FULL PAPER
Synthesis and Conformational Analysis of Saturated
3,1,2-Benzoxazaphosphinine 2-Oxides
Henri Kivelä,[a] Zita Zalán,[a,b] Petri Tähtinen,[a] Reijo Sillanpää,[c] Ferenc Fülöp,*[b] and
Kalevi Pihlaja*[a]
Keywords: Phosphorus heterocycles / Fused-ring systems / Structure elucidation / Configuration determination / Confor-
mation analysis
N-Unsubstituted, N-methyl and N-benzyl cis- and trans-2-
(hydroxymethyl)cyclohexylamines were subjected to ring
closure with phenylphosphonic dichloride, phenyl dichlo-
rophosphate and bis(2-chloroethyl)phosphoramidic dichlo-
ride in order to synthesize P-epimeric diastereomers of the
corresponding unsubsituted and N-substituted 2-phenyl-, 2-
phenoxy- and 2-[bis(2-chloroethyl)amino]octahydro-2H-
3,1,2-benzoxazaphosphinine 2-oxides. The stereochemistry
and conformations of the prepared compounds were ana-
lyzed mainly by variable-temperature1H, 13C and 31P NMR
spectroscopy. Geometry optimizations were performed for
some trans-fused molecules by utilizing the B3LYP DFT
ling constant calculations at the UB3LYP/cc-pVTZ level of
theory. The population of the N-out conformation of the cis-
fused compounds was found to increase with increasing ste-
ric size of the N substituent (H Ͻ Me Ͻ CH2Ph), and also to
be strongly influenced by the configuration at the phospho-
rus atom. The heteroring of the trans-fused compounds pre-
dominantly adopts a chair conformation with the notable ex-
ception of the (2R*,4aS*,8aS*) epimers of the 2-phenoxy-
substituted compounds, for which the axial tendency of OPh
causes the heteroring to adopt mainly B2,4a- and/or 1S4a-type
nonchair conformations.
(© Wiley-VCH Verlag GmbH & Co. KGaA, 69451 Weinheim,
method and a locally dense basis set, followed by JH,P coup- Germany, 2005)
ane moiety have recently been reported to possess matrix
Introduction
metalloproteinase-inhibitory[5] and pesticide activities.[6]
Conformational analyses of monocyclic 1,3,2-oxazaphos-
phinanes have revealed numerous interesting details con-
cerning the conformational properties of the heteroring.[7]
However, the synthesis and conformations of cycloalkane-
condensed 1,3,2-oxazaphosphinanes have been studied less
extensively. Their conformational behavior may differ from
that of cycloalkane-fused 1,3-heterocycles which often
adopt a biased chair–chair conformation in trans-fused de-
rivatives and two interconvertible chair–chair conforma-
tions in the cis isomers.[8] As with bicyclic heterocycles,[8]
the orientation of the substituents in the 2-position, and
also the substituent on the nitrogen atom when it is next to
the ring annulation position, liekly has a significant influ-
ence on the conformers that predominate.
Conformational analyses of various 2-aryloxy- and 2-
bis(2-chloroethyl)amino-substituted cis- and trans-perhy-
dro-1,3,2-benzoxazaphosphinine 2-oxides have revealed
that the heteroring in these compounds can exist not only
in a chair, but also in some unusual skew conforma-
tions.[9,10] The chair/skew and O-in/O-out conformational
equilibria in these compounds are strongly influenced by
the nature of the ring’s N substituent.[10]
The synthesis and transformations of 1,3,2-oxazaphos-
phinane 2-oxide derivatives have been thoroughly studied
in recent decades as a consequence of their potential wide-
ranging synthetic applications and the therapeutic impor-
tance of this type of compounds. Alkylation and condensa-
tion reactions of P-benzyl-1,3,2-oxazaphosphinane 2-oxides
and nucleophilic addition to vinylphosphonate derivatives
that contain a 1,3,2-oxazaphosphinane ring are effective
methods for the stereoselective formation of single carbon–
carbon bonds.[1,2]
The 1,3,2-oxazaphosphinane ring system is found in al-
kylating anticancer drugs (e.g. cyclophosphamide and ifos-
famide),[3] numerous derivatives of which have been synthe-
sized in order to determine their structure–activity relation-
ships.[4] Compounds that contain the 1,3,2-oxazaphosphin-
[a] Department of Chemistry, University of Turku,
20014 Turku, Finland
Fax: +358-2-333-6750
E-mail: kpihlaja@utu.fi
[b] Institute of Pharmaceutical Chemistry, University of Szeged,
P. O. Box 121, 6701 Szeged, Hungary
E-mail: fulop@pharma.szote.u-szeged.hu
[c] Department of Chemistry, University of Jyväskylä,
P. O. Box 35, 40351 Jyväskylä, Finland
E-mail: resillan@jyu.fi
Of the regioisomeric cis- and trans-perhydro-3,1,2-benz-
oxazaphosphinine 2-oxides, only the 1-benzyl-2-phenyl-sub-
stituted derivatives have been reported in the literature,[11]
Supporting information for this article is available on the
WWW under http://www.eurjoc.org or from the author.
