Multi-component one-pot reaction of aromatic carbonyl compounds, tosylhydrazide, and arylboronic acids

Article abstract of DOI:10.3390/molecules22122168

In this paper, we developed a new method using 4-bromoacetophenone as the starting material, with tosylhydrazide and two arylboronic acids using Barluenga and Suzuki couplings in a four-component one-pot reaction to afford the target product 4-benzyl-1,1-biphenyls. This system that we have developed enables the use of easily accessible starting materials and can be employed on a wide variety of substrates with good functional group tolerance. In particular, this protocol can be applied to the synthesis of 4-(1-([1,1-biphenyl]-4-yl)ethyl)pyridine derivatives, a class of potential analogs of CPY17 inhibitors of prostate cancer.

Full text of DOI:10.3390/molecules22122168

molecules
Article
Multi-Component One-Pot Reaction of Aromatic
Carbonyl Compounds, Tosylhydrazide, and
Arylboronic Acids
Ningning Gu, Yu Wei, Ping Liu *, Yan Liu * and Bin Dai
Key Laboratory for Green Processing of Chemical Engineering of Xinjiang Bingtuan,
School of Chemistry and Chemical Engineering, Shihezi University, Shihezi 832003, China;
tenggeli116@126.com (N.G.); yuweichem@126.com (Y.W.); db_tea@shzu.edu.cn (B.D.)
* Correspondence: liuping1979112@aliyun.com (P.L.); liuyan1979810@aliyun.com (Y.L.);
Tel.: +86-0993-2057213 (P.L.)
Received: 26 November 2017; Accepted: 6 December 2017; Published: 7 December 2017
Abstract: In this paper, we developed a new method using 4-bromoacetophenone as the starting
material, with tosylhydrazide and two arylboronic acids using Barluenga and Suzuki couplings in a
four-component one-pot reaction to afford the target product 4-benzyl-1,10-biphenyls. This system
that we have developed enables the use of easily accessible starting materials and can be employed
on a wide variety of substrates with good functional group tolerance. In particular, this protocol can
0
be applied to the synthesis of 4-(1-([1,1 -biphenyl]-4-yl)ethyl)pyridine derivatives, a class of potential
analogs of CPY17 inhibitors of prostate cancer.
Keywords: one-pot reaction; tosylhydrazide; arylboronic acid; 4-benzyl-1,10-biphenyl derivatives
1. Introduction
4-Benzyl-1,10-biphenyl derivatives are important structural units in numerous thermal recording
materials, electrophotographic photoreceptors and biologically active molecules, including a number
of anticancer agents [
for the synthesis of such compounds, which may be catalyzed by solid acid catalysts [12
Particularly, patents have been reported on the synthesis of benzyl-1,10-biphenyl derivatives starting
from biphenyl and benzyl chloride using catalysts such as montmorillonite and zeolites [15 16].
1–
11]. Typically, the Friedel-Crafts reaction (Scheme 1, Method 1) is employed
–
14].
,
Previously, the kinetics of the reaction between biphenyl and benzyl chloride over dealuminated
HY zeolites has been reported [17]. In addition, the Suzuki–Miyaura reaction, which involves the
coupling of an arylboronic acid derivative and an organohalide, proved to be an extremely useful
synthetic tool for the construction of a biphenyl scaffold. Among others, some convenient features
involved in the use of arylboronic acid precursors in these reactions are as follows: arylboronic acid
derivatives demonstrate air and moisture stability, relatively low toxicity and high compatibility to
various functional groups [18–
21]. However, the synthesis of 4-benzyl-1,10-biphenyl derivatives by
the Suzuki-Miyaura reaction is more challenging (Scheme 1, Method 2). More often, this protocol
suffers from poor selectivity in the first step, resulting in a mixture of mono- and bis-coupled
products, thereby necessitating the purification of the intermediate. Chemoselectivity is crucial
if sequential cross-coupling reactions are to be effective. It may be achieved using precursors
containing activating groups of different reactivities, such as 1-bromo-4-(halomethyl)benzene [22,23].
Multicomponent reactions (MCRs) are ideal synthetic tools for generating complex molecules from
readily available starting materials in a single synthetic operation; hence, they minimize waste
generation, rendering green transformations [24–27]. The separation and purification of this step
raises the cost and decrease the efficiency of this synthesis method. Therefore, it is desirable to develop
a more efficient synthetic path.
Molecules 2017, 22, 2168; doi:10.3390/molecules22122168
www.mdpi.com/journal/molecules

Molecules 2017, 22, 2168
2 of 13
Recently, N-tosylhydrazones as important intermediates have attracted extensive attention
because of their various useful applications in organic synthesis [28 35]. Significant progress has been
achieved in sequential transformations of N-tosylhydrazones through auto tandem catalysis [36 38].
–
–
In 2010, Wang et al. developed MCRs of N-tosylhydrazones with an arylhalide and a terminal
alkyne [39]. In 2013, Hamze et al. reported a three-component one-pot reaction of hydrazones,
dihaloarenes and amines [40,41]. On the basis of our previous work [42–45], we herein report a new
multi-component reaction of aromatic carbonyl compounds, tosylhydrazide and aryl boronic acids for
the synthesis of 4-benzyl-1,10-biphenyl derivatives (Scheme 1).
0
Scheme 1. Synthetic methods for 4-benzyl-1,1 -biphenyl derivatives.
2. Results and Discussion
First, from the structural analysis of the 4-(1-phenylethyl)-1,10-biphenyl skeleton (Figure 1),
Csp2–Csp2 bond and Csp2–Csp3 bonds were constructed for building such a molecular structure.
The Csp2–Csp3 bond is well known to be obtained by the reductive coupling reaction of aryl hydrazone
with an aryl boronic acid, and the Csp2–Csp2 bond is formed by the palladium-catalyzed Suzuki
coupling of aryl halide with an arylboronic acid. One common factor between these two reactions is the
use of a base, but the Suzuki coupling reaction usually requires the involvement of a palladium catalyst.
Hence, if we use the 40-halo-acetophenone as starting reactants, and optimize the reaction conditions,
it is possible to easily achieve access to 4-benzyl-1,10-biphenyl derivatives by a one-pot multi-step
reaction. It is an ideal route to synthesis of the target compound by a simple and efficient way.
R
R'
Csp2-Csp3 bond
Csp2-Csp2 bond
0
Figure 1. Structure of 4-benzyl-1,1 -biphenyl derivatives.
Based on the above considerations, we decided to use cost-effective, readily available 4-bromoacetophenone
as the starting material. N-tosylhydrazones were generated in situ using TsNHNH2, reacted with an
arylboronic acid to afford a 4-bromo-diarylmethane intermediate by reductive coupling, leading to the
formation of a Csp2–Csp3 bond. With treatment using a transition-metal palladium catalyst, without
isolation, the intermediate product was treated with another arylboronic acid by Suzuki coupling to
construct the Csp2–Csp2 bond, ultimately affording 4-benzyl-1,10-biphenyl derivatives (Scheme 2).

