molecules
Article
Ionic Liquids: Efficient Media for the
Lipase-Catalyzed Michael Addition
Yunchang Fan *, Dongxu Cai, Xin Wang and Lei Yang
College of Chemistry and Chemical Engineering, Henan Polytechnic University, Jiaozuo 454003, China;
CDX940407@163.com (D.C.); asnol21@163.com (X.W.); xcy78413@tom.com (L.Y.)
* Correspondence: fanyunchang@hpu.edu.cn; Tel.: +86-391-398-6813
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 5 August 2018; Accepted: 25 August 2018; Published: 27 August 2018
Abstract: Recently, ionic liquids (ILs) have been regarded as ideal media for non-aqueous bio-catalysis.
In this work, the synthesis of warfarin by the lipase-catalyzed Michael addition in IL media and the
parameters that affected the warfarin yield were investigated. Experimental results demonstrated
that the chemical structures of the ILs were a major factor for influencing the warfarin yield. The ILs
–
containing the NTf2 anion were suitable reaction media due to the high chemical stability of this
anion. The incorporation of the hydroxyl group on the IL cation significantly improved the lipase
activity due to the H2O-mimicking property of this group. The lipase activity decreased by increasing
the alkyl chain length on the IL cation due to the non-polar domain formation of the IL cation at
the active site entrance of lipase. The ILs and lipase could be reused no less than five times without
reduction in the warfarin yield.
Keywords: ionic liquids (ILs); lipase; Michael addition; warfarin; bio-catalysis
1. Introduction
In recent decades, enzymes have been regarded as green catalysts because they are recyclable
non-toxic materials and the enzymatic reactions are usually performed under mild conditions [
Lipases are the most used enzymes because of their high stability, activity, wide range of substrates,
and low cost [ ]. They can catalyze many reactions such as the Michael addition [ ],
esterification [ ], ester-hydrolysis [ ], and transesterification [ ]. Among these reactions, Michael
1,2].
3–
6
3–5
6
7
8
addition is one of the most effective ways to form mild C–C bonds and generate interesting,
drug-like scaffolds. The synthesis of warfarin by Michael addition of 4-hydroxycoumarin (4-HC)
to benzylideneacetone (BA) is a classic case. Warfarin and sodium warfarin are widely used as vitamin
K antagonists, which prevent the vitamin K-dependent synthesis of blood-clotting proteins and, thus,
decrease blood coagulation [
the lipase-catalyzed Michael addition in dimethyl sulfoxide (DMSO) media, which presented a yield
of 87%. Sano et al. [ ] also reported the lipase-catalyzed Michael reaction of 4-HC to BA in anhydrous
DMSO and a higher yield (85%) was achieved. Although some interesting results have been reported
by these excellent papers, there is still one problem [ 11]. Although lipases exhibit the highest
9,10]. Xie et al. [11] reported the synthesis of warfarin and derivatives via
5
3,5,
activity in DMSO medium, DMSO is flammable and toxic even at low concentrations (<10%, v/v) [12].
Therefore, it is of great importance to find environmentally-benign solvents. In this context, ionic
liquids (ILs) are considered as environmentally-benign solvents compared to the conventional solvents
because of their negligible vapor pressure, high dissolving power, and high thermal stability and
recyclability [13
biomass [15] and biocatalysis [16
–
15]. At present, ILs have found applications in diverse areas such as the conversion of
19]. Schutt et al. studied the impact of water-dilution on the solvation
–
properties of an ester-functionalized IL for model biomass molecules through the use of biased and
unbiased molecular dynamics (MD) simulations. It is found that hydrogen-bonding interactions
Molecules 2018, 23, 2154; doi:10.3390/molecules23092154
www.mdpi.com/journal/molecules

Molecules 2018, 23, 2154
2 of 11
between the IL anion and water are a major driving force that significantly impacts the solvent
properties of the ester-functionalized IL as well as conformational preferences of the cellulosic model
compound [15]. Burney et al. studied the impact of imidazolium-based ILs on enzyme functionality
by using molecular simulations. It is found that the enzymes lipase and α-chymotrypsin are altered by
randomly mutating lysine surface residues to glutamate in aqueous ILs 1-butyl-3-methylimidazolium
chloride and 1-ethyl-3-methylimidazolium ethyl sulfate. These mutations resemble succinylation
of the enzyme by chemical modification, which enhances the stability of both enzymes in ILs [19].
Very recently, the lipase-catalyzed esterification [20], ester-hydrolysis [21], and transesterification [22
]
reactions in the IL media have been widely reported. Furthermore, many reports have demonstrated
–
–
that the ILs with the anions PF6 and BF4 were suitable reaction media for the lipase-catalyzed
transesterification [22 23] and esterification [24
25] reactions. However, the anions PF6– and BF4– are
hydrolytically unstable, which results in a propensity to decompose and release corrosive HF [26 27].
