Synthesis, characterization, in vitro antimicrobial and anticancer studies of new platinum N-heterocyclic

carbene (NHC) complexes and unexpected nickel complexes^1†

Kar Bee Choo,^aSui Mae Lee,^aWai Leng Lee,^aand Yuen Lin Cheow *^a

^aSchool of Science, Monash University Malaysia, Jalan Lagoon Selatan, 47500 Bandar Sunway, Selangor, Malaysia.

*Corresponding author: cheow.yuen.lin@monash.edu

Abstract

A series of bidendate pyridine-functionalized metal N-heterocyclic carbene (NHC) complexes with various

wingtip substituents (R = methyl, phenyl and tert-butyl) had been prepared from silver oxide-mediated

transmetalation method. The basic backbone of the NHC ligands were prepared in two stepwise reactions:

reduction of the commercially available 2-benzoylpyridine, followed by halogenation to yield 2-

(chloro(phenyl)methyl)pyridine. Subsequent reactions with different imidazoles gave the desired imidazolium

salts (or NHC precursors) with different R groups at the N wingtip (R = Me, Ph, t-Bu). Transmetalation of the

imidazolium salts into platinum NHC complexes were achieved by using Ag₂O mediated method with

Pt(cod)Cl₂as the transmetalating agent. On the other hand, nickel NHC complexes were obtained via one pot

synthesis method with nickel chloride as the transmetalating agent and reflux in the presence of a base.

Following recrystallisation, the molecular structure of Pt NHC complex (±)-5a had been successfully elucidated

via single crystal X ray diffraction (XRD) analysis. The six-membered ring of the platinum NHC complexes

adopted a boat conformation with the phenyl ring arranged at the axial position. Meanwhile, two unexpected

nickel complexes, i.e. a simple nickel coordination complex and a nickelate complex, were obtained and studied

using XRD. These Pt NHC complexes and unexpected Ni complexes were evaluated for their in vitro

antimicrobial and anticancer activities against a panel of pathogenic microorganisms and three selected human

cancer cell lines, including breast (MCF7), colon (HCT116) and oral (H103) cancer cells. Generally, the Pt

NHC complexes displayed enhanced antimicrobial activities upon coordination to metals, as compared to the

corresponding imidazolium salts i.e. NHC precursors, with minimum inhibitory concentration (MIC) values in

micromolar (µM) range. A couple of platinum NHC complexes synthesized exhibited antimicrobial activities

with MIC as low as 2 µM, which are comparable to silver NHC complexes with renowned antimicrobial

profiles. Similarly, upon coordination to the metals, the cytotoxic effects of the platinum NHC complexes

increased significantly as compared to the imidazolium salts. Among all, platinum NHC complex (±)-5c

displayed significant cytotoxicities towards the cancer cells with IC₅₀values that are two to three times lower

than that of the anticancer drug cisplatin. In summary, evidences for influence of both wingtip substituents and

metals on the biological activities of the complexes have been found.

Keywords

N-heterocyclic carbene • platinum NHC complexes • nickel complexes • cytotoxicity • antimicrobial

^†Electronic Supplementary Information (ESI) available: CCDC 1901952, 1901953, and 1901954 contain the crystallographic data (in

CIF format) for complex (±)-5, 9 and 10, respectively, and NMR spectroscopy data of all synthesized compounds.

ACCEPTED MANUSCRIPT

Introduction

Current strategy in the development of organometallic drugs has increasingly focused on the use of transition

metal complexes containing organic ligands. The effectiveness of metallodrugs is highly associated with the

choice of ligands. Ligands are most often, but not limited to, organic compounds that bind metal ions, hence

modifying the physical and chemical properties of the compounds. Ligands are important for modifying

reactivity and lipophilicity, stabilising special oxidation states and contributing to substitution inertness. Most

importantly, with its capability to modify the oral/systemic bioavailability of metal ions, ligands can play an

integral role in muting the potential toxicity of a metallodrug to have a positive impact for diagnosis and therapy.

Organometallic drugs with N-heterocyclic carbene (NHC) ligands have come into the spotlight over the past

decade. There are over multiple hundreds of transition metal NHC complexes being reported as potential

antimicrobials and anti-tumour drugs over the past five years. Their therapeutic potential is further highlighted

by several patents held by several universities and pharmaceutical companies [1-6]. N-heterocyclic carbenes

(NHCs) is an interesting class of ligand similar to phosphine ligand. They are generally derived from persistent

carbenes, which are stable compounds of divalent carbons. In simpler terms, NHCs are defined as heterocyclic

species containing a carbene carbon and at least one nitrogen atom within the ring structures. Today, as an

excellent ligand to the transition metals, NHCs have found multiple applications in various field, particularly

highlighted in biology, catalysis and supramolecular chemistry [7, 8].

Following the success of platinum based metallodrugs, such as cisplatin, as chemotherapeutic agents, platinum

complexes would be a great starting point for the search of novel therapeutic agents. Recently, researchers have

shifted the focus towards the synthesis of novel platinum-based drugs by changing the coordinated nitrogen

ligand or altering the leaving groups. Platinum NHC complexes have been highlighted as a promising and

original platform for building new drugs. One of the most notable highlight of Pt NHC complexes is the

patented monometallic trans-PtI₂(NHC)(amine) complexes and bimetallic trans-[PtI₂(NHC)]₂(diamine)

complexes developed by Marinetti’s group, which exhibited cytotoxic activities with IC₅₀at micromolar range

against both cisplatin-sensitive (CEM and H460) and cisplatin-resistant (A2780/DDP, CH1/DDP and SKOV3)

cell lines [4, 9, 10]. They even outperformed cisplatin and oxaliplatin, with cytotoxicity that are two- to five-

fold higher than the anticancer drugs, under similar experimental condition. While trans-configured complexes

were previously deemed as inactive in initial anticancer research, they have now been acknowledged for their

ability to form different platinum-DNA adducts, less recognized by RNA-repair machinery, and therefore to

reduce cross-resistance pertaining to cisplatin [11-13]. Che’s group also reported a series of luminescent

cyclometalated [Pt(6-phenyl-2,2’-bipyridine)(NHC)] complexes with variable lipophilicity (NHC N-substituents)

and nuclearity (mono- or bis-), which displayed significant anticancer activities [14-16]. These Pt NHC

complexes were about 5 to 300 folds more potent towards HeLa cells compared with cisplatin and displayed

high specificity towards cancer cells. Most importantly, in vivo study with mice have shown that the Pt NHC

complex developed could inhibit tumour growth significantly with no obvious side effects.

Although the study on Ni NHC complexes and their biomedical application is relatively scarce compared to

other Group 10 metal NHC complexes, but the apparent potential of nickel complexes in antitumor studies has

been reported recently. Ray and co-workers have designed three tetradendate Ni NHC complexes with the

intention to use them as agents for developing resistance to nickel toxicity [17]. These Ni NHC complexes have

shown less cytotoxicity than NiCl₂.6H₂O against HeLa and MCF7 cell lines under analogous condition. In

addition, Ni NHC complex displayed only half the toxicity than that of cisplatin against the non-tumorigenic

CHO cell line with minimal cell surface distortion [17]. These observations supported that the drastic reduction

ACCEPTED MANUSCRIPT

in the cytotoxic activity of nickel was successfully achieved by encapsulation of the metal centre in Ni NHC

complexes. This is desirable as the cyclometalated configuration of the Ni NHC complexes can ensure the

stability of the complexes during drug delivery.

The impetus for the antimicrobial study came from the knowledge that several elemental metals display

antimicrobial properties, for example silver. There is no previous report on the antimicrobial properties of any

Group 10 metal NHC complexes. However, numerous transition metal NHC complexes were shown to exhibit

significant antimicrobial activities against Gram positive and/or Gram negative bacteria with minimum

inhibitory concentration (MIC) below 10 µg/mL, namely Ag, Au, Rh and Ru NHC complexes [1, 3, 18-20].

Although plenty of impressive anticancer properties have been reported for Group 10 metal NHC complexes,

the information on their antimicrobial properties are limited. Nonetheless, Haque’s group have reported a series

of Pd NHC complexes with selective concentration-dependent antimicrobial activity, displaying high

effectiveness against Gram positive S. aureus, but not the Gram negative E. coli [21, 22]. Therefore, we decided

to resume the study of these Pt and Ni NHC complexes’ antimicrobial activities to explore their potential

biomedical applications.

We previously reported a series of pyridine-functionalised bidendate Pd NHC complexes which displayed

substantial antimicrobial activities with minimum inhibitory concentration at micromolar range, and they are

cytotoxic towards the MCF7 (breast), HCT116 (colon) and H103 (oral) cancer cell lines tested [23]. The

promising in vitro bioactivity of Pd NHC complexes have prompted us to explore the potential of other Group

10 metal NHC complexes as novel antimicrobial and anticancer agents. The synthesis of the novel Pt and Ni

NHC complexes which are analogous to the Pd NHC complexes would be an interesting starting point to study

the effect of different metals on the biological activities of these metal NHC complexes. As literature implies,

the metal centre plays an important role in interacting with biological targets while lipophilicity is maintained at

optimum level by adjusting the side chain in the metal NHC complex [24]. This study focuses on the influence

of different N wingtip substituents on the structure of respective Group 10 metal NHC complexes on the

antimicrobial activities and cytotoxicity against cancer cells.

Results and discussion

Synthesis and characterization of platinum NHC complexes

The synthesis of the targeted complexes followed established synthesis routes with minor modifications

(Scheme 1) [25, 26]. Firstly, the commercially available 2-benzoylpyridine 1 was reduced to phenyl(pyridine-2-

yl)methanol 2, followed by halogenation to yield 2-(chloro(phenyl)methyl)pyridine 3. After that, the targeted

pyridine-functionalized imidazolium salts 4a, 4b, 4c were attained by reacting with their respective imidazoles

(1-methylimidazole, 1-phenylimidazole and 1-tert-butylimidazole) under reflux for 48 hours [25, 27]. The

racemic Pt NHC complexes (±)-5 were prepared using silver(I) oxide-mediated transmetalation method from

the imidazolium salts 4. A crude silver NHC complex were generated in situ, which was then filtered and

immediately subjected to the subsequent reaction to yield Pt NHC complexes (±)-5, using dichloro(1,5-

cyclooctadine)platinum(II) as the transmetalating agent. On the other hand, Ni NHC complexes (±)-6 were

synthesized via a one pot synthesis method by refluxing the imidazolium salts 4 with NiCl₂and K₂CO₃for 24

hours, followed by purification to obtain the final product. All synthesized complexes were characterized by ¹H

and ¹³C nuclear magnetic resonance (NMR) spectroscopy as well as mass spectrometry.

ACCEPTED MANUSCRIPT

As we previously reported, the acidic proton (NHCN) signal of compounds 4 in the ¹H NMR spectra confirmed

the formation of the salts and it resonated in a low field for all salts [23]. For examples, the characteristic

imidazolium proton peak was observed at δ 10.39 ppm, 11.30 ppm and 11.19 ppm for compound 4a, 4b, 4c,

respectively. Besides that, their identities were also confirmed by the resonance of the different wingtip group

1

on the heterocyclic ring, such as a singlet in the H NMR at δ 4.03 ppm for the methyl group in compound 4a

and a singlet at δ 1.70 ppm for the tert-butyl group in compound 4c. For all the salts, the proton at the chiral

centre has a downfield shift appearing in the aromatic proton region (¹H NMR at δ 6.25 to 7.90) and was

indistinguishable from other aromatic protons.

Similar to our previously reported Pd NHC complexes, we synthesized the Pt NHC complexes via

transmetalation through the corresponding Ag(I) NHC complexes which act as a transfer agent. This method is

highly established and very attractive compared to other procedures, which often require inert or harsher

conditions. In this scenario, silver oxide plays the roles of a base as well as a metalation agent. The ease of the

Ag-carbene bond formation is highly desirable because of the great affinity of the electron exchange between

carbene C and Ag centre. The NHC species are good electronic donors whereby Ag acts as an excellent

acceptor of electron density. The overall electronic exchange is the best example of a σ donation from carbene

C to the Ag centre and a π back-donation from Ag to carbene C [24].

