The syntheses of a novel 1,4,8,11,15,18,22,25-octahexyloxy-2,3,9,10,16,17,23,24-octa-(4-trifluo romethoxyphenyl) phthalocyanine (3a) and its zinc(II) phthalocyanine derivative (3b) have been described and characterized by elemental analysis,1H NMR, 13C NM

Full text of DOI:10.3390/molecules24010077

molecules
Article
Novel Hexadeca-Substituted Metal Free and Zinc(II)
Phthalocyanines; Design, Synthesis and
Photophysicochemical Properties
2
Ayoub I. Awaji 1, Baybars Köksoy 2 , Mahmut Durmus¸ , Ateyatallah Aljuhani 1 and
Shaya Y. Alraqa 1,
*
1
Department of Chemistry, Taibah University, Al-Madinah Al Munawrah, P.O. Box 344, Saudi Arabia;
a-awaji@hotmail.com (A.I.A.); ateyatallah@hotmail.com (A.A.)
Department of Chemistry, Gebze Technical University, 41400 Gebze, Kocaeli, Turkey;
baybarsky@gmail.com (B.K.); durmus@gtu.edu.tr (M.D.)
2
*
Correspondence: sqahtani@taibahu.edu.sa; Tel.: +966-507-738-708
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 4 November 2018; Accepted: 21 December 2018; Published: 26 December 2018
Abstract: The syntheses of a novel 1,4,8,11,15,18,22,25-octahexyloxy-2,3,9,10,16,17,23,24-octa-(4-trifluo
romethoxyphenyl) phthalocyanine (3a) and its zinc(II) phthalocyanine derivative (3b) have been
described and characterized by elemental analysis,1H NMR, 13C NMR, 19F NMR, mass, UV-Vis
and FT-IR. The newly prepared metal-free phthalocyanine and its zinc(II) counterpart are soluble
in most organic solvents. The photophysical and photochemical properties such as aggregation,
fluorescence, singlet oxygen generation and photodegradation under light irradiation of these
phthalocyanines have been investigated in DMF. The hexadeca-substituted phthalocyanines (3a and
3b) showed longer absorption and emission wavelength values when compared to that of reported
phthalocyanine derivatives due to substitution of the all possible positions in the phthalocyanine
framework. The zinc(II) phthalocyanine derivative does not only have a good singlet oxygen
generation but also has other photophysicochemical properties that enables this phthalocyanine to be
useful as a photosensitizer for cancer treatment using photodynamic therapy.
Keywords: phthalocyanine; Suzuki-coupling; photophysical; photochemical; photodynamic therapy
1. Introduction
Phthalocyanines (Pcs) are a family of aromatic macrocycles with delocalized 18-
system and are also known as useful functional materials due to their high stability and outstanding
chemical and physical properties [ ]. These unique properties have lead them to be used in many
applications in different scientific and technological areas such as chemical sensors [ ], catalysis [ ],
liquid crystals [ ], photodynamic therapy of cancer [ ], solar energy conversion [ ], nonlinear
optics [ ], semiconductors [ ], and optical data storage [10]. Zinc phthalocyanine derivatives are
π electrons
1
2
3
4
5,
6
7
8
9
candidates for use as photosensitizing agents in the photodynamic therapy (PDT) of certain cancers
because they have long triplet lifetimes and are highly efficient in photogeneration of cytotoxic
singlet oxygen [11]. Also, closed-shell and diamagnetic metal ions such as zinc(II), aluminum(III) and
silicon(IV) produce metallophthalocyanine derivatives having both long lifetimes and high triplet
yields which are also good candidates for photocatalytic applications such as PDT [12].
Hexadeca-substituted phthalocyanines are relatively less studied compared to tetra- or
octa-substituted counterparts [13,14]. These phthalocyanines are also useful compounds for PDT [15],
catalyst [16], optical materials [17], and Langmuir-Blodgett films [18]. Recently these types of
phthalocyanines have become a focus of interest for PDT because of their red-shifted absorptions and
Molecules 2019, 24, 77; doi:10.3390/molecules24010077
www.mdpi.com/journal/molecules

Molecules 2019, 24, 77
2 of 13
their existence in one isomeric form (peripheral and non-peripheral tetra phthalocyanines form isomer
mixtures) [19 20]. The wavelength of light used in PDT applications is generally within in the range of
,
550 and 860 nm. The second-generation photosensitizers show high absorption in this wavelength range,
and their deep-tissue accumulations are quite high compared to the first generation photosensitizers.
Pcs, are known as second generation PDT sensitizers, have excellent photochemical properties due to
their high singlet oxygen production capacity and intense absorption in the far red-near IR spectral
region (600–850 nm) with a high extinction coefficient. Also, the used light at this wavelength region
is not harmful to healthy cells in the body due to their lower energy. In our previously study, the
1,4,8,11,15,18,22,25-octahexyloxy-2,3,9,10,16,17,23,24-octa-(3,5-dichlorophenyl)phthalocyaninato zinc(II)
synthesized. The photophysical properties of this zinc(II) phthalocyanine were determined by electronic
absorption in the UV-Vis region, fluorescence emission, nanosecond transient absorption and cyclic
voltammetry but the PDT properties of this zinc(II) phthalocyanine did not determined [21]. For these
reasons, novel hexadeca-substituted metal-free and zinc(II) phthalocyanines bearing hexyloxy groups
on the non-peripheral positions and (4-trifluoromethoxyphenyl) groups on the peripheral positions
of phthalocyanine ring were designed and synthesized in the present study. The photochemical and
photophysical properties of these novel phthalocyanines were also investigated.
2. Results and Discussion
2.1. Synthesis and Characterization
The starting compound, 4,5-dibromo-3.6-dihydroxy phthalonitrile, (
to published procedure [22]. Phthalonitrile ( ) was prepared using the Suzuki coupling reaction
where 4,5-dibromo-3,6-dihexyloxyphthalonitrile ( ) was reacted with 4-trifluoromethoxyphenylboronic
acid (Scheme 1). This compound ( ) was purified by column chromatography resulting in a 45%
yield. The target metal-free phthalocyanine (3a) was synthesized by the cyclotetramerization of the
phthalonitrile ( ). The zinc(II) phthalocyanine derivative (3b) was synthesized by the addition of
1) was synthesized according
3
2
3
3
zinc(II) acetate to the metal-free phthalocyanine derivative (3a) (Scheme 1).
