Catalytic Asymmetric PictetÀSpengler-
Type Reaction for the Synthesis of
Optically Active Indolo[3,4-
cd][1]benzazepines
Dao-Juan Cheng, Hai-Bian Wu, and Shi-Kai Tian*
Joint Laboratory of Green Synthetic Chemistry, Department of Chemistry, University of
Science and Technology of China, Hefei, Anhui 230026, China
tiansk@ustc.edu.cn
Received August 31, 2011
ABSTRACT
A new strategy has been introduced to develop a catalytic asymmetric PictetÀSpengler-type reaction by replacing the aldehyde with an imine. A
range of 4-(2-aminoaryl)indoles smoothly undergo the chiral phosphoric acid catalyzed asymmetric PictetÀSpengler-type reaction with imines at
room temperature to give structurally diverse indolo[3,4-cd][1]benzazepines in good to excellent yields and ee.
The PictetÀSpengler reaction, discovered 100 years
ago,1 is now widely employed in the construction of various
nitrogen-containing heterocycles.2 This transformation is
generally accomplished by treatment of aldehydes with
β-(hetero)arylethylamines in the presence of acidic catalysts,
which promote imine formation and subsequent cyclization
through an intramolecular FriedelÀCrafts reaction (Scheme
1, path a). In recent years a number of catalytic asymmetric
(1) Pictet, A.; Spengler, T. Ber. Dtsch. Chem. Ges. 1911, 44, 2030–
2036.
(2) For reviews, see: (a) Cox, E. D.; Cook, J. M. Chem. Rev. 1995, 95,
1797–1842. (b) Chrzanowska, M.; Rozwadowska, M. D. Chem. Rev.
2004, 104, 3341–3370. (c) Lorenz, M.; Van Linn, M. L.; Cook, J. M.
(4) (a) Raheem, I. T.; Thiara, P. S.; Jacobsen, E. N. Org. Lett. 2008,
10, 1577–1580. (b) He, Y.; Lin, M.; Li, Z.; Liang, X.; Li, G.; Antilla, J. C.
Org. Lett. 2011, 13, 4490–4493.
€
Curr. Org. Synth. 2010, 7, 189–223. (d) Stockigt, J.; Antonchick, A. P.;
Wu, F.; Waldmann, H. Angew. Chem., Int. Ed. 2011, 50, 8538–8564.
(3) (a) Taylor, M. S.; Jacobsen, E. N. J. Am. Chem. Soc. 2004, 126,
10558–10559. (b) Seayad, J.; Seayad, A. M.; List, B. J. Am. Chem. Soc.
2006, 128, 1086–1087. (c) Wanner, M. J.; van der Haas, R. N. S.; de
Cuba, K. R.; van Maarseveen, J. H.; Hiemstra, H. Angew. Chem., Int.
Ed. 2007, 46, 7485–7487. (d) Raheem, I. T.; Thiara, P. S.; Peterson, E. A.;
Jacobsen, E. N. J. Am. Chem. Soc. 2007, 129, 13404–13405. (e)
Sewgobind, N. V.; Wanner, M. J.; Ingemann, S.; de Gelder, R.; van
Maarseveen, J. H.; Hiemstra, H. J. Org. Chem. 2008, 73, 6405–6408. (f)
Mergott, D. J.; Zuend, S. J.; Jacobsen, E. N. Org. Lett. 2008, 10, 745–
748. (g) Muratore, M. E.; Holloway, C. A.; Pilling, A. W.; Storer, R. I.;
Trevitt, G.; Dixon, D. J. J. Am. Chem. Soc. 2009, 131, 10796–10797. (h)
Wanner, M. J.; Boots, R. N. A.; Eradus, B.; de Gelder, R.; van
Maarseveen, J. H.; Hiemstra, H. Org. Lett. 2009, 11, 2579–2581. (i)
Klausen, R. S.; Jacobsen, E. N. Org. Lett. 2009, 11, 887–890. (j)
Holloway, C. A.; Muratore, M. E.; Storer, R. I.; Dixon, D. J. Org. Lett.
2010, 12, 4720–4723. (k) Duce, S.; Pesciaioli, F.; Gramigna, L.; Bernardi,
L.; Mazzanti, A.; Ricci, A.; Bartoli, G.; Bencivenni, G. Adv. Synth.
Catal. 2011, 353, 860–864.
(5) (a) Liu, C.-R.; Li, M.-B.; Yang, C.-F.; Tian, S.-K. Chem. Com-
mun. 2008, 1249–1251. (b) Dong, D.-J.; Li, H.-H.; Tian, S.-K. J. Am.
