FRET Studies of Quinolone-Based Bitopic Ligands and
their Structural Analogues at the Muscarinic M1 Receptor
Regina Messerer, Michael Kauk, Daniela Volpato, Maria Consuelo Alonso Cañizal,
Jessica Kloeckner, Ulrike Zabel, Susanne Nuber, Carsten Hoffmann, and Ulrike Holzgrabe
ACS Chem. Biol., Just Accepted Manuscript • DOI: 10.1021/acschembio.6b00828 • Publication Date (Web): 24 Jan 2017
Downloaded from http://pubs.acs.org on January 25, 2017
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
ACS Chemical Biology is published by the American Chemical Society. 1155 Sixteenth
Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 27
ACS Chemical Biology
1
2
3
4
5
1
2
FRET Studies of Quinolone-Based Bitopic Ligands and their Structural Analogues at the
Muscarinic M1 Receptor
6
3
7
8
9
4
5
6
Regina Messerera, ⱡ, Michael Kaukb, c, ⱡ, Daniela Volpatoa, Maria Consuelo Alonso Canizalb,c,
Jessika Klöcknera, Ulrike Zabelb,c, Susanne Nuberb,c, Carsten Hoffmannb, c, * and Ulrike
Holzgrabea, *
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
7
8
9
a Department of Pharmaceutical and Medical Chemistry, Institute of Pharmacy, University
of Würzburg, Am Hubland, 97074 Würzburg, Germany
10
11
b Department of Pharmacology and Toxicology, University of Würzburg, Versbacher Str. 9,
97078 Würzburg, Germany
12
13
c Rudolf Virchow Center for Experimental Biomedicine, University of Würzburg, Josef
Schneider Straße 2, 97080 Würzburg, Germany
14
15
16
17
Author Information
ⱡ R.M. and M.K. contributed equally.
* Corresponding author: e-mail address:
18
19
ulrike.holzgrabe@uni-wuerzburg.de (Prof. Dr. Ulrike Holzgrabe); tel.: +49 931 31-85460;
fax: +49 931 31-85494.
20
21
c.hoffmann@toxi.uni-wuerzburg.de (Prof. Dr. Carsten Hoffmann); tel.: +49 931 31-48304;
fax: +49 931 31-48539.
22
23
Keywords:
24
25
Quinolones, Bitopic ligands, Partial Agonism, Allosteric Modulation, M1 muscarinic
receptor, FRET.
26
27
1
ACS Paragon Plus Environment

ACS Chemical Biology
Page 2 of 27
1
2
3
28
Abbreviations:
4
5
6
7
8
29
30
31
32
33
ACh, acetylcholine; BQCA, benzyl quinolone carboxylic acid; CFP, cyan fluorescent protein;
DAG, diacylglycerol; FlAsH, fluoresceine arsenical hairpin binder; FRET, fluorescence
resonance energy transfer; GPCR, G protein-coupled receptor; IL, intracellular loop; M1,
muscarinic acetylcholine subtype 1; mAChR, muscarinic acetylcholine receptor; PAM,
positive allosteric modulator; YFP, yellow fluorescent protein.
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
34
35
Abstract
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
Aiming to design partial agonists as well as allosteric modulators for the M1 muscarinic
acetylcholine (M1AChR) receptor, two different series of bipharmacophoric ligands and
their structural analogues were designed and synthesized. The hybrids were composed of
the benzyl quinolone carboxylic acid (BQCA) -derived subtype selective allosteric
modulator 3 and the orthosteric building block 4-((4,5-dihydroisoxazol-3-yl)oxy)-N,N-
dimethylbut-2-yn-1-amine (base of iperoxo)
1 or the endogenous ligand 2-
(dimethylamino)ethyl acetate (base of acetylcholine) 2, respectively. The two
pharmacophores were linked via alkylene chains of different lengths (C4, C6, C8, and
C10). Furthermore, the corresponding structural analogues of 1, 2 and of modified BQCA
3 with varying alkyl chain length between C2 and C10 were investigated. Fluorescence
resonance energy transfer (FRET) measurements in a living single cell system were
investigated in order to understand how these compounds interact with a G protein-
coupled receptor (GPCR) on a molecular level and how the single moieties contribute to
ligand receptor interaction. The characterization of the modified orthosteric ligands
indicated that a linker attached to an orthoster rapidly attenuates the receptor response.
Linker length elongation increases the receptor response of bitopic ligands, until reaching
a maximum, followed by a gradual decrease. The optimal linker length was found to be six
methylene groups at the M1AChR. A new conformational change is described that is not
of inverse agonistic origin for long linker bitopic ligands and was further investigated by
exceptional fragment based screening approaches.
56
57
2
ACS Paragon Plus Environment

Page 3 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
58
59
60
61
62
63
64
65
1) Introduction
Muscarinic acetylcholine receptors (mAChRs) belong to class A of G protein-coupled
receptors (GPCRs) and are divided into five M receptor subtypes (M1-M5). These subtypes
regulate the activity of many important functions of the peripheral and central nervous
system. They differ in their appearance and physiological function; e.g. the M1 muscarinic
acetylcholine receptor is mostly expressed in the central nervous system (cortex,
hippocampus and striatum) and is therefore an interesting therapeutic target for the
treatment of Alzheimer`s disease and schizophrenia.1, 2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
The orthosteric binding pocket appears to be homologues among the five receptor
subtypes.3 This issue is challenging for developing subtype selective therapeutics. To our
knowledge Spalding et al.4 described for the first time an alternative - allosteric binding
region at M1 receptors. This region does not show a high sequence identity and is thus, a
promising target for developing subtype selective allosteric modulators. Allosteric
modulators can influence the affinity of ligands bound to the topographically distinct
orthosteric site, either in a positive, neutral or negative manner.5 The benzyl quinolone
carboxylic acid (BQCA) and their analogues were among others reported by Kuduk et al.
to be positive allosteric modulators (PAMs) with respect to orthosteric agonist binding,
including the endogenous neurotransmitter acetylcholine, and function in M1 receptors.6,
7, 8, 9
To combine the advantages of the two binding sites, the concept of bitopic ligands
was developed.10 These ligands engage the allosteric and orthosteric site simultaneously.
Recently, bipharmacophoric ligands consisting of the base of the superagonist iperoxo 111,
12
and a benzyl quinolone carboxylic acid moiety 3 were designed, and found to act as
partial hM1 receptor agonists.13
81
82
83
84
85
86
87
88
For the last two decades a series of different receptor sensors, based on fluorescence
resonance energy transfer (FRET), were generated for different GPCRs.14, 15, 16 Usually,
such sensors are tagged C-terminally with cyan fluorescent protein (CFP) and in the third
intracellular loop (IL) region with a yellow fluorescent protein (YFP) or a tetracysteine
motif capable of binding a small soluble fluorophore called fluoresceine arsenical hairpin
binder (FlAsH). These receptor sensors proved to be valuable tools for pharmacological
characterizations in intact cells, especially for monitoring receptor activation in real time
and to investigate receptor ligand interaction on a molecular level.17, 18 According to Chen
3
ACS Paragon Plus Environment