Scheme 1. Synthetic pathway of the novel hexadeca-substituted metal-free (3a) and zinc(II) (3b) phthalocyanines.
These novel phthalocyanines are soluble in common organic solvents such as toluene,
dichloromethane, CHCl3, THF, and DMF due to the hexadecasubstitution of the phthalocyanine

Molecules 2019, 24, 77
3 of 13
framework with hexyloxy groups on the non-peripheral positions and (4-trifluoromethoxyphenyl)
groups on the peripheral positions.
The FT-IR spectra clearly indicated the formation of phthalonitrile (
N stretching frequency at 2300 cm−1. The 1H-NMR spectrum showed that all the substituents and
ring protons were observed in their expected regions (Figure S1). For phthalonitrile ( ), the aromatic
region displayed two doublet peaks at 7.08 and 7.02 ppm attributed to the four aromatic protons on
3) due to the appearance of
C
≡
3
the phenyl substituents. The 13C-NMR spectrum of phthalonitrile (
3) confirmed that all aromatic and
aliphatic carbons are present in their expected regions (Figure S2). The 19F-NMR spectrum showed a
single peak at −57.83 ppm due to the -OCF3 group (Figure S3). The structure of the phthalonitrile (3)
was also confirmed by MALDI-TOF with the m/z value located at 649.70 as [M + H]+ (Figure S4).
The vibration peak for C N stretching of phthalonitrile (3) was not show in the FT-IR spectrum
≡
of phthalocyanine (3a), which provided important support for the formation of the phthalocyanine
derivative. The structure of the phthalocyanine (3a) was also confirmed by examination of the UV-Vis
spectrum because two absorption bands were observed in the Q band region of this phthalocyanine in
toluene (Figure 1a). These two Q bands were converted to a single narrow band after addition of zinc(II)
metal which is an indicator for the formation of zinc(II) phthalocyanine (3b) (Figure 1a). The 1H-NMR,
19F-NMR and 13C-NMR spectra of the novel phthalocyanines (3a) and (3b) also confirmed the target
structures of these phthalocyanines. For 1H-NMR spectra, all aromatic and aliphatic protons were
observed at their expected regions and integration of the peaks were found to be consistent with the
expected numbers of the protons (Figures S5 and S6). The 13C-DEPT NMR spectrum of (3a) and the
13C-NMR spectrum of (3b) confirmed that all aliphatic and aromatic carbon atoms appeared at their
expected regions (Figures S7 and S8). The 19F-NMR spectra showed a single peak at
both phthalocyanines (3a and 3b) (Figures S9 and S10). The molecular weight values of the novel
phthalocyanines (3a and 3b) were confirmed by MALDI-TOF and m/z values were located at 2596.54
and 2658.54 as [M]+ for these phthalocyanines, respectively (Figures S11 and S12).
−
57.94 ppm for
2.2. Electronic Absorption Spectra
Normally, while the metallophthalocyanine derivatives show single narrow Q band absorption in
the UV–vis absorption spectra due to their D4h symmetries, the metal-free phthalocyanines contain
two characteristic Q-bands owing to changing symmetries from D4h to D2h. But, the UV-Vis absorption
spectrum of the studied hexadeca-substituted metal-free phthalocyanine (3a) showed a single broad Q
band in DMF (Figure 1b) due to consist of a mixture of deprotonated/free base species in this solvent.
The deprotonation of the inner hydrogen atoms could be due to formation of hydrogen bond between
inner NH group and DMF molecules because of the basicity of DMF solvent (SB = 0.613) [23]. Similar
spectra were obtained in other solvents such as DMSO (SB = 0.647) and 1-pentanol (SB = 0.860) [23].
Easy deprotonation of phthalocyanine (3a)is probably due to distortion of the macrocycle. Also further
proof for deprotonation of the inner –NH protons was obtained by the addition of 0.05 mL 40%
tetrabutylammoniumhydroxide as a base to the solution of metal-free phthalocyanine (3a) in toluene
(Figure 1b). Only one Q band was observed after addition of base to the toluene solution of 3a indicating
that deprotonation occurred in the basic media like in DMF. The UV-Vis electronic absorption spectrum
of the zinc(II) phthalocyanine complex (3b) showed a characteristic single narrow absorption band
in the Q band region at 737 nm in DMF as expected. The molar absorption coefficients values of the
compounds (3a and 3b) were found to be 0.98
respectively. These obtained molar absorption coefficients are consistent with those values for
phthalocyanine derivatives given in the literature.
×
105 L
·
mol−1
·
cm−1 and 1.15
×
105 L
·
mol−1 cm−1
,
·

Molecules 2019, 24, 77
4 of 13
Figure 1. UV-vis absorption spectra of (a) 3a and 3b in toluene (b) 3a in DMF, toluene and by the
addition of tert-butylammoniumhydroxide as a base in the toluene solution.
2.3. Aggregation Studies
Aggregation is usually depicted as a coplanar association of rings progressing from monomer to
dimer and higher order complexes. It is dependent on the concentration, nature of the solvent, nature
of the substituents, complexed metal ions and temperature [24]. In this study, the aggregation behavior
of hexadeca-substituted metal-free (3a) and zinc(II) (3b) phthalocyanines were investigated at different
concentrations in DMF (Figure S13). The Beer-Lambert law was obeyed for all of these compounds
at concentrations ranging from 2–12 µM for determination of the most suitable concentration for
further photophysical and photochemical properties of the studied phthalocyanines (3a and 3b).
Both hexadeca-substituted phthalocyanines did not show any aggregation at these concentrations
range in DMF.
2.4. Fluorescence Studies
Figure S14 shows the fluorescence emission spectra of the novel phthalocyanines (3a and 3b).
The metal-free phthalocyanine derivative (3a) showed two peaks at 742 and 779 nm in DMF due to the
formation of protonated and deprotonated species in this solvent. The zinc(II) phthalocyanine (3b
)
showed only one emission peak at 750 nm as expected in DMF solution.