Chem. Soc. 2010, 132, 5018–5020. (c) Dong, D.-J.; Li, Y.; Wang, J.-Q.;
Tian, S.-K. Chem. Commun. 2011, 47, 2158–2160. (d) Fang, F.; Li, Y.;
Tian, S.-K. Eur. J. Org. Chem. 2011, 1084–1091. (e) Jin, Y.-H.; Fang, F.;
Zhang, X.; Liu, Q.-Z.; Wang, H.-B.; Tian, S.-K. J. Org. Chem. 2011, 76,
4163–4167.
(6) For other recent examples, see: (a) Mi, X.; Luo, S.; He, J.; Cheng,
J.-P. Tetrahedron Lett. 2004, 45, 4567–4570. (b) Ke, B.; Qin, Y.; He, Q.;
Huang, Z.; Wang, F. Tetrahedron Lett. 2005, 46, 1751–1753. (c) Temelli,
B.; Unaleroglu, C. Tetrahedron Lett. 2005, 46, 7941–7943. (d) Temelli,
B.; Unaleroglu, C. Tetrahedron 2006, 62, 10130–10135. (e) Soueidan, M.;
Collin, J.; Gil, R. Tetrahedron Lett. 2006, 47, 5467–5470. (f) Esquivias,
ꢀ
ꢀ
J.; Gomez-Arrayas, R.; Carretero, J. C. Angew. Chem., Int. Ed. 2006, 45,
ꢀ
ꢀ
629–633. (g) Alonso, I.; Esquivias, J.; Gomez-Arrayas, R.; Carretero,
J. C. J. Org. Chem. 2008, 73, 6401–6404. (h) Thirupathi, P.; Kim., S. S. J.
Org. Chem. 2010, 75, 5240–5249. (i) Fan, R.; Wang, W.; Pu, D.; Wu, J. J.
Org. Chem. 2007, 72, 5905–5907. (j) Qian, B.; Xie, P.; Xie, Y.; Huang, H.
Org. Lett. 2011, 13, 2580–2583.
r
10.1021/ol202361t
Published on Web 09/26/2011
2011 American Chemical Society

PictetÀSpengler reactions have been developed for the synth-
esis of optically active six-membered nitrogen-containing
heterocycles with high enantioselectivity.3,4 Nevertheless, to
our knowledge, there is no catalytic asymmetric PictetÀ
Spengler-type reaction reported previously for the construc-
tion of chiral seven-membered ring systems.
Figure 1. Chiral indole-fused ring systems based on the catalytic
asymmetric modification of the pyrrole ring of indole.
Scheme 1. Proposed PictetÀSpengler-Type Reaction
Our investigation is based on Kundu’s recent report on
the synthesis of racemic indolo[3,4-cd][1]benzazepines
through a trifluoroacetic acid catalyzed modified PictetÀ
Spengler reaction of 4-(2-aminoaryl)indoles with
aldehydes.11 Initially, we found that phosphoric acids were
effective in catalyzing this transformation.12 For example,
treatment of 4-(2-aminophenyl)indole (1a) with aldehyde
2aa (1.1 equiv) and 10 mol % of phosphoric acid 4a in
dichloromethane at room temperature resulted in the
formation of indolo[3,4-cd][1]benzazepine 3a in 99% yield
and with 33% ee (Table 1, entry 1). To improve the
enantioselectivity according to our aforementioned hy-
pothesis, we replaced aldehyde 2aa with imine 2ab in the
reaction and, gratifyingly, found thatthe enantioselectivity
was enhanced to 39% for the same product albeit a
decreased reaction rate was observed (Table 1, entry 2).
Screening of solvents revealed that the reaction exhibited
the best enantioselectivity in tetrahydrofuran (46% ee,
Table 1, entry 8). It was fruitless to improve the enantio-
selectivity by replacing the p-methoxyphenyl group of
imine 2ab with another aryl group, a sulfonyl group, or a
diphenylphosphinyl group (Table 1, entries 10À18).
Nevertheless, the reactivity and enantioselectivity were
dramatically affected by the structure of the chiral phos-
phoric acid (Table 1, entries 19À26), and the employment
of commercially available catalyst 4d enhanced the enan-
tioselectivity to 82% ee (Table 1, entry 21). Finally, the
Prompted by our recent exploration of new reactions
through the complete cleavage of carbonÀnitrogen double
bonds,5,6 we envisioned that a PictetÀSpengler-type reac-
tion could occur by replacing the aldehyde with an imine
because the same precursor for cyclization could be gen-
erated through transimination under acidic conditions
(Scheme 1, path b).7 Although the N-substituent of an
imine would not go to the final product, it might affect
reactivity and enantioselectivity through nonbonding in-
teractions with a chiral acidic catalyst. We hoped that the
formation of an amine or an ammonia equivalent, instead
of water, as the byproduct would be beneficial to enhance
enantioselectivity.
