Molecular and Crystal Structure of (1S,2R)-1-{2-[(1S)-1-(Dimethylamino)Ethyl]Phenyl}-1,2-Diphenylethane-1,2-Diol

Article abstract of DOI:10.1134/S0022476619040176

The (R)-configuration of the carbinol center formed as a result of diastereospecific reduction of (2S)-2-{2-(1S)-1-(dimethylamino)ethyl]phenyl}-2-hydroxy-1,2-diphenylethanone is established by the XRD method. The analysis of shortened nonvalent intramolec

Full text of DOI:10.1134/S0022476619040176

ISSN 0022-4766, Journal of Structural Chemistry, 2019, Vol. 60, No. 4, pp. 654-661. © Pleiades Publishing, Inc., 2019.
Russian Text © The Author(s), 2019, published in Zhurnal Strukturnoi Khimii, 2019, Vol. 60, No. 4, pp. 680-687.
MOLECULAR AND CRYSTAL STRUCTURE
OF (1S,2R)-1-{2-[(1S)-1-(DIMETHYLAMINO)ETHYL]PHENYL}
-1,2-DIPHENYLETHANE-1,2-DIOL
1 1
V. M. Demyanovich , I. N. Shishkina ,
2 2
K. A. Potekhin , A. V. Maleev *, and
2
A. A. Gevorgyan
The (R)-configuration of the carbinol center formed as a result of diastereospecific reduction of
(2S)-2-{2-(1S)-1-(dimethylamino)ethyl]phenyl}-2-hydroxy-1,2-diphenylethanone is established by the
XRD method. The analysis of shortened nonvalent intramolecular contacts testifies that the molecule is
quite rigid, despite the presence of a large number of single valence bonds. Layered nature of molecular
packaging is revealed.
DOI: 10.1134/S0022476619040176
Keywords: aminoalcohols, aminoketoalcohols, reduction, stereoselectivity, configuration, atom-atom
potentials, molecular agglomerates in crystals.
INTRODUCTION
The synthesis of chirally pure compounds is an urgent problem of modern organic chemistry. It is related to the
production of catalysts for the asymmetric synthesis widely used nowadays to obtain chiral compounds and to design drugs
whose pharmacological activity depends on their configuration.
The interest in the study of molecular agglomerates (finite or infinite ensembles of molecules which are most tightly
bound in a crystal) is due to the fact that final agglomerates or fragments of molecular chains and layers are often maintained
in the solutions or melts after the crystal is destroyed; also, they can pass from crystal to crystal during polymorphic phase
transitions or in the course of solid-phase chemical reactions [1].
We earlier reported that N,N-dimethyl-1-phenylethanamine (I, readily available in both enantiomeric forms) can be
used to obtain chirally pure aminoalcohols [2] which showed good asymmetrical activity in the reaction of enantioselective
addition of diethylzinc to aromatic aldehydes [3]. An approach to estimate the stability of molecular agglomerates in a crystal
was proposed in [4].
To continue these works, we studied the reduction of the previously obtained (2S)-2-{2-(1S)-1-
(dimethylamino)ethyl]phenyl}-2-hydroxy-1,2-diphenylethanone (II) [5] by metal hydrides (NaBH4, LiAlH4, (tert-
BuO)3LiAlH) and showed that (1S,2R)-1-{2-[(1S)-1-(dimethylamino)ethyl]phenyl}-1,2-diphenylethane -1,2-diol (III) is
formed with diastereomeric purities of 50%, 80%, and 100%, respectively.
1Moscow State University, Russia. 2Vladimir State University, Russia; *andr_mal@mail.ru. Original article
submitted February 17, 2018; revised September 12, 2018; accepted September 18, 2018.
654
0022-4766/19/6004-0654 © 2019 by Pleiades Publishing, Ltd.

