Structural Chemistry
https://doi.org/10.1007/s11224-019-01390-1
ORIGINAL RESEARCH
Synthesis, structural analysis, and photophysical
properties of bi-1,2,3-triazoles
Ivette Santana-Martínez1 & María Teresa Ramírez-Palma1 & Javier Sánchez-Escalera1 & Diego Martínez-Otero1
Marco A. García-Eleno1 & Alejandro Dorazco-González1 & Erick Cuevas-Yañez1
&
Received: 15 May 2019 /Accepted: 27 June 2019
#
Springer Science+Business Media, LLC, part of Springer Nature 2019
Abstract
Structural insights of a group of bi-1,2,3-triazoles derived from oxidative CuAAC are described through an X-ray crystallography
study, distinguishing a dihedral angle which is ranged from 76.45 to 86.39° between the two 1,2,3-triazole rings. In addition,
compound 1 containing a phenyl moiety displays a strong blue emission (λem = 394 nm); this structure-related
photoluminescence is attributed to the rigidity of the molecule and the conjugation between phenyl groups and the triazole
fragments.
.
.
.
Keywords Bi-1,2,3-triazole Crystal structure Dihedral angle Fluorescent emission
Introduction
aromatic rings linked by a single bond forming the biaryl
part of the molecule. For example, Zhu and coworkers
found rigid axially chiral structures in bi-1,2,3-triazoles
with a broader range of dihedral angle distribution than
that of BINAPs which provide more opportunities for li-
gand design in catalysis area [5].
5,5′-(1,2,3-Triazolyl)-1,2,3-triazoles, usually known as bi-
1,2,3-triazoles, are promising molecules derived from oxida-
tive copper-catalyzed azide-alkyne cycloaddition (CuAAC)
[1, 2]. Since their discovery by Angell and Burgess [3], the
number of works about the synthesis of bi-1,2,3-triazoles have
increased considerably in recent years; however, there are few
reports which describe structural and other physical character-
istics [4–11].
Bi-1,2,3-triazole structure is similar to other biaryl com-
pounds such as binaphthyls [12–14], bipyridines [15],
biimidazoles [16, 17], bipyrazoles [18, 19], and 4,4′-bi-
1,2,4-triazoles [20, 21]. This characteristic converts bi-
1,2,3-triazoles in potential useful ligands for catalysis with
the advantage that these compounds are easily available
from oxidative CuAAC reaction. Hence, structural studies
in bi-1,2,3-triazoles are important in order to describe
properties such as possible coordination sites and stable
conformations, especially those which are related to the
On the other hand, there is a significant current interest in
the development of fluorescent triazole derivatives owing to
their well-known biological properties that offer promise for
medical applications and more recently due to their use as
optical molecular sensors for ionic species [22]. Particularly,
the emission upon excitation is a physical property that has
been found several applications lately in sensing of inorganic
anions [23–25], color emitting devices [26], and metal
chemosensing characterization of 1,2,3-triazole-based
regioisomers [27–29]. The photophysical properties of organ-
ic fluorophores are essentially dependent on the conjugated
aromatic rings, planarity of the system, solvation environ-
ment, and substituent groups in the fluorescent core [22, 30].
In this context, CuAAC reaction has allowed the preparation
of a wide variety of triazole-based molecules, from modest
push-pull chromophores/fluorophores [31, 32] to multipolar
structures with non-linear optical responses such as two-
photon absorption [33]. In this regard, the abovementioned
photophysical properties have not been already described for
bi-1,2,3-triazoles, and only some reported transition metal
complexes of bi-1,2,3-triazoles exhibit these characteristics
[34–37].
* Erick Cuevas-Yañez
ecuevasy@uaemex.mx
1
Centro Conjunto de Investigación en Química Sustentable
UAEM-UNAM, Universidad Autónoma del Estado de México,
Carretera Toluca-Atlacomulco Km 14.5, 50200 Toluca, State of
Mexico, Mexico

Struct Chem
In connection with other projects, we some time ago initi-
ated studies on the synthesis of bi-1,2,3-triazoles, few exam-
ples of which were then known, as well as thorough structural
and photophysical property studies about this kind of com-
pounds. In light of the new discoveries about this topic, we
consider disclosing our most recent results in this area.
Scheme 1 Synthesis of bi-1,2,3-triazoles
Experimental
diffractometer. Three standard reflections every 97 reflections
were used to monitor the crystal stability. The structure was
solved by direct methods; missing atoms were found by dif-
ference Fourier synthesis, and refined on F2 by a full-matrix
least-squares procedure using anisotropic displacement pa-
rameters using SHELX-97. Crystallographic data for the
structure reported in this paper have been deposited with the
Cambridge Crystallographic Data Centre (CCDC). Copies of
available materials can be obtained free of charge on applica-
tion to the director of CCDC (12 Union Road, Cambridge
CB2 IEZ, UK (facsimile: (44) 01223 336033); e-mail:
deposit@ccdc.ac.uk).