The fluorescence quantum yields (
determined in DMF. The metal-free phthalocyanine (3a) consists of a mixture of deprotonated/free
base species in DMF. The obtained F value for this phthalocyanine (3a) is related with the mixture
of these two species in DMF. The ΦF values of these phthalocyanines were found to be typical of
those for previously studied metal-free and zinc phthalocyanines [25]. While the F value of zinc(II)
ΦF) of the metal-free (3a) and zinc(II) (3b) phthalocyanines were
Φ
Φ
phthalocyanine (3b) (ΦF = 0.16) was found similar to the standard unsubstituted zinc phthalocyanine
(std-ZnPc) (ΦF = 0.17 [26]), the ΦF value of the metal-free derivative (3a) (ΦF = 0.09) was found
lower than std-ZnPc in DMF. The τF values of (3a and 3b) were also determined in DMF using

Molecules 2019, 24, 77
5 of 13
the time correlated single photon counting (TCSPC) technique. The related lifetime spectra for the
studied phthalocyanines obtained using this technique are shown in Figure S15. The phthalocyanine
derivatives (3a and 3b) exhibited typical mono-exponential decay curves in their lifetime spectra.
The τF value was found 3.17 ns for (3a) and 2.03 ns for (3b) which were lower than the τF of the
unsubstituted zinc(II) phthalocyanine (τF = 3.64 ns [26]) in DMF.
2.5. Singlet Oxygen Generation Measurements
Photodynamic therapy (PDT) is a method for treatment of cancer, which uses singlet oxygen generated
by a photosensitizer to destroy tumor cells. Pc derivatives are known as second generation photosensitizers
for PDT applications due to their high singlet oxygen generation abilities. The photosensitizer molecule is
excited to its singlet state and passes to its triplet state through intersystem crossing. The photosensitizer
molecule then transfers its energy to the ground state oxygen producing the excited singlet state
oxygen which is the chief cytotoxic species for cancer cells. The formed singlet oxygen subsequently
kills the tumor cells by a Type II mechanism [27]. The amount of the generated singlet oxygen is
quantified as singlet oxygen quantum yield (Φ∆). The Φ∆ values of the novel metal-free (3a) and
zinc(II) (3b) phthalocyanines were determined by using a chemical method for investigation of the
photosensitizer ability of phthalocyanines. 1,3-Diphenylisobenzofuran (DPBF) was used as a singlet
oxygen trap molecule for the determination of singlet oxygen generated by the novel phthalocyanines
(3a and 3b) in DMF. The disappearance of the DPBF absorbance at 417 nm in the presence of the novel
phthalocyanines by light irradiation was monitored using a UV–Vis spectrophotometer (Figure 2 for
3b and S16 for 3a). The Q band of the samples did not decompose and shifted during light irradiation
suggesting that both samples did not degrade by light during singlet oxygen measurements.
Figure 2. UV-Vis absorption spectral changes for the phthalocyanine 3b in the presence of DPBF during
−5
the determination of singlet oxygen quantum yield at a concentration of 1
1,3-Diphenylisobenzofuran (DPBF) absorbances versus time.
×
10 M in DMSO. Insets:
The Φ∆ values of the novel metal-free (3a) and zinc(II) (3b) phthalocyanines were found to be 0.10
and 0.53, respectively in DMF. The obtained Φ∆ value for metal-free phthalocyanine (3a) was obtained
as the value of the mixture of deprotonated/free base species because this phthalocyanine formed
a mixture of these two species in DMF. Both values were lower than standard unsubstituted zinc(II)
phthalocyanine (Φ∆ = 0.56 [26]). The zinc(II) phthalocyanine (3b) generated more singlet oxygen than
its metal-free counterpart (3a) due to presence of a closed shell d10 zinc(II) metal ion in the cavity of the
phthalocyanine (3b). It is known that diamagnetic metal ions enhance the singlet oxygen generation
ability of the phthalocyanine photosensitizers [27].

Molecules 2019, 24, 77
6 of 13
2.6. Photodegradation Studies
Degradation of the molecules under light irradiation is used to study their stability and this is
especially important for those molecules intended for use as photocatalysts. The photodegradation of
the studied metal-free (3a) and zinc(II) (3b) phthalocyanines were determined in DMF. The collapse
of the absorption spectra of these phthalocyanines without any distortion of the shape confirms
photodegradation is not associated with phototransformation into different forms of phthalocyanines
due to light irradiation (Figure 3 for 3b and S17 for 3a). The photodegradation rating is determined
as photodegradation quantum yields (
phthalocyanines (3a and 3b) (1.91
10−4 for 3a and 2.13
those obtained for phthalocyanine derivatives having different metals in their cavities and substituents
on the phthalocyanine ring [11 28]. The Φd value of metal-free phthalocyanine (3a) in DMF was
Φ
d). The Φd values are in the order of 10−4 for both novel
10−4 for 3b) and these values are similar to
×
×
,
obtained as the value of the mixture of deprotonated/free base species because this phthalocyanine
formed a mixture of these two species in this solvent. Stable zinc phthalocyanine molecules show
Φd values as low as 10−6 and unstable molecules show these values in the order of 10−3
[
11].
d values when compared to unsubstituted
[26]) suggesting that the substitution of the phthalocyanine
Both studied phthalocyanine derivatives showed higher
zinc(II) phthalocyanine (Φd = 0.23
10−4
Φ
×
macrocycle with hexyloxy groups on the peripheral positions and 4-trifluoromethoxyphenyl groups
on the non-peripheral positions of the phthalocyanine framework decreased the stability of the studied
phthalocyanine derivatives.
Figure 3. UV-Vis absorption spectral changes during the determination of photodegradation quantum
yield for phthalocyanine 3b in DMSO showing the disappearance of the Q band at 20 minutes intervals.
Inset: the plots of the phthalocyanine (Pc) absorbance versus time.