It has been proven that bis(trifluoromethanesulphonyl)imide (NTf2–) has the higher chemical stability
,
,
,
–
–
than PF6 and BF4
[27,28]. Some work suggests that the hydroxyl-functionalized ILs have a good
compatibility with biomolecules such as catalase [29] and cytochrome c [30]. Therefore, it will be
–
expected that the hydroxyl-functionalized ILs containing NTf2 can be used as ideal media for the
lipase-catalyzed Michael addition reaction.
In this paper, the feasibility of the use of the hydroxyl-functionalized ILs as the reaction media
of lipase-catalyzed Michael addition and the parameters affecting the reaction yield have been
investigated systematically. Furthermore, the recyclability of ILs and lipase has also been studied.
For clarity, the names and abbreviations of the ILs are listed in Table 1.
Table 1. Names and abbreviations of the ILs used in this work.
Name
Abbreviation
1-Butyl-3-methylimidazolium tetrafluoroborate
1-Butyl-3-methylimidazolium hexafluorophosphate
[C1C4im]BF4
[C1C4im]PF6
1-Butyl-3-methylimidazolium bis(trifluoromethylsulfonyl)imide
[C1C4im]NTf2
1-Methyl-3-(6-hydroxyhexyl) imidazolium bis(trifluoromethylsulfonyl)imide
1-Butyl-3-(3-hydroxypropyl) imidazolium bis(trifluoromethylsulfonyl)imide
1-Methyl-3-(3-hydroxypropyl) imidazolium bis(trifluoromethylsulfonyl)imide
1-Butyl-3-(11-hydroxyundecyl) imidazolium bis(trifluoromethylsulfonyl)imide
1-Methyl-3-(11-hydroxyundecyl) imidazolium bis(trifluoromethylsulfonyl)imide
[C1C6OHim]NTf2
[C4C3OHim]NTf2
[C1C3OHim]NTf2
[C4C11OHim]NTf2
[C1C11OHim]NTf2
2. Results and Discussion
2.1. Selection of ILs
In this work, eight kinds of ILs and DMSO have been investigated systematically in order
to find the most suitable reaction medium. As shown in Figure 1, the lipase activity in
dialkylimidazolium-based IL media follows the order: [C1C4im]PF6 > [C1C4im]BF4 > [C1C4im]NTf2.
–
–
It has been reported that the nucleophilicity of anions increases in the following trend: PF6 < BF4
< NTf2– where the more nucleophilic anions have a tendency to interact with the positively charged
sites in the enzyme structure and to change the enzyme’s conformation, which could eventually result
in a denaturation of the enzyme [31–
33]. However, PF6– and BF4– are moisture-sensitive anions and
tend to hydrolyze and release toxic HF. From the point of view of safety and environmental protection,
–
the use of NTf2 is more preferable [26,27].

Molecules 2018, 23, 2154
3 of 11
Figure 1. The correlation of the hydrophobicity of solvents used in this work and the warfarin yield.
◦
Reaction conditions: BA, 1.0 mmol, water, 0.1 mL, reaction time, 96 h, temperature, 45 C, lipase, 30 mg,
4-HC, 0.5 mmol, [C1C3OHim]NTf2, 2.0 g.
An interesting phenomenon, seen in Figure 1, is that the incorporation of the hydroxyl group
on the IL cation significantly improves the enzyme activity ([C1C3OHim]NTf2 versus [C1C4im]NTf2)
and the lipase activity in [C1C3OHim]NTf2 is also much higher than in DMSO. This accounts for
the fact that the essential water layer around the lipase molecule maintains the enzyme activity in
organic media. The IL [C1C3OHim]NTf2 contains a hydroxyl group and holds the H2O-mimicking
property and hydrogen-bonding functionality, which helps the enzyme to maintain its flexible and
active conformation [30,34,35].
Lastly, as shown in Figure 1, the lipase activity in the hydroxyl-functionalized ILs follows the order:
[C1C3OHim]NTf2 > [C1C6OHim]NTf2 > [C4C3OHim]NTf2 > [C1C11OHim]NTf2 > [C4C11OHim]NTf2,
which is opposite to the order of their hydrophobicity. It is known that the entrance of active sites
of lipase is formed by the non-polar residues. The IL cation can diffuse into the active sites of lipase
driven by van der Waals interactions. This means that the substrates have to compete with the IL
cations to reach the active sites [33,36]. The increase in the hydrophobicity results in the increase in the
van der Waals interactions between the alkyl chains of the ILs and the active sites of lipase. Moreover,
stronger hydrophobic ILs have longer hydrophobic tails (alkyl chains). Recent studies suggest that
the hydrophobic tails of the IL cations tend to cluster together and form non-polar domains in the
IL-water mixtures with longer tails able to do so more effectively [33,36,37]. These domains are close
to the active site entrance of lipase, which may generate a negative impact on the ability of substrates
entering or leaving the active sites of lipase and reduce the activity of lipase accordingly [33,36].
Above all, [C1C3OHim]NTf2 can be used in the subsequent experiments as the optimal
reaction medium.