The effect of the chiral carbinol center (С-1, (S)-configuration) adjacent to the carbonyl group on the
stereoselectivity of the reaction was estimated using the reduction of {2-(1S)-1-
(dimethylamino)ethyl]phenyl}(phenyl)methanone by (tert-BuO)3LiAlH which demonstrated low degree of stereoselectivity
(below 50%).
To establish the configuration of the newly formed carbinol center in the obtained diastereomer III, the molecular
structure of the latter was studied with the XRD method.
EXPERIMENTAL
The reduction of the aminoketoalcohols II was carried out in a water-alcohol environment (NaBH4) or in the
absolute ether (LiAlH4, (tert-BuO)3LiAlH).
23.23 mmol of absolute tert-butanol (distilled over Р2О5 and double distilled over Na) was dropwise added to the
stirred solution of 7.74 mmol of LiAlH4 in 20 ml of absolute ether at 0 °C while stirred. The reaction mixture was kept for 30
min at 0 °C, then the solution of 1.94 mmol ketoamino alcohol II in 50 ml of absolute ether was added dropwise. The mixture
was additionally kept for 30 min at 0 °C, 30 ml of water was decomposed at cooling, NaCl was added to saturation and
extracted with ether (6×10 ml). After drying over MgSO4, the ether was removed by distillation to obtain a crystalline
substance, yield 85%, Тm 185° (from ethanol), [α]D –118,4° (c 1, ethanol).
IR spectrum: νОН 3150-2400 cm–1 (ОН group linked by the intramolecular hydrogen bond (ВВС)), νОН 3610 cm–1
(free OH group), νОН 3530 cm–1 (dimeric OH group).
1Н NMR (400 MHz, СDСl3, ТМС) δ ppm: 0.98 d (СН3 СН, 3Н, J 6.8), 1.98 s (NСН3 6Н), 2.44 s (benzyl ОН at
С(2), 1Н) 3.54 q (СН–СН3, 1Н, J 6.8), 5.51 s (СН–ОН, 1Н), 6.9-8.15 m (arom. 14Н); 10.0 s (benzhydryl ОН at С(1), 1Н).
13С NMR spectrum (400 MHz, СDСl3) δ ppm: 7.27 s. (СН3–СН), 38.34 wide s. ((СН3)2N), 57.02 (СН–СН3), 78.53 s.
(НСОН), 80.32 s. (СОН), 127,4-146.0 (aromatic).
Found,%: С 80.07, Н 7.65, N 3.67. C24H27NO2. Calculated,%: С 79.75, Н 7.53, N 3.87.
X-ray analysis of single crystals III. Rhombic crystals, T = 293 K: a = 7.618(3) Ǻ, b = 9.461(5) Ǻ,
c = 26.987(9) Ǻ, V = 1945(2) Ǻ3, space group P212121, Z = 4, dcalc = 1.234 g/cm3, μ = 0.078 mm–1. Unit cell parameters and
the intensities of 1780 independent diffraction reflections were recorded on an automatic four-circle diffractometer Siemens
P3/PC (λMoK , graphite monochromator, θ/2θ scanning, θmax = 24°). The absorption correction was ignored. The structure
α
2
was solved by the direct method and refined by the least squares method with respect to F in the anisotropic approximation
for non-hydrogen atoms. Two hydrogen atoms of hydroxyl groups of the molecule III were localized using the difference
electron density synthesis, their positions were refined in the isotropic approximation. The coordinates of the remaining H
atoms were calculated geometrically and refined using a riding model. The final divergence factors were R1 = 0.0378 and
wR2 = 0.1051 for 1686 diffraction reflections with I > 2σ(I), R1 = 0.0412, and wR2 = 0.1146 for the whole array of
independent diffraction reflections. All calculations were carried out using the SHELXTL software package [6].
CIF files containing complete data on structure III were deposited with the CCDC under the number 1588127 and
can be freely obtained on request on the site ccdc.cam.ac.uk/data_request/cif.
655

