Ordered and Oriented Supramolecular n/p-Heterojunction
Surface Architectures: Completion of the Primary Color
Collection
Ravuri S. K. Kishore,† Oksana Kel,‡ Natalie Banerji,‡ Daniel Emery,†
Guillaume Bollot,† Jiri Mareda,† Alberto Gomez-Casado,¶ Pascal Jonkheijm,¶
Jurriaan Huskens,¶ Plinio Maroni,§ Michal Borkovec,§ Eric Vauthey,*,‡
Naomi Sakai,*,† and Stefan Matile*,†
Departments of Organic, Inorganic and Analytical, and Physical Chemistry, UniVersity of
GeneVa, GeneVa, Switzerland, and Molecular Nanofabrication Group, UniVersity of Twente,
Enschede, The Netherlands
Received April 23, 2009; E-mail: eric.vauthey@unige.ch; naomi.sakai@unige.ch; stefan.matile@unige.ch
Abstract: In this study, we describe synthesis, characterization, and zipper assembly of yellow p-oligophenyl
naphthalenediimide (POP-NDI) donor-acceptor hybrids. Moreover, we disclose, for the first time, results
from the functional comparison of zipper and layer-by-layer (LBL) assembly as well as quartz crystal
microbalance (QCM), atomic force microscopy (AFM), and molecular modeling data on zipper assembly.
Compared to the previously reported blue and red NDIs, yellow NDIs are more π-acidic, easier to reduce,
and harder to oxidize. The optoelectronic matching achieved in yellow POP-NDIs is reflected in quantitative
and long-lived photoinduced charge separation, comparable to their red and much better than their blue
counterparts. The direct comparison of zipper and LBL assemblies reveals that yellow zippers generate
more photocurrent than blue zippers as well as LBL photosystems. Continuing linear growth found in QCM
measurements demonstrates that photocurrent saturation at the critical assembly thickness occurs because
more charges start to recombine before reaching the electrodes and not because of discontinued assembly.
The found characteristics, such as significant critical thickness, strong photocurrents, large fill factors, and,
according to AFM images, smooth surfaces, are important for optoelectronic performance and support the
existence of highly ordered architectures.
Introduction
efficient exciton dissociation without losses in charge mobil-
ity, bicontinuous electron-(e-) and hole (h+)-transporting
Directional energy, electron and hole transport along
sophisticated multicomponent donor-acceptor cascades, is
essential in biological photosynthesis.1 In bilayer organic
solar cells, electrons and holes generated by exciton dis-
sociation at the interface of n- and p-semiconductors travel
through gradient-free bulk layers.2a In bulk n/p-heterojunction
(BHJ) solar cells, the active interface is increased to maximize
the efficiency of exciton dissociation.2-5 Improved exciton
dissociation at increased interfaces usually comes at the cost
of decreased hole and electron mobility in less continuous
and organized n- and p-semiconducting materials. To achieve
channels that are aligned coaxially on the molecular level
are desired. This ideal architecture has been referred to as
supramolecular n/p-heterojunction (SHJ). Contrary to the
advanced situation with covalent donor-acceptor architec-
tures,6 synthetic “bottom-up” access to SHJs7-10 remains,
however, as challenging as the installation of redox
gradients.11-16 In the bioinspired ideal scenario, electrons
and holes generated by photoinduced charge separation (PCS)
would be rapidly carried away in opposite directions along
oriented multicolored antiparallel redox gradients (OMARGs)
in the adjacent n- and p-channels of SHJs. Ideal OMARG-
SHJ architectures can be expected to give not only maximal
short circuit photocurrents but also maximal fill factors5a as
well as open circuit voltages11,14a (see below).
† Department of Organic Chemistry, University of Geneva.
‡ Department of Physical Chemistry, University of Geneva.
§ Department of Inorganic and Analytical Chemistry, University of
Geneva.
¶ Molecular Nanofabrication Group, University of Twente.
(1) (a) Deisenhofer, J.; Michel, H. Science 1989, 245, 1463–1473. (b)
Nelson, N.; Ben-Shem, A. Nat. ReV. Mol. Cell Biol. 2004, 5, 971–
982. (c) Carmeli, I.; Frolov, L.; Carmeli, C.; Richter, S. J. Am. Chem.
Soc. 2007, 129, 12352–12353. (d) Barber, J. Chem. Soc. ReV. 2009,
38, 185–196.
(3) (a) Lee, J. K.; Ma, W. L.; Brabec, C. J.; Yuen, J.; Moon, J. S.; Kim,
J. Y.; Lee, K.; Bazan, G. C.; Heeger, A. J. J. Am. Chem. Soc. 2008,
130, 3619–3623. (b) Yang, X.; Loos, J.; Veenstra, S. C.; Verhees,
W. J. H.; Wienk, M. M.; Kroon, J. M.; Michels, M. A. J.; Janssen,
R. A. J. Nano Lett. 2005, 5, 579–583.
(2) (a) Tang, C. W. Appl. Phys. Lett. 1986, 48, 183–185. (b) Yu, G.; Gao,
J.; Hummelen, J. C.; Wudl, F.; Heeger, A. J. Science 1995, 270, 1789–
1791. (c) Thompson, B. C.; Fre´chet, J. M. J. Angew. Chem., Int. Ed.
2008, 47, 58–77. (d) Gnes, S.; Neugebauer, H.; Sariciftci, N. S. Chem.
ReV. 2007, 107, 1324–1338.
(4) Ma, C.; Fonrodona, M.; Schikora, M. C.; Wienk, M. M.; Janssen,
R. A. J.; Ba¨uerle, P. AdV. Funct. Mater. 2008, 18, 3323–3331.
(5) (a) Yang, F.; Shtein, M.; Forrest, S. Nat. Mater. 2005, 4, 37–41. (b)
O’Regan, B.; Gra¨tzel, M. Nature 1991, 353, 737–741.
9
11106 J. AM. CHEM. SOC. 2009, 131, 11106–11116
10.1021/ja9030648 CCC: $40.75  2009 American Chemical Society

Supramolecular n/p-Heterojunction Surface Architectures
A R T I C L E S
Figure 1. Frontier orbital energy levels of NDIs (general structures C2-G), POPs (general structure as in Figure 2), chlorophyll, and ubiquinone (solid lines,
HOMO; dashed lines, LUMO); dashed arrows, absorption of light (hν) with wavelength (nm) of maximal absorption (top) and emission (bottom); data from
refs 20-24, 33, and this report.
Recently, we have introduced zipper assembly as a new
approach toward OMARG-SHJs and other applications in
molecular optoelectronics.8 Zipper architectures are composed
of e--transporting π-stacks aligned along h+-transporting strings
of rods. The π-acidic 1,4,5,8-naphthalenediimides (NDIs)17-26
have been selected as π-stacks in zipper architectures because
they can change spectral and redox properties without global
structural changes (Figure 1).9,20-23 Compared to the many other
possible multicolor collections (e.g., perylenediimides, Alexa
Fluors, fluoresceins, BODIPYs, cyanines, porphyrinoids, or
triangular dehydrobenzo[12]annulenes),27-30 the spectacular
combination of (1) decreasing HOMO/LUMO energies with
increasing HOMO/LUMO energy differences (Figure 1),24-26
(2) full coverage of the visible range, (3) global structural
preservation, (4) n-semiconductivity, (5) π-acidity, (6) planarity,
(7) compactness (“atom efficiency”), and (8) synthetic acces-
sibility offered by NDIs remains unique. Multicolor redox
