A new approach to imidazo[1,2-a]pyridine derivatives and their application to the synthses of novel 2H-pyrano[2',3':4,5] imidazo[1,2-a]pyridin-2-one derivatives

Article abstract of DOI:10.3987/COM-09-S(S)41

3-[Bis(methylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinones were prepared from the S-alkylation of pyridinium 1-[1-carbamoyl-1-[(methylthio) thiocarbonyl]]methylides with methyl iodide followed by the alkaline treatment of the resulting pyridinium salts.

Full text of DOI:10.3987/COM-09-S(S)41

HETEROCYCLES, Vol. 80, No. 1, 2010
439
HETEROCYCLES, Vol. 80, No. 1, 2010, pp. 439 - 454. © The Japan Institute of Heterocyclic Chemistry
Received, 26th June, 2009, Accepted, 18th August, 2009, Published online, 18th August, 2009
DOI: 10.3987/COM-09-S(S)41
A NEW APPROACH TO IMIDAZO[1,2-a]PYRIDINE DERIVATIVES
AND THEIR APPLICATION TO THE SYNTHSES OF NOVEL
2H-PYRANO[2’,3’:4,5] IMIDAZO[1,2-a]PYRIDIN-2-ONE DERIVATIVES1
Takashi Abe, Yukihisa Okumura, Hiroyuki Suga, and Akikazu Kakehi*
Department of Chemistry and Material Engineering, Faculty of Engineering,
Shinshu
University,
Wakasato,
Nagano
380-8553.
E-Mail:
xkakehi@shinshu-u.ac.jp
Abstract – 3-[Bis(methylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinones were
prepared from the S-alkylation of pyridinium 1-[1-carbamoyl-1-[(methylthio)
thiocarbonyl]]methylides with methyl iodide followed by the alkaline treatment
of
the
resulting
pyridinium
salts.
The
reactions
of
these
3-methylene-2(3H)-imidazo[1,2-a]pyridinones with some ethyl cyano- or
acyl-substituted acetates in the presence of a base did not afford the initially
expected 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-one derivatives, but,
instead of them, provided ethyl 3-[2-hydroxyimidazo[1,2-a]pyridin-3-yl]acrylates.
The thermolyses of these acrylates without any solvent under reduced pressure
gave the corresponding 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-one
derivatives.
Imidazo[1,2-a]pyridine derivatives have a variety of biological activities and have attracted much
attention as potential pharmaceutical and agricultural medicines.2―8 Thus, various constructive routes
for this skeleton have been developed,3-5,7-13 but, the access by their methods to the suitably
functionalized imidazo[1,2-a]pyridine derivatives which can readily lead to the fused one is usually
difficult. In a continuation of our work on nitrogen-bridged heterocycles, we were interested in the
preparation of such functionalized imidazo[1,2-a]pyridine derivatives, because we were familiar with the
formation and the reaction of its 1-deaza analogue, indolizine derivative. For example, we have
described that 2(3H)-indolizinones derivatives14 were useful precursors for the syntheses of some
-----------------------------------------------------------------------------------------------------------------------------
Dedicated to Professor Akira Suzuki on his 80th birthday.

440
HETEROCYCLES, Vol. 80, No. 1, 2010
functionalized
compounds
such
as
3-[bis(alkylthio)methylene]-2(3H)-indolizinones15
and
3-vinylindolizines,16 and which in turn were converted to the corresponding indolizine derivatives fused
with
furan,17 pyran,15 and oxepine ring.18,19 So, we planned the preparation of
a
3-[bis(alkylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinone (A, see Figure 1) as a potential precursor for
a novel heterocycle, 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-one. However, the brief survey of the
literature20 disclosed its inaccessibility from the potential precursor, 3-[mercapto(alkylthio)methylene]-
2(3H)-imidazo[1,2-a]pyridine (B), because this molecule behaved as its enolic tautomer, alkyl
2-hydroxyimidazo[1,2-a]pyridine-3-dithiocarboxylate (B’), and afforded only the O-alkylated product
(C). We next looked for an alternative method for the preparation of such molecules and developed a
new one for them in which the higher acidity of the amide proton in 1-(1-carbmoylvinyl)pyridinium salt
(D) was utilized for the construction of the imidazole ring. In this paper, we report the preparation of
3-[bis(methylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinones and their reaction with activated ethyl
acetates to provide novel pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine derivatives via the thermolyses of the
resulting ethyl 3-(2-hydroxyimidazo[1,2-a]pyridin-3-yl)acrylates.
N
N
N
R'Y
O
R
OH
OR'
R
R
N
N
N
base
SH
S
S
R'S
R'S
R'S
B
B'
C
R'Y base
R
R
1) 1,5-Cycliz.
2) -H2
N
N
O
N
R
N
-HX
NH
NH2
X
R'S
R'S
R'S
R'S
SR'
O
O
R'S
A
D
Figure 1
RESULTS AND DISCUSSION
Preparations of 3-methylene-2(3H)-imidazo[1,2-a]pyridinones (4). Since an amide proton has higher
acidity than that of normal amino protons, we thought that the desired 3-methylene-2(3H)-
imidazo[1,2-a]pyridinone derivatives such as 4 could be obtained by the deprotonation of the carbamoyl
group in the corresponding 1-[1-carbamoylvinyl]pyridinium halides (3) with a base, followed by the
attack of the resulting imide ion to the 2-position of the pyridine ring and the dehydrogenation of the
primary bicycloadducts. In fact, although the treatment of the 1-[1-carbamoyl-2,2-bis(methylthio)-
vinyl]pyridinium iodides (3a―c), readily obtainable from the reactions of pyridinium 1-[1-carbamoyl-1-
[(methylthio)thiocarbonyl]]methylides (2a―c) with methyl iodide, with a comparatively weak base such

