5070
M. Gianotti et al. / Bioorg. Med. Chem. Lett. 20 (2010) 5069–5073
R3
introducing zwitterion moieties to known H1/5-HT2A antagonist
scaffolds.7 This approach led Hypnion to quickly progress several
compounds into the clinical phase, one of which, HY-10275 (LY-
2624803), successfully achieved its Proof of Concept as a sleep
drug.8
Herein we report our results applying the zwitterionic approach
that led to the identification of several advanced leads with excel-
lent developability profiles.
A novel synthetic pathway was put in place for the synthesis of
the compounds reported in this paper; in particular the first two
steps that allow access to the key intermediate 4 (Scheme 1)
proved critical.
The first step is the crucial one, in particular for substituted imi-
dazoles 2c–g, in order to obtain the target cycloketone 4 with the
desired regiochemistry of substituents R and R1. Imidazole 2a
and symmetric dimethyl imidazole 2b, were reacted with 1 in
DMF, without the use of any additional base, to give the correspon-
dent alkylated imidazoles 3a and 3b.
R3
A
R
H
N
N
R2
R2
[ ]n
N
N
[ ]n
N
i
ii
4
N
iii
N
N
R
R1
8 - 22
R1
5: R2 = R3 = H, n = 1
6: R2 = R3 = H, n = 2
7: R2 = R3 = Me (cis), n = 1
Scheme 2. Reagents and conditions: (i) appropriate piperazine derivative (see
Table 1), TMSOTf, 130°C, 2 h; (ii) appropriate ester (A, see Tables 1), DCE,
NaBH(OAc)3, rt, 12 h; (iii) KOH or LiOH, MeOH/H2O; reflux, 3 h.
on the tricyclic portion of the compound, in particular on the imid-
azole ring, with the aim to mask and reduce its basicity.
All the newly prepared chemical entities were assayed for their
agonistic and antagonistic properties using two kinds of functional
assays: FLIPR11 (fluorescent imaging plate reader) assays, using
either adherent transfected Chinese hamster ovary (CHO) cells
stably expressing the recombinant human H1 receptor or adherent
SHSY5Y cells stably expressing recombinant human 5-HT2B or
5-HT2C receptors; luminescence12 (aequorin) assays using either
frozen Chinese hamster ovary (CHO) cells stably expressing the
human H1 receptor and aequorin apo-protein or frozen human
embryonic kidney (HEK) cells stably expressing the human 5-
HT2A, 5-HT2B, or 5-HT2C receptors and aequorin apo-protein.
Before going into a detailed discussion of the results obtained, a
few general observations need to be made. No agonistic activity
was observed for any of the amino acids considered; high selectiv-
ity versus 5-HT2B and 5-HT2C receptors proved elusive, however
this was not considered a criterion to preclude compound progres-
sion. While there are few evidences of slight increases in wakeful-
ness and motor activity after blockade of the 5-HT2B receptor,13 no
significant alteration in the percentage distribution of any sleep
Subsequent cyclization with LDA gave 4a and 4b, respectively,
exploiting the acidity of the hydrogen in the 2-position of the imid-
azole. Regarding the mono-substituted imidazoles, two approaches
were developed for the selective syntheses of the imidazole deriv-
atives 3. To obtain the 5-substituted benzyl imidazoles 3c, 3d, and
3g, at least as the major regioisomers, we employed the same base
free conditions as reported above, while for the 4-substituted ben-
zyl imidazoles 3e and 3f, we were able to obtain high levels of
selectivity by introducing a base to the reaction mixture. An optimi-
zation process was required for this reaction as the bases examined
initially, such as K2CO3 and NaH, allowed formation of the desired
4-substituted product with satisfactory selectivity but in low yield
as these bases promoted oligomerisation of the bromoester 1. This
problem was overcome by the use of a Verkade proazaphosphatra-
ne9 base to effect the alkylation. This nonionic reagent is a strong
base readily able to deprotonate the imidazole and hence favors
the 4-substituted products but it is a very weak Lewis acid and
therefore avoids the oligomerisation side reaction. The ring closure
step of compounds 3c–g, to the corresponding tricyclic ketones
4c–g, was carried out using LDA as described for 4a,b. The ketones
4 obtained were then treated with trimethylsilyl triflate (TMSOTf)
in the presence of the appropriate piperazine derivative to give
the intermediates 5, 6 and 710 (Scheme 2). The amino acid side
chain was introduced either by means of a reductive amination
reaction or, in the case of compounds 8 and 11, an aza-Michael
reaction of the intermediates 5a and 7a, respectively, with an acry-
late. Compound 12 was synthesized using methyl 2-(bromo-
methyl)-2-propenoate. Finally, hydrolysis of the esters furnished
the desired final zwitterionic compounds 8–22 (see Table 1).
The SAR exploration was principally focused on three elements:
first, substitution/homologation of the piperazine in order to study
the influence of the most basic center of the compounds; second,
modulation of the acidic moiety; third, introduction of substituents
stage, arousal and light SWS (SWS1), was observed with the inhi-
14
bition of the 5-HT2C
.
Therefore the presence of 5-HT2B and 5-
HT2C activity in our compounds may not represent a potential issue
for their hypnotic profile. With regards to selectivity versus adren-
ergic a1A and a1B receptors, which was a concern for our initial hit
5a (Fig. 1), for the zwitterionic compounds synthesized and tested
in this assay, we never observed any significant activity on these
two receptors.15
From the outset of our exploration we noticed that in terms of
activity versus the primary targets the zwitterionic modification
always led to a reduction of both H1 and 5-HT2A activities, but
while a suitable level of potency is generally maintained at H1, po-
tency at 5-HT2A is much more sensitive, thus since the beginning it
was clear that the challenge for the exploration was to find com-
pounds with balanced H1/5-HT2A activity. The first two zwitter-
ionic compounds in the table are testimony to this behavior.
Compound 8 shows good H1 activity while its 5-HT2A activity is
unsatisfactory for progression. In contrast, compound 9, character-
O
O
N
O
O
ized by additional geminal dimethyl groups
a to the acidic moiety
O
2
N
i or ii
iii
that have the dual function of increasing lipophilicity and ‘mask-
ing’ the acid, demonstrates good H1/5-HT2A activity and selectivity
versus 5-HT2B but not versus 5-HT2C. Due to its good overall
in vitro profile, compound 9 was progressed into a rat pharmacoki-
netics (PK) study,16 see Table 2. It showed moderate blood clear-
ance, moderate volume of distribution, a half-life of 0.7 h and
good oral bioavailability. Compound 9 was also characterized by
a high brain fraction unbound (>50%) and low brain penetration
(0.02). As a result of this low brain penetration there is a substan-
tial imbalance between the free drug concentrations in the brain
and in the blood (free blood concentrations ꢀ50-fold higher than
N
4
HN
+
N
R
5
N
4a-g
R
R1
R
1
3a-g
R1
Br
2a-g
a: R=H, R1=H
R1
e: R=Cl, R1=H
b: R=Me, R1=Me f: R=F, R1=H
c: R=Me, R1=H g: R=H, R1=OMe
d: R=H, R1=Cl
Scheme 1. Reagents and conditions: (i) (used for compounds 3a, 3b, 3c, 3d, and 3g)
DMF, room temperature, 8 h; (ii) (used for compounds 3e and 3f) THF, Verkade’s
Superbase, room temperature, 2 h; (iii) THF, LDA, from À78 °C to room temperature,
12 h.