General
The starting materials were purchased from Aldrich Chemical
Co. and were used without further purification. Solvents were
distilled before use. The tartrate-NaOH solution (Fehling B
solution) was prepared dissolving sodium hydroxide (23.5 g,
0.04 mol) and tartaric acid (18.3 g, 0.012 mol) in H2O
(100 mL). The CuSO4 solution (Fehling A solution) was pre-
.
pared by dissolving CuSO4 5H2O (9.89 g, 0.039 mol) in H2O
(100 mL). Silica plates of 0.20-mm thickness were used for
thin layer chromatography. Melting points were determined
with a Krüss Optronic melting point apparatus and they are
uncorrected. 1H and 13C NMR spectra were recorded using a
Bruker AVANCE 300 or a Varian 500-MHz instrument; the
chemical shifts (δ) are given in ppm relative to TMS as inter-
nal standard (0.00). For analytical purposes, the mass spectra
were recorded on a Shimadzu GCMS-QP2010 Plus in the EI
mode, 70 eV, 200 °C via direct inlet probe. Only the molecular
and parent ions (m/z) are reported. IR spectra were recorded
on a Bruker TENSOR 27 FT instrument.
The absorption and emission spectra were recorded from
methanolic solutions of compounds 1–5 (10 μM and 2 μM
respectively) in a quartz cuvette placed in a compartment of
spectrophotometer thermostated at 25.0° 0.1 on a Cary-100
Agilent UV-vis spectrophotometer and Cary Eclipse Agilent
fluorescence spectrophotometer. Emission quantum yields
were determined using L-tryptophan in a degassed aqueous
solution as the standard (Φ = 0.13; ex = 280 nm).
General procedure for the synthesis
of bi-1,2,3-triazoles
The corresponding azide (1 mmol) and alkyne (1 mmol) were
added to a solution of glucose (0.045 g, 0.25 mmol) in H2O
(1 mL) and MeOH (5 mL). The mixture was treated succes-
sively with the tartrate-NaOH solution (Fehling B solution,
0.1 mL) and CuSO4 solution (Fehling A solution, 0.25 mL,
0.1 mmol). The resulting mixture was stirred at 0 °C for 24 h.
The solvent was removed under reduced pressure and the final
product was purified by column chromatography (SiO2,
hexane/AcOEt 8:2).
3,3′-Dibenzyl-5, 5′-diphenyl—3H, 3′H-[4,4′] bi
[[1,2,3]triazolyl] (1). White solid, mp. 110 °C. IR (KBr) ѵ =
1
695, 721, 973, 1219, 1296, 1452, 3100 cm−1. H RMN:
(500 MHz, DMSO-d6) δ 7.4 (m, 4H), 7.14–7.25 (m, 6H),
7.07–7.20 (m, 6H), 6.81 (d, 4H), 4.81 (d, 2H), 4.74 (d, 2H)
ppm. 13C RMN (125 MHz, DMSO-d6) δ 147.22, 134.04,
129.54, 129.24, 129.07, 128.98, 128.77, 128.36, 125.81,
52.63 ppm; MS [EI+] m/z (%) 468 [M]+ (40), 349 [M-
Differential scanning calorimetry (DSC) studies were per-
formed on the Netzsch STA 449 F3 Jupiter for experiment A
at a rate of 10 °C/min and 1 °C/min, atmosphere: high purity
nitrogen. For experiment B, at a heating and cooling rate of
5 °C/min, atmosphere: helium BIP and nitrogen, both exper-
iments in aluminum crucible, with a hole in the lid.
Table 1 Synthesis of bi-1,2,3-triazoles
Compound
R1
R2
% yield
For the RX diffraction studies, crystals of compounds 2–7
were obtained by slow evaporation of a dilute MeOH solution.
Crystallographic data for compounds were collected on a
Bruker SMART APEX DUO three-circle diffractometer
equipped with an Apex II CCD detector using MoKα (λ =
0.71073 Å (Incoatec IμS microsource and Helios optic mono-
chromator); the temperature of collections was − 173 °C
(100 K)). Suitable crystals were coated with hydrocarbon
oil, picked up with a nylon loop, and mounted the
1
2
3
4
5
6
7
CH2Ph
CH2Ph
CH2Ph
CH2Ph
CH2Ph
(CH2)3Ph
CH2Ph
Ph
68
90
65
77
70
78
50
CH2O(2-Cl)C6H4
CH2O(4-Cl)C6H4
CH2O(4-Br)C6H4
CH2O(4-CH3)C6H4
Ph
CH2OH

Struct Chem

Struct Chem
Fig. 1 ORTEP diagrams for compounds 1 (a), 2 (b), 3 (c), 4 (d), 5 (e), 6 (f), and 7 (g)
C7H7N2]+ (35), 321 [M-C7H7N4]+ (35), 91 [C6H5CH2]+
(100).