Molecules 2017, 22, 2168
3 of 13
Scheme 2. One-pot, multi-step, multi-component reactions of 4-bromoacetophenone, tosylhydrazide,
with two arylboronic acids.
On the basis of their study and our previous work [17], the reaction conditions of the third step
were optimized, namely, the effects of ligand, base and temperature on the Suzuki coupling reaction
were examined. Initially, the coupling reaction of 4-bromoacetophenone, TsNHNH2 and phenylboronic
acid was selected as a model reaction to optimize the reaction conditions. Table 1 summarizes
the results. The use of only Pd(OAc)2 as the catalyst and K2CO3 as the base in 1,4-dioxane at
◦
110 C produced the desired product 3a in only 15% yield (entry 1). The phosphine ligands were
screened for this reaction, and PCy3
coupling product 3a (entry 3). Among the various bases examined, organic bases (Et3N), and
inorganic bases (K3PO4 H2O and NaOH) gave the desired product in moderate yields (63–72%,
·
HBF4 was found to be the most effective one for forming
·
entries 4–6, respectively). Cs2CO3 was not effective, and corresponding product 3a was obtained in a
low yield (entry 7). Gratifyingly, when the amounts of tosylhydrazide and phenylboronic acid were
increased, the yield of the product dramatically increased to 89% (entry 8). In addition, when the
amount of Pd(OAc)2 was increased to 2 mol %, the yield of product did not improve significantly
(entry 9). When the temperature of the Suzuki coupling reaction was decreased to 80 ◦C, the product
was isolated in only 52% yield (entry 10). Hence, the combination of 4-bromoacetophenone (0.5 mmol),
tosylhydrazide (1.5 equiv.), phenylboronic acid (3.0 equiv.), Pd(OAc)2 (1 mol %), PCy3 HBF4 (4 mol %)
·
and K2CO3 (3.0 equiv.) at T1 = 80 ◦C (t1 = 2 h), T2 = 110 ◦C (t2 = 5 h), and T3 = 110 ◦C (t3 = 12 h) in
1,4-dioxane (5 mL) were found to be the most suitable reaction conditions.
Table 1. Optimization of one-pot, multi-step reaction conditions a.
Yield (%) b
Entry
Pd(OAc)2
Ligand
PhB(OH)2
Base
1
2
3
4
5
1 mol %
1 mol %
1 mol %
1 mol %
1 mol %
1 mol %
1 mol %
1 mol %
2 mol %
1 mol %
-
2.5
2.5
2.5
2.5
2.5
2.5
2.5
3.0
3.0
3.0
K2CO3
K2CO3
K2CO3
Et3N
15
61
78
63
71
72
28
89
90
52
PPh3
PCy3·HBF4
PCy3·HBF4
PCy3·HBF4
PCy3·HBF4
PCy3·HBF4
PCy3·HBF4
PCy3·HBF4
PCy3·HBF4
K3PO4
·
H2O
6
NaOH
Cs2CO3
K2CO3
K2CO3
K2CO3
7
8 c
9
10 d
a
Reaction condition: (i) 0.5 mmol 4-bromoacetophenone 1a, 0.75 mmol tosylhydrazide, 5 mL 1,4-dioxane, 80 ◦C,
2 h; (ii) 0.75 mmol K2CO3, phenylboronic acid (2.5 or 3.0 equivalent), 110 ◦C, 5 h; (iii) 1–2 mol % Pd(OAc)2, 4 mol %
ligand, 0.75 mmol base, 110 ◦C, 12 h. Isolated yield. 0.75 mmol tosylhydrazide was used. The Suzuki coupling
b
c
d
reaction was carried out at 80 ◦C.
With the optimized conditions, we further investigated the substrate scope of this one-pot,
three-step reductive coupling reaction process. As shown in Figure 2, the 4-substituted arylboronic

Molecules 2017, 22, 2168
4 of 13
acid substrates bearing electron-withdrawing or electron-donating groups effectively afforded desired
products 3b 3f in good yields (77–87%). Moreover, m-tolylboronic acid, (3-methoxyphenyl)boronic
acid and (3,4,5-trifluorophenyl)boronic acid were found to produce desired coupling products
3g 3i in 56–94% yields, respectively. Furthermore, the reductive coupling reactions involving
–
–
ortho-substituted arylboronic acids were investigated. Both electronic properties and steric hindrance
of the substrates affect the coupling reaction. For example, the coupling reaction of o-tolylboronic
acid with 4-bromoacetophenone and TsNHNH2 afforded 3j in 92% yield. Naphthalene-2-ylboronic
acid used as the coupling partner afforded 3k in 83% yield. Moreover, 3-bromoacetophenone and
4-bromobenzaldehyde also reacted with m-tolylboronic acid affording target products 3l and 3m in
82% and 74% yields. In contrast, 2-bromobenzaldehyde as the substrate reacted with m-tolylboronic
acid affording the desired product 3n in only 29% yield. Notably, the gram-scale synthesis of 3g was
performed to verify the practical application of this synthesis system. Fortunately, the reaction was
performed using 5 mmol of 4-bromoacetophenone, 7.5 mmol TsNHNH2 and 15 mmol m-tolylboronic
acid, affording product 3g in 88% yield (1.254 g).
Figure 2. One-pot, four-component reactions of 4-bromophenyl aldehydes or ketones, TsNHNH2, with
a
two same arylboronic acids a,b
.
Reaction conditions: (i) 0.5 mmol carbonyl compound, 0.75 mmol
tosylhydrazide, 4 mL 1,4-dioxane, 80 ◦C, 2 h; (ii) 1.5 mmol boronic acid, 1.5 equivalent K2CO3,
110 ◦C, 5 h. (iii) 1 mol % Pd(OAc)2, 4 mol % PCy3 HBF4, 110 ◦C, 12 h. Isolated yield. Reaction
·
b
c
conditions: (i) 5 mmol 4-bromoacetophenone, 7.5 mmol tosylhydrazide, 20 mL dioxane, 80 ◦C, 16 h;
◦
(ii) 3.0 equivalent m-tolylboronic acid, 1.5 equivalent K2CO3, 110 C, 10 h; (iii) 1 mol % Pd(OAc)2,
4 mol % PCy3·HBF4, 110 C, 22 h.
◦

Molecules 2017, 22, 2168
5 of 13
For further ascertaining the applicable scope of this methodology, various arylboronic acids and
carbonyl compounds were examined. As shown in Figure 3, arylboronic acids bearing 4-methoxy,
4-n-propyl, 4-fluoro, 4-trifluoromethyl and 2,4-difluoro groups were transformed into corresponding
products 3o
–3s in 50–80% yields. The substrate containing carbazolyl groups only afforded
products 3t in 32% yield. In addition to 4-bromoacetophenone, 1-(3-bromophenyl)ethan-1-one and
4-bromobenzaldehyde or 2-bromobenzaldehyde also could be applied, affording products 3u–3w in
23–42% yields.