RESULTS AND DISCUSSION
Aminodiol III was obtained as a result of the reduction of aminoketoalcohol II by the action of (tert-BuO)3LiAlH;
its structure was confirmed by IR and NMR spectroscopy data. It was shown that the reaction is diastereospecific, and the
presence of the chiral (carbinol) center near the reduced carbonyl group significantly affects the stereoselectivity of the
1
reaction which was estimated by Н NMR spectra. According to the XRD data, the formed chiral carbinol center in the
obtained diastereomer III has a (R)-configuration.
Fig. 1 shows the perspective view of the molecule (according to the XRD data) with numbered non-hydrogen atoms.
The intramolecular hydrogen bond O(1)–H(1)…N with geometric parameters O(1)–H(1) 0.97(4), H(1)…N 1.73(5), O(1)…N
2.679(3) Ǻ, angle O(1)–H(1)…N 165(4)° is shown by a dashed line. This H-bond closes the 7-membered cycle C(1)–C(2)–
C(3)–C(8)–N…H(1)–O(1) and therefore fixes the torsion angle O(1)–C(1)–C(2)–C(3). As a result, even small rotations of the
aryl fragment of the C(2)…C(7) molecule around the C(1)–C(2) bond are substantially limited. Moreover, any rotations of
the molecule fragments around single bonds C(1)–C(12), С(12)–C(13), and С(1)–C(19) are also limited by short non-valence
contacts C…C, O…C, and C…H (Table 1) of the type 1…4, 1…5, and even 1…6. These contacts are shorter than the double
geometric mean of the corresponding van der Waals radii [7].
Fig. 1. Perspective view of molecule III with
numbered atoms. Only hydrogen atoms of hydroxyl
groups and chiral centers are shown.
TABLE 1. Some of the Shortened Intramolecular Nonvalent Contacts in the Molecule III
Contact
Type
Distance d*, Ǻ
Contact
Type
Distance d, Ǻ
Δ, Ǻ
Δ**, Ǻ
O(1)…C(13)
O(1)…C(20)
C(7)…C(12)
C(13)…C(19)
C(8)…C(19)
C(14)…C(19)
C(14)…C(20)
C(9)…H(4)
1…4
1…4
1…4
1…4
1…5
1…5
1…6
1…5
1…4
2.77
2.80
2.90
3.05
3.22
3.29
3.32
2.49
2.88
0.20
0.17
0.52
0.37
0.20
0.13
0.10
0.33
0.54
O(2)…C(14)
O(2)…C(7)
1…4
1…5
1…4
1…4
1…4
1…4
1…4
1…5
–
2.80
2.87
2.97
3.18
3.29
3.32
2.48
2.49
–
0.17
0.10
0.45
0.24
0.13
0.10
0.34
0.33
–
C(2)…C(24)
C(3)…C(19)
C(12)…C(24)
C(13)…C(20)
C(19)…H(8)
C(12)…H(7)
C(9)…С(4)
–
* Interatomic distance rounded to 0.01 Ǻ.
** Δ = 2 R ⋅ R − d , where Ri and Rj are van der Waals radii of the atoms.
i
j
656

As a result, the relaxation of the molecule's steric strain caused by the repulsion of too closely spaced atoms of its
fragments is due to the deformation of valence angles and valence bonds rather than the changes of the torsion angles. For
example, tetrahedral valence angles C(2)–C(1)–C(12) and C(1)–C(12)–C(13) are increased to 113.2(2)° and 113.0(2)°,
respectively, and the valence bond C(1)–C(12) is stretched to 1.570(4) Ǻ. Note that the valence bond C(1)–C(12) is 0.014 Ǻ
longer than the average bond (С#)3–C–CH–(С#)2 [8].
According to the analysis of the Dirichlet packing polyhedron of molecule III performed by the procedure described
in [9], the coordination number of the molecule in a crystal is 14. For each geometric molecular dimer (GMD) formed by the
basic molecule with all the molecules of its first coordination environment, the energies of intermolecular interactions were
calculated using the atom-atom potential model according to the formula
U
=
ϕ , where
∑
ij
М⎯М
i, j
−6
ij ij
ϕ = −A r + B exp(−C r ) are atom-atom potentials and Aij, Bij, Cij are parameters of the interaction between the ith
ij
ij
ij ij
atom of the first molecule and the jth atom of the second molecule which are determined by the types of these atoms from the
formulas A = A A , B = B B , and C = C C . All energy calculations were performed using the program
ij
T
i
T
ij
T
i
T
ij
T
i
T
j
j
j
[10], parameters AT, BT, and CT for the atoms C, H, O, and N are cited from [11].
In [12], we suggested a new approach for the study and description of intermolecular interactions based on the
analysis of the potentials of individual intermolecular atom-atom contacts. The contacts with the potential close to the
minimum on the corresponding potential curve (ϕ ≤ ϕw, where ϕw = ϕ(rw) is the potential at the inflection point of the
2
∂ ϕ(r )
w
potential curve
= 0) are referred to below as potential well contacts (PWCs). The left edge of the potential well is
2
∂r
limited by the distance rl such that ϕ(rl) = ϕw. The contacts corresponding to the left side of the potential curve and having
nonpositive atom-atom potentials are referred to as left contacts (LCs), and those with positive atom-atom potentials are
referred to as positive contacts (PCs). Fig. 2 shows the potential curve with the indication of PWC, PC, and LC regions of
atom-atom contacts C…C. Since atom-atom PWC contacts between the molecules are the strongest energy contacts, the
number of PWCs between two adjacent molecules can be used to characterize the intensity and stability of intermolecular
contacts. The presence of LCs and particularly PCs in intermolecular interactions may indicate the appearance of specific
interactions (π-stacking, Т-stacking, weak H-bonds) between the corresponding molecular fragments.
Let us consider GMDs, each consisting of the basic molecule and a molecule of its first coordination sphere.
Obviously, the number of GMDs is equal to the coordination number (CN = 14). At the same time, there are only seven
crystallographically independent GMDs within the first coordination sphere of the basic molecule.
Fig. 2. The curve of the atom-atom potential interaction between
two carbon atoms.
657