Much attention has been paid to the construction of
indole-fused ring systems due to their broad range of
interesting biological properties.8 Catalytic asymmetric
modification of the pyrrole ring of indole has recently
emerged as a powerful approach to the construction of
chiral indole-fused ring systems. However, they are limited
to 1,2- and 2,3-fused indole derivatives (Figure 1).9,3,10
Herein, we wish to report a catalytic asymmetric synthesis
of optically active 3,4-fused indole derivatives, indolo[3,4-
cd][1]benzazepines, through a chiral phosphoric acid cata-
lyzed PictetÀSpengler-type reaction of 4-(2-aminoaryl)indoles
with imines.
˚
addition of 3 A molecular sieves and decreasing the con-
centration allowed the synthesis of indolo[3,4-cd]-
[1]benzazepine 3a with up to 90% ee (Table 1, entry 27).
It is noteworthy that the enantioselectivity is much better
than that obtained from the reaction with aldehyde 2aa
under the same conditions (83% ee, Table 1, entry 28).
Under the optimized reaction conditions, a range of
4-(2-aminoaryl)indoles smoothly underwent the asym-
metric PictetÀSpengler-type reaction with various imines
in the presence of 10 mol % of chiral phosphoric acid 4d at
room temperature to give structurally diverse indolo[3,4-
cd][1]benzazepines in good to excellent yields and ee (Table
2). It is noteworthy that this reaction tolerated a variety of
functional groups, such as alkoxy, halide, sulfonate, and
(7) For examples, see: (a) Zajac, W. W.; Walters, T. R.; Darcy, M. G.
J. Org. Chem. 1988, 53, 5856–5860. (b) Giuseppone, N.; Schmitt, J.-L.;
Schwartz, E.; Lehn, J.-M. J. Am. Chem. Soc. 2005, 127, 5528–5539.
(8) For reviews, see: (a) Somei, M.; Yamada, F. Nat. Prod. Rep. 2004,
21, 278–311. (b) Somei, M.; Yamada, F. Nat. Prod. Rep. 2005, 22, 73–
103. (c) Kawasaki, T.; Higuchi, K. Nat. Prod. Rep. 2005, 22, 761–793. (d)
Ishikura, M.; Yamada, K.; Abe, T. Nat. Prod. Rep. 2010, 27, 1630–1680.
(9) (a) Bandini, M.; Eichholzer, A.; Tragni, M.; Umani-Ronchi, A.
Angew. Chem., Int. Ed. 2008, 47, 3238–3241. (b) Enders, D.; Wang, C.;
Raabe, G. Synthesis 2009, 4119–4124. (c) Hong, L.; Sun, W.; Liu, C.;
Wang, L.; Wang, R. Chem.;Eur. J. 2010, 16, 440–444. (d) Cai, Q.;
Zheng, C.; You, S.-L. Angew. Chem., Int. Ed. 2010, 49, 8666–8669.
(10) (a) Bandini, M.; Melloni, A.; Piccinelli, F.; Sinisi, R.; Tommasi,
S.; Umani-Ronchi, A. J. Am. Chem. Soc. 2006, 128, 1424–1425. (b) Han,
X.; Widenhoefer, R. A. Org. Lett. 2006, 8, 3801–3804. (c) Li, C.-F.; Liu,
H.; Liao, J.; Cao, Y.-J.; Liu, X.-P.; Xiao, W.-J. Org. Lett. 2007, 9, 1847–
1850. (d) Huang, H.; Peters, R. Angew. Chem., Int. Ed. 2009, 48, 604–
(11) Saifuddin, M.; Agarwal, P. K.; Sharma, S. K.; Mandadapu,
A. K.; Gupta, S.; Harit, V. K.; Kundu, B. Eur. J. Org. Chem. 2010, 5108–
5117.
(12) For reviews of asymmetric catalysis with chiral phosphoric
acids, see: (a) Terada, M. Synthesis 2010, 1929–1982. (b) Terada, M.
Chem. Commun. 2008, 4097–4112. (c) Akiyama, T. Chem. Rev. 2007,
107, 5744–5758.
ꢀ
606. (e) Franzen, J.; Fisher, A. Angew. Chem., Int. Ed. 2009, 48, 787–791.
(f) Cai, Q.; Zhao, Z.-A.; You, S.-L. Angew. Chem., Int. Ed. 2009, 48,
7428–7431. (g) Zhang, J.-W.; Cai, Q.; Shi, X.-X.; Zhang, W.; You, S.-L.
Synlett 2011, 1239–1242.
Org. Lett., Vol. 13, No. 20, 2011
5637