3,3′-Dibenzyl-5,5′-bis-(2-chlorophenoxymethyl)-3H,3′
H-[4,4′]bi[[1,2,3]triazolyl] (2). White solid mp. 92 °C. IR
(KBr) ѵ = 3062, 3028, 2916, 2850, 1715, 1589, 1484, 1447,
1276, 1244, 1228, 1060, 1042, 1002, 860, 825, 747, 737, 709,
695, 670, cm−1. 1H RMN: (500 MHz, DMSO-d6) δ7.41 (dd,
2H), 7.31 (m, 4H), 7.28 (m, 6H), 7.22 (m 2H), 6.94 (m, 2H),
5.09 (d, 2H) 4.95 (d, 2H), 4.77 (d, 2H) 4.64 (d, 2H) ppm. 13
C
RMN (125 MHz, DMSO-d6) δ 153.24, 144.65, 134.52,

Struct Chem
Fig. 2 TG thermogram and DSC curve of compound 1
130.43, 129.23, 128.58, 128.30, 122.5, 121.65, 114.35, 61.75,
52.44 ppm. MS [EI+] m/z (%) 596 [M]+ (10), 526 [M-Cl2]+
(20), 119 [C7H7N2]+ (20), 91 [C7H7]+ (100). Elemental anal-
ysis calculated: C, 64.33; H, 4.39; N, 14.07, found: C, 64.31;
H, 4.27; N, 14.05.
3,3′-Dibenzyl-5,5′-bis-(4-chlorophenoxymethyl)-3H,3′
H-[4,4′]bi[[1,2,3]triazolyl] (3). White solid; mp.70 °C. IR
(KBr) ѵ = 3141, 2925, 2853, 1886, 1731, 1579, 1490, 1239,
1221, 993, 830, 815, 756, 720, 649, 515, 473 cm−1; 1H RMN:
(500 MHz, DMSO-d6) δ 7.19-7.34 (m, 14H.) 6.93 (d, 2H)
Fig. 3 DSC heating and cooling scan of compound 1

Struct Chem
Fig. 4 DSC heating and cooling scan of compound 2
6.69 (d, 2H) 5.75 (s, 4H) 5.07 (d, 4H) ppm; 13C RMN
(125 MHz, DMSO-d6) δ 157.28, 143.15, 136.41, 129.68,
129.22, 128.63, 128.39, 125.21, 117,116.99, 61.81,
53.31 ppm. MS [EI+] m/z (%) 596 [M]+ (5), 92 [C7H8]+
(100). Elemental analysis calculated: C, 64.33; H, 4.39; N,
14.07, found: C, 64.10; H, 4.48; N, 13.77.
3,3′-Dibenzyl-5,5′-bis-(4-bromophenoxymethyl)-3H,3′
H-[4,4′]bi[[1,2,3]triazolyl] (4). White solid, mp. 68 °C; IR
(KBr) ѵ = 2952, 2922, 2853, 1577, 1483, 1459, 1337,1336,
1285,1237, 1211, 1118, 1000, 858,809, 730, 706, 615, 592,
507 cm−1. 1H RMN: (500 MHz, DMSO-d6) δ 7.39 (m, 4H),
7.17–7.31 (m, 10H), 6.93 (s, 4H), 5.57 (s, 4H) 5.18 (s, 4H)
ppm. 13C RMN (125 MHz, DMSO-d6) δ 164.85, 137.3,
133.85, 131.85, 117.7, 114.45, 76.47, 40.21, 39.79, 39.62,
39.45 ppm. MS [EI+] m/z (%) 684 [M]+ (5), 526 [M-Br2]+
(30), 119 [C7H7N2]+ (20), 92 [C7H8]+ (100). Elemental
analysis calculated: C, 55.99; H, 3.82; N, 12.24, found: C,
55.13; H, 4.00; N, 12.05.
