C O M M U N I C A T I O N S
Acknowledgment. This research was supported by the NIH
(GM61238). F.F. is a MEC-Fulbright Postdoctoral Fellow. NMR
spectrometers were purchased in part by grants from NIH and NSF;
diffraction equipment was supported by grants from NSF. We thank
S. H. Choi for growing the crystals of tetrapeptide mimics 1
and 2.
Supporting Information Available: Experimental details, com-
pound characterizations, NMR data and crystallographic data. This
Figure 4. Sequences of 5-8.
in specific tertiary structural contexts, represent substantial sources
of intrinsic secondary structural stability. To probe the significance
of lateral residue pairings in parallel ꢀ-sheet, we prepared 7 and 8,
the sequence isomers of 5 and 6, respectively, in which the
attachment points of the strands to the Gly-CHDA linker have been
swapped (Figure 4). Of the six lateral residue pairings in the hairpin
conformation of 5 or 6, four are altered in the sequence isomers
(two do not change because the residues are identical). In each of
these four asymmetric pairings, the orientation in 5 and 6 is
predicted to be superior to that in 7 and 8, based on the protein
structure database analysis.13 The behavior of 7 and 8 is consistent
with this prediction: 2D NMR data reveal that neither molecule
shows any NOE between protons on sequentially nonadjacent
residues. Thus, neither 7 nor 8 appears to form parallel ꢀ-sheet
secondary structure in aqueous solution. These results show that
the Gly-CHDA linkers are not dominant drivers of parallel ꢀ-sheet
formation; instead, these linkers enable parallel ꢀ-sheet interactions
between attached strands, but interstrand attractions must contribute
to overall conformational stability. Moreover, these results show
that intrinsic ꢀ-sheet propensities of strand residues are not sufficient
to drive folding; instead specific and favorable interactions between
side chains on adjacent strands appear to be necessary for parallel
ꢀ-sheet formation.
References
(1) Chakrabartty, A.; Baldwin, R. L. AdV. Protein Chem. 1995, 46, 141.
(2) (a) Gellman, S. H. Curr. Opin Chem. Biol. 1998, 2, 717. (b) Searle, M. S.;
Ciani, B. Curr. Opin. Struct. Biol. 2004, 14, 458. (c) Hughes, R. M.; Waters,
M. L. Curr. Opin. Struc. Biol. 2006, 16, 514–524. (d) De Alba, E.; Rico,
M.; Jime´nez, M. A. Protein Sci. 1999, 8, 2234.
(3) (a) Levin, S.; Nowick, J. S. J. Am. Chem. Soc. 2007, 129, 13043. (b)
Nowick, J. S.; Smith, E. M.; Noronha, G. J. Org. Chem. 1995, 60, 7386.
(c) Nowick, J. S.; Insaf, S. J. Am. Chem. Soc. 1997, 119, 10903. (d) Nowick,
J. S. Acc. Chem. Res. 1999, 32, 287.
(4) (a) Wagner, G.; Feigel, M. Tetrahedron 1993, 49, 10831. (b) Ranganathan,
D.; Haridas, V.; Kurur, S.; Thomas, A.; Madhusudanan, K. P.; Nagaraj,
R.; Kunwar, A. C.; Sarma, A. V. S.; Karle, I. L. J. Am. Chem. Soc. 1998,
120, 8448. (c) Fisk, J. D.; Powell, D. R.; Gellman, S. H. J. Am. Chem.
Soc. 2000, 122, 5443.
(5) For analysis of parallel ꢀ-sheet model systems in aqueous or mixed
aqueous-organic solvents, see: (a) Kemp, D. S.; Blanchard, D. E.; Muendel,
C. C. In Peptides-Chemistry and Biology; Smith, J., Rivier, J., Eds.;
ESCOM: Leiden, The Netherlands, 1992; p 319. (b) Junquera, E.; Nowick,
J. S. J. Org. Chem. 1999, 64, 2527. (c) Chitnumsub, P.; Fiori, W. R.;
Lashuel, H. A.; Diaz, H.; Kelly, J. W. Bioorg. Med. Chem. 1999, 7, 39.
(6) (a) Fisk, J. D.; Gellman, S. H. J. Am. Chem. Soc. 2001, 123, 343. (b) Fisk,
J. D.; Schmitt, M. A.; Gellman, S. H. J. Am. Chem. Soc. 2006, 128, 7148.
(7) (a) Bolm, C.; Atodiresei, L.; Schiffers, I.; Kanai, M.; Shibasaki, M. Org.