2.7. Fluorescence Quenching Studies by 1,4-Benzoquinone
The fluorescence quenching behavior of novel metal-free (3a) and zinc(II) (3b) phthalocyanines
by 1,4-benzoquinone (BQ) in DMF was found to obey Stern–Volmer kinetics, which is consistent
with diffusion controlled bimolecular reactions. As an example, Figure 4a shows the quenching
of (3b) by BQ in DMF see Figure S18 for (3a)). The slope of the plots shown at Figure 4b gave
Stern–Volmer constant (KSV) values for the novel hexadeca-substituted phthalocyanines (3a and 3b).
These values were found to be 17.82 M−1 and 22.79 M−1 for phthalocyanines (3a) and (3b), respectively.
The KSV values of the substituted metal-free (3a) and zinc(II) (3b) phthalocyanines in DMF were lower
than unsubstituted zinc(II) phthalocyanine (KSV = 31.90 M−1
[26]) suggesting that the substitution
decreased the interaction ability of the novel phthalocyanines to BQ. The bimolecular quenching rate
constant (kq) values of the substituted phthalocyanines (3a and 3b) were also determined and they

Molecules 2019, 24, 77
7 of 13
found to be 0.56
×
1010 M−1
·
s−1 for (3a) and 1.12
×
1010 M−1
·
s−1 for (3b) in DMF. The kq values of
the substituted phthalocyanines were also found lower than unsubstituted zinc(II) phthalocyanine
(
kq = 2.61 × 1010 M−1·vs−1 [26]). The kq values were found to be close to the diffusion-controlled
limits, ~ 1010 M−1 −1, which agrees with the Einstein–Smoluchowski approximation at room
s
·
temperature for diffusion-controlled bimolecular interactions [29].
(a)
Figure 4.
(
a
) Fluorescence emission spectral changes of 3b (1
×
10−5 M) by the addition of different
concentrations of BQ in DMF (Excitation wavelength = 700 nm) and (
1,4-benzoquinone (BQ) quenching of introduced metal-free and zinc(II) phthalocyanines. [MPc] = 1
M in DMF. [BQ] = 0, 0.008, 0.016, 0.024, 0.032 0.04 M.
b) Stern–Volmer plots f−o5r
×
10
3. Materials and Methods
3.1. Materials
All used chemicals and solvents were of reagent grade quality. The starting compound,
4,5-dibromo-3.6-dihydroxy phthalonitrile (1) was synthesized according to published procedure [22].
p-Trifluoromethoxyophenyl boronic acid, zinc(II) acetate, Cs2CO3 and Pd(PPh3)4 were purchased from
Sigma-Aldrich (St. Louis, MO, USA) and they were used as received. 1,3-Diphenylisobenzofuran
(DPBF) was purchased from Fluka (St. Louis, MO, USA). The used solvents were purified, dried and
stored over molecular sieves (4Å). All reactions were carried out under dry nitrogen atmosphere unless
otherwise noted. Column chromatography was performed on silica gel 60 for a proper purification of
the crude compound. Melting points of the phthalocyanine compounds were found to be higher than
300 ◦C. The purity of the products was tested in each step by thin layer chromatography (Silica gel
F-254 coated TLC plate).
3.2. Equipment
FT-IR spectra were recorded using KBr sample disks on a Schimadzu Fourier Transform
Infrared Spectrometer FTIR-400 (San Jose, CA, USA) and a Perkin Elmer Spectrum 100 spectrometer
(Waltham, MA, USA). 1H, 13C and 19F-NMR spectra of phthalocyanine derivatives were recorded
on a Bruker AVANCE 400 MHz spectrometer (Madison, MI, USA). UV-Vis spectra were recorded on

Molecules 2019, 24, 77
8 of 13
a Schimadzu 2101 UV/Vis spectrometer (Kyoto, Japan). Mass spectra were acquired on Microflex
MALDI-TOF mass spectrometer (Bruker Daltonics MS, Bremen, Germany) equipped with a nitrogen
UV-Laser operating at 337 nm and the spectra recorded in reflectron mode with average of 50 shots
using 2,5-dihydroxybenzoicacid (DHB) as a MALDI matrix. The samples for matrix-assisted laser
desorption/ionization (MALDI) were prepared by mixing sample solutions (1 mg/mL in DMF) and
the matrix solution (1:10 v/v) in a 0.5 mL Eppendorf® micro tube (Hamburg, Germany). Finally, 0.5
µL
of this mixture was deposited on the sample plate, dried at room temperature, and then analyzed.
Elemental analyses were performed by the Thermo Finnigan Flash 1112 Instrument (Waltham, MA,
USA). Fluorescence excitation and emission spectra (non-corrected) were recorded on a Varian Eclipse
spectrofluorometer using a 1 cm path length cuvette at room temperature. Photo-irradiations were
done using a General Electric quartz line lamp (300W). A 600 nm glass cut off filter (Schott) and a water
filter were used to filter off ultraviolet and infrared radiations, respectively. An interference filter (Intor,
700 nm with a band width of 40 nm) was additionally placed in the light path before the sample. Light
intensities were measured with a POWER MAX5100 (Los Angeles, CA, USA, Molelectron detector
incorporated) power meter.
3.3. Photophysical and Photochemical Parameters
3.3.1. Fluorescence Quantum Yields and Lifetimes
Fluorescence quantum yields (
Equation (1) [30],
Φ
F) were determined by the comparative method using
F × AStd × n2
ΦF = ΦF(Std)
(1)
FStd × A × n2Std
where F and FStd are the areas under the fluorescence emission curves of the samples (3a and 3b
)
and the standard, respectively. A and AStd are the respective absorbances of the samples (3a and
3b) and standard at the excitation wavelengths, respectively. n2 and nS2td are the refractive indices of
solvents used for the samples (3a and 3b) and standard, respectively. Unsubstituted ZnPc (ΦF = 0.17 in
DMF) [31] was employed as the standard. Fluorescence lifetimes were measured by a time correlated
single photon counting (TCSPC) method using FLUOROLOG-3 spectrofluorometer (Horiba JobinYvon,
Edison, NJ, USA) equipped with a NanoLED and a standard air cooled R928 PMT detector.