In general, the ¹H-NMR spectra of Pt NHC complexes (±)-5 in DMSO-d₆confirm the successful deprotonation

of imidazolium moieties indicating coordination of the ligand to the platinum centre. A crucial observation was

the disappearance of the characteristic NHCN proton signal of imidazolium salts 4 in the ¹H NMR spectra upon

coordination of Pt in complex (±)-5. Similarly, the proton at the chiral centre shifted downfield and fell within

the aromatic region, thus unidentifiable from other aromatic protons. The chemical shift values obtained lay

within the range reported in our previous study of the analogous Pd NHC complexes [23]. No NCN resonance

was observable in the ¹³C NMR spectrum of the synthesized Pt NHC complexes in DMSO-d₆. This is expected

as metal NHC complexes with similar behaviour were previously reported. The rationale behind the absence of

carbene signals is still unclear, however a fast dynamic behaviour together with the poor relaxation of

quaternary NCN could be responsible for it [28].

Due to the poor solubility of complex (±)-5a in a wide array of solvents but DMSO, a few drops of DMSO was

added to the MeOH solution of (±)-5a to solubilize it completely. X-ray crystallography grade single-crystal of

(±)-5a was obtained upon slow addition of diethyl ether into a methanol/DMSO solution of (±)-5a. An X-ray

diffraction study was performed to elucidate the molecular structure of complex (±)-5a. As illustrated in Figure

1, the X-ray diffraction study of complex (±)-5a revealed that the six-membered ring is in the boat conformation,

with the phenyl ring in the axial position. The platinum centre adopts a square planar geometry with the

tetrahedral distortion angle θ = 5.7° between the planes of [Cl(1)-Pt(1)-Cl(2)] and [C(13)-Pt(1)-N(1)]. Besides

that, the Pt(1)-Cl(2) bond is 0.058 Å longer than the Pt(1)-Cl(1) bond. This may be due to the trans effect as

Cl(2) is trans to a strong trans directing ligand NHC as compared to the Cl(1). In addition, the electron density

of the double bond is equally shared among the two nitrogen atoms next to the carbene atom in the imidazole

ring. This is observed through the similar bond length of N(2)-C(13) and N(3)-C(13), which both are

approximately equal to 1.36 Å (an average of a C–N bond of 1.465 Å and a C=N bond of 1.279 Å).

Hereby we observed the similar interesting characteristics of complex (±)-5a, which was similar to its

analogous Pd NHC complex [29]. Firstly, instead of the chair conformation, the six-membered ring preferably

adopted a boat conformation. This is because in chair conformation, the angles in the pyridine and imidazole

ring will be highly tensed owing to the presence of many sp²hybridized carbons in the six-membered ring as

ACCEPTED MANUSCRIPT

well as the planar pyridine and imidazole ring. Secondly, the bulkier phenyl ring is in the axial position rather

than the usual equatorial position. In axial position, the phenyl group experienced minimal steric interaction

with the pyridine and imidazole ring, which is highly favourable. Besides that, the square planar geometry in the

platinum centre reduced the flagpole interaction experienced by the bulky phenyl group as the chlorine atoms

will be pointing away from the phenyl group, thereby avoiding unfavourable steric interactions.

As for the complex (±)-5b, the recrystallisation attempt to obtain crystals which are suitable for single crystal

X-ray diffraction analysis to determine the absolute configuration of (±)-5b is still on-going. We also face

difficulties in obtaining crystallography grade crystals from recrystallization of racemic complex (±)-5c.

Attempts to change the ancillary ligand from dichloro to dibromo and diiodo were performed. Dibromo

complex (±)-7 and diiodo complex (±)-8 would have a poorer solubility as compared to dichloro complex,

which may ease recrystallization. The identities of complexes (±)-7 and (±)-8 (Scheme 2) were verified with

NMR and MS analyses, which both resembled the spectral data of complex (±)-5c.

Synthesis and characterization of nickel NHC complexes

Unlike the analogous Pd and Pt NHC complexes, transmetalation method was attempted using NiCl₂, adapted

from Ray et al. for synthesis of Ni NHC complexes [17]. The imidazolium salts 4, NiCl₂and K₂CO₃were

stirred and refluxed for 24 hours in this one-pot synthesis method to obtain the crude Ni NHC complexes (±)-6,

which were then subjected to purification using column chromatography method. Generally, it was observed

that by using the NiCl₂one-pot synthesis method, we were able to obtain the racemic Ni NHC complexes (±)-6

1

after purification with column chromatography, which were preliminarily confirmed by the H NMR before

recrystallisation. However, unexpected products were obtained after recrystallisation attempts: a nickel

coordination complex 9 yielded from the mother liquor of (±)-6a and a nickelate complex 10 yielded from the

mother liquor of (±)-6c (Scheme 3).

Light green crystals were obtained from slow diffusion of diethyl ether into a methanol solution of racemic

complex (±)-6a. Characterisation of the crystals using single crystal XRD analysis confirmed it to be an

unexpected nickel coordination complex 9 with molecular formula of C₁₀H₂₀Cl₂N₄O₂Ni. The molecular ion

peak for [M-Cl]⁺can be found at 322.1890 (calcd. 322.0707) in MS. Figure 2 displays its molecular structure

and Table 2 lists the selected bond lengths and bond angles. The nickel atom was coordinated to three different

ligands including methanol, methylimidazole and chloride. The nickel centre adopted a typical octahedral

molecular geometry with six bonding atoms positioned at approximately 90 ° to each other. The incorporation

of solvent molecule into a chemical structure as observed in complex 9 was not surprising. Zhang et al. had

reported nickel NHC complexes that have solvent molecules incorporated into the structure apart of the NHC

ring, where the solvent molecule is always located at the equatorial plane and arranged trans to a NHC ring [30].

Proton NMR was unable to resolve the peaks of complex 9, regardless of whether DMSO-d₆or CDCl₃was used.

Essentially, the unexpected complex 9 obtained was a high spin paramagnetic species (d⁸octahedral), which

makes NMR spectroscopic characterisation difficult. Hence their structures were only determined by X-ray

diffraction studies. In the proton NMR spectra obtained for complex 9, the signals are broad and poorly

resolved due to the different sets of ligand signals which indicate the different magnetically inequivalent ligands

coordinated to the nickel centre. This will be further accentuated if there are coordinating solvents, for example

DMSO, that will coordinate to the metal centre and induce octahedral broadening. The analysis of NMR

spectrum is further complicated by the effect of the paramagnetic nickel centre on chemical shifts.

ACCEPTED MANUSCRIPT

Our observation on C-N cleavage and isolation of complex 9 was not surprising. Previous literature reported

different nickel NHC complexes with C-N bond cleavage which resulted in different Ni complexes as well as

cleavage of a pyridine ligand around the metal centre [31, 32]. Zhong et al. proposed that a complex reaction

took place during transmetalation, especially in methanol or other alcohol in the presence of a base, which

resulted in the cleavage of the C-N bond at the adjacent bridge to the imidazolium ring. However, the exact

mechanism is yet to be elucidated [31].

Previously Winston et al. reported a series of Ni NHC complexes with varying coordination geometries, where

they encountered the problems in obtaining pure crystals from Ni NHC complexes reaction mixture due to

formation of co-crystals [33]. This is similar to our observation on the selective isolation of complex 9 from

complex (±)-6a. It is characteristic of nickel(II) complexes that complicated equilibria, which are generally

temperature dependent and sometimes concentration dependent. It exist between various structural types.

Nevertheless, the formation of co-crystals can be rationalised by postulating the establishment of an equilibrium

involving mono- and di-substituted Ni containing species. The equilibrium proposed below is thereby plausible

and has been suggested for other Ni(II)/bidendate ligand system [33, 34].

NiCl₂(MeOH) ⇌ NiCl₂(NHC) ⇌ NiCl₂(NHC)₂

NiCl₂(MeOH) + NiCl₂(NHC)₂⇌ Cl₂Ni(NHC)₂(MeOH)₂⇌ Ni₂Cl₄(NHC)₂+ MeOH

Blue green crystals were obtained from slow diffusion of diethyl ether into a methanol solution of racemic

complex (±)-6c. Characterisation of the crystals using single crystal XRD analysis confirmed it to be an

unexpected nickelate complex 10 with molecular formula of (C₁₉H₂₂N₃)₂NiCl₄(Figure 3). The molecular ion

peak for [M-NiCl₄]⁺can be found at 291.1700 (calcd. 292.1814) in MS. Table 3 presents the selected bond

lengths and angles. The X-ray diffraction study showed the crystal was made up of two units of positively-

charged pyridine-functionalised imidazole ring with tert-butyl at the N wing-tip, and a negatively-charged

2-

NiCl₄ion respectively. The negatively-charged NiCl₄ion was in an expected tetrahedral coordination

geometry with an average angle of 109.5°. From the bond length of N(3)-C(13), N(2)-C(13) and C(15)-C(14),

also corresponded to N(5)-C(32), N(6)-C(32) and C(33)-C(34), which are all approximately 1.33 Å, it is evident

that the positive charge delocalised over the entire five-membered imidazole ring, thereby offering the cationic

ligand additional stability.

Zhang et al. had suggested that it is impossible to host two ligands around nickel ions due to large steric

hindrance, hence the failure in incorporation of large and bulky group to create Ni NHC complexes [30]. In

addition to that, weaker M-C bonds are being formed in Ni case as compared to Pd and Pt. Therefore, it is

speculated that the separation of the bulky phenyl group and pyridine group from the overall structure of

complex (±)-6c, which yielded complex 10 upon recrystallization, could be due to their large steric repulsion

pressure that force the complex to restructure. It was previously reported in literature that reprotonation of the

carbene moieties had occurred upon transmetalation, instead of transfer to nickel, with formation of a mixed

tetrachloronickelate/chloride imidazolium salt [35, 36]. It was reasoned that the formation of stable [NiCl₄]^2-

was more kinetically favoured as compared to transmetalation to Ni, thus preventing transmetalation.

ACCEPTED MANUSCRIPT

Antimicrobial study

In this study, broth microdilution assay was conducted to determine the antimicrobial activities of the

synthesized complexes against a panel of microorganisms including nine strains of Gram positive bacteria, four

strains of Gram negative bacteria, and a Candida albicans (yeast). The complexes tested include the pyridine-

functionalized imidazolium salts 4a-c, racemic Pt NHC complexes (±)-5a-c, the racemic dibromo and diiodo Pt

NHC complexes (±)-7 and (±)-8, the unexpected nickel coordination complex 9 and nickelate complex 10.

Their antimicrobial activities were quantitatively expressed in terms of minimum inhibitory concentration (MIC)

and minimum bactericidal concentration (MBC). MIC is the minimum concentration of a compound to inhibit

the growth of the microorganisms, whereas MBC is referring to the minimum concentration of a compound to

kill the microorganisms tested. An antibiotic, chloramphenicol, was used as the reference drug in the

antimicrobial assay. Chloramphenicol is a type of broad spectrum antibiotic that exerts antimicrobial effect

through protein synthesis inhibition by binding to the 50S ribosomal subunit. Table 4 shows the compounds

tested and their respective MIC and MBC values.

In general, only a lower micromolar concentrations of the synthesized complexes were required to inhibit the

growth of the Gram positive bacterial strains, while Gram negative bacterial strain often required a higher

concentration. The different susceptibility of Gram positive and Gram negative bacteria can be attributed to

their morphological differences. The outer peptidoglycan layer of Gram positive bacteria is not an effective

permeability layer. In contrast, the outer membrane of Gram negative bacteria contained structural

lipopolysaccharide components, thus making the cell wall impermeable to lipophilic solutes whereby porins, a

membrane transport proteins, constitute a selective barrier to the hydrophilic solutes. The metal NHC

complexes synthesized were not soluble in a wide array of solvents but DMSO, and they were made up of

several conjugated rings, which give rise their hydrophobicity (i.e. lipophilicity). Therefore, the lack of efficacy

against gram-negative bacteria was not surprising.

