Cyclometalated Platinum(II) Complexes of Pyrazole-Based,
N∧C∧N-Coordinating, Terdentate Ligands: the Contrasting Influence of
Pyrazolyl and Pyridyl Rings on Luminescence
Ste´phanie Develay, Octavia Blackburn, Amber L. Thompson, and J. A. Gareth Williams*
Department of Chemistry, UniVersity of Durham, Durham, DH1 3LE, U.K.
Received July 29, 2008
1,3-Bis(1-pyrazolyl)-5-methyl-benzene, HL2, undergoes cyclometalation at the C2 position upon reaction with K2PtCl4,
to generate an N∧C∧N-coordinated complex, PtL2Cl. This compound is luminescent in degassed solution at 298 K,
emitting in the blue region of the spectrum on the microsecond time scale (λmax ) 453 nm, τ ) 4.0 µs, Φlum
)
0.02, in CH2Cl2). Compared to the analogous complex Pt(dpyb)Cl that incorporates pyridyl rather than pyrazole
rings {dpybH ) 1,3-di(2-pyridyl)-benzene}, the excited state is displaced to higher energy by 1700 cm-1. This
effect is rationalized in terms of the poorer π-acceptor nature of pyrazolyl compared to pyridyl rings, leading to
destabilization of the lowest unoccupied molecular orbital, which is largely localized on the heteroaromatic rings in
both cases. Cyclic voltammetry and density functional theory calculations reinforce this interpretation, and suggest
that the lowest-energy excited state is probably best described as heavily mixed πL/dPt/pCl f π*L (IL/MLCT/LLCT)
in character. 5-Aryl-substituted analogues of HL2 are accessible in three steps from 1,3,5-tribromobenzene by
Pd-catalyzed cross-coupling with aryl boronic acids, followed by copper-catalyzed bromo-iodo exchange, and
subsequent amination with pyrazole under relatively mild conditions also catalyzed by copper. The corresponding
Pt(II) complexes display red-shifted and more intense luminescence compared to PtL2Cl. Ligands incorporating
one pyrazole and one pyridyl ring are also accessible; for example, 1-(1-pyrazolyl)-3-(2-pyridyl)benzene, HL6. Their
complexes are highly luminescent in solution; for example, for PtL6Cl, λmax ) 487 nm, τ ) 6.9 µs, Φlum ) 0.55,
in dilute solution in CH2Cl2. At elevated concentrations, PtL6Cl displays an additional excimeric emission band that
is substantially blue-shifted compared to that displayed by Pt(dpyb)Cl (bands centered at 645 and 695 nm,
respectively), indicating that the presence of the pyrazole ring destabilizes the excimer. The introduction of a
methyl substituent into the central aryl ring of such complexes is sufficient to eliminate the excimer emission.
Introduction
thermally accessible to the emissive state. It is the thermally
activated population of such distorted states that accounts
for the lack of room temperature emission in simple
complexes like Pt(bpy)Cl2 and [Pt(tpy)Cl]+.1,2 The key to
raising the energy of the d-d states is to introduce strong-
field ligands or co-ligands. For example, a wide range of
luminescent complexes have been obtained by using acetylide
co-ligands in complexes of the general type Pt(N∧N)-
(sCtCR)2 and [Pt(N∧N∧N)(sCtCR)]+ (where N∧N and
N∧N∧N represent di- and tri-imine ligands such as bipyridine
and terpyridine),1d,e,3 while cyclometalating ligands such as
2-phenylpyridine and 6-phenyl-2,2′-bipyridine have a ben-
eficial effect on luminescence quantum yields compared to
Over the past 15 years, several families of platinum(II)
complexes have been developed that display photolumines-
cence in solution at room temperature.1 A strategy for
promoting emission over non-radiative decay has emerged,
namely to ensure that d-d excited states involving the
2
2
population of the strongly antibonding dx -y orbital are not
* To whom correspondence should be addressed. E-mail: j.a.g.williams@
durham.ac.uk.