HETEROCYCLES, Vol. 80, No. 1, 2010
441
as DBU, triethylamine, or potassium carbonate did not afford the desired 3-[bis(methylthio)methylene]-
2(3H)-imidazo[1,2-a]pyridinone derivatives (4a―c) at all, the use of a stronger base such as potassium
t-butoxide in ethanol (method A) or in DMF (method B) gave the corresponding products 4a―c in
moderate yields (21―51%) as orange to reddish crystals. Interestingly, in the reaction of unsymmetrical
3-methylpyridinium iodide (3b) only the 8-methyl derivative 4b was obtained, while the alternative
6-methyl one 4b’ was not. In general, it is well known that the attack at the 2-position of the pyridine
ring in the cyclization and the cycloaddition reactions of the 3-substituted pyridinium ylides or salts in the
ground state is preferred over that at the 6-position,21-23 but the observation of the exclusive mode at the
2-position is rare. These results are shown in Scheme 1.
R1
8
R1
R2
R1
R2
1
N
MeI
7
2
t-BuOK
O
N
N
+
N
4
+
R2
in acetone
quant.
6
3
A: in EtOH
B: in DMF
5
MeS
SMe
MeS2C
CONH2
CONH2
MeS
SMe
I
2a-c
4a-c
3a-c
Yield(%)
CS2-Me2SO4
R1 R2
No
A
B
aq-NaOH
Yield
(%)
R1 R2
R1 R2
H
H
H
No
No
1a
1b
R1
R2
4a
4b
21 24
38 --
Me
H
H
H
2a
32
H
H
H
N
+
Me
56
H
Me
(4b')
Me
0
--
2b
2c
Cl
CONH2
Me Me 45
1c Me Me
4c
Me Me
51 30
1a-c
Scheme 1
The structural assignment of these compounds (4a―c)
was accomplished mainly from physical and spectral
means, and confirmed by the X-ray analysis of one
compound 4c. For example, elementary analyses of
compound (4a―c) were in good accord with the
compositions of our proposed structures. The IR
spectra of these compounds showed a strong carbonyl
absorption band near 1630 cm-1, indicating the
contribution of a similar polarized structure as
observed in 3-methylene-2(3H)-indolizinones (near
1600 cm-1). 1H-NMR spectra of 4a―c showed two
N1
O1
N2
S1
S2
Figure 2. ORTEP drawing of 4c

442
HETEROCYCLES, Vol. 80, No. 1, 2010
methylthio proton signals at separate positions ( 2.47―2.50 and 2.67―2.69) as each singlet due to their
magnetic nonequivalence. These values showed distinctly that both methyl groups are attached to the
sulfur atom but not to the oxygen atom. Furthermore, that the product from the 3-methylpyridinium salt
3b was the 8-methyl derivative 4b was clearly showed by the presence of the vicinal ABC pattern signals
1
13
in the H-NMR spectra. The numbers for the sp2- and sp3-carbons in their C-NMR spectra of 4a―c
were well in accord with those of our proposed structures. Finally, the X-ray analysis of one compound
4c was carried out and the structure was confirmed. The ORTEP drawing24 of 4c is shown in Figure 2.
Preparation of ethyl 3-[2-hydroxyimidazo[1,2-a]pyridin-3-yl]acrylates (6) and their transformation
to 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-ones (7). In imitation of our previous syntheses of
pyrano[2,3-b]indolizines,15 the reactions of 4a―c with some activated ethyl acetates were investigated.
However, these reactions of 4a―c with ethyl cyanoacetate (5a), diethyl malonate (5b), ethyl
benzoylacetate (5c), and ethyl acetoacetate (5d) under various conditions did not afford the expected
2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-2-one derivatives (7a―l) at all. Instead of them, many of
these reactions formed ethyl 3-[2-hydroxyimidazo[1,2-a]pyridin-3-yl]acrylates. For example, when the
reactions of 4a―c with 5a―c were carried out in the presence of potassium t-butoxide in t-butanol
(method C) at room temperature, the smooth evolution of methanethiol was observed and the
corresponding acrylate derivatives 6a―i were isolated in 55―98% yields from the reaction mixtures. On
the other hand, similar reactions of 4a,b and 5d gave only complex mixtures and any significant products
such as 6j,k could not be isolated from them, though the reaction of 4c with 5d afforded the normal
product 6l in 75% yield. The same products 6c,l were obtained from the reactions of 4c with 5a,d in the
presence of DBU in chloroform (method D) at room temperature in 62 and 75% yields respectively, but
the application of method D to the reactions of 4a,b and 5d did not give good results.
Since we failed to obtain directly 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-2-one derivatives (7) from
the reactions of 2(3H)-imidazo[1,2-a]pyridinones (4) and acetates 5, we next examined the elimination of
ethanol from acrylates 6a―i,l obtained. Heating of acrylates 6a―i,l in various solvents or treatment
with acetic acid or concentrated sulfuric acid did not provide the condensation products 7a―i,l.
However, when acrylates 6a―h were heated without any solvent at reduced pressure (3 torr), the
eliminations smoothly occurred to give the expected products 6a―h in 21―73% yields. On the other
hand, similar treatment of 6i,l did not provide the corresponding products 7i,l, but 4-unsubstituted 7i’ and
3-unsubstituted 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-one derivatives (7l’) were formed in 34
and 16% yields, respectively. These results are shown in Scheme 2.
The elementary analyses of compounds 6a―i,l were in good accord with our postulated structures. The
IR spectra of 6a―i,l exhibited characteristic absorption bands at 3406―3447 cm-1 and at 1608―1651
cm-1 due to the presences of the 2-hydroxy and the 3-vinyl groups respectively. Each 1H-NMR spectra

HETEROCYCLES, Vol. 80, No. 1, 2010
443
R1
R1
9
R1
R3CH2CO2Et
5a—d
10
N
N
N
heat
1
8
O
OH
CO2Et
O
2
N
N
N
in vacuo
R2
R2
7
R2
C: t-BuOK/t-BuOH
D: DBU/CHCl3
O
5
6
4
SMe
3
R4
R3
R3
MeS
MeS
6a-l
7a-i,l
4a-c
5a (R3=CN), 5b (R3=CO2Et), 5c (R3=COPh), 5d (R3=COMe)
Yield (%)
Yield
(%)
R1
No
R1
R2
R3
No
R2
R3
R4
C
D
6a
6b
6c
6d
6e
6f
H
H
H
CN
CN
68 --
72 --
55 62
7a
7b
7c
7d
7e
7f
H
H
H
CN
CN
SMe
21
50
42
59
65
73
59
66
0
Me
Me
H
Me
Me
H
SMe
SMe
Me CN
Me CN
H
H
CO2Et 55 --
CO2Et 74 --
H
H
CO2Et SMe
CO2Et SMe
Me
Me
H
Me
Me
H
Me CO2Et 84 --
Me CO2Et SMe
6g
6h
6i
H
H
COPh 73 --
COPh 98 --
7g
7h
7i
H
H
COPh
COPh
SMe
SMe
SMe
H
Me
Me
H
Me
Me
Me
Me
Me
Me COPh 78 --
Me COPh
Me COPh
6j
H
H
COMe
COMe
0a 0a
0a 0a
7i'
7l
34
0
6k
6l
Me
Me
Me COMe SMe
Me SMe
Me COMe 69 75
a) Complex mixture.
7l'
H
16
Scheme 2
showed only one set of proton signals for 6a―i,l. Similarly, any signals of mixture were not observed
13
in the C-NMR spectra of unsymmetrical acrylates 6g―i. This fact suggested that compounds 6a―i,l
are the sole products, and not cis-trans mixtures in the relation of the 3-vinyl group, though we could not
determined their E/Z configurations for 6a―c,g―i,l because of the tetra-substituted mode. In addition,
the presences of one methylthio signal at  1.94―2.58 (3H, s) and one or two ethoxycarbonyl signals at 
0.95―1.27 (3H, t) and 3.86―4.18 (2H, q) in compounds 6a―i,l were also indicated, together with
protons and methyl group(s) on the pyridine ring. On the other hand, each proton signal for the
2-hydroxy group in 6a―i was not shown, but this must be due to the broadening of the signal because
one sp3-carbon signal which should appear in its tautomeric 2(3H)-imidazo[1,2-a]pyridinone structure did
not appear in the 13C-NMR spectra. Judging from these data and their smooth transformation to
subsequent elimination products 7a―h,i’,l’, we concluded 6a―i,l to be ethyl 3-[2-hydroxyimidazo-
[1,2-a]pyridin-3-yl]acrylates.
1
Similarly, compounds 7a―h afforded satisfactory elemental analyses and their H-NMR spectra
demonstrated clearly the disappearance of an ethoxy group from the precursors 6a―h. However, the
analyses for 7i’,l’ exhibited formulas C19H14N2O3 and C13H12N2O2S respectively and they were not in

