Social Self-Sorting: Alternating Supramolecular Oligomer
Consisting of Isomers
Naoki Tomimasu, Akira Kanaya, Yoshinori Takashima, Hiroyasu Yamaguchi, and
Akira Harada*
Department of Macromolecular Science, Graduate School of Science, Osaka UniVersity,
Toyonaka, Osaka 560-0043, Japan
Received May 21, 2009; E-mail: harada@chem.sci.osaka-u.ac.jp
Abstract: The isomers of cinnamoyl R-CDs (2-CiO-R-CD and 3-CiO-R-CD) organize by themselves to give
different types of supramolecular complexes in aqueous solutions. 2-CiO-R-CD was found to form a double-
threaded dimer, which was characterized by single crystal X-ray analysis. The molecular sizes of
supramolecular complexes consisting of CiO-R-CDs were estimated by pulsed field gradient spin-echo
NMR, which gives the diffusion coefficient (D). D of 2-CiO-R-CD was found to be 2.3 × 10-10 m2/s at
concentrations over 10 mM and D was saturated. It should be noted that the hydrodynamic radius derived
from D of 2-CiO-R-CD was found to be 9.6 Å, which closely matched the result from the single crystal
X-ray analysis. D of 3-CiO-R-CD, however, was smaller than that of 2-CiO-R-CD at concentrations over 32
mM, indicating that 3-CiO-R-CD formed a supramolecular oligomer. Two-dimensional (2D)-ROESY spectra
of the mixture of 2-CiO-R-CD and 3-CiO-R-CD did not show a correlation between the same species; rather,
correlation peaks between 2-CiO-R-CD and 3-CiO-R-CD were observed. D’s of a mixture of 2-CiO-R-CD
and 3-CiO-R-CD were found to be larger than those of 2-CiO-R-CD and 3-CiO-R-CD, respectively, indicating
that the mixture of 2-CiO-R-CD and 3-CiO-R-CD formed an alternative supramolecular oligomer and not a
self- or random- supramolecular complex. CDs recognize a guest molecule and the substitutional position
of a guest molecule on CD, suggesting that CDs have social self-sorting capability.
coordination bonds,8-17 solvophobic effects,18,19 dynamic co-
valent bonds.20-22 In recent years, supramolecular assemblies23-26
Introduction
Biological materials, such as microtubules1 and hemoglobin,2
are composed of two kinds of building blocks. These molecules
exhibit a high affinity for one another and, hence, are referred
to as social self-sorting.3 Notable self-sorting systems have been
constructed on the basis of the formation of hydrogen bonds,7
and supramolecular polymers27-29 from enantiomers were
designed by researchers. In many cases, the mixture of isomers
led to formation of homosupramolecular assemblies and su-
pramolecular polymers, indicating that in the process of narcis-
sistic self-sorting,30 molecules that show a high affinity for
(1) (a) Amos, L. A.; Baker, T. S. Nature 1979, 279, 607–612. (b) Luduena,
R. F. Mol. Bol. Cell 1993, 4, 445–457. (c) Sullivan, K. F. Annu. ReV.
Cell Biol. 1988, 4, 687–716. (d) Wade, R. H.; Chretien, D. J. Struct.
Biol 1993, 110, 1–27.
(8) (a) Kra¨mer, R.; Lehn, J.-M.; Marquis-Rigault, A. Proc. Natl. Acad.
Sci. U.S.A. 1993, 90, 5394–5398. (b) Stiller, R.; Lehn, J.-M. Eur.
J. Inorg. Chem. 1998, 977–982. (c) Nitschke, J. R.; Lehn, J.-M. Proc.
Natl. Acad. Sci. U.S.A. 2003, 100, 11970–11974.
(9) Caulder, D. L.; Raymond, K. N. Angew. Chem., Int. Ed. Engl. 1997,
36, 1440–1442.
(2) (a) Dugas, H.; Penney, C. Hemoglobin and myoglobin in their reactions
with ligands, Antonini, E. Brunori, M. North-Holland, Amsterdam,
1971. (b) Bunn, H. F., Bernard, G. Hemoglobin: molecular, genetic
and clinical aspects, Saunders Philadelphia, PA, 1986.
(10) Enemark, E. J.; Stack, T. D. P. Angew. Chem., Int. Ed. 1998, 37, 932–
935.
(3) (a) Wu, A.; Chakraborty, A.; Fettinger, J. C.; Flowers, R. A.; Isaacs,
L. Angew. Chem., Int. Ed. 2002, 41, 4028–4031. (b) Wu, A.; Isaacs,
L. J. Am. Chem. Soc. 2003, 125, 4831–4835. (c) Liu, S.; Ruspic, C.;
Mukhopadhyay, P.; Chakrabarti, S.; Zavalij, P. Y.; Isaacs, L. J. Am.