Ar1
(ii)
K2CO3
Ar1B(OH)2
O
(iii) Pd(OAc)2
PCy3•HBF4
Ar2B(OH)2
(i)
TsNHNH2
R
R
Ar2
Br
1,4-dioxane
80 °C, 2 h
110 °C, 5 h 110 °C, 12 h
1
3
CH3
CH3
CH3
CH3
CH3
CH3
C3H7
MeO
F
3o, 80%
CH3
3p, 75%
3q, 68%
CH3
CH3
N
CH3
CH3
F3C
F
F
3r, 50%
3s, 73%
3t, 32%
OMe
H
MeO
CH3
H
CH3
CH3
MeO
CH3
3u, 42%
3v, 23%
3w, 25%
Figure 3. One-pot, four-component reactions of 4-bromophenyl aldehydes or ketones, TsNHNH2, with
a
two different arylboronic acids a,b
.
Reaction conditions: (i) 0.5 mmol carbonyl compound, 0.5 mmol
tosylhydrazide, 4 mL 1,4-dioxane, 80 C, 2 h; (ii) 0.55 mmol Ar1B(OH)2, 1.5 equivalents K2CO3, 110 C,
◦
5 h. (iii) 1 mol % Pd(OAc)2, 4 mol % PCy3
HBF4, 0.75 mmol Ar2B(OH)2, 110 C, 12 h. Isolated yield.
◦
◦
b
·
Next, we intend to apply this one-pot, multi-step reactions for preparing compound 3x, an analog
of CPY17 inhibitors [10]. However, the reaction did not proceed smoothly in one-pot. Hence, we
decided to adopt a step-wise approach for synthesizing 3x. First, 4-bromoacetophenone reacted
with TsNHNH2 to afford the acylhydrazone. Then, it reduced coupling with 4-pyridine boronic
acid afforded the intermediate product 4-(1-(4-bromophenyl)ethyl)pyridine with 41% isolated yield.
Finally, the 4-(1-(4-bromophenyl)ethyl)pyridine was treated with phenylboronic acid, affording
coupling product 3x in 61% yield, but the total yield was only 24.6% (Scheme 3).
Scheme 3. Synthesis of 3x by three-step, four-component reactions.

Molecules 2017, 22, 2168
6 of 13
In response to the challenges above, we also attempted to synthesize 3x by an alternative route
(Scheme 4). Using 4-acetylpyridine as the starting material, first reacted with TsNHNH2, generates
the corresponding hydrazine, then, to reductive coupling with 4-bromophenylboronic acid. In the
third step, the second phenylboronic acid with a palladium catalyst were added to the above reaction
solution, after the Suzuki coupling reaction, the ultimate product 3x formed with 60% yield directly
without the need to isolate any of the reaction intermediates. Similarly, methoxy substituted product
3y was also obtained with 51% yield by this method.
Scheme 4. Synthesis of 3x and 3y by one-pot, three-step, four-component reactions.
3. Materials and Methods
Chemicals were obtained commercially and used as received. NMR spectra were recorded on a
Bruker DPX-400 spectrometer using TMS as the internal standard. EI-Mass spectra were measured on a
LC/Q-TOF MS (Micromass, Wilmslow, UK) (see Supplementary Materials). All products were isolated
by short chromatography on a silica gel (200–300 mesh) column using petroleumether (60–90 ◦C) as
mobile phase, unless otherwise noted. 4-Bromoacetophenone derivatives, and arylboronic acids were
of analytical grade quality, purchased from Adamas-beta Pharmaceuticals, Inc. (Shanghai, China).
3.1. General Procedure for the One-Pot, Four-Component Reactions of 4-Bromoacetophenone, TsNHNH2,
and Two Same Arylboronic Acids
A solution of 4-bromoacetophenone or 4-bromobenzaldehyde derivatives (0.5 mmol) and
◦
tosylhydrazide (0.75 mmol) in 4 mL of 1,4-dioxane was stirred at 80 C for 2 h in a reaction tube.
Second, potassium carbonate (1.5 mmol) and the appropriate arylboronic acid (1.1 mmol) were added
◦
to the reaction mixture. Third, the reaction system was refluxed at 110 C for 5 h with stirring.
Next, 2 mol % Pd(OAc)2, and 4mol % PCy3 HBF4 were added, and the reaction was continued for
·
12 h at 110 ◦C. Then, the reaction was completed, and the crude mixture was allowed to reach room
temperature. Finally, dichloromethane and a saturated solution of NaHCO3 were added, and the
layers were separated. The aqueous phase was extracted three times with dichloromethane, and the
combined organic layers were washed with two portions of a saturated NaHCO3 solution and one
portion of brine, and then dried over anhydrous MgSO4 and filtered. The solvent was removed under
reduced pressure. The products were purified by silica gel chromatography.
3.2. General Procedure for the One-Pot, Four-Step, Four-Component Reactions of 4-Acetylbiphenylderivatives,
TsNHNH2, and Two Different Arylboronic Acids
A solution of 4-bromoacetophenone derivatives (0.5 mmol) and tosylhydrazide (0.75 mmol)
◦
in 4 mL of 1,4-dioxane was stirred at 80 C for 2 h in a reaction tube. Then, potassium carbonate
(1.5 mmol) and the appropriate arylboronic acid (0.6 mmol) were added to the reaction mixture.
◦
The system was refluxed at 110 C for 5 h with stirring. Third, 2 mol % Pd(OAc)2, 4 mol % PCy3
·
HBF4,
and another arylboronic acid (0.75 mmol) were added, and the reaction was continued for 12 h at
110 ◦C. After the reaction was completed, the crude mixture was allowed to reach room temperature.
Finally, dichloromethane and a saturated solution of NaHCO3 were added, and the layers were
separated. The aqueous phase was extracted three times with dichloromethane, and the combined
organic layers were washed with two portions of a saturated NaHCO3 solution and one portion of

Molecules 2017, 22, 2168
7 of 13
brine, and then dried over anhydrous MgSO4 and filtered. The solvent was removed under reduced
pressure. The products were purified by silica gel chromatography.
