Synthesis and evaluation of analogs of the phenylpyridazinone
NPD-001 as potent trypanosomal TbrPDEB1 phosphodiesterase
inhibitors and in vitro trypanocidals
Johan Veerman a, Toine van den Bergh a, Kristina M. Orrling b, Chimed Jansen b, Paul Cos c, Louis Maes c,
Eric Chatelain d, Jean-Robert Ioset d, Ewald E. Edink b, Hermann Tenor e, Thomas Seebeck f, Iwan de Esch b,
Rob Leurs b, Geert Jan Sterk a,b,
⇑
a Mercachem, PO Box 6747, 6503 GE Nijmegen, The Netherlands
b Division of Medicinal Chemistry, Faculty of Sciences, Amsterdam Institute of Molecules, Medicines & Systems (AIMMS), Vrije Universiteit Amsterdam, De Boelelaan 1083,
1081 HV Amsterdam, The Netherlands
c Laboratory for Microbiology, Parasitology and Hygiene (LMPH), University of Antwerp, Groenenborgerlaan 171, 2020 Wilrijk, Belgium
d DNDi (Drugs for Neglected Diseases initiative), 15 Chemin Louis Dunant, 1202 Geneva, Switzerland
e Takeda, Takeda Pharmaceuticals International GmbH, Thurgauerstrasse 130, 8152 Glattpark-Opfikon, Zurich, Switzerland
f Institute of Cell Biology, University of Bern, Baltzerstrasse 4, 3012 Bern, Switzerland
a r t i c l e i n f o
a b s t r a c t
Article history:
Trypanosomal phosphodiesterases B1 and B2 (TbrPDEB1 and TbrPDEB2) play an important role in the life
cycle of Trypanosoma brucei, the causative parasite of human African trypanosomiasis (HAT), also known
as African sleeping sickness. Knock down of both enzymes leads to cell cycle arrest and is lethal to the
parasite. Recently, we reported the phenylpyridazinone, NPD-001, with low nanomolar IC50 values on
both TbrPDEB1 (IC50: 4 nM) and TbrPDEB2 (IC50: 3 nM) (J. Infect. Dis. 2012, 206, 229). In this study, we
now report on the first structure activity relationships of a series of phenylpyridazinone analogs as
TbrPDEB1 inhibitors. A selection of compounds was also shown to be anti-parasitic. Importantly, a good
correlation between TbrPDEB1 IC50 and EC50 against the whole parasite was observed. Preliminary anal-
ysis of the SAR of selected compounds on TbrPDEB1 and human PDEs shows large differences which
shows the potential for obtaining parasite selective PDE inhibitors. The results of these studies support
the pharmacological validation of the Trypanosome PDEB family as novel therapeutic approach for
HAT and provide as well valuable information for the design of potent TbrPDEB1 inhibitors that could
be used for the treatment of this disease.
Received 18 December 2015
Revised 21 February 2016
Accepted 24 February 2016
Available online xxxx
Keywords:
Pyridazinone
Phosphodiesterase
Trypanosome brucei
African trypanosomiasis
TbrPDEB1
Human PDEs
Ó 2016 Elsevier Ltd. All rights reserved.
1. Introduction
list of Neglected Tropical Diseases for which there is an urgent
need for more effective and less toxic medications.2–4
Human African trypanosomiasis (HAT), or African sleeping sick-
ness, is a neglected tropical disease that affects tens of thousands
of patients annually.2 The causative agent of this disease is the par-
asite Trypanosoma brucei (T. brucei), which is transmitted by the
tsetse fly. The disease is fatal unless treated and current treatment
options are limited.2–4 Consequently, the disease ranks high on the
Spatiotemporal control of the cyclic nucleotide signaling path-
ways is essential for any cell and disruption of this control may
be detrimental to its survival.5,6 Cyclic nucleotide phosphodi-
esterases (PDEs) play a vital role in the control of the homeostasis
of the intracellular cyclic nucleotides cAMP and cGMP in any
eukaryotic cell. Inhibition of PDEs has therefore been recognized
as an effective therapeutic concept in man (e.g., erectile dysfunc-
tion, chronic obstructive pulmonary disease (COPD) and psoriasis),
and more recently also as a potential concept for the design of
novel antiparasitic drugs.7–9
Abbreviations: MOE, Molecular Operating Environment; MW, microwave;
TbrPDEB1, Trypanosoma brucei phosphodiesterase B1; TbrPDEB2, Trypanosoma
brucei phosphodiesterase B2.