3,3′-Dibenzyl-5,5′-bis-p-tolyloxymethyl-3H,3′
H-[4,4′]bi[[1,2,3]triazolyl] (5) White solid, m.p. 85 °C. IR
(KBr) ѵ = 3064, 3032, 2923, 2857, 1725, 1611, 1568,
1509, 1456, 1290, 1228, 1177, 1027, 1016, 813, 709,
1
511 cm−1. H RMN: (500 MHz, DMSO-d6) δ 7.31 (ddd,
6H), 7.07 (m, 4H), 6.93 (d, 4H), 6.57 (d, 4H), 5.15 (d,
Table 3 Dihedral angles
(°) formed by triazole
Compound
Dihedral angle (°)
rings in bi-1,2,3-triazoles
1
2
3
4
5
6
7
82.07
77.93
80.64
81.28
83.58
86.39
76.45
Fig. 5 Orthogonal conformation in the triazole rings in compound 6

Struct Chem
Fig. 6 Intramolecular interactions C–H—pi found in compound 6
2H), 5.03 (d, 2H), 4.58 (d, 2H), 4.44 (d, 2H), 2.21 (s, 6H)
ppm. 13C RMN (125 MHz, DMSO-d6) δ 155.61, 145.39,
134.69, 129.94, 129.28, 128.11, 122.4, 115.40, 114.73,
60.66, 52.25, 20.045 ppm. MS [EI+] m/z (%) 556 [M]+
(5), 91 [C7H7]+ (100). Elemental analysis calculated: C,
72.99; H, 4.98; N, 15.96, found: C, 72.93; H, 4.91; N,
15.95.
5,5′-Diphenyl-3,3′-bis-(3-phenylpropyl)-3H,3′
H-[4,4′]bi[[1,2,3]triazolyl] (6). White solid, m. p. 131 °C. IR
1
(ATR) ѵ = 2915, 2862, 1439 cm−1. H NMR (300 MHz,
CDCl3) δ 7.79 (m, 4H), 7.42–7.20 (m, 2H), 3.79 (dd, 4H),
2.57 (t, 4H), 1.98 (t, 2H). 13C NMR (75 MHz, CDCl3) δ
147.1, 141.6, 131.9, 129.2, 128.9, 128.6, 127.9, 126.3,
122.8, 49.3, 34.2, 25.7. MS [EI+] m/z (%) 552 [M]+ (5), 91
Fig. 7 Dimer formed by the C–H—N2 interaction in the crystal packing of compound 6. Symmetry code (i) = − x, 1 − y, 1 − z

Struct Chem
Table 4 Photophysical properties
bi-1,2,3-triazoles 1-5 in CH3OH
Compound R2
λ
(nm)
max abs
Extinction coefficient Emission
Quantum
RFIc
(M−1 cm−1
)
(nm)a
yield (%)b
1
2
3
4
5
Ph
244; 286 1.3 × 105; 5.8 × 104
243; 262 7.6 × 104; 3.7 × 104;
242; 263 6.8 × 104; 3.8 × 104
242; 267 5.3 × 104; 3.0 × 104
384
361
355
341
338
10.4
5.8
5.2
3.4
4.5
–
CH2O(2-Cl)C6H4
CH2O(4-Cl)C6H4
CH2O(4-Br)C6H4
0.43
0.40
0.23
0.29
CH2O(4-CH3)C6H4 242; 265 3.5 × 104; 1.7 × 104
a λexc = 286 nm
b Relative to L-tryptophan
c RFI relative fluorescence intensity normalized with respect to 1
[C7H7]+ (100). Elemental analysis calculated: C, 78.23; H,
6.57; N, 15.21, found: C, 78.29; H, 6.52; N, 15.16.
Compounds 1–7 were fully characterized by the conven-
tional spectroscopic techniques. Moreover, these compounds
were crystalline solids suitable for X-ray crystallography stud-
ies. Crystallographic data and structural refinement parame-
ters of compounds 1–7 are summarized in Table 2 and the
corresponding ORTEP representations are shown in Fig. 1,
confirming the proposed structure for these compounds.
Single-crystal X-ray diffraction analysis performed on com-
pounds 1–7 revealed some interesting facts. For example, crystal
structure of bi-1,2,3-triazole 1 represents a new polymorphic
form of this compound which previously crystallized in an or-
thorhombic crystal system under a centrosymmetric space group
Pbca [11]. In this case, the new polymorph of 1 crystallized in a
triclinic crystal system under a space group P-11 with 4 mole-
cules in the asymmetric unit, two of them displaying disorder in
the phenyl moiety (molecule a in Fig. 1). In order to corroborate
the presence of polymorphs in compound 1, simultaneous TGA
and DSC studies were determined with a heating rate of
10 °C/min (Fig. 2). TG thermogram of 1 shows only an impor-
tant weight loss which takes place at above 350 °C associated to
the molecule degradation and demonstrating that this product is
neither a solvated, nor a hydrated form of compound 1, while the
DSC curve of this sample displays an endothermic process at
141.1 °C. A second sample was analyzed under a cycle plotted in
( 3 , 3 ′ - D i b e n z y l - 5 ′ - h y d r o x y m e t h y l - 3 H , 3 ′
H-[4,4′]bi[[1,2,3]triazolyl]-5-yl)-methanol (7) White solid,
m.p. 85 °C. IR (KBr) ѵ = 3350, 2923, 2857, 1611, 1568,
1509, 1456, 1290, 1230 cm−1 1H RMN: (500 MHz,
.