444
HETEROCYCLES, Vol. 80, No. 1, 2010
1
accord with our initially expected compositions (C20H16N2O3S and C15H14N2O3S). H-NMR spectral
analyses of 7i’,l’ provided a solution for the structural question, that is, the loss of a methylthio or an
acetyl group from the initially formed 7i,l
and the appearance of a new olefinic proton
N1
at the 4- (7i’) or 3-position (7l’) were shown.
These findings suggested that the cyclization
O1
products 7i,l underwent a further elimination
O2
reaction under the conditions employed here
N2
to give the observed ones 7i’,l’, though the
detailed mechanisms for them is unclear.
O3
Finally, one (7d) of this type of compound
S1
was subjected to X-ray analysis and the
O4
skeleton was completely confirmed to be
2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-
Figure 3. ORTEP drawing of 7d.
2-one. The ORTEP drawing of 7d is shown
in Figure 3.24
Reaction Mechanisms. Possible mechanisms are shown in Scheme 3. As described above,
3-methylene-2(3H)-imidazo[1,2-a]pyridinones (4a―c) can be created by the intramolecular nucleophilic
cyclization of the imide ion 8, generated by the proton abstraction from the comparatively acidic
carbamoyl group of pyridinium salts (3a―c), to the 2-position on the pyridine ring, followed by the
dehydrogenation of the primary bicycloadducts 9. The production of ethyl 3-[2-hydroxyimidazo-
[1,2-a]pyridin-3-yl]acrylates (6a―i,l) can be explained by the nucleophilic attack of the carbanion 10,
produced in situ by the treatment of active methylene compounds 5a―d with a base, to the electron-poor
3(1)-methylene carbon in 4a―c, followed by the elimination of a methylthio anion from the resulting
adduct 11 and the 1,5-shift of a hydrogen atom from the 3(2)-position to the 2-carbonyl oxygen in
intermediates 12. Although the reason why the transformation from 6a―i,l to 7a―i,l was ineffective on
heating in a solvent or by treatment with an acid or a base is still uncertain, the route from 6a―i,l to
pyranoimidazopyridines (7a―i,l) should proceed via the nucleophilic addition of the lone pair electrons
of the 2-hydroxy oxygen to the ester carbonyl carbon attached with the 3-vinyl group and subsequent
elimination of a molecule of ethanol.
EXPERIMENTAL
Melting points were measured with a Yanagimoto micromelting point apparatus and were not corrected.
Microanalyses were carried out on a Perkin-Elmer 2400 elemental analyzer.
The 1H-NMR and

HETEROCYCLES, Vol. 80, No. 1, 2010
445
R1
R2
R1
R2
R1
H
N
NH
tert-BuOK
1,5-Cycliz.
O
+
+N
N
R2
-KI
-tert-BuOH
MeS
MeS
SMe
CONH2
CONH-
MeS
SMe
SMe
-
I
5a-d
9
8
+
3a-c
-H
-H2
R3
R1
R1
R1
-
CO2Et
10
N
N
O
N
N
-
O
O
-MeS-
N
N
R2
R2
R2
H
SMe
SMe
R3
H
R3
+
MeS
MeS
MeS
CO2Et
4a-c
EtO2C
12
11
1,5-Shift
R1
R1
R1
N
H
N
N
heat
OH
CO2Et
O
+
-
O
N
N
O
N
R2
R2
R2
O
-EtOH
OEt
MeS
MeS
13
R3
R3
MeS
6a-i,l
R3
7a-i,l
Scheme 3
13C-NMR spectra were determined with a JEOL JNM-LA400 (1H: 400 MHz and 13C: 100.4 MHz)
spectrometer in deuteriochloroform25 with tetramethylsilane used as the internal standard; the chemical
shifts are expressed in  values.
The IR spectra were taken with JASCO FT/IR-5300 IR
spectrophotometers.
Materials. 1-(Carbamoylmethyl)pyridinium chloride (1a—c) were prepared in good yields from the
reaction of pyridine, 3-methylpyridine, and 3,5-dimethylpyridine with -chloroacetamide in acetone
according to the literature.26 Some physical and spectral data for the new compound 1c are as follows:
1-Carbamoylmethyl-3,5-dimethylpyridinium chloride (1c); 80%, colorless prisms, mp 250—253 °C
(from CHCl3-hexane), IR (KBr)  1682, 3086, 3244 cm-1.
1H-NMR : 2.59 (6H, s, 3- and 5-H), 5.68
(1H, br, NH), 5.82 (2H, s, NCH2), 8.04 (1H, br s, 4-H), 8.95 (2H, br s, 2- and 6-H), 9.66 (1H, br, NH).
Anal. Calcd for C9H13ClN2O: C, 53.87; H, 6.53; N, 13.96. Found: C, 53.78; H, 6.43; N, 14.15.
Pyridinium 1-(1-carbamoyl)[1-methylthio(thiocarbonyl)]methylides 2a—c were prepared from the
treatment of a mixture of pyridinium salts 1a—c, carbon disulfide, and dimethyl sulfate with aqueous
sodium hydroxide, according to the procedure described by Tominaga et al.27 Some data for new
pyridinium
methylides
2b,c
are
as
follows:
3-Methylpyridinium
1-(1-carbamoyl)-