3.3.2. Singlet Oxygen Quantum Yields
Singlet oxygen quantum yields (
out using the experimental set-up described in the literature [26
phthalocyanine solutions (C = 1
10−5 M) containing the singlet oxygen quencher were irradiated in
the Q band region with the photo-irradiation set-up described in references [26 27]. Singlet oxygen
quantum yields ( ∆) were determined in air using the relative method using unsubstituted ZnPc (in
Φ
∆) of phthalocyanine compounds (3a and 3b) were carried
,27]. Typically, a 3 mL portion of
×
,
Φ
DMF) as a reference. DPBF was used as a chemical quencher for singlet oxygen in DMF. Equation (2)
was employed for the calculations:
Std
R × I
abs
Φ∆ = ΦS∆td
(2)
RStd×Iabs
The ΦS∆td is the singlet oxygen quantum yield for the standard unsubstituted ZnPc (Φ∆ = 0.56 in
DMF) [26]. R and RStd are the DPBF photobleaching rates in the presence of the respective samples
Std
(3a and 3b) and standard, respectively. Iabs and
I
are the rates of light absorption by samples (3a
abs
and 3b) and the standard, respectively. To avoid chain reactions induced by DPB−F5in the presence of
singlet oxygen, the concentration of the quencher (DPBF) was lowered to
∼
3
×
10 M [32]. Solutions
of the sensitizer and the standard (C = 1
×
10−5 M) containing DPBF were prepared in the dark and

Molecules 2019, 24, 77
9 of 13
irradiated in the Q band region using the photo-irradiation setup. DPBF degradation at 417 nm was
monitored. A light intensity of 6.60 × 1015 photons s−1 cm−2 was used for Φ∆ determinations.
3.3.3. Photodegradation Quantum Yields
Photodegradation quantum yield (Φd) determinations were carried out using the experimental
set-up described in literature [26
,
27]. Photodegradation quantum yields were determined using
Equation (3),
(C0 − Ct) × V × NA
Φd
=
(3)
Iabs × S × t
The C0 and Ct are the concentrations of phthalocyanine compounds (3a and 3b) before and after
irradiation, respectively, V is the reaction volume, NA is Avogadro’s constant, S is the irradiated cell
area, t is the irradiation time and Iabs is the overlap integral of the radiation source light intensity
and the absorption of the samples (3a and 3b). A light intensity of 2.20
employed for Φd determinations.
×
1016 photons s−1 cm−2 was
3.3.4. Fluorescence Quenching by 1,4-Benzoquinone (BQ)
Fluorescence quenching experiments on the substituted metal-free and zinc(II) phthalocyanines
(3a and 3b) were carried out by the addition of different concentrations of BQ to a fixed concentration of
the phthalocyanines, and the concentrations of BQ in the resulting mixtures were 0, 0.008, 0.016, 0.024,
0.032 and 0.040 M. The fluorescence spectra of substituted metal-free and zinc(II) phthalocyanines (3a
and 3b) at each BQ concentration were recorded, and the changes in fluorescence intensity related to
BQ concentration were determined by the Stern–Volmer (SV) Equation [33] (Equation (4)):
IO
I
= 1 + KSV[BQ]
(4)
The Io and I are the fluorescence intensities of fluorophore in the absence and presence of quencher,
respectively. KSV is the Stern–Volmer constant; and this is the product of the bimolecular quenching
constant (kq) and the fluorescence lifetime (τF) (Equation (5)):
KSV = kq × τF
(5)
The ratios Io/I were calculated and plotted against [BQ] according to Equation (4), and KSV
determined from the slope.
3.4. Synthesis
3.4.1. 4,5-Bis(4-trifloromethoxyphenyl)-3,6-bis(hexyloxy)phthalonitrile (3)
4,5-Dibromo-3,6-dihexyloxyphthalonitrile (100 mg, 0.205 mmol), 4-(trifluoromethoxy) phenyl
boronic acid (127 mg, 0.615 mmol), tetrakis (triphenylphosphine) palladium(0) complex (118 mg,
0.102 mmol) and cesium carbonate (668 mg, 2.1 mmol) as a base were added to a solution of toluene,
ethanol and water (v/v/v, 3:3:1) solvent mixture. The reaction mixture was heated at refluxing
temperature for 24 h with stirring under a nitrogen atmosphere. Then the solvent mixture was
removed under vacuum using rotary evaporator. The target phthalonitrile was isolated by column
chromatography with silica gel using hexane:THF (v/v, 10:1) solvent system as an eluent. Finally,
◦
the product was recrystallized from ethanol. Yield: 59.8 mg (45%). M.p. 150 C. FT-IR [ATR
ν
max/cm−1]: 3039 (Aromatic-CH), 2940-2856 (Aliphatic-CH), 2300 (C
≡
N), 1562 (Aromatic-C=C),
δ 7.08 (d, J = 8.6 Hz, 4H, Aromatic-CH), 7.02 (d, J = 8.6 Hz, 4H,
900 (C–F). 1H-NMR (400 MHz, CDCl3)

Molecules 2019, 24, 77
10 of 13
Aromatic-CH), 3.69 (t, J = 6.4 Hz, 4H, Aliphatic-CH), 1.42-1.33 (m, 4H, Aliphatic-CH), 1.16-1.06 (m,
4H, Aliphatic-CH), 1.05-0.98 (m, 8H, Aliphatic-CH), 0.8 (t, J = 7.06 Hz, 6H, Aliphatic-CH). 13C-NMR
(100 MHz, CDCl3) δ: 156.5 (Aromatic-C), 148.9 (Aromatic-C), 141.2 (Aromatic-C), 131.9 (Aromatic-C),
131.8 (Aromatic-C), 120.4 (Aromatic-C), 120.3 (1C, q, JC–F = 259 Hz, CF3)., 113.0 (Aromatic-C), 109.8
(Aromatic-C), 76.03 (Aliphatic-OCH2), 31.2 (Aliphatic-CH2), 29.6 (Aliphatic-CH2), 25.1 (Aliphatic-CH2),
22.3 (Aliphatic-CH2), 13.8 (Aliphatic-CH3). 19F- NMR (377 MHz, CDCl3)
δ -57.83 (C–F), Mass
(MALDI-TOF): m/z, Calcd. for C34H34N2F6O4; 648.64 g/mol, found; 649.70 [M + H]+. Anal Calc. for
C34H34N2F6O4: C, 62.96%; H, 5.28%; N, 4.32%. Found: C, 63.08%; H, 5.14%; N, 4.26%.