In this study, we have tested multiple strains of the same bacteria. For examples, the Staphylococcus aureus

strains which are sensitive to methicillin (MSSA) and those which are resistant to methicillin (MRSA), as well

as Enterococcus faecalis and its antibiotic-resistant strain (vancomycin-resistant Enterococci, VRE). This is

because certain compounds may have different degree of antimicrobial activities against different strains of

bacteria, especially against the antibiotic-resistant strains. The strain variation effect would render the

antimicrobial compound to be effective against some strains but not the other, which in turn would make the

antimicrobial compounds less viable to be used as an antimicrobial drug. Notably, the antimicrobial activities of

the metal NHC complexes against S. aureus was observed to be strain dependent. For instance, there was an

eight-fold difference in the MIC values of the (±)-5b against MSSA ATCC 6538P and MRSA ATCC 700699

(Table 4). CLSI (2012) had proposed that two treatments with MIC values within two-fold difference is not

significantly different from each other. The strain dependent activity observed could be due to differences in the

cell wall compositions, such as presence of membrane-bound penicillin-binding proteins in MRSA [37, 38].

Majority of the antimicrobial studies of metal NHC complexes focused only on a single strain of each bacterial

species and concluded that they are effective against the bacterial species [20-22, 39-42]. However, our results

suggested otherwise, which implies the importance of testing the complexes against several strains of a same

bacterium.

ACCEPTED MANUSCRIPT

Imidazolium salts or NHC precursors 4 have showed antimicrobial activities at 5 mM or below against the

microorganisms tested. The results are in agreement with other imidazolium-based salts that displayed

antimicrobial properties as reported by literature [43-47]. Yet, the activities were not comparable to some

imidazolium salts which have MIC values in µM range [45]. This could be due to the structure of the

synthesized imidazolium salts 4 were lacking effectively long alkyl chain. Literature have suggested that the

antimicrobial activity is often dependent on the chain length of the N-substituted imidazolium salts, in which the

lowest MIC were achieved by compounds with long alkyl chains (C₈to C₁₆) while alkyl chains of less than six

carbons are generally not active [44, 46]. Longer alkyl chain is thought to be associated with disruption of

bacterial membrane, probably due to the integration of the long hydrocarbon chain with the lipid bilayer of the

cell membrane, leading to leakage of the cell content [48]. Nonetheless, the optimum antimicrobial activities of

an imidazolium salts can be postulated to several factors including hydrophobicity, adsorption, critical micellar

concentrations, aqueous solubility and transport in the assay medium, with solubility in the assay medium being

the limiting factor for transport.

Notably, the antimicrobial activities increased remarkably upon coordination to platinum ((±)-5a). Surprisingly,

these Pt NHC complexes (±)-5 exhibited significant antimicrobial activities surpassed that of their analogous Pd

NHC complexes we reported before [23]. The (±)-5b and (±)-5c complexes, which bear the aromatic phenyl

ring and the bulky tert-butyl group at the N tip of the imidazole ring respectively, were more capable of

inhibiting the growth of microorganisms at a lower concentration as compared to the (±)-5a complex which

bears the aliphatic CH₃group. The (±)-5b and (±)-5c complexes displayed similar pattern of antimicrobial

activities against the microorganisms tested, with MIC at the micromolar range being reported. The most

substantial antimicrobial activities were observed against Gram positive bacteria with MIC below 10 µM (or

below 5 µg/mL).

The difference in the antimicrobial activities for (±)-5a-c could be due to the overall lipophilicity of the entire

structure. The complex (±)-5a only made up of a single carbon unit alkyl chain while longer chain length would

be expected for better antimicrobial activities. Whereas the respective aromatic phenyl group and bulky tert-

butyl group in Pt NHC complex (±)-5b and (±)-5c would give the intrinsic lipophilicity to the structures

resulting in better antimicrobial activities of those two complexes. Although there is no available literature

reported on the antimicrobial activities of Pt NHC complexes, the antimicrobial activities of (±)-5 complexes

were comparable to those Ag and Au NHC complexes which are widely known for their antimicrobial

properties. For examples, Young’s group reported a series of Ag NHC complexes with MIC lower than 10

µg/mL [3, 49]. Ray et al. also reported two antimicrobial gold and silver NHC complexes with MIC values at

15 µM and 25 µM, respectively [20]. Notably, it is observed that the complexes (±)-5c, (±)-7 and (±)-8, which

have different ancillary ligands (chloride, bromide and iodide, respectively), exhibited similar antimicrobial

activities. This suggested that the change of ancillary ligands does not have significant effect on the complexes’

antimicrobial activities in this case.

In general, the findings suggested that the antimicrobial activity arises from a synergy between the metal and

the ligand. Based on Tweedy’s chelation theory, the ion polarity of the metal centre is reduced by overlapping

of the ligand orbitals and the exchange of the partial positive charge of the metal ion to the donor atoms of the

ligands; thereby the delocation of π-electrons on the chelate ring increase and improve the lipophilicity of the

complexes [50]. The increased lipophilicity allows the complex to penetrate the lipid membrane and block the

metal binding sites on the enzymes, which might result in the disturbance of cellular respiration and protein

synthesis, thereby inhibiting the growth. Generally, the nucleic acids, especially the deoxyribonucleic acid

(DNA), is commonly considered to be the main target of Group 10 metallodrugs through the formation of intra-

ACCEPTED MANUSCRIPT

and inter-strand adducts, while metal-bonding to sulphur-containing groups in proteins and interference with

mitochondria functions were also reported [51].

Lastly, the unexpected nickel coordination complex 9 and nickelate complex 10 did not display antimicrobial

activities at the highest concentration tested (0.5 mM). However, nickelate complexes were known to have

antimicrobial activities towards both Gram positive and Gram negative bacteria though comparison cannot be

made in this case as the antimicrobial activities were reported in terms of zone of inhibition obtained from disk

diffusion assay and well diffusion assay [51-53]. It is speculated that the lack of antimicrobial activities of the

nickelate complex 10 was due to the low final concentration tested. Therefore, antimicrobial activities are

expected in case of increment of the final concentration tested of this nickelate complex 10.

Cytotoxicity study

As mentioned earlier, numerous Pt NHC complexes have shown outstanding antiproliferative activities against

cancer cells. In present study, MTT cell viability assay was performed to determine cell cytotoxicity of the

synthesized complexes on selected carcinoma cell lines, including H103 (oral carcinoma), HCT116 (colon

carcinoma) and MCF7 (breast carcinoma). In this assay, cisplatin was utilised as a positive control as it is a

clinically used antitumor drug. Cisplatin was known to exert its antitumor action via binding of cisplatin to

DNA and non-DNA targets, which further induce cell death through apoptosis, necrosis or both within the

heterogenous population of cells that forms a tumoral mass. It is a great reference drug for comparing the cell

cytotoxicity of the synthesized metal NHC complexes to reflect the possible effectiveness and applicability of

these metal NHC complexes as novel anticancer drugs in this preliminary screening stage.

In general, the results showed that the compounds tested had an inhibitory effect in a dose-dependent manner

against the cancer cells tested (Table 5). This is expected as different cell lines would have different growth

rates, drug sensitivities, oncogene expressions and other factors that might possibly cause the variations in the

cells [54, 55]. Literatures have also demonstrated that those reported IC₅₀values of metal NHC complexes may

vary between different cell lines evaluated, therefore it is plausible that these metal NHC complexes would have

different magnitudes of potency in other cell types.

Remarkably, no cell cytotoxicity effect was observed for the imidazolium salts 4 up to 40 µM against the three

carcinoma cell lines tested. Therefore, the cytotoxic effects observed in the racemic palladium and platinum

complexes (±)-5 is speculated to be mainly due to the metal-ligand interaction with cellular components. The

cell cytotoxic effects of these active complexes were comparable to those of other reported organic anticancer

agents, including noscapine (IC₅₀of 20-35 µM) and estramustine (IC₅₀of 0.5-17 µM) [56, 57]. Also, the IC₅₀

values of metal NHC complexes were previously reported to vary within different cell lines, hence it is

conceivable that these metal NHC complexes could show greater potency in other cell types.

In general, the metal NHC complex (±)-5b (with aromatic phenyl N-tip) and (±)-5c (with bulky tert-butyl N-tip),

regardless of palladium or platinum, have shown better cytotoxic effect compared to their analogue (±)-5a (with

aliphatic methyl N-tip) against the tested carcinoma cell lines as evidenced by the low IC₅₀values recorded.

This structure-activity relationship may be attributed to the central metal atom as explained by Tweedy’s

chelation theory and overall lipophilicity of the compounds [58]. In addition, it was known that the steric factors

(bulk, size and shape) of drug can affect how easily it can approach and interact with a binding site. Bulky

substituents may act like a steric shield and hinder the ideal interaction between a compound and its binding site,

ACCEPTED MANUSCRIPT

alternatively, it may help to orientate the compound properly for maximum binding and increase activity [59,

60].

Comparison between different metal centres of the metal NHC complexes have revealed that there are

variations in their cytotoxicities against the cancer cells tested. The (±)-5 complexes displayed higher

cytotoxicities against the carcinoma cell line tested as compared to the analogous Pd NHC complexes (IC₅₀

range of 13.90 to 38.74 µM) with IC₅₀ranging from 5.52 to 28.34 µM [23]. Among all, (±)-5c with the bulky

tert-butyl N substituent was the most potent among all the metal NHC complexes tested, with IC₅₀that are two

to three times lower than that of the anticancer drug cisplatin. These results are not surprising as platinum NHC

complexes were well known for their anticancer properties, as evident by the widespread applications of

platinum-based drugs as chemotherapeutics. Literature have reported a series of Pt NHC complexes with

varying IC₅₀compared to cisplatin, ranging from as low as 0.01 µM to more than 100 µM [9, 15, 61]. Therefore,

the Pt NHC complexes (±)-5 were moderately cytotoxic towards the cancer cells tested, among others.

The mode of action of platinum NHC complexes is generally due to covalent bonding at the minor groove of

DNA causing crosslinking of the bases (especially with guanine), and the square planar configuration at the

metal centre enabled intercalation of the compounds with the DNA involving a π–π stacking. There were also

reports on the Pt NHC complexes accumulated in the nucleus, mitochondria or cytoplasm and play an important

role in triggering cell apoptosis [15, 62]. Apart from the usual DNA target, platinum NHC complexes were

recently shown to be interacting with G-quadruplex (G4) structures from telomeric sequence involved in

oncogene promotors and thereby causing cell death [63].

Last of all, it was observed that the unexpected nickel coordination complex 9 did not display cytotoxicity

against the cancer cells at the highest concentration tested (40 µM). While the unexpected nickelate complex 10

was not cytotoxic towards HCT116 and MCF7 at 40 µM, it was cytotoxic towards the oral cancer cells (H103)

with IC₅₀value of 32.71 µM. There was a previous report on a sodium tris(aspartato)nickelate(II) complex

which displayed LC₅₀(the concentration of a given compound which is lethal to 50% of the cell) values of

4.187-8.044 µg/mL in an in vivo brine shrimp lethality bioassay [64]. This thereby suggesting that nickelate

complex could be a cytotoxic agent towards living cells. Nonetheless, the low cytotoxicity of the nickelate

complex 10 against cancer cells observed could be attributed the low final concentration used in the assay, and

the cytotoxicity is expected to enhance with increment of the final concentration tested of this nickelate

complex 10.

Selectivity index study

Despite that the cytotoxic effects of the tested complexes (±)-5 towards the selected cancer cells are promising,

these metal NHC complexes should not harm the normal cells. Therefore, a selectivity index study was

conducted to compare the cytotoxic effects of these metal complexes against both cancer cells and normal cells.

First and foremost, the synthesized complexes that were effective against the cancer cells were also tested

against a panel of normal human cells including OKF6 (human oral epithelial cells), HACAT (human skin

keratinocytes) and BEAS2B (human lung epithelial cells). The selection of these three human cell lines was to

explore the prospect of possible drug delivery methods for future applications, i.e. oral administration of drug,

dermal or transdermal drug delivery via skin, as well as pulmonary delivery via lung. Table 6 shows their

respective cytotoxicities against OKF6, HACAT and BEAS2B. Likewise, a dose-dependent pattern was

ACCEPTED MANUSCRIPT

observed for the same compound against the normal cell lines tested. Besides, the IC₅₀values obtained were

neither significantly higher nor lower than that of against the cancer cells.