TABLE 2. Energy Characteristics of Pairwise Intermolecular Interactions Between Molecule III and the Molecules of its
First Coordination Environment
№
Symmetry
operation
GMD interaction
energy, kJ/mol
Interaction energy of
non-hydrogen atoms,
kJ/mol
Number of PWCs of
non-hydrogen atoms
Total energy of PWCs of
non-hydrogen
atoms, kJ/mol
1
2
3
x+1, y, z
(x–1, y, z)*
x, y+1, z
–29.5
–26.7
–23.5
–23.0
–20.6
–19.3
18
17
11
–6.5
–6.1
–4.2
(x, y–1, z)
x–1/2, –y–
1/2, –z
(x+1/2, –y–
1/2, –z)
4
5
6
7
1–x, y+1/2,
1/2–z
–17.0
–13.8
–12.4
–9.7
–15.9
–11.3
–11.0
–8.7
3
7
4
3
–1.1
–2.5
–1.4
–1.0
(1–x, y–1/2,
1/2–z)
–x, y+1/2,
1/2–z
(–x, y–1/2,
1/2–z)
x+1/2, 1/2–y,
–z
(x–1/2, 1/2–y,
–z)
x–1, y+1, z
(x+1, y–1, z)
* The parentheses contain symmetry operations of symmetric analogs of original crystallographically independent
GMDs.
Table 2 shows the following parameters for seven crystallographically independent GMDs: 1) symmetry operations
that connect the basic molecule with the molecules from its first coordination sphere of this GMD and its symmetric analog;
2) intermolecular interaction energy in the GMD calculated by the method of atom-atom potentials ignoring the energy of
electrostatic interaction; 3) part of this energy corresponding to the interaction of non-hydrogen atoms only; 4) number of
PWCs between non-hydrogen atoms in the GMD, and 5) total energy of these PWCs.
The first GMD has 18 PWCs, which is only 2.5% of the total (729) contacts between non-hydrogen atoms. At the
same time, the total energy of these 18 PWCs (–6.5 kJ/mol) is larger than 31% of the contact energy between non-hydrogen
atoms. There is also another feature of intermolecular interaction in this dimer. Four atoms C(20), C(21), C(22), and C(23) of
the phenyl ring of the basic molecule interact with eight atoms O(2A), C(12A), C(13A), C(14A), C(15A), C(16A), C(17A),
and C(18A) of the flat fragment of the neighboring molecule (hereinafter, lettered numbering will be used for the atoms of
the molecules from the first coordination sphere). The interaction of these two fragments of neighboring molecules involves
14 of 18 atom-atom PWCs. These contacts are shown by dashed lines in Fig. 3а. The total energy of intermolecular
interactions of these 14 PWCs is –5.1 kJ/mol.
A special feature of intermolecular interactions in the first GMD is the presence of PCs of the С…Н type with large
positive potentials. For example, the contact between the С(22) atom of the basic molecule and the Н(2А) atom of the
hydroxyl group of the molecule of its first coordination sphere has the potential equal to +2.2 kJ/mol. As mentioned above,
the presence of a PC (a contact with a positive energy of atom-atom interaction) indicates the possible presence of a specific
interaction between these atoms. Geometric parameters of the С(22)…Н(2А) contact are as follows: distance С(22)…О(2А)
658