2.2. Optimization of the Warfarin Yield
Reaction time and temperature are important factors for the warfarin yield. As can be seen from
Figure 2a, the warfarin yield keeps increasing in the range of reaction time from 0 to 168 h and remains
almost constant above 168 h. Therefore, 168 h is regarded as the optimal reaction time and is used in
the subsequent experiments.
The effect of the reaction temperature on the warfarin yield is shown in Figure 2b. The warfarin
◦
◦
yield increases with a rise in temperature from 25 C to 50 C. It is understood that higher temperature
lowers the viscosity of reaction media, which is favorable for reducing the mass transfer resistance and,

Molecules 2018, 23, 2154
4 of 11
thus, improves the reaction yield [38
,
39]. When the reaction temperature is above 50 ◦C, the warfarin
yield keeps constant by further increasing the reaction temperature. Thus, 50 ◦C is a choice for the
optimal reaction temperature.
Figure 2. Influence of reaction time (
a
) and temperature (
b
) on the warfarin yield. Reaction conditions:
◦
(
a) BA, 1.0 mmol, water, 0.1 mL, temperature, 45 C, lipase, 30 mg, 4-HC, 0.5 mmol, [C1C3OHim]NTf2,
2.0 g.
(b) BA, 1.0 mmol, water, 0.1 mL, reaction time, 168 h, lipase, 30 mg, 4-HC, 0.5 mmol,
[C1C3OHim]NTf2, 2.0 g.
Generally, the dosage of solvent has a significant effect on the reaction yield [22,40]. As shown
in Figure 3a, the warfarin yield increases with the [C1C3OHim]NTf2 dosage from 0 g to 0.5 g while
warfarin yield will decrease with a further increase in the [C1C3OHim]NTf2 dosage. This can be
explained by the facts that the addition of the solvent ([C1C3OHim]NTf2) can improve the enzyme
stability and activity by maintaining an appropriate microenvironment with mild polarity around the
lipase active sites. However, excess solvent can dilute the concentrations of substrates, which will
result in a lower reaction yield [22
,40]. Since 0.5 g of [C1C3OHim]NTf2 provides the highest warfarin
yield (99.1%), it is, thus, selected as the optimal IL dosage in the reactions.
Figure 3. Influence of the dosages of [C1C3OHim]NTf2 (
a
) and water (
b
). Reaction conditions: (
a
) BA,
) BA,
◦
1.0 mmol, water, 0.1 mL, reaction time, 168 h, temperature, 50 C, lipase, 30 mg, 4-HC, 0.5 mmol. (
b
◦
1.0 mmol, reaction time, 168 ho, temperature, 50 C, lipase, 30 mg; 4-HC, 0.5 mmol, [C1C3OHim]NTf2,
0.5 g.
The amount of water plays an important role for the enzymatic catalysis in organic media [22,41]:
an essential amount of water can activate the enzyme by increasing the polarity and structural flexibility
of the enzyme active sites. Nevertheless, excess water is harmful to the enzyme by facilitating enzyme
aggregation, which diminishes the substrate diffusion and eventually leads to the enzyme inactivation.
Furthermore, recent studies reported the impact of water dilution on the overall liquid structure and
properties of ILs. It is found that the presence of water can reduce the viscosity of ILs and the liquid
structure of ILs depends on the IL concentration: there is strong ordering in the local structure of IL at

Molecules 2018, 23, 2154
5 of 11
high IL concentrations and a breakdown of the structure at low IL concentrations [15
,37]. Therefore,
it is necessary to study the impact of the water dosage. The results are shown in Figure 3b. We observed
that the addition of an appropriate amount of water can improve the enzyme activity, which achieves
the highest warfarin yield (0.1 mL of water), but the warfarin yield decreases with a further increase of
the water dosage. Thus, 0.1 mL is regarded as the optimal water dosage.
The effect of enzyme dosage on the warfarin yield has also been researched in this work and the
results are shown in Figure 4a. We observed that the warfarin yield increases continuously with the
enzyme dosage increasing from 5 mg to 30 mg and decreasing slightly with a further increase of the
amount of enzyme. It has been reported that the addition of lipase is essential and higher amounts
of lipase have higher activity within a certain range. Beyond that range, the addition of excess lipase
would no longer enhance the warfarin yield since an optimal amount of water is required to activate
the added enzyme. In this way, at a non-optimal water dosage, some portion of the enzyme may be
inactive [22,42]. In light of this, 30 mg of lipase is selected for the following experiments.
Figure 4b illustrates the effect of the molar ratio of BA to 4-HC on the warfarin yield. The highest
yield is obtained at a 2:1 molar ratio of BA to 4-HC. Further increasing the number of equivalents of BA
does not improve the warfarin yield. Therefore, 2:1 is taken as the optimal molar ratio of BA to 4-HC.
