Hydrosulfide (HS-) Coordination in Iron Porphyrinates
Jeffrey W. Pavlik,† Bruce C. Noll,† Allen G. Oliver,† Charles E. Schulz,*,‡ and W. Robert Scheidt*,†
†Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, Indiana 46556 and
‡Department of Physics, Knox College, Galesburg, Illinois 61401
Received September 18, 2009
Recent reports of potential physiological roles of hydrogen sulfide have prompted interest in heme-sulfide
interactions. Heme-H2S and/or heme-HS- interactions could potentially occur during endogenous production,
transport, signaling events, and catabolism of H2S. We have investigated the interaction of the hydrosulfide ion (HS-)
with iron porphyrinates. UV-vis spectral studies show the formation of [Fe(Por)(SH)]-, [Fe(Por)(SH)2]2-, and the
mixed-ligand species [Fe(Por)(Im)(SH)]-. UV-vis binding studies of [Fe(OEP)] and [Fe(T-p-OMePP)] (OEP =
octaethylporphyrinate; T-p-OMePP = tetra-p-methoxyphenylporphyrinate) with HS- allowed for calculation of the
formation constants and extinction coefficients of mono- and bis-HS- complexes. We report the synthesis of the first
HS--bound iron(II) porphyrin compounds, [Na(222)][Fe(OEP)(SH)] 0.5C6H6 and [Na(222)][Fe(T-p-OMePP)-
3
(SH)] C6H5Cl (222 = Kryptofix-222). Characterization by single-crystal X-ray analysis, mass spectrometry, and
€
3
Mossbauer and IR spectroscopy is all consistent with that of known sulfur-bound high-spin iron(II) compounds. The
II
-
˚
Fe-S distances of 2.3929(5) and 2.3887(13) A are longer than all reported values of [Fe (Por)(SR)] species. An
analysis of the porphyrin nonplanarity for these derivatives and for all five-coordinate high-spin iron(II) porphyrinate
derivatives with an axial anion ligand is presented. In our hands, attempts to synthesize iron(III) HS- derivatives led to
iron(II) species.
Introduction
to 80 ppm of H2S, they had sequential drops in their
metabolic rate and core body temperature, similar to that
observed in animals during the onset of hibernation.10 After
H2S treatment was stopped, vital signs returned to normal,
and no long-term functional or behavioral abnormalities
were observed. This has prompted speculation into the use
of H2S as a means to improving postsurgery and post-trauma
recovery.11
H2S is produced endogenously in mammals by two en-
zymes. Cystathionine γ-lyase is the primary source of physio-
logical H2S in the mammalian cardiovascular system12 and
cystathionine β-synthase (CBS) in the central nervous sys-
tem.13 The endogenous H2S levels in mammalian tissues is
about 15 nM,2 allowing for localized high intracellular gas
concentrations like those observed in NO signaling, wherein
the tissue function is altered upon nanomolar fluctuations.14
At the biological pH of 7.4, dissolved H2S, pKa = 6.9, is
partially deprotonated; the HS-/H2S ratio is 3:1, so one or
more sulfide species could act as ligands to receptor pro-
teins. Neither the binding species nor the receptors for
potential sulfide-protein interactions associated with the
Hydrogen sulfide (H2S) has recently been recognized as a
third possible gasotransmitter, along with NO and CO, and
may play a role in vasodilation, blood pressure regulation,
and neurological health.1-5 Previously known H2S biology
consisted of its malodor and ability to inhibit cytochrome
c oxidase.6 However, the interaction of H2S with mitochon-
drial cytochrome c oxidase is concentration-dependent.7
Endogenously produced H2S has been linked to hippo-
campal long-term potentiation8 as well as neurological dis-
orders such as Down’s Syndrome and Alzheimer’s disease.9
The prospect of suspended animation in animals and humans
is yet another facet of H2S biology. When mice were exposed
*To whom correspondence should be addressed. E-mail: scheidt.1@
nd.edu.
