Discovery of A-971432, an Orally Bioavailable Selective
Sphingosine-1-Phosphate Receptor 5 (S1P5) Agonists for
the Potential Treatment of Neurodegenerative Disorders
Adrian D Hobson, Christopher M Harris, Elizabeth van der Kam, Sean C Turner, Ayome Abibi, Ana L
Aguirre, Peter Bousquet, Tegeste Kebede, Donald B Konopacki, Gary Gintant, Youngjae Kim, Kelly Larson,
John Maull, Nigel S Moore, Dan Shi, Anurupa Shrestha, Xiubo Tang, Peng Zhang, and Kathy K Sarris
J. Med. Chem., Just Accepted Manuscript • DOI: 10.1021/acs.jmedchem.5b00928 • Publication Date (Web): 28 Oct 2015
Downloaded from http://pubs.acs.org on November 2, 2015
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
Journal of Medicinal Chemistry is published by the American Chemical Society. 1155
Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 37
Journal of Medicinal Chemistry
1
2
3
4
5
6
7
8
9
Discovery of Aꢀ971432, an Orally Bioavailable
Selective Sphingosineꢀ1ꢀPhosphate Receptor 5
(S1P5) Agonists for the Potential Treatment of
Neurodegenerative Disorders
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Adrian D. Hobson,*a Christopher M. Harris,a Elizabeth L. van der Kam,c Sean C. Turner,c
Ayome Abibi,a,d Ana L. Aguirre,b Peter Bousquet,a Tegest Kebede,a Donald B. Konopacki,a
Gary Gintant,b Youngjae Kim,a Kelly Larson,b John W. Maull,a Nigel S. Moore,a Dan Shi,a
Anurupa Shrestha,b Xiubo Tang,e Peng Zhange and Kathy K. Sarris.b
a AbbVie Bioresearch Center, 381 Plantation Street, Worcester, Massachusetts 01605, United States
b AbbVie, Inc., 1 North Waukegan Road, North Chicago, Illinois 60064, United States
c AbbVie Deutschland GmbH & Co KG, Knollstrasse 50, 67061, Ludwigshafen, Germany
d Now at Cellular Biology, R&D, Firmenich, Inc, Alexandria Center 450 E 29th, New York, NY 10016
e
Shanghai ChemPartner Co. Ltd. Building 10, 998 Halei Road, Zhangjiang HiꢀTech Park, Pudong New Area,
Shanghai, China, 201203
KEYWORDS Selective S1P5 agonist, Neurodegenerative Disorders, Aꢀ971432
ABSTRACT S1P5 is one of 5 receptors for sphingosineꢀ1ꢀphosphate and is highly expressed on
endothelial cells within the bloodꢀbrain barrier, where it maintains barrier integrity in in vitro
models.1 Little more is known about the effects of S1P5 modulation due to the absence of tool
molecules with suitable selectivity and drugꢀlike properties. We recently reported that molecule
Aꢀ9714322 (29 in this paper) is highly efficacious in reversing lipid accumulation and ageꢀrelated
cognitive decline in rats.3 Herein we describe the development of a series of selective S1P5
agonists that led to the identification of compound 29, which is highly selective for S1P5 and has
excellent plasma and CNS exposure after oral dosing in preꢀclinical species. In order to further
ACS Paragon Plus Environment
1

Journal of Medicinal Chemistry
Page 2 of 37
1
2
3
4
5
6
7
8
9
support its suitability for in vivo studies of S1P5 biology, we extensively characterized 29,
including confirmation of its selectivity in pharmacodynamic assays of S1P1 and S1P3 function
in rats. In addition, we found that 29 improves bloodꢀbrain barrier integrity in an in vitro model
and reverses ageꢀrelated cognitive decline in mice. These results suggest that S1P5 agonism is an
innovative approach with potential benefit in neurodegenerative disorders involving lipid
imbalance and/or compromised bloodꢀbrainꢀbarrier, such as Alzheimer’s disease or Multiple
Sclerosis.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
INTRODUCTION
The pleiotropic signaling factor sphingosineꢀ1ꢀphosphate is recognized by a family of 5 receptors
called S1P1, S1P2, S1P3, S1P4 and S1P5.4 Synthetic agonists of S1P1 drive lymphocyte
sequestration and immune suppression.5 Most notably, the proꢀdrug FTY720 (Fingolimod)
reduces relapse rate and lesion activity in multiple sclerosis, and it also results in cardiovascular
events.6 In addition to agonizing S1P1, the phosphorylated form of FTY720 activates S1P3, S1P4
and S1P5.5 Many other chemotypes of S1P1 agonists interact with multiple S1P receptors,
especially S1P5.7 S1P5 is most highly expressed in the central nervous system, particularly on
oligodendrocytes and brain endothelium.1,8 Activation of S1P5 on brain endothelial cells
enhances barrier integrity and reduces transendothelial migration of monocytes in vitro.1 There is
indirect evidence that some of the efficacy of Gilenya in models of multiple sclerosis is from a
direct, neuroprotective effect within the CNS.9 Based on the findings above, we hypothesized
that a selective S1P5 agonist may be efficacious for neurodegenerative disorders. If so, the lack
of S1P1ꢀdriven immune suppression and cardiovascular effects would be advantageous. There
are previous reports of selective S1P5 agonists,10 but our profiling indicates these have
insufficient pharmacodynamic properties to establish S1P5 target validation in vivo (see Results
section). Herein we describe the optimization of the first S1P5 agonists with the selectivity and
drugꢀlike properties to interrogate S1P5 biology in vitro and in vivo.
RESULTS AND DISCUSSION
To test the hypothesis that a selective S1P5 agonist would be efficacious for neurodegenerative
disorders it would require a compound with the requisite potency as an S1P5 agonist, selectivity
profile, primarily at the other S1P family receptors and PK properties to enable once daily oral
dosing. However, at the offset of this project there were no such selective S1P5 agonists reported
in the literature and so a medicinal chemistry program was initiated to identify such a compound
to enable POC studies. Cognizant of Sir James Black’s famous comment that the best way to
find a new drug is to start with an existing one, we decided to leverage the experience from our
sphingosineꢀ1 phosphate receptor agonist program. This was a very successful collaboration
with the University of Virginia based on the S1P1 chemical matter discovered by Macdonald et
al at UVA.11 As part of this project we identified12 cyclopentyl amino alcohol compound 1.
This compound is phosphorylated on the hydroxyl of the amino alcohol in vivo affording a
highly potent S1P1 receptor agonist 2. This meant that to enable in vitro SAR in this drug series
the amino alcohols had to be phosphorylated in an additional synthetic step prior to screening.
To facilitate a more rapid screening cascade a replacement for the amino alcohol “head group”
was therefore desired.
ACS Paragon Plus Environment
2

Page 3 of 37
Journal of Medicinal Chemistry
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. Structures of literature S1P1 agonists
