Iron Transport-Mediated Drug Delivery: Practical Syntheses and In
Vitro Antibacterial Studies of Tris-Catecholate Siderophore−
Aminopenicillin Conjugates Reveals Selectively Potent
Antipseudomonal Activity
Cheng Ji, Patricia A. Miller, and Marvin J. Miller*
Department of Chemistry and Biochemistry, University of Notre Dame, 251 Nieuwland Science Hall, Notre Dame, Indiana 46556,
United States
S
* Supporting Information
since P. aeruginosa is intrinsically resistant to many of the
ABSTRACT: An artificial tris-catecolate siderophore with
a tripodal backbone and its conjugates with ampicillin and
amoxicillin were synthesized. Both conjugates exhibited
significantly enhanced in vitro antibacterial activities
against Gram-negative species compared to the parent
drugs, especially against Pseudomonas aeruginosa. The
conjugates appeared to be assimilated by an induced
bacterial iron transport process as their activities were
inversely related to iron concentration. The easily
synthesized tris-catecolate siderophore has great potential
for future development of various drug conjugates to target
antibiotic-resistant Gram-negative bacteria.
existing antibiotics, including β-lactams. Inadequate penetration
through the cell envelope is a significant factor in the resistance
of P. aeruginosa to β-lactam antibiotics, such as ampicillin and
amoxicillin.11,12 The use of drug conjugates of native side-
rophores of P. aeruginosa, namely pyoverdin and pyochelin, to
promote active uptake of antibiotics has been explored.13−17
Conjugates of aminopenicillin with artificial bis-, tris- and
tetrakis-catecholate siderophores based on polyamino carbox-
ylic acids have also been synthesized and found to effectively
inhibit growth of P. aeruginosa.18−21
Like many other types of bacteria, strains of P. aeruginosa
have developed receptors to recognize and transport Fe(III)−
siderophore complexes from other species (xenosiderophores)
in order to gain a competitive growth advantage.22 Enterobactin
(Figure 1) is a tris-catecholate siderophore primarily found in
he development of antimicrobial resistance among Gram-
T
negative pathogens poses a serious threat to global public
health.1,2 Among several mechanisms of antibiotic resistance in
Gram-negative bacteria, a major problem is the low
permeability of their outer membrane which serves as a barrier
to prevent antibiotic uptake by passive diffusion.3 Thus, the
development of methods to overcome this permeability-
mediated resistance is an important therapeutic goal. During
the course of infection, most microbes assimilate physiologically
essential iron by synthesizing and utilizing high-affinity ferric
ion chelators, called siderophores. The Fe(III)−siderophore
complexes are recognized, and active transport through the
bacterial cell membrane is intitiated via specific receptors.4,5
Attachment of antibiotics to siderophores produces potential
“Trojan Horse” conjugates that are anticipated to enter
pathogenic bacteria via their iron uptake system, thereby
circumventing the permeability-mediated drug resistance
problem. While studies of both natural and artificial side-
rophore−drug conjugates (sideromycins) have demonstrated
their potential for development of selective antimicrobial
agents,6,7 additional studies are needed. Herein, we report
that synthetic conjugates of a relatively simple siderophore
mimic and penicillins do, in fact, have selectively potent
antipseudomonal activity, while the parent antibiotics,
themselves, are inactive.
Figure 1. Structures of enterobactin 1 and triscatecholate siderophore
2.
Gram-negative bacteria, such as Escherichia coli and Salmonella
typhimurium.23 Enterobactin can also promote iron uptake into
P. aeruginosa, and the uptake is specifically inducible by
enterobactin under iron-limiting conditions.24 Using enter-
obactin as a shuttle to deliver antibiotics into P. aeruginosa and
other producing bacteria is an attractive strategy to pursue.
However, it is also synthetically challenging as enterobactin has
no functionality or site suitable for drug conjugation.
Investigation of receptor binding and transport of Fe(III)-
enterobactin has revealed that an unsubstituted tris-catechol
iron center and the coordinated catechol amide groups are
Pseudomonas aeruginosa is an opportunistic Gram-negative
bacterium that endangers immunocompromised patients,
including those with cystic fibrosis (CF),8 cancer,9 or AIDS.10
Once the infection is established it is very difficult to eradicate
Received: April 10, 2012
Published: June 4, 2012
© 2012 American Chemical Society
9898
dx.doi.org/10.1021/ja303446w | J. Am. Chem. Soc. 2012, 134, 9898−9901

Journal of the American Chemical Society
Communication
a
Scheme 1. Syntheses of the Tris-Catecholate Siderophore and Its Aminopenicillin Conjugates 10 and 11
a
Reagents and conditions: (a) 1. BH3-THF, THF, reflux; 2. Boc2O, Et3N, MeOH, reflux, 83% for 2 steps; (b) NiCl2, NaBH4, MeOH, sonication, rt,
92%; (c) methyl succinyl chloride, Et3N, CH2Cl2, 0 °C to rt, 75%; (d) 6 N HCl, reflux, 100%; (e) 2,3-diacyloxybenzoyl chloride 8, aqueous
NaHCO3/THF, 0 °C to rt, 57%; and (f) 1. isobutyl chloroformate, N-methyl morpholine, THF, 0 °C; 2. ampicillin or amoxicillin, Et3N, THF/H2O,
0 °C to rt, 55% (for 10), 50% (for 11).