ACS Chemical Biology
Page 4 of 27
1
2
3
4
5
6
7
8
9
89
90
et al., structure-activity relationships (SARs) showed that the BQCA analogue containing a
benzyl moiety at the nitrogen atom as well as a 6-fluoro substituted aromatic ring
resulted in a partial hM1 receptor agonist.13 Due to these findings, the same structural
BQCA modification was used for the herein newly designed compounds. Thus, analogues
of the superagonist 1, orthosteric agonist 2, and of the BQCA-derived subtype selective
allosteric modulator 3 were designed, synthesized and characterized, resulting in
modified analogues with varying alkyl chain length between C2 and C10 (1-Cn, 2-Cn, and
4-Cn, where n gives the length of the linker, i.e. the number of C-atoms, Scheme 1 and
Scheme 2). The attachment point was chosen on the tetramethyl moiety as this group
points out of the orthosteric binding pocket as seen for iperoxo.19 Furthermore, the
fluoro-substituted allosteric BQCA moieties were linked to the base of orthosteric
agonists iperoxo and to the base of acetylcholine, aiming to design bipharmacophoric M1
receptor agonists (5-C and 6-C, Scheme 2). The linker elongation on the BQCA modified
pharmacophore was attached on the carboxylic acid residue due to molecular modeling
studies suggesting that the carboxylic acid position points out toward the extracellular
site of the receptor.20 Furthermore, the carboxylic moiety is a suitable attachment point
for improving allosteric modulation. For the pharmacological characterization of these
ligands a novel M1 FRET sensor was used. This study provides an insight into M1 receptor
activation, receptor conformational changes monitored by the movement of fluorescent
labeled domains, and signaling behavior.
91
92
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
2) RESULTS AND DISCUSSION
111
112
113
114
115
116
117
118
2.1) Chemistry. The reaction sequences of the iperoxo analogues 1-C2 to 1-C10 and of the
acetylcholine analogues 2-C4, 2-C6, 2-C8, and 2-C10 are illustrated in Scheme 1. 4-((4,5-
dihydroisoxazol-3-yl)oxy)-N,N-dimethylbut-2-yn-1-amine11 (base of iperoxo) 1 and 2-
(dimethylamino)ethyl acetate (base of acetylcholine) 2, respectively, were reacted with
the corresponding bromoalkane in acetonitrile, affording the final monoquaternary
ammonium salts 1-C2 to 1-C10 and 2-C4, 2-C6, 2-C8, and 2-C10 in 48-91% yield. The
synthesis of the acetylcholine analogues 2-C4, 2-C6, and 2-C8 were described previously
using a different synthetic pathway.21
4
ACS Paragon Plus Environment

Page 5 of 27
ACS Chemical Biology
1
2
3
4
5
6
119
120
Insertion of Scheme 1 about here
7
8
9
121
122
123
124
125
126
127
128
129
130
131
132
As already reported, the fluoro-4-oxo-quinolone skeleton of 8 was synthesized using the
Gould-Jacobs procedure, starting off with the condensation of 4-fluoroaniline with diethyl
2-(ethoxymethylene)-malonate and subsequent cyclization in boiling diphenyl
ether.22, 23, 24 Ester hydrolysis led to compound 3.25 Conversion of the ester function (9)
with the aminoalcohols of the corresponding spacer length (C4, C6, C8, C10), substitution
of the alcohol function with a bromine atom using HBr/H2SO4 and subsequent reaction
with trimethylamine in acetonitrile at 40 °C led to the monoquaternary ammonium salts
4-C4, 4-C6, 4-C8, and 4-C10 in 53-96% yield. For the preparation of the final
BQCA/iperoxo hybrids 5-C4, 5-C613, 5-C8, and 5-C10 as well as the BQCA/ACh hybrids 6-
C4, 6-C6, 6-C8, and 6-C10, the intermediate bromides were connected to the base of
iperoxo and to the base of acetylcholine, respectively, in the presence of KI/K2CO3 in
acetonitrile (Scheme 2).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
133
134
135
Insertion of Scheme 2 about here
2.2) Pharmacology/Fret measurements
136
137
138
139
140
141
142
143
144
145
146
147
148
2.2.1) Receptor sensor and ligand characterization. In comparison to the previously
reported M1-, M3-, M5-26 and M2-ACh receptor FRET-sensors 27, we created a novel full
length FRET sensor of the human M1-ACh receptor which was not truncated in the 3rd
intracellular loop (IL3). This novel sensor consists of the native amino acid sequence fused
at the receptor C-terminus to CFP by adding the amino acids Ser/Arg encoding for an XbaI
site. Additionally, a FlAsH binding motif CCPGCC was inserted between Gly227 and Ser228
(Fig. 1a) at the N-terminal part of IL3 shortly underneath transmembrane domain 5
outside of the G protein-coupling region.28 The receptor construct M1-I3N-CFP expressed
well at the cell surface as analyzed by confocal scanning laser microscopy (Supplementary
Figure 1). Since the previously published truncated sensors were not different from wild-
type receptors in radioligand binding,17 we characterized only functional response of the
novel sensor. To evaluate the effect of the six amino acid insertion into the M1-CFP
receptor we used a dual fluorescence probe, which responds with an increase in red
5
ACS Paragon Plus Environment

ACS Chemical Biology
Page 6 of 27
1
2
3
4
5
6
7
8
9
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
fluorescence intensity upon increase in Ca2+ and a decrease in green fluorescence upon
binding to diacylglycerol (DAG). Therefore, the probe can specifically report on the
activation of Gq-signalling.29 The dual fluorescent probe was transfected in HEK293 cells
either alone or co-expressed with the M1-CFP or the novel M1-I3N-CFP sensor and
analyzed by confocal microscopy (see supplementary information for details). The dual
probe did not respond to carbachol if no receptor was co-transfected. As shown in
Supplementary Figure 2 the carbachol stimulated response was indistinguishable for the
M1-CFP receptor or the M1-I3N-CFP sensor. In combination with previous binding
experiments on a truncated sensor version17 it was concluded that this sensor is not
disturbed in its signaling properties by insertion of the CCPGCC sequence. For further
FRET experiments the M1-I3N-CFP was stably expressed in HEK293 cells and single cells
were used for further analysis. To study dynamic conformational changes in real time the
M1-I3N-CFP sensor was exposed to the endogenous agonist ACh and the synthetic full
agonist iperoxo. To eliminate potential artefacts from changes in flow rates, the cells
were constantly superfused with buffer. Under these conditions the receptor sensor
shows a constant baseline. Upon ligand addition a sharp antiparallel movement of the
CFP and FlAsH signal was observed (Supplementary Figure 3), resulting in a concentration
dependent change in the FRET signal of 8-12% for iperoxo (Fig. 1b). When the superfusion
solution was switched back from agonist to buffer, the signal returned to the baseline. A
slight reduction of the FRET signal over time was detectable and could be due to
photobleaching. To prevent artificial underestimation of ligand efficacy reference and
ligand were measured in an alternating exposure regime. Thus, we were able to generate
concentration dependent response (Fig. 1c) curves for the endogenous agonist ACh
(EC50 = 2.91 µM) and the synthetic full agonist iperoxo (EC50 = 0.57 µM). The observed
EC50 value for ACh is in very good agreements with previously obtained value using the
truncated receptor sensor.17 Due to a five-fold higher potency of iperoxo compared to
ACh, the base of iperoxo 1 was chosen as the orthosteric building block for the studied
bitopic ligands to ensure high receptor activation via the orthosteric binding site.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
177
178
179
180
As allosteric building block a structural analogue of benzyl quinolone carboxylic acid
(BQCA) origin was chosen. In 2009, BQCA was reported to be a M1 selective positive
allosteric modulator (PAM)9 whose binding region was studied in detail.20 However, an
essential property of allosteric modulators is probe dependency. Thus, an experimental
6
ACS Paragon Plus Environment