3.4.2. 1,4,8,11,15,18,22,25-Octakis(hexyloxy)-2,3,9,10,16,17,23,24-octakis(4-trifloro methoxyphenyl)
phthalocyanine (3a)
4,5-Bis(4-trifloromethoxyphenyl)-3,6◦-bis(hexyloxy) phthalonitrile (
3) (100 mg, 0.154 mmol) was
dissolved in 1-pentanol and heated at 160 C for 30 min, and then a small piece of Li was added to the
solution under argon atmosphere. Then, the reaction mixture was cooled to the room temperature
then a few drops of acetic acid were added to the solution to remove the metal (Li). The methanol
was added to precipitate the target phthalocyanine compound. Finally, a further purification was
done by silica gel column chromatography using hexane/ethyl acetate (v/v, 1:1) solvent system as an
eluent. Yield: 9 mg (18%). M.p. > 300 ◦C. FT-IR [ATR max/cm−1]: 3480 (-NH), 3037 (Aromatic-C-H),
ν
2964-2854 (Aliphatic C-H), 1540 (Aromatic-C=C). UV/Vis (DMF)
λ
max/nm (log
ε
): 339 (4.59), 397 (4.51),
1
665 (4.40), 731 (4.99). H-NMR (400 MHz, CDCl3)
δ 7.34 (d, J = 8.1 Hz, 16H, Aromatic-CH), 7.11 (d,
J = 8.1 Hz, 16H, Aromatic-CH), 4.64 (bs, 16H, Aliphatic-CH), 1.66-1.56 (m, 16H, Aliphatic-CH), 1.18-0.98
(m, 48H, Aliphatic-CH), 0.81-0.74 (m, 24H, Aliphatic-CH), 0.34 (s, 2H, NH). 13C-DEPT135 NMR (400
MHz, CDCl3)
δ: 133.3 (CH aromatic), 120.0 (CH aromatic), 76.8 (OCH2), 31.8 (CH2), 30.1 (CH2), 25.8
(CH2), 25.5 (CH2), 14.0 (CH3), 19F- NMR (377 MHz, CDCl3)
δ
-57.94 (C–F), Mass (MALDI-TOF): m/z:
Calcd. for C136H138N8F24O16; 2596.57 g/mol, found 2596.54 [M]+. Anal Calc. for C136H138N8F24O16:
C, 62.91%; H, 5.36%; N, 4.32%. Found: C, 63.11%; H, 5.45%; N, 4.40%.
3.4.3. 1,4,8,11,15,18,22,25-Octakis(hexyloxy)-2,3,9,10,16,17,23,24-octakis(4-trifloro methoxyphenyl)
phthalocyaninato zinc(II) (3b)
15 mg (0.00578 mmol) metal-free phthalocyanine derivative 3a was dissolved in 5 mL dry
DMF and 2.12 mg (0.01156 mmol) zinc(II) acetate was added to this solution. This reaction mixture
◦
was stirred and heated at 150 C about 12 h under argon atmosphere and then poured into water
after cooling to room temperature and centrifuged. The crude product was purified by column
chromatography using dichloromethane as an eluent. Yield: 12 mg (78%). FT-IR [ATR
ν
max/cm−1]:
λmax/nm (log
3039 (Aromatic-C-H), 2956-2856 (Aliphatic C-H), 1512 (Aromatic-C=C). UV/Vis (DMF)
1
ε
): 345 (4.45), 398 (4.33), 654 (4.33), 737 (5.06). H-NMR (400 MHz, CDCl3)
δ
7.45 (d, J = 8.1 Hz, 16H,
Aromatic-CH), 7.19 (d, J = 8.1 Hz, 16H, Aromatic-CH), 4.80 (bs, 16H, Aliphatic-CH), 1.73-1.67 (m,
16H, Aliphatic-CH), 1.32-1.08 (m, 48H, Aliphatic-CH), 0.91–0.84 (m, 24H, Aliphatic-CH). 13C-NMR
(100 MHz, CDCl3) δ: 152.4 (Aromatic-C), 148.1 (Aromatic-C), 137.2 (Aromatic-C), 133.1 (Aromatic-C),
132.2 (Aromatic-C), 130.8 (Aromatic-C), 119.6 (1C, q, JC–F = 259 Hz, CF3), 110.2 (Aromatic-C), 109.7
(Aromatic-C), 73.7 (Aliphatic-CH2), 31.8 (Aliphatic-CH2), 29.7 (Aliphatic-CH2), 25.8 (Aliphatic-CH2),
22.5 (Aliphatic-CH2), 13.8 (Aliphatic-CH2). 19F- NMR (377 MHz, CDCl3)
δ -57.94 (C–F), Mass
(MALDI-TOF): m/z: Calcd. for C136H136N8F24O16Zn; 2658.35 g/mol, found 2658.54 [M]+. Anal
Calc. for C136H136N8F24O16Zn: C, 61.41%; H, 5.15%; N, 4.21%. Found: C, 61.34%; H, 5.08%; N, 4.41%.
4. Conclusions
In conclusion, the novel hexadeca-substituted metal-free (3a) and zinc(II) (3b) phthalocyanines
bearing 4-trifluoromethoxyphenyl groups on the peripheral positions and hexyloxy groups
on the non-peripheral positions of the phthalocyanine macrocycle were synthesized. While
4-trifluoromethoxyphenyl groups were introduced by the Suzuki-Miyaura coupling reaction, hexyloxy

Molecules 2019, 24, 77
11 of 13
groups were attached to phthalocyanine ring by the Mitsunobu reaction. The novel phthalocyanines
1
were characterized by elemental analysis, H NMR, 13C NMR, 19F NMR, mass, UV-Vis and FT-IR.
The photophysical and photochemical properties such as aggregation, fluorescence quantum yields
and lifetimes, singlet oxygen generation and photodegradation under light irradiation of these novel
phthalocyanines were also investigated in DMF. These properties were determined as a mixture of
deprotonated/free base species of metal-free phthalocyanine (3a) in DMF because this phthalocyanine
formed a mixture of these two species in DMF. Both studied phthalocyanines showed excellent
solubility in common organic solvents such as toluene, dichloromethane, chloroform, THF and DMF.
