F. Pisaneschi et al.
a pipette. The gamma-counting tubes were placed in a gamma counter
and analysed for 1 min each.
(2E)-N-{4-[(3-Chloro-4-fluorophenyl)amino]-3-cyano-7-ethoxyquinolin-
6-yl}-4-[({1-[3-fluoro-4,5-dihydroxy-6-(hydroxymethyl)oxan-2-yl]-1H-1,2,
3-triazol-4-yl}methyl)amino]but-2-enamide (5)
1H NMR (500 MHz, D2O) δ 8.88 (s, 1H), 8.64 (s, 1H), 8.41 (s, 1H), 7.56 (dd,
J = 2.2, 6.4, 1H), 7.38–7.31 (m, 2H), 7.25 (s, 1H), 6.85 (dt, J = 6.7, 15.3, 1H),
6.58 (d, J = 15.5, 1H), 6.06 (dd, J = 2.6, 9.0, 1H), 4.87 (dt, J = 50.6, 9.0, 1H),
4.47 (s, 2H), 4.33 (q, J = 7.0, 2H), 4.03–3.94 (m, 3H), 3.85 (d, J = 10.5, 1H),
3.77–3.64 (m, 2H), 3.60 (t, J = 9.4, 1H), 1.47 (t, J = 7.0, 3H); 13C NMR
(126 MHz, D2O) δ 164.7 (s), 160.5 [s, (d, JCF = 352.5),] 155.6 (s), 154.5 (s),
151.3 (s), 148.2 (d), 138.3 (s), 137.6 (s), 134.2 (d), 133.1 (s), 129.7 (d),
In vitro cell uptake
A431 and MCF7 cells were seeded 48 h prior to the experiment in
complete Dulbecco’s modified Eagle’s medium in triplicate wells of six-
well plates at densities of 4 × 105 and 3 × 105 cells per well, respectively.
On the day of the experiment, cells were incubated with 0.55 MBq
(15 μCi) of [18F]5 for 60 min at 37 °C. After incubation, the excess
radioactivity was washed from the cells twice with PBS. Cells were
trypsinised and transferred into a counting tube. Following centrifugation
at 5000 rpm for 2 min at 4 °C, the obtained cell pellet was resuspended in
lysis buffer, and counts were measured on a gamma counter. The decay-
corrected counts per minute acquired were normalised to the protein
levels by carrying out a bicinchoninic acid assay.
129.5 (d), 128.6 (s), 127.7 [d, (d, JCF = 8.1)], 126.0 (d), 117.5 [d, (d, JCF
22.8)], 114.2 (d), 111.4 (s), 101.5 (d), 90.4 [d, (d, JCF = 187.5)], 85.6 (s),
84.7 [d, (d, JCF = 24.1)], 79.0 (s), 74.1 [d, (d, JCF = 16.5)], 68.5 [d, (d, JCF
=
=
8.0)], 66.6 (t), 66.5 (d), 60.1 (t), 46.9 (t), 40.9 (t), 13.4 (q); HR-MS (ESI) calcd
for C31H32ClF2N8O6: 685.2101, found 685.2109 (Δ 1.2 ppm); MS (ESI): m/z
(%) 685 [MH+] (20).
Results and discussion
Radiochemistry
In order to improve the pharmacokinetic properties of our
cyanoquinoline tracer while retaining high metabolic stability, we
synthesised a glycosylated triazole cyanoquinoline [18F]5, which
was designed to be radiolabelled by ‘click’ chemistry with the
prosthetic group 2-[18F]fluoro-2-deoxy-β-D-glucopyranosyl azide
([18F]6) (Figure 2).[11a] Not only have 2-[18F]fluoro-2-deoxy-β-D-
glucopyranosyl triazoles been found to be metabolically stable,
but also, incorporation of these moieties have been reported
previously to improve the in vivo properties of PET radiotracers,
such as [18F]fluorodeoxyglucose folate.12 Furthermore, the
calculated distribution coefficient of cyanoquinoline 5 (logDpH
7.4 = 2.40)7 appeared to be more favourable for PET imaging of
somatic lesions.