The T. brucei phosphodiesterases TbrPDEB1 and TbrPDEB2 are
essential for the survival of the bloodstream form of the parasite.
Concomitant RNAi-induced knock-down of both enzymes kills
⇑
Corresponding author.
E-mail address: g.j.sterk@vu.nl (G.J. Sterk).
http://dx.doi.org/10.1016/j.bmc.2016.02.032
0968-0896/Ó 2016 Elsevier Ltd. All rights reserved.
Please cite this article in press as: Veerman, J.; et al. Bioorg. Med. Chem. (2016), http://dx.doi.org/10.1016/j.bmc.2016.02.032

2
J. Veerman et al. / Bioorg. Med. Chem. xxx (2016) xxx–xxx
the parasite in vitro and also saves mice from parasitaemia in vivo.5
Next to this genetic evidence, pharmacological validation of the
TbrPDEB family as therapeutic target has been performed using
the potent tetrazole-containing phenylpyridazinone 1 (NPD-001,
previously reported as compd A)1 and its pyrazolone analog, 2
(VUF13525)10 and a series of piclamilast (3) analogs with low
micromolar activity against both TbrPDEB1 and -B211 (see Fig. 1).
Other chemical classes of PDE inhibitors have been investigated
as well for TbrPDEB1 inhibition but only with minor results.12–17
The phenylpyridazinone 1 shows low nanomolar inhibitory
activities against both TbrPDEB enzymes (TbrPDEB1: IC50 = 4 nM;
TbrPDEB2: IC50 = 3 nM), increases cAMP levels in the whole para-
sites and prevents cytokinesis, resulting in multinucleated, multi-
flagellated cells that eventually lyse, resulting in potent in vitro
trypanocidal activity against the bloodstream form of Trypanosoma
brucei.1 NPD-001 was originally described as a potent PDE4 inhibi-
tor with sub-nanomolar potency,18 limiting its use as anti-try-
panocidal.1 This limitation does not stem from the side effects of
O
R1
R2
R1
R2
a
X
X
O
+
O
CO2H
O
4a: R1=R2=MeO; X1
5a: R1=MeO; R2=H; X1
8a: R1=R2=MeO; X4
9a: R1=R2=MeO; X2
10a: R1=R2=MeO; X3
b
R1
R2
R1
R2
X
c
X
N
N
R3
O
N
N
H
O
5: R1=R2=MeO; X1; R3=c-Hept
6: R1=MeO; R2=H; X1; R3=c-Hept
8: R1=R2=MeO; X4; R3=c-Hept
9: R1=R2=MeO; X2; R3=c-Hept
10: R1=R2=MeO; X3; R3=c-Hept
11: R1=R2=MeO; X2; R3=2-Prop
4: R1=R2=MeO; X1
5b: R1=MeO; R2=H; X1
8b: R1=R2=MeO; X4
9b: R1=R2=MeO; X2
10b: R1=R2=MeO; X3
PDE4 inhibitors per se but mainly from its TNF
as this cytokine plays a crucial role in host defense during infec-
tions.19–21 TNF
suppression makes a patient more vulnerable to
a suppressive effect
H
H
a
H
H
infections which is a very undesirable condition in rural Africa.
However, as most potent TbrPDEB1 and -B2 inhibitor to date,
NPD-001 is an interesting scaffold for hit exploration and SAR
development. To evaluate the usefulness of the phenylpyridazi-
none scaffold for the design of a parasite-specific TbrPDEB1 inhibi-
tor, we report here on a series of phenylpyridazinone analogs and
their inhibitory activities on both TbrPDEB1 and on Trypanosoma
brucei growth inhibitory activity in the Alamar blue test.
