Chemistry of iminofurans. New example of unusual aza-Wittig reaction at lactone carbonyl group

Full text of DOI:10.1134/S1070428010060291

ISSN 1070-4280, Russian Journal of Organic Chemistry, 2010, Vol. 46, No. 6, pp. 936–937. © Pleiades Publishing, Ltd., 2010.
Original Russian Text © N.Yu. Lisovenko, A.E. Rubtsov, 2010, published in Zhurnal Organicheskoi Khimii, 2010, Vol. 46, No. 6, pp. 935–936.
SHORT
COMMUNICATIONS
Chemistry of Iminofurans. New Example of Unusual Aza-Wittig
Reaction at Lactone Carbonyl Group
N. Yu. Lisovenko and A. E. Rubtsov
Perm State University, ul. Bukireva 15, Perm, 614990 Russia
e-mail: rubtsov@psu.ru
Received December 15, 2009
DOI: 10.1134/S1070428010060291
Aza-Wittig reaction provides a convenient method
for building up a new carbon–nitrogen double bond
[1, 2]. Three examples of the aza-Wittig reaction in-
volving lactone carbonyl group were reported, where
the substrates were substituted 3-methylidene-5-phen-
yloxazol-2-ones [3] and 5-aryl-2,3-dihydrofuran-2,3-
diones [4, 5]. In the present work we used as substrate
5-aryl-2,3-dihydrofuran-2,3-diones Ia–Ic having
a bulky substituent in position 4 of the furan ring.
Presumably, initial nucleophilic attack by phospha-
zine II at the lactone carbonyl group in the furan ring
gave zwitterionic intermediate which underwent rear-
rangement into spiro-fused oxazaphosphetidine A.
Elimination of triphenylphosphine oxide from struc-
ture A afforded compound III. The classical Wittig re-
action of compound Ia with methyl phosphanylidene-
acetate was also reported to give product of addition at
the lactone carbonyl group despite the presence of
other carbonyl groups in the substrate molecule [6].
Prolonged storage of a solution of IIIa in toluene
resulted in the formation of 4-benzoyl-1-(9H-fluoren-
9-ylideneamino)-5-phenyl-2,3-dihydro-1H-pyrrole-
2,3-dione (IV) whose spectral parameters were con-
sistent with published data for structurally related com-
pounds synthesized previously by other methods [7].
The reactions of 4-benzoyl-5-phenyl-2,3-dihydro-
furan-2,3-dione (Ia) and 5-aryl-4-(3-arylquinoxalin-2-
yl)-2,3-dihydrofuran-2,3-diones Ib and Ic with
9H-fluoren-9-one (triphenyl-λ5-phosphanylidene)hy-
drazone (II) gave 4-benzoyl-5-phenyl-2,3-dihydro-
furan-2,3-dione 2-(9H-fluoren-9-ylidene)hydrazone
(IIIa) and 5-aryl-4-(3-arylquinoxalin-2-yl)-2,3-dihy-
drofuran-2,3-dione 2-(9H-fluoren-9-ylidene)hydra-
zones IIIb and IIIc.
4-Benzoyl-2-[N′-(9H-fluoren-9-ylidene)hydra-
zono]-5-phenyl-2,3-dihydrofuran-3-one (IIIa). A so-
O
O
PPh3
Ar
R
O
N
+
N
N
R
O
N
PPh3
Ar
O
O
Ia–Ic
II
A
O
Ph
O
Ph
O
Ar
N
N
N
N
–Ph3P=O
Ar = Ph, R = Bz
O
R
O
IIIa–IIIc
IV
Ar = Ph, R = Bz (a), 3-phenylquinoxalin-2-yl (b); Ar = 4-MeC6H4, R = 3-(4-methylphenyl)quinoxalin-2-yl (c).
936