446
HETEROCYCLES, Vol. 80, No. 1, 2010
[1-methylthio(thiocarbonyl)]methylide (2b), 56%, yellow prisms, mp 179—180 °C (from CHCl3-hexane).
IR (KBr): 1631, 3243, 3293 cm-1. 1H-NMR : 2.48 (3H, s, SMe), 2.58 (3H, s, 3-Me), 5.53 (1H, br,
NH), 7.79 (1H, dd, J=8.0, 6.1 Hz, 5-H), 8.19 (1H, br d, J=8.0 Hz, 4-H), 8.29 (1H, br s, 2-H), 8.30 (1H, br
d, J=6.1 Hz, 6-H), 10.69 (1H, br, NH). 13C-NMR : 16.67, 18.62, 126.34, 126.41, 138.20, 145.06, 146.57,
148.89, 165.11, 178.18. Anal. Calcd for C10H12N2OS2: C, 49.97; H, 5.03; N, 11.66. Found: C, 49.73; H,
5.27; N, 11.66. 3,5-Dimethylpyridinium 1-(1-carbamoyl)[1-methylthio(thiocarbonyl)]methylide (2c),
45%, yellow prisms, mp 199—200 °C (from CHCl3-hexane). IR (KBr): 1631, 3244, 3281 cm-1.
1H-NMR : 2.49 (3H, s, SMe), 2.53 (6H, s, 2-, 6-Me), 5.53 (1H, br, NH), 7.98 (1H, br s, 4-H), 8.49 (2H,
br s, 2-, 6-H), 10.70 (1H, br, NH). 13C-NMR : 16.68, 18.49, 126.36, 137.51, 145.82, 146.19, 165.22,
178.02. Anal. Calcd for C11H14N2OS2: C, 51.94; H, 5.55; N, 11.01. Found: C, 51.88; H, 5.59; N, 10.91.
Preparations of 3-[bis(methylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinones (4a—c). General
Method. The mixture of pyridinium methylide (2, 10 mmol) and methyl iodide (1.846 g, 13 mmol) in
acetone (20 mL) was stirred at room temperature for 1 day. The precipitates of pyridinium salt 3 which
separated were collected by suction and washed with acetone (20 mL). Without further purification, the
salt 3 was treated with potassium t-butoxide (1.346 g, 12 mmol) in ethanol (25 mL, Method A) or DMF
(25 mL, Method B) at room temperature and stirred for the time given in the description for each product.
The resulting solution was concentrated under reduced pressure at a temperature below 30 °C. The
residue was then separated by column chromatography on alumina using CHCl3 as an eluent. The
yellow to orange layers which eluted first were collected and the combined solution was concentrated
under reduced pressure. The recrystallization from CHCl3-Et2O provided the corresponding product 4.
In these reactions the use of other bases such as DBU, triethylamine, or potassium carbonate did not
provide the desired 2(3H)-imidazo[1,2-a]pyridinone derivative (4) at all. Furthermore, the formation of
an alternative 6-methyl derivative 4b’ in the alkaline treatment of unsymmetrical 3-methylpyridinium salt
3b could not be detected.
3-[Bis(methylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinones (4a): From 2a, 21% (Method A,
reaction time 5 h) or 24% (Method B, reaction time 5 h), orange prisms, mp 142—143 °C.
IR (KBr):
1610 cm-1. 1H-NMR : 2.48 and 2.68 (each 3H, s, SMe), 6.64 (1H, ddd, J=7.0, 7.0, 1.4 Hz, 6-H), 7.14
(1H, br d, J=9.0 Hz, 8-H), 7.44 (1H, ddd, J=9.0, 7.0, 1.4 Hz, 7-H), 8.93 (1H, br d, J=7.0 Hz, 5-H).
13C-NMR : 19.63, 20,72, 110.45, 116.04, 124.46, 130.19, 137.52, 152.34, 160.91, 170.84. Anal. Calcd
for C10H10N2OS2: C, 50.39; H, 4.23; N, 11.75. Found: C, 50.17; H, 4.37; N, 12.01.
3-[Bis(methylthio)methylene]-8-methyl-2(3H)-imidazo[1,2-a]pyridinones (4b): From 2b, 38%
(Method A, reaction time 4 h), red prisms, mp 149—151 °C.
IR (KBr): 1630 cm-1. 1H-NMR :

HETEROCYCLES, Vol. 80, No. 1, 2010
447
2.38 (3H, s, 8-Me), 2.50 and 2.69 (each 3H, s, SMe), 6.57 (1H, t, J=7.0, 6-H), 7.25 (1H, br d, J=7.0 Hz,
7-H), 8.79 (1H, br d, J=7.0 Hz, 5-H). 13C-NMR : 17.13, 19.58, 20.66, 110.25, 124.88, 125.80, 127.46,
135.69, 151.72, 160.97, 170.85. Anal. Calcd for C11H12N2OS2: C, 52.35; H, 4.79; N, 11.10. Found: C,
52.40; H, 4.82; N, 11.03.
3-[Bis(methylthio)methylene]-6,8-dimethyl-2(3H)-imidazo[1,2-a]pyridinones (4c): From 2c, 51%
(Method A, reaction time 2 h) or 30% (Method B, reaction time 4 h), red prisms, mp 209—211 °C.
IR
(KBr): 1630 cm-1. 1H-NMR : 2.23 (3H, s, 6-Me), 2.37 (3H, s, 8-Me), 2.47 and 2.67 (each 3H, s,
SMe), 7.13 (1H, br s, 7-H), 8.57 (1H, br s, 5-H). 13C-NMR : 17.19, 18.07, 19.70, 21.02, 119.77,
125.19, 125.27, 125.54, 138.62, 151.25, 160.11, 171.04. Anal. Calcd for C12H14N2OS2: C, 51.94; H,
5.55; N, 11.01. Found: C, 51.88; H, 5.59; N, 10.91.
Preparations of ethyl 3-[2-hydroxy-2(3H)-imidazo[1,2-a]pyridin-3-yl]acrylates (6a—l). General
method. A mixture of 3-[bis(methylthio)methylene]-2(3H)-imidazo[1,2-a]pyridinone (4, 1 mmol) and
an active methylene compound (5, 1.2 mmol) was stirred with potassium t-butoxide (0.135 g, 1.2 mmol)
in t-BuOH (30 mL) (method C) or with DBU (0.182 g, 1,2 mmol) in CHCl3 (30 mL) (Method D) at room
temperature for the time indicated in the description for each product. The solution was then
concentrated under reduced pressure, and the residue was separated by column chromatography on
alumina using CHCl3-EtOH (9:1) as an eluent. The yellow layers were collected and the combined
solution was concentrated under reduced pressure. Recrystallization of the crude product from EtOH
afforded the corresponding ethyl 3-[2-hydroxyimidazo[1,2-a]pyridine-3-yl]-acrylates (6a—i,l).
The reactions of 2(3H)-imidazo[1,2-a]pyridinones 4a,b with ethyl acetoacetate (5d) gave complex
mixtures and the isolation of significant products such as 6j,k from them was unsuccessful. Some
physical and spectral data for these products 6a—i,l are shown below.
Ethyl 2-cyano-3-(2-hydroxyimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6a): From 4a and
ethyl cyanoacetate (5a), 68% (Method C, reaction time 6 h), yellow needles, mp 260—263 °C. IR
(KBr): 1651, 1685, 2199, 3412 cm-1. 1H-NMR : 1.27 (3H, br, OCH2CH3), 2.52 (3H, br s, SMe), 4.17
(2H, br, OCH2CH3), 7.10 (1H, br t, J=6.8, 6.8 Hz, 6-H), 7.46 (1H, br d, J=8.5 Hz, 8-H), 7.53 (1H, br q,
J=8.5, 6.8 Hz, 7-H), 8.03 (1H, br d, J=6.8 Hz, 5-H). Anal. Calcd for C14H13N3O3S: C, 55.43; H, 4.32; N,
13.85. Found: C, 55.46; H, 4.24; N, 13.91.
Ethyl 2-cyano-3-(2-hydroxy-8-methylimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6b): From
4b and 5a, 72% (Method C, reaction time 3 h), yellow needles, mp 284—287 °C. IR (KBr): 1620,
1705, 2203, 3425 cm-1. 1H-NMR : 1.27 (3H, br, OCH2CH3), 2.50 (3H, br s, SMe), 2.58 (3H, br s,
8-Me), 4.18 (2H, br, OCH2CH3), 7.02 (1H, br t, J=6.8, 6.8 Hz, 6-H), 7.33 (1H, br d, J=6.8 Hz, 7-H), 7.99

