10.1002/cmdc.201700447
ChemMedChem
FULL PAPER
detection: UV 254 nm]: tR (min): 13.4–15.6 (enantiomer 1: compound 32;
ESI-HRMS: m/z [M + H]+ calcd for C18H19FN5O2S: 388.1243, found:
388.1241), 15.6–18.5 (enantiomer 2: BAY 1143572).
physicochemical properties. M. Bergmann and K. Greenfield are
acknowledged for valuable technical support with the manuscript.
The activities of the LDC have been co-funded by the Max-
Planck Foundation, on behalf of the Max-Planck Society, as well
as by a grant from the Ministry for Research and Technology
(BMBF, grant number 0315326).
(R)-4-(4-Fluoro-2-methoxyphenyl)-N-{3-[(S-methylsulfonimidoyl)-
methyl]phenyl}-1,3,5-triazin-2-amine (BAY 1143572)
Mp: 165 °C; []58920 = –14.0 ± 0.40 (c = 1 in DMSO); 1H NMR (600 MHz,
[D6]DMSO): = 2.81 (br s, 3H), 3.57 (s, 1H), 3.88 (br s, 3H), 4.29–4.40
(m, 2H), 6.90 (td, 1H), 7.09 (dd, 1H), 7.13 (d, 1H), 7.36 (t, 1H), 7.62–8.09
(m, 3H), 8.75–8.83 (m, 1H), 10.34 ppm (s, 1H); 13C NMR (125 MHz,
[D6]DMSO): = 40.9, 56.2, 62.3, 100.4, 106.7, 120.2, 122.8, 122.9, 125.8,
128.4, 130.9, 133.2, 138.5, 160.0, 163.1, 164.5, 166.2, 171.1 ppm; IR
Keywords: PTEFb • CDK • antitumor agents • sulfoximines •
drug design
References:
(KBr): = 3325–3246, 3013, 2960–2918, 1616–1403, 1284–1103 cm–1
;
ESI-HRMS: m/z [M + H]+ calcd for C18H19FN5O2S: 388.1243, found:
[1]
a) J. Wesierska-Gadek, I. Chamrad, V. Krystof, Future Med. Chem.
2009, 1, 1561; b) G. Mariaule, P. Belmont, Molecules 2014, 19, 14366;
c) J. Cicenas, K. Kalyan, A. Sorokinas, A. Jatulyte, D. Valiunas, A.
Kaupinis, M. Valius, Cancers 2014, 6, 2224; d) L. Santo, K. T. Siu, N.
Raje, Semin. Oncol. 2015, 42, 788; e) C. Sanchez-Martinez, L. M.
Gelbert, M. Jose Lallena, A. de Dios, Bioorg. Med. Chem. Lett. 2015,
25, 3420; f) U. Asqhar, A. K. Witkiewicz, N. C. Turner, E. S. Knudsen,
Nat. Rev. Drug Discovery 2015, 14, 130.
388.1246.
(R)-N-[(3-{[4-(4-Fluoro-2-methoxyphenyl)-1,3,5-triazin-2-yl]amino}-
benzyl)(methyl)oxido-6-sulfanylidene]acetamide (33)
Acetyl chloride (22 mg, 0.28 mmol) was added dropwise to a solution of
BAY 1143572 (100 mg, 0.26 mmol) in TEA (31 mg, 0.31 mmol) and DCM
(3.0 mL) at 0 °C. The ice bath was removed and the mixture was stirred
at RT for 3 h. Then, the mixture was diluted with water and extracted with
DCM (3 ×). The combined organic phases were filtered using a Whatman
filter and concentrated. The residue was purified by preparative HPLC
(acidic conditions) to give 33 as a white solid (63 mg, 0.15 mmol, 57%):
1H NMR (600 MHz, [D6]DMSO): = 2.14 (s, 3H), 3.05 (s, 3H), 3.94 (s,
3H), 4.67 (d, 1H), 4.80 (d, 1H), 6.74–6.83 (m, 2H), 7.17 (d, 1H), 7.42 (t,
1H), 7.82 (br s, 2H), 7.97 (br s, 1H), 8.03 (br s, 1H), 8.83 ppm (s, 1H);
ESI-HRMS: m/z [M + H]+ calcd for C20H21FN5O3S: 430.1349, found:
430.1346.
[2]
a) M. E. Law, P. E. Corsino, S. Narayan, B. K. Law, Mol. Pharmacol.
2015, 88, 846; b) B. O’Leary, R. S. Finn, N. C. Turner, Nat. Rev. Clin.
Oncol. 2016, 13, 417.
[3]
[4]
[5]
S. Cho, S. Schroeder, M. Ott, Cell Cycle 2010, 9, 1697.
V. Krystof, S. Baumli, R. Fürst, Curr. Pharm. Des. 2012, 18, 2883.
See, for example: a) R. E. J. Beckwith, D. T. Curtis, E. Harrington, J.
H.-H. Hinrichs, J. A. Tallarico (Novartis AG), WO 2008079933, 2008; b)
M. Augustin, L. Zeitlmann, G. Stumm, M. A. Pleiss, P. Wabnitz, H.
Allgeier (Ingenium Pharmaceuticals AG), WO 2008049856, 2008; c) H.
Allgeier, M. Augustin, A. Mueller, L. Zeitlmann, A. Marquardt, M. A.
