quenching. The fluorescence was recovered upon washing
with water. This observation confirms the ability of the
attoreactors to act as sensors that can be generated in situ and
bind metal ions in a reversible fashion (4 cycles).
In the future, the analytical potential of the attosensor
mats could be expanded to become a massively parallel
sensing array by reading one or few individual attoreactors
(from a mat comprising approximately 107 attosensors).
While this qualitative test was performed at a high analyte
concentration (200 mm, 200 nL, pH 5), it can be performed at
a concentration as low as 5 ppm. One of the advantages of the
present approach is the possible use of small samples (down
to pL) obtained by concentrating diluted samples. In any case,
owing to the density of the nanofiber mat, there will be
approximately 104 individual attoliters sensors under every
10 nL droplet. Importantly, nanofiber mats can comprise
more than two reagents. We tested a nanomat composed of
four different nanofibers: A fiber doped with an amine such
as tetraethylene pentamine (5N), another one with dansyl
chloride (DS), one with fluorescamine (FL, Fluram), and one
with 7-chloro-4-nitrobenz-2-oxa-1,3-diazole (NBD).
None of these four chemicals are fluorescent, but the
products of the reaction of the fluorophore precursors (DS,
FL, NBD) with the amine are. Thus, the dansylated pentam-
ine displays cyan emission (lmax = 480 nm, t = 7.85 ns), the
Fluram-amine product shows blue emission (lmax = 465 nm,
t = 2.80 ns), and the NBD-amine a green emission (lmax
525 nm, t = 3.87 ns), Figure 3A–E.
=
The in-situ-synthesized probes may be generated in the
nanofiber mat to match the analyte composition. In an even
more general sense, the amounts of the label–receptor probes
may be adjusted on demand to satisfy the requirements for
excitation/emission wavelengths, amount, and concentration
of the analyte, etc. Figure 3F shows nine probes (3 ꢀ 3) with
DS–5N, FL–5N, and NBD–5N as well as zoomed-in images of
each junction type to show the difference in fluorescence
output. The three probes, DS–5N, FL–5N, and NBD–5N, have
different affinity to metal ions. This is because, for example,
FL–5N comprises a carboxylate group that may participate in
the metal ion binding, while the nitrogen atom in the
oxadiazole ring of NBD–5N may participate in the formation
of the probe–ion complex, or because the sulphonamide
oxygen in the DS–5N may interact with oxophilic cations, etc.
Similarly, a varying of the ethylene amines (4N, 5N, 6N)
introduces a variable likely to induce a different response to
different metal ions.
In the attosensor mat, the amine-bearing and fluoro-
phore-precursor-doped nanofibers are deposited at an angle
of approximately 908 to form a rectangular grid (Fig-
ure 3A,F). The location of the respective DS, FL, NBD
fibers is, however, random. Thus, the location of the in-situ
generated probes within the grid is random as the junctions
with blue/cyan/green emission are not formed in an exact pre-
defined location. This is, however, not a hindrance because
the probes are optically encoded with their specific emission
profiles.
Figure 3. The reaction of fluorophore precursors (DS, FL, NBD) with
tetraethylene pentamine in situ (i.e. in the nanofiber junctions) results
in fluorescent products. The color of emission (fluorescence image is
superimposed on a bright-field image) corresponds to the images
above (A). The emission can be observed as an image based on
fluorescence lifetime (B), so called fluorescence lifetime (FLIM) image.
The virtual sensor array comprising in situ prepared fluorescent probes
DS–5N, FL–5N, and NBD-5N (F). The three probes, FL–5N (C), NBD–
5N (D), and DS–5N (E), were synthesized from pentamine-doped
polyurethane fibers (vertical) and the fluorophore precursors in the
horizontal direction. The images are bright-field images with super-
imposed confocal fluorescence images.
ing all the probes (Figure 3). The metal sensing data were
acquired from analyte droplets (0.2 mL) deposited on the mat
together with a reference sample (water, pH 5). The drops
were allowed to dry prior to fluorescence measurement using
a UV/vis scanner (excitation at ca. 365 nm) that records
While the individual attosensors operate independently
(on a microscopic level, Figure 2), in practice, the fluores-
cence is recorded from the whole mat (12 ꢀ 12 mm) compris-