Figure 4. Influence of enzyme dosage (
1.0 mmol, water, 0.1 mL, temperature, 50 C, 4-HC, 0.5 mmol, reaction time, 168 h, [C1C3OHim]NTf2,
a
) and molar ratio of BA to 4-HC (
b
). Reaction conditions: (
a
) BA,
◦
◦
0.5 g. (
b
) Water, 0.1 mL, temperature, 50 C, lipase, 30 mg, 4-HC, 0.5 mmol, reaction time, 168 ho,
[C1C3OHim]NTf2, 0.5 g.
2.3. Reusability of Lipase and [C1C3OHim]NTf2
The reuse of lipase and [C1C3OHim]NTf2 is clearly preferable from both environmental and
economic points of view. To reuse lipase, the reaction mixture is dissolved with acetone after the
end of the reaction. After centrifugation, the upper phase (acetone phase) is collected to recover
[C1C3OHim]NTf2 and warfarin. The bottom phase is lipase, which is washed with acetone several
times until◦no [C1C3OHim]NTf2, BA, 4-HC, and warfarin are detected in the washings. After being
dried at 25 C for 24 h, the recovered lipase is loaded into the reaction mixture for a new reaction cycle
under the optimal reaction conditions. The catalytic performance of lipase after recycling is shown in
Figure 5a. As can be seen, no obvious changes in warfarin yield are observed after five consecutive
cycles, which exhibits excellent reusability of lipase. The FT-IR spectra of lipase before and after use
were measured and the results shown in Figure 6 indicate that the FT-IR spectrum of the recovered
lipase is identical to that of the fresh one, which suggests that lipase remains its native conformation
after reaction. This explains why the lipase can be reused without the loss of its catalytic performance.

Molecules 2018, 23, 2154
6 of 11
Figure 5. Reusability study of lipase (
conditions.
a) and [C1C3OHim]NTf2 (b) under the optimal reaction
Figure 6. The FT-IR spectra of the original lipase and the recovered one.
To reuse [C1C3OHim]NTf2, the acetone phase, which is obtained from the recycling of lipase,
is distilled to remove acetone. The residue is mixed with NaOH solution (the molar amount of NaOH is
equal to the theoretical amount of warfarin), the upper phase (NaOH solution) of the resultant mixture
is collected to isolate warfarin, and the bottom phase is [C1C3OHim]NTf2, which contains 5.5% of BA,
◦
2.0% of 4-HC, and 1.2% of warfarin. After being dried at 60 C for 24 h, the recovered [C1C3OHim]NTf2
can be used for the next reaction cycle. Figure 5b shows that the warfarin yield stays almost constant
after five runs, which suggests that [C1C3OHim]NTf2 also possesses excellent reusability.
2.4. Separation of Warfarin from the Reaction Mixture
As mentioned above, after the end of the reaction, acetone is used to dissolve the product mixture
and the resultant acetone phase is distilled to remove acetone. The resultant residue is mixed with
NaOH solution to generate the aqueous phase containing warfarin sodium. In doing so, the product
can be separated from the reaction mixture. Then, the pH of the aqueous phase is adjusted to about
3.0 with acetic acid and a light yellow precipitate is obtained (crude warfarin). The resultant crude
warfarin is washed with the mixture of ethanol and acetic acid solution (pH 2.5) (3:5, v/v) several
times until white powder is obtained. Part of warfarin is lost during washings and the final warfarin
yield is 83.7% and the purity of warfarin (determined via the HPLC method) is 99.3%. The specific
rotation of the synthesized warfarin is
R-warfarin are 25.5
1◦ and +24.8
racemic mixture, which is in agreement with the clinically available warfarin [44].
−
1.8◦. It is known that the specific rotations of S-warfarin and
1◦, respectively [43]. Therefore, the synthesized warfarin is a
−
±
±

Molecules 2018, 23, 2154
7 of 11
3. Materials and Methods
3.1. Reagents
Lipase from Candida ruosa (type VII, activity,
≥
700 unit mg–1) was purchased from
Sigma-Aldrich Co. (St. Louis, MO, USA). 4-Hydroxycoumarin (4-HC, 98%), warfarin sodium
(98%), and benzylideneacetone (BA, 99%) were obtained from Aladdin Reagent Co. (Shanghai,
≥
China). n-Octanol (98%), sodium 1-heptanesulfonate (99%), and acetonitrile (99.9%) were obtained
from Energy Chemical Co. (Shanghai, China). The ILs, [C1C4im]BF4 (99%), [C1C4im]PF6
(99%), and [C1C4im]NTf2 (99%) were supplied by the Lanzhou Institute of Chemical Physics,
Chinese Academy of Sciences (Lanzhou, China). The ILs, [C1C6OHim]NTf2, [C1C3OHim]NTf2,
[C4C3OHim]NTf2, ([C4C11OHim]NTf2, and [C1C11OHim]NTf2 were synthesized on the basis of our
early work [45]. All the other reagents were of an analytical grade unless stated otherwise. Ultrapure
water (18.2 M
Ω cm) used throughout the experiments was produced by an Aquapro purification
system (Aquapro International Co., Ltd., Dover, DE, USA).