Synth. 2005, 82, 120. (b) Bolm, C.; Schiffers, I.; Dinter, C. L.; Gerlach, A.
J. Org. Chem. 2000, 65, 6984.
(8) Please see Supporting Information.
(9) (a) Setnicka, V.; Huang, R.; Thomas, C. L.; Etienne, M. A.; Kubelka, J.;
Hammer, R. P.; Keiderling, T. A. J. Am. Chem. Soc. 2005, 127, 4992. (b)
Aravinda, S.; Shamala, N.; Rajkishore, R.; Gopi, H. N.; Balaram, P. Angew.
Chem., Int. Ed. 2002, 41, 3863–3865.
We have introduced a new linker, Gly-CHDA, for connecting
peptide strands via their N-termini and shown that this unit (in either
enantiomeric form) constitutes the first N-terminal linker to support
parallel ꢀ-sheet folding in aqueous solution. Because ꢀ-sheet
secondary structure forms without buttressing from a tertiary
context, and because folding depends upon intrinsic attractions
between the strands themselves, Gly-CHDA linkers will be valuable
tools for fundamental study of the factors that influence the stability
of parallel ꢀ-sheet, a very common structural motif within proteins.
We have illustrated this utility by providing a first qualitative test
of predictions based on the recent database analysis of lateral residue
pairing preferences by Hutchinson et al.13
The new Gly-CHDA linkers complement previously described
C-terminal linkers that promote parallel ꢀ-sheet folding in water.6
The availability of both N- and C-terminal linkers will be useful
for preparation of cyclic peptides, to provide spectroscopic bench-
marks for the fully folded state of parallel hairpin model systems,
and these linkers will be essential for generating autonomously
folding parallel ꢀ-sheets that contain three or more strands.
(10) Fisk, J. D. Ph.D. Thesis, University of Wisconsin-Madison, 2004.
(11) Griffiths-Jones, S. R.; Maynard, A. J.; Searle, M. S. J. Mol. Biol. 1999,
292, 1051–1069.
(12) (a) Mun˜oz, V.; Serrano, L. Proteins: Struct. Funct. Genet. 1994, 20, 301.
(b) Minor, D. L.; Kim, P. S. Nature 1994, 371, 264.
(13) Fooks, H. M.; Martin, A. C. R.; Woolfson, D. N.; Sessions, R. B.;
Hutchinson, E. G. J. Mol. Biol. 2006, 356, 32.
(14) (a) COSY: Aue, W. P.; Bartholdi, E.; Ernst, R. R. J. Chem. Phys. 1976,
64, 2229. (b) TOCSY: Bax, A.; Davis, D. G. J. Magn. Reson. 1985, 65,
355(c) ROESY: Bothner-by, A. A.; Stephens, R. L.; Lee, J. M.; Warren,
C. D.; Jeanloz, R. W. J. Am. Chem. Soc. 1984, 106, 811.
(15) (a) Cohen, Y.; Avram, L.; Frish, L. Angew. Chem., Int. Ed. 2005, 44, 520.
(b) Dehner, A.; Kessler, H. ChemBioChem 2005, 6, 1550. (c) Altieri, A. S.;
Hinton, D. P.; Byrd, R. A. J. Am. Chem. Soc. 1995, 117, 7561.
(16) (a) Wu¨thrich, K. NMR of Proteins and Nucleic Acids; Wiley: New York,
1986. (b) Dyson, H. J.; Wright, P. E. Annu. ReV. Biophys. Biophys. Chem.
1991, 20, 519.
(17) Syud, F. A.; Stanger, H. E.; Gellman, S. H. J. Am. Chem. Soc. 2001, 123,
8667.
(18) Chothia, C. J. Mol. Biol. 1973, 75, 295.
(19) Bru¨ngerm, A. T.; Adams, P. D.; Clore, G. M.; DeLano, W. L.; Gros, P.;
Grosse-Kunstleve, R. W.; Jiang, J. S.; Kuszewski, J.; Nilges, M.; Pannu,
N. S.; Read, R. J.; Rice, L. M.; Simonson, T.; Warren, G. L. Acta
Cristallogr., Sect. D 1998, D54, 905.
JA802042C
9
J. AM. CHEM. SOC. VOL. 130, NO. 25, 2008 7841