Page 7 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
approach to show this cooperative effect of BQCA analogue (3) combined with iperoxo
(Fig. 1d) was designed. To study positive modulation, a concentration of iperoxo which
results in approximately 20% of the maximal observed signal (EC20) was chosen. This way
a clear signal was observed and still a large detection range to observe positive allosteric
modulation was available. As seen in Figure 1d by applying the allosteric modulator 3
alone, a small conformational change was found. This small response was not clearly
detectable for all cells measured. This might be explained by the very small signal that
could not always be distinguished from noise. When applying saturating concentrations of
iperoxo, a significant signal was monitored. Next iperoxo at 0.1 µM concentration was
applied which results in 25% signal compared to saturating ligand concentrations. Now
the superfusion was changed to a mix of iperoxo and 3 and again back to iperoxo alone. A
clear enhanced receptor response was observed by applying 3 and iperoxo at the same
time, compared with the appropriate iperoxo response. This enhanced response is higher
than a theoretical additive effect of the conformational changes induced by 3 and iperoxo
alone and can be described as positive allosteric modulation.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
2.2.2) Linker elongation attenuates orthosteric properties. Besides their orthosteric and
allosteric moieties, bitopic ligands consist of a linker region that is often not investigated
in a systematic way and hence, the linker is often inappropriately treated. To date the
molecular effects of additional carbon atoms at an orthosteric ligand for muscarinic
receptors are still unknown. Therefore, nine different structural analogues of 1 with a
linker attached to the amine group were synthesized (Scheme 1, 1-C2 to 1-C10). These
compounds were investigated via FRET for their ability to induce a conformational change
at the M1 receptor. The results are summarized in Figure 2. Figure 2a shows a single FRET
experiment comparing the effect of iperoxo and different concentrations of 1-C2 and 1-
C3. Even saturating concentrations of 1-C2 exhibit a much reduced FRET signal compared
to the reference compound iperoxo. From these data it can be concluded, that additional
methylene units significantly reduce the efficacy to 65% compared to iperoxo.
Nonetheless it was possible to generate a concentration response curve for 1-C2. Besides
the reduced efficacy a 3-fold lower affinity (EC50 (1-C2) = 1.65 µM) to the receptor sensor
became evident (Fig. 2b). For 1-C3 a more than 80% reduced conformational change was
found. These signals were too small to establish a reliable concentration response curve.
The iperoxo analogues (1-C4 to 1-C10) did not induce any conformational change at the
7
ACS Paragon Plus Environment

ACS Chemical Biology
Page 8 of 27
1
2
3
4
5
6
7
8
9
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
receptor sensor (Fig. 2c). In order to test, whether the linker extended ligands were able
to bind the receptor sensor at the orthosteric binding site, competition experiment were
performed shown in Figure 2d. To test for binding of 1-C6 first 10 µM of iperoxo as a
concentration which induces 80% of the maximal signal response (EC80) was applied. In
the first case a single ligand to the receptor sensor was superfused (Fig 2d). Next, a 10 µM
solution of iperoxo with 100 µM of the linker analogue 1-C6 was added. As can be seen in
Figure 2d, the receptor response induced by the ligand mix was significantly reduced
compared to the signal induced by iperoxo alone, most likely indicating, that the two
ligands compete for the orthosteric binding site and that the 1-C6 analogue shows affinity
to the orthosteric binding site but does not exhibit efficacy as shown by the lack of
conformational changes in Figure 2c. In Figure 2e the results for a corresponding set of
ligands of ACh origin (Scheme 1) is displayed. The given FRET trace proves, that a distinct
linker elongation at an orthosteric ligand attenuates orthosteric efficacy. This
phenomenon could be due to a steric hindrance within the binding pocket or due to
preventing an essential receptor movement like closing the aromatic lid, which was
proposed before to be essential for receptor activation.19
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
2.2.3) Evaluation of Bitopic ligands. Bitopic ligands are thought to interact with both
orthosteric and the allosteric binding site at the same time.10 They are also thought to
interact with the receptor in a dynamic binding mode, which consist at least of two
different states.30, 31 Abdul-Ridha et al.20 investigated both binding sites in great detail by
mutational analysis. Using this approach, it was possible to restrict the relative position of
both moieties to a certain area of the receptor.20 In combination with the crystal
structure of iperoxo bound to the M2-receptor subtype19 and the recently published
crystal structure of the M1-receptor subtype3, we focused on bitopic ligands with
different linker length consisting of either four, six, eight or ten carbon atoms. Thus, these
ligands cover a relative distance of 6 Å to 15 Å between both pharmacophore moieties
and hence representing the seven transmembrane helical core. A series of bitopic ligands
consisting of the base of iperoxo (1) and the BQCA analogue (3) were synthesized
(Scheme 2). Correspondingly these ligands are called 5-Cn with n reflecting the linker
length (4, 6, 8, 10) (Scheme 2). As can be seen in Figure 3a, showing a representative FRET
trace of 5-C6, clear concentration dependent increase in conformational change has
taken place. This is the largest conformational change at this FRET sensor compared to all
8
ACS Paragon Plus Environment

Page 9 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
other structural analogues in this series. All other ligands were also able to induce a
conformational change at the M1 receptor sensor. Figure 3b shows the maximal ligand
induced changes in comparison to iperoxo. The dashed line indicates the maximal
observed signal for the allosteric moiety 3 when tested alone. Since all corresponding
iperoxo linker analogues (1-C4 to 1-C10) alone did not induce a conformational change
(cf. Fig. 2c), the difference in conformational changes of the hybrids above the dashed
line should either result from the positive cooperativity between the orthosteric and
allosteric moieties, or an alternative binding pose. Moreover, for the M1 receptor the
optimal linker length for the combination of 1 and 3 is in the range of six methylene
groups (see Fig. 3b), whereas for the M2-receptor subtype longer linker lengths are
necessary to improve bitopic ligand efficacy.30 Thus, the optimal linker length as well as
the nature of the linker chain are crucial for receptor activation and are different for each
receptor subtype, depending on their tertiary structure. A first indication for receptor
subtype selectivity among acetylcholine receptors is shown in supplementary figure 4.
Compound 5-C6 was tested at a previously published M3-ACh receptor FRET sensor26 and
did not evoke a conformational change as observed for iperoxo. Furthermore, after
reaching an optimal linker length, the efficacy of bitopic ligands decline by further linker
elongation (Fig. 3b). Surprisingly, when investigating compound 5-C10 a concentration
dependent signal with opposite signal direction compared to iperoxo was found (Fig. 3C).
Since changes in FRET signals in general represent a relative distance change this property
was used as a readout for conformational changes at GPCRs. The opposite FRET signal
induced by 5-C10 was not observed before for any bitopic ligand at M-receptors.
Comparable inverse FRET signals were reported for inverse agonistic responses at
constitutively active mutants of the α2a adrenergic receptor32 and the M3 mutant33. At
constitutively active M3 receptors, atropine behaves as an inverse agonist. Hence, to
compare the effect found for 5-C10 at the M1-I3N-CFP with eventual constitutive activity,
the effect of atropine at this construct was studied. However, neither atropine nor
tiotropium did induce any conformational change (see Fig. 3d or Supplementary Figure 5),
arguing against constitutive activity as an explanation for the behavior of 5-C10. Of note,
the high receptor affinity of atropine becomes visible by the fact, that it was almost
impossible to induce a second signal for iperoxo after the first application of 10 µM
atropine. To further study the surprising effect of 5-C10, a series of bitopic ligands based
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
9
ACS Paragon Plus Environment