448
HETEROCYCLES, Vol. 80, No. 1, 2010
(1H, br d, J=6.8 Hz, 5-H). Anal. Calcd for C15H15N3O3S+1/2C2H5OH: C, 56.46; H, 5.33; N, 12.34.
Found: C, 56.64; H, 5.04; N, 12.59.
Ethyl 2-cyano-3-(2-hydroxy-6,8-dimethylimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6c):
From 4c and 5a, 55% (Method C, reaction time 15 h) or 62% (Method D, reaction time 15 h), yellow
needles, mp 299—302 °C. IR (KBr): 1633, 1693, 2200, 3437 cm-1. 1H-NMR : 1.26 (3H, br,
OCH2CH3), 2.33 (3H, br s, 6-Me), 2.50 (3H, br s, 8-Me), 2.53 (3H, br s, SMe), 4.18 (2H, br, OCH2CH3),
7.17 (1H, br s, 7-H), 7.75 (1H, br s, 5-H). Anal. Calcd for C16H17N3O3S: C, 57.99; H, 5.17; N, 12.68.
Found: C, 57.99; H, 5.17; N, 12.69.
Diethyl [1-(2-hydroxyimidazo[1,2-a]pyridin-3-yl)-1-(methylthio)]methylene]malonate (6d): From 4a
and diethyl malonate (5b), 55% (Method C, reaction time 15 h) or 62% (Method D, reaction time 15 h),
yellow needles, mp 64—66 °C. IR (KBr): 1616, 1651, 1718, 3404 cm-1. 1H-NMR : 1.18 (6H, t,
J=7.1 Hz, 2×OCH2CH3), 2.16 (3H, s, SMe), 4.17 (4H, q, J=7.1 Hz, 2×OCH2CH3), 6.97 (1H, br t, J=6.8,
6.8 Hz, 6-H), 7.33 (1H, br q, J=8.8, 6.8 Hz, 7-H), 7.43 (1H, br d, J=8.8 Hz, 8-H), 8.05 (1H, br d, J=6.8 Hz,
5-H). 13C-NMR : 13.97, 15.71, 60.99, 97.01, 109.87, 114.40, 120.04, 124.52, 127.26, 135.59, 146.83,
156.88, 164.34. Anal. Calcd for C16H18N2O5S: C, 54.84; H, 5.18; N, 7.99. Found: C, 54.54; H, 5.29; N,
8.28.
Diethyl [1-(2-hydroxy-8-methylimidazo[1,2-a]pyridin-3-yl)-1-(methylthio)methylene]malonate (6e):
From 4b and (5b), 55% (Method C, reaction time 15 h) or 62% (Method D, reaction time 15 h), yellow
needles, mp 95—98 °C. IR (KBr): 1608, 1638, 1697, 3423 cm-1. 1H-NMR : 1.18 (6H, t, J=7.1 Hz,
2×OCH2CH3), 2.18 (3H, s, SMe), 2.57 (3H, s, 8-Me), 4.17 (4H, q, J=7.1 Hz, 2×OCH2CH3), 6.88 (1H, t,
J=7.0, 7.0 Hz, 6-H), 7.13 (br d, J=7.0 Hz, 7-H), 7.96 (1H, br d, J=7.0 Hz, 5-H). 13C-NMR : 14.05,
15.72, 16.38, 60.94, 97.57, 114.06, 119.58, 120.81, 122.54, 127.17, 136.47, 147.47, 157.29, 164.49.
Anal. Calcd for C17H20N2O5S: C, 56.03; H, 5.53; N, 7.69. Found: C, 55.93; H, 5.71; N, 7.61.
Diethyl [1-(2-hydroxy-6,8-dimethylimidazo[1,2-a]pyridin-3-yl)-1-(methylthio)methylene]malonate
(6f): From 4c and (5b), 84% (Method C, reaction time 15 h) or 62% (Method D, reaction time 15 h),
yellow needles, mp 182—185 °C. IR (KBr): 1610, 1705, 3447 cm-1. 1H-NMR : 1.17 (6H, t, J=7.1
Hz, 2×OCH2CH3), 2.17 (3H, s, SMe), 2.29 (3H, s, 6-Me), 2.51 (3H, s, 8-Me), 4.15 (4H, q, J=7.1 Hz,
2×OCH2CH3), 6.97 (1H, br s, 7-H), 7.75 (1H, br s, 6-Me). Anal. Calcd for C18H22N2O5S: C, 57.13; H,
5.86; N, 7.40. Found: C, 57.19; H, 5.87; N, 7.33.
Ethyl 2-benzoyl-3-(2-hydroxyimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6g): From 4a and
ethyl benzoylacetate (5c), 73% (Method C, reaction time 3 h), red prisms, mp 260—263 °C. IR (KBr):
1624, 1653, 1701, 3406 cm-1. 1H-NMR : 1.07 (3H, t, J=7.1 Hz, OCH2CH3), 2.02 (3H, s, SMe), 4.12
(2H, q, J=7.1 Hz, OCH2CH3), 7.05 (1H, t, J=6.9, 6-H), 7.31—7.47 (5H, m, 7-, 8-H, Phenyl-H),

