Synthesis and pharmacological investigation of new N-hydroxyalkyl-

2-aminophenothiazines exhibiting marked MDR inhibitory effect

Daniella Takács ^a, Orsolya Egyed ^a, László Drahos ^a, Pál Szabó ^b, Katalin Jemnitz ^b, Mónika Szabó ^b,

Zsuzsa Veres ^b, Júlia Visy ^b, József Molnár ^c, Zsuzsanna Riedl ^a, György Hajós ^a,

⇑

^aInstitute of Organic Chemistry, Research Centre for Natural Sciences, Hungarian Academy of Sciences, Pusztaszeri út 59, H-1025 Budapest, Hungary

^bInstitute of Molecular Pharmacology, Research Centre for Natural Sciences, Hungarian Academy of Sciences, Pusztaszeri út 59, H-1025 Budapest, Hungary

^cDepartment of Medical Microbiology, University of Szeged, Dóm tér 10, H-6720 Szeged, Hungary

a r t i c l e i n f o

a b s t r a c t

Article history:

Novel N-hydroxyalkyl-2-aminophenothiazines implying a tetrazole moiety at the alkyl chain have been

synthesized by hydroboration–oxidation of dienes followed by Buchwald–Hartwig cross-coupling reac-

tion. Also, some sulfoxide and sulfone derivatives have been prepared by selective oxidations. MDR inhi-

bition studies on rat hepatocyte cell culture revealed that some derivatives exhibit marked biological

efﬁcacy exceeding that of the standard verapamil (e.g., 3h, 4h, 16). Selected derivatives were subjected

to chemical resolution to provide both enantiomers which were shown of similar activity on P-gp inter-

action measurements. The new compounds exhibited no toxicity.

Received 24 January 2013

Revised 11 April 2013

Accepted 12 April 2013

Available online xxxx

Keywords:

N-Hydroxyalkyl-2-aminophenothiazines

Sulfoxide and sulfone derivatives

MDR inhibition

Ó 2013 Published by Elsevier Ltd.

Buchwald–Hartwig cross-coupling reaction

Resolution of racemate

1. Introduction

displayed unwanted pharmacokinetic interactions. Third-genera-

tion inhibitors can speciﬁcally and potently inhibit P-gp function,

Multidrug resistance (MDR) is a major clinical obstacle in the

treatment of several cancers including hematological malignancies

and solid tumors. The ATP-binding cassette transporter P-glyco-

protein (P-gp, ABCB1), is one molecule that is involved in drug

resistance.¹Cancer cells can escape from the toxic effect of drugs

mainly due to the highly expressed membrane transporters that

pump drugs out of cells.²To overcome P-gp mediated MDR, mod-

ulators, so called P-gp inhibitors, can be used to block efﬂux pump

activity. P-gp inhibitors can be used in combination with antican-

cer drugs to enhance the effectiveness of chemotherapy against

resistant tumor cells. On the other hand, P-gp is presented in nor-

mal tissues, thus non-selective blockage of P-gp can cause unde-

sired side effects. Therefore, it is important to deliver P-gp

inhibitor only to the tumor cells (along with anticancer drug)

and limit its distribution in the body. Much effort has been devoted

to developing P-gp inhibitors to modulate MDR. However, none of

the inhibitors on the market have been successful. Three genera-

tions of inhibitors have been developed in order to reverse MDR.

First-generation inhibitors including verapamil, and cyclosporine

several of them have been tested in controlled clinical trials, but

no satisfactory results have been obtained.⁴For almost three dec-

ades, research has been conducted to overcome MDR through

pharmacological inhibition of ABC transporters with limited clini-

cal success. Therefore it is still urgent to develop some new agents

to overcome MDR.⁵

During the recent years, investigation of inhibition of multi-

drug resistance (MDR) attracted an increased interest world-wide.⁶

Among the effective compounds that proved to inhibit resistance,

some phenothiazine derivatives were found of high activity.⁷With

some of the most important such compounds involving chloro-

promazine,⁸triﬂuoperazine,⁹thioridazine,¹⁰two common struc-

tural features of these compounds should be pointed out: (i)

presence of an alkyl chain attached to the nitrogen atom of the

phenothiazine ring; (ii) presence of an amino moiety in most of

the derivatives.

Earlier, we described a novel synthetic approach to N-dienyl-

phenothiazines¹¹and, quite recently, reduction of these com-

pounds to N-butyl and N-hydroxybutyl derivatives¹²has been

reported. Even if the MDR inhibitory efﬁcacy of these new com-

pounds proved to be only moderate, further functionalization of

these derivatives seemed promising in order to discover new po-

tent MDR inhibitors among the newly synthesized phenothiazine

derivatives.