ACS Chemical Biology
Page 10 of 27
1
2
3
4
5
6
7
8
9
277
278
279
280
281
282
on acetylcholine as orthosteric building block 6-C4 to 6-C10 (Scheme 2) was investigated.
Figure 3e displays a representative FRET trace of acetylcholine based bitopic ligands and
the bar graph in Figure 3f summarizes the measured FRET-signals. Again a linker length
dependent receptor response was found. Moreover, again inverse FRET-signals for bitopic
ligands of longer chain length were detected. Interestingly, for this compound series a
FRET-signal with similar direction as observed for ACh was never detected.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
2.2.4) Linker fusion at the allosteric building block. In order to find out, why bitopic
ligands with longer linkers produce an inverse FRET signal it was of interest to unravel the
moiety of the ligands contributing to the observed signals. Additionally, the question
arose whether it would be possible to reconstruct the signal derived by different bitopic
ligands by combining the individual components in a fragment-based screening approach
in a single cell. Therefore, the ligands 5-C6 and 5-C10 who showed the most extreme
signals were studied. As shown in Figure 1d the BQCA analogue (3) induces a small
conformational change but the corresponding linker extended iperoxo analogue (1-C6)
did not exhibit a detectable effect at our receptor sensor (Fig. 2c), but 1-C6 binds to the
receptor (Fig. 2d). Both effects are shown in Figure 4a, this time measured at the same
cell. By applying both compounds (3 and 1-C6) at the same time a receptor response was
observed that was on the one hand significantly different to the BQCA response but on
the other hand similar in the maximal signal intensity as reported before for the bitopic
ligand 5-C6 (Fig. 3a), indicating first that it is possible to reconstruct the effect of a bitopic
ligand interacting with a receptor by applying the fragments at the same time to the
receptor sensor, and second that there is cooperativity between the allosteric modulator
BQCA (3) and the ligand 1-C6, which showed high affinity to the orthosteric binding site.
300
301
302
303
304
305
306
307
Comparable experiments were performed with the ligand 5-C10 and its respective
building blocks (Fig. 4b). Interestingly in this case it was impossible to reconstruct the
signal of the bitopic ligand by applying the single fragments, suggesting, that the inverse
signal is likely mechanistically different to the agonistic signal. Interestingly at the M2
mAChR, iperoxo-based bitopic ligands have been shown to bind in at least two different
binding poses31 and one of them was shown to be purely allosteric. This has recently been
further investigated by molecular modeling.34 In an attempt to explain the inverse FRET
signal mechanistically, the set of compounds 4-C4 to 4-C10, consisting of the allosteric
10
ACS Paragon Plus Environment

Page 11 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
308
309
310
311
312
313
314
315
316
317
moiety, was studied. Here a linker moiety of different length and a tertiary amine are
combined to imitate the positively charged amine of the orthosteric ligand (Scheme 2) in
the presence of the allosteric moiety. Figure 4c displays a representative FRET trace
recorded for a single cell that was super-fused with the indicated ligands. Increasing linker
length lead to the appearance of an inverse signal for compound 4-C8 and 4-C10 even in
the absence of the orthosteric moiety similar to the signal observed for compound 5-C10
or 6-C10. This result supports the notion of an alternative second binding pose for the
linker extended bitopic ligands at the M1 receptor, as recently described for the M2
receptor.34 Another hypothesis is the possible binding of the ligands to two allosteric
binding sites in a dimeric receptor.35
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
2.3) Concluding remarks. Bitopic ligands are molecular entities, which bind to more than
one pharmacological interesting region of membrane proteins and are thought to have an
impact on further drug development. This study provides a molecular insight of the
interactions between GPCRs and bitopic ligands for a better understanding of ligand
receptor interactions on a molecular level. Here, linker dependent responses of bitopic
ligands at a M1 receptor FRET sensor were investigated. The findings indicate an optimal
linker length of the bitopic ligands for conformational changes at the M1 mAChR. This
optimal linker length is probably different for each receptor subtype and is likely
dependent on the individual receptor architecture. Furthermore, a previously unknown
conformational change for GPCRs induced by bitopic ligands of long linker length was
observed. Furthermore, an understanding of the origin of different conformational
changes of GPCRs is provided. The influences of the reported movements on the
downstream signaling of GPCRs are subjects of current studies. Bitopic ligands were
discussed critically due to the fact, whether the lipophilic linker can pass the aromatic lid
of muscarinic receptors. Here, it could be shown that an increased linker first hampers
the orthoster to induce a conformational change although there is a distinct affinity to the
orthosteric binding region. This phenomenon might be due to a steric clash with the
aromatic lid structure in muscarinic acetylcholine receptors. Moreover, the findings
indicate, that this fact is no longer true for the bitopic analogues indicating that here the
linker is able to interact with the aromatic lid without being sterically hindered.
11
ACS Paragon Plus Environment