3.2. Determination of Warfarin
To monitor the reaction, the ultraviolet-visible (UV-Vis) spectra of the raw materials and
the products were measured by a TU-1810 spectrophotometer (Purkinje General Instrument Co.,
Beijing, China) (Figure S1). As can be seen from the spectra of the reaction mixture (Figure S1),
after reaction, the absorbance of BA decreases remarkably and the absorption peaks of warfarin appear,
which suggests that the reaction occurred. To more accurately measure the concentrations of warfarin
in the reaction media, an Agilent 1200 high performance liquid chromatograph (HPLC, Santa Clara,
CA, USA) equipped with a variable wavelength detector (VWD) and an auto-sampler was used.
An Amethyst C18-H column (4.6 mm
×
150 mm, 5 µm, Sepax Technologies Inc., Newark, NJ, USA)
was used to separate warfarin. The mobile phase was the mixture of acetonitrile and 0.10% (v/v) acetic
acid aqueous solution (55:45, v/v), the flow rate was 0.70 mL min−1, the injection volume was 5.0
µL,
the column temperature was 30 ◦C, and the detection wavelength was set at 308 nm.
3.3. Determination of the Hydrophobic Parameters of the ILs
The n-octanol–water partition coefficients (Pow), which are usually expressed as logPow values,
are regarded as measures of hydrophobicity of organic substances. The logPow values of the ILs
used in this work were measured according to the reported methods [46,47]: the IL solutions
(
5.0 × 10–4 mol L–1 for each) and the n-octanol were presaturated with n-octanol and water, respectively.
As an example, the mixture composed of IL solution (10.0 mL) and n-octanol (10.0 mL) was stirred
for 30 min at 25 C. Then the n-octanol and the water phases were separated by centrifugation.
◦
The concentrations of the ILs both in the n-octanol and water phases were determined by the
HPLC method. The chromatographic conditions were listed as follows: injection volume, 2.0 µL,
flow rate, 0.80 mL min–1, detection wavelength, 220 nm, mobile phase, a mixture of acetonitrile
and 2.0 × 10–3 mol L–1 of aqueous sodium 1-heptanesulfonate solution (50% (v/v) of acetonitrile for
determining [C4C11OHim]NTf2 and [C1C11OHim]NTf2; 40% (v/v) of acetonitrile for measuring the
remaining ILs).
The Pow value is calculated according to the equation below [46,47].
Cn−octanol
Cwater
Pow
=
(1)
In the equation, Cn
and Cwater are the concentrations of a given IL in the n-octanol and
-octanol
water phases, respectively. The logPow value of DMSO is from the reported literature [48].

Molecules 2018, 23, 2154
8 of 11
3.4. Synthesis of Warfarin
Typically, a mixture composed of 4-HC (0.5 ◦mmol), BA (1.0 mmol), IL (0.5 g), lipase (30 mg),
and water (0.1 mL) was kept stirring for 168 h at 50 C. After the reaction, the concentration of warfarin
in the prepared product was measured by the HPLC method. The product pre-processing procedure
was as follows: at the end of the reaction, the product mixture was diluted to 20 mL with ethanol,
filtrated to remove lipase, and then the resulting ethanol solution was further diluted 10 times with
ethanol before HPLC measurements. The percent yield is defined as the ratio of the actual amount of
warfarin to the theoretical amount.
3.5. Measurements of Fourier Transform Infrared (FT-IR) Spectra
The FT-IR spectra were measured by the KBr pressed disc method on a Bruker V70 FT-IR
spectrophotometer (Bruker Optic GmbH, Ettlingen, Germany).
3.6. Measurements of the Specific Rotation of the Synthesized Warfarin
The measurements of the specific rotation of the synthesized warfarin were performed on a SGW-1
automatic polarimeter (Shanghai instrument physical optics instrument Co., Ltd., Shanghai, China).
The temperature was 25 ◦C and the concentration of warfarin was 25 g L–1 (solvent, ethanol).
All the above experiments were conducted in triplicate and the data presented in this work are
averages of the obtained values.
4. Conclusions
In this work, a series of ILs were used as the reaction media of the lipase-catalyzed
Michael addition of 4-HC to BA. Compared with the conventional solvent DMSO and the
dialkylimidazolium-based ILs, the hydroxyl-functionalized IL [C1C3OHim]NTf2 is a more ideal
reaction medium because the hydroxyl group in the IL greatly promotes the lipase activity due to its
H2O-mimicking property and hydrogen-bonding functionality. The lipase activity decreases with an
increasing alkyl chain length of the IL cation, which can be ascribed to the direct interactions of the IL
cations with the active sites of lipase and the non-polar domain formation of the IL cations at the active
site entrance of lipase. After the end of the reaction, lipase and [C1C3OHim]NTf2 could be recovered
and reused no less than five times without a decrease of the catalytic performance of lipase.
Supplementary Materials: The following are available online, Figure S1: UV-Vis absorption spectra of warfarin,
4-HC, BA, and the reaction mixture before and after the reaction.