Fig. 3. Interaction of a fragment of the basic molecule with a fragment of the neighboring
molecule in the first GMD (a), “chelate trap” in the second GMD (b).
is 3.47 Ǻ, distance С(22)…Н(2А) is 2.66 Ǻ, and angle С(22)…Н(2А)–О(2А) is 167°. According to the nomenclature
proposed in [13], this contact is referred to as a Н-bond of the О–Н…π type localized on the С(22) atom of the basic
molecule. Similarly, the hydrogen atom H(21A) of the phenyl of the molecule from the first coordination environment has
four PCs with atoms C(13), C(16), C(17), C(18) of the phenyl of the basic molecules with a total energy of +0.73 kJ/mol. The
energies of LCs between the H(21A) atom and the two remaining carbon atoms of this phenyl are close to zero to testify the
possible presence of a weak delocalized hydrogen bond of the Car–H…π type with the following geometrical parameters:
distance C(21A)…X is 3.46 Ǻ, distance H(21A)…X is 2.79 Ǻ, and angle С(21A)–H(21А)…X is 129°, where X is the
centroid of the phenyl С(13)…С(18).
Intermolecular contacts of the first GMD and its symmetric analogue form a molecular chain of translationally
identical molecules oriented along the crystallographic axis a. According to the nomenclature proposed in [1], this molecular
chain is abbreviated as Bs(1) (beads) and is fully designated as Pc(X)1, Z = 1. It is stabilized by a large number of PWCs and
H-bonds of О–Н…π and Car–H…π types.
In the second crystallographically independent GMD, two phenyl fragments of the basic molecule actively interact
with the neighboring aryl fragment. Six atoms of the basic molecule (C(14), C(15), C(16) on the one side and C(21), C(22),
C(23) on the other side) hold in a chelate-like manner six atoms С(3A), C(4A), C(5A), C(6A), С(9A), C(11A) of the
neighboring molecule (Fig. 3b) obtained by the basis translation along the crystallographic axis b. This “chelate trap”
involves all 17 PWCs of the considered GMD with the total energy of intermolecular interaction equal to –6.1 kJ/mol. These
17 PWC are shown in Fig. 3b by dashed lines.
The second molecular dimer contains no PCs of the С…Н and/or О…Н type with a potential higher than
+0.7 kJ/mol. Intermolecular contacts of the second GMD and its symmetric analog form a molecular chain of translationally
identical molecules oriented along the crystallographic axis b. According to the nomenclature proposed in [1], this molecular
chain is abbreviated as Bs(1) and is fully designated as Pc(Y)1, Z = 1. It is stabilized only by a large number of PWCs.
The third crystallographically independent GMD has 11 PWCs. The fragment of three non-hydrogen atoms С(5),
С(6), and С(7) of the basic molecule is contained in the “chelate trap” formed by two fragments of the molecule of its first
coordination sphere. The situation is almost the same as in the second GMD (Fig. 3b), but the “trap” is small in this case
(containing only three non-hydrogen atoms). The third GMD has no PCs of the С…Н and/or О…Н type with a potential
higher than +0.7 kJ/mol. The intermolecular contacts of the third GMD and its symmetric analog form a molecular chain
659

