Design, synthesis, and biological evaluation of novel

EF24 and EF31 analogs as potential iκB kinase β

inhibitors for the treatment of pancreatic cancer

This article was published in the following Dove Press journal:

Drug Design, Development andTherapy

12 May 2017

Number of times this article has been viewed

Xuemeng Xie

Jinfu Tu

heyi You

Abstract: Given the important role that inhibitory kappa B (IκB) kinase β (IKKβ) plays in

pancreatic cancer (PC) development and progression, inhibitors targeting IKKβ are believed to

be increasingly popular as novel anti-PC therapies. Two synthetic molecules, named EF24 and

EF31, exhibited favorable potential in terms of inhibition of both IKKβ activity and PC cell

proliferation. Aiming to enhance their cellular efﬁcacy and to analyze their structure–activity

relationship, four series of EF24 and EF31 analogs were designed and synthesized. Through

kinase activity and vitality screening of cancer cells, D6 displayed excellent inhibition of both

IKKβ activity and PC cell proliferation. Additionally, multiple biological evaluations showed

that D6 was directly bound to IKKβ and signiﬁcantly suppressed the activation of the IKKβ/

nuclear factor κB pathway induced by tumor necrosis factor-α, as well as effectively inducing

cancer cell apoptosis. Moreover, molecular docking and molecular dynamics simulation analysis

indicated that the dominant force between D6 and IKKβ comprised hydrophobic interactions.

In conclusion, D6 may be a promising therapeutic agent for PC treatment and it also provides

a structural lead for the design of novel IKKβ inhibitors.

Bingren hu

Department of laparoscopic surgery,

First affiliated hospital of Wenzhou

Medical University,Wenzhou, Zhejiang,

People’s republic of china

Keywords: anti-pancreatic cancer activity, IκB kinase β, molecular docking, molecular dynam-

ics simulation

Abbreviations

ATCC, American Type Culture Collection; CUR, curcumin; DCM/MeOH, dichlo-

romethane/methanol; DMSO, dimethyl sulfoxide; DTT, dithiothreitol; EDC/NHS,

1-ethyl-3-(3-dimethylaminopropyl)-carbodiimide/N-hydroxysuccinimide; EDTA,

ethylenediaminetetraacetic acid; EGFR, epidermal growth factor receptor;

ESI-MS, electron-spray ionization mass spectrometry; FBS, fetal bovine serum; FDA,

US Food and Drug Administration; GAPDH, glyceraldehyde 3-phosphate dehydro-

genase; GEM, gemcitabine; G_SA, surface area energy; GSK-3α/β, glycogen synthase

kinase-3α/β; HEPES, [2-[4-(2-hydroxyethyl)-1-piperazinyl]ethanesulfonic acid];

HPLC, high-performance liquid chromatography; HTS, high-throughput screening;

IC₅₀, half-maximal inhibitory concentration; IκB, inhibitory kappa B; IKKβ, IκB

kinase β; IR, inhibitory ratio; KD, kinase domain; K_d, equilibrium dissociation con-

stant; LCPO, linear combinations of pairwise overlaps; LGA, Lamarckian genetic

algorithm; MD, molecular dynamics; MM/GBSA, molecular mechanics/generalized

Born surface area; MS, mass spectrometry; MTT, 3-(4,5-dimethylthiazol-2-yl)-2,5-

diphenyltetrazolium bromide; NF-κB, nuclear factor κB; NMR, nuclear magnetic

resonance; PBST, phosphate buffered saline plus Tween 20; PC, pancreatic cancer;

correspondence: Bingren hu

Department of laparoscopic surgery,

First Afﬁliated Hospital of Wenzhou

Medical University, Wenzhou, Zhejiang

325000, People’s republic of china

Tel/fax +86 577 5557 9422

email wzmuhbr@163.com

submit your manuscript | www.dovepress.com

Dove press

Drug Design, Development andTherapy 2017:11 1439–1451

1439

and incorporate the Creative Commons Attribution – Non Commercial (unported, v3.0) License (http://creativecommons.org/licenses/by-nc/3.0/). By accessing the work you

hereby accept the Terms. Non-commercial uses of the work are permitted without any further permission from Dove Medical Press Limited, provided the work is properly attributed. For permission

for commercial use of this work, please see paragraphs 4.2 and 5 of our Terms (https://www.dovepress.com/terms.php).

http://dx.doi.org/10.2147/DDD T .S133172

Xie et al

Dove press

PDAC, pancreatic ductal adenocarcinoma; PDB, Protein ubiquitination, and separation of the IκB/NF-κB complex,

Data Bank; PE/EA, petroleum ether/ethyl acetate; pIKKβ, allowing the release and translocation of NF-κB into the

phosphorylated IKKβ; PKC, protein kinase C; PVDF, poly- nucleus to regulate multiple key genes involved in cell

vinylidene diﬂuoride; RMSD, root-mean-square deviation; oncogenesis, inﬂammation, and apoptosis.^18–21In recent

RU, response units; SASA, solvent accessible surface area; years, numerous studies have documented that constitutive

SDD, scaffold/dimerization domain; SDS-PAGE, sodium activation of NF-κB triggered by deregulation of IKKβ

dodecyl sulfate polyacrylamide gel electrophoresis; siRNA, occurs in almost all PC specimens, as well as in various PC

small interfering RNA; SPR, surface plasmon resonance; cell lines.^14,22,23For example, Ling et al²⁴noted that IKKβ-

STAT-3, signal transducer and activator of transcription-3; mediated NF-κB activation is highly required for develop-

TBST, tris-buffered saline plus Tween 20; TLC, thin layer ment of PDAC, and pancreas-targeted IKKβ inactivation

chromatography; TLR4, toll-like receptor 4; TNF, tumor inhibited both NF-κB activation and PDAC tumorigenesis.

necrosis factor; ULD, ubiquitin-like domain.

