A Neutral Naphthalene Diimide
[2]Rotaxane
Henri-Pierre Jacquot de Rouville, Julien Iehl, Carson J. Bruns, Psaras L. McGrier,
Marco Frasconi, Amy A. Sarjeant, and J. Fraser Stoddart*
Department of Chemistry, Northwestern University, 2145 Sheridan Road, Evanston,
Illinois 60208-3113, United States
stoddart@northwestern.edu
Received August 17, 2012
ABSTRACT
A neutral donorÀacceptor [2]rotaxane, which has been synthesized using click chemistry, has had its solid-state structure and superstructure
elucidated by X-ray crystallography. Both dynamic 1H NMR spectroscopy and electrochemical investigations have been employed in an attempt to
shed light on both geometrical reorganization and redox-switching processes that are occurring or can be induced within the [2]rotaxane.
During the past 30 years, the advent of the mechanical
bond1 has provided a fresh incentive to chemical synthesis
and opened up a whole new field of scientific research,
which we have referred to as mechanostereochemistry.2
Countless mechanically interlocked molecules2,3 (MIMs)
havebeensynthesizedby exploitingmolecularrecognition4
and self-assembly5 processes in their template-directed6
synthesis. For the class of MIMs templated by aromatic
donorÀacceptor interactions, X-ray crystal structures of
[2]catenanes7 are commonplace,8 whereas solid-state struc-
tures of donorÀacceptor [2]rotaxanes are far more rare
since they have proven to be, with a few exceptions,9 much
harder to crystallize on account of the flexibility of their
dumbbell components.