The selectivity index (SI) indicates the cytotoxic selectivity of the compound against cancer cells and its safety

towards normal cells. It was determined from the ratio of the IC₅₀value obtained from the cell viability test on

normal cells versus the IC₅₀value obtained for the cancer cells. The compound with selectivity index value

higher than 3 is suggested to have high selectivity towards a particular cell line while value above 1 indicates

greater inhibition of cancer cells survival than normal cells [65-68]. In this case, selectivity index was computed

based on the IC₅₀values of three cancer cell lines and a normal cell at a time. Table 7 displays the selectivity

index of the active complexes for OKF6 (oral epithelial cells), HACAT (skin keratinocytes) and BEAS2B (lung

epithelial cells).

Overall, it was observed that the Pt NHC complexes (±)-5, (±)-7 and (±)-were not selective against the cancer

cells as the SI value obtained were below 2 and lay between the range of 0.22 to 1.88. Although some of the

tested complexes have the SI values that are comparable or even surpassed that of cisplatin, the selectivity

towards the cancer cells was unsatisfactory as it is less than three. Cisplatin is renowned for its high

effectiveness in the treatment for ovarian and testicular cancers and is also widely employed for treatment of

cervical, bladder, head and neck, oesophageal and small cell lung cancers. Cisplatin is traditionally administered

through the vein intravenously as an infusion. Therefore, the low selectivity index of cisplatin calculated was

not surprising as the cell lines utilised are oral, colon and breast cells. On top of that, the low selectivity of

cisplatin towards the normal cells explained the toxicities of cisplatin towards the cancer patients, which are

reflected by the side effects after cisplatin treatment.

However, these low selectivity index obtained could be due to the fast doubling time of the normal oral

epithelial cells (OKF6), normal skin keratinocytes (HACAT) and normal lung epithelial cells (BEAS2B), which

are similar to that of the cancer cell lines. As a result, these fast-growing normal cells were also susceptible to

the metal complexes at low concentration of compounds, as observed from their IC₅₀values. Otherwise,

literature have suggested that higher concentration of drug is required to inhibit slow-growing cells in relations

with its higher doubling time in culture, and this would make the cell resistant to the cytotoxic agents tested [65,

69]. Therefore, it is anticipated that the cytotoxicity of these synthesized complexes would reduce when it is

tested against a slow-growing cell line, such as CCD841CON (a colorectal epithelial cell line), which resembled

the growth rate of typical normal cells, thereby increase the selectivity index in such cases.

Conclusions

This study presented a new series of platinum NHC complexes derived from pyridine-functionalized

imidazolium salts. All NHC precursors, imidazolium salts (or NHC precursors), metal NHC complexes and the

unexpected nickel complexes were characterized by analytical and spectroscopic techniques. The molecular

structure of Pt NHC complex (±)-5a were elucidated by the means of single crystal X ray diffraction technique.

Besides, the recrystallization attempts of the Ni NHC complexes (±)-6 have yielded an unexpected nickel

coordination complex 9 and a nickelate complex 10, which both have been structurally determined through X

ray crystallography study. While the imidazolium salts (or NHC precursors) 4 exhibited insubstantial

antimicrobial activities than those reported by the literatures, the Pt NHC complexes (±)-5 have shown

improved antimicrobial activities upon coordination to metals. Remarkably, complexes (±)-5b and (±)-5c

exhibited significant antimicrobial activities with MIC as low as 2 µM, which are comparable to silver NHC

ACCEPTED MANUSCRIPT

complexes with renowned antimicrobial profiles. Likewise, the cytotoxic effects of complexes (±)-5 increased

significantly upon coordination to platinum (as compared to the imidazolium salts 4). Most notably, complex

(±)-5 displayed outstanding cytotoxicities towards the cancer cells with IC₅₀values that are two to three times

lower than that of the anticancer benchmark cisplatin. However, selectivity index study’s results indicate that

the tested complexes and cisplatin demonstrated similar selectivity towards the tested cancer cells. Essentially,

evidences for the influence of metals and N wingtip substituents on the NHC ring on the antimicrobial and

anticancer activities of these metal NHC complexes have been found. Although the mechanism of action for the

reported biological activities is not known at present, it is apparent from this work that these Pt NHC complexes

could be some potential drug candidates in the future.

Experimental

General procedures

All the commercially available chemicals and solvents were used without prior drying or purification.

Dichloro(1, 5-cyclooctadiene)platinum(II) Pt(cod)Cl₂, 1-phenylimidazole and 1-tert-butylimidazole were

prepared according to literature methods with some modifications [70-72]. Melting point determination was

carried out using Stuart Digital Melting Point Apparatus SMP10 with 1 °C resolution. Mass spectra were

recorded on Agilent 1290 Infinity LC system coupled to Agilent 6520 Accurate-Mass Q-TOF mass

spectrometer with dual ESI source. Proton nuclear magnetic resonance (¹H NMR) and carbon nuclear magnetic

resonance (¹³C NMR) spectroscopy were performed on a Bruker Advance 300 NMR spectrometer. The number

of protons (n) for a given resonance is indicated by n H. Coupling constants are reported as a J value in Hz.

1

Proton nuclear magnetic resonance spectra H NMR are reported as δ in units of parts per million (ppm)

downfield from SiMe₄(δ 0.00). Carbon nuclear magnetic resonance spectra ¹³C NMR are reported as δ in units

of parts per million (ppm) relative to the signal of chloroform-d (δ 77.16 ppm, triplet) and DMSO-d₆(δ 39.52

ppm, septet). All chemical shifts reported are referenced to the chemical shifts of their respective residual

solvent resonances. Unless stated otherwise, all NMR experiments are carried out at 300 K. The single crystal X

ray diffraction studies were performed by X ray crystallography facilities in University Malaya (UM) and

Universiti Kebangsaan Malaysia (UKM), Malaysia.

Synthesis of phenyl(pyridin-2-yl)methanol, 2

The method for reduction of 2-benzoylpyridine into phenyl(pyridin-2-yl)methanol was modified from literature

[27]. Sodium borohydride (2.04 g, 54 mmol) in 50 mL 95 % ethanol was added dropwise into a solution of 2-

benzoylpyridine (5 g, 27 mmol) in 50 mL 95% ethanol on an ice bath. The reaction mixture was stirred

continuously for 1 hour until reaction is completed. Then, 100 mL of water was added to the reaction mixture

and the solution was heated at 90 °C for 15 minutes. Then, the solution was extracted with ethyl acetate thrice

and the solvent was evaporated under reduced pressure to obtain a pale green oil. Slow evaporation of a solution

in ethanol at room temperature yielded the clear crystal solid, 5.01 g, 96.4 %. M.p. = 88 – 90 °C. ¹H NMR (300

MHz, CDCl₃): δ = 5.29 (d, 1 H, J_H,H= 4.5 Hz, OH), 5.75 (d, 1 H, J_H,H= 4.5 Hz, HC-OH), 7.13-7.39 (m, 7 H,

arom.), 7.60-7.61 (m, 1 H, arom.) and 8.55 (ddd, 1 H, J_H,H= 5.1 Hz, J_H,H= 1.2 Hz, J_H,H= 0.9 Hz, arom.) ppm.

¹³C NMR (75 MHz, CDCl₃): δ = 75.00 (HC-OH), 121.35, 122.42, 127.07, 127.82, 128.56, 136.83, 143.23,

147.83 and 160.91 ppm. MS (ESI) m/z: [M+H]⁺calcd. for C₁₂H₁₂NO 186.0919, found 186.0912.

ACCEPTED MANUSCRIPT

Synthesis of 2-(chloro(phenyl)methyl)pyridine, 3

Phenyl(pyridin-2-yl)methanol 2 (1.85 g, 10.5 mmol) and triethylamine (3.4 mL, 24.4 mmol) in 32 mL of

CH₂Cl₂was stirred in an ice bath. Methanesulfonyl chloride (1.2 mL, 15.8 mmol) was added dropwise into the

stirring solution. The reaction mixture was left to warm up slowly to room temperature. The reaction mixture

was allowed to stir overnight and then poured into a saturated aqueous NaHCO₃solution. The aqueous layer

was extracted with chloroform thrice. The combined organic layers were washed with H₂O, dried over

anhydrous MgSO₄and evaporated in vacuo to give a red liquid. The resultant red liquid was subjected to

column chromatography (ethyl acetate/hexane 1:4 v/v) give yellow oil, 1.52 g, 74.3 %. The spectral data for this

compound are consistent with those reported in the literature [25]. ¹H NMR (300 MHz, CDCl₃): δ = 6.16 (s, 1 H,

ClCH), 7.20 (ddd, 1 H, J_H,H= 7.5 Hz, J_H,H= 4.8 Hz, J_H,H= 1.2 Hz, arom.), 7.25-7.37 (m, 3 H, arom.), 7.45-7.56

13

(m, 3 H, arom.), 7.67-7.73 (m, 1 H, arom.) and 8.57 (ddd, 1 H, J_H,H= 4.8, J_H,H= 1.8, J_H,H= 0.9 Hz) ppm. C

NMR (75 MHz, CDCl₃): δ = 64.54 (ClCH), 122.09, 122.81, 127.78, 128.28, 128.64 and 137.05, 139.96, 149.19

and 159.75 ppm. MS (ESI) m/z: [M-Cl]⁺calcd. for C₁₂H₁₀N 168.0813, found 168.0804.

Synthesis of pyridine-functionalized imidazolium salts 4

Liquid 1-methylimidazole (a) or 1-phenylimidazole (b) or 1-tert-butylimidazole (c) (1 mol equiv.) was added to

a stirring solution of compound 3 (1 mol equiv.) in 50 mL of CH₃CN. The reaction mixture was heated at

refluxing temperature for 48 hours. Then, the reaction mixture was reduced in vacuo and the resulting oil was

stirred in diethyl ether. The diethyl ether layer was decanted away to give ligand 4a, 4b and 4c. The spectral

data for these compounds are consistent with those reported in the literature [25, 26, 29].

Synthesis of 1-methyl-3-[phenyl(pyridin-2-yl)methyl]-1H-imidazolium chloride, 4a

1

Hygroscopic off white solid, 45.8 %. H NMR (300 MHz, CDCl₃): δ = 4.03 (s, 3 H, CH₃), 7.26-7.37 (m, 4 H,

arom.) 7.41-7.46 (m, 3 H, arom.), 7.63-7.76 (m, 4 H, arom.), 8.57-8.60 (m, 1 H, arom.) and 10.39 (s, 1 H,

13

carbenic proton) ppm. C NMR (75 MHz, CDCl₃): δ = 36.63 (CH₃), 65.98 (NCPh), 122.48, 122.58, 123.78,

124.36, 128.84, 129.24, 129.34, 136.43, 137.61, 137.85, 149.52 and 155.09 ppm. MS (ESI) m/z: [M-H]⁺calcd.

for C₁₆H₁₅N₃Cl 284.0954, found 284.2074.

Synthesis of 1-phenyl-3-[phenyl(pyridin-2-yl)methyl]-1H-imidazolium chloride, 4b

Brown oil, 2.71 g, 28.8 %.¹H NMR (300 MHz, CDCl₃): δ = 7.34-7.39 (m, 3 H, arom.), 7.49-7.61 (m, 5 H,

arom.), 7.67-7.79 (m, 5 H, arom.), 7.96 (t, 1 H, J_H,H= 1.8 Hz, arom.), 8.23 (s, 1H, arom.), 8.60 (ddd, 1 H, J_H,H

=

0.9 Hz, J_H,H= 1.8 Hz, J_H,H= 4.8 Hz, arom.) and 11.30 (s, 1 H, carbenic proton) ppm. ¹³C NMR (75 MHz,

CDCl₃): δ = 65.82 (NCPh), 119.47, 121.71, 123.44, 123.80, 124.81, 129.10, 129.25, 129.41, 130.19, 130.56,

134.54, 136.28, 136.42, 137.71, 149.34, and 155.02 ppm. MS (ESI) m/z: [M-Cl]⁺calcd. for C₂₁H₁₈N₃312.1501,

found 312.1508.

