Angewandte
Chemie
fluorophenyl substrate exhibited high diastereoselectivity
(20:1) and enantioselectivity, but with a decreased yield.
Para-phenyl substitution provided the lactone product (13)
with excellent diastereoselectivity. Electron-donating substi-
tution was tolerated in the meta-position furnishing lactone
products 15 and 16 in high yield (73–77%) with good
selectivities. Finally, the cyclopropyl ketone proceeded to
furnish lactone 17 in moderate yield and enantioselectivity,
but with excellent diastereoselectivity.[20]
In this organocatalytic DKR process, electron-rich aryl
ketones proceeded directly to the cyclopentene product
(Table 3). Presumably, more available electron density pro-
Scheme 3. Synthetic transformations (see the Supporting Information
for details): a) PhCH2NH2, CH2Cl2, 238C; b) SiO2, C6H6, 608C;
c) LiAlH4, Et2O, 0 to 238C; d) [Ir(py)(cod)PCy3], H2, CH2Cl2, 238C;
e) ClSO2NH2, pyridine, CH2Cl2, 0 to 238C; f) [Rh2(OAc)4], MgO, PhI-
(OAc)2, CH2Cl2, 408C.
Table 3: Enantioselective synthesis of cyclopentenes.[a–c]
natural product synthesis.[23] To demonstrate the potential
utility of this DKR, we processed these b-lactones into diverse
compounds (Scheme 3). The treatment of 5a with benzyl-
amine gave amide 24 in 94% yield while heating 5a with SiO2
at 608C[24] followed by lithium aluminum hydride provided
homoallylic alcohol 25 in 84% yield over two steps. A
selective hydrogenation with Crabtreeꢁs catalyst[25] afforded
trans-cyclopentane 26 (79%, 8:1 d.r.), while 10% Pd/C
hydrogenation favored the cis-cyclopentane (91%, 2.2:1
d.r., see the Supporting Information). Following a similar
reaction sequence, sulfonylamine 27 was prepared in three
steps with a 60% overall yield. The exposure of 27 to
Du Boisꢁs conditions generated bicyclic aziridine 28 (91%
yield).[26]
Our current understanding of this DKR process is
depicted in Scheme 4. Addition of the NHC to enal (Æ)-
1 induces the formation of the extended Breslow intermedi-
ate. The homoenolate undergoes b-protonation to form enols
I and III. The mildly basic reaction conditions allow for these
two intermediates to be in rapid equilibrium. Addition to the
re-face of the enol is favored for both intermediates (I and III)
due to a favorable hydrogen-bonding interaction between the
NHC-enol and ketone forming a 6-membered transition state
(II and IV). The importance of the hydrogen bonding is
reinforced by the poor conversion observed with solvents that
disturb this hydrogen-bonding interaction (coordinating polar
aprotic). The major diastereomer ((+)-2a) arises from enol II,
in which the ester is in a pseudo axial orientation. This
conformation is more favorable than IV, which yields minor
diastereomer ((+)-2b), due to destabilization created by
a gauche interaction of the ethyl ester and the aryl group. This
destabilization is increased with ortho substituted substrates
(favoring intermediate II) and as a result virtually none of the
minor diastereomer ((+)-2b) is observed (lactone 10 and
cyclopentene 18). The combination of a fast aldol addition
with II compared to IV and the rapid equilibrium of I and III
drives the reaction primarily in the direction of (+)-2a (97–
99% ee). The rationale behind the absence of the corre-
sponding enantiomer (À)-2a (which would arise from si-face
attack of III) is twofold. First, there is an unfavorable
arylester syn destabilization, and second, there is no hydrogen
bonding to promote the aldol/acylation. The minor diaste-
[a] 0.4 mmol scale. [b] Yields of isolated products (average of two
reactions). [c] ee determined by HPLC. [d] Lactone decarboxylated on
SiO2.
motes a facile decarboxylation. Unfortunately, along with this
process comes an inherent decrease in enantioselectivity and
investigations are underway to increase the selectivity. The 2-
ethoxyphenyl ketone proceeded in high yield and enantiose-
lectivity (90% ee). Other substrates, however, provided
decreased yields and enantioselectivities of cyclopentene
products 19–21.[21]
Given the highly selective nature of the method, we
envisioned a stereodivergent parallel kinetic resolution
(PKR) would be possible.[22] In contrast to a standard kinetic
resolution, a PKR converts both enantiomers of a starting
material into two distinct products. For this process we
employed a racemic substrate that is not epimerizable under
the reaction conditions (Scheme 2). The reaction proceeded
as planned with a-methylated b-keto ester 22 and complete
Scheme 2. Parallel kinetic resolution.
cyclization to diastereomeric b-lactone products 23 was
achieved in excellent yield (50% theoretical yield for each)
and enantioselectivity.
b-Lactones are highly useful building blocks for the
synthesis of target compounds, especially in the area of