Eur. J. Org. Chem. 2005, 1189–1200
DOI: 10.1002/ejoc.200400611
© 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1189

H. Kivelä, Z. Zalán, P. Tähtinen, R. Sillanpää, F. Fülöp, K. Pihlaja
FULL PAPER
and their solution-state conformations have not been ana- prepared in order to allow a comparison of the conforma-
lyzed. As a continuation of our previous studies on cycloal- tional effects of the different N substituents.
kane-condensed 1,3,2-oxazaphosphinane 2-oxides,[10] the
effect of P and N substituents on the stereochemistry of
ring-closure reactions and the conformations of the title
compounds are discussed in this paper.
Characterization of Structures
The structures formed in the cyclization reactions were
characterized by solution-state multinuclear (1H, 13C and
31P) NMR methods and were supported by DFT calcula-
tions on compounds 8, 10, 14 and 16 and the X-ray crystal
structure determined for 16a. The 1H and 13C chemical
shifts were assigned with the aid of 1D NOESY or NOE
Results and Discussion
Synthesis
The amino alcohols 1–6 were prepared according to the difference and 2D homonuclear (dqf-COSY) and heteronu-
procedures described in the literature.[12] Compounds 1–6 clear (HETCOR, COLOC) correlation experiments. The
were cyclized with phenylphosphonic dichloride, phenyl proton chemical shifts and coupling constants were deter-
dichlorophosphate and bis(2-chloroethyl)phosphoramidic mined by an iterative analysis with PERCH NMR soft-
1
dichloride at ambient temperatures by using a procedure ware.[13] For the cis-fused compounds, the H spin systems
similar to that described earlier[10a] to give 1,4,4a,5,6,7,8,8a- could be solved completely, whereas the fine structure of
octahydro-2H-3,1,2-benzoxazaphosphinine 2-oxides 7–20 the -(CH2)4- proton resonances of the trans-fused com-
(Scheme 1 and Scheme 2). In most cases, two diastereomers pounds was often poorly reproduced by the simulations be-
(a and b), which differ in their configuration at the phos- cause of the difficulties arising from overlapping signals and
phorus atom, were formed and were separated by column the complexity of the coupling network. Comprehensive
chromatography. The ring-closure reactions of amino NMR data are presented in the Supporting Information.
alcohols 1 and 4 with phenylphosphonic dichloride pro-
In the configurational and conformational analysis of
ceeded with complete diastereoselectivity to give compound certain 1,3,2-benzoxaza- and -dioxaphosphinine derivatives
7a and 10b, respectively, as single diastereomers; no traces it has been possible to use the 31P chemical shifts.[9,10] How-
of the corresponding P epimers (7b or 10a) were detected, ever, for the 2-Ph- and 2-OPh-substituted compounds
even in the crude products. Compound 20 was obtained as studied here, the differences in δP between epimers were al-
a 45:55 mixture of 20a and 20b. The known 1-benzyl-2- ways less than 3 ppm. Only in case of the 2-N(CH2CH2Cl)2
phenyl-substituted derivatives 11a,b and 12a,b[11] were also derivatives were distinctive ∆δP values found; epimers with
Scheme 1. Reagents: (i) Cl2POPh/Et3N in THF, column chromatography, 8–45%; (ii) Cl2PO(OPh)/Et3N in THF, column chromatography,
14–37%; (iii) Cl2PO[N(CH2CH2Cl)2]/Et3N in THF, column chromatography, 30–35%. R = H: 1, 7, 13; R = Me: 3, 9, 15; R = CH2Ph:
5, 11, 17.
1190
© 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.eurjoc.org
Eur. J. Org. Chem. 2005, 1189–1200

Saturated 3,1,2-Benzoxazaphosphinine 2-Oxides
FULL PAPER
Scheme 2. Reagents: (i) Cl2POPh/Et3N in THF, column chromatography, 10–37%; (ii) Cl2PO(OPh)/Et3N in THF, column chromatog-
raphy, 16–42%; (iii) Cl2PO[N(CH2CH2Cl)2]/Et3N in THF, column chromatography, 63%. R = H: 2, 8, 14; R = Me: 4, 10, 16; R =
CH2Ph: 6, 12, 18.
1
Table 1. Selected H NMR chemical shifts [ppm] of the trans-fused compounds.[a]
Proton
8a
8b
10b
12a
12b
14a
14b
16a
16b
18a
18b
20a[b]
20b[b]
4-Hax
4-Heq
4a-H
8a-H
4.22
4.08
1.78
3.27
3.64
4.17
1.76
2.71
3.79
4.07
2.03
3.00
4.12
4.04
1.87
2.85
3.81
4.15
2.04
3.14
4.07
4.22
1.85
3.10
4.07
4.20
1.71
2.99
4.06
4.13
2.04
2.77
4.03
4.09
1.90
2.90
3.93
4.11
2.24
2.66
4.08
4.12
1.90
3.18
3.87
3.97
1.43
2.90
3.77
4.03
1.51
2.74