ACCEPTED MANUSCRIPT

Synthesis of 1-tert-butyl-3-[phenyl(pyridin-2-yl)methyl]-1H-imidazolium chloride, 4c

Brown solid, 8.24 g, 54.0 %. ¹H NMR (300 MHz, CDCl₃): δ = 1.70 (s, 9 H, CCH₃), 7.27-7.37 (m, 5 H, arom.),

7.50-7.55 (m, 2H, arom.), 7.69-7.75 (m, 1 H, arom.), 7.81-7.83 (m, 1 H, arom.), 8.14 (s, 1 H, arom.), 8.59 (ddd,

13

1 H, J_H,H= 0.9 Hz, J_H,H= 1.8 Hz, J_H,H= 4.8 Hz) and 11.19 (s, 1 H, carbenic proton) ppm. C NMR (75 MHz,

CDCl₃): δ = 30.05 (CCH₃), 60.13 (NCCH3), 65.26 (NCPh), 117.97, 122.50, 123.60, 124.87, 128.91, 129.07,

136.53 and 136.96, 137.55, 149.30 and 155.44 ppm. MS (ESI) m/z: [M-Cl]⁺calcd. for C₁₉H₂₂N₃292.1814,

found 292.3259.

Synthesis of pyridine functionalized Pt NHC complexes (±)-5

To a solution of pyridine-functionalized NHC precursors 4a, 4b, 4c (1 mol equiv.) in 30 mL of CH₂Cl₂, Ag₂O

(0.5 mol equiv.) was added in the dark. The reaction mixture was stirred at room temperature for 12 hours and

was filtered through a short plug of celite. The Pt(cod)Cl₂(1 mol equiv.) was added to the orange filtrate in the

dark. The reaction mixture was then allowed to stir at room temperature for two weeks and was filtered through

celite. The filtrate was then reduced in vacuo to yield the racemic Pt NHC complexes (±)-5.

Synthesis of racemic Pt NHC complex (±)-5a

Off white solid 0.760 g, 35.0 %. M.p. = 236 – 238 °C (decomposed). ¹H NMR (300 MHz, DMSO-d₆): δ = 3.90

(s, 3 H, CH₃), 7.05 (s, 1 H, arom.), 7.26-7.45 (m, 6 H, arom.), 7.54-7.60 (m, 1 H, arom.), 7.75 (d, 1 H, J_H,H= 2.1

Hz, arom.), 7.97-7.99 (m, 1 H, arom.), 8.20-8.26 (m, 1 H, arom.) and 9.31 (dd, 1 H, J_H,H= 1.5 Hz, J_H,H= 6.0 Hz,

13

arom.) ppm. C NMR (75 MHz, DMSO-d₆): δ = 37.60 (CH₃), 66.95 (NCPh), 122.09, 123.90, 126.32, 127.22,

128.49, 129.07, 129.48, 138.15, 139.84, 140.29, 154.57, 155.57 ppm. MS (ESI) m/z: [M]⁺calcd. for

C₁₆H₁₅Cl₂N₃Pt 514.0291, found 514.0169. Light yellow crystals were obtained from slow diffusion of diethyl

ether into a methanol/DMSO solution of (±)-5a.

Synthesis of racemic Pt NHC complex (±)-5b

Orange solid 1.37 g, 44.5 %. M.p. = 241 – 243 °C (decomposed). ¹H NMR (300 MHz, DMSO-d₆): δ = 7.42 (s, 1

H. arom.), 7.47-7.51 (m, 4 H, arom.), 7.55-7.61 (m, 4 H, arom.), 7.72-7.74 (m, 1 H, arom.), 7.86-7.92 (m, 3 H,

arom.), 8.14-8.19 (m, 2 H, arom.), 8.30-8.31 (m, 1 H, arom), 9.41 (dd, 1 H, J_H,H= 1.2 Hz, 5.7 Hz, arom.) ppm.

¹³C NMR (75 MHz, DMSO-d₆): δ = 67.53 (NCPh), 121.83, 125.37, 127.03, 127.45, 128.89, 129.12, 129.49,

129.82, 130.32, 139.04, 139.37, 140.76, 155.07 and 155.58 ppm. MS (ESI) m/z: [MH-Cl]⁺calcd. for

C₂₁H₁₈ClN₃Pt 542.0837, found 542.0283.

Synthesis of racemic Pt NHC complex (±)-5c

1

Brown solid, 1.71g, 51.0%. M.p. = 227 – 228 °C (decomposed). H NMR (300 MHz, DMSO-d₆): δ = 1.61 (s, 9

H, CCH₃), 7.21 (s, 1 H, arom.), 7.34-7.48 (m, 6 H, arom.), 7.77-7.90 (m, 2 H, arom.), 7.94-7.96 (m, 1 H, arom.),

8.07 (t, 1 H, J_H,H= 2.1 Hz, arom.) and 8.64-8.66 (m, 1 H, arom.) ppm. ¹³C NMR (75 MHz, DMSO-d₆): δ =

30.88 (CCH₃), 60.38 (NCCH₃), 66.45 (NCPh), 120.90, 123.02, 123.89, 124.34, 128.37, 128.96, 129.56, 135.42,

ACCEPTED MANUSCRIPT

137.43, 138.23, 150.09 and 155.88 ppm. MS (ESI) m/z: [M-H]⁺calcd. for C₁₉H₂₀Cl₂N₃Pt 555.0682, found

555.0453.

Preparation of racemic dibromide Pt NHC complex (±)-7

The solution of racemic complex (±)-5c (1.64 g, 2.94 mmol) in 50.0 mL dichloromethane was added to

potassium bromide (3.53 g, 29.7 mmol) in acetone (50.0 mL) and water (10.0 mL). The mixture was then stirred

vigorously for 15 minutes. The solvents were removed in vacuo and the residue was extracted with

dichloromethane and water. Then, the organic layer was dried by using anhydrous magnesium sulphate.

Removal of solvent gave (±)-7 as a brown solid, 1.04 g, 54.7 %. M.p. = 205 – 207 °C (decomposed). ¹H NMR

(300 MHz, DMSO-d₆): δ = 1.61 (s, 9 H, CCH₃), 7.18 (s, 1 H, arom.), 7.41-7.49 (m, 5 H, arom.), 7.65-7.70 (m, 1

H, arom.), 7.88-7.96 (m, 3 H, arom.), 8.07 (t, 1 H, J_H,H= 1.8 Hz, arom.) and 8.65 (ddd, 1 H, J_H,H= 0.9 Hz, J_H,H

=

1.8 Hz, J_H,H= 4.8 Hz, arom.) ppm. ¹³C NMR (75 MHz, DMSO-d₆): δ = 30.36 (CCH₃), 59.64 (NCCH3), 65.70

(NCPh), 120.12, 122.26, 123.10, 123.59, 127.92, 128.18, 128.79, 134.56, 136.61, 137.47, 149.32 and 155.06

ppm. MS (ESI) m/z: [M]⁺calcd. for C₁₉H₂₁Br₂N₃Pt 643.9750, found 644.0705.

Preparation of racemic diiodo Pt NHC complex (±)-8

The solution of racemic complex (±)-Pt-5c (1.01 g, 1.81 mmol) in 100 mL dichloromethane was mixed with

sodium iodide (2.00 g, 13.3 mmol) in acetone (100 mL). The mixture was then stirred vigorously for 15 minutes.

The solvents were removed in vacuo and the residue was extracted with dichloromethane. Then, the solvent was

removed under reduced pressure and diethyl ether was added to obtain (±)-8 as a brown solid, 1.05 g, 78.4 %.

1

M.p. = 213 – 216 °C (decomposed). H NMR (300 MHz, DMSO-d₆): δ = 1.61 (s, 9 H, CCH₃), 7.16 (s, 1 H,

arom.), 7.34-7.48 (m, 5 H, arom.), 7.88-7.95 (m, 3 H, arom.), 8.07 (t, 1 H, J_H,H= 2.1 Hz, arom.) and 8.65 (ddd, 1

H, J_H,H= 0.9 Hz, J_H,H= 1.8 Hz, J_H,H= 4.8 Hz, arom.) ppm. ¹³C NMR (75 MHz, DMSO-d₆): δ = 31.07 (CCH₃),

59.92 (NCCH₃), 66.06 (NCPh), 120.38, 122.54, 123.35, 123.86, 128.44, 129.06, 129.71, 134.77, 136.82, 137.74,

149.58 and 155.30 ppm. MS (ESI) m/z: [M]⁺calcd. for C₁₉H₂₁I₂N₃Pt 739.9437, found 740.1476.

Synthesis of pyridine functionalized Ni NHC complexes (±)-6

The pyridine-functionalized NHC precursors 4a, 4b, 4c (1 mol equiv.), NiCl₂(1.5 mol equiv.) and K₂CO₃(3

mol equiv.) were taken in 50.0 mL of acetonitrile. The reaction mixture was refluxed for 24 hours, filtered and

the solvent was removed. The residue was extracted in CH₂Cl₂, which was filtered and evaporated under

vacuum to obtain the oil. The crude oil was subjected to purification using column chromatography with

CH₂Cl₂/MeOH (50:50 v/v) as the mobile phase to yield the racemic Ni NHC complexes (±)-6.

Synthesis of racemic Ni NHC complex (±)-6a

1

Hygroscopic greenish brown solid, 3.30 g, 39.2 %. H NMR (300 MHz, DMSO-d₆): δ = 4.05 (s, 3 H, CH₃),

7.21 (s, 1 H, arom.), 7.27-7.37 (m, 5 H, arom.), 7.45-7.48 (m, 3 H, arom.), 7.70-7.76 (m, 2 H, arom.) and 8.59

(d, 1 H, J_H,H= 4.5 Hz, arom.) ppm. Light green crystals were obtained from slow diffusion of diethyl ether into

ACCEPTED MANUSCRIPT

a methanol solution of (±)-Ni-5a. Characterisation of the crystals using single crystal XRD analysis confirmed it

to be an unexpected nickel coordination complex 9 with molecular formula of C₁₀H₂₀Cl₂N₄O₂Ni. MS (ESI) m/z:

[MH-Cl]⁺calcd. for C₁₀H₂₁ClN₄O₂Ni 322.0707, found 322.1890. M.p. = 130 – 131 °C.

Synthesis of racemic Ni NHC complex (±)-6b

1

Hygroscopic brown solid, 0.590 g, 25.7%. H NMR (300 MHz, DMSO-d₆): δ = 7.25-7.90 (m, 11 H, arom.),

7.87-7.93 (m, 1 H, arom.), 8.03-8.06 (m, 2 H, arom.), 8.08 (t, 1 H, J_H,H= 11.5 Hz, arom.) and 8.72-8.73 (m, 1 H,

arom.) ppm.

Synthesis of racemic Ni NHC complex (±)-6c

Hygroscopic green solid, 1.53 g, 72.7 %. ¹H NMR (300 MHz, DMSO-d₆): δ = 1.80 (s, 9 H, CCH₃), 7.24 (s, 1 H,

arom.), 7.31-7.33 (m, 1 H, arom.), 7.44-7.49 (m, 1 H, arom.), 7.52-7.57 (m, 2 H, arom.), 8.12-8.22 (m, 4 H,

arom.) and 8.33-8.45 (m, 1 H, arom.) ppm. Blue green crystals were obtained from slow diffusion of diethyl

ether into a methanol solution of (±)-Ni-5c. Characterisation of the crystals using single crystal XRD analysis

confirmed it to be an unexpected nickelate complex 10 with molecular formula of (C₁₉H₂₂N₃)₂NiCl₄. MS (ESI)

m/z: [M-NiCl₄]⁺calcd. for C₁₉H₂₂N₃292.1814, found 292.1700. M.p. = 145 – 146 °C.

