Article
4-(7-Hydroxyimidazo[2,1-b]benzothiazol-2-yl)-N,N-dimethyl-
Journal of Medicinal Chemistry, 2011, Vol. 54, No. 4 955
Weber, and Elisabeth Aiwanger for excellent technical support,
Antje Willuweit, Michael Schoor, and Heinzvon der Kammer
for provision of APP/PS1 (Arte10) animals, Prof. Johannes
Buchner and his group for electron microscopy of amyloid
aggregates and Prof. Axel Walch and Andreas Voss for excellent
technical support for fluorescence microscopy. This work was
supported by grants from Deutsche Forschungsgemeinschaft
(DFG) (Nos. HE4560/1-2, DR 445/3-1, and DR 445/4-1),
IRTG 1373 and Elite Network of Bavaria.
benzenamine (4c). Compound 3c (97 mg, 0.3 mmol) was reacted
with BBr3 following a procedure similar to that for compound
4a. The crude product was recrystallized from MeOH (87 mg,
90% yield) and used further for 11C-methylation reaction. LC-
MS-ESI [M þ 1] =310.1; DMSO-d6 1H NMR δ 2.89 (6H,s), 5.88
(1H,s), 6.26 (1H,s) 6.77 (2H,d), 7.65 (2H,d), 7.88 (1H,m), 8.41
(1H, s), 9.85 (1H, s); DMSO-d6 13C NMR δ 38.0, 107.4, 111.6,
113.3, 114.5, 114.9, 125.5, 128.6, 129.3, 130.2, 133.3, 134.6,
136.8, 147.3, 155.8.
4-(7-Methoxyimidazo[2,1-b]benzothiazol-2-yl)-benzenamine (4d).
A mixture of the nitro derivative 3e (321 mg, 0.99 mmol) and SnCl2
(5 equiv, 690 mg) in 20 mL of EtOH was heated for 2 h at reflux
temperature under nitrogen. The reaction mixture was concentrated
under vacuum, and the residue was taken up in 200 mL of ethyl
acetate, the organic phase was washed with 1 M NaOH solution,
followed by water, and subsequently dried over sodium sulfate, and
the solution was concentrated. The crude product was purified by
flash chromatography in DCM/methanol; then the solvents were
evaporated under reduced pressure and dried under high vacuum
(223 mg, 73% yield with HPLC purity of >98%) and directly used
as precursor for radiosynthesis of [11C]5. LC-MS-ESI [M þ 1] =
296.1; DMSO-d6 1H NMR δ 3.81 (3H,s), 5.16 (2H, s), 6.61 (2H,d),
7.11 (1H,dd) 7.48 (2H,d), 7.63 (1H,d), 7.82 (1H,d), 8.37 (1H, s);
DMSO-d6 13C NMR δ 55.8, 106.2, 109.4, 113.5, 113.9, 121.9, 125.6,
130.2, 145.5, 147.2, 148.0, 156.6).
Supporting Information Available: The experimental part of
HPLC purity measurements, animal studies, PET imaging, ex
vivo evaluation, general procedures for radiosynthesis, general
procedures for measurement of log P, and general procedures
for metabolite analyses. This material is available free of charge
References
(1) Selkoe, D. J. Toward a comprehensive theory for Alzheimer’s
disease. Hypothesis: Alzheimer’s disease is caused by the cerebral
accumulation and cytotoxicity of amyloid beta-protein. Ann. N.Y.
Acad. Sci. 2000, 924, 17–25.
(2) Klunk, W. E. Biological markers of Alzheimer’s disease. Neurobiol.
Aging 1998, 19 (2), 145–147.
(3) Selkoe, D. J. Alzheimer’s disease: Genes, proteins, and therapy.
Physiol. Rev. 2001, 81 (2), 741–766.
(4) Selkoe, D. J. Imaging Alzheimer’s amyloid. Nat. Biotechnol. 2000,
18 (8), 823–824.