Author Contributions: Y.F. conceptualization and writing-original draft. D.C. investigation. X.W. data curation.
L.Y. writing-review and editing.
Funding: This research was funded by the National Natural Science Foundation of China (21307028),
the Foundation of Henan Province (182102310728), and the Program for Innovative Research Team of Henan
Polytechnic University (T2018-3).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Ghaffari-Moghaddam, M.; Eslahi, H.; Aydin, Y.A.; Saloglu, D. Enzymatic processes in alternative reaction
media: A mini review. J. Biol. Meth. 2015, 2, e25. [CrossRef]
2.
Solano, D.M.; Hoyos, P.; Hernáiz, M.J.; Alcántara, A.R.; Sánchez-Montero, J.M. Industrial biotransformations
in the synthesis of building blocks leading to enantiopure drugs. Bioresour. Technol. 2012, 115, 196–207.
[CrossRef] [PubMed]
3.
Yuan, Y.; Yang, L.; Liu, S.; Yang, J.; Zhang, H.; Yan, J.; Hu, X. Enzyme-catalyzed Michael addition for the
synthesis of warfarin and its determination via fluorescence quenching of L-tryptophan. Spectrochim. Acta A
2017, 176, 183–188. [CrossRef] [PubMed]

Molecules 2018, 23, 2154
9 of 11
4.
5.
Steunenberg, P.; Sijm, M.; Zuilhof, H.; Sanders, J.P.M.; Scott, E.L.; Franssen, M.C.R. Lipase-catalyzed
aza-Michael reaction on acrylate derivatives. J. Org. Chem. 2013, 78, 3802–3813. [CrossRef] [PubMed]
Sano, K.; Saito, S.; Hirose, Y.; Kohari, Y.; Nakano, H.; Seki, C.; Tokiwa, M.; Takeshita, M.; Uwai, K.
Development of a novel method for warfarin synthesis via lipase-catalyzed stereoselective Michael reaction.
Heterocycles 2013, 87, 1269–1278. [CrossRef]
6.
7.
Stergiou, P.Y.; Foukis, A.; Filippou, M.; Koukouritaki, M.; Parapouli, M.; Theodorou, L.G.; Hatziloukas, E.;
Afendra, A.; Pandey, A.; Papamichael, E.M. Advances in lipase-catalyzed esterification reactions.
Biotechnol. Adv. 2013, 31, 1846–1859. [CrossRef] [PubMed]
Sekiya, M.; Osuga, J.I.; Yahagi, N.; Okazaki, H.; Tamura, Y.; Igarashi, M.; Takase, S.; Harada, K.; Okazaki, S.;
Iizuka, Y.; et al. Hormone-sensitive lipase is involved in hepatic cholesteryl ester hydrolysis. J. Lipid Res.
2008, 49, 1829–1838. [CrossRef] [PubMed]
8.
9.
Canet, A.; Bonet-Ragel, K.; Benaiges, M.D.; Valero, F. Lipase-catalysed transesterification: Viewpoint of the
mechanism and influence of free fatty acids. Biomass Bioenergy 2016, 85, 94–99. [CrossRef]
Danziger, J. Vitamin K-dependent proteins, warfarin, and vascular calcification. Clin. J. Am. Soc. Nephrol.
2008, 3, 1504–1510. [CrossRef] [PubMed]
10. Anderes, E.; Nand, S. Commonly used drugs in hematologic disorders, Neurologic Aspects of Systemic
Disease Part II. In Handbook of Clinical Neurology; Elsevier: Amsterdam, The Netherlands, 2014; pp. 1125–1139.
11. Xie, B.H.; Guan, Z.; He, Y.H. Promiscuous enzyme-catalyzed Michael addition: Synthesis of warfarin and
derivatives. J. Chem. Technol. Biotechnol. 2012, 87, 1709–1714. [CrossRef]
12. Galvao, J.; Davis, B.; Tilley, M.; Normando, E.; Duchen, M.R.; Cordeiro, M.F. Unexpected low-dose toxicity of
the universal solvent DMSO. FASEB J. 2014, 28, 1317–1330. [CrossRef] [PubMed]
13. Raut, D.G.; Sundman, O.; Su, W.; Virtanen, P.; Sugano, Y.; Kordas, K.; Mikkola, J.P. A morpholinium ionic
liquid for cellulose dissolution. Carbohydr. Polym. 2015, 130, 18–25. [CrossRef] [PubMed]