HETEROCYCLES, Vol. 80, No. 1, 2010
449
7.86—7.91 (2H, m, Phenyl-H), 8.29 (1H, br d, J=6.9 Hz, 5-H). 13C-NMR : 14.09, 15.73, 60.78, 97.76,
109.86, 114.68, 124.46, 126.34, 127.39, 128.06, 128.53, 132.32, 135.70, 137.84, 145.49, 157.31, 164.24,
193.20. Anal. Calcd for C20H18N2O4S: C, 62.81; H, 4.74; N, 7.33. Found: C, 62.77; H, 5.04; N, 7.07.
Ethyl 2-benzoyl-3-(2-hydroxy-8-methylimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6h):
From 4b and 5c, 98% (Method C, reaction time 17 h), red prisms, mp 209—212 °C. IR (KBr): 
1638, 1661, 1719, 3429 cm-1. 1H-NMR : 1.05 (3H, t, J=7.1 Hz, OCH2CH3), 1.94 (3H, s, SMe),
2.48 (3H, s, 8-Me), 4.10 (2H, q, J=7.0 Hz, OCH2CH3), 6.92 (1H, t, J=7.0, 6-H), 7.13 (1H, br d, J=7.0 Hz,
7-H), 7.31—7.37 (2H, m, Ph-H), 7.41—7.47 (1H, m, Ph-H), 7.99—8.04 (2H, m, Ph-H), 8.30 (1H, br d,
13
J=6.8 Hz, 5-H). C-NMR : 14.11, 15.51, 16.13, 60.63, 98.20, 114.65, 120.50, 122.35, 126.52, 127.40,
128.01, 128.87, 132.33, 135.95, 137.87, 144.02, 157.76, 164.25, 193.66. Anal. Calcd for C21H20N2O4S:
C, 63.62; H, 5.08; N, 7.07. Found: C, 63.53; H, 5.16; N, 7.08.
Ethyl 2-benzoyl-3-(2-hydroxy-6,8-dimethylimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6i):
From 4c and 5c, 78% (Method C, reaction time 17 h), red prisms, mp 234—236 °C. IR (KBr): 1616,
1660, 1712, 3409 cm-1. 1H-NMR : 1.05 (3H, t, J=7.1 Hz, OCH2CH3), 1.95 (3H, s, SMe), 2.32 (3H, s,
6-Me), 2.41 (3H, s, 8-Me), 4.10 (2H, q, J=7.1 Hz, OCH2CH3), 7.15 (1H, br s, 7-H), 7.30—7.37 (2H, m,
Ph-H), 7.39—7.47 (1H, m, Ph-H), 7.97—8.04 (2H, m, Ph-H), 8.09 (1H, br s, 5-H). 13C-NMR : 14.11,
15.32, 15.50, 16.14, 60.62, 98.22, 114.62, 120.55, 122.35, 126.59, 127.35, 128.01, 128.90, 132.32, 136.04,
137.89, 144.00, 157.78, 164.24, 193.63. Anal. Calcd for C22H22N2O4S: C, 64.37; H, 5.40; N, 6.82.
Found: C, 64.51; H, 5.42; N, 6.68.
Ethyl 2-acetyl-3-(2-hydroxy-6,8-dimethylimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6l):
From 4c and 5c, 78% (Method C, reaction time 17 h), red prisms, mp 234—236 °C. IR (KBr): 1616,
1660, 1712, 3409 cm-1. 1H-NMR  DMSO-d6): 0.95 (3H, t, J=7.1 Hz, OCH2CH3), 2.08 (3H, s, SMe),
2.09 (3H, s, 6-Me), 2.22 (3H, s, 8-Me), 2.23 (3H, s, COMe), 4.10 (2H, q, J=7.1 Hz, OCH2CH3), 7.09 (1H,
br s, 7-H), 8.17 (1H, br s, 5-H), 8.24 (1H, s, OH). Anal. Calcd for C17H20N2O4S: C, 64.37; H, 5.40; N,
6.82. Found: C, 64.51; H, 5.42; N, 6.68.
Preparation of 2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-ones (7a-h,i’,l’). General method.
Ethyl 3-(2-hydroxyimidazo[1,2-a]pyridin-3-yl)-3-(methylthio)acrylate (6, 0.5 mmol) without any solvent
was put in a test tube equipped with a vacuum system, and the tube was heated by an electronic furnace
under reduced pressure (3 torr) at the reaction temperature and for the time described for each compound
7a—h,i’,l’. The resulting reaction mixture was dissolved in as small amount of CHCl3 as possible and
the solution was separated by column chromatography on silica gel using CHCl3-EtOH (9:1). The
yellow fractions which eluted first were combined and concentrated under reduced pressure. The

450
HETEROCYCLES, Vol. 80, No. 1, 2010
recrystallization
of
the
residue
from
CHCl3-Et2O
afforded
the
corresponding
2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-one derivative (7).
First we examined the syntheses of these compounds 7a—i,l by the reactions of ethyl
3-[2-hydroxyimidazo[1,2-a]pyridine-3-yl]acrylates (6a—i,l) under various reaction conditions (for
o
example, heating at 80 C in DMF in the presence of a base such as potassium t-butoxide, heating at 80
oC in acetic acid, and treatment with concentrated sulfuric acid at room temperature), but the expected
2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-2-ones (7a—i,l) could not be obtained at all.
Some physical and spectral data for these products 7a—h,i’,l’ are shown below.
4-Methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-carbonitrile (7a): From 6a, 21%
(reaction temperature 75 °C, time 15 min), yellow needles, mp 266—270 °C. IR (KBr): 1715, 2216
cm-1. 1H-NMR : 3.11 (3H, s, SMe), 7.23 (1H, ddd, J=7.0, 7.0, 1.4 Hz, 7-H), 7.67 (1H, ddd, J=9.0, 7.0,
1.2 Hz, 8-H), 7.79 (1H, br d, J=9.0 Hz, 9-H), 9.17 (1H, br d, J=7.0 Hz, 6-H). Anal. Calcd for
C12H17N3O2S: C, 56.02; H, 2.74; N, 16.33. Found: C, 56.20; H, 2.79; N, 16.11.
9-Methyl-4-methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-carbonitrile (7b): From
6b, 50% (reaction temperature 150 °C, time 10 min), yellow needles, mp 287—291 °C. IR (KBr): 
1705, 2214 cm-1. 1H-NMR : 2.65 (3H, s, 9-Me), 3.09 (3H, s, SMe), 7.12 (1H, t, J=7.0, 7-H), 7.46 (1H,
br d, J=7.0 Hz, 8-H), 9.02 (1H, br d, J=7.0 Hz, 6-H). Anal. Calcd for C13H9N3O2S: C, 57.55; H, 3.34; N,
15.49. Found: C, 57.44; H, 3.26; N, 15.69.
7,9-Dimethyl-4-methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-carbonitrile
(7c):
From 6c, 42% (reaction temperature 200 °C, time 20 min), yellow needles, mp >300 °C. IR (KBr):
1667, 2212 cm-1. 1H-NMR : 2.44 (3H, s, 7-Me), 2.61 (3H, s, 9-Me), 3.08 (3H, s, SMe), 7.32 (1H, s,
8-H), 8.80 (1H, br s, 6-H). Anal. Calcd for C14H11N3O2S: C, 58.93; H, 3.89; N, 14.73. Found: C, 58.63;
H, 3.88; N, 15.01.
Ethyl 4-methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-carboxylate (7d): From 6d,
59% (reaction temperature 100 °C, time 15 min), yellow needles, mp 172—175 °C. IR (KBr): 1703
cm-1. 1H-NMR : 1.42 (3H, t, J=7.2 Hz, OCH2CH3), 2.63 (3H, s, SMe), 4.43 (2H, q, J=7.2 Hz,
OCH2CH3), 7.13 (1H, ddd, J=7.0, 7.0, 1.2 Hz, 7-H), 7.54 (1H, ddd, J=9.0, 7.0, 1.2 Hz, 8-H), 7.73 (1H, br
d, J=9.0 Hz, 9-H), 9.17 (1H, br d, J=7.0 Hz, 6-H). 13C-NMR : 14.01, 17.79, 62.31, 105.99, 112.06,
114.50, 117.71, 127.06, 129.49, 145.37, 145.83, 156.52, 157.42, 164.96. Anal. Calcd for C14H12N2O4S:
C, 55.25; H, 3.97; N, 9.21. Found: C, 55.25; H, 4.07; N, 9.50.
Ethyl 9-methyl-4-methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-carboxylate (7e):
From 6e, 65% (reaction temperature 100 °C, time 20 min), yellow needles, mp 164—167 °C. IR (KBr):
1709 cm-1. 1H-NMR : 1.42 (3H, t, J=7.2 Hz, OCH2CH3), 2.61 (3H, s, 8-Me), 2.62 (3H, s, SMe), 4.43