DMSO-d6) δ 7.31 (ddd, 6H), 7.07 (m, 4H), 6.93 (d, 4H),
6.57 (d, 4H), 5.15 (d, 2H), 5.03 (d, 2H), 4.58 (d, 2H), 4.44
(d, 2H) ppm. 13C RMN (125 MHz, DMSO-d6) δ 141.4, 136.8,
129.94, 129.3, 128.1, 121.9, 59.7, 52.1 ppm. MS [EI+] m/z
(%) 376 [M]+ (5), 375 [M-H]+ (10), 92 [C7H8]+ (100).
Elemental analysis calculated: C, 63.82; H, 5.36; N, 22.33,
found: C, 63.83; H, 5.29; N, 22.25.
Results and discussion
The initial experiments were aimed to prepare bi-1,2,3-triazoles
through an adaptation of a previous work by our group (Scheme
1) [11, 38]. Thus, treatment of diverse azides with the appropriate
alkynes in the presence of catalytic amounts of a Fehling
Reagent-glucose-NaOH system at 0 °C afforded the correspond-
ing bi-1,2,3-triazoles 1–7 in 65–90% yields (Table 1).
Fig. 8 Absorption and fluorescence spectra of compounds 1–5 (10 μM and 2 μM for UV-vis and fluorescence respectively, λex = 280 nm) in CH3OH

Struct Chem
Fig. 9 Absorption (a) and fluorescence (b) spectra of 1 (10 μM and 2 μM for UV-vis and fluorescence respectively, λex = 280 nm) in CH3OH. The inset
shows solution of A under irradiation at 365 nm UV light
Fig. 3 (heating-cooling-heating rates of 1 °C/min); the DSC scan
shows three small endothermic peaks of crystallization at 133.2,
135.9, and 138.1 °C which indicate the existence of 3 polymor-
phic forms.
small structural changes; an example is the regioisomerism
which dramatically modifies the molecular absorption and
emission attributes in these compounds [25, 32]. Taking this
point into consideration, we explored the effect of substituent
− R2 (see Table 1) on the photophysical properties of bi-1,2,3-
triazoles 1–5. The basic photophysical properties (absorption
maxima, emission, and quantum yields) of 1–5 in methanolic
solutions are collected in Table 4 and the corresponding UV-
vis and fluorescence spectra are plotted in Fig. 8.
All compounds display good solubility in methanol and the
corresponding solutions were used for further studies.
Compound 1 exhibits a strong blue emission under ambient
conditions with bands centered at 384 upon excitation at
286 nm, as shown in Fig. 9. Solutions of 2–3 present a modest
emission at 361 and 355 nm respectively. In contrast, com-
pounds 4–5 display very low fluorescence. One particular
point is that insertion of an electron-donating group
(halophenoxymethyl groups in compounds 2–4 and
tolyloxymethyl group in compound 5 at the C-4 triazole posi-
tion in 1,1′-dibenzyl-bis(1,2,3-triazole) fragment induces a
considerable quenching of the emission accompanied by sig-
nificant blue-shift of 23-46 nm in the position of the longest
wavelength bands.
According to RFI parameter with respect to bi-1,2,3-tri-
azole 1, the effect of substitution of the bi-1,2,3-triazole core
on the decrease in the emission can be described as phenyl >
2-chlorophenoxymethyl > 4-chlorophenoxymethyl >
tolyloxymethyl. This trend is consistent with the quantum
yield values determined (Table 4). Similar photochemical
properties with UV/blue-light emission in the range of 316–
422 nm have been reported previously for a series of aryl-
1,2,3-triazoles derivatives with Stokes shift in the range of
38–94 nm [39]. Thus, the emission performance effect of sub-
stituent group at C-4 position on 3,3′- dibenzyl -5, 5′-
diphenyl-bi-1,2,3-triazolyl fragment as a fluorescence core
A similar behavior was observed in compound 2, which
crystallized with 2 molecules in the asymmetric unit
(molecule b in Fig. 1). Two polymorphs were detected in
compound 2 through a DSC heating-cooling cycle curve anal-
ysis which exhibits two small endothermic peaks of crystalli-
zation at − 28.7 °C and − 31.2 °C respectively (Fig. 4).
A noteworthy feature found in compounds 1–7 is an almost
orthogonal conformation between triazole rings similar to other
reported bi-1,2,3-triazoles [5]. Dihedral angles formed by triazole
rings are presented in Table 3 and exhibit a range from 76.45 to
86.39°.
For example, dihedral angle N(1)-C(10)-C(27)-N(4) in
compound 6 is 86.39(13)° (Fig. 5). In addition, the presence
of a C–H—pi interaction between the C(22)-H(22) and the
centroid of phenyl ring at 5-position of triazole determines a
distance of 3.7658(17) Å between these two elements and a
dihedral angle C(10)-C(11)-C(12)-C(17) of 23.84(17)° (Fig.