3.3. General Procedure for the Synthesis of 3x and 3y
A solution of 4-acetylpyridine (0.5 mmol) and tosylhydrazide (0.75 mmol) in 4 mL of 1,4-dioxane
was stirred at 80 ◦C for 3 h in a reaction tube. Then, potassium carbonate (1.5 mmol) and
4-bromophenylboronic acid (0.55 mmol) were added to the reaction mixture. The system was refluxed
◦
at 110 C for 7 h with stirring. Third, 1 mol % Pd(OAc)2, 4 mol % PCy3
·
HBF4, and another arylboronic
◦
acid (0.75 mmol) were added, and the reaction was continued for 10 h at 110 C. After the reaction was
completed, the crude mixture was allowed to reach room temperature. Finally, dichloromethane and a
saturated solution of NaHCO3 were added, and the layers were separated. The aqueous phase was
extracted three times with dichloromethane, and the combined organic layers were washed with two
portions of a saturated NaHCO3 solution and one portion of brine, and then dried over anhydrous
MgSO4 and filtered. The solvent was removed under reduced pressure. The products were purified by
silica gel chromatography.
0
◦
4-(1-Phenylethyl)-1,1 -biphenyl (3a) [46]: White solid (121.43 mg, 94%). 60.8–62.0 C. 1H NMR (400 MHz,
CDCl3) (Figure S1) 7.55–7.48 (m, 4H), 7.39–7.35 (m, 2H), 7.29–7.24 (m, 7H), 7.19–7.14 (m, 1H),
δ
4.16 (q, J = 7.2 Hz, 1H), 1.65 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3) (Figure S2)
δ 146.4, 145.6,
141.1, 139.1, 128.9, 128.6, 128.2, 127.8, 127.3, 127.2, 127.1, 126.3, 44.6(CH), 22.0(CH3). IR (neat, cm−1):
3016, 2960, 2918, 2875, 1508, 806.
0
0
◦
4-Methyl-4 -(1-(p-tolyl)ethyl)-1,1 -biphenyl (3b): White solid (121.72 mg, 85%), m.p. 48.0–49.0 C. 1H NMR
(400 MHz, CDCl3) (Figure S3) 7.47 (dd, J = 10.8, 8.4 Hz, 4H), 7.28–7.21 (m, 5H), 7.13 (dd, J = 18.1,
8.1 Hz, 3H), 4.15 (dd, J = 14.4, 7.2 Hz, 1H), 2.34 (d, J = 25.7 Hz, 6H), 1.65 (d, J = 7.2 Hz, 3H). 13C NMR
(101 MHz, CDCl3) (Figure S4) 145.6, 143.5, 139.0, 138.3, 136.9, 135.7, 129.6, 129.2, 128.0, 127.6, 127.0,
δ
δ
44.2(CH3), 22.1(CH), 21.2(CHCH3). HRMS (EI) (Figure S5): m/z calcd. for C22H22 [M]: 286.1722, found
[M]: 286.1718. IR (neat, cm−1): 3016, 2960, 2918, 2875, 1508, 806.
4-Methoxy-40-(1-(4-methoxyphenyl)ethyl)-1,10-biphenyl (3c): White solid (138.51 mg, 87%), m.p. 76.0–77.1 ◦C.
1H NMR (400 MHz, CDCl3) (Figure S6)
δ
7.47 (d, J = 8.8 Hz, 4H), 7.16 (d, J = 8.0 Hz, 4H), 6.89 (d,
J = 8.8 Hz, 4H), 4.13 (q, J = 7.2 Hz, 1H), 3.80 (s, 6H), 1.63 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz,
CDCl3) (Figure S7) 159.1, 158.0, 145.4, 138.6, 133.7, 128.6, 128.1, 128.0, 126.8, 114.3, 113.9, 55.4(OCH3),
δ
43.7(CH), 22.2(CH3). HRMS (EI) (Figure S8): m/z calcd. for C22H22O2 [M] 318.1620, found [M]:
318.1620. IR (neat, cm−1): 3003, 2968, 2928, 2831, 1603, 1508, 1248, 816.
4-Fluoro-40-(1-(4-fluorophenyl)ethyl)-1,10-biphenyl (3d): White solid (128.04 mg, 87%), m.p. 72.1–73.6 ◦C.
1H NMR (400 MHz, CDCl3) (Figure S9)
δ
7.52–7.44 (m, 4H), 7.26–7.18 (m, 4H), 7.10 (t, J = 8.4 Hz,
2H), 6.98 (t, J = 8.4Hz, 2H), 4.17 (q, J = 7.2 Hz, 1H), 1.65 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz,
CDCl3) (Figure S10) 163.7, 162.7, 161.3, 160.2, 145.5, 142.0, 138.3, 137.1, 129.1, 128.7, 128.1, 127.2,
δ
115.5, 43.9(CH), 22.2(CH3). HRMS (EI) (Figure S11): m/z calcd. for C20H16F2 [M]: 294.1220, found [M]:
294.1222. IR (neat, cm−1): 3043, 2968, 2876, 1888, 1607, 1508, 1217, 1169, 822.
4-(Trifluoromethyl)-40-(1-(trifluoromethyl)phenyl)ethyl)-1,10-biphenyl (3e): White solid (151.73 mg, 77%),
◦
1
m.p. 60.0–61.2 C. H NMR (400 MHz, CDCl3) (Figure S12)
7.3–7.30 (m, 4H) 4.27 (q, J = 7.2 Hz, 1H), 1.70 (d, J = 7.2 Hz,3H). 13C NMR (101 MHz, CDCl3) (Figure S13)
150.2 (d, J = 1.4 Hz), 145.6, 144.4, 138.0, 129.6, 129.3, 128.9, 128.4, 128.1, 127.5, 125.7, 123.1, 44.5(CH),
δ 7.67 (s, 4H), 7.57–7.52 (m, 4H),
δ
21.7(CH3). HRMS (EI) (Figure S14): m/z calcd. for C22H16F6 [M]: 394.1156, found [M]: 394.1160.
IR (neat, cm−1): 3026, 2976, 2930, 1618, 1325, 1106, 828.
0
0
1
4-Propyl-4 -(1-(4-propylphenyl)ethyl)-1,1 -biphenyl (3f): Colorless oil (140.43 mg, 82%). H NMR (400 MHz,
CDCl3) (Figure S15) 7.48–7.45 (m, 4H), 7.25 (d, J = 8.0 Hz, 2H), 7.19 (d, J = 8.0 Hz, 2H), 7.14 (d,
J = 8.0 Hz, 2H), 7.08 (d, J = 8.0 Hz, 2H), 4.12 (q, J = 7.2 Hz, 1H), 2.60–2.51 (m, 4H), 1.68–1.58 (m, 7H),
δ

Molecules 2017, 22, 2168
8 of 13
0.96–0.90 (m, 6H). 13C NMR (101 MHz, CDCl3) (Figure S16)
δ
145.5, 143.7, 141.6, 140.4, 139.0, 138.5,
129.5, 128.6, 128.1, 127.6, 127.0, 44.3(CHCH3), 37.8(CH2CH2CH3), 24.7 (CH2CH2CH3), 22.1(CHCH3),
14.1(CH2CH2CH3). HRMS (EI) (Figure S17): m/z calcd. for C26H30 [M]: 342.2348, found [M]: 342.2345.