X3
X1
X4
X2
Scheme 1. Synthetic route via Friedel–Craft acylation. Reagents: (a) AlCl3 DCM, rt,
16 h. (b) EtOH, N2H4, reflux, 2 h. (c) DMF/NaH, R3-Br, 0 °C, 20 min; rt, 16 h.
by potassium hydroxide to 17. The methyl-substituted tetrazoles
12 and 13 were prepared as mixture by alkylation of 1 and purified
by preparative HPLC. The regioisomer identity of the two methyl
isomers was established using NMR experiments; NOESY, HSQC
and HMBC.
2. Results
2.1. Synthesis
All compounds, except the achiral 8 and 10, were prepared as
racemic mixtures of the cis-diastereomers (4aS,8aR and 4aR,8aS).
The synthesis Schemes 1 and 2 depict the synthetic routes of all
compounds, some of which (1, 4, 5, 9, 11 and 14–18) have been
published before as PDE4 inhibitors,18,22 while the others (6, 7, 8,
10, 12, 13, 19–25) are new. For the compounds with the 3,4-
dimethoxy (4, 5, 8–11) and the 4-methoxy (6) substitution the syn-
thesis route (Scheme 1) started with a Friedel–Craft acylation. Sub-
sequent condensation with hydrazine gave the pyridazinones
which could be alkylated using sodium hydride in DMF. In all other
cases (1, 7, 12–25) the route started with a Grignard reaction
(Scheme 2) to obtain the gamma-ketopropionic acids. These car-
boxylic acids were then converted to the corresponding pyridazi-
nones using the same chemistry as already outlined in Scheme 1.
For the preparation of 1 and 12–25 the 3-cyclopentyloxy group
of intermediate 1c was hydrolyzed by 4-toluenesulfonic acid in
toluene in a Dean Stark apparatus.18 The obtained phenol was then
substituted to obtain the desired compounds using different condi-
tions. The bromoalkyl intermediate 1e was further derivatized by
reacting with a phenol (1f, 14, 17a) or 5H-pyrrolo[3,2-d]pyrimidine
(15). The nitrile 1f was converted to the tetrazole 1 using sodium
azide and ammonium chloride while the ester 17e was hydrolyzed
2.2. Pharmacological testing
All analogs were tested in at least two independent experi-
ments for inhibition of TbrPDEB1-mediated [3H]-cAMP hydrolysis,
using a scintillation proximity assay as described previously.1
Selected compounds were tested for inhibition of T. brucei blood-
stream form trypomastigote proliferation and for cytotoxicity on
MRC-5 fibroblasts using established techniques.23,24 The antipara-
sitic effect of the compounds was determined for the subspecies T.
brucei brucei, which is not infective to humans.
At this early stage of research, assessment of TbrPDEB2 inhibi-
tion was omitted, as suppression of parasite proliferation would
imply concomitant inhibition of TbrPDEB1 and TbrPDEB2. In addi-
tion, two previous studies on TbrPDE inhibitors suggest high
degree of equipotency against the paralogues,1,10 as expected from
the high sequence homology. The binding sites of these two
enzymes are completely identical and the sequence identity of
the catalytic domain is 88%, of which the major discrepancies occur
O
Cl
O
O
H
N
O
O
O
O
O
O
O
N
Cl
N
N
N
N
N
N
N
O
N
NH
Piclamilast
3
VUF13525
2
TbrPDEB1 IC50: 0.049µM
TbrPDEB2 IC50: 0.072µM
T.b. brucei IC50: 0.52µM
N
NH
NPD-001
1
TbrPDEB1 IC50: 0.004
TbrPDEB2 IC50: 0.003
T.b. brucei IC50: 0.08µM
N
TbrPDEB1 IC50: 7.6µM
µ
µ
M
M
TbrPDEB2 IC50: not tested
T.b. brucei IC50: 9.8µM
Figure 1. Known TbrPDE inhibitors with antitrypanosomal activity; 1,1 2,10 and 3.11
