1024
A. K. Ghosh et al. / Tetrahedron: Asymmetry 19 (2008) 1020–1026
23
2.60 (m, 1H), 3.09 (d, J = 10 Hz, minor), 3.18 (d,
J = 10 Hz, 1H), 3.26 (s, 3H), 3.27 (s, minor), 3.41–3.49
(m, 3H), 4.05–4.29 (m, 3H), 5.04–5.11 (m, 3H), 5.33 (t,
J = 7.5 Hz, minor), 5.45 (t, J = 7 Hz, 1H), 5.65–5.79 (m,
1H), 6.17 (dd, J = 16, 10 Hz, 1H), 6.25 (dd, J = 16,
10 Hz, minor), 6.48 (d, J = 16 Hz, 1H), 7.13–7.19 (m,
2H), 7.34 (t, J = 7.5 Hz, 3H), 7.69 (d, J = 7.5 Hz, 2H);
13C NMR (100 MHz, CDCl3): d 13.9 (major), 21.0 (minor),
21.1 (major), 21.2 (major), 31.8 (minor), 32.1 (major), 37.9
(major), 38.0 (minor), 50.2 (major), 50.7 (minor), 58.4
(minor), 58.5 (major), 61.1 (minor), 61.3 (major), 67.7 (ma-
jor), 67.9 (minor), 70.4 (major), 70.7 (minor), 82.3 (major),
82.6 (minor), 118.0 (major), 118.1 (minor), 126.3 (minor),
126.4 (major), 127.5 (minor), 127.7 (major), 128.5 (major),
133.2 (minor), 133.4 (major), 135.7 (minor), 136.0 (major),
136.8 (major), 137.1 (minor), 169.6 (major), 169.7 (minor),
169.8 (major), 169.9 (major), 170.0 (minor); FT-IR (film,
NaCl) 2361, 1742 1370, 972 cmꢀ1. HRMS (CI) [M+Na]+
calcd for C24H32O7Na 455.2046, found 455.2050.
Compound 7c: ½aꢁD ¼ ꢀ5:5 ðc 1; CHCl3Þ; 1H NMR
(500 MHz, CDCl3): d 1.30 (t, J = 7 Hz, 3H), 2.04 (s, 3H),
2.09 (s, 3H), 2.31–2.37 (m, 2H), 2.43–2.47 (m, 1H), 2.65–
2.71 (m, 1H), 3.32 (s, 3H), 3.49–3.54 (m, 2H), 3.80 (br s,
1H), 4.14–4.28 (m, 2H), 5.56 (t, J = 7 Hz, 1H), 5.81–5.87
(m, 1H), 5.99–6.04 (m, 1H); 13C NMR (125 MHz, CDCl3)
d 13.9, 21.1, 21.2, 33.2, 40.1, 53.7, 58.6, 61.4, 74.0, 81.8,
128.3, 130.4, 170.2, 170.4, 170.5; FT-IR (film, NaCl)
1738, 1371, 1233 cmꢀ1. HRMS (CI) [M+H]+ calcd for
C16H25O7 329.1600, found 329.1603.
4.1.8. (3S,3aS,6aR)-3-(2-Methoxyethyl)-2-oxo-3,3a,6,6a-
tetrahydro-2H-cyclopenta[b]furan-3-yl acetate 8b. To a
stirred solution of 6b (90 mg, 0.27 mmol) in a mixture
(3:1:1) of THF/EtOH/H2O (3 mL) at 0 °C was added solid
LiOH (35 mg, 0.82 mmol) and the mixture was stirred for
6 h at 23 °C. After this period, the solvent was evaporated
and aqueous layer was then acidified with 1 M HCl to pH 3
and extracted with EtOAc (3ꢂ). The combined organic
layer was dried over Na2SO4 and concentrated under re-
duced pressure and purified by flash column chromatogra-
phy on silica gel to provide the lactone (34 mg, 64% yield)
as colorless oil.
4.1.6. (R)-Ethyl 2-acetoxy-2-((1S,5R)-5-acetoxycyclopent-2-
enyl)propanoate 7a. To a stirring solution of 6a (230 mg,
0.59 mmol) in CH2Cl2 (120 mL) was added a second gener-
ation Grubbs catalyst (15 mg, 0.018 mmol) under argon.
The reaction was allowed to stir at 23 °C for 4 h. After this
period the reaction mixture was concentrated under re-
duced pressure and purified by flash column chromatogra-
phy on silica gel to afford cyclopentene 6a (147 mg, 88%
To the above lactone (34 mg, 0.17 mmol) in dry CH2Cl2
(3 mL) at 0 °C were added DMAP (103 mg, 0.84 mmol)
and acetic anhydride (160 lL, 1.7 mmol). The resulting
solution was stirred at 23 °C for 12 h. After this time the
reaction mixture was diluted with CH2Cl2 and washed with
1 N HCl, water, and brine. The organic layer was concen-
trated under reduced pressure and the residue purified by
column chromatography on silica gel to provide 8b
yield) as a colorless oil, Rf = 0.4 (20% EtOAc in hexanes),
23
½aꢁD ¼ ꢀ3:5 ðc 1; CHCl3Þ; 1H NMR (500 MHz, CDCl3): d
1.28 (t, J = 7 Hz, 3H), 1.69 (s, 3H), 2.03 (s, 3H), 2.07 (s,
3H), 2.23–2.37 (m, 1H), 2.69–2.74 (m, 1H), 3.40–3.42 (m,
1H), 4.14–4.22 (m, 2H), 5.51 (dt, J = 6.5, 3 Hz 1H), 5.38
(t, J = 5 Hz, 1H), 5.76–5.88 (m, 1H), 6.24 (dd, J = 16,
10 Hz, 1H), 6.46 (d, J = 16 Hz, 1H), 7.26–7.30 (m, 1H),
7.35 (t, J = 7 Hz, 2H), 7.43 (d, J = 8.5 Hz, 2H); 13C
NMR (125 MHz, CDCl3) d 13.9, 20.8, 21.2, 21.3, 37.9,
52.7, 61.4, 70.3, 81.8, 118.5, 122.7, 126.4, 127.7, 128.6,
133.1, 135.7, 136.6, 169.7, 169.9, 170.6; FT-IR (film, NaCl),
2981, 1742, 1642 cmꢀ1. HRMS (ESI) [M+Na]+ calcd for
C14H20O6Na 307.1158, found 307.1155.