IR (film): 3018, 2965, 2926, 2868, 1500, 1452, 810.
1
3-Methyl-40-(1-(m-tolyl)ethyl)-1,10-biphenyl (3g): Colorless oil (134.61 mg, 94%). H NMR (400 MHz,
CDCl3) (Figure S18) δ 7.49–7.47 (m, 2H), 7.35 (d, J = 8.4 Hz, 2H), 7.27 (t, J = 8.4 Hz, 3H), 7.19–6.98 (m,
5H), 4.13 (q, J = 7.2 Hz, 1H), 2.38 (s, 3H), 2.30 (s, 3H), 1.64 (d, J = 7.2Hz, 3H). 13C NMR (101 MHz, CDCl3)
(Figure S19) δ 146.4, 145.6, 141.2, 139.1, 138.3, 138.0, 128.7, 128.6, 128.4, 128.1, 128.0, 127.9, 127.2, 127.0,
124.8, 124.3, 44.6(CHCH3), 22.0(CHCH3), 21.7(CH3). HRMS (EI) (Figure S20): m/z calcd. for C22H22
[M]: 286.1722, found [M]: 286.1721. IR (film): 3024, 2972, 2922, 2870, 1604, 1479, 835, 783, 700.
0
0
1
3-Methoxy-4 -(1-(3-methoxyphenyl)-1,1 -biphenyl (3h): Colorless oil (136.92 mg, 86%). H NMR (400 MHz,
CDCl3) (Figure S21) 7.49 (dt, J = 4 Hz, 2Hz, 2H), 7.33–7.27 (m, 3H), 7.22–7.05 (m, 4H), 6.85 (dd, J = 7.4,
2.8 Hz, 2H), 6.81–6.80 (m, 1H), 4.14 (q, J = 7.2 Hz, 1H), 3.81 (s, 3H), 3.75 (s, 3H), 1.65 (d, J = 7.2 Hz,
3H). 13C NMR (101 MHz, CDCl3) (Figure S22)
160.0, 159.8, 148.0, 145.6, 142.6, 139.0, 131.5, 129.80,
δ
δ
129.5, 128.0, 127.3, 120.2, 119.7, 113.9, 112.9, 112.6, 111.1, 55.3(OCH3), 44.6(CH), 21.9(CH3). HRMS (EI)
(Figure S23): m/z calcd. for C22H22O2 [M]: 318.1620, found [M]: 318.1616. IR (film): 2999, 2962, 2935,
2835, 1601, 1485, 1261, 1157, 835.
0
0
1
3,4,5-Trifluoro-4 -(1-(3,4,5-trifluorophenyl)ethyl)-1,1 biphenyl (3i): Colorless oil (102.56 mg, 56%). H NMR
(400 MHz, CDCl3) (Figure S24) 7.45–7.42 (m, 2H), 7.25–7.14 (m, 4H), 6.87–6.79 (m, 2H), 4.12 (q,
J = 7.2 Hz, 1H), 1.63 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3) (Figure S25)
152.6, 150.2, 145.2,
δ
δ
142.4, 140.6, 139.6, 138.1, 137.0, 128.3, 127.3, 111.6, 111.0, 44.0(CH), 21.6(CH3). HRMS (EI) (Figure S26):
m/z calcd. for C20H12F6 [M]: 366.0843, found [M]: 366.0844. IR (film): 3042, 2968, 2926, 1618, 1537,
1445, 1348, 1244, 1041, 831.
2-Methyl-40-(1-(o-tolyl)ethyl)-1,10-biphenyl (3j): Colorless oil (131.75 mg, 92%). 1H NMR (400 MHz,
CDCl3) (Figure S27)
δ 7.31 (d, J = 7.6 Hz, 1H), 7.23–7.19 (m, 9H), 7.15–7.13 (m, 2H), 4.36 (q, J = 7.2 Hz,
1H), 2.26 (d, J = 10.8 Hz, 6H), 1.65 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3) (Figure S28)
δ
144.8, 144.1, 141.9, 139.5, 136.2, 135.5, 130.5, 130.0, 129.2, 127.4, 127.2, 126.9, 126.2, 125.8, 40.8(CHCH3),
22.2(CHCH3), 20.7(CH3), 20.0(CH3). HRMS (EI) (Figure S29): m/z calcd. for C22H22 [M]: 286.1722,
found [M]: 286.1724. IR (film): 3017, 2968, 2926, 2866, 1601, 1481, 835, 756.
◦
2-(4-(1-(Naphthalene-2-yl)ethyl)phenyl)naphthalene (3k): White solid (148.77 mg, 83%), m.p. 110.9–111.5 C.
1H NMR (400 MHz, CDCl3) (Figure S30)
δ
8.03 (d, J = 16.8 Hz, 1H), 7.90–7.73 (m, 8H), 7.71–7.64 (m,
2H), 7.50–7.44 (m, 4H), 7.41–7.36 (m, 3H), 4.38 (dd, J = 13.9, 6.8 Hz, 1H), 1.80 (dd, J = 12.5, 7.0 Hz, 3H).
13C NMR (101 MHz, d6-DMSO) (Figure S31)
145.6, 143.7, 137.7, 137.3, 133.3, 133.1, 132.1, 131.7, 128.4,
δ
128.1, 127.9, 127.6, 127.5, 127.4, 127.0, 126.6, 126.3, 126.1, 126.0, 125.5, 125.0, 124.9, 43.8(CH), 21.3(CH3).
HRMS (EI) (Figure S32): m/z calcd. for C28H22 [M]: 358.1722, found [M]: 358.1718. IR (neat, cm−1):
3053, 2960, 2870, 1601, 1501, 1448, 860,817.
1
3-Methyl-3-(1-(m-tolyl)ethyl-1,1-biphenyl (3l): Colorless oil (117.42 mg, 82%). H NMR (400 MHz, CDCl3)
(Figure S33)
J = 7.2 Hz, 1H), 2.34 (d, J = 37.8 Hz, 6H), 1.66 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3) (Figure S34)
147.0, 146.4, 141.6, 141.5, 138.4, 138.0, 128.8, 128.7, 128.6, 128.4, 128.1, 127.0, 126.7, 126.6, 125.1, 124.7,
δ 7.45 (t, J = 1.7 Hz, 1H), 7.40–7.27 (m, 5H), 7.19–7.12 (m, 3H), 7.06–6.97 (m, 3H), 4.16 (q,
δ
124.5, 45.0(CH), 22.1(CHCH3), 21.7(CH3), 21.6(CH3). HRMS (EI) (Figure S35): m/z calcd. for C22H22
[M]: 286.1722, found [M]: 286.1724. IR (film): 3036, 2961, 2913, 2879, 1591, 1475, 791, 700.