HETEROCYCLES, Vol. 80, No. 1, 2010
451
(2H, q, J=7.2 Hz, OCH2CH3), 7.05 (1H, t, J=7.0, 7.0 Hz, 7-H), 7.35 (br d, J=7.0 Hz, 8-H), 9.01 (1H, br d,
J=7.0 Hz, 6-H). 13C-NMR : 14.12, 17.00, 17.91, 62.32, 106.41, 112.16, 114.41, 124.73, 128.05,
128.58, 145.31, 146.05, 156.33, 157.50, 164.85. Anal. Calcd for C15H14N2O4S: C, 56.59; H, 4.43; N,
8.80. Found: C, 56.52; H, 4.34; N, 8.97.
Ethyl 7,9-dimethyl-4-methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-carboxylate
(7f): From 6f, 73% (reaction temperature 100 °C, time 90 min), yellow needles, mp 181—184 °C. IR
(KBr): 1693 cm-1. 1H-NMR : 1.42 (3H, t, J=7.1 Hz, OCH2CH3), 2.41 (3H, s, 7-Me), 2.60 (3H, s,
9-Me), 2.62 (3H, s, SMe), 4.43 (2H, q, J=7.1 Hz, OCH2CH3), 7.21 (1H, br s, 8-H), 8.81 (1H, br s, 6-Me).
13C-NMR : 14.14, 16.89, 17.91, 18.61, 62.29, 106.33, 111,76, 122.71,124.37, 127.17, 131.63, 144.97,
145.37, 156.28, 157.58, 165.01. Anal. Calcd for C16H26N2O4S: C, 57.82; H, 4.85; N, 8.43. Found: C,
57.78; H, 4.78; N, 8.54.
3-Benzoyl-4-methylthio-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-2-one (7g): From 6g, 59%
(reaction temperature 50 °C, time 20 min), orange needles, mp 161—164 °C. IR (KBr): 1655, 1696
cm-1. 1H-NMR : 2.44 (3H, s, SMe), 7.14 (1H, ddd, J=7.0, 7.0, 1.4 Hz, 7-H), 7.46—7.52 (2H, m,
Phenyl-H), 7.56 (1H, ddd, J=9.0, 7.0, 1.2 Hz, 8-H), 7.58—7.64 (1H, m, Phenyl-H), 7.86—7.91 (2H, m,
Phenyl-H), 8.29 (1H, br d, J=7.0 Hz, 5-H). Anal. Calcd for C18H12N2O3S+H2O: C, 61.01; H, 3.98; N,
7.91. Found: C, 60.87; H, 4.24; N, 7.79.
3-Benzoyl-9-methyl-4-methylthio-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-2-one (7h): From 6h,
66% (reaction temperature 100 °C, time 15 min), orange needles, mp 193—196 °C. IR (KBr): 1697
cm-1. 1H-NMR : 2.42 (3H, s, SMe), 2.67 (3H, s, 9-Me), 7.04 (1H, t, J=7.0, 7.0 Hz, 7-H), 7.36 (1H, br d,
J=7.0 Hz, 8-H), 7.44—7.51 (2H, m, Ph-H), 7.57—7.63 (1H, m, Ph-H), 7.95—8.00 (2H, m, Ph-H), 9.06
(1H, br d, J=7.0 Hz, 6-H). Anal. Calcd for C19H14N2O3S: C, 65.13; H, 4.03; N, 7.99. Found: C, 65.04; H,
3.97; N, 8.14.
3-Benzoyl-7,9-dimethyl-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-2-one (7i’): From 6i, 34%
(reaction temperature 100 °C, time 45 min), orange needles, mp 250—252 °C. IR (KBr): 1641,
1716 cm-1. 1H-NMR : 2.42 (3H, s, 7-Me), 2.62 (3H, s, 9-Me), 7.28 (1H, br s, 8-H), 7.41—7.48 (2H, m,
Ph-H), 7.52—7.59 (1H, m, Ph-H), 7.76—7.82 (2H, m, Ph-H), 8.03 (1H, br s, 6-H), 8.56 (1H, s, 4-H).
13C-NMR : 16.72, 18.21, 100.37, 107.97, 113.16, 120.74, 125.12, 127.65, 128.03, 128.97, 132.49,
133.11, 133.95, 137.67, 146.33, 159.12, 160.68, 192.40. Anal. Calcd for C19H14N2O3: C, 71.69; H, 4.43;
N, 8.80. Found: C, 71.83; H, 4.33; N, 8.77.
7,9-Dimethyl-4-methylthio-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridin-2-one (7l’): From 6l, 16%
(reaction temperature 100 °C, time 30 min), yellow needles, mp 222—226 °C. IR (KBr): 1701 cm-1.

