Towards high efficiency solid emitters with aggregation-induced emission
and electron-transport characteristicsw
Wang Zhang Yuan,ab Shuming Chen,c Jacky W. Y. Lam,a Chunmei Deng,a Ping Lu,d
Herman H-Y. Sung,a Ian D. Williams,a Hoi Sing Kwok,c Yongming Zhangb and
Ben Zhong Tang*ae
Received 9th July 2011, Accepted 1st September 2011
DOI: 10.1039/c1cc14122h
Combination of an aggregation-induced emission (AIE) moiety
and a dimesitylboron group yields a new three-coordinate boron
compound exhibiting a synergistic effect: the resultant TPED-
MesB shows AIE feature with solid-state emission efficiency up
to unity and good electron-transport property, and thus remark-
able electroluminescence (EL) performances.
formation.7 The mechanism of such AIE phenomenon has
been identified as the restriction of intramolecular rotation
(RIR).7b We wondered whether we can create new multifunc-
tional materials through rational simple coupling of different
functional moieties, namely AIE chromophores and charge-
transport segments. Encouragingly, we recently reported the
synthesis of triphenylamine-containing solid emitters with
good hole-transport property and solid-state emission
efficiency up to unity.8 Such a win–win strategy eliminated
the ACQ effect of triphenylamine without sacrificing its hole-
transport property, moreover, giving greatly enhanced emission
efficiencies.8
Design and synthesis of high efficiency solid-state organic
materials is of fundamental importance and technical implications
for various optoelectronic and photonic applications, such as
organic light-emitting diodes (OLEDs),1 organic lasers,2
organic light-emitting transistors (OLETs),3 and sensors.4
Particularly, for OLEDs, development of multifunctional
compounds which are capable of functioning as efficient
emitters as well as charge-transport materials is of crucial
importance to simplify the device configuration, improve the
device duration, enhance the efficiency, and reduce the cost.5
Therefore, intense endeavors have been made to generate
electron- and/or hole-transport emitters in the past decades.6
Whereas many molecules are highly emissive in dilute solutions,
they become weakly fluorescent or non-emissive when aggregated
in poor solvents or fabricated as thin films in the solid state.
This notorious effect of aggregation-caused quenching (ACQ)
has made the development of highly emissive multifunctional
organic luminogens a daunting task.
The success of obtaining hole-transport and highly luminescent
organic solids promoted us to create electron-transport/
emitting bifunctional materials. It is known that electron
mobility in organic materials is generally orders of magnitude
lower than the hole mobility. Therefore, the development of
efficient electron-transport materials plays an important role
in the improvement of the overall OLED device performance.9
So far, several types of electron-transport materials, such as
CQN double bond-containing heterocycles, metal-quinolinol
complexes, fluoro-substituted compounds, cyano-substituted
poly(p-phenylenevinylene)s, and three-coordinated organoborons
have been developed.9–11 Among these, the organoboron
compounds are particularly attractive and promising due to
their unique properties stemming from the pp–p* conjugation
between the vacant p orbital on the boron atom with the p*
orbital of the p-conjugated framework.5,10b,12 Many works
have shown the applications of three-coordinate organoboron
compounds in nonlinear optical organic material, light-emitting
diodes, fluorescent sensing, and so on.4,13–19 Here, we reported
our work on the preparation of electron-transport highly
fluorescent solid emitters based on a new approach through
combination of AIE-active units (TPE) and the dimesitylboron
group. The resulting compound TPEDMesB shows unique
AIE characteristics with a solid state efficiency of 100% as well
as good electron-transport ability. The OLED employing
TPEDMesB as an emitter without an additional electron-
transport layer showed bright bluish-green emission with a
In 2001, our group discovered a novel phenomenon of
aggregation-induced emission (AIE): some propeller-like molecules
such as siloles and tetraphenylethene (TPE) are non-emissive
in solutions but are induced to emit intensely by aggregate
a Department of Chemistry, The Hong Kong University of Science &
Technology, Clear Water Bay, Kowloon, Hong Kong, China.
E-mail: tangbenz@ust.hk
b School of Chemistry and Chemical engineering, Shanghai Jiao Tong
University, Shanghai 200240, China
c Center for Display Research, HKUST, Kowloon, Hong Kong, China
d State Key Laboratory of Supramolecular Structure and Materials,
Jilin University, Changchun 130023, China
e Department of Polymer Science and Engineering, Zhejiang
University, Hangzhou 310027, China
w Electronic supplementary information (ESI) available: Experimental
details, NMR, mass and UV-vis spectra, DSC, TGA curves, other EL
data and cyclic voltammogram. CCDC 833200. For ESI and crystal-
lographic data in CIF or other electronic format see DOI: 10.1039/
c1cc14122h
luminous efficiency of 7.13 cd AÀ1
.
The target compound TPEDMesB was obtained in good yield
(82.5%) by the lithiation of 1-(4-bromophenyl)-1,2,2-triphenylethene
c
11216 Chem. Commun., 2011, 47, 11216–11218
This journal is The Royal Society of Chemistry 2011

View Article Online
Scheme 1 The synthetic route to TPEDMesB.
