkc, Y. Had, Y.S. Kimd, Synthesis and
photophysical studies of iridium complexes of fluorinated phenylisoquinolines,
Mol. Cryst. Liq. Cryst. 444 (2006) 145–155.
[10] C.I. Stathakis, M.S.S. Bernhardt, B.S.V. Quint, P. Knochel, Improved air-stable solid
aromatic and heterocyclic zinc reagents by highly selective metalations for negishi
cross-couplings, Angew. Chem. Int. Ed. 51 (2012) 9428–9432.
to afford pure product 5a, Yield 68%. 1H NMR (400 MHz, CDCl3)
δ 8.89

150
Z.-G. Niu et al. / Inorganic Chemistry Communications 43 (2014) 146–150
[12] Crystal data for 5a·O2, C42H26F12IrN4O2P: Mr = 1069.88, Orthorhombic, space group
Pbca, a = 17.9724(7) Å, b = 20.7518(7) Å, c = 22.8570(10) Å, α = 90º, β = 90º,
γ = 90º, V = 8524.7(6) Å3, Z = 8, F(000) = 2888, GOF = 1.007, R1 = 0.0630,
wR2 = 0.1682 [I N 2σ(I)]. The data were collected on an Agilent Technologies
Gemini A Ultra diffractometer equipped with graphite-monochromated Mo Kα
(λ = 0.71073 Å) at 293 K; Crystal data for 5c, C42H26F6IrN6P: Mr = 951.86, mono-
clinic, space group P21/c, a = 9.37298(7) Å, b = 18.92864(14) Å, c = 20.49833(16)
Å, α = 90º, β = 94.1655(7)º, γ = 90º, V = 3627.16(5) Å3, Z = 4, F(000) = 1864,
GOF = 1.035, R1 = 0.0275, wR2 = 0.0648 [I N 2σ(I)]. The data were collected on
an Agilent Technologies Gemini A Ultra diffractometer equipped with graphite-
monochromated Cu Kα radiation (λ = 1.54184 Å) at 293 K. Data collection and reduc-
tion were processed with CrysAlisPro software. The structure was solved and refined
using Full-matrix least-squares based on F2 with program SHELXS-97 and SHELXL-97
within Olex2. All non-hydrogen atoms were found in alternating difference Fourier
syntheses and least-squares refinement cycles and, during the final cycles, refined
anisotropically. Hydrogen atoms were placed in calculated positions and refined as
riding atoms with a uniform value of Uiso.
[13] J.Y. Qiang, Y.Q. Xu, B.H. Tong, X.F. Ma, Q. Chen, W.H. Leung, Q.F. Zhang, Synthesis,
characterization, luminescence properties, and DFT calculation of a cationic
cyclometalated iridium(III) complex with fluorine-containing phenylquinolinyl
and 2,2′-bipyridine ligands, Inorg. Chim. Acta 394 (2013) 184–189.
[14] S. Kammer, I. Starke, A. Pietrucha, A. Kelling, W. Mickler, U. Schilde, C. Dosche, E.
Kleinpeter, H.J. Holdt, 1,12-Diazaperylene and 2,11-dialkylated-1,12-diazaperylene
iridium(III) complexes [Ir(C^N)2(N^N)]PF6: new supramolecular assemblies, Dalton
Trans. 41 (2012) 10219–10227.
Fig. 4. Normalized emission spectra of 5a–5d in CH2Cl2 at room temperature.
[15] K.K.W. Lo, P.K. Lee, J.S.Y. Lau, Synthesis, characterization, and properties of lumines-
cent organoiridium(III) polypyridine complexes appended with an alkyl chain and
their interactions with lipid bilayers, surfactants, and living cells, Organometallics
27 (2008) 2998–3006.
[16] A.B. Tamayo, B.D. Alleyne, P.I. Djurovich, S. Lamansky, I. Tsyba, N.N. Ho, R. Bau,
M.E. Thompson, Synthesis and characterization of facial and meridional
tris-cyclometalated iridium(III) complexes, J. Am. Chem. Soc. 125 (2003)
7377–7387.
[17] T. Sajoto, P.I. Djurovich, A.B. Tamayo, J. Oxgaard, W.A. Goddard, M.E. Thompson,
Temperature dependence of blue phosphorescent cyclometalated Ir(III) complexes,
J. Am. Chem. Soc. 131 (2009) 9813–9822.
[18] J.S.Y. Lau, P.K. Lee, K.H.K. Tsang, C.H.C. Ng, Y.W. Lam, S.H. Cheng, K.K.W. Lo, Lumines-
cent cyclometalated iridium(III) polypyridine indole complexes-synthesis,
photophysics, electrochemistry, protein-binding properties, cytotoxicity, and
cellular uptake, Inorg. Chem. 48 (2009) 708–718.
[19] F. Neve, M. La Deda, A. Crispini, A. Bellusci, F. Puntoriero, S. Campagna, Cationic
cyclometalated iridium luminophores: photophysical, redox, and structural charac-
terization, Organometallics 23 (2004) 5856–5863.
[20] R.J. Wang, L.J. Deng, T. Zhang, J.Y. Li, Substituent effect on the photophysical
properties, electrochemical properties and electroluminescence performance
of orange-emitting iridium complexes, Dalton Trans. 41 (2012) 6833–6841.
