Chemistry of Heterocyclic Compounds, Vol. 43, No. 5, 2007
UNEXPECTED RESULT FROM THE INTERACTION OF 1,8-DIAMINO-
NAPHTHALENE WITH AROMATIC NITRILES IN POLYPHOSPHORIC ACID
I. V. Aksenova, I. V. Borovlev, A. S. Lyakhovnenko, S. V. Pisarenko, and A. V. Aksenov
Keywords: 1,8-diaminonaphthalene, perimidine, polyphosphoric acid, 1,3,5-triazapyrenes, annelation,
acylation.
The reaction of 1,8-diaminonaphthalene dihydrochloride with acetonitrile and butyronitrile at high
temperature gave 2-methyl- and 2-propylperimidine respectively [1]. We investigated the reaction of
1,8-diaminonaphthalene (1) with aromatic nitriles in polyphosphoric acid* (PPA) assuming that it would form
only 2-Ar-perimidines, or (by analogy with carbonic acids [2]) products of their acylation. The reaction occurred
on heating the reagents above 100°C, but the unexpected products were the previously unknown 2,6,8-triaryl-
1,3,7-triazapyrenes 3a-c.
Ar
2
N 1
3 N
NH2
NH2
Ar–C
N
2a–c
10
9
4
5
PPA, 100°С
8
6
1
Ar
Ar
N
7
3a–c
3 a Ar = Ph; b Ar = 4-BrC6H4; c Ar = 4-O2NC6H4
The proposed mechanism for this conversion includes formation of a 2-Ar-perimidine 4, electrophilic
attack on 4 by the nitrile cation at position 6(7), and then at nitrogen atom of the ketimine 5 to give the
intermediate 6 and its subsequent cyclization at the peri position. Subsequent aromatization occurs via
elimination of ammonia.
So interaction of aromatic nitriles in PPA with the peri diamine 1 not only leads to closure of the
perimidine ring but also to peri-annelation of the [c,d]pyridine ring leading to a one-pot synthesis of the
previously unknown 1,3,7-triazapyrene. We intend to investigate some general characteristics of this reaction
with respect to perimidine and other condensed aromatic and heteroaromatic compounds.
_______
* PPA used contains 86% P2O5; was prepared as in [3].
__________________________________________________________________________________________
Stavropol State University, Stavropol 355009, Russia; e-mail: k-biochem-org@stavsu.ru. Translated
from Khimiya Geterotsiklicheskikh Soedinenii, No. 5, 788-790, May, 2007. Original article submitted May 4,
2007.
0009-3122/07/4305-0665©2007 Springer Science+Business Media, Inc.
665

1
The H NMR spectra of CDCl3 solutions with TMS as internal standard were recorded on a Bruker-200
(200 MHz) instrument.
Ar
H
+
N
N
2
Ar
N
H
1
+
PPA
– H
4
Ar
H
Ar
N
N
H
+
N
N
+
Ar
N
H
H
3
+
+
– NH4
– H
N
Ar
NH
NH
Ar
5
6
Ar
General Method. A mixture of 1,8-diaminonaphthalene (1) (0.158 g, 1 mmol), the corresponding nitrile
(3.5 mmol), and PPA (3-4 g) was vigorously stirred for 3 h at 180°C. The reaction mixture was cooled to 80°C
and poured with stirring into cold water (30 ml), basified with ammonia solution to pH ~ 8, the precipitate was
filtered off and dried in the air. The dried substance was extracted with ethyl acetate for 1.5 h in a Soxhlet
apparatus. The solution was evaporated and the precipitate filtered off.
2,6,8-Triphenyl-1,3,7-triazapyrene (3a, C31H19N3). Yield 0.155 g (35%). Yellow crystals, mp
1
286-288°C (ethyl acetate). H NMR spectrum, δ, ppm (J, Hz): 7.61 (9H, m, H-m and –p, 2-, 6-, and 8-C6H5);
7.95 (4H, d, J = 7.5, 6- and 8-C6H5, H-o); 8.26 (2H, d, J = 9.5, H-5,9); 8.76 (2H, d, J = 9.5, H-4,10); 8.84 (2H, d,
J = 7.5, o-H, 2-C6H5). Found, %: C 86.09; H 4.21; N 9.49. C31H19N3. Calculated, %: C 85.89; H 4.42; N 9.69.
2,6,8-Tri(4-bromophenyl)-1,3,7-triazapyrene (3b, C31H16Br3N3) Yield 0.168 g (24%). Yellow
crystals, mp 193-195°C (ethyl acetate). 1H NMR spectrum, δ, ppm (J, Hz): 7.61 (4H, d, J = 8.8, 6 and 8-C6H5);
7.74 (2H, d, J = 8.1, H-m 2-C6H5); 7.94 (4H, d, J = 8.8, H-o 6- and 8-C6H5); 8.29 (2H, d, J = 9.5, H-5,9); 8.72
(2H, d, J =9.5, H-4,10); 8.75 (2H, d, J = 8.1, H-o 2-C6H5). Found, %: C 55.72; H 2.38; N 6.21. C31H16Br3N3.
Calculated, %: C 55.56; H 2.41; N 6.27.
2,4,6-Tri(4-nitrophenyl)-1,3,7-triazapyrene (3c, C31H16N6O6). Yield 0.142 g (27%). Yellow crystals,
1
mp 182-184°C (ethyl acetate). H NMR spectrum, δ, ppm (J, Hz): 7.98 (4H, d, J = 8.7, H-o, 6-, 8-C6H5); 8.29
(2H, d, J = 9.5, H-5,9); 8.42 (4H, d, J = 8.7, 3,5-H-m 6-, 8-C6H5); 8.46 (2H, d, J = 8.5, H-m 2-C6H5); 8.76 (2H,
d, J = 9.5, H-4,10); 8.79 (2H, d, J = 8.5, C-2, H-o 2-C6H5). Found, %: C 65.68; H 2.81; N 14.67. C31H16N6O6.
Calculated, %: C 65.50; H 2.84; N 14.78.
REFERENCES
1.
2.
E. L. Holljes and E. C. Wagner, J. Org. Chem., 9, 31 (1944).
A. F. Pozharskii, I. V. Borovlev, and I. S. Kashparov, Khim. Geterotsikl. Soedin., 543 (1975). [Chem.
Heterocycl. Comp., 11, 480 (1975)].
3.
F. Uhlig, Angew. Chem., 66, 435 (1954).