Alternatively, 4d was prepared by deprotection of 3d under
microwave heating conditions with 2 M NaOH at 100 °C for 30
min in 81% yield.
(5) Wang, Y.; Klunk, W. E.; Debnath, M. L.; Huang, G. F.; Holt,
D. P.; Shao, L.; Mathis, C. A. Development of a PET/SPECT agent
for amyloid imaging in Alzheimer’s disease. J. Mol. Neurosci. 2004,
24 (1), 55–62.
(6) Mathis, C. A.; Wang, Y.; Klunk, W. E. Imaging beta-amyloid
plaques and neurofibrillary tangles in the aging human brain. Curr.
Pharm. Des. 2004, 10, 1469–1492.
(7) Weiner, M. W. Editorial: Imaging and biomarkers will be used for
detection and monitoring progression of early Alzheimer’s disease.
J. Nutr. Health Aging 2009, 13 (4), 332–333.
(8) Yang, T.; Arslanova, D.; Gu, Y.; Augelli-Szafran, C.; Xia, W.
Quantification of gamma-secretase modulation differentiates in-
hibitor compound selectivity between two substrates Notch and
amyloid precursor protein. Mol. Brain 2008, 1, 15.
(9) Imbimbo, B. P. Therapeutic potential of gamma-secretase inhibi-
tors and modulators. Curr. Top. Med. Chem. 2008, 8, 54–61.
(10) Wolfe, M. S. Inhibition and modulation of gamma-secretase for
Alzheimer’s disease. Neurotherapeutics 2008, 5, 391–398.
(11) Wolfe, M. S. Gamma-secretase inhibition and modulation for
Alzheimer’s disease. Curr. Alzheimer Res. 2008, 5, 158–164.
(12) Ikonomovic, M. D.; Klunk, W. E.; Abrahamson, E. E.; Mathis,
C. A.; Price, J. C.; Tsopelas, N. D.; Lopresti, B. J.; Ziolko, S.; Bi,
W.; Paljug, W. R.; Debnath, M. L.; Hope, C. E.; Isanski, B. A.;
Hamilton, R. L.; DeKosky, S. T. Post-mortem correlates of in vivo
PiB-PET amyloid imaging in a typical case of Alzheimer’s disease.
Brain 2008, 131, 1630–1645.
(13) Rowe, C. C.; Ackerman, U.; Browne, W.; Mulligan, R.; Pike, K. L.;
O’Keefe, G.; Tochon-Danguy, H.; Chan, G.; Berlangieri, S. U.;
Jones, G.; Dickinson-Rowe, K. L.; Kung, H. P.; Zhang, W.; Kung,
M. P.; Skovronsky, D.; Dyrks, T.; Holl, G.; Krause, S.; Friebe, M.;
Lehman, L.; Lindemann, S.; Dinkelborg, L. M.; Masters, C. L.;
Villemagne, V. L. Imaging of amyloid beta in Alzheimer’s disease
with 18F-BAY94-9172, a novel PET tracer: proof of mechanism.
Lancet Neurol. 2008, 7 (2), 129–135.
2-(p-Methylaminophenyl)-7-methoxyimidazo[2,1-b]benzothia-
zole (5). Compound 4d (295 mg, 1 mmol) was dissolved in DMF
(10 mL) and treated with potassium carbonate (anhydrous, 2
equiv, 280 mg). One equivalent of methyl iodide was added to
the mixture at 80 °C. The reaction mixture was cooled to room
temperature, 50 mL of water was added, and the resulting mixture
was extracted with dichloromethane (3ꢀ50 mL). The combined
organic phase was washed with brine, dried over sodium sulfate,
and concentrated. The crude product was purified by flash chr-
omatography. (108 mg, 35% yield with HPLC purity of>98%).