Pleiss, U. Heiser, A. J. Niestroj (Ingenium Pharmaceuticals AG), WO
2009047359, 2009; d) P. Barsanti, C. Hu, J. Jin, R. Keyes, R. Kucejko,
X. Lin, Y. Pan, K. B. Pfister, M. Sendzik, J. Sutton, L. Wan (Novartis
AG), WO 2011012661, 2011; e) M. W. Nowicki, M. D. Walkinshaw,
Chem. Biol. 2010, 17, 1047; f) X. Liu, S. Shi, F. Lam, C. Pepper, P. M.
Fischer, S. Wang, Int. J. Cancer 2012, 130, 1216; g) H. Shao, S. Shi, S.
Huang, A. J. Hole, A. Y. Abbas, S. Baumli, X. Liu, F. Lam, D. W. Foley,
P. M. Fischer, M. Noble, J. A. Endicott, C. Pepper, S. Wang, J. Med.
Delivery/AstraZeneca-boosts-oncology-arsenal-with-CDK9-inhibitor-
platform (accessed July, 2017); i) J. Gong, Z.-F. Tao, Y. Tong, G. Zhu,
T. Penning, A. J. Souers (Abbvie Inc.), WO 2014151444, 2014; j) T. Yin,
M. J. Lallena, E. L. Kreklau, K. R. Fales, S. Carballares, R. Torrres, G.
N. Wishart, R. T. Ajamie, D. M. Cronier, P. W. Iversen, T. I. Meier, R. T.
Foreman, D. Zeckner, S. E. Sissons, B. W. Halstead, A. B. Lin, G. P.
Donoho, Y. Qian, S. Li, S. Wu, A. Aggarwal, X. S. Ye, J. J. Starling, R.
B. Gaynor, A. de Dios, J. Diu, Mol. Cancer Ther. 2014, 13, 1442; k) F.
Morales, A. Giordano, Cell Cycle 2016, 15, 519.
X-ray structure determination of 33
Single crystals of 33 were obtained by slow evaporation of an ethyl
acetate solution of 33 at RT. A single crystal was mounted on a
CryoLoop using inert oil. Data collection was carried out using a Bruker
diffractometer equipped with an APEX II CCD area detector, an IS
microsource with Cu K radiation, mirrors as monochromator and a
Kryoflex low temperature device (T = 110 K). The program APEX II
v.2011.8-0 was used for data collection and reduction.[29] Absorption
correction and scaling was performed using SADABS.[30] The crystal
structure solution was achieved using direct methods as implemented in
SHELXTL version 6.14[31] and visualized using the XP program[31]
.
Missing atoms were subsequently located from difference Fourier
synthesis and added to the atom list. Least-squares refinement on F2
using all measured intensities was carried out using the program
SHELXTL version 6.14.[31] All non-hydrogen atoms were refined including
anisotropic displacement parameters. Final data collection and structure
refinement parameters: = 1.54178 Å, T = 110 K, space group = P2(1),
a = 10.3041(8) Å, b = 7.9030(9) Å, c = 12.8716(11) Å , = 108.990(5)°, Z
[6]
[7]
[8]
P. L. Toogood, P. J. Harvey, J. T. Repine, D. J. Sheehan, S. N.
VanderWel, H. Zhou, P. R. Keller, D. J. McNamara, D. Sherry, T. Zhu, J.
Brodfuehrer, C. Choi, M. R. Barvian, D. W. Fry, J. Med. Chem. 2005,
48, 2388.
= 2, reflections collected = 6794, independent reflections = 1261 (Rint
=
0.0848), completeness = 98.2%, data-to-parameter ratio = 11.5, R1 (I >
2) = 0.061, wR2 (all data) = 0.1420, GOF = 0.988, Flack parameter =
0.05(4), largest difference peak and hole = 0.297/–0.262 e·Å–3. The
crystallographic data for 33 have been deposited with the Cambridge
Crystallographic Data Centre with the code CCDC 1565910.
D. Parry, T. Guzi, F. Shanahan, N. Davis, D. Prabhavalkar, D. Wiswell,
W. Seghezzi, K. Paruch, M. P. Dwyer, R. Doll, A. Nomeir, W. Windsor,
T. Fischmann, Y. Wang, M. Oft, T. Chen, P. Kirschmeier, E. M. Lees,
Mol. Cancer Ther. 2010, 9, 2344.
a) G. Siemeister, U. Lücking, A. M. Wengner, P. Lienau, W. Steinke, C.
Schatz, D. Mumberg, K. Ziegelbauer, Mol. Cancer Ther. 2012, 11,
2265; b) U. Lücking, R. Jautelat, M. Krüger, T. Brumby, P. Lienau, M.
Schäfer, H. Briem, J. Schulze, A. Hillisch, A. Reichel, A. M. Wengner, G.
Siemeister, ChemMedChem 2013, 8, 1067.
Acknowledgements
[9]
M. Herbrink, J. H. M. Schellens, J. H. Beijnen, B. Nuijen, J. Controlled
Release 2016, 239, 118.
We thank K. Sauvageot-Witzku, R. Golde, A. Glowczewski, C.
Pakebusch, N. Gallus and R. Droschinski for technical support,
O. Schenk for HPLC separations, S. Gründemann and G. Depke
for analytical support, and U. Ganzer for the measurement of
[10] C. Bissantz, B. Kuhn, M. Stahl, J. Med. Chem. 2010, 53, 5061.
[11] H. R. Bentley, E. E. McDermott, J. Pace, J. K. Whitehead, T. Moran,
Nature 1949, 163, 675.