ACS Chemical Biology
Page 12 of 27
1
2
3
339
4
5
6
7
8
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
3) METHODS
3.1) Chemistry. Melting points were determined with a Stuart melting point apparatus
SMP3 (Bibby Scientific) and are uncorrected. H (400.132 MHz) and 13C (100.613 MHz)
1
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
NMR spectra were recorded on a Bruker AV 400 instrument (Bruker Biospin). As internal
standard, the signals of the deuterated solvents were used (DMSO-d6: H 2.5 ppm, 13C
1
39.52 ppm; CDCl3: H 7.26 ppm, 13C 77.16 ppm). Abbreviation for data quoted are: s,
1
singlet; d, doublet; t, triplet; q, quartet; m, multiplet; b, broad; dd, doublet of doublets;
dt, doublet of triplets; tt, triplet of triplets; tq, triplet of quartets. Coupling constants (J)
are given in Hz. TLC analyses were performed on commercial pre-coated plates, silica gel
60 F254 (Macherey-Nagel); spots were further evidenced by spraying with Dragendorff
reagent, 36 for amines. ESI mass spectra of the compounds were obtained on an Agilent
LC/MSD Trap G2445D instrument. Data are reported as mass-to-charge ratio (m/z) of the
corresponding positively charged molecular ions. Microwave assisted reactions were
carried out on a MLS-rotaPREP instrument (Milestone). Chemicals were of analytical
grade and purchased from Aldrich and Merck.
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
The purities of the compounds (2-C4, 2-C6, 2-C8, and 2-C10) were determined using
qNMR and were found to be >95% (method see supporting information). Purity of
compounds 1-C2, 1-C6, 1-C7, 1-C8, 1-C9, 1-C10, 5-C4, and 6-C6 were determined using
capillary electrophoresis and were found to be >95% (method see supporting
information). Compounds 1-C4 and 6-C4 (confirming purity >95%) and compounds 5-C8
and 5-C10 (confirming purity >90%) were measured on a HPLC system (Agilent 1100
series system with UV detector) using a C18 reversed-phase (Knauer) (150 x 4.6 mm)
column. The mobile phase (MeOH/phosphate buffer = 70/30) was used at a flow rate of
1.5 mL/min, detecting at 254 nm. The HPLC analyses of compounds 4-C4 (confirming
purity >90%) 4-C6, 4-C8, 4-C10, 6-C8, and 6-C10 (confirming purity >95%) were performed
on a LCMS 2020 Shimadzu. The LCMS-system from Shimadzu Products, contained a DGU-
20A3R degassing unit, a LC20AB liquid chromatograph and a SPD-20A UV/Vis detector.
Mass spectra were obtained by a LCMS 2020. As stationary phase a Synergi 4U fusion-RP
(150 * 4.6 mm) column and as mobile phase a gradient of MeOH/water was used.
Parameters for method: Solvent A: water with 0.1% formic acid, solvent B: MeOH with
12
ACS Paragon Plus Environment

Page 13 of 27
ACS Chemical Biology
1
2
3
4
5
6
370
371
372
0.1% formic acid. Solvent B from 0% to 90% in 13 min, then 90% for 5 min, from 90% to
5% in 1 min, then 5% for 4 min. The method was performed with a flow rate of 1.0
mL/min. UV detection was measured at 254 nm.
7
8
9
373
374
375
376
377
The compounds 1-C3, 1-C5,12 and 325 as well as 9, 10-C6, 11-C6, and 5-C613 were prepared
according to previously reported procedures. The synthesis of the 4-oxo-quinoline
skeleton 837, 38 was performed in analogy to the Gould-Jacobs procedure, using diethyl 2-
(ethoxymethylene)-malonate for the condensation with 4-fluoroaniline followed by
microwave assisted cyclization in diphenyl ether.22, 23, 24
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
378
379
380
381
382
383
384
385
386
3.1.1) General Procedure for the Synthesis of the Iperoxo Analogues 1-C2, 1-C4, 1-C6, 1-
C7, 1-C8, 1-C9, and 1-C10. To a solution of 4-((4,5-dihydroisoxazol-3-yl)oxy)-N,N-
dimethylbut-2-yn-1-amine11 0.45 g (2.47 mmol) in 10 mL of acetonitrile or chloroform, 5 -
10 equivalents of the corresponding 1-bromoalkane 7-C2 to 7-C10 and a catalytic amount
of KI/K2CO3 (1:1) were added. The mixture was stirred in a sealed container at a
temperature between 55 and 70 °C. The precipitate obtained was filtered and Et2O was
added to complete the precipitation. The solid was washed several times with Et2O, and
dried over P2O5 in vacuo.
387
388
389
390
391
392
393
394
395
3.1.2) General Procedure for the Synthesis of the Acetylcholine Analogues 2-C4, 2-C6, 2-
C8, and 2-C10. To a solution of 2-(dimethylamino)ethyl acetate 0.50 g (3.81 mmol) in
acetonitrile (10 mL), 2 equiv. of the corresponding 1-bromoalkane 7-C4, 7-C6, 7-C8, and 7-
C10 and a catalytic amount of KI/K2CO3 (1:1) were added. The reaction mixture was
heated in the microwave (500 W, 70 °C) for 4 h. After cooling to room temperature the
surplus of KI/K2CO3 was filtered and the filtrate was evaporated to the half of the volume.
After addition of Et2O, a viscous oil was formed. The solvent was decanted and the
product obtained was dried in vacuo.
396
397
398
399
3.1.3) General Procedure for the Synthesis of the Quinolone Analogues 4-C4, 4-C6, 4-C8,
and 4-C10. To a solution of bromoalkyl 4-oxo-quinoline-3-carboxamides 11-C4, 11-C6, 11-
C8, and 11-C10 (0.11 mmol) in acetonitrile (5 mL), trimethylamine (45% in H2O, 0.22
13
ACS Paragon Plus Environment

ACS Chemical Biology
Page 14 of 27
1
2
3
4
5
6
7
8
9
400
401
402
403
mmol) was added. The reaction was heated at 40 °C. After completion of the reaction
(5 h) controlled by TLC (CH2Cl2/MeOH = 85:15, Rf = 0.10 – 0.45), the mixture was cooled to
room temperature. The solvent was distilled off. The so obtained solid was crystallized
from acetonitrile, filtered and dried in vacuo.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
404
405
406
407
408
409
410
411
412
3.1.4) General Procedure for the Synthesis of the Quinolone-Iperoxo Hybrids 5-C4, 5-C8,
and 5-C10. To a solution of 1 equiv. of the bromoalkyl 4-oxo-quinoline-3-carboxamides
11-C4, 11-C8, and 11-C10 in 20 mL acetonitrile, 2 equiv. 4-((4,5-dihydroisoxazol-3-yl)oxy)-
N,N-dimethylbut-2-yn-1-amine11 and a catalytic amount of KI/K2CO3 (1:1) were added.
The reaction mixture was heated in the microwave (500 W, 80 °C) for 4 h. The reaction
was monitored by TLC (MeOH/NH4NO2 (0.2 M) = 3:2, Rf = 0.54 – 0.68). After cooling to
room temperature the surplus of KI/K2CO3 was filtered. Et2O was added to the filtrate to
obtain a precipitation. The solid was filtered, washed with Et2O and dried in vacuo.
413
414
415
416
417
418
419
420
3.1.5) General Procedure for the Synthesis of the Quinolone-Acetylcholine Hybrids 6-C4,
6-C6, 6-C8, and 6-C10. To a solution of 1 equiv. of the bromoalkyl 4-oxo-quinoline-3-
carboxamides 11-C4, 11-C8, and 11-C10 in 15 mL acetonitrile, 2 equiv. 2-
(dimethylamino)ethyl acetate and a catalytic amount of KI/K2CO3 (1:1) were added. The
reaction mixture was heated in the microwave (500 W, 80 °C) for 4.0 – 6.5 h. After cooling
to room temperature the surplus of KI/K2CO3 was filtered and Et2O was added to the
filtrate. The solid obtained was filtered, washed with Et2O and dried in vacuo.
421
422
3.2) Pharmacology
423
424
425
426
427
428
429
3.2.1) Construction of the hM1 receptor FRET sensor. Muscarinic ACh receptor construct
was C-terminally fused to the enhanced variants of cyan fluorescent protein (eCFP) (BD
Bioscience Clontech) by standard PCR extension overlap technique.39 The amino acid
sequence SR, coding for an Xba I restriction site, was inserted as a linker sequence
between receptor and fluorescent protein. In the third intracellular loop (IL3) an amino
acid motif was introduced, thus the novel sequence reads QG227CCPGCCSGS228E. It
specifically binds the fluorescein arsenical hairpin binder (FlAsH) and codes for a
14
ACS Paragon Plus Environment