ESI-MS [Mþ1]=310.1; 1H NMR (DMSO-d6) δ 2.7 (d, J=5 Hz,
3H), 3.3 (s, 3H), 5.7 (br s, 1H), 6.6 (d, J=8.5 Hz, 2H), 7.1 (q, JA=
8.5, JB=2.5 Hz, 1H), 7.6 (m,4H), 8.4 (s, 1H); 13C NMR (DMSO-
d6) δ 30.2, 56.3, 106.8, 109.9, 112.1, 114.1, 118.8, 122.2, 126.1,
126.6, 130.7, 146.1, 147.6, 149.7, 157.1.
4-(7-Hydroxyimidazo[2,1-b]benzothiazol-2-yl)-benzenamine (6).
The compound 4d (59 mg, 0.2 mmol) was reacted with BBr3
and workup following a procedure similar to that for 4a, which
afforded the product (52 mg, 93% yield in>98% HPLC purity)
confirmed by LC-MS-ESI [M þ 1] =282.1; DMSO-d6 1H NMR
δ 7.02 (1H,dd), 7.39 (4H,m) 7.85 (3H,m), 8.07 (1H,dd), 8.85 (1H,
s); DMSO-d6 13C NMR δ 94.8, 108.0, 109.7, 114.4, 117.3, 123.0,
125.5, 130.5, 140.5, 142.5, 146.2, 155.7.
2-(p-Methylaminophenyl)-7-hydroxyimidazo[2,1-b] benzothia-
zole (7). The compound 5 (62 mg, 0.2 mmol) was reacted with 1.5
mol equiv of BBr3 (1 M solution) in 5 mL of dichloromethane
under microwave heating at 150 °C for 30 min. The reaction
mixture was quenched with 10 mL of 1 N HCl and extracted
with 3 ꢀ 10 mL of CH2Cl2. The combined organic phase was
washed with saturated sodium bicarbonate solution (20 mL),
dried over sodium sulfate, and evaporated. The product (45 mg,
76% yield in >98% HPLC purity) was confirmed by LC-MS-
(14) Nordberg, A. Amyloid plaque imaging in vivo: Current achieve-
ment and future prospects. Eur. J. Nucl. Med. Mol. Imaging 2008,
35 (Suppl. 1), S46–50.
1
(15) Drzezga, A.; Grimmer, T.; Henriksen, G.; Stangier, I.; Perneczky,
R.; Diehl-Schmid, J.; Mathis, C. A.; Klunk, W. E.; Price, J.;
DeKosky, S.; Wester, H.-J.; Schwaiger, M.; Kurz, A. Imaging of
amyloid plaques and cerebral glucose metabolism in semantic
dementia and Alzheimer’s disease. Neuroimage 2008, 39, 619–633.
(16) Zhang, W.; Kung, M. P.; Oya, S.; Hou, C.; Kung, H. F. 18F-labeled
styrylpyridines as PET agents for amyloid plaque imaging. Nucl.
Med. Biol. 2007, 34, 89–97.
ESI [M þ 1] = 296.1; H NMR (500 MHz, DMSO-d6) δ 8.33
(1H, s), 7.72 (1H, J = 8.7, 0.4 Hz, dd), 7.57 (2H, J =8.7 Hz, d),
7.34 (1H, J =2.4, 0.4 Hz, dd), 6.93 (1H, J =2.9, 0.4 Hz, dd), 6.57
(2H, J =9.1 Hz, d), 3.33 (1H, s), 2.70 (3H, s); 13C NMR (126
MHz, DMSO-d6) δ 155.2, 150.5, 148.3, 147.4, 130.6, 126.4,
126.0, 125.5, 122.3, 114.7, 112.2, 111.3, 106.7, 30.4.
(17) Small, G. W.; Kepe, V.; Barrio, J. R. Seeing is believing: Neuroi-
maging adds to our understanding of cerebral pathology. Curr.
Opin. Psychiatry 2006, 19, 564–569.
Acknowledgment. We thank Katrina McGuire, Janette M.
Carlsen, Andrea Alke, Markus Sirl, Sybille Reder, Axel
