Intramolecular Energy Transfer within Butadiyne-Linked
Chlorophyll and Porphyrin Dimer-Faced, Self-Assembled
Prisms
Richard F. Kelley,†,‡ Suk Joong Lee,†,‡ Thea M. Wilson,†,‡ Yasuyuki Nakamura,|
David M. Tiede,*,‡,§ Atsuhiro Osuka,*,| Joseph T. Hupp,*,†,‡ and
Michael R. Wasielewski*,†,‡
Department of Chemistry and Argonne-Northwestern Solar Energy Research (ANSER) Center,
Northwestern UniVersity, EVanston, Illinois 60208-3113, Chemistry DiVision, Argonne National
Laboratory, Argonne, Illinois 60439, and Department of Chemistry, Graduate School of Science,
Kyoto UniVersity, Kyoto 606-8502, Japan
Received July 23, 2007; E-mail: m-wasielewski@northwestern.edu
Abstract: The synthesis and photophysical properties of butadiyne-linked chlorophyll and porphyrin dimers
in toluene solution and in several self-assembled prismatic structures are described. The butadiyne linkage
between the 20-positions of the macrocycles results in new electronic transitions polarized along the long
axes of the dimers. These transitions greatly increase the ability of these dimers to absorb the solar spectrum
over a broad wavelength range. Femtosecond transient absorption spectroscopy reveals the relative rate
of rotation of the macrocycles around the butadiyne bond joining them. Following addition of 3-fold symmetric,
metal-coordinating ligands, both macrocyclic dimers self-assemble into prismatic structures in which the
dimers comprise the faces of the prisms. These structures were confirmed by small-angle X-ray scattering
experiments in solution using a synchrotron source. Photoexcitation of the prismatic assemblies reveals
that efficient, through-space energy transfer occurs between the macrocyclic dimers within the prisms.
The distance dependence of energy transfer between the faces of the prisms was observed by varying the
size of the prismatic assemblies through the use of 3-fold symmetric ligands having arms with different
lengths. These results show that self-assembly of discrete macrocyclic prisms provides a useful new strategy
for controlling singlet exciton flow in antenna systems for artificial photosynthesis and solar cell applications.
Introduction
desired low-energy transition. To address this problem, another
recent study introduced a bridging ligand into a solution of
Photofunctional materials for use in organic photovoltaics
must be capable of transferring energy efficiently due to the
relatively long distances photogenerated excitons must travel
to reach the interface at which charge carriers are generated.1,2
Several studies have examined multiporphyrin arrays constructed
with ethynyl and butadiynyl linkers for applications in photo-
voltaic devices.3,4 The linkers in these arrays provide extended
conjugation between the macrocycles resulting in new, low-
energy electronic transitions, which provide enhanced solar
spectral absorption. The same studies, however, have also shown
these linkers allow rotational conformational heterogeneity,
which can diminish the population of molecules having the
butadiyne-linked porphyrin arrays to coordinate to the porphyrin
metal centers, thus locking the chromophores in a rigid, oriented
fashion.5 The strain induced by the coordinating ligand caused
the chromophores to deviate from planarity by bending the
butadiyne linkage. This bending may result in disorder if the
systems were to be incorporated into solid-phase devices.
Coordination bond formation between tetrapyrrole metal centers
and polydentate ligands is an attractive strategy for building
supramolecular structures in which the chromophores are
planarized as the result of coordination. This coordination-driven
self-assembly strategy has become a very successful method
for constructing a variety of 3-D supermolecules.6-22 Increasing
the number of coordination bonding sites within the structure
† Department of Chemistry, Northwestern University.
‡ ANSER Center, Northwestern University.
§ Chemistry Division, Argonne National Laboratory.
| Graduate School of Science, Kyoto University.
(1) Haugeneder, A.; Neges, M.; Kallinger, C.; Spirkl, W.; Lemmer, U.;
Feldmann, J.; Scherf, U.; Harth, E.; Gugel, A.; Mu¨llen, K. Phys. ReV. B:
Condens. Matter 1999, 59, 15346-15351.
(5) Winters, M. U.; Kaernbratt, J.; Eng, M.; Wilson, C. J.; Anderson, H. L.;
Albinsson, B. J. Phys. Chem. C 2007, 111, 7192-7199.
(6) Tabushi, I.; Kugimiya, S.; Kinnaird, M. G.; Sasaki, T. J. Am. Chem. Soc.
1985, 107, 4192-4199.
(7) Hunter, C. A.; Meah, M. N.; Sanders, J. K. M. J. Chem. Soc., Chem.
Commun. 1988, 694-696.
(2) Peumans, P.; Yakimov, A.; Forrest, S. R. J. Appl. Phys. 2003, 93, 3693-
3723.
(8) Hunter, C. A.; Leighton, P.; Sanders, J. K. M. J. Chem. Soc., Perkin Trans.
1989, 1, 547-552.
(3) Kumble, R.; Palese, S.; Lin, V. S. Y.; Therien, M. J.; Hochstrasser, R. M.
J. Am. Chem. Soc. 1998, 120, 11489-11498.
(9) Camara-Campos, A.; Hunter, C. A.; Tomas, S. Proc. Natl. Acad. Sci. U.S.A.
2006, 103, 3034-3038.
(4) Ahn, T. K.; Yoon, Z. S.; Hwang, I.-W.; Lim, J. K.; Rhee, H.; Joo, T.; Sim,
E.; Kim, S. K.; Aratani, N.; Osuka, A.; Kim, D. J. Phys. Chem. B 2005,
109, 11223-11230.
(10) Ballester, P.; Oliva, A. I.; Costa, A.; Deya, P. M.; Frontera, A.; Gomila,
R. M.; Hunter, C. A. J. Am. Chem. Soc. 2006, 128, 5560-5569.
9
10.1021/ja075494f CCC: $40.75 © 2008 American Chemical Society
J. AM. CHEM. SOC. 2008, 130, 4277-4284
4277

A R T I C L E S
Kelley et al.
Figure 1. Structures of the molecules in this study.