Evaluation of Antimicrobial Activity

The broth microdilution assay was conducted on 96-well microtiter plates according to protocol stated by

Clinical and Laboratory Standards Institute with some amendments [73]. The compounds tested were prepared

in 10% DMSO in PBS solution. Positive controls utilised in this assay were chloramphenicol (0.250 mg/mL) for

bacteria and cyclohexamine (1.00 mg/mL) for Candida sp.. Two negative controls were prepared: with MHB

broth only, and with 10.0 % DMSO in PBS. Overnight bacteria culture in Mueller-Hinton broth (MHB) was

adjusted to match 0.5 McFarland standard and diluted 1:100 in MHB. Into each well of the 96-well microtiter

plate, the compounds of interest were serially diluted two-fold with MHB to obtain final working concentrations

range between 0.500 mM and 0.391 µM (for metal complexes) or 5.00 mM and 3.91 µM (for compounds other

than metal complexes) in 100 µL broth. Then, 100 µL of 1:100 diluted bacterial suspensions were added into

each well prior to incubation at 37 ºC for 24 hours. The well with the lowest concentration of compounds that

has no observed growth was determined as the minimum inhibitory concentration (MIC). The content of clear

wells was streaked on Mueller-Hinton agar (MHA) and incubated overnight. The minimum bactericidal

concentration (MBC) was determined as the lowest concentration of compound in which the inoculum did not

gave bacterial broth on the MHA. The experiment was performed in triplicates.

Evaluation of Cytotoxicity

Cytotoxicity studies were carried out using the human colorectal carcinoma cell line HCT116, the human oral

carcinoma cell line H103, and the breast adenocarcinoma cell line MCF7. Besides that, complexes with

significant cytotoxicity against cancer cells were tested against three non-cancerous human cell lines for

ACCEPTED MANUSCRIPT

possible application routes including OKF6 (oral epithelial cells), HACAT (skin keratinocytes) and BEAS2B

(lung epithelial cells). All cell lines were obtained from American Type Culture Collection (ATCC). MTT (3-

(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide) cell viability assay was performed to evaluate the

cell cytotoxic effects of the synthesized compounds [74]. The compounds tested were prepared in 2% DMSO in

PBS solution. Positive control utilised in this assay was cisplatin (prepared in 0.9% NaCl solution). The cells

were seeded in 96-well microtiter plate at a density of 5000 cells/well in 100µL cell culture medium and

incubated at 37 ºC (5 % CO₂) for 24 hours. After 18 hours of seeding, the medium was removed and then the

cells were incubated at 37 ºC for 48 hours in CO₂incubator with absence and/or presence of various

concentrations of compounds of interest ranging from 10, 20, 25, 30, 35 and 40 µM. Given that the compound’s

treatments containing 0.2 % of final DMSO concentration, 0.2 % DMSO in PBS solution was used as the

negative control. After incubation, 10 µL of MTT solution (5 mg/mL in PBS) was added into each well. These

plates were incubated again for 4 hours in CO₂incubator at 37 ºC. After that, the medium-MTT solutions are

removed and the purple formazan crystals formed were dissolved in 200 µL dimethyl sulfoxide. The resulting

MTT-products were determined by measuring the absorbance at 570 nm, with reference wavelength at 620 nm.

The experiment was carried out in quadruplicate for each compound/complex, and the medium not containing

the complexes served as the control. The cell viability was determined by using the formula: Cell viability % =

(optical density of sample / optical density of control) × 100 (solvent controls set to 100% viable cells). IC₅₀

value were defined as the concentrations that show 50% inhibition of proliferation on any tested cell line.

Conflicts of interest

The authors declare no conflict of interest.

Acknowledgements

Authors would like to express their gratitude for the financial support from the Ministry of Higher Education

(MOHE), Malaysia via Fundamental Research Grant Scheme (FRGS) (FRGS/1/2014/ST01/MUSM/03/1) and

the School of Science, Monash University Malaysia. We also thank Dr. Tan Kong Wai from University of

Malaya (UM) and Mr. Mohammad Fadzlee from Universiti Kebangsaan Malaysia (UKM) for their competent

technical assistance and analysis on the X ray crystallography data obtained in this study.

References

[1] C.M. Che, R.W.Y. Sun, L.F. Chow, J. Yan, Pharmaceutical composition containing cyclometalated n-

heterocyclic carbene complexes for cancer treatment, Patent (2011) WO2011050574A1.

[2] K.M. Hindi, D.A. Medvetz, M. Panzner, C. Tessier, W.J. Youngs, Metal complexes incorporated within

biodegradable nanoparticles and their use, Patent (2009) WO2008150830A2.

[3] K.M. Hindi, T.J. Siciliano, S. Durmus, M.J. Panzner, D.A. Medvetz, D.V. Reddy, L.A. Hogue, C.E. Hovis,

J.K. Hilliard, R.J. Mallet, C.A. Tessier, C.L. Cannon, W.J. Youngs, Synthesis, stability, and antimicrobial

studies of electronically tuned silver acetate N-heterocyclic carbenes, Journal of Medicinal Chemistry 51(6)

(2008) 1577-1583.

ACCEPTED MANUSCRIPT

[4] P. Mailliet, A. Marinetti, M. Skander, Platinum-N-heterocyclic carbene derivatives, preparation thereof and

therapeutic use thereof, Patent (2009) WO2009118475A2.

[5] W. Youngs, C. Tessier, W. Kofron, R. Simons, J. Garrison, Carbene porphyrins and carbene porphyrinoids,

methods of preparation and uses thereof, Patent (2004) WO2002038566A2.

[6] W.J. Youngs, C.A. Tessier, J. Garrison, C. Quezada, A. Melaiye, M. Panzner, S. Durmas, Metal complexes

of N-heterocyclic carbenes as radiopharmaceuticals and antibiotics, Patent (2005) US20070021401A1.

[7] S. Budagumpi, S. Endud, Group XII Metal–N-Heterocyclic Carbene Complexes: Synthesis, Structural

Diversity, Intramolecular Interactions, and Applications, Organometallics 32(6) (2013) 1537-1562.

[8] L. Oehninger, R. Rubbiani, I. Ott, N-Heterocyclic carbene metal complexes in medicinal chemistry, Dalton

Transactions 42(10) (2013) 3269-3284.

[9] M. Skander, P. Retailleau, B. Bourrié, L. Schio, P. Mailliet, A. Marinetti, N-Heterocyclic Carbene-Amine

Pt(II) Complexes, a New Chemical Space for the Development of Platinum-Based Anticancer Drugs, Journal of

Medicinal Chemistry 53(5) (2010) 2146-2154.

[10] M. Chtchigrovsky, L. Eloy, H. Jullien, L. Saker, E. Ségal-Bendirdjian, J. Poupon, S. Bombard, T. Cresteil,

P. Retailleau, A. Marinetti, Antitumor trans-N-Heterocyclic Carbene–Amine–Pt(II) Complexes: Synthesis of

Dinuclear Species and Exploratory Investigations of DNA Binding and Cytotoxicity Mechanisms, Journal of

Medicinal Chemistry 56(5) (2013) 2074-2086.

[11] C. Mauro, N. Giovanni, Trans-Platinum Complexes in Cancer Therapy, Anti-cancer agents in medicinal

chemistry 7(1) (2007) 111-123.

[12] M. Van Beusichem, N. Farrell, Activation of the trans geometry in platinum antitumor complexes.

Synthesis, characterization, and biological activity of complexes with the planar ligands pyridine, N-

methylimidazole,

thiazole,

and

quinoline.

Crystal

and

molecular

structure

of

trans-

dichlorobis(thiazole)platinum(II), Inorganic chemistry 31(4) (1992) 634-639.

[13] N. Farrell, L.F. Povirk, Y. Dange, G. DeMasters, M.S. Gupta, G. Kohlhagen, Q.A. Khan, Y. Pommier, D.A.

Gewirtz, Cytotoxicity, DNA strand breakage and DNA–protein crosslinking by a novel transplatinum

compound in human A2780 ovarian and MCF-7 breast carcinoma cells, Biochemical Pharmacology 68(5)

(2004) 857-866.

[14] K. Li, T. Zou, Y. Chen, X. Guan, C.-M. Che, Pincer-Type Platinum(II) Complexes Containing N-

Heterocyclic Carbene (NHC) Ligand: Structures, Photophysical and Anion-Binding Properties, and Anticancer

Activities, Chemistry – A European Journal 21(20) (2015) 7441-7453.

[15] R.W.-Y. Sun, A.L.-F. Chow, X.-H. Li, J.J. Yan, S.S.-Y. Chui, C.-M. Che, Luminescent cyclometalated

platinum(ii) complexes containing N-heterocyclic carbene ligands with potent in vitro and in vivo anti-cancer

properties accumulate in cytoplasmic structures of cancer cells, Chemical Science 2(4) (2011) 728-736.

[16] T. Zou, C.-N. Lok, Y.M.E. Fung, C.-M. Che, Luminescent organoplatinum(ii) complexes containing

bis(N-heterocyclic carbene) ligands selectively target the endoplasmic reticulum and induce potent photo-

toxicity, Chemical Communications 49(47) (2013) 5423-5425.

ACCEPTED MANUSCRIPT

[17] S. Ray, J. Asthana, J.M. Tanski, M.M. Shaikh, D. Panda, P. Ghosh, Design of nickel chelates of

tetradentate N-heterocyclic carbenes with subdued cytotoxicity, Journal of Organometallic Chemistry 694(15)

(2009) 2328-2335.

[18] M.V. Baker, P.J. Barnard, S.J. Berners-Price, S.K. Brayshaw, J.L. Hickey, B.W. Skelton, A.H. White,

Cationic, linear Au(I) N-heterocyclic carbene complexes: Synthesis, structure and anti-mitochondrial activity,

Dalton Transactions (30) (2006) 3708-3715.

[19] B. Cetinkaya, E. Cetinkaya, H. Kucukbay, R. Durmaz, Antimicrobial activity of carbene complexes of

rhodium(I) and ruthenium(II), Arzneimittel-Forschung 46(8) (1996) 821-3.

[20] S. Ray, R. Mohan, J.K. Singh, M.K. Samantaray, M.M. Shaikh, D. Panda, P. Ghosh, Anticancer and

Antimicrobial Metallopharmaceutical Agents Based on Palladium, Gold, and Silver N-Heterocyclic Carbene

Complexes, Journal of the American Chemical Society 129(48) (2007) 15042-15053.

[21] R.A. Haque, U.F.M. Haziz, A.A. Amirul, N. Shaheeda, M.R. Razali, Synthesis of a palladium(II) complex

of a N-heterocylic carbene via transmetalation: crystal structure and antibacterial studies, Transition Metal

Chemistry 41(7) (2016) 775-781.

[22] R.A. Haque, A.W. Salman, S. Budagumpi, A.A.-A. Abdullah, A.M.S.A. Majid, Sterically tuned Ag(i)- and

Pd(ii)-N-heterocyclic carbene complexes of imidazol-2-ylidenes: synthesis, crystal structures, and in vitro

antibacterial and anticancer studies, Metallomics 5(6) (2013) 760-769.

[23] K.B. Choo, W.L. Mah, S.M. Lee, W.L. Lee, Y.L. Cheow, Palladium complexes of bidentate pyridine N-

heterocyclic carbenes: Optical resolution, antimicrobial and cytotoxicity studies, Applied Organometallic

Chemistry 32(8) (2018) e4377.

[24] S.B. Aher, V. Dubey, P.N. Muskawar, K. Thenmozhi, A.R. Ghosh, P.R. Bhagat, Cytotoxic behavior of

binuclear silver N-heterocyclic carbenes in HCT 116 cells and influence of substitution on cytotoxicity,

Research on Chemical Intermediates (2017) 1-12.

[25] M. Chiang, Y. Li, D. Krishnan, P. Sumod, K.H. Ng, P.-H. Leung, Synthesis and characterisation of a novel

chiral bidentate pyridine-n-heterocyclic carbene-based palladacycle, European Journal of Inorganic Chemistry

2010(9) (2010) 1413-1418.

[26] K.H. Ng, Y. Li, W.X. Tan, M. Chiang, S.A. Pullarkat, Synthesis and characterization of conformationally

rigid chiral pyridine-N-heterocyclic carbene-based palladacycles with an unexpected Pd-N bond cleavage,

Chirality 25(3) (2013) 149-59.