452
HETEROCYCLES, Vol. 80, No. 1, 2010
1H-NMR  DMSO-d6): 2.38 (3H, s, 7-Me), 2.58 (3H, s, 9-Me), 2.64 (3H, s, SMe), 5.71 (1H, s, 3-H),
7.12 (1H, br s, 8-H), 8.35 (1H, br s, 6-H). Anal. Calcd for C13H12N2O2S: C, 59.98; H, 4.65; N, 10.76.
Found: C, 60.27; H, 4.64; N, 10.48.
Crystallography of 3-[Bis(methylthio)methylene]-6,8-dimethyl-2(3H)-imidazo[1,2-a]pyridinone (4c)
A red prismatic single crystal (0.82×0.28×0.24 mm) grown from CHCl3-hexane was used for the unit-cell
determinations and data was collected using a Rigaku AFC5S four-circle diffractometer with
graphite-monochromated MoKradiation (=0.71069 Å). The crystal data of this compound are as
follows: 4c: C12H14N2OS2; M=266.38; monoclinic, space group P21/n (#14), Z=4 with a=10.95(3) Å,
b=10.388(14) Å, c=11.518(14) Å, =105.97(14)o, V=1259.8(38) Å3 and Dcalc.=1.404 g/cm3. All
calculations were performed using CrystalStructure.28 The structure was solved by a direct method
(SIR).29 The non-hydrogen atoms were refined anisotropically, and the hydrogen atoms were attached at
the idealized position and not refined. The final R- and Rw-factors after full-matrix least-squares
refinements were 0.048 and 0.039 respectively for 1897 (I>2.00observed reflections.
Crystallography of ethyl 4-methylthio-2-oxo-2H-pyrano[2’,3’:4,5]imidazo[1,2-a]pyridine-3-
carboxylate (7d)
A yellow prismatic single crystal (0.82×0.68×0.32 mm) grown from CHCl3 was
used for the unit-cell determinations and data was collected using a Rigaku AFC5S four-circle
diffractometer with graphite-monochromated MoKradiation (=0.71069 Å). The crystal data of this
compound are as follows: 3c: C14H12N2O4S; M=304.32; triclinic, space group P-1(#2), Z=2 with
a=7.959(13) Å, b=13.19(2) Å, c=7.116(13) Å, =103.98(16)o, =104.73(14)o, =75.74(13)o,V=687.2(19)
Å3 and Dcalc.=1.471 g/cm3. All calculations were performed using CrystalStructure.28 The structure
was solved by a direct method (SIR).29 The non-hydrogen atoms were refined anisotropically, and the
hydrogen atoms were attached at the idealized position and not refined. The final R- and Rw-factors after
full-matrix least-squares refinements were 0.076 and 0.068 respectively for 2383 (I>2.00observed
reflections.
REFERENCES
1. Preparation of new nitrogen-bridged heterocycles. 66. For part 65 of this series, see H. Isawa, A.
Kakehi, and H. Suga, Heterocycles, 2009, 78, 319.
2. A. S. Howard, In Comprehensive Heterocyclic Chemistry II; ed. by A. R. Katritzky, C. W. Rees, and
E. V. F. Scriven; Pergamon Press: London, 1996; Vol. 8, pp. 262―274; Chapter 10 and references
cited therein.
3. L. Almirante, A. Mugnaini, N. De Toma, A. Gamba, and W. Murmann, J. Med. Chem., 1970, 13,
1048.

HETEROCYCLES, Vol. 80, No. 1, 2010
453
4. A. Gueiffier, S. Mavel, M. Lhassani, A. Elhakmaoui, R. Snoeck, G. Andrei, O. Chavignon, J.-C.
Teulade, M. Witvrouw, J. Balzarini, E. de Clercq, and J.-P. Chapat, J. Med. Chem., 1998, 41, 5108.
5. C. Enguehead, J.-N. Renou, H. Allouchi, J.-M. Leger, and A. Gueiffier, Chem. Pharm. Bull., 2000,
48, 935.
6. Y. Ito, K. Takuma, H. Mizoguchi, T. Nagai, and K. Yamada, J. Pharm. Ex. Therap., 2007, 320, 819.
7. N. Donora, V. Laquintana, M. G. Pisu, R. Dore, L. Murru, A. Latrofa, G. Trapani, and E. Sanna, J.
Med. Chem., 2008, 51, 6876.
8. R. B. Lacerda, C. K. F. de Lima, L. L. da Silva, N. C. Romeiro, A. N. P. Miranda, E. J. Barreiro, and
C. A. M. Fraga, Bioorg. Med. Chem., 2009, 17, 74.
9. A. E. Tschitschibabin, Chem. Ber., 1924, 57, 2092.
10. A. E. Tschitschibabin, Chem. Ber., 1925, 58, 1704.
11. S. Ide, K. Katou, T. Itou, C. Motokawa, Y. Chiyomaru, and Y. Matsuda, Yakugaku Zasshi, 1993,
113, 861.
12. J. Wang, R. Mason, D. VanDerveer, K. Feng, and X. R. Bu, J. Org. Chem., 2003, 68, 5415.
13. M. Adib, E. Sheibani, L.-G. Zhu, and P. Mirzaei, Tetrahedron Lett., 2008, 49, 5108.
14. A. Kakehi, S. Ito, K. Watanabe, M. Kitagawa, S. Takeuchi, and T. Hashimoto, J. Org. Chem., 1980,
45, 5100.
15. A. Kakehi, S. Ito, K. Nakanishi, K. Watanabe, and M. Kitagawa, Bull. Chem. Soc. Jpn., 1980, 53,
1115.
16. A. Kakehi, S. Ito, B. Wada, K. Watanabe, K. Nishimura, and A. Kumagai, Bull. Chem. Soc. Jpn.,
1982, 55, 3590.
17. A. Kakehi, S. Ito, T. Ohizumi, and M. Ito, Bull. Chem. Soc. Jpn., 1983, 56, 1219.
18. A. Kakehi, S. Ito, and H. Muranaka, J. Fac. Eng. Shinshu Univ., 1994, 75, 31.
19. A. Kakehi, S. Ito, and H. Muranaka, Bull. Chem. Soc. Jpn., 1994, 67, 2795.
20. K. Kurata, H. Awaya, Y. Tominaga, Y. Matsuda, and G. Kobayashi, Yakugaku Zasshi, 1981, 101,
980.
21. Y. Tamura, Y. Sumida, Y. Miki, and M. Ikeda, J. Chem. Soc., Perkin I, 1975, 406.
22. A. Kakehi, S. Ito, M. Ito, T. Yotsuya, and K. Nagata, Bull. Chem. Soc. Jpn., 1985, 58, 1432.
23. Y. Tominaga, Y. Shiroshita, and A. Hosomi, J. Heterocycl. Chem., 1988, 25, 1745.
24. C. K. Johnson, "ORTEO II, Report ORNL-5138," Oak Ridge National Laboratory, Oak Ridge,
Tennessee, 1976.
25. Only compound 6l was measured in DMSO-d6 because of its low solubility.
26. F. Krönke, Ber. deut. chem. Ges., 1935, 68, 1177.
27. Y. Tominaga, Y. Miyake, H. Fujito, Y. Matsuda, and G. Kobayashi, Yakugaku Zasshi, 1977, 97,

454
HETEROCYCLES, Vol. 80, No. 1, 2010
927.
28. CrystalStructure 3.8: Crystal Structure Analysis Package, Rigaku and Rigaku/MSC (2000—2006).
9009 New Trails Dr. The Woodlands TX 77381 USA.
29. SIR92: A. Altmare, G. Cascarano, C. Giacovazzo, A. Guagliardi, M. Burla, G. Polridori, and M.
Camalli, J. Appl. Cryst., 1994, 27, 435.