Page 15 of 27
ACS Chemical Biology
1
2
3
4
5
430
431
restriction site. The construct was cloned into pcDNA3 (Invitrogen) and verified by
sequencing, done by Eurofins Genomics.
6
7
8
432
9
433
434
435
436
437
438
439
440
441
3.2.2) Stable cell line generation. Cells were seeded into a culture dish with a confluency
of 30% three hours before transfecting the cells with the Effectene® reagent ordered
from Quiagene. Reagent concentration and incubation times were applied in accordance
with the manufacturer’s instructions. 24 hours after transfecting the normal culture
medium was replaced by culture medium supplemented with 400 µg mL1 G-418. After
that the medium was refreshed every day until all untransfected cells died. Now the cells
were counted, diluted and applied to 48-well plates resulting in a one cell to well
distribution. This homogenous cell population were characterized with fluorescence
microscopy and were investigated concerning their cDNA content.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
442
443
444
445
446
447
3.2.3) Cell culture. HEK293 cells stably expressing the hM1 receptor FRET sensor were
maintained in DMEM with 4.5 g l 1, 10% (v/v) FCS, 100 U mL1 penicillin, 100 µg mL1
streptomycin sulfate and 2 mM L-glutamine and 200 µg mL 1 G-418. The cells were kept at
37 °C in a humidified 7% CO2 atmosphere and were routinely passaged every two to three
days. Untransfected HEK cells maintained in cell culture medium without G-418.
448
449
450
451
452
453
454
455
456
457
3.2.4) FlAsH labeling. A labeling protocol was applied as described previously.15, 40, 41 In
brief, cells were grown to near confluency on Poly-D-lysine coated glass coverslips.
Initially cells were washed with labeling buffer (150 mM NaCl, 10 mM HEPES, 2.5 mM KCl,
4 mM CaCl2, 2mM MgCl2 supplemented with 10 mM glucose (pH 7.3)). After that cells
were incubated with labeling buffer containing 500 nM FlAsH and 12.5 µM
1,2-ethanedithiol (EDT) for 1 h at 37 °C followed by flushing with labeling buffer. To
reduce non-specific FlAsH binding, the cells were incubated for 10 min with labeling
buffer containing 250 µM EDT. After flushing with labeling buffer the cells were held in
cell culture medium.
458
15
ACS Paragon Plus Environment

ACS Chemical Biology
Page 16 of 27
1
2
3
4
5
6
7
8
9
459
460
461
462
463
464
3.2.5) Ligand application.The reference ligands were prepared from 1 mM stock solutions
that were stored at -20 °C, taking into consideration, that at least acetylcholine remains
instable in solution.42 Used stock solutions have not been older than a couple of weeks.
Bitopic ligands or analogues were stored at 4 °C and were weighed out directly before the
experiment. Than the ligands were solubilized in measuring buffer (140 mM NaCl, 10 mM
HEPES, 5.4 mM KCl, 2 mM CaCl2, 1 mM MgCl2 (pH 7.3)) to a final concentration of 100 µM.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
3.2.6) Single cell FRET experiments. FRET measurements were performed using a Zeiss
Axiovert 200 inverted microscope endued with a PLAN-Neoflar oil immersion 100-
objective, a dual emission photometric system and a Polychrome IV light source (Till
Photonica) as described previously.15, 14 Experiments were conducted at 25 °C using live
HEK293 cells stably expressing the hM1 receptor FRET-sensor or the previously published
hM3 receptor FRET-sensor26 that were maintained in assay buffer. Single cells were
excited at 436 nm (dichroic 460 nm) with a frequency of 10 Hz. Emitted light was
recorded using 535/30 nm and 480/40 nm emission filters and a DCLP 505 nm beam
splitter for FlAsH and CFP, respectively. FRET was observed as the ratio of FlAsH/CFP,
which was corrected offline for bleed through, direct FlAsH excitation and photo
bleaching using the 2015 version of the Origin software as described recently. To
investigate changes in FRET on ligand addition, cells were continuously super fused with
FRET buffer complemented with various ligands in saturating concentrations as indicated.
Superfusion was done using the ALA-VM8 (ALA Scientific Instruments).
480
481
482
483
3.2.7) Data processing. Data are shown as means ± SD for n independent observations.
Fluorescence intensities were acquired using Clampex (Axon Instruments). Statistical
analysis and curve fitting were performed using Origin (OriginLab).
484
16
ACS Paragon Plus Environment

Page 17 of 27
ACS Chemical Biology
1
2
3
485
Supporting Information
4
5
6
7
8
486
487
488
489
Supporting Information Available: This material is available free of charge via the internet.
More detailed syntheses, elemental analyses data and spectral data of intermediate and
target compounds as well as calcium measurement procedure description and supporting
figures.
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
490
491
Acknowledgements
492
493
494
495
496
497
M. Kauk and D. Volpato were supported by the international doctoral college “Receptor
Dynamics: Emerging Paradigms for Novel Drugs” funded within the framework of the Elite
Network of Bavaria. M.C. Alonso Canizal was supported by the Marie Curie Initial Training
Networks (ITN) “WntsApp” grant agreement number 608180. We thank Montana
Molecular and Dr. Anne Marie Quinn for technical support and help to use the dual
sensor.
498
17
ACS Paragon Plus Environment

ACS Chemical Biology
Page 18 of 27
1
2
3
4
5
499
500
Scheme 1: Synthesis of orthosteric M1 agonist agents based on Iperoxo – and Acetylcholine
Analogues.
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
501
502
503
Reagents and conditions: (i) KI/K2CO3, CH3CN/CHCl3, 70 °C (48-89%); (ii) KI/K2CO3, CH3CN,
70 °C (microwave) (65-91%).
504
18
ACS Paragon Plus Environment

Page 19 of 27
ACS Chemical Biology
1
2
3
505
Scheme 2: Synthesis of Quinolone Analogues, BQCA/Iperoxo Hybrids and BQCA/ACh Hybrids.
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
506
507
508
509
510
Reagents and conditions: (i) benzyl chloride, K2CO3, DMF, 80 °C (72%); (ii) 6 N HCl, MeOH, reflux
(77%); (iii) H2N(CH2)nOH, 150 °C (28-33%); (iv) HBr (48%), H2SO4, reflux (73-93%); (v)
trimethylamine, CH3CN, 40 °C (53-96%); (vi) 1, KI/K2CO3, CH3CN, 80 °C (microwave) (37-66%); (vii)
2, KI/K2CO3, CH3CN, 80 °C (microwave) (19-73%).
511
19
ACS Paragon Plus Environment