1
3-Methyl-40-(3-methylbenzyl)-1,10-biphenyl (3m) [47]: Colorless oil (100.78 mg,74%). H NMR (400 MHz,
CDCl3) (Figure S36)
Hz, 3H), 3.97 (s, 2H), 2.40 (s, 3H), 2.32 (s, 3H). 13C NMR (101 MHz, CDCl3) (Figure S37)
139.2, 138.4, 138.2, 129.8, 129.4, 128.8, 128.5, 127.95, 127.3, 127.0, 126.1, 124.2, 41.7(CH), 21.7(CHCH3),
δ
7.50 (dt, J = 4.0, 2.0 Hz, 2H), 7.37–7.25 (m, 4H), 7.23–7.12 (m, 3H), 7.02 (d, J = 7.7
δ
141.1, 140.4,

Molecules 2017, 22, 2168
9 of 13
21.6(CH3). HRMS (EI) (Figure S38): m/z calcd. for C21H20 [M]: 272.1565, found [M]: 272.1560. IR (film):
3030, 2916, 2858, 1606, 1479, 783.
1
30-Methyl-3-(2-methylbenzyl)-1,10-biphenyl (3n) [47]: Colorless oil (39.50 mg, 29%). H NMR (400 MHz,
CDCl3) (Figure S39)
δ
7.28–7.19 (m, 5H), 7.14–7.04 (m, 4H), 6.95 (d, J = 7.0 Hz, 1H), 6.79 (d, J = 5.6 Hz,
142.5, 141.7,
2H), 3.90 (s, 2H), 2.34 (s, 3H), 2.25 (s, 3H). 13C NMR (101 MHz, CDCl3) (Figure S40)
δ
141.6, 138.5, 137.8, 137.6, 130.3, 130.1, 129.8, 128.2, 128.0, 127.7, 127.5, 126.6, 126.5, 126.2, 126.1, 39.2(CH),
21.5(CH3). HRMS (EI) (Figure S41): m/z calcd. for C21H20 [M]: 272.1565, found [M]: 272.1566. IR (film):
3022, 2914, 2858, 1597, 1485, 762, 698.
◦
4-Methoxy-40-(1-(p-tolyl)ethyl)-1,10-biphenyl (3o): White solid (120.96 mg, 80%), m.p. 99.2–100.7 C.
1H NMR (400 MHz, CDCl3) (Figure S42)
7.47 (dd, J = 13.7, 8.5 Hz, 4H), 7.27–7.24 (m, 2H), 7.13 (q,
J = 8.2 Hz, 4H), 6.97–6.92 (m, 2H), 4.14 (q, J = 7.2 Hz, 1H), 3.83 (s, 3H), 2.31 (s, 3H), 1.65 (d, J = 7.2 Hz,
3H). 13C NMR (101 MHz, CDCl3) (Figure S43)
159.1, 145.2, 143.5, 138.6, 135.7, 133.8, 129.2, 128.1,
δ
δ
127.6, 126.8, 114.3, 55.5(OCH3), 44.2(CH), 22.1(CHCH3), 21.1(CH3). HRMS (EI) (Figure S44): m/z calcd.
for C22H22O [M]: 302.1671, found [M]: 302.1666. IR (neat, cm−1): 3034, 2968, 2905, 1606, 1501, 1454,
1248, 1035, 820.
4-Propyl-40-(1-(p-tolyl)ethyl)-1,10-biphenyl (3p): Colorless oil (136.92 mg, 86%). 1H NMR (400 MHz,
CDCl3) (Figure S45)
7.07 (dd, J = 8.0, 2.3 Hz, 2H), 4.15–4.09 (m, 1H), 2.65–2.51 (m, 2H), 2.28 (d, J = 2.4 Hz, 3H), 1.64–1.61
(m, 5H), 0.96–0.92(m, 3H). 13C NMR (101 MHz, CDCl3) (Figure S46)
145.5, 143.5, 141.7, 139.0, 138.5,
δ 7.48–7.44 (m, 4H), 7.25–7.23 (m, 2H), 7.20–7.18 (m, 2H), 7.14–7.11 (m, 2H),
δ
135.6, 129.2, 128.9, 128.0, 127.6, 127.0, 126.9, 44.2(CH), 37.8(CH3), 24.7(CH2CH2CH3), 22.1(CHCH3),
21.1(CH2CH2CH3), 14.0(CH2CH2CH3). HRMS (EI) (Figure S47): m/z calcd. for C24H26 [M]: 314.2035,
found [M]: 314.2029. IR (film): 3024, 2960, 2928, 2866, 1502, 808.
4-Flouro-40-(1-(p-toly)etyl)-1,10-biphenyl (3q): White solid (98.73 mg, 68%), m.p. 85.2–86.0 ◦C. 1H NMR
(400 MHz, CDCl3) (Figure S48) δ 7.52–7.48 (m, 2H), 7.44 (d, J = 8.4 Hz, 2H), 7.28–7.24 (m, 2H), 7.15–7.07
(m, 6H), 4.15 (q, J = 7.2 Hz, 1H), 2.31 (s, 3H), 1.65 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3)
(Figure S49) δ 162.5, 160.1, 144.7, 142.2, 136.8, 136.1, 134.6, 128.1, 127.5, 127.0, 126.4, 125.9, 114.6, 114.4,
43.0(CH), 20.9(CHCH3), 20.0(CH3). HRMS (EI) (Figure S50): m/z calcd. for C21H19F [M]: 290.1471,
found [M]: 290.1472. IR (neat, cm−1): 3032, 2966, 2924, 2870, 1597, 1500, 1240, 820.
0
0
4-(1-(p-Tolyl)ethyl)-4 -(trifluoromethyl)-1,1 -biphenyl (3r): Colorless oil (85.10 mg, 50%). 1H NMR (400 MHz,
CDCl3) (Figure S51) 7.65 (s, 4H), 7.50 (dt, J = 4.0, 2.0 Hz, 2H), 7.31 (d, J = 8.0 Hz, 2H), 7.16–7.07
(m, 4H), 4.16 (q, J = 7.2 Hz, 1H), 2.31 (s, 3H), 1.66 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3)
(Figure S52) 146.9, 144.5 (d, J = 1.6 Hz), 143.0, 137.4, 135.7, 131.4, 129.2, 128.2, 127.4, 127.2, 125.6,
δ
δ
123.0(CF3), 44.1(CH), 21.9(CH3), 21.0(CHCH3). HRMS (EI) (Figure S53): m/z calcd. for C22H19F3 [M]:
340.1439, found [M]: 340.1441. IR (film): 3021, 2966, 2926, 2882, 1618, 1504, 1325, 1169, 1121, 829.