Unlabelled reference compound 5 was obtained by Cu(I)-
catalysed Huisgen cycloaddition (the ‘click’ reaction) between
2-fluoro-2-deoxy-β-D-glucopyranosyl azide 6 and the N-Boc-
protected alkynylcyanoquinoline 7 (Scheme 1) followed by
deprotection with concentrated HCl–dioxane in 69% overall
yield. Building blocks 6 and 7 were synthesised following
literature procedures.6,11
Synthesis of [18F]6
Aqueous [18F]fluoride (2 mL) was trapped on a QMA cartridge and eluted
with a mixture of Kryptofix-2.2.2 (400μL of a 12 mg/mL stock solution in
water), K2CO3 (100 μL of an 18 mg/mL stock solution in water) and KH2PO4
(100μL of a 18 mg/mL stock solution in water). [18F]Fluoride was dried at
105°C under a stream of nitrogen. MeCN (0.5 mL) was added and
distillation continued. After cooling at room temperature, triflate precursor
8 (3 mg) in acetonitrile (300 μL) was added. This procedure was performed
automatically on the Advion Nanotek platform. The mixture was delivered
into an external heating block and heated at 80 °C for 5 min. The mixture
was then diluted in water (8 mL), and the activity was trapped on a Sep-
Pak light tC18 cartridge (Waters), which was then washed with water
(5 mL). Activity as eluted in a vial with MeCN (2 mL) and concentrated at
80 °C under a stream of He (flow rate 20 mL/min) in ~10 min. NaOH
(60 mM, 250 μL) was added and the mixture heated at 80 °C for 10 min
then neutralised with HCl (60 mM, 250 μL).
Synthesis of [18F]5
A mixture of CuSO4.5H2O (50 μL of a 34.8 mg/mL stock solution in water),
sodium ascorbate (50 μL of a 174 mg/mL stock solution in phosphate-
buffered saline (PBS)), bathophenanthroline disulfonic acid disodium salt
(BPDS) (2.5 mg in 20 μL of PBS) and alkyne 10 (1 mg in 25 μL of water and
25 μL of MeCN) was added to [18F]6, and the mixture was left at room
temperature for 5 min. [18F]5 was isolated by semi-preparative HPLC
[Phenomenex Luna C18 150 × 10 mm HPLC column, isocratic mobile
phase of 20% MeCN/water (5 mM H3PO4), flow rate 3 mL/min]. The HPLC
solution was diluted with water (5 mL) and the activity trapped on a Sep-
Pak light C18 cartridge (Waters, preconditioned with 5 mL of EtOH and
10 mL of PBS). The cartridge was washed with water (5 mL) and the
activity eluted in EtOH/PBS: 1,1.
Figure 2. Epidermal growth factor receptor glycosylated ‘click’ cyanoquinoline
[
18F]5.
Epidermal growth factor receptor tyrosine kinase enzyme inhibition
assay
Epidermal growth factor receptor tyrosine kinase enzyme inhibition
assay was performed as reported in the literature.6
LogD determination
To 50 μL of
[
18F]5 formulated in 10% EtOH in PBS, 450 μL of
preequilibrated PBS and 500 μL of preequilibrated n-octanol were added.
The mixture was vortexed for 20 s before centrifugation at 15 krpm for
3 min. To each of five Eppendorf tubes, 75 μL from the upper n-octanol
layer, 175 μL of preequilibrated n-octanol and 250 μL of preequilibrated
PBS were added. The Eppendorf tubes were vortexed and centrifuged
as earlier. From the upper n-octanol layer, 100 μL was transferred to a
gamma-counting tube with a pipette. The lower PBS layer was first
transferred with a syringe fitted on a thin needle to a second Eppendorf
tube from which 100 μL was transferred to a gamma-counting tube with
Scheme 1. Synthesis of reference compound 5. Reagents and conditions: a)
CuSO4.5H2O, Na ascorbate, water, CH3CN, r.t., 12 h. b) 10% concentrated HCl in
dioxane, r.t., 10 min (69% overall yield).