[27] H. Kim, S.K. Kang, Crystal structure of phenyl(pyridin-2-yl)methanol, Acta Crystallographica Section E

70(9) (2014) o947.

[28] J.C. Garrison, W.J. Youngs, Ag (I) N-heterocyclic carbene complexes: synthesis, structure, and application,

Chemical Reviews 105(11) (2005) 3978-4008.

[29] M. Chiang, Synthesis, Characterisation And Catalytic Application Of Novel Cyclopalladated Pyridine

Functionalized N-Heterocyclic Carbenes Complexes, School of Physical and Mathematical Sciences, Nanyang

Technological University, Singapore, 2011.

ACCEPTED MANUSCRIPT

[30] X. Zhang, B. Liu, A. Liu, W. Xie, W. Chen, Steric Bulkiness-Dependent Structural Diversity in Nickel (II)

Complexes of N-Heterocyclic Carbenes: Synthesis and Structural Characterization of Tetra-, Penta-, and

Hexacoordinate Nickel Complexes, Organometallics 28(5) (2009) 1336-1349.

[31] W. Zhong, Z. Fei, R. Scopelliti, P.J. Dyson, Alcohol-Induced C−N Bond Cleavage of Cyclometalated N-

Heterocyclic Carbene Ligands with a Methylene-Linked Pendant Imidazolium Ring, Chemistry – A European

Journal 22(34) (2016) 12138-12144.

[32] M.A. Huertos, J. Pérez, L. Riera, A. Menéndez-Velázquez, From N-Alkylimidazole Ligands at a Rhenium

Center: Ring Opening or Formation of NHC Complexes, Journal of the American Chemical Society 130(41)

(2008) 13530-13531.

[33] S. Winston, N. Stylianides, A.A. Tulloch, J.A. Wright, A.A. Danopoulos, Picoline and pyridine

functionalised chelate N-heterocyclic carbene complexes of nickel: synthesis and structural studies, Polyhedron

23(17) (2004) 2813-2820.

[34] D. Handley, P. B Hitchcock, G. Leigh, Triangulo-pentahalotrimetal complexes of nickel(II) and cobalt(II)

with N,N,N′,N′,N-tetramethylethane-1,2-diamine and related compounds, Inorganica Chimica Acta 314(1)

(2001) 1-13.

[35] S. Hameury, P. de Frémont, P.-A. R. Breuil, H. Olivier-Bourbigou, P. Braunstein, Synthesis and

characterization of oxygen-functionalised-NHC silver(i) complexes and NHC transmetallation to nickel(ii),

Dalton Transactions 43(12) (2014) 4700-4710.

[36] S. Hameury, P. de Frémont, P.-A.R. Breuil, H. Olivier-Bourbigou, P. Braunstein, Synthesis and

Characterization of Palladium(II) and Nickel(II) Alcoholate-Functionalized NHC Complexes and of Mixed

Nickel(II)–Lithium(I) Complexes, Inorganic chemistry 53(10) (2014) 5189-5200.

[37] D.C. Oliveira, A. Tomasz, H. de Lencastre, Secrets of success of a human pathogen: molecular evolution

of pandemic clones of meticillin-resistant Staphylococcus aureus, The Lancet Infectious Diseases 2(3) (2002)

180-189.

[38] M.I. Crisóstomo, H. Westh, A. Tomasz, M. Chung, D.C. Oliveira, H. de Lencastre, The evolution of

methicillin resistance in Staphylococcus aureus: Similarity of genetic backgrounds in historically early

methicillin-susceptible and -resistant isolates and contemporary epidemic clones, Proceedings of the National

Academy of Sciences of the United States of America 98(17) (2001) 9865-9870.

[39] F. Gümüş, I. Pamuk, T. Özden, S. Yıldız, N. Diril, E. Öksüzoǧlu, S. Gür, A. Özkul, Synthesis,

characterization and in vitro cytotoxic, mutagenic and antimicrobial activity of platinum (II) complexes with

substituted benzimidazole ligands, Journal of inorganic biochemistry 94(3) (2003) 255-262.

[40] G. Onar, M.O. Karataş, S. Balcıoğlu, T.T. Tok, C. Gürses, I. Kılıç-Cıkla, N. Özdemir, B. Ateş, B. Alıcı,

Benzotriazole functionalized N-heterocyclic carbene–silver (I) complexes: Synthesis, cytotoxicity,

antimicrobial, DNA binding, and molecular docking studies, Polyhedron 153 (2018) 31-40.

[41] M.O. Karatas, B. Olgundeniz, S. Gunal, I. Ozdemir, B. Alici, E. Cetinkaya, Synthesis, characterization and

antimicrobial activities of novel silver(I) complexes with coumarin substituted N-heterocyclic carbene ligands,

Bioorg Med Chem 24(4) (2016) 643-50.

ACCEPTED MANUSCRIPT

[42] C. Schmidt, B. Karge, R. Misgeld, A. Prokop, R. Franke, M. Brönstrup, I. Ott, Gold(I) NHC Complexes:

Antiproliferative Activity, Cellular Uptake, Inhibition of Mammalian and Bacterial Thioredoxin Reductases,

and Gram-Positive Directed Antibacterial Effects, Chemistry – A European Journal 23(8) (2017) 1869-1880.

[43] A. Mumtaz, A. Saeed, N. Fatima, M. Dawood, H. Rafique, J. Iqbal, Imidazole and its derivatives as

potential candidates for drug development, Bangladesh Journal of Pharmacology 11(4) (2016) 756.

[44] D. Demberelnyamba, K.-S. Kim, S. Choi, S.-Y. Park, H. Lee, C.-J. Kim, I.-D. Yoo, Synthesis and

antimicrobial properties of imidazolium and pyrrolidinonium salts, Bioorganic & Medicinal Chemistry 12(5)

(2004) 853-857.

[45] S.N. Riduan, Y. Zhang, Imidazolium salts and their polymeric materials for biological applications,

Chemical Society Reviews 42(23) (2013) 9055-9070.

[46] P. Borowiecki, M. Milner-Krawczyk, D. Brzezińska, M. Wielechowska, J. Plenkiewicz, Synthesis and

antimicrobial activity of imidazolium and triazolium chiral ionic liquids, European Journal of Organic

Chemistry 2013(4) (2013) 712-720.

[47] J. Gravel, A.R. Schmitzer, Imidazolium and benzimidazolium-containing compounds: from simple toxic

salts to highly bioactive drugs, Org Biomol Chem (2017).

[48] C.R. Birnie, D. Malamud, R.L. Schnaare, Antimicrobial Evaluation of N-Alkyl Betaines and N-Alkyl-N,N-

Dimethylamine Oxides with Variations in Chain Length, Antimicrobial Agents and Chemotherapy 44(9) (2000)

2514-2517.

[49] A. Kascatan-Nebioglu, A. Melaiye, K. Hindi, S. Durmus, M.J. Panzner, L.A. Hogue, R.J. Mallett, C.E.

Hovis, M. Coughenour, S.D. Crosby, A. Milsted, D.L. Ely, C.A. Tessier, C.L. Cannon, W.J. Youngs, Synthesis

from caffeine of a mixed N-heterocyclic carbene−silver acetate complex active against resistant respiratory

pathogens, Journal of Medicinal Chemistry 49(23) (2006) 6811-6818.

[50] C. Burgos, E. Ana, L. Tamayo, R. Torrellas-Hidalgo, Synthesis, characterization and antimicrobial activity

of a Pd (II) complex with a 1, 3-diphenylpyrazole-4-carboxaldehyde thiosemicarbazone ligand, Revista UDCA

Actualidad & Divulgación Científica 17(2) (2014) 477-486.

[51] A.T. Çolak, F. Çolak, O.Z. Yeşilel, E. Şahin, Synthesis, spectroscopic, thermal, crystal characterization and

biological activity of [Ni(phen)3][Ni(dipic)2]2.17H2O (H2dipic:pyridine-2,6-dicarboxylic acid, phen: 1,10-

phenanthroline), Journal of the Iranian Chemical Society 7(2) (2010) 384-393.

[52] A.M. Mohamed, R.A. Palmer, A.A. Soayed, H.M. Refaat, D.E. Basher, The Ni (II) Complex of 2-

Hydroxy-Pyridine-N-Oxide 2-Isothionate: Synthesis, Characterization, Biological Studies, and X-ray Crystal

Structures using (1) Cu Kα Data and (2) Synchrotron Data, J Mater Sci Nanotechnol 2(1) (2014) 101.

[53] R.R. Khojasteh, S.J. Matin, Synthesis, characterization, and antibacterial activities of some metal

complexes of heptadentate schiff base ligand derived from acetylacetone, Russian Journal of Applied Chemistry

88(6) (2015) 921-925.

[54] J. Barretina, G. Caponigro, N. Stransky, K. Venkatesan, A.A. Margolin, S. Kim, C.J. Wilson, J. Lehár, G.V.

Kryukov, D. Sonkin, A. Reddy, M. Liu, L. Murray, M.F. Berger, J.E. Monahan, P. Morais, J. Meltzer, A.

Korejwa, J. Jané-Valbuena, F.A. Mapa, J. Thibault, E. Bric-Furlong, P. Raman, A. Shipway, I.H. Engels, J.

ACCEPTED MANUSCRIPT

Cheng, G.K. Yu, J. Yu, P. Aspesi, M. de Silva, K. Jagtap, M.D. Jones, L. Wang, C. Hatton, E. Palescandolo, S.

Gupta, S. Mahan, C. Sougnez, R.C. Onofrio, T. Liefeld, L. MacConaill, W. Winckler, M. Reich, N. Li, J.P.

Mesirov, S.B. Gabriel, G. Getz, K. Ardlie, V. Chan, V.E. Myer, B.L. Weber, J. Porter, M. Warmuth, P. Finan,

J.L. Harris, M. Meyerson, T.R. Golub, M.P. Morrissey, W.R. Sellers, R. Schlegel, L.A. Garraway, The Cancer

Cell Line Encyclopedia enables predictive modelling of anticancer drug sensitivity, Nature 483 (2012) 603.

[55] J.I. Johnson, S. Decker, D. Zaharevitz, L.V. Rubinstein, J.M. Venditti, S. Schepartz, S. Kalyandrug, M.

Christian, S. Arbuck, M. Hollingshead, E.A. Sausville, Relationships between drug activity in NCI preclinical

in vitro and in vivo models and early clinical trials, British Journal Of Cancer 84 (2001) 1424.

[56] K.M. Nicholson, R.M. Phillips, S.D. Shnyder, M.C. Bibby, In vitro and in vivo activity of LS 4477 and LS

4559, novel analogues of the tubulin binder estramustine, European Journal of Cancer 38(1) (2002) 194-204.

[57] J. Zhou, K. Gupta, S. Aggarwal, R. Aneja, R. Chandra, D. Panda, H.C. Joshi, Brominated derivatives of

noscapine are potent microtubule-interfering agents that perturb mitosis and inhibit cell proliferation, Molecular

Pharmacology 63(4) (2003) 799-807.

[58] A.S. El-Tabl, M. Mohamed Abd El-Waheed, M.A. Wahba, N. Abd El-Halim Abou El-Fadl, Synthesis,

characterization, and anticancer activity of new metal complexes derived from 2-hydroxy-3-(hydroxyimino)-4-

oxopentan-2-ylidene)benzohydrazide, Bioinorganic Chemistry and Applications 2015 (2015) 126023.

[59] T. Moller, P. Wonneberger, N. Kretzschmar, E. Hey-Hawkins, P-chiral phosphorus heterocycles: a

straightforward synthesis, Chemical Communications 50(44) (2014) 5826-5828.

[60] G.L. Patrick, An introduction to medicinal chemistry, 5th ed., Oxford University Press, New York, NY,

2013.

[61] G. Dahm, C. Bailly, L. Karmazin, S. Bellemin-Laponnaz, Synthesis, structural characterization and in vitro

anti-cancer activity of functionalized N-heterocyclic carbene platinum and palladium complexes, Journal of

Organometallic Chemistry 794 (2015) 115-124.