Chem. Soc. 2005, 127, 15959–15967. (d) Mukhopadhyay, P.; Zavalij,
P. Y.; Isaacs, L. J. Am. Chem. Soc. 2006, 128, 14093–14102.
(4) (a) Jolliffe, K. A.; Timmerman, P.; Reinhoudt, D. N. Angew. Chem.,
Int. Ed. 1999, 38, 933–937. (b) Prins, L. J.; Huskens, J.; de Jong, F.;
Timmerman, P.; Reinhoudt, D. N. Nature 1999, 398, 498–502.
(5) (a) Shi, X.; Fettinger, J. C.; Cai, M.; Davis, J. T. Angew. Chem., Int.
Ed. 2000, 39, 3124–3127. (b) Shi, X.; Fettinger, J. C.; Davis, J. T.
J. Am. Chem. Soc. 2001, 123, 6738–6739. (c) Cai, M.; Shi, X.; Sidorov,
V.; Fabris, D.; Lam, Y.-F.; Davis, J. T. Tetrahedron 2002, 58, 661–
671.
(11) Crego Calama, M.; Timmerman, P.; Reinhoudt, D. N. Angew. Chem.,
Int. Ed. 2000, 39, 755.
(12) Marguly, E.; McDonald, R.; Branda, N. R. Org. Lett. 2000, 2, 3169–
3172.
(13) Albrecht, M.; Schneider, M.; Ro¨ttele, H. Angew. Chem., Int. Ed. 1999,
38, 557–559.
(14) Kondo, T.; Oyama, K.-I.; Yoshida, K. Angew. Chem., Int. Ed. 2001,
40, 894–897.
(15) Bilgicu¨er, B.; Xing, X.; Kumar, K. J. Am. Chem. Soc. 2001, 123,
11815–11816.
(16) Saur, B.; Scopelliti, R.; Severin, K. Chem.sEur. J. 2006, 12, 1058–
1066.
(17) (a) Yang, H. B.; Ghosh, K.; Northrop, B. H.; Stang, P. J. Org. Lett.
2007, 9, 1561–1564. (b) Zheng, Y.-R.; Yang, H. B.; Northrop, B. H.;
Ghosh, K.; Stang, P. J. Inorg. Chem. 2008, 47, 4706–4711.
(18) Legrand, Y. M.; Van der Lee, A.; Barboiu, M. Inorg. Chem. 2007,
46, 9540–9547.
(6) (a) Corbin, P. S.; Lawless, L. J.; Li, Z.; Ma, Y.; Witmer, M. J.;
Zimmerman, S. C. Proc. Natl. Acad. Sci. U.S.A. 2002, 99, 5099–5104.
(b) Ma, Y.; Kolotuchin, S. V.; Zimmerman, S. C. J. Am. Chem. Soc.
2002, 124, 13757–13769.
(7) Barrett, E. S.; Dale, T. J.; Rebek, J. J. Am. Chem. Soc. 2008, 130,
2344–2350.
(19) Corbett, P. T.; Leclaire, J.; Vial, L.; West, K. R.; Wietor, J.-L.; Sanders,
J. K. M.; Otto, S. Chem. ReV. 2006, 106, 3652–3711.
9
10.1021/ja903988c CCC: $40.75  2009 American Chemical Society
J. AM. CHEM. SOC. 2009, 131, 12339–12343 12339

A R T I C L E S
Tomimasu et al.
themselves operate in these systems. Social self-sorting is
comparatively rare in supramolecular assemblies31-33 because
two hetero units often form a thermodynamically unfavorable
structure to assemble to a less compact structure. Therefore,
although there have been reports on the preparation of supramo-
lecular alternating copolymers,34-42 two heterochiral units make
(20) (a) Rowan, S. J.; Sanders, J. K. M. J. Org. Chem. 1998, 63, 1536–
1546. (b) Rowan, S. J.; Hamilton, D. G.; Brady, P. A.; Sanders,
J. K. M. J. Am. Chem. Soc. 1997, 119, 2578–2579. Rowan, S. J.;
Reynolds, D. J.; Sanders, J. K. M. J. Org. Chem. 1999, 64, 5804–
5814.
(21) Jeon, W. S.; Moon, K.; Park, S. H.; Chun, H.; Ko, Y. H.; Lee, J. Y.;
Lee, E. S.; Samal, S.; Selvapalam, N.; Rekharsky, M. V.; Sindelar,
V.; Sobransingh, D.; Inoue, Y.; Kaifer, A. E.; Kim, K. J. Am. Chem.
Soc. 2005, 127, 12984–12989.
Figure 1. Structures of 2-CiO-R-CD and 3-CiO-R-CD.