14. Vijaykumar, B.V.D.; Premkumar, B.; Jang, K.; Choi, B.I.; Falck, J.R.; Sheldrake, G.N.; Shin, D.S.
Environmentally benign perfluorooctanesulfonate alternatives using a Zn/CuI mediated Michael-type
addition in imidazolium ionic liquids. Green Chem. 2014, 16, 2406–2410. [CrossRef]
15. Schutt, T.C.; Hegde, G.A.; Bharadwaj, V.S.; Johns, A.J.; Maupin, C.M. Impact of water-dilution on the
solvation properties of the ionic liquid 1-methyltriethoxy-3-ethylimidazolium acetate for model biomass
molecules. J. Phys. Chem. B 2017, 121, 843–853. [CrossRef] [PubMed]
16. Itoh, T. Ionic liquids as tool to improve enzymatic organic synthesis. Chem. Rev. 2017, 117, 10567–10607.
[CrossRef] [PubMed]
17. Lozano, P.; Bernal, J.M.; Garcia-Verdugo, E.; Sanchez-Gomez, G.; Vaultier, M.; Burguete, M.I.; Luis, S.V.
Sponge-like ionic liquids: A new platform for green biocatalytic chemical processes. Green Chem. 2015, 17,
3706–3717. [CrossRef]
18. Xu, P.; Zheng, G.W.; Du, P.X.; Zong, M.H.; Lou, W.Y. Whole-cell biocatalytic processes with ionic liquids.
ACS Sustain. Chem. Eng. 2016, 4, 371–386. [CrossRef]
19. Burney, P.R.; Nordwald, E.M.; Hickman, K.; Kaar, J.L.; Pfaendtner, J. Molecular dynamics investigation
of the ionic liquid/enzyme interface: Application to engineering enzyme surface charge. Proteins Struct.
Funct. Bioinform. 2015, 83, 670–680. [CrossRef] [PubMed]
20. Shi, Y.G.; Wu, Y.; Lu, X.Y.; Ren, Y.P.; Wang, Q.; Zhu, C.M.; Yu, D.; Wang, H. Lipase-catalyzed esterification of
ferulic acid with lauryl alcohol in ionic liquids and antibacterial properties in vitro against three food-related
bacteria. Food Chem. 2017, 220, 249–256. [CrossRef] [PubMed]
21. Xin, J.Y.; Zhao, Y.J.; Shi, Y.G.; Xia, C.G.; Li, S.B. Lipase-catalyzed naproxen methyl ester hydrolysis in
water-saturated ionic liquid: Significantly enhanced enantioselectivity and stability. World J. Microb. Biotechnol.
2005, 21, 193–199. [CrossRef]
22. Su, F.; Peng, C.; Li, G.L.; Xu, L.; Yan, Y.J. Biodiesel production from woody oil catalyzed by Candida rugosa
lipase in ionic liquid. Renew. Energy 2016, 90, 329–335. [CrossRef]
23. Liu, Y.; Chen, D.; Yan, Y.; Peng, C.; Xu, L. Biodiesel synthesis and conformation of lipase from Burkholderia
cepacia in room temperature ionic liquids and organic solvents. Bioresour. Technol. 2011, 102, 10414–10418.
[CrossRef] [PubMed]
24. Fischer, F.; Happe, M.; Emery, J.; Fornage, A.; Schütz, R. Enzymatic synthesis of 6- and 60-O-linoleyl-
maltose: From solvent-free to binary ionic liquid reaction media. J. Mol. Catal. B 2013, 90, 98–106. [CrossRef]
α-D-

Molecules 2018, 23, 2154
10 of 11
25. Yang, Z.; Guo, Z.; Xu, X. Ionic liquid-assisted solubilization for improved enzymatic esterification of phenolic
acids. J. Am. Oil Chem. Soc. 2012, 89, 1049–1055. [CrossRef]
26. Freire, M.G.; Neves, C.M.; Marrucho, I.M.; Coutinho, J.A.; Fernandes, A.M. Hydrolysis of tetrafluoroborate
and hexafluorophosphate counter ions in imidazolium-based ionic liquids. J. Phys. Chem. A 2010, 114,
3744–3749. [CrossRef] [PubMed]
27. Sowmiah, S.; Srinivasadesikan, V.; Tseng, M.C.; Chu, Y.H. On the chemical stabilities of ionic liquids.
Molecules 2009, 14, 3780–3813. [CrossRef] [PubMed]
28. Somers, A.E.; Howlett, P.C.; MacFarlane, D.R.; Forsyth, M. A review of ionic liquid lubricants. Lubricants
2013, 1, 3–21. [CrossRef]
29. Dong, X.; Fan, Y.; Yang, P.; Kong, J.; Li, D.; Miao, J.; Hua, S.; Hu, C. Ultraviolet-visible (UV-Vis) and
fluorescence spectroscopic investigation of the interactions of ionic liquids and catalase. Appl. Spectrosc.