[62] N. Chekkat, G. Dahm, E. Chardon, M. Wantz, J. Sitz, M. Decossas, O. Lambert, B. Frisch, R. Rubbiani, G.

Gasser, G. Guichard, S. Fournel, S. Bellemin-Laponnaz, N-Heterocyclic Carbene–Polyethylenimine Platinum

Complexes with Potent in Vitro and in Vivo Antitumor Efficacy, Bioconjugate Chemistry 27(8) (2016) 1942-

1948.

[63] J.-F. Betzer, F. Nuter, M. Chtchigrovsky, F. Hamon, G. Kellermann, S. Ali, M.-A. Calméjane, S. Roque, J.

Poupon, T. Cresteil, M.-P. Teulade-Fichou, A. Marinetti, S. Bombard, Linking of Antitumor trans NHC-Pt(II)

Complexes to G-Quadruplex DNA Ligand for Telomeric Targeting, Bioconjugate Chemistry 27(6) (2016)

1456-1470.

[64] T. Aiyelabola, E. Akinkunmi, I. Ojo, E. Obuotor, C. Adebajo, D. Isabirye, Syntheses, Characterization,

Resolution, and Biological Studies of Coordination Compounds of Aspartic Acid and Glycine, Bioinorganic

Chemistry and Applications 2017 (2017) 15.

[65] R.A. Haque, M.Z. Ghdhayeb, S. Budagumpi, M.B. Khadeer Ahamed, A.M.S. Abdul Majid, Synthesis,

crystal structures, and in vitro anticancer properties of new N-heterocyclic carbene (NHC) silver(i)- and

gold(i)/(iii)-complexes: a rare example of silver(i)–NHC complex involved in redox transmetallation, RSC Adv.

6(65) (2016) 60407-60421.

ACCEPTED MANUSCRIPT

[66] W. Mahavorasirikul, V. Viyanant, W. Chaijaroenkul, A. Itharat, K. Na-Bangchang, Cytotoxic activity of

Thai medicinal plants against human cholangiocarcinoma, laryngeal and hepatocarcinoma cells in vitro, BMC

Complementary and Alternative Medicine 10(1) (2010) 55.

[67] O. Peña-Morán, M. Villarreal, L. Álvarez-Berber, A. Meneses-Acosta, V. Rodríguez-López, Cytotoxicity,

Post-Treatment Recovery, and Selectivity Analysis of Naturally Occurring Podophyllotoxins from Bursera

fagaroides var. fagaroides on Breast Cancer Cell Lines, Molecules 21(8) (2016) 1013.

[68] S. Flis, J. Spławiński, Inhibitory Effects of 5-Fluorouracil and Oxaliplatin on Human Colorectal Cancer

Cell Survival Are Synergistically Enhanced by Sulindac Sulfide, Anticancer Research 29(1) (2009) 435-441.

[69] M.L. Henriksson, S. Edin, A.M. Dahlin, P.-A. Oldenborg, Å. Öberg, B. Van Guelpen, J. Rutegård, R.

Stenling, R. Palmqvist, Colorectal Cancer Cells Activate Adjacent Fibroblasts Resulting in FGF1/FGFR3

Signaling and Increased Invasion, The American Journal of Pathology 178(3) (2011) 1387-1394.

[70] R.E. Cowley, R.P. Bontchev, E.N. Duesler, J.M. Smith, Removing the sting from the tail: Reversible

protonation of scorpionate ligands in cobalt (II) tris (carbene) borate complexes, Inorganic chemistry 45(24)

(2006) 9771-9779.

[71] J.X. McDermott, J.F. White, G.M. Whitesides, Thermal decomposition of bis (phosphine) platinum (II)

metallocycles, Journal of the American Chemical Society 98(21) (1976) 6521-6528.

[72] L. Rout, S. Jammi, T. Punniyamurthy, Novel CuO nanoparticle catalyzed C− N cross coupling of amines

with iodobenzene, Organic letters 9(17) (2007) 3397-3399.

[73] CLSI, Methods for dilution antimicrobial susceptability test for bacteria that grow anaerobically: Approved

standard - Ninth Edition, CLSI Document M07-A9 Clinical and Laboratory Institute (2012) Wayne,

Pennsylvania.

[74] T.L. Riss, R.A. Moravec, A.L. Niles, H.A. Benink, T.J. Worzella, L. Minor, Cell Viability Assays, in: G.S.

Sittampalam, N. Gal-Edd, M. Arkin, D. Auld, C. Austin, B. Bejcek, M. Glicksman, J. Inglese, V. Lemmon, Z.

Li, J. McGee, O. McManus, L. Minor, A. Napper, T. Riss, O.J. Trask, J. Weidner (Eds.), Assay Guidance

Manual, Bethesda (MD), 2004.

ACCEPTED MANUSCRIPT

List of Schemes

ii

i

*

O

OH

Cl

N

3

2

1

iii

Cl^-

*

N

4

R

iv, v

vi

R = Me (a), Ph (b), tBu (c)

*

N

Pt

N

Ni

Cl

R

R = Me (a), Ph (b), tBu (c)

5

6

Scheme 1. Synthesis pathway of racemic Pt and Ni NHC complexes. Reagents and conditions: (i) NaBH₄,

EtOH, 1hr, 90°C, 15 mins, 1:1 EtOAc/H₂O; (ii) methanesulfonyl chloride, Et₃N, DCM, overnight, rt, 1:4

EtOAc/hexane; (iii) 1-methylimidazole (a)/ 1-phenylimidazole (b)/ 1-tert-butylimidazole (c), CH₃CN, reflux, 48

hrs; (iv) Ag₂O, CH₂Cl₂, rt, overnight, in dark; (v) Pt(cod)Cl₂, rt, 2 weeks, in dark (vi) NiCl₂, K₂CO₃, CH₃CN,

reflux, 24hr, 1:1 CH₂Cl₂/MeOH.

Scheme 2. Structure of dibromo complex (±)-7 and diiodo complex (±)-8.

ACCEPTED MANUSCRIPT

Scheme 3. Overall schematic representation for synthesis and characterisation of Ni NHC complexes in this

study.

ACCEPTED MANUSCRIPT

List of Figures

Figure 1. Molecular structure of racemic Pt NHC complex (±)-5a with thermal ellipsoids at 50% probability.

Hydrogen atoms are omitted for clarity.

Figure 2. Molecular structure of unexpected nickel complex 9 with thermal ellipsoids at 50% probability.

Hydrogen atoms are omitted for clarity.

ACCEPTED MANUSCRIPT

Figure 3. Molecular structure of unexpected nickelate complex 10 with thermal ellipsoids at 50% probability.

Hydrogen atoms are omitted for clarity.

ACCEPTED MANUSCRIPT

List of Tables

Table 1. Selected bond lengths (Å) and angles (°) for racemic Pt NHC complex (±)-5a.

Pt(1)-Cl(1)

Pt(1)-Cl(2)

Pt(1)-N(1)

Pt(1)-C(13)

N(1)-C(8)

N(1)-C(12)

2.301(4)

2.359(4)

2.02(1)

1.95(1)

1.36(2)

1.33(2)

91.2(1)

92.4(4)

90.8(3)

85.8(5)

136(1)

N(2)-C(7)

N(2)-C(13)

N(2)-C(15)

N(3)-C(13)

N(3)-C(14)

N(3)-C(16)

1.47(2)

1.37(2)

1.41(2)

1.35(2)

1.40(2)

1.44(2)

176.1(4)

176.8(3)

119.9(9)

120.1(9)

120.0(9)

Bond length (Å)

Bond angle (°)

Cl(1)-Pt(1)-Cl(2)

Cl(1)-Pt(1)-C(13)

Cl(2)-Pt(1)-N(1)

C(13)-Pt(1)-N(1)

Pt(1)-C(13)-N(3)

Cl(2)-Pt(1)-C(13)

Cl(1)-Pt(1)-N(1)

Pt(1)-C(13)-N(2)

Pt(1)-N(1)-C(8)

Pt(1)-N(1)-C(12)

Table 2. Selected bond lengths (Å) and angles (°) for unexpected nickel complex 9.

Ni(1)-Cl(1)

Ni(1)-O(1)

2.4502

2.1

Ni(1)-Cl(1)

Ni(1)-O(1)

2.4502

2.1

Ni(1)-N(2)

2.076

Ni(1)-N(2)

2.076

O(1)-H(1)

O(1)-C(5)

N(2)-C(4)

N(2)-C(3)

N(1)-C(4)

N(1)-C(2)

N(1)-C(1)

C(3)-C(2)

N(2)-Ni(1)-Cl(1)

N(2)-Ni(1)-O(1)

N(2)-Ni(1)-Cl(1)

N(2)-Ni(1)-O(1)

O(7)-Ni(1)-N(1)

O(2)-Ni(1)-N(1)

Cl(2)-Ni(1)-N(1)

N(7)-Ni(1)-Cl(1)

0.85(2)

1.418(3)

1.315(4)

1.373(3)

1.344(3)

1.359(4)

1.467(5)

1.350(4)

90.72

90.79

89.28

89.21

90.79

O(1)-H(1)

O(1)-C(5)

N(2)-C(4)

N(2)-C(3)

N(1)-C(4)

N(1)-C(2)

N(1)-C(1)

C(3)-C(2)

Cl(5)-Ni(1)-O(1)

Cl(4)-Ni(1)-O(1)

Cl(5)-Ni(1)-O(1)

Cl(4)-Ni(1)-O(1)

Cl(1)-Ni(1)-Cl(1)

O(1)-Ni(1)-O(1)

N(1)-Ni(1)-N(1)

0.85(2)

1.418(3)

1.315(4)

1.373(3)

1.344(3)

1.359(4)

1.467(5)

1.350(4)

89.59

90.41

89.59

90.41

180

Bond length (Å)

Bond angle (°)

89.21

89.28

90.72

180

ACCEPTED MANUSCRIPT

Table 3. Selected bond lengths (Å) and angles (°) for unexpected nickelate complex 10.

Ni(1)-Cl(2)

Ni(1)-Cl(1)

N(3)-C(13)

N(3)-C(15)

N(3)-C(16)

N(1)-C(8)

C(1)-C(6)

C(1)-C(7)

C(1)-C(2)

C(8)-C(7)

2.268(2)

2.253(2)

1.342(8)

1.359(8)

1.496(6)

1.315(7)

1.382(7)

1.517(6)

1.39(1)

Ni(1)-Cl(3)

Ni(1)-Cl(4)

N(2)-C(13)

N(2)-C(7)

N(2)-C(14)

2.238(2)

2.253(2)

1.323(6)

1.488(7)

1.365(9)

1.34(1)

1.52(1)

1.53(1)

1.52(1)

1.38(2)

N(1)-C(12)

C(16)-C(17)

C(16)-C(18)

C(16)-C(19)

C(9)-C(10)

Bond length (Å)

1.508(9)

1.41(1)

C(8)-C(9)

C(5)-C(4)

1.37(1)

C(6)-C(5)

1.380(7)

1.35(1)

1.37(2)

116.54(7)

106.88(7)

107.64(7)

C(2)-C(3)

C(10)-C(11)

C(4)-C(3)

Cl(1)-Ni(1)-Cl(2)

Cl(1)-Ni(1)-Cl(3)

Cl(1)-Ni(1)-Cl(2)

1.375(9)

1.33(1)

1.38(1)

105.02(7)

112.82(7)

108.12(7)

C(15)-C(14)

C(12)-C(11)

Cl(1)-Ni(1)-Cl(2)

Cl(1)-Ni(1)-Cl(3)

Cl(1)-Ni(1)-Cl(4)

Bond angle (°)

Article Doi

Synthesis, characterization, in vitro antimicrobial and anticancer studies of new platinum N-heterocyclic carbene (NHC) complexes and unexpected nickel complexes

DOI: 10.1016/j.jorganchem.2019.07.019

Source and publish data:

Authors:

Article abstract of DOI:10.1016/j.jorganchem.2019.07.019

Full text of DOI:10.1016/j.jorganchem.2019.07.019

Products guided by the article

R&D Labs maybe for 1438252-69-7

Relevant to this article

Hot Product