6). Similar distance and dihedral angle are observed from
interactions of the opposite C(5)-H(5)/5′-phenyl-1′,2′,3′-
triazolyl system. These elements suggest the presence of a
rigid axially structure along C10–C27 bond which is favored
by the C–H—pi interactions.
In the crystal packing some intermolecular interactions
have been found. C-H—N2 interactions, C(20)i-H(20A)i—
N(2) and C(18)i-H(18B)i—N(2) H—N are 2.55 and 2.70 Å
respectively forming a dimer in the unit cell as a show in the
Fig. 7. The angles C–H–N are close to 150°, the distance
ppC(20)i-N(2) is 3.5913(14) Å, and the distance C(18)i-N(2)
is 3.4728(13) Å with a symmetry code (i) − x, 1 − y, 1 − z.
1,2,3-Triazole-based molecular compounds have shown a
large diversity of photophysical properties as a function of

Struct Chem
chemistry: approaches, applications and challenges. Nova Science
Publishers, New York, pp 51–68
2. Zheng ZJ, Wang D, Xu Z, Xu LW (2015) Synthesis of bi- and bis-1,
2,3-triazoles by copper-catalyzed Huisgen cycloaddition: a family
of valuable products by click chemistry. Beilstein J Org Chem 11:
2557–25776
3. Angell Y, Burgess K (2007) Base dependence in copper-catalyzed
Huisgen reactions: efficient formation of bistriazoles. Angew Chem
Int Ed 46:3649–3651
4. Monkowius U, Ritter S, König B, Zabel M, Yersin H (2005)
Synthesis, characterisation and ligand properties of novel bi-1,2,3-
triazole ligands. Eur J Inorg Chem:4597–4606
5. Brassard CJ, Zhang X, Brewer CR, Liu P, Clark RJ, Zhu L (2016)
Cu (II)-catalyzed oxidative formation of 5,5′-bistriazoles. J
Organomet Chem 81:12091–12105
6. Key JA, Cairo CW, Ferguson MJ (2008) 7,70-(3,30-Dibenzyl-3H,
30H-4,40-bi-1,2,3-triazole-5,500-diyl)bis(4-methyl-2hchromen-2-
one). Acta Crystallogr E E64: o1910.
7. Miyanishi S, Zhang Y, Hashimoto K, Tajima K (2012) Controlled
synthesis of fullerene-attached poly(3-alkylthiophene)-based copol-
ymers for rational morphological design in polymer photovoltaic
devices. Macromolecules 45:6424–6437
8. de la Cerda-Pedro JE, Rojas-Lima S, Santillan R, López-Ruiz H
(2015) Phenylboronic Acid/CuSO4 as an efficient catalyst for the
synthesis of 1,4-disubstituted-1,2,3-triazoles from terminal acety-
lenes and alkyl azides. J Mex Chem Soc 59:130–136
can be elucidated as follows: (1) the emission is considerably
higher when bi-1,2,3-triazole fragment contains rigid substit-
uents such as phenyl. It is well known that rigidity increase in
small fluorescent molecules reduces the energy loss through
non-radiative processes such as vibrations [39, 40]; (2) a sig-
nificant quenching is observed by insertion of electro-
donating groups; this optical effect is not unexpected, because
the emission in organic fluorophores is favored by the combi-
nation of a strongly electron-donating moiety conjugated
through to π-linker to a strongly electron-accepting one
(push-pull system) [41, 42]; and (3) the highest fluorescent
emission in bi-1,2,3-triazole 1 compared with the other stud-
ied compounds can be assigned to a good conjugation be-
tween phenyl group and triazole ring (dihedral angles between
0.5 and 20°). These results reveal the potential influence of
some C-4 substituent groups on photophysical properties of
bi-1,2,3-triazole derivatives. Hence, the strong emission of 1
is possible through a combination provided by a straightfor-
ward synthesis from the click chemistry approach, turning this
molecule into a promising candidate for the design of more
sophisticated blue-light-emitting molecules.
