S.J. Barraza et al.
Bioorganic & Medicinal Chemistry Letters 46 (2021) 128171
target that is very well defined and discriminating.
Table 2
Modification of the benzyl amide of 1.
Our attention then turned towards the central piperidine ring and the
piperidine-4-carboxamide. Compound 224 was employed as the lead for
this series due to its equipotency with 12 and greater ease of analog
synthesis. Biological results are summarized in Table 3. The carbox-
amide imparts significant conformational bias to the linker between the
piperidine and the pyridine, so we initially explored replacing it with E
or Z olefins 17 and 18, respectively, which are conformationally locked
bioisosteres for the two possible rotamers of the carboxamide.47
Remarkably, both analogs lost all activity, indicating that the cabox-
amide itself is likely making at least one key binding interaction. To
explore this further, inverse amide 19 and shifted amide 20 were pre-
pared, each proving to be over 30-fold less active than 2. This supported
that a carboxamide bound directly to the piperidine 4-carbon through
the carbonyl is a critical part of the pharmacophore. We therefore
retained this motif through the remainder of our investigation.
No
125
R
IC50 (µM)a
15.6 ± 1.8
CC50 (µM)b
>100
5c
30.6 ± 7.3
>100
6
7
>100
>100
>100
>100
Urea analog 21 and unsaturated amide 22 were examined next, each
of which retained all of the atoms of the carboxamide and its position
relative to the piperidine, but would be expected to have some minor
conformational differences. The simple unsaturated amide retained
more activity than the urea, but still lost nearly 10-fold potency. Methyl
analogs 23 and 24 were particularly informative. While the previously
prepared N-methyl analog 2424 only lost 2-fold potency, suggesting that
8
9
>100
>100
>100
>100
–
the N H is not functioning as a hydrogen bond donor, the new
α-methyl
10
11
>100
>100
>100
>100
analog 23 lost all activity, indicating that the carbonyl likely plays a
much more significant role. The α-methyl group is either occluding the
amide carbonyl from binding (sterically or conformationally) or is
impeding favorable chair conformations of the piperidine. Finally, since
–
we had shown with 24 that the N H was not critical for activity, we
12
13
14
0.53 ± 0.04
1.7 ± 0.1
7.1 ± 0.9
>100
>100
>100
prepared the highly rigid bicyclic analog 25. This analog lost most po-
tency, obviously indicating that it is not locked in the optimal confor-
mation. Collectively, the results for 17 – 25 highlight the importance of a
sterically unhindered and flexible carboxamide to the pharmacophore.
For the next three analogs 26 – 28, we retained the “flexible” car-
boxamide moiety in the linker, and focused on freezing the conforma-
tional mobility of the piperidine ring. While the exo-bicycle 26 and the
spirocycle 28 lost over 20-fold potency, the tricyclic analog 27 retained
almost all of the potency of lead 2, suggesting that the locked equatorial-
equatorial relationship between the 1- and 4-substituents may reflect the
unknown bioactive conformation, Unfortunately, no activity improve-
ment was realized by this conformational restraint.
1525
16
15.2 ± 4.7
>100
62 ± 13
>50
Conversely, we examined an azapane analog 29 that we expected
would be more flexible than piperidine 2 but about the same overall
length. Interestingly, this compound was equally potent with the lead
despite being a racemate. Depending on the eudismic ratio (not deter-
mined), the active enantiomer could potentially be two-fold more active,
marking this compound as the most active compound to-date in the
WEEV replicon assay. The simplest explanation for this positive result is
that a larger population of azapane conformers are available that are
favorable to binding than are available to the piperidine.
aInhibition of luciferase expression in WEEV replicon assay. bCell viability determined
by the MTT reduction assay. Values are mean of at least n = 3 independent
experiments. cBased on nipecotic acid central ring (racemate).25
the isonipecotic acid frame of 1 (Table 2). Previously prepared analogs25
5 and 15 are included in the table for comparison. Remarkably, the
majority of new analogs (6 – 11) exhibited no activity whatsoever,
suggesting that the binding pocket for the N-benzyl amide is well
defined and intolerant of many rigid conformations. One compound
(12), however, proved to possess markedly better potency than all
others in this series, which we do not believe can be attributed to simple
increased lipophilicity or chain extension because analogs of similar
ClogP (14) and length (1525 and 16) were less potent (Table 2). Inter-
estingly, the racemic methyl analog 13 was also quite active; however its
lower potency relative to 12 is further evidence that the amide binding
site is well defined and not tolerant of even modest additional bulk or
altered conformation. Importantly, the increased potency of 12 has
apparently been achieved without a commensurate increase in cyto-
toxicity vs 1. Finally, the dramatic loss of potency of analogs 7 and 8,
each a single methylene shorter than the corresponding active analogs
12 and 14, respectively, suggests that some degree of flexibility is
required to engage the binding site. Overall, the results in Table 2 are
consistent with an amide binding pocket in the unknown molecular
The replicon activity of azapane 29 was confirmed in an antiviral
assay in FMV-infected BE(2)-C cells. At 5 µM, 29 demonstrated a nearly
two-fold improvement in infected cell viability (36.1 ± 4.0% versus
negative control 19.6 ± 4.0%), similar to the two-fold enhancement
observed for lead 2 at 25 µM. At higher concentration improvement was
more modest (22.9 ± 4.9% cell viability at 25 µM), possibly due to
concentration-dependent cytotoxicity.
The primary objective of this work was to establish a 3D pharma-
cophore model that could facilitate future optimization and enable vir-
tual screening to identify alternative templates. We first noted that a
number of small changes in the structure resulted in large differences in
biological activity, suggesting that an “activity cliff” analysis48 could be
useful for identifying key pharmacophoric elements. Employing Data-
Warrior49, we identified pairs of compounds exhibiting both high 2D
structural similarity and divergent potency and ranked them according
to structure activity landscape index (SALI)50 scores (Table S1 in
3