1
2,4-Difluoro-40-(1-(p-tolyl)ethyl)-1,10-biphenyl (3s): Colorless oil (112.47 mg, 73%). H NMR (400 MHz,
CDCl3) (Figure S54)
δ 7.40 (dd, J = 8.2, 1.7 Hz, 2H), 7.35–7.27 (m, 3H), 7.12 (q, J = 8.3 Hz, 4H), 6.93–6.84
(m, 2H), 4.15 (q, J = 7.2 Hz, 1H), 2.31 (s, 3H), 1.64 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3)
(Figure S55) δ 163.4, 161.0, 158.6, 146.3, 143.1, 135.7, 132.6, 131.3, 129.2, 127.7, 127.5, 125.2, 111.5, 104.3,
44.2(CH), 21.9(CHCH3), 21.0(CH3). HRMS (EI) (Figure S56): m/z calcd. for C21H18F2 [M]: 308.1377,
found [M]: 308.1371. IR (film): 3024, 2965, 2924, 2868, 1607, 1495, 1139, 848, 812.
◦
9-(4-(1-([1,1
1H NMR (400 MHz, CDCl3) (Figure S57)
(m, 13H), 7.34–7.28 (m, 2H), 4.36 (q, J = 7.2 Hz, 1H), 1.81 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz,
'-Biphenyl]-4-yl)ethyl)phenyl)-9H-carbazole (3t): White solid (67.77 mg, 32%), m.p. 141.2–143.0 C.
δ
8.17 (dt, J = 7.8, 1.1 Hz, 2H), 7.67–7.60 (m, 4H), 7.57–7.34
CDCl3) (Figure S58)
δ 145.6, 145.0, 140.9, 139.3, 135.6, 129.0, 128.8, 128.1, 127.1, 125.9, 123.3, 120.3, 119.8,
109.9, 44.3(CH), 22.0(CH3). HRMS (EI) (Figure S59): m/z calcd. for C32H25N [M]+: 423.1987, found
[M]+:423.1982. IR (neat, cm-1): 3051, 2963, 2876, 1595, 1510, 1232, 835, 812.

Molecules 2017, 22, 2168
10 of 13
1
40-Methoxy-3-(1-(p-tolyl)ethyl)-1,10-biphenyl (3u): Colorless oil (63.51 mg, 42%). H NMR (400 MHz,
CDCl3) (Figure S60) 7.51–7.47 (m, 2H), 7.40 (t, J = 1.8 Hz, 1H), 7.36 (dt, J = 7.7, 1.5 Hz, 1H), 7.31
(t, J = 7.6 Hz, 1H), 7.12 (dd, J = 23.2, 8.4 Hz, 5H), 6.97–6.93 (m, 2H), 4.16 (q, J = 7.2 Hz, 1H), 3.83 (s,
3H), 2.30 (s, 3H), 1.66 (d, J = 7.2 Hz, 3H). 13C NMR (101 MHz, CDCl3) (Figure S61)
159.2, 147.2,
δ
δ
143.4, 141.0, 135.6, 134.1, 129.2, 128.8, 128.3, 127.6, 126.3, 126.1, 124.6, 114.3, 55.5(OCH3), 44.6(CH),
22.1(CHCH3), 21.1(CH3). HRMS (EI) (Figure S62): m/z calcd. for C22H22O [M]: 302.1671, found [M]:
302.1665. IR (film): 3003, 2930, 2682, 1612, 1520, 1244, 818.
◦
4-Methoxy-40-(4-methylbenzyl)-1,10-biphenyl (3v): White solid (33.16 mg, 23%), m.p. 94.7–96.6 C.
1H NMR (400 MHz, CDCl3) (Figure S63)
7.47 (dd, J = 14.7, 8.5 Hz, 4H), 7.22 (d, J = 8.3 Hz, 2H), 7.11
(s, 4H), 6.95 (d, J = 8.8 Hz, 2H), 3.97 (s, 2H), 3.84 (s, 3H), 2.32 (s, 3H). 13C NMR (101 MHz, CDCl3)
(Figure S64) 159.0, 139.9, 138.6, 138.0, 135.6, 133.6, 129.19, 128.8, 128.0, 126.8, 114.1, 55.3(OCH3),
δ
δ
41.1(CH2), 21.0(CH3). HRMS (EI) (Figure S65): m/z calcd. for C21H20O [M]: 288.1514, found [M]:
288.1513. IR (neat, cm−1): 2957, 2912, 2837, 1607, 1504, 1248, 800.
0
0
1
4 -Methoxy-2-(4-methylbenzyl)-1,1 -biphenyl (3w) [48]: Colorless oil (36.05 mg, 25%). H NMR (400 MHz,
CDCl3) (Figure S66) 7.25–7.23 (m, 3H), 7.20–7.17 (m, 3H), 7.02 (d, J = 7.9 Hz, 2H), 6.92–6.88 (m,
4H), 3.91 (s, 2H), 3.83 (s, 3H), 2.29 (s, 3H). 13C NMR (101 MHz, CDCl3) (Figure S67)
158.7, 141.9,
δ
δ
138.7, 138.6, 135.3, 134.2,130.5, 130.4, 129.1, 128.9, 127.3, 126.2, 113.6, 55.4(OCH3), 38.7(CH2), 21.1(CH3).
HRMS (EI) (Figure S68): m/z calcd. for C21H20O [M]: 288.1514, found [M]: 288.1519. IR (film): 3018,
2924, 2849, 1609, 1246, 764.
4-(1-([1,10-Biphenyl]-4-yl)ethyl)pyridine (3x): White solid (77.80 mg, 60%), m.p. 55.8–56.5 ◦C. 1H NMR
(400 MHz, CDCl3) (Figure S69)
δ 8.53 (d, J = 5.6 Hz, 2H), 7.58–7.53 (m, 4H), 7.42 (t, J = 7.5 Hz, 2H), 7.33
(d, J = 7.3, 1H), 7.27–7.24 (m, 2H), 7.19 (dd, J = 4.8, 1.2 Hz, 2H), 4.17 (q, J = 7.2 Hz, 1H), 1.68 (d, J = 7.2
Hz, 3H). 13C NMR (101 MHz, CDCl3) (Figure S70)
δ 155.7, 149.5, 143.4, 140.8, 139.8, 128.9, 128.1, 127.5,
127.4, 127.1, 123.3, 44.1(CH), 21.2(CH3). HRMS (ESI) (Figure S71): m/z calcd. for C19H18N [M + H]+:
260.1439, found [M + H]+: 260.1432. IR (neat, cm−1): 3352, 2885, 1591, 1404, 839.
4-(1-(40-Methoxy-[1,10-biphenyl]-4-yl)ethyl)pyridine (3y): Light yellow solid (73.80 mg, 51%), m.p.
