An unusual P-P double bond formed via phospha-Wittig transformation of a terminal PO complex

Article abstract of DOI:10.1021/ja903860k

(Chemical Equation Presented) The terminal phosphorus monoxide complex (OP)Mo(N[^tBu]Ar)₃, 1 (Ar = 3,5-Me₂C ₆H₃), undergoes an O-for-PSiR₃ metathesis reaction with the niobium phosphinidene

Full text of DOI:10.1021/ja903860k

Published on Web 06/08/2009
An Unusual P-P Double Bond Formed via Phospha-Wittig Transformation of
a Terminal PO Complex
Nicholas A. Piro and Christopher C. Cummins*
Department of Chemistry, 77 Massachusetts AVenue, Room 6-435, Massachusetts Institute of Technology,
Cambridge, Massachusetts 02139
Received May 12, 2009; E-mail: ccummins@mit.edu
First reported in 1997, (OP)Mo(N[tBu]Ar)3 (1, Ar ) 3,5-
Me2C6H3) is the only example of an isolable terminal phosphorus
monoxide complex.1 As a result, the chemistry of this unique
functional group has remained largely unexplored. Initial reactivity
studies indicated that 1 is electrophilic at phosphorus and nucelo-
philic at oxygen, as illustrated by its reaction with Cp2ZrMe2 to
afford Cp2MeZrOP(Me)Mo(N[tBu]Ar)3.1 Extending this concept,
we speculated that reaction of 1 with a suitable phospha-Wittig
reagent might generate a diphosphenido ligand complexed atop the
molybdenum trisanilide platform. High oxidation state, early metal
phosphinidene complexes have been shown to serve as effective
phospha-Wittig reagents in combination with a variety of reagents
including aldehydes and ketones.2-8 We have recently exploited a
versatile niobium terminal phosphide anion as a precursor to a
variety of phosphinidene complexes,9-11 and the high degree of
oxophilicity possessed by the niobium trisanilide fragment
t
Nb(N[CH2 Bu]Ar)3 represents a formidable driving force for
phosphorus transfer from niobium to main-group acceptors.11,12
i
The silylphosphinidene complex Pr3SiPNb(N[CH2tBu]Ar)3 (2) is
formed by the reaction of iPr3SiOTf (OTf ) trifluoromethanesulfonate)
and the sodium salt of [PNb(N[CH2tBu]Ar)3]-. Complex 2 is isolated
as an orange solid in 61% yield by crystallization from Et2O and
displays a broad 31P NMR resonance at 433 ppm. A single-crystal
X-ray diffraction study revealed a short Nb-P distance of 2.2454(6)
Å and a Nb-P-Si angle of 158.34(4)° (Figure 1B).13 At 22 °C,
complex 2 reacts with the purple phosphorus monoxide complex 1
over the course of several minutes to afford the oxoniobium complex
ONb(N[CH2tBu]Ar)3 (3) and one new species (4), identified by 31P,
1H, and 13C NMR spectroscopies (Figure 1A). The 31P NMR data for
Figure 1. (A) Silyldiphosphenido complex 4 and oxoniobium complex 3
are generated via an O-for-PSiR3 metathesis reaction between 1 and 2. (B
and C) ORTEP representations of complexes 2 and 4, respectively, with
50% probability ellipsoids and selected interatomic distances (Å) and angles
4 are a very broad doublet at 543 ppm and a less broad doublet at 158
ppm with a large P-P coupling constant (1JPP ) 655 Hz). These data
are consistent with the desired silyldiphosphenido product,
iPr3SiPdPMo(N[tBu]Ar)3, where the downfield resonance is attributed
to the phosphorus atom bound directly to the Mo center.14,15 A red-
orange single crystal grown from an Et2O solution of the product
mixture was subjected to an X-ray diffraction study.13 The molecular
structure of the diphosphenido complex (Figure 1C) can be described
as “singly bent” (angles at P of 158.27(3)° and 104.46(3)°) in analogy
to descriptions of diazenido complexes where the diazenido ligand
serves as a 3e- donor.16 The Mo-P (2.1439(5) Å) and P-P (2.0398(7)
Å) distances are both very short, an indication of multiple bonding
across the Mo-P-P π-system. These metrical parameters are in
contrast to the few known diphosphenido complexes,17-19 which are
best described as “doubly bent”, with their metal-phosphorus single
bonds reflected in substantially longer M-P distances. In such
complexes the R phosphorus maintains its lone pair, which has been
shown to engage in chemistry with various electrophilic reagents.19-21
Unlike nitrogen analogues of 4, such as the silyldiazenido
complex Me3SiNNMo(N[tBu]Ar)3 and the azaphosphenido complex
MesNPMo(N[tBu]Ar)3, the diphosphenido complex 4 is not stable
(deg).
in solution for extended periods of time.22,23 Over the course of
hours to days, or upon heating, complex 4 reacts to form
PMo(N[tBu]Ar)3 (5), the cyclic phosphinidene trimer (iPr3SiP)3 (6),
and the phosphinidene tetramer (iPr3Si)2P3P(SiiPr3)2 (7); the latter
two were identified by their 31P NMR spectra which were
successfully simulated (see Supporting Information).23-25 Attempts
to make analogues of 4 bearing smaller silyl groups (Me3Si, Ph3Si)
led to much more rapid formation of the corresponding phosphin-
idene trimers, such that the diphosphenido complexes were not
observed. Also, the generation of terminal phosphide complex 5
was observed to proceed more rapidly in concentrated solutions of
4 than in dilute solutions.26 Together, these observations lead us
to postulate the following mechanism: a bimolecular reaction
between 2 equiv of 4 generates 2 equiv of the terminal phosphide
complex 5 and 1 equiv of Pr3SiPdPSiiPr3 (8); this reactive
diphosphene then consumes a third equivalent of 4 to yield the
cyclic trimer 6; the tetrameric product 7 arises from an insertion
i
9
8764 J. AM. CHEM. SOC. 2009, 131, 8764–8765
10.1021/ja903860k CCC: $40.75  2009 American Chemical Society