ACS Chemical Biology
Page 20 of 27
1
2
3
4
5
512
513
References
6
7
8
9
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
[1] Wess, J. (2004) Muscarinic acetylcholine receptor knockout mice: novel phenotypes and
clinical implications, Annu. Rev. Pharmacol. Toxicol. 44, 423-450.
[2] Kruse, A. C., Kobilka, B. K., Gautam, D., Sexton, P. M., Christopoulos, A., and Wess, J. (2014)
Muscarinic acetylcholine receptors: novel opportunities for drug development, Nat. Rev. Drug.
Discov. 13, 549-560.
[3] Thal, D. M., Sun, B., Feng, D., Nawaratne, V., Leach, K., Felder, C. C., Bures, M. G., Evans, D. A.,
Weis, W. I., Bachhawat, P., Kobilka, T. S., Sexton, P. M., Kobilka, B. K., and Christopoulos, A.
(2016) Crystal structures of the M1 and M4 muscarinic acetylcholine receptors, Nature 531,
335-340.
[4] Spalding, T. A. (2002) Discovery of an Ectopic Activation Site on the M1 Muscarinic Receptor,
Mol. Pharmacol. 61, 1297-1302.
[5] De Amici, M., Dallanoce, C., Holzgrabe, U., Tränkle, C., and Mohr, K. (2010) Allosteric ligands
for G protein-coupled receptors: a novel strategy with attractive therapeutic opportunities,
Med. Res. Rev. 30, 463-549.
[6] Mistry, S. N., Valant, C., Sexton, P. M., Capuano, B., Christopoulos, A., and Scammells, P. J.
(2013) Synthesis and pharmacological profiling of analogues of benzyl quinolone carboxylic
acid (BQCA) as allosteric modulators of the M1 muscarinic receptor, J. Med. Chem. 56, 5151-
5172.
[7] Kuduk, S. D., Chang, R. K., Di Marco, C. N., Ray, W. J., Ma, L., Wittmann, M., Seager, M. A.,
Koeplinger, K. A., Thompson, C. D., Hartman, G. D., and Bilodeau, M. T. (2010) Quinolizidinone
carboxylic acids as CNS penetrant, selective m1 allosteric muscarinic receptor modulators, ACS
Med. Chem. Lett. 1, 263-267.
[8] Davie, B. J., Valant, C., White, J. M., Sexton, P. M., Capuano, B., Christopoulos, A., and
Scammells, P. J. (2014) Synthesis and pharmacological evaluation of analogues of benzyl
quinolone carboxylic acid (BQCA) designed to bind irreversibly to an allosteric site of the M (1)
muscarinic acetylcholine receptor, J. Med. Chem. 57, 5405-5418.
[9] Ma, L., Seager, M. A., Wittmann, M., Jacobson, M., Bickel, D., Burno, M., Jones, K., Graufelds,
V. K., Xu, G., Pearson, M., McCampbell, A., Gaspar, R., Shughrue, P., Danziger, A., Regan, C.,
Flick, R., Pascarella, D., Garson, S., Doran, S., Kreatsoulas, C., Veng, L., Lindsley, C. W., Shipe,
W., Kuduk, S., Sur, C., Kinney, G., Seabrook, G. R., and Ray, W. J. (2009) Selective activation of
the M1 muscarinic acetylcholine receptor achieved by allosteric potentiation, Proc. Natl. Acad.
Sci. U. S. A. 106, 15950-15955.
[10] Mohr, K., Schmitz, J., Schrage, R., Tränkle, C., and Holzgrabe, U. (2013) Molecular alliance-
from orthosteric and allosteric ligands to dualsteric/bitopic agonists at G protein coupled
receptors, Angew. Chem. Int. Ed. Engl. 52, 508-516.
[11] Kloeckner, J., Schmitz, J., and Holzgrabe, U. (2010) Convergent, short synthesis of the
muscarinic superagonist iperoxo, Tetrahedron Lett. 51, 3470-3472.
[12] Schrage, R., Seemann, W. K., Kloeckner, J., Dallanoce, C., Racke, K., Kostenis, E., De Amici, M.,
Holzgrabe, U., and Mohr, K. (2013) Agonists with supraphysiological efficacy at the muscarinic
M2 ACh receptor, Br. J. Pharmacol. 169, 357-370.
[13] Chen, X., Kloeckner, J., Holze, J., Zimmermann, C., Seemann, W. K., Schrage, R., Bock, A.,
Mohr, K., Tränkle, C., Holzgrabe, U., and Decker, M. (2015) Rational design of partial agonists
for the muscarinic m1 acetylcholine receptor, J. Med. Chem. 58, 560-576.
[14] Vilardaga, J. P., Bünemann, M., Krasel, C., Castro, M., and Lohse, M. J. (2003) Measurement of
the millisecond activation switch of G protein-coupled receptors in living cells, Nat. Biotechnol.
21, 807-812.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
[15] Hoffmann, C., Gaietta, G., Bünemann, M., Adams, S. R., Oberdorff-Maass, S., Behr, B.,
Vilardaga, J. P., Tsien, R. Y., Ellisman, M. H., and Lohse, M. J. (2005) A FlAsH-based FRET
20
ACS Paragon Plus Environment