[21] Q. Zhao, S.J. Liu, M. Shi, C.M. Wang, M.X. Yu, L. Li, F.Y. Li, Yi Tao, C.H. Huang, Series of
new cationic iridium(III) complexes with tunable emission wavelength and excited
state properties: structures, theoretical calculations, and photophysical and electro-
chemical properties, Inorg. Chem. 45 (2006) 6152–6160.
[22] M.G. Colombo, A. Hauser, H.U. Guedel, Evidence for strong mixing between the LC
and MLCT excited states in bis(2-phenylpyridinato-C2, N′) (2,2′-bipyridine)
iridium(III), Inorg. Chem. 32 (1993) 3088–3092.
Fig. 5. Cyclic voltammograms of 5a–5d measured in CH3CN solution containing
n-Bu4NClO4 (0.1 M). The scan rate was 100 mV/s.
[23] K.A. King, P.J. Spellane, R.J. Watts, Excited-state properties of a triply ortho-metalated
iridium(III) complex, J. Am. Chem. Soc. 107 (1985) 1431–1432.
[24] S.J. Liu, Q. Zhao, Q.L. Fan, W. Huang, A series of red-light-emitting ionic iridium com-
plexes: structures, excited state properties, and application in electroluminescent
devices, Eur. J. Inorg. Chem. (2008) 2177–2185.
[25] Y. Wang, N. Herron, V.V. Grushin, D. LeCloux, V. Petrov, Highly efficient electrolumi-
nescent materials based on fluorinated organometallic iridium compounds, Appl.
Phys. Lett. 79 (2001) 449–451.
[26] S. Bettington, M. Tavasli, M.R. Bryce, A. Beeby, H. Al-Attar, A.P. Monkman,
Tris-cyclometalated iridium(III) complexes of carbazole(fluorenyl)pyridine ligands:
synthesis, redox and photophysical properties, and electrophosphorescent light-
emitting diodes, Chem. Eur. J. 13 (2007) 1423–1431.
[27] M.K. Nazeeruddin, R.T. Wegh, Z. Zhou, C. Klein, Q. Wang, F.D. Angelis, S. Fantacci, M.
Grätzel, Efficient green-blue-light-emitting cationic iridium complex for light-
emitting electrochemical cells, Inorg. Chem. 45 (2006) 9245–9250.
[28] W. Lee, T.H. Kwon, J. Kwon, J.Y. Kim, C. Lee, J.I. Hong, Effect of main ligands on organic
photovoltaic performance of Ir(III) complexes, New J. Chem. 35 (2011) 2557–2563.
(d, J = 8.0 Hz, 2H), 8.77 (d, J = 8.0 Hz, 2H), 8.38 (d, J = 7.6 Hz, 2H), 8.19
(t, J = 7.6 Hz, 2H), 7.95 ~ 7.98 (m, 2H), 7.82 ~ 7.86 (m, 4H), 7.76 (d, J =
5.6 Hz, 2H), 7.51 (d, J = 7.2 Hz, 2H), 7.37 ~ 7.45 (m, 6H), 6.43 (s, 2H). MS-ESI:
m/z calculated: 893.2; found: 893.3 (M+); Synthesis of 5b: 5b was obtained by a
method similar to the preparation of 5a, Yield 62%. 1H NMR (400 MHz, CDCl3) δ
9.64 (s, 2H), 8.93 (d, J = 7.2 Hz, 2H), 8.71 (d, J = 7.6 Hz, 2H), 8.46 (d, J =
8.4 Hz, 2H), 8.14 ~ 8.18 (m, 2H), 7.97 (t, J = 6.4 Hz, 2H), 7.80 ~ 7.86 (m, 6H), 7.62
(t, J = 8.0 Hz, 2H), 7.39 ~ 7.54 (m, 6H), 6.75 (s, 2H). MS-ESI: m/z calculated:
813.2; found: 813.3 (M+); Synthesis of 5c: 5c was obtained by a method similar
to the preparation of 5a, Yield 78%. 1H NMR (400 MHz, CDCl3) δ 8.89 (d, J =
5.6 Hz, 2H), 8.76 (d, J = 8.8 Hz, 2H), 8.41 (d, J = 7.2 Hz, 2H), 8.20 (t, J =
8.0 Hz, 2H), 7.98 ~ 8.01 (m, 2H), 7.87 ~ 7.89 (m, 4H), 7.76 (d, J = 4.8 Hz, 2H),
7.54 (d, J = 6.4 Hz, 2H), 7.42 ~ 7.46 (m, 6H), 6.51 (s, 2H). MS-ESI: m/z calculated:
807.2; found: 807.3 (M+); Synthesis of 5d: 5d was obtained by a method similar
to the preparation of 5a, Yield: 54%. 1H NMR (400 MHz, CDCl3) δ 8.85 ~ 8.92
(m, 2H), 8.71 (t, J = 8.0 Hz, 1H), 8.12 ~ 8.18 (m, 2H), 8.08 (d, J = 9.2 Hz, 1H),
8.00 ~ 8.04 (m, 1H), 7.89 ~ 7.94 (m, 2H), 7.73 ~ 7.83 (m, 6H), 7.33 ~ 7.43 (m, 4H),
7.20 ~ 7.28 (m, 3H), 6.99 ~ 7.03 (m, 1H), 5.99 ~ 6.01 (m, 1H), 1.99 ~ 2.08 (m, 6H).
MS-ESI: m/z calculated: 821.2; found: 821.3 (M+).