9. Kwon M, Jang Y, Yoon S, Yang D, Jeon HB (2012) Unusual Cu(I)-
catalyzed 1,3-dipolar cycloaddition of acetylenic amides: formation
of bistriazoles. Tetrahedron Lett 53:1606–1609
10. Goyard D, Chajistamatiou AS, Sotiropoulou AI, Chrysina ED,
Praly JP, Vidal S (2014) Efficient atropodiastereoselective access
to 5,5’-bis-1,2,3-triazoles: studies on 1-glucosylated 5-halogeno 1,
2,3-triazoles and their 5-substituted derivatives as glycogen phos-
phorylase inhibitors. Chem Eur J 20:5423–5432
11. González J, Pérez VM, Jiménez DO, Lopez-Valdez G, Corona D,
Cuevas-Yañez E (2011) Effect of temperature on triazole and
bistriazole formation through copper-catalyzed alkyne–azide cyclo-
addition. Tetrahedron Lett 52:3514–3517
12. Parmar D, Sugiono E, Raja S, Rueping M (2014) Complete field
guide to asymmetric binol-phosphate derived Brønsted acid and
metal catalysis: history and classification by mode of activation;
Brønsted acidity, hydrogen bonding, ion pairing, and metal phos-
phates. Chem Rev 114:9047–9153
Conclusion
In summary, the structure of some bi-1,2,3-triazoles was elu-
cidated, showing dihedral angles in the crystalline structure of
some bi-1,2,3-triazoles which suggest the presence of a rigid
axially chiral structure, and therefore, atropisomers, such as
Zhu and coworkers have proposed for other bi-1,2,3-triazoles
[5]. This rigidity, in combination with a significant conjuga-
tion effect through homocyclic and heterocyclic rings, also
produces an outstanding fluorescent emission in bi-1,2,3-tri-
azole 1 that has not been registered in this kind of compounds
and will open new study lines about these molecules. The
elements herein described suggest that bi-1,2,3-triazoles will
enjoy widespread applications in the future.
13. Brunel JM (2005) BINOL: a versatile chiral reagent. Chem Rev
105:857–898
14. Chen Y, Yekta S, Yudin AK (2003) Modified BINOL ligands in
asymmetric catalysis. Chem Rev 103:3155–3212
15. Kaes C, Katz A, Hosseini MW (2000) Bipyridine: the most widely
used ligand. A review of molecules comprising at least two 2,2’-
bipyridine units. Chem Rev 100:3553–3590
Acknowledgments The authors would like to thank N. Zavala, A. Nuñez,
and L. Triana for the technical support.
16. Murata T, Yakiyama Y, Nakasuji K, Morita Y (2010)
Supramolecular architectures and hydrogen-bond directionalities
of 4,40-biimidazole metal complexes depending on coordination
geometries. Cryst Growth Des 10:4898–4905
Funding information Financial support from CONACYT is gratefully
acknowledged.
17. Kennedy DC, James BR (2010) Syntheses of ruthenium(II)-4,4’-
biimidazole complexes and their potential anti-tumour activity. Can
J Chem 88:886–892
18. Baig RBN, Varma RS (2013) Organic synthesis via magnetic at-
traction: benign and sustainable protocols using magnetic
nanoferrites. Green Chem 15:398–417
Compliance with ethical standards
Conflict of interest The authors declare that they have no competing
interests.
19. Luque R, Baruwati B, Varma RS (2010) Magnetically separable
nanoferrite-anchored glutathione: aqueous homocoupling of
arylboronic acids under microwave irradiation. Green Chem 12:
1540–1543
References
1. Santana-Martinez I, Cuevas-Yañez E (2017) Bi-1,2,3-Triazoles:
Synthesis and Perspectives. In: Chen Y, Tong ZR (eds) Click
20. Liu X, Gao W, Sun P, Su Z, Chen S, Wei Q, Xie G, Gao S (2015)
Environmentally friendly high-energy MOFs: crystal structures,

Struct Chem
thermostability, insensitivity and remarkable detonation perfor-
absorption and tuneable photoluminescence. Chem Commun:
2029–2031
mances. Green Chem 17:831–836
21. Wang XL, Cao JJ, Liu GC, Tian AX, Luan J, Lin HY, Zhang JW, Li
N (2014) Keggin-based 3D frameworks tuned by silver polymeric
motifs: effect of the bi(triazole) substituent group on the architec-
tures. CrystEngComm 16:5732–5740
22. Katan C, Savel P, Wong BM, Roisnel T, Dorcet V, Fillaut JL,
Jacquemin D (2014) Absorption and fluorescence signatures of 1,
2,3-triazole based regioisomers: challenging compounds for TD-
DFT. Phys Chem Chem Phys 16:9064–9073
23. Ghosh D, Rhodes S, Hawkins K, Winder D, Atkinson A, Ming W,
Padgett C, Orvis J, Aiken K, Landge S (2015) A simple and effec-
tive 1,2,3-triazole based “turn-on” fluorescence sensor for the de-
tection of anions. New J Chem 39:295–303
24. White NG, Beer PD (2013) A rotaxane host system containing
integrated triazole C–H hydrogen bond donors for anion recogni-
tion. Org Biomol Chem 11:1326–1333
34. Welby CE, Grkinic S, Zahid A, Uppal BS, Gibson EA, Rice CR,
Elliott PIP (2012) Synthesis, characterisation and theoretical study
of ruthenium 4,4′-bi-1,2,3-triazolyl complexes: fundamental
switching of the nature of S1 and T1 states from MLCT to MC.