1
(37 mg, 92% yield) as colorless oil. H NMR (500 MHz,
CDCl3): d 2.07–2.11 (m, 2H), 2.13 (s, 3H), 2.66 (d,
J = 18 Hz, 1H), 2.73–2.79 (m, 1H), 3.36 (s, 3H), 3.51–
3.54 (m, 1H), 3.67–3.75 (m, 2H), 5.35 (t, J = 6.7 Hz, 1H),
5.76–5.79 (m, 1H), 5.84–5.88 (m, 1H); 13C NMR
(125 MHz, CDCl3) d 20.7, 34.3, 38.7, 56.5, 58.8, 67.3,
79.6, 81.4, 127.1, 131.8, 174.2.
4.1.9. (3S,3aS,6aR)-3-(2-Methoxyethyl)-2-oxo-3,3a,6,6a-
tetrahydro-2H-cyclopenta[b]furan-3-yl acetate 8c. The
procedure described for 8b was used for 8c. Accordingly,
cyclopentene 7c (25 mg, 0.08 mmol), and LiOH (10 mg,
0.23 mmol) afforded lactone (13 mg, 85% yield) as colorless
oil. The above lactone (12 mg, 0.06 mmol), DMAP (37 mg,
0.30 mmol), and acetic anhydride (57 lL, 0.6 mmol) in
CH2Cl2 (2 mL) afforded 8c (11 mg, 70% yield) as a color-
less oil. 1H NMR (500 MHz, CDCl3): d 2.16 (s, 3H),
2.23–2.28 (m, 1H), 2.58–2.64 (m, 1H), 2.78–2.79 (m, 2H),
3.34 (s, 3H), 3.52–3.57 (m, 1H), 3.62–3.66 (m, 1H), 3.95–
3.97 (m, 1H), 5.06–5.09 (m, 1H), 5.40–5.42 (m, 1H),
5.86–5.88 (m, 1H); 13C NMR (125 MHz, CDCl3) d 21.2,
35.2, 40.0, 56.1, 58.7, 67.3, 80.3, 81.8, 126.7, 131.8, 169.8,
173.3.
4.1.7. (R)-Ethyl-2-acetoxy-2-((1S,5R)-5-cetoxycyclopent-2-
enyl)-4-methoxybutanoate 7b. The procedure described
for 7a was used for 7b. Accordingly, styrene 6b (210 mg,
0.16 mmol), second generation Grubbs catalyst (12 mg,
0.015 mmol) in CH2Cl2 (30 mL) afforded cyclopentenes
7b (92 mg, 58%) and 7c (25 mg, 16%).
23
Compound 7b: ½aꢁD ¼ ꢀ3:2 ðc 1; CHCl3Þ; 1H NMR
(500 MHz, CDCl3): d 1.30 (t, J = 7 Hz, 3H), 2.02 (s, 3H),
2.10 (s, 3H), 2.52 (dt, J = 14.8, 6.5 Hz, 1H), 2.60 (dt,
J = 14.8, 6.5 Hz, 1H), 2.65–2.71 (m, 1H), 3.30 (s, 3H),
3.47–3.54 (m, 2H), 3.78–3.80 (m, 1H), 4.16–4.26 (m, 2H),
5.56 (dt, J = 6.5, 1.7 Hz, 1H), 5.82–5.85 (m, 1H), 5.87–
5.93 (m, 1H); 13C NMR (125 MHz, CDCl3) d 14.0, 21.0,
21.5, 34.2, 39.9, 54.5, 61.4, 68.1, 73.0, 82.7, 128.8, 129.5,
169.9, 170.1, 170.4; FT-IR (film, NaCl) 1739, 1370,
1236 cmꢀ1. HRMS (CI) [M+H]+ calcd for C16H25O7
329.1600, found 329.1607.
4.1.10. (R)-Ethyl2-((2R,3R,5R)-2-allyl-tetrahydro-5-phenyl-
furan-3-yl)-2-(tosylamino)acetate (10). To a mixture of
freshly distilled a-N-tosyl imino ester 9 (255 mg, 1 mmol)
and (R)-2,3-dihydro-2-phenylfuran 1 (175 mg, 1.2 mmol)
in dry CH2Cl2 (10 mL) at ꢀ78 °C was added a solution
of TiCl4 (1.0 M in CH2Cl2, 1.1 mmol) and the resulting