C O M M U N I C A T I O N S
Scheme 1a
this sense, the reaction between 4 and PPh3 serves as a model for
the bimolecular reaction that forms diphosphene 8.
Herein we have described a molybdenum diphosphenido complex
arrived at via O-for-PSiR3 metathesis involving a terminal phos-
phorus monoxide ligand. The diphosphenido ligand serves as a 3e-
donor, and its reactivity is distinct from prior examples of 1e- donor
diphosphenido complexes that are nucleophilic at the R phosphorus.
The electronic structure of diphosphenido complex 4 is unusual
and confers upon it the reactivity of a potent phosphinidene source
with terminal phosphide 5 serving as a stable leaving group.
Acknowledgment. We thank the U.S. National Science Foun-
dation for support through Grant CHE-719157 and Thermphos for
a generous donation of funds and supplies.
a 5 ) PMo(N[tBu]Ar)3.
Supporting Information Available: Full experimental details and
spectroscopic data (pdf). Details of X-ray structure determinations (cif).
This material is available free of charge via the Internet at http://
pubs.acs.org.
of the phosphinidene unit of a fourth equivalent of 4 into a P-Si
bond of trimer 6 (Scheme 1).
Having invoked intermediate diphosphene 8, we sought to engage
it in trapping reactions.27 Accordingly, complex 4 was warmed to
60 °C in a THF solution of spiro[2.4]hepta-4,6-diene, and the
product mixture was analyzed by 31P NMR spectroscopy. The [2+4]
cycloaddition product of E-diphosphene capture by the organic
diene, 9, was observed as a pair of doublets in the 31P NMR
spectrum (JPP ) 240 Hz) at -112.5 and -117.5 ppm.28 When 2,3-
dimethylbutadiene was used instead, the then C2-symmetric product,
10, displayed a single 31P resonance at -138 ppm. The observed
formation of 9 and 10 is consistent with the mechanism illustrated
in Scheme 1.
References
(1) Johnson, M. J. A.; Odom, A. L.; Cummins, C. C. Chem. Commun. 1997,
1523–1524.
(2) Cowley, A. H. Acc. Chem. Res. 1997, 30, 445–451.
(3) Cummins, C. C.; Schrock, R. R.; Davis, W. M. Angew. Chem., Int. Ed.
Engl. 1993, 32, 756–759.
(4) Masuda, J. D.; Jantunen, K. C.; Ozerov, O. V.; Noonan, K. J. T.; Gates,
D. P.; Scott, B. L.; Kiplinger, J. L. J. Am. Chem. Soc. 2008, 130, 2408–
2409.
(5) Breen, T. L.; Stephan, D. W. J. Am. Chem. Soc. 1995, 117, 11914–11921.
(6) Basuli, F.; Tomaszewski, J.; Huffman, J. C.; Mindiola, D. J. J. Am. Chem.
Soc. 2003, 125, 10170–10171.
(7) Cossairt, B. M.; Cummins, C. C. Angew. Chem., Int. Ed. 2008, 47, 8863–
8866.
(8) Shah, S.; Protasiewicz, J. D. Coord. Chem. ReV. 2000, 210, 181–201.
(9) Figueroa, J. S.; Cummins, C. C. Angew. Chem., Int. Ed. 2004, 43, 984–
988.
(10) Piro, N. A.; Figueroa, J. S.; McKellar, J. T.; Cummins, C. C. Science 2006,
313, 1276–1279.
(11) Figueroa, J. S.; Cummins, C. C. J. Am. Chem. Soc. 2004, 126, 13916–
13917.
(12) Piro, N. A.; Cummins, C. C. Angew. Chem., Int. Ed. 2008, 48, 934–938.
(13) Full crystallographic data are available in cif files as part of the Supporting
Information, or from the CCDC under deposition numbers 7710581 and
710582. These data can be obtained free of charge from The Cambridge
Crystallographic Data Centre via www.ccdc.cam.ac.uk/data_request/cif.
(14) Chemical shielding calculations on the model complex Me3SiPPMo-
(N[tBu]Ar)3 predict the following 31P NMR chemical shifts: δ(PR) ) 497
ppm, δ(Pꢀ) ) 195 ppm.
To analyze the bonding in 4, we carried out a DFT study on the
slightly truncated complex Me3SiPPMo(N[tBu]Ar)3 (4m) using the
ADF package.29,30 The geometry optimization converged on a
structure similar to that obtained from the X-ray study, with a nearly