CHEMISTRY OF IMINOFURANS. NEW EXAMPLE OF UNUSUAL AZA-WITTIG
937
lution of 2.78 g (10 mmol) of compound Ia [8] and
4.54 g (10 mmol) of phosphorane II in 30 ml of anhy-
drous toluene was kept for 24 h at room temperature,
and the precipitate was filtered off and recrystallized
from toluene. Yield 4.04 g (89%), yellow crystals,
mp 170–171°C (from toluene). IR spectrum, ν, cm–1:
1693 (C3=O), 1646 (PhCO), 1601, 1589, 1565 (C=C,
tals, decomposition point 176–177°C (from toluene).
IR spectrum, ν, cm–1: 1766 (C2=O), 1706 (C3=O), 1654
1
(PhCO), 1596, 1579 (C=C, C=N). H NMR spectrum:
δ 7.2–8.2 ppm, m (18H, Harom). Found, %: C 79.30;
H 3.96; N 6.20. C30H18N2O3. Calculated, %: C 79.28;
H 3.99; N 6.16.
The IR spectra were recorded on an FSM-1201
spectrometer from samples dispersed in mineral oil.
1
C=N). H NMR spectrum: δ 7.27–8.38 ppm, m (18H,
1
H
arom). Found, %: C 79.24; H 4.00; N 6.17.
The H NMR spectra were measured on a Varian
C30H18N2O3. Calculated, %: C 79.28; H 3.99; N 6.16.
Mercury Plus-300 instrument at 300 MHz using
DMSO-d6 as solvent and HMDS as internal reference.
The purity of the isolated compounds was checked,
and the progress of reactions was monitored, by TLC
on Silufol UV-254 plates using diethyl ether–benzene–
acetone (10:9:1) as eluent.
5-Phenyl-4-(3-phenylquinoxalin-2-yl)-2-[N′-(9H-
fluoren-9-ylidene)hydrazono]-2,3-dihydrofuran-3-
one (IIIb). A solution of 0.76 g (2 mmol) of furan-
dione Ib [9] and 0.9 g (2 mmol) of phosphorane II in
30 ml of anhydrous benzene was kept for 24 h at room
temperature. The mixture was evaporated, and the resi-
due was recrystallized from acetonitrile. Yield 0.80 g
(72%), orange crystals, mp 216–218°C (from aceto-
nitrile). IR spectrum, ν, cm–1: 1704 (C3=O), 1622
(C=N). 1H NMR spectrum, δ, ppm: 7.27–8.25 m (22H,
This study was performed under financial support
by the Russian Foundation for Basic Research (project
no. 08-03-00448).
REFERENCES
H
arom). Found, %: C 80.14; H 4.03; N 10.08.
1. Palacios, F., Alonso, C., Aparicio, D., Rubiales, G., and
Santos, J.M., Tetrahedron, 2007, vol. 63, p. 523.
2. Gusar’, N.I., Usp. Khim., 1991, vol. 60, p. 285.
3. Gelmi, M.L., Pocar, D., Viziano, M., Destro, R., and
Merati, F., J. Chem. Soc., Perkin Trans. 1, 1992, p. 701.
4. Andreichikov, Yu.S., Shurov, S.N., Zalesov, V.V., and
Shapet’ko, N.N., Zh. Org. Khim., 1986, vol. 22, p. 854.
5. Zalesov, V.V., Pulina, N.A., and Andreichikov, Yu.S.,
Zh. Org. Khim., 1989, vol. 25, p. 1054.
6. Ungoren, S.H., Sacmaci, M., Akcamur, Y., Arici, C., and
Ulku, D., J. Heterocycl. Chem., 2004, vol. 41, p. 151.
7. Kollenz, G., Igel, H., and Ziegler, E., Monatsh. Chem.,
C37H22N4O2. Calculated, %: C 80.13; H 4.00; N 10.10.
5-(4-Methylphenyl)-4-[3-(4-methylphenyl)quin-
oxalin-2-yl]-2-[N′-(9H-fluoren-9-ylidene)hydra-
zono]-2,3-dihydrofuran-3-one (IIIc) was synthesized
in a similar way from compounds Ic and II. Yield
0.88 g (75%), orange crystals, mp 208–210°C (from
acetonitrile). IR spectrum, ν, cm–1: 1692 (C3=O), 1600
1
(C=N). H NMR spectrum, δ, ppm: 2.34 s (3H, Me),
2.35 s (3H, Me), 7.09–8.26 m (20H, Harom). Found, %:
C 80.41; H 4.51; N 9.60. C39H26N4O2. Calculated, %:
C 80.39; H 4.50; N 9.62.
4-Benzoyl-1-(9H-fluoren-9-ylideneamino)-
5-phenyl-2,3-dihydro-1H-pyrrole-2,3-dione (IV).
A solution of 2.27 g (5 mmol) of compound IIIa in
20 ml of toluene was kept for 10 days at room tem-
perature. It was then cooled to –20°C, and the precip-
itate was filtered off. Yield 1.8 g (79%), dark red crys-
1972, vol. 103, p. 450.
8. Ziegler, E., Eder, M., Belegratis, C., and Prewedoura-
kis, E., Monatsh. Chem., 1967, vol. 98, p. 2249.
9. Maslivets, A.N., Lisovenko, N.Yu., Golovnina, O.V.,
Vostrov, E.S., and Tarasova, O.P., Khim. Geterotsikl.
Soedin., 2000, p. 556.
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 46 No. 6 2010