These phthalocyanines exhibited light absorption at long wavelength in the UV-Vis spectra due to the
hexadeca-substitution. As a result of the photophysical and photochemical properties, the metal free
phthalocyanine (3a) and especially the zinc(II) phthalocyanine derivative (3b) can be considered as
candidates for photosensitizers in the treatment of cancer using the PDT technique due to the high
singlet oxygen generation ability of the phthalocyanine derivatives. In vitro cytotoxicity properties
and photodynamic activities of the studied phthalocyanines, especially(3b), will be tested against
different cancer cell lines including different carcinoma cells lines in future work.
1
Supplementary Materials: The following are available online. Figure S1: H-NMR spectrum of compound
3
in
CDCl3, Figure S2: 13C-NMR spectrum of compound
3
in CDCl3, Figure S3: 19F-NMR spectrum of compound
3
in CDCl3, Figure S4: MALDI-TOF spectrum of compound 3
in CDCl3, Figure S5: 1H-NMR spectrum of
compound 3a in CDCl3, Figure S6: H-NMR spectrum of compound 3b in CDCl3, Figure S7: 13C-NMR spectrum
1
of compound 3a in CDCl3, Figure S8: 13C-NMR spectrum of compound 3b in CDCl3, Figure S9: 19F-NMR
spectrum of compound 3a in CDCl3, Figure S10: 19F-NMR spectrum of compound 3b in CDCl3, Figure S11:
MALDI-TOF spectrum of compound 3a in CDCl3, Figure S12: MALDI-TOF spectrum of compound 3b in CDCl3,
Figure S13: UV–vis spectra of (a) 3a and (b) 3b in DMF at different concentration (C=2–12
Fluorescence emission spectra of (a) phthalocyanine 3a and (b) phthalocyanine 3b in DMF at 5
(Excitation wavelength = 686 nm for 3a and 700 nm for 3b), Figure S15: Time correlated single photon counting
(TCSPC) trace for (a) 3a (Excitation wavelength = 686 nm) and (b) 3b (Excitation wavelength = 700 nm) in DMF
with residuals, Figure S16: The electronic absorption spectral changes during the determination of singlet oxygen
µ
M), Figure S14:
×
10−6 M.
quantum yields. This determination was for 3a in DMF at a concentration of 1
×
10−5 M. (Inset: Plot of DPBF
absorbances versus time), Figure S17: The electronic absorption spectral changes of 3a in DMF under light
irradiation showing the disappearance of the Q-band (Inset: plot of phthalocyanine absorbances versus time),
Figure S18: Fluorescence emission spectral changes of 3a (1
of BQ in DMF.
×
10–5 M) by the addition of different concentrations
Author Contributions: A.I.A., A.A. and S.Y.A. did the synthesis part and all experiments related and
characterizations; B.K. and M.D. carried out the photophysical and photochemical properties part. All of the
authors wrote and revised the paper.
Funding: This research received no external funding.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
Leznoff, C.C.; Lever, A.B.P. Phthalocyanines: Properties and Applications; Wiley-VCH: New York, NY, USA,
1989; Volume 3.
Bouvet, M.; Gaudillat, P.; Suisse, J.M. Phthalocyanine-based hybrid materials for chemosensing. J. Porphyr.
Phthalocyanines 2013, 17, 913–919. [CrossRef]
Zhao, J.L.; Guo, S.H.; Qiu, J.; Gou, X.F.; Hua, C.W.; Chen, B. Iron(III) phthalocyanine-chloride-catalyzed
synthesis of sulfones from sulfonylhydrazones. Tetrahedron Lett. 2016, 57, 2375–2378. [CrossRef]
Sergeev, S.; Pouzet, E.; Debever, O.; Levin, J.; Gierschner, J.; Cornil, J.; Aspe, R.G.; Geerts, Y.H. Liquid
crystalline octaalkoxycarbonyl phthalocyanines: Design, synthesis, electronic structure, self-aggregation and
mesomorphism. Mater. Chem. 2007, 17, 1777–1784. [CrossRef]
5.
Al-Raqa, S.; Köksoy, B.; Durmus¸, M. A novel lutetium(III) acetate phthalocyanine directly substituted
with N.,N’-dimethylaminophenyl groups via CC bonds and its water-soluble derivative for photodynamic
therapy. Tetrahedron Lett. 2017, 58, 685–689. [CrossRef]

Molecules 2019, 24, 77
12 of 13
6.
Liu, J.-Y.; Wang, C.; Zhu, C.; Zhang, Z.; Xue, J. Preparation and in vitro photodynamic activity of glucosylated
zinc(II) phthalocyanines as underlying targeting photosensitizers. Molecules 2017, 22, 845. [CrossRef]
[PubMed]
7.
8.
Tritsch, J.R.; Chan, W.L.; Wu, X.; Monahan, N.R.; Zhu, X.-Y. Harvesting singlet fission for solar energy
conversion via triplet energy transfer. Nat. Comm. 2013, 4, 1–7. [CrossRef]
Maksheed, S.; Al-Sawah, M.; Samuel, J.; Manaa, H. Synthesis, characterization and nonlinear optical
properties of nonaggregating hexadeca-substituted phthalocyanines. Tetrahedron Lett. 2009, 50, 165–168.
[CrossRef]
9.
Zhang, J.; Wang, H.; Yan, X.; Wang, J.; Shi, J.; Yan, D. Phthalocyanine composites as high-mobility
semiconductors for organic thin-film transistors. Adv. Mat. 2005, 17, 1191–1193. [CrossRef]
10. Usol’tseva, N.V.; Smirnova, A.I.; Kazaka, A.V.; Giricheva, N.I.; Galanin, N.E.; Shaposhnikov, G.P.;
Bodnarchuk, V.V.; Yablonskii, S.V. Mix-substituted phthalocyanines of “push–pull”-type and their metal
complexes as prospective nanostructured materials for optoelectronics. Opt. Electron. Rev. 2017, 25, 127–136.