a
Table 1. Diameter of Growth Inhibition Zones (mm) in the Agar Diffusion Antibacterial Susceptibility Assay
b
10
11
ampicillin
amoxicillin
+Fe
−Fe
+Fe
−Fe
+Fe
−Fe
+Fe
−Fe
P. aeruginosa KW799/wt
P. aeruginosa KW799/61
P. aeruginosa PAO1
20
13P
0
24
21
16
18
0
25
13P
0
26
26
19
20
0
23p
27
42
0
18p
40
40
39
0
0
0
P. aeruginosa Pa4
0
0
0
h
0
h
P. aeruginosa Pa6
0
0
0
0
0
0
P. aeruginosa K648 (pvd−, pch−)
E. coli H1443 (fepA+, cir+, fiu+)
E. coli H1876 (fepA−, cir−, fiu−)
0
15
19
0
0
17
21
14p
0
19/23P
0
0
16/23p
0
0
0
19/23p
0
0
0
19/24P
0
0
0
a
p, partially clear inhibition zone/colonies in the inhibition zone; P, unclear inhibition zone/many colonies in the inhibition zone; h: indicates only a
hint of growth inhibition detectable; exactly 50 μL of a 0.2 mM solution of each compound dissolved in 1:9 DMSO/MeOH was added to 9 mm
wells in agar media (standard I nutrient agar, Serva or Mueller−Hinton II Agar, Becton, Dickinson and Company); inhibition zones were read after
b
incubation at 37 °C for 24 h. Compound 10 was tested at 0.1 mM.
essential for recognition as a siderophore, while the trilactone
backbone is not required and can be replaced with very
different molecular scaffolds.23 Building on this important
information, and with the goal of developing practical syntheses
of microbe-selective sideromycins, we anticipated that
simplified symmetrical siderophore analogs, like 2, with linkers
remote from the site of iron binding would be suitable for
conjugation to antibiotics.
The syntheses of triscatecholate siderophore 2 and its
aminopenicillin conjugates (10 and 11) are summerized in
Scheme 1. As the backbone of the artificial siderophore,
tricarbamate 4 was synthesized from trinitrile 3 according to a
published procedure25 with minor modifications. In brief,
trinitrile 3 was reduced with borane in THF, and the resulting
triamine was protected with Boc2O to give tricarbamate 4.
Reduction of the nitro group in 4 was accomplished with
NaBH4 in the presence of a catalytic amount of NiCl2 to give
amine 5 in 92% yield. Treatment of amine 5 with methyl
succinyl chloride provided a succinate derivative 6, of which the
carboxyl terminus later served as the coupling site with the
aminopenicillins. Treatment of 6 with 6 N HCl effected
simultaneous removal of the Boc protecting groups and
hydrolysis of the methyl ester to give triamino acid 7 as its
tris HCl salt in quantitative yield. As demonstrated by
Mollmann et al.,21 using acylated catecholates as the side-
̈
rophore components has the benefit of not only facilitating
synthesis but also preventing pharmacological side effects of the
catechol groups. The acylated catecholates are expected to
serve as prodrugs to the required iron binding catechols while
circumventing potential methylation by a catechol O-methyl-
transferase (COMT) that would lead to a permanent loss of
effective iron binding ability necessary for siderophore
activity.26 Therefore, triamino acid 7 was acylated with 2,3-
diacyloxybenzoyl chloride 8 in aqueous sodium bicarbonate to
give tripodal siderophore 9, which can serve as a common
intermediate for attachment of various amino- or hydroxyl-
containing drugs via an amide or ester linkage. As a proof-of-
principle study, two aminopencillins, ampicillin and amoxicillin,
which by themselves are not active against wild-type strains of
P. aeruginosa, were chosen for the syntheses of conjugates.
Thus, siderophore 9 was coupled via its mixed anhydride with
ampicillin and amoxicillin to provide conjugates 10 and 11,
respectively.
Conjugates 10 and 11 were first evaluated for their
antibacterial ability against a collection of strains of P.
aeruginosa using the agar well diffusion test. The influence of