Fig. 4. Projection of the crystal structure III along the crystallographic axis a.
designated as SP(21) or simply SP (skating pace) according to the nomenclature proposed in [1]. Since this molecular chain
is oriented along the crystallographic axis a, its full designation is Pc(X)21, Z = 2(1).
Among the remaining four crystallographically independent GMDs of the basic molecule with the molecules of its
first coordination sphere, the fifth and the sixth deserve special attention. In the fifth GMD, the fragment of three non-
hydrogen atoms С(16), С(17), and С(18) of the basic molecule is in the “chelate trap” (7 PWC), and the sixth GMD has a PC
with a positive potential of +1.6 kJ/mol between the Н(23) atom of the basic molecule and the О(2А) atom. The geometrical
parameters of this contact are as follows: distance С(23)…О(2А) is 3.26 Ǻ, distance Н(23)…О(2А) is 2.53 Ǻ, angle
С(23)–Н(23)…О(2А) is 136°. According to the nomenclature proposed in [14], this contact is referred to as a weak H-bond
of the Сar–Н…О type.
Note that the first three crystallographically independent GMDs are significantly different from the other four
GMDs in terms of their integral energy characteristics (Table 2) (contact energy and interaction energy of non-hydrogen
atoms) and differential energy characteristics (the number of PWCs of non-hydrogen atoms and the total energy of PWCs of
non-hydrogen atoms). Consequently, these three GMDs, together with their symmetric analogs, can be considered as the
main elements of the molecular agglomerate in the crystal structure III. Such an agglomerate is the molecular layer parallel to
the crystallographic plane (0 0 1). The boundaries of these molecular layers are shown in Fig. 4 by dashed lines. Note that the
energy of interaction between the molecules inside the layers significantly exceeds the energy of interaction between the
molecules from adjacent layers. According to the nomenclature proposed in [1], the structural class of this molecular layer is
referred to as Pl21(XY), Z = 2(1).
The most energy-intensive element of this molecular layer is the molecular chain oriented along the axis a (first and
third GMDs with their symmetric analogs). The structural class of this molecular chain is Pc(X)21, Z = 2(1), its boundaries are
shown in Fig. 4 by dotted lines.
Thus, the crystal structure III refers to one of the two most common [1] subclasses of the structural class
P212121, Z = 4(1) schematized as 1 – Pc(X)21, Z = 2(1)↑↑Pl(XY)↑↓P212121, Z = 4(1).
660

CONCLUSIONS
It was shown that the reduction of aminoketoalcohol II by the action of (tert-BuO)3LiAlH is diastereospecific, and
the presence of the chiral (carbinol) center next to the reaction center significantly affects the stereoselectivity of the
reduction. The XRD data testify that the newly formed chiral carbinol center in the diastereomer III has the (R)-
configuration.
According to the analysis of intermolecular interaction energy and taking into account both integral (total
intermolecular interaction energy in GMDs) and differential (PWC and PC) characteristics, the crystal structure III contains
molecular agglomerates in the form of molecular chains Pc21(X), Z = 2(1) and molecular layers Pl21(XY), Z = 2(1).
FUNDING
This work was supported by the Russian Foundation for Basic Research (grants Nos. 17-02-00835-a and 17-42-
330787 р-а).
CONFLICT OF INTERESTS
The authors declare that they have no conflict of interests.
REFERENCES
1. P. Zorkii and O. Zorkaya. J. Struct. Chem., 1998, 39(1), 103.
2. V. Demyanovich, I. Shishkina, K. Potekhin, Yu. Struchkov, and N. Zefirov. Dokl. RAS, 1993, 333, 183.
3. V. Demyanovich, I. Shishkina, and N. Zefirov. Chirality, 2001, 13, 507.
4. A. Maleev, B. Sedov, I. Zhitkov, and V. Rau. J. Struct. Chem., 2007, 48(1), 150.
5. V. Demyanovich, I. Shishkina, K. Potekhin, A. Lysov, and N. Zefirov. Dokl. RAS, 1999, 368(1), 59.
6. G. M. Sheldrick. Acta Crystallogr., 2008, A64(1), 112–122.
7. Yu. Zefirov and P. Zorkii. Russ. Chem. Rev., 1989, 58(5), 421.
8. F. Allen, D. Watson, L. Brammer, A. Orpen, and R. Taylor. Int. Tables Crystallogr., 2006, C, 790.
9. V. Panov, A. Goncharov, and K. Potekhin. Crystallogr. Rep., 1998, 43(6), 1007.
10. A. Maleev and A. Gevorgyan. Program for energy and geometric analysis of intermolecular atomic-atom contacts in
crystals. Certificate of registration of the computer program № 2018665015. Moscow: Federal Service for Intellectual
Property (Rospatent), 2018. (submitted for registration)
11. D. Williams and D. Houpt. Acta Crystallogr., 1986, B42, 286.
12. A. Maleev, A. Gevorgyan, and K. Potekhin. J. Struct. Chem., 2018, 59(2), 455.
13. D. Schollmeyer, O. Shishkin, T. Rühl, and M. Vysotsky. CrystEngComm, 2008, 10(6), 715.
14. M. Glowka, D. Martynowski, and K. Kozlowska. J. Mol. Struct., 1999, 474, 81.
661