[CrossRef]
11. Nyokong, T. Effects of substituents on the photochemical and photophysical properties of main group metal
phthalocyanines. Coord. Chem. Rev. 2007, 251, 1707–1722. [CrossRef]
12. Okura, I. Photosensitization of Porphyrins and Phthalocyanines, 1st ed.; Gordon and Breach Publishers: Tokyo,
Japan, 2001.
13. Al-Raqa, S.Y. The synthesis and photophysical properties of novel, symmetrical, hexadecasubstituted Zn
phthalocyanines and related unsymmetrical derivatives. Dyes Pigments 2008, 77, 259–265. [CrossRef]
14. Atsay, A.; Nar, I.; Hamuryudan, E.; Koçak, M.B.; Gul, A. A honeycomb-like crystalline self-assembled
hexadeca-substituted phthalocyanine. ChemistrySelect 2017, 2, 9233–9235. [CrossRef]
15. Lyubimtsev, A.; Iqbal, Z.; Crucius, G.; Syrbu, S.; Taraymovich, E.S.; Ziegler, T.; Hanack, M. Aggregation
behavior and UV-vis spectra of tetra- and octaglycosylated zinc phthalocyanines. J. Porphyr. Phthalocyanines
2011, 15, 39–46. [CrossRef]
16. Khanh, B.V.; Phung, T.K. cis-Cyclooctene epoxidation catalyzed by bulk metallophthalocyanines,
metallohexadecafluorophthalocyanines and hollow silica-supported metallohexadecafluorophthalocyanine.
J. Ind. Eng. Chem. 2016, 40, 40–46.
17. Mana, H.; Al Mulla, A.; Makhseed, S.; Al-Sawah, M.; Samuel, J. Fluorescence and nonlinear optical properties
of non-aggregating hexadeca-substituted phthalocyanine. J. Opt. Mat. 2009, 32, 108–114. [CrossRef]
18. Gaffo, L.; Zucolotto, V.; Cordeiro, M.R.; Moreira, W.C.; Oliveira, O.N.; Cerdeira, F.; Brasil, M.J.S.P. Structural
aspects of Langmuir–Blodgett and cast films of zinc phthalocyanine and zinc hexadecafluorophthalocyanine.
Thin Solid Films 2007, 515, 7307–7312. [CrossRef]
19. Kurt, O.; Ozcesmeci, I.; Sesalan, B.S.; Kocak, M.B. The synthesis and investigation of binding properties of a
new water soluble hexadeca zinc(II) phthalocyanine with bovine serum albumin and DNA. New J. Chem.
2015, 39, 5767–5775. [CrossRef]
20. Atsay, A.; Gül, A.; Koçak, M.B. A new hexadeca substituted non-aggregating zinc phthalocyanine.
Dyes Pigments 2014, 100, 177–183. [CrossRef]
21. Al-Raqa, S.Y.; Messali, M.; Al-Refae, S.; Ghanem, B.; Moussa, Z.; Ahmed, S.; El-Khouly, M.; Fukuzumi, S.
Synthesis, electrochemical, and photophysical studies of hexadecachlorinatedphthalocyaninato zinc(II).
Dyes Pigments 2011, 91, 231–236. [CrossRef]
22. Cook, M.J.; Heeney, M.J. Phthalocyaninodehydroannulenes. Chem. Eur. J. 2000, 6, 3958–3967. [CrossRef]
23. Catalán, J.; Díaz, C.; López, V.; Pérez, P.; De Paz, J.-L.G.; Rodríguez, J.G. A generalized solvent basicity scale:
The solvatochromism of 5-nitroindoline and its homomorph 1-methyl-5-nitroindoline. Liebigs. Ann. 1996
,
1785–1794. [CrossRef]
24. Hans, E.; Roeland, J.M.N. Molecular materials based on crown ether functionalized phthalocyanines.
J. Porphyr. Phthalocyanines 2000, 4, 454–459.
25. Can, O.S.; Kaya, E.N.; Durmus¸, M.; Bulut, M. High photosensitized singlet oxygen generating zinc(II)
and indium(III) acetate phthalocyanines containing 6,8-di-tert-butyl-3-(p-oxyphenyl)coumarin groups.
J. Photochem. Photobiol. A 2016, 317, 56–67.
26. Zorlu, Y.; Dumoulin, F.; Durmus¸, M.; Ahsen, V. Comparative studies of photophysical and photochemical
properties of solketal substituted platinum(II) and zinc(II) phthalocyanine sets. Tetrahedron 2010, 66,
3248–3258. [CrossRef]

Molecules 2019, 24, 77
13 of 13
27. Durmus¸, M. Photochemical and Photophysical Characterization. In Photosensitizers in Medicine, Environment,
and Security; Nyokong, T., Ahsen, V., Eds.; Springer: New York, NY, USA, 2012.
28. Smith, K. The Handbook of Porphyrin Science; Kadish, K.M., Smith, K.M., Eds.; Academic Press: New York, NY,
USA, 2010.
29. Dutt, G.B.; Periasamy, N. Electron-transfer distance in intermolecular diffusion-limited reactions. J. Chem.
Soc. Faraday Trans. 1991, 87, 3815–3820. [CrossRef]
30. Forgues, F.S.; Lavabre, D. Are fluorescence quantum yields so tricky to measure? A demonstration using
familiar stationery products. J. Chem. Educ. 1999, 76, 1260–1264. [CrossRef]
31. Maree, D.; Nyokong, T.; Suhling, K.; Phillips, D. Effects of axial ligands on the photophysical properties of
silicon octaphenoxyphthalocyanine. J. Porphyr. Phthalocyanines 2002, 6, 373–376. [CrossRef]
32. Spiller, W.; Kliesch, H.; Wöhrle, D.; Hackbarth, S.; Roder, B.; Schnurpfeil, G. Singlet oxygen quantum yields
of different photosensitizers in polar solvents and micellar solutions. J. Porphyr. Phthalocyanines 1998, 2,
145–158. [CrossRef]
33. Rose, J. Advanced Physico-Chemical Experiments; Sir Isaac Pitman & Sons Ltd.: Billerica, MA, USA, 1964.
Sample Availability: Samples of the compounds 1, 2, 3, 3a and 3b are available from the authors.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