Page 21 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
approach to determine G protein-coupled receptor activation in living cells, Nat. Methods 2,
171-176.
[16] Stumpf, A. D., and Hoffmann, C. (2016) Optical probes based on G protein-coupled receptors
- added work or added value?, Br. J. Pharmacol. 173, 255-266.
[17] Vilardaga, J. P., Bünemann, M., Feinstein, T. N., Lambert, N., Nikolaev, V. O., Engelhardt, S.,
Lohse, M. J., and Hoffmann, C. (2009) GPCR and G proteins: drug efficacy and activation in live
cells, Mol. Endocrinol. 23, 590-599.
[18] Lohse, M. J., Nuber, S., and Hoffmann, C. (2012) Fluorescence/bioluminescence resonance
energy transfer techniques to study G-protein-coupled receptor activation and signaling,
Pharmacol. Rev. 64, 299-336.
[19] Kruse, A. C., Ring, A. M., Manglik, A., Hu, J. X., Hu, K., Eitel, K., Hübner, H., Pardon, E., Valant,
C., Sexton, P. M., Christopoulos, A., Felder, C. C., Gmeiner, P., Steyaert, J., Weis, W. I., Garcia, K.
C., Wess, J., and Kobilka, B. K. (2013) Activation and allosteric modulation of a muscarinic
acetylcholine receptor, Nature 504, 101-106.
[20] Abdul-Ridha, A., Lopez, L., Keov, P., Thal, D. M., Mistry, S. N., Sexton, P. M., Lane, J. R., Canals,
M., and Christopoulos, A. (2014) Molecular determinants of allosteric modulation at the M1
muscarinic acetylcholine receptor, J. Biol. Chem. 289, 6067-6079.
[21] Ogino, K., Tokuda, Y., Nakai, T., and Tagaki, W. (1994) Hydrolysis of acetylcholine analogs
catalyzed by an anionic surfactant containing 2-hydroxymethylimidazole and sulfate groups in
the absence and presence of Cu2+ ion in mixed micellar systems, Mem. Fac. Eng., Osaka City
Univ. 35, 187-197.
[22] Gould, R. G., and Jacobs, W. A. (1939) The Synthesis of Certain Substituted Quinolines and
5,6-Benzoquinolines, J. Am. Chem. Soc. 61, 2890-2895.
[23] de la Cruz, A., Elguero, J., Goya, P., Martínez, A., and Pfleiderer, W. (1992) Tautomerism and
acidity in 4-quinolone-3-carboxylic acid derivatives, Tetrahedron 48, 6135-6150.
[24] Shindikar, A. V., and Viswanathan, C. L. (2005) Novel fluoroquinolones: design, synthesis, and
in vivo activity in mice against Mycobacterium tuberculosis H37Rv, Bioorg. Med. Chem. Lett.
15, 1803-1806.
[25] Zhi, Y., Gao, L. X., Jin, Y., Tang, C. L., Li, J. Y., Li, J., and Long, Y. Q. (2014) 4-Quinolone-3-
carboxylic acids as cell-permeable inhibitors of protein tyrosine phosphatase 1B, Bioorg. Med.
Chem. 22, 3670-3683.
[26] Ziegler, N., Bätz, J., Zabel, U., Lohse, M. J., and Hoffmann, C. (2011) FRET-based sensors for
the human M1-, M3-, and M5-acetylcholine receptors, Bioorg. Med. Chem. 19, 1048-1054.
[27] Maier-Peuschel, M., Frölich, N., Dees, C., Hommers, L. G., Hoffmann, C., Nikolaev, V. O., and
Lohse, M. J. (2010) A fluorescence resonance energy transfer-based M2 muscarinic receptor
sensor reveals rapid kinetics of allosteric modulation, J. Biol. Chem. 285, 8793-8800.
[28] Wess, J. (1998) Molecular basis of receptor/G-protein-coupling selectivity, Pharmacol. Ther.
80, 231-264.
[29] Tewson, P., Westenberg, M., Zhao, Y., Campbell, R. E., Quinn, A. M., and Hughes, T. E. (2012)
Simultaneous detection of Ca2+ and diacylglycerol signaling in living cells, PLoS One 7, e42791.
[30] Bock, A., Merten, N., Schrage, R., Dallanoce, C., Batz, J., Kloeckner, J., Schmitz, J., Matera, C.,
Simon, K., Kebig, A., Peters, L., Müller, A., Schrobang-Ley, J., Tränkle, C., Hoffmann, C., De
Amici, M., Holzgrabe, U., Kostenis, E., and Mohr, K. (2012) The allosteric vestibule of a seven
transmembrane helical receptor controls G-protein coupling, Nat. Commun. 3, 1044.
[31] Bock, A., Chirinda, B., Krebs, F., Messerer, R., Batz, J., Muth, M., Dallanoce, C., Klingenthal, D.,
Tränkle, C., Hoffmann, C., De Amici, M., Holzgrabe, U., Kostenis, E., and Mohr, K. (2014)
Dynamic ligand binding dictates partial agonism at a G protein-coupled receptor, Nat. Chem.
Biol. 10, 18-20.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
[32] Vilardaga, J. P., Steinmeyer, R., Harms, G. S., and Lohse, M. J. (2005) Molecular basis of
inverse agonism in a G protein-coupled receptor, Nat. Chem. Biol. 1, 25-28.
[33] Hoffmann, C., Nuber, S., Zabel, U., Ziegler, N., Winkler, C., Hein, P., Berlot, C. H., Bunemann,
M., and Lohse, M. J. (2012) Comparison of the activation kinetics of the M3 acetylcholine
21
ACS Paragon Plus Environment

ACS Chemical Biology
Page 22 of 27
1
2
3
4
5
6
7
8
9
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
receptor and a constitutively active mutant receptor in living cells, Mol. Pharmacol. 82, 236-
245.
[34] Bock, A., Bermudez, M., Krebs, F., Matera, C., Chirinda, B., Sydow, D., Dallanoce, C.,
Holzgrabe, U., De Amici, M., Lohse, M. J., Wolber, G., and Mohr, K. (2016) Ligand Binding
Ensembles Determine Graded Agonist Efficacies at a G Protein-coupled Receptor, J. Biol. Chem.
291, 16375-16389.
[35] Ilien, B., Glasser, N., Clamme, J. P., Didier, P., Piemont, E., Chinnappan, R., Daval, S. B., Galzi, J.
L., and Mely, Y. (2009) Pirenzepine promotes the dimerization of muscarinic M1 receptors
through a three-step binding process, J. Biol. Chem. 284, 19533-19543.
[36] Nayeem AA, K. A., Rahman MS, Rahman M. (2011) Evaluation of phytochemical and
pharmacological properties of Mikania cordata (Asteraceae) leaves, J. Pharmacognosy
Phytother. 3, 118-123.
[37] Leyva, E., Monreal, E., and Hernández, A. (1999) Synthesis of fluoro-4-hydroxyquinoline-3-
carboxylic acids by the Gould–Jacobs reaction, J. Fluor. Chem. 94, 7-10.
[38] Niedermeier, S., Singethan, K., Rohrer, S. G., Matz, M., Kossner, M., Diederich, S., Maisner, A.,
Schmitz, J., Hiltensperger, G., Baumann, K., Holzgrabe, U., and Schneider-Schaulies, J. (2009) A
small-molecule inhibitor of Nipah virus envelope protein-mediated membrane fusion, J. Med.
Chem. 52, 4257-4265.
[39] Ho, S. N., Hunt, H. D., Horton, R. M., Pullen, J. K., and Pease, L. R. (1989) Site-Directed
Mutagenesis by Overlap Extension Using the Polymerase Chain-Reaction, Gene 77, 51-59.
[40] Zürn, A., Zabel, U., Vilardaga, J. P., Schindelin, H., Lohse, M. J., and Hoffmann, C. (2009)
Fluorescence resonance energy transfer analysis of alpha 2a-adrenergic receptor activation
reveals distinct agonist-specific conformational changes, Mol. Pharmacol. 75, 534-541.
[41] Hoffmann, C., Gaietta, G., Zürn, A., Adams, S. R., Terrillon, S., Ellisman, M. H., Tsien, R. Y., and
Lohse, M. J. (2010) Fluorescent labeling of tetracysteine-tagged proteins in intact cells, Nat.
Protoc. 5, 1666-1677.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
[42] Sletten, D. M., Nickander, K. K., and Low, P. A. (2005) Stability of acetylcholine chloride
solution in autonomic testing, J. Neurol. Sci. 234, 1-3.
642
22
ACS Paragon Plus Environment

Page 23 ofA27CS Chemical Biology
Cooperative
Eꢀects
1
2
3
4
ACS Paragon Plus Environment
5
FRET
6

ACS Chemical Biology
Page 24 of 27
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1
165x196mm (300 x 300 DPI)
ACS Paragon Plus Environment

Page 25 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 2
232x388mm (300 x 300 DPI)
ACS Paragon Plus Environment

ACS Chemical Biology
Page 26 of 27
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 3
236x400mm (300 x 300 DPI)
ACS Paragon Plus Environment

Page 27 of 27
ACS Chemical Biology
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 4
169x206mm (300 x 300 DPI)
ACS Paragon Plus Environment
