C O M M U N I C A T I O N S
Figure 2. AFM image of the UV-patterned HD-UV-PA-modified surface
after drop-casting SWCNTs form a H2O/methanol solution (3:1 volume).
The higher resolution images on the left and right illustrate the high
selectivity of the deposition.
In conclusion, we have patterned the surface of an oxide
substratate to produce both hydrophobic and hydrophilic regions
using self-assembly of a photosensitive compound. The use of UV
light to pattern the surface energy of a monolayer is scalable and
can be readily implemented in current semiconductor processing.
Moreover, the combination of UV patterning with simple solution
processing methods yields patterns of SWCNTs with excellent
selectivity and high density. Further development of this process,
including the use of more advanced exposure techniques, may lead
to a simple and effective method for the selective placement and
alignment of individual SWCNTs.
Figure 1. (a) Illustration of creating the photopatterned monolayer, (b)
illustration of the UV-induced reaction of SAM 6, and (c) AFM image of
the photopatterned monolayer surface.
to that of the ODPA monolayer is probably due to the larger
footprint of the former leading to a lower density of alkyl chains
on the surface after assembly. After blanket UV exposure, the water
contact angle of the monolayer decreased significantly, yielding a
water contact angle of about 15 ( 5° after a 45 min exposure.
Bain et al. reported water contact angles of approximately 5° for
carboxyl-terminated alkane thiols of various chain lengths on gold.9
The higher contact angle measured for the carboxyl-terminated
monolayer is also attributed to the larger molecular footprint of
the HD-UV-PA molecule.
Acknowledgment. This material is based on work partially
supported by DARPA under Contract N66001-06-C-2047. J.A.B.
thanks the University of Washington Center for Nanotechnology
for the Nanotechnology Fellowship. The authors thank Dr. Dario
Goldfarb for use of the photopatterning equipment, and the IBM
MRL fabrication facility for fabrication of wafers and deposition
of dielectrics.
Due to the large size of the cleaved portion of the assembled
molecule (approximately 2 nm fully extended), atomic force
microscope (AFM) images were useful in verifying the monolayer
reaction. Figure 1b shows an AFM image of the patterned HD-
UV-PA surface. The measured height difference between the UV-
exposed and unexposed regions of the monolayer was approxi-
mately 0.7 nm (Supporting Information). The lower value of the
measured height difference compared to the theoretical value is
most likely due to the flexibility of the alkyl chain. The monolayer
reaction was also verified by X-ray photoelectron spectroscopy
through the elimination of the N 1s peak in the spectrum after UV
exposure (Supporting Information).
Supporting Information Available: Detailed synthesis experimental
procedures and SAM characterization. This material is available free
References
(1) (a) Avouris, Ph.; Appenzeller, J.; Martel, R.; Wind, S. Proc. IEEE 2003,
91, 1772–1784. (b) Avouris, Ph. Acc. Chem. Res. 2002, 35, 1026–1034.
(c) Wildo¨er, J.; Venema, L.; Rinzler, A.; Smalley, R.; Dekker, C. Nature
1998, 391, 59–62. (d) Odom, T.; Huang, J.-L.; Kim, P.; Lieber, C. Nature
1998, 391, 62–64.
(2) (a) Avouris, Ph. MRS Bull. 2004, 29, 403–410. (b) Javey, A.; Guo, J.;
Farmer, D. B.; Wang, Q.; Wang, D.; Gordon, R. G.; Lundstrom, M.; Dai,
H. Nano Lett. 2004, 4, 447–450. (c) Dai, H. Surf. Sci. 2002, 500, 218–
241. (d) Lin, Y. M.; Appenzeller, J.; Knoch, J.; Avouris, Ph. IEEE Trans.
Nanotechnol. 2005, 4, 481–489. (e) Bachtold, A.; Hadley, P.; Nakanishi,
T.; Dekker, C. Science 2001, 294, 1317–1320.
Deposition of the aqueous solution of SWCNTs by drop-casting
on the patterned monolayer surface yielded the desired combination
of excellent selectivity and densely packed SWCNTs. Since the
unexposed areas of the monolayer are very hydrophobic, the
aqueous SWCNT solution prefers to wet the areas that have been
exposed to UV light, forming microdroplets on the exposed areas.
The solvent then evaporates leaving the SWCNTs on the carboxyl-
terminated surfaces. Figure 2 shows a 20 µm AFM image of drop-
cast SWCNTs on a patterned HD-UV-PA surface. Higher resolution
images of the hydrophobic and hydrophilic regions of the monolayer
after SWCNT deposition are shown adjacent to the 20 µm image
in Figure 2.
(3) (a) Nakanishi, T.; Masuda, Y.; Koumoto, K. Chem. Mater. 2004, 16, 3484–
3488. (b) Xiang, J.; Masuda, Y.; Koumoto, K. AdV. Mater. 2004, 16, 1461–
1464. (c) Benor, A.; Hoppe, A.; Wagner, V.; Knipp, D. Thin Solid Films
2007, 515, 7679–7682. (d) Yerushalmi, R.; Ho, J. C.; Jacobson, Z. A.;
Javey, A. Nano Lett. 2007, 7, 2764. (e) Fan, F.; Stebe, K. J. Langmuir
2004, 20, 3062–3067.
(4) Ko, H.; Peleshanko, S.; Tsukruk, V. J. Phys. Chem. B 2004, 108, 4385–
4393.
(5) (a) Hannon, J. B; Afzali, A.; Klinke, C.; Avouris, Ph. Langmuir 2005, 21,
8569–8571. (b) Klinke, C.; Hannon, J. B.; Afzali, A.; Avouris, Ph. Nano
Lett. 2006, 6, 906–910. (c) Tulevski, G.; Hannon, J. B.; Afzali, A.; Chen,
Z.; Avouris, Ph.; Kagan, C. R. J. Am. Chem. Soc. 2007, 129, 11964–11968.
(6) Klinke, C.; Afzali, A.; Avouris, Ph. Chem. Phys. Lett. 2006, 430, 75.
(7) Bochet, C. J. Chem. Soc., Perkin Trans. 1 2002, 125–142.
(8) Hoque, E.; DeRose, J. A.; Hoffmann, P.; Mathieu, H. J.; Bhushan, B.;
Cichomski, M. J. Chem. Phys. 2006, 124, 174710–174716.
It should be noted that some local ordering of bundled SWCNTs
is visible in the AFM image shown in Figure 2. This type of
“woven” structure has been noted previously10 and was attributed
in part to the motion of the liquid-solid-air contact line.
(9) Bain, C. D.; Troughton, E. B.; Tao, Y.-T.; Eval, J.; Whitesides, G. M.;
Nuzzo, R. G. J. Am. Chem. Soc. 1989, 111, 321–335.
(10) Xin, H.; Wooley, A. T. Nano Lett. 2004, 4, 1481–1484.