2016, 70, 1851–1860. [CrossRef] [PubMed]
30. Papadopoulou, A.A.; Tzani, A.; Alivertis, D.; Katsoura, M.H.; Polydera, A.C.; Detsi, A.; Stamatis, H. Hydroxyl
ammonium ionic liquids as media for biocatalytic oxidations. Green Chem. 2016, 18, 1147–1158. [CrossRef]
31. Hernández-Fernández, F.J.; de los Ríos, A.P.; Tomás-Alonso, F.; Gómez, D.; Víllora, G. Stability of hydrolase
enzymes in ionic liquids. Can. J. Chem. Eng. 2009, 87, 910–914. [CrossRef]
32. Zhao, H. Methods for stabilizing and activating enzymes in ionic liquids—A review. J. Chem.
Technol. Biotechnol. 2010, 85, 891–907. [CrossRef]
33. Klähn, M.; Lim, G.S.; Seduraman, A.; Wu, P. On the different roles of anions and cations in the solvation of
enzymes in ionic liquids. Phys. Chem. Chem. Phys. 2011, 13, 1649–1662. [CrossRef] [PubMed]
34. Lai, J.Q.; Li, Z.; Lü, Y.H.; Yang, Z. Specific ion effects of ionic liquids on enzyme activity and stability.
Green Chem. 2011, 13, 1860–1868. [CrossRef]
35. Zhao, H.; Baker, G.A.; Holmes, S. New eutectic ionic liquids for lipase activation and enzymatic preparation
of biodiesel. Org. Biomol. Chem. 2011, 9, 1908–1916. [CrossRef] [PubMed]
36. Ventura, S.P.M.; Santos, L.D.F.; Saraiva, J.A.; Coutinho, J.A.P. Concentration effect of hydrophilic ionic liquids
on the enzymatic activity of Candida antarctica lipase B. World J. Microb. Biotechnol. 2012, 28, 2303–2310.
[CrossRef] [PubMed]
37. Hegde, G.A.; Bharadwaj, V.S.; Kinsinger, C.L.; Schutt, T.C.; Pisierra, N.R.; Maupin, C.M. Impact of water
dilution and cation tail length on ionic liquid characteristics: Interplay between polar and non-polar
interactions. J. Chem. Phys. 2016, 145, 064504. [CrossRef]
38. Zhang, H.; Li, H.; Pan, H.; Liu, X.; Yang, K.; Huang, S.; Yang, S. Efficient production of biodiesel with
promising fuel properties from Koelreuteria integrifoliola oil using a magnetically recyclable acidic ionic liquid.
Energy Convers. Manag. 2017, 138, 45–53. [CrossRef]
39. Yang, J.; Feng, Y.; Zeng, T.; Guo, X.; Li, L.; Hong, R.; Qiu, T. Synthesis of biodiesel via transesterification of
tung oil catalyzed by new Brönsted acidic ionic liquid. Chem. Eng. Res. Des. 2017, 117, 584–592. [CrossRef]
40. Zhang, K.P.; Lai, J.Q.; Huang, Z.L.; Yang, Z. Penicillium expansum lipase-catalyzed production of biodiesel in
ionic liquids. Bioresour. Technol. 2011, 102, 2767–2772. [CrossRef] [PubMed]
41. Ribeiro, B.D.; Santos, A.G.; Marrucho, I.M. Biocatalysis in ionic liquids. In White Biotechnology for Sustainable
Chemistry; Royal Society of Chemistry: Cambridge, UK, 2015.
42. Aghababaie, M.; Beheshti, M.; Razmjou, A.; Bordbar, A.K. Enzymatic biodiesel production from crude Eruca
sativa oil using Candida rugosa lipase in a solvent-free system using response surface methodology. Biofuels
2017, 14, 1–7. [CrossRef]
43. Bhonoah, Y. Warfarin: Rat Poison or Wonder Drug? Available online: http://www.ch.ic.ac.uk/local/
projects/bhonoah/characterisation.html (accessed on 17 August 2018).
44. Takahashi, H.; Echizen, H. Pharmacogenetics of warfarin elimination and its clinical implications.
Clin. Pharmacokinet. 2001, 40, 587–603. [CrossRef] [PubMed]
45. Fan, Y.; Dong, X.; Li, Y.; Zhong, Y.; Miao, J.; Hua, S.; Sun, Y. Extraction of L-tryptophan by
hydroxyl-functionalized ionic liquids. Ind. Eng. Chem. Res. 2015, 54, 12966–12973. [CrossRef]
46. Lee, S.H.; Lee, S.B. Octanol/water partition coefficients of ionic liquids. J. Chem. Technol. Biotechnol. 2009, 84,
202–207. [CrossRef]
47. Ropel, L.; Belvèze, L.S.; Aki, S.N.V.K.; Stadtherr, M.A.; Brennecke, J.F. Octanol–water partition coefficients of
imidazolium-based ionic liquids. Green Chem. 2005, 7, 83–90. [CrossRef]

Molecules 2018, 23, 2154
11 of 11
48. Jamalzadeh, L.; Ghafoori, H.; Sariri, R.; Rabuti, H.; Nasirzade, J.; Hasani, H.; Aghamaali, M.R. Cytotoxic
effects of some common organic solvents on MCF-7, RAW-264.7 and human umbilical vein endothelial cells.
Avicenna J. Med. Biochem. 2016, 4, e33453. [CrossRef]
Sample Availability: Samples of the compounds are not available from the authors.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