Accumulating evidence suggests that aberrant IKKβ

activity intensively contributes to pancreatic tumorigenesis

by triggering the production of many antiapoptotic and

Introduction

PC is currently one of the most devastating malignant proliferation-related molecules that NF-κB regulates, such

neoplasms.^1,2According to statistics, it has been estimated as Bcl-xL, cIAP, cyclin D1, KU70, and KU80.^25,26Moreover,

that the number of new cases of Americans diagnosed with the IKKβ/NF-κB pathway is a versatile and complicated

PC was 53,070 in 2016, and 41,780 people had died of this pathway that is widely associated with other pivotal signal

disease.³The overall 5-year survival rate of PC patients proteins (Ras, MAPKs, GSK-3β, and Notch), which may

is ~7%.³For patients with advanced disease, this ﬁgure activate IKKβ/NF-κB in a bypass manner and promote car-

is worse, as low as 1%.⁴Due to the highly nonspeciﬁc cinogenesis as an accomplice.^22,24,27Wilson and Baldwin²²

incipient symptoms, 80%–85% of patients diagnosed reported that GSK-3α/β upregulated the activity of IKKβ to

with PC already were in the advanced and metastatic promote the survival of PANC-1 and MiaPaCa-2 cells (two

stages and not suited for surgical resection.⁵Thus, che- human PC cell lines). All these reports reveal that exploiting

motherapy becomes the principal remedy for patients with effective IKKβ inhibitors could be an advisable approach for

advanced PC. As the only standard ﬁrst-line therapy for the treatment of PC.

advanced PC patients, GEM, a conventional cytotoxic drug,

Given the important therapeutic potential of IKKβ inhibi-

exerts favorable anticancer action by breaking down the tors for treating PC, numerous selective IKKβ inhibitors have

deoxynucleotide metabolism of PC cells.^6,7However, the been discovered, including BMS-345541, ML-120B, and

increasing occurrence of acquired resistance by PC cells TPCA-1, the IC₅₀values of which were 300, 45, and 18 nM,

and the nonselective cytotoxicity to normal cells led to the respectively (Figure 1).^28–30Nonetheless, no small-molecule

outcomes of GEM monotherapy being extremely poor.^8–10IKKβ inhibitor has been approved for clinical applications so

Currently, various combination therapeutic regimens have far.³¹Part of the reason for these inhibitors possessing excel-

been assessed in clinical or preclinical practice in the hope lent enzymatic inhibitory activity but failing in the preclinical

of overcoming the intricate mechanism of resistance.^11,12trials is their poor metabolism and severe toxicity to normal

Unfortunately, this approach is also more likely to increase cells. CUR, a well-known anticancer compound derived from

the incidence of toxic effects, such as irreversible myelo- turmeric, has become the research hotspot of natural prod-

suppression and gastrointestinal adverse reactions.¹³Thus, ucts and drug candidates in recent years due to its inhibition

development of new targeted therapies for PC is highly of multiple targets highly related to cancer, such as IKKβ,

urgent and crucial. Of the proteins closely related to the STAT-3, and PKC, as well as its nontoxicity (Figure 1).^32,33

formation and progress of PC, IKKβ is considered to be However, the low biostability of CUR dramatically restrains

an important potential target.^14,15

its clinical application. By screening a large number of CUR

The IKK family consists of a series of four enzymes analogs, two more stable and effective analogs of CUR,

(IKKα, IKKβ, IKKγ, and IKKε).¹⁶IKKβ is the predomi- named as EF24 and EF31 (Figure 1), were discovered suc-

nant catalytic subunit mediating the classic IKK/NF-κB cessively, the IC₅₀values of which against IKKβ were 1.9

pathway, and it contains an N-terminal KD, a central ULD, and 1.92 μM, respectively.^34,35In addition, EF24 and EF31

and a C-terminal SDD structurally.¹⁷Following extracellular also exhibited striking inhibition of PC cells.^36,37Although the

stimulations (stress, cytokines, and free radicals), IKKβ KD favorable suppression effect of EF24 and EF31 against IKKβ

becomes phosphorylated, resulting in the phosphorylation, and PC cells attracted much researcher interest, surprisingly,

submit your manuscript | www.dovepress.com

Drug Design, Development andTherapy 2017:11

1440

Dove press

Design, synthesis, and biological evaluation of novel EF24 and EF31 analogs

&,

2

1+_ꢀ

1+

1+_ꢀ

0H2

2

6

1

+

)

1

+1

1+_ꢀ

1

+

1

2

%06ꢀꢁꢂꢃꢃꢂꢄ

0/ꢀꢄꢅꢆ%

73&$ꢀꢄ

)

2

)

2

1

20H

2+

0H2

+2

1

+

1

+

&XUFXPLQ

()ꢅꢂ

()ꢁꢄ

Figure 1 chemical structures of some reported iKKβ inhibitors.