(1) For recent reviews, see for example: (a) McMillin, D. R.; Moore, J. J.
Coord. Chem. ReV. 2002, 229, 113. (b) Lai, S. W.; Che, C. M. Top.
Curr. Chem. 2004, 241, 27. (c) Ma, B.; Djurovich, P.; Thompson,
M. E. Coord. Chem. ReV. 2005, 249, 1501. (d) Castellano, F. N.;
Pomestchenko, I. E.; Shikhova, E.; Hua, F.; Muro, M. L.; Rajapakse,
N. Coord. Chem. ReV., 2006, 250, 1819. (e) Wong, K. M. C.; Yam,
V. W. W. Coord. Chem. ReV. 2007, 251, 2477. (f) Williams, J. A. G.
Top. Curr. Chem. 2007, 281, 205.
(2) Barigelletti, F.; Sandrini, D.; Maestri, M.; Balzani, V.; von Zelewsky,
A.; Chasot, L.; Jolliet, P.; Maeder, U. Inorg. Chem. 1988, 27, 3644.
10.1021/ic8014157 CCC: $40.75  2008 American Chemical Society
Inorganic Chemistry, Vol. 47, No. 23, 2008 11129
Published on Web 11/01/2008

Develay et al.
Scheme 1. Generic Structures of the Pyrazole-Containing Complexes
(II and III) and Those Based on 1,3-Dipyridylbenzene (I)
complexes with their non-cyclometalated cousins bpy and
tpy.4,5 Potential applications range from chromophores for
promoting photoinduced charge separation for artifical pho-
tosynthesis,6 to triplet emitters in organic light-emitting
devices (OLEDs).7,8
Among metal complexes, a feature essentially unique to
square planar d8 systems is their coordinative unsaturation,
which allows them to engage in intermolecular interactions
that involve either metal orbitals orthogonal to the plane of
the molecule or overlap of cofacial ligand orbitals. Such
interactions include the formation of excimers, which may
themselves be emissive. If the excimer and monomer
emissions between them span the bulk of the visible
spectrum, this effect can provide a means of obtaining single-
dopant white-light OLEDs.7a,d,8
We have been exploring the chemistry and applications
of a family of brightly emissive cyclometalated platinum(II)
compounds incorporating N∧C∧N-coordinating terdentate
ligands based on 1,3-di(2-pyridyl)benzene (dpybH) (Scheme
1, generic structure I). As previously reported in this journal,
these complexes emit from triplet states with high lumines-
cence quantum yields, {e.g., for R ) H, Φlum ) 0.6},9 and
they function efficiently in OLEDs.10 The emission wave-
length is tunable over a wide range by varying the substituent
R, without compromising the quantum yield (λmax from 481
nm for R ) CO2Me to 588 nm for -C6H4-NMe2 in CH2Cl2
solution).11 At elevated concentrations in solution, the
complexes form excimers that emit with unusually high
efficiency at around 700 nm (Φlum ∼ 0.3). Neat thin films
display emission uniquely in this region, leading to high-
performance near-IR OLEDs,12 while the combination of
monomer and excimer emission when doped at appropriate
concentrations in polymer matrixes has led to particularly
efficient white-light emitting devices.13 In this contribution,
we describe our studies into the synthesis and luminescence
properties of a family of compounds, structurally related to
Pt(dpyb)Cl, but comprising either one or two pyrazoles (pyz)
in place of the pyridine (py) rings (Scheme 1, generic
structure II). Given the poorer π-acceptor nature of the
pyrazole compared to pyridine ring, we reasoned that the
lowest unoccupied molecular orbital (LUMO) energy in such
complexes would be raised relative to that in complexes of
type-I structure, potentially offering a route to triplet emission
in the challenging blue region of the spectrum. We also
sought to determine how the switch from py to pyz rings
would affect intermolecular interactions, particularly excimer
formation. The influence of aryl substituents at position R
is considered, and asymmetric systems incorporating one pyz
and one py ring (Scheme 1, generic structure III) have been
explored.