A

were limited by unacceptable toxicity.³Second-generation

agents such as dexverapamil, PSC833 had better tolerability but

⇑

Corresponding author. Tel.: +36 4381110; fax: +36 4381145.

E-mail address: hajos.gyorgy@ttk.mta.hu (G. Hajós).

0968-0896/$ - see front matter Ó 2013 Published by Elsevier Ltd.

http://dx.doi.org/10.1016/j.bmc.2013.04.034

Please cite this article in press as: Takács, D.; et al. Bioorg. Med. Chem. (2013), http://dx.doi.org/10.1016/j.bmc.2013.04.034

2

D. Takács et al. / Bioorg. Med. Chem. xxx (2013) xxx–xxx

route "A"

OCH₃

3''

NR¹R²

Cl

4''

4a''

N

2''

a

b, c

N

1''

5''

S

OH

S

10a''

0-49%

5a''

45-86%

10''

N

6''

7''

2

4

N

9a''

1

3

N

9''

1'

2'

8''

1

2

3

3'

4'

6'

5'

a) 2 equiv. HNR¹R², 5-7.5 mol% Pd-catalyst,10-15 mol% XPhos, 2 equiv. base

abs. toluene, 0.5-24 h, 80-110 °C, Ar

OCH₃

N

b) BH₃xMe₂S, abs. THF, 0°C rt

c) MeOH, 10% NaOH, 30% H₂O₂, rt, 24 h

O

S

OH

N

4f

OCH₃

Scheme 1. Synthetic route ‘A’ to N-(2-hydroxybutyl)-2-aminophenothiazines (3).

benzylation). Also, an alternative route ‘C’ was applied by reacting

5 with tert-butyldiphenylchlorosilane (^tBuPh₂SiCl) to give the

2. Results and discussion

2.1. Synthesis

In this paper we report on a well executable synthetic protocol

to N-tetrazolylbutylphenothiazines bearing various amino func-

tions in position 2 of the tricyclic ring as well as on biological eval-

uation of the new derivatives.

Table 1

Used primary/secondary amines and acid amides in the synthesis of N-(2-hydrox-

ybutyl)-2-aminophenothiazines (3) via route A (Scheme 1)

Compound 3

HNR¹R²

Yield %

Two of our recent ﬁndings provided proper starting point in or-

der to perform the above planned transformations: (a) the success-

ful reduction of phenothiazinyldienes to the related butyl

compounds by borane¹²and, (b) the convenient introduction of

amino groups into the desired position of phenothiazine by Buch-

wald–Hartwig cross-coupling reaction of the commercially avail-

able 2-chlorophenothiazine.^13a

N

a

—

NH₂

O

N

b

c

26

30

NH₂

By utilization of these structural conversions, the synthetic

strategy route ‘A’ starting from the easily accessible dienylpheno-

thiazine (1) shown in Scheme 1 seemed straightforward, that is,

Buchwald–Hartwig amination to 2 followed hydroboration–oxida-

tion to give the saturated monohydroxy product (3). As pharmaco-

logical measurements indicated that, concerning the MDR

modulatory activity, those compounds bearing a 4-methoxyphenyl

group on the N2 atom of the tetrazole ring are superior and, thus,

all further chemical transformations have been carried out with

such methoxy compounds (cf. Table 2 later in this publication).

Scheme 1 reveals these transformations proceeded in medium

to low yield only and, in some cases, decomposition was experi-

enced and no product could be isolated (Table 1). It is interesting

to note that in one case: with the diethylamino derivative 2f, the

expected product 3f was found as a minor component of the reac-

tion mixture, whereas a sulfoxide (4f) was formed in majority

(67%). A speciﬁc NMR spectral feature of this product is appearance

of two sets of signals due to the presence of two chiral centers (i.e.,

the secondary alcohol and sulfoxide moeties).

CH₃

NH₂

H

d

46

NH₂

e

f

—

NH

23

H

N

g

49

NH

O

h

i

33

49

44

—

N

O

NH

j

NH

k

l

—

The above ﬁndings prompted us to apply another synthetic

strategy and, thus, route ‘B’ was decided next (Scheme 2). This

route involved the hydroboration–oxidation of the diene (1) to

the hydroxybutyl derivative (5) as described in our recent publica-

tion,¹²followed by protection of the OH group (formation of 6 by

H

NH₂

O

m

H₃C

NH₂