Dalton Trans 41:7637–7646
35. Welby CE, Armitage GK, Bartley H, Sinopoli A, Uppal BS, Elliott
PIP (2014) Photochemical ligand ejection from non-sterically pro-
moted Ru(II)bis(diimine) 4,4’-bi-1,2,3-triazolyl complexes.
Photochem Photobiol Sci 13:735–738
36. Welby CE, Gilmartin L, Marriott RR, Zahid A, Rice CR, Gibson
EA, Elliott PIP (2013) Luminescent biscyclometalated arylpyridine
iridium(III) complexes with 4,4’-bi-1,2,3-triazolyl ancillary li-
gands. Dalton Trans 42:13527–13536
37. Ross DAW, Scattergood PA, Babaei A, Pertegás A, Bolink HJ,
Elliott PIP (2016) Luminescent osmium(II) bi-1,2,3-triazol-4-yl
complexes: photophysical characterisation and application in
light-emitting electrochemical cells. Dalton Trans 45:7748–7757
38. García MA, Ríos ZG, González J, Pérez VM, Lara N, Fuentes A,
González C, Corona D, Cuevas-Yañez E (2011) The use of glucose
as alternative reducing agent in copper-catalyzed alkyne-azide cy-
cloaddition. Lett Org Chem 8:701–706
39. Scattergood PA, Sinopoli A, Elliott PIP (2017) Photophysics and
photochemistry of 1,2,3-triazole-based complexes. Coord Chem
Rev 350:136–154
40. Rendón-Balboa JC, Villanueva-Sánchez L, Rosales-Vázquez LD,
Valdes-García J, Vilchis-Nestor AR, Martínez-Otero D, Martínez-
Vargas S, Dorazco-González A (2018) Structure of a luminescent
3D coordination polymer constructed with a trinuclear core of
cadmium-trimesate and isoquinoline. Inorg Chim Acta 483:235–
240
41. Jarowski PD, Wu YL, Schweizer WB, Diederich F (2008) 1,2,3-
Triazoles as conjugative π-linkers in push−pull chromophores: im-
portance of substituent positioning on intramolecular charge-trans-
fer. Org Lett 10:3347–3350
42. Yan W, Wang Q, Lin Q, Li M, Petersen JL, Shi X (2011) N-2-Aryl-
1,2,3-triazoles: A novel class of UV/blue-light-emitting
fluorophores with tunable optical properties. Chem Eur J 17:
5011–5018
25. Lee IL, Sung YM, Wu CH (2014) Wu SP (2014) Colorimetric
sensing of iodide based on triazole-acetamide functionalized gold
nanoparticles. Microchim Acta 181:573–579
26. Fernández-Hernández JM, Beltrán JI, Lemaur V, Gálvez-López
MD, Chien CH, Polo F, Orselli E, Fröhlich R, Cornil J, De Cola
L (2013) Iridium(III) emitters based on 1,4-disubstituted-1H-1,2,3-
triazoles as cyclometalating ligand: synthesis, characterization, and
electroluminescent deviceS. Inorg Chem 52:1812–1824
27. Hao E, Meng ZTM, Pang W, Zhou Y, Jiao L (2011) Solvent depen-
dent fluorescent properties of a 1,2,3-triazole linked 8-
hydroxyquinoline chemosensor: tunable detection from zinc(II) to
Iron(III) in the CH3CN/H2O System. J Phys Chem A 115:8234–
8241
28. Kim SH, Choi HS, Kim J, Lee SJ, Quango DT, Kim JS (2010)
Novel optical/electrochemical selective 1,2,3-triazole ring-
appended chemosensor for the Al3+ ion. Org Lett 12:560–563
29. Erdemir S, Kocyigit O, Malkondu SJ (2015) Detection of Hg2+ ion
in aqueous media by new fluorometric and colorimetric sensor
based on triazole–rhodamine. J Photochem Photobiol A 309:15–21
30. AEl-Betany AMM, McKeown NB (2012) The synthesis and fluo-
rescence properties of macromolecular components based on 1,8-
naphthalimide derivatives and dimers. Tetrahedron Lett 53:808–
810
31. Zoon PD, Van Stokkum IHM, IHM PM, Mongin O, Blanchard-
Desce M, Brouwer AM (2010) Fast photo-processes in triazole-
based push–pull systems. Phys Chem Chem Phys 12:2706–2715
32. Zhou Z, Fahrni CJ (2004) A fluorogenic probe for the copper(I)-
catalyzed azide−alkyne ligation reaction: modulation of the fluores-
cence emission via 3(n,π*)−(π,π*) inversion. J Am Chem Soc 126:
8862–8863
Publisher’s note Springer Nature remains neutral with regard to
jurisdictional claims in published maps and institutional affiliations.
33. Parent M, Mongin O, Kamada K, Katan C, Blanchard-Desce M
(2005) New chromophores from click chemistry for two-photon