linear Mo-P-P angle (163°), a bent P-P-Si angle (106°), and
short Mo-P (2.145 Å) and P-P (2.059 Å) distances. An examina-
tion of the frontier orbitals (Figure S12, Supporting Information)
reveals that the HOMO and HOMO-1 of 4m contain substantial
contributions from the out-of-plane and in-plane p orbitals on the
ꢀ-phosphorus, respectively. The HOMO can be considered as a
back-bond from a reducing, formally d2 metal center to the strongly
π-accepting diphosphenido ligand. Conversely, the HOMO-1 is
(15) Due to similar solubility properties between oxoniobium 3 and diphos-
phenido 4, we have been unable to isolate 4 as a pure substance in quantity.
(16) DuBois, D. L.; Hoffmann, R. NoV. J. Chim. 1977, 1, 479.
(17) Weber, L.; Reizig, K.; Bungardt, D.; Boese, R. Organometallics 1987, 6,
110–114.
(18) Jutzi, P.; Meyer, U. Chem. Ber. 1988, 121, 559–560.
(19) Weber, L.; Kirchhoff, R.; Boese, R.; Stammler, H. G.; Neumann, B.
Organometallics 1993, 12, 731–737.
(20) Weber, L.; Frebel, M.; Boese, R. Angew. Chem., Int. Ed. Engl. 1987, 26,
1010–1011.
(21) Weber, L.; Meine, G.; Niederpru¨m, N.; Boese, R. Organometallics 1987,
6, 1989–1991.
2
interpreted as a ligand-to-metal π-donation. The LUMO is dz -like
at the metal but also contains lobes on both the R and ꢀ phosphorus
atoms and is partially P-P σ-antibonding in character. The
contributions from the ꢀ phosphorus to both the HOMO and LUMO
are indicative of ambiphilic character, as might be expected in view
of the proposed bimolecular reaction yielding 8.
(22) Peters, J. C.; Cherry, J.-P. F.; Thomas, J. C.; Baraldo, L.; Mindiola, D. J.;
Davis, W. M.; Cummins, C. C. J. Am. Chem. Soc. 1999, 121, 10053–
10067.
The diphosphenido complex 4 was found to engage in reVersible
phosphinidene transfer reactions with PPh3 to form an equilibrium
i
(23) Laplaza, C. E.; Davis, W. M.; Cummins, C. C. Angew. Chem., Int. Ed.
Engl. 1995, 34, 2042–2044.
mixture of 4, 5, Pr3SiPdPPh3, and PPh3. The phosphoranylidene
phosphorane iPr3SiPdPPh3 was identified by its 31P NMR spectrum,
which exhibits two sharp doublets (JPP ) 590 Hz) at 30.5 and
-263.8 ppm.31 By varying the concentration of 5 and PPh3, the
(24) Baudler, M.; Makowka, B. Z. Anorg. Allg. Chem. 1985, 528, 7–21.
(25) Goerlich, J. R.; Schmutzler, R. Z. Anorg. Allg. Chem. 1994, 620, 173–
176.
(26) Attempts at quantitative kinetic measurements for this reaction were
hindered by the many competitive pathways in the reaction mixture.
(27) Weber, L. Chem. ReV. 1992, 92, 1839–1906.
1
equilibrium constant for this reaction was measured by H NMR
spectroscopy as Keq ) 0.7. This value near to unity was initially
surprising to us, but a comparison of the relative energies of DFT
optimized model complexes revealed a very small ∆E ) 1.5 kcal/
(28) The conversion to (iPr3Si)2P2C6H10 was measured by 31P NMR spectroscopy
versus an internal standard and found to be 40-50%.
(29) Baerends, E. J. et al. ADF, ADF 2007. 01; Theoretical Chemistry, Vrije
Universiteit: Amsterdam, The Netherlands, 2007 (http://www.scm.com).
(30) te Velde, G.; Bickelhaupt, F. M.; Baerends, E. J.; Fonseca Guerra, C.; van
Gisbergen, S. J. A.; Snijders, J. G.; Ziegler, T. J. Comput. Chem. 2001,
22, 931–967.
mol for the reaction PPh3 + Me3SiPdPMo(N[tBu]Ar)3
f
Me3SiPdPPh3 + PMo(N[tBu]Ar)3. This equilibrium reaction sug-
gests that 4 is susceptible to nucleophilic attack at its ꢀ-phosphorus,
resulting in transfer of the phosphinidene with the triply bonded
molybdenum terminal phosphide 5 serving as a leaving group. In
(31) Smith, R. C.; Shah, S.; Protasiewicz, J. D. J. Organomet. Chem. 2002,
646, 255–261.
JA903860K
9
J. AM. CHEM. SOC. VOL. 131, NO. 25, 2009 8765
