Active Metal Template Synthesis of [2]Catenanes
Stephen M. Goldup, David A. Leigh,* Tao Long, Paul R. McGonigal,
Mark D. Symes, and Jhenyi Wu
School of Chemistry, UniVersity of Edinburgh, The King’s Buildings, West Mains Road,
Edinburgh EH9 3JJ, United Kingdom
Received August 19, 2009; E-mail: david.leigh@ed.ac.uk
Abstract: The synthesis of [2]catenanes by single macrocyclization and double macrocyclization strategies
using Cu(I) ions to catalyze covalent bond formation while simultaneously acting as the template for the
mechanically interlocked structure is reported. These “active metal template” strategies employ appropriately
functionalized pyridine ether or bipyridine ligands and either the CuAAC “click” reaction of azides with
terminal alkynes or the Cu(I)-mediated Cadiot-Chodkiewicz heterocoupling of an alkyne halide with a
terminal alkyne. Using one macrocyclic and one acyclic building block, heterocircuit (the rings are
constitutionally different) [2]catenanes are produced via the single macrocyclization route in up to 53%
yield by optimizing the reaction conditions and relative stoichiometry of the starting materials. Alternatively,
with the active template CuAAC reaction, a single acyclic unit can be used to form a homocircuit (two
identical rings) [2]catenane in 46% yield through a one-pot, double macrocyclization, procedure. Remarkably,
<7% of the corresponding noninterlocked macrocycle is isolated from this reaction, indicating the efficacy
of Cu(I) as both a template for the catenane and a catalyst for covalent bond formation in the reaction.
strategies,1a “clipping” approaches to rotaxanes and catenanes
(involving single or double macrocyclization of ligands, directed
Introduction
The synthesis of catenanes and rotaxanes was revolutionized
by the application of template-directed syntheses,1 in which the
components are preorganized prior to covalent capture of the
interlocked architecture. Although a large number of different
types of template-directed reactions have been successfully
employed to form rotaxanes in threading-followed-by-stoppering
by the template)2 are rather more demanding and have only
been demonstrated with a small number of different macrocy-
clization reaction types. Of these, Williamson ether synthesis,2
the Huisgen-Meldal-Fokin Cu(I)-catalyzed 1,3-cycloaddition
of azides with terminal alkynes (the CuAAC “click” reaction),3,4
amide or ester bond-forming reactions,5 ring-closing metathesis,6
imine bond formation,1u,6f,7 and metal-ligand coordination8 are
the most commonly used. The effectiveness of these reactions
for catenane synthesis lies in their reactive end groups being
sufficiently stable in solution to react overwhelmingly in the
desired fashion even when accessing the required reaction
geometry is a rare event (as it is for the cyclization of large