55.8–56.5 ◦C. 1H NMR (400 MHz, CDCl3) (Figure S72) δ 8.51 (d, J = 6.0 Hz, 2H), 7.49 (m, 4H), 7.19 (m,
4H), 6.95 (d, J = 8.8 Hz, 2H), 4.13 (q, J = 7.2 Hz, 1H), 3.81 (s, 3H), 1.65 (d, J = 7.2 Hz, 3H). 13C NMR
(101 MHz, CDCl3) (Figure S73)
δ 159.2, 155.6, 149.5, 142.7, 139.3, 133.3, 128.1, 127.0, 123.2, 114.3,
55.4(OCH3), 44.0(CH), 21.1(CH3). HRMS (ESI) (Figure S74): m/z calcd. for C20H20NO [M + H]+:
290.1545, found [M + H]+: 290.1534. IR (neat, cm−1): 3035, 2970, 2843, 1604, 1497, 1248, 1028, 814.
4. Conclusions
In summary, we developed an operationally simple, efficient general procedures for synthesizing
4-benzyl-1,10-biphenyl derivatives, via a four-component one-pot reaction of 4-bromoacetophenone,
tosylhydrazide and two arylboronic acids as the starting materials, involving Barluenga and Suzuki
couplings. This method can be processed in one-pot with multiple steps; indeed it is a simpler and
more efficient way to synthesis 4-benzyl-1,10-biphenyl compounds. Also, we demonstrated the utility
of this method from commercially available starting materials to afford the corresponding products in
moderate to excellent yields with good functional group tolerance. Notably, this protocol also proves
to be suitable for synthesizing 4-pyridyl biphenylmethane-type compounds, which are analogs of
CPY17 inhibitors.
Supplementary Materials: Supplementary materials are available online. the charts of 1H-, 13C-NMR and HRMS
of products.
Acknowledgments: We gratefully acknowledge financial support of this work by the National Natural Science
Foundation of China (No. 21563025), and the Program for Changjiang Scholars and Innovative Research Team in
University (No. IRT_15R46), and Yangtze River Scholar Research Project of Shihezi University (No. CJXZ201601).

Molecules 2017, 22, 2168
11 of 13
Author Contributions: P. Liu and Y. Liu conceived and designed the experiments; N. Gu performed the
experiments; B. Dai contributed reagents/materials/analysis tools; Y. Wei wrote the paper.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
Tanabe, K.; Hölderich, W.F. Industrial application of solid acid-base catalysts. Appl. Catal. A 1999, 181,
399–434. [CrossRef]
Beltrame, P.; Zuretti, G.; Demartin, F. Benzylation of biphenyl with benzyl chloride over crystalline,
amorphous, and MCM-41 solid acid catalysts. Ind. Eng. Chem. Res. 2000, 39, 1209–1214. [CrossRef]
Hino, M.; Arata, K. The synthesis of thermally stable oils by the benzylation of biphenyl with benzyl chloride
catalyzed by Iron(III) oxide. Bull. Chem. Soc. Jpn. 1981, 54, 311–312. [CrossRef]
Huhtaniemi, I.; Nikula, H.; Parvinen, M.; Rannikko, S. Histological and functional changes of the testis
tissue during GnRH agonist treatment of prostatic cancer. Am. J. Clin. Oncol. 1988, 11, S11–S15. [CrossRef]
[PubMed]
5.
6.
Titus, M.A.; Schell, M.J.; Lih, F.B.; Tomer, K.B.; Mohler, J.L. Testosterone and dihydrotestosterone tissue levels
in recurrent prostate cancer. Clin. Cancer Res. 2005, 11, 4653–4657. [CrossRef] [PubMed]
Stanbrough, M.; Bubley, G.J.; Ross, K.; Golub, T.R.; Rubin, M.A.; Penning, T.M.; Febbo, P.G.; Balk, S.P.
Increased expression of genes converting adrenal androgens to testosterone in androgen-independent
prostate cancer. Cancer Res. 2006, 66, 2815–2825. [CrossRef] [PubMed]
7.
8.
Montgomery, R.B.; Mostaghel, E.A.; Vessella, R.; Hess, D.L.; Kalhorn, T.F.; Higano, C.S.; True, L.D.; Nelson, P.S.
Maintenance of intratumoral androgens in metastatic prostate cancer: A mechanism for castration-resistant
tumor growth. Cancer Res. 2008, 68, 4447–4454. [CrossRef] [PubMed]
Holzbeierlein, J.; Lal, P.; La Tulippe, E.; Smith, A.; Satagopan, J.; Zhang, L.; Ryan, C.; Smith, S.; Scher, H.;
Scardino, P.; et al. Gene expression analysis of human prostate carcinoma during hormonal therapy identifies
androgen-responsive genes and mechanisms of therapy resistance. Am. J. Pathol. 2004, 164, 217–227.
[CrossRef]
9.
Labrie, F.; Dupont, A.; Belanger, A.; Cusan, L.; Lacourciere, Y.; Monfette, G.; Laberge, J.G.; Emond, J.P.;
Fazekas, A.T.; Raynaud, J.P.; et al. New hormonal therapy in prostatic carcinoma: Combined treatment with
an LHRH agonist and an antiandrogen. Clin. Investig. Med. 1982, 5, 267–275.
10. Hu, Q.Z.; Yin, L.; Jagusch, C.; Hille, U.E.; Hartmann, R.W. Isopropylidene substitution increases activity
and selectivity of biphenylmethylene 4-pyridine type CYP17 inhibitors. J. Med. Chem. 2010, 53, 5049–5053.
[CrossRef] [PubMed]
11. Hu, Q.Z.; Jagusch, C.; Hille, U.E.; Haupenthal, J.; Hartmann, R.W. Replacement of imidazolyl by pyridyl in
biphenylmethylenes results in selective CYP17 and dual CYP17/CYP11B1 inhibitors for the treatment of
prostate cancer. J. Med. Chem. 2010, 53, 5749–5758. [CrossRef] [PubMed]
12. Yadav, G.D.; George, G. Monoalkylation of biphenyl over modified heteropoly acids: Novelty of cesium
substituted dodecatungstophosphoric acid supported on hexagonal mesoporous silica. Catal. Today 2009
141, 130–137. [CrossRef]
,
13. Beltrame, P.; Demartin, F.; Zuretti, G. An improved kinetic model for the reaction of biphenyl with benzyl
chloride over an MCM-41 solid acid catalyst. Appl. Catal. A Gen. 2001, 218, 61–67. [CrossRef]
14. Jana, S.K. Recent developments of heterogeneous solid catalysts for liquid-phase Friedel-Crafts type
benzylation reaction. Catal. Surv. Asia 2005, 9, 25–34. [CrossRef]
15. Haase, J.; Hillner, K.; Brueggemann, W.; Momm, G. p-Benzylbiphenyl. Eur. Pat. Appl. Eur. Patent 431,265,
12 June 1991.
16. Sakura, K.; Takeuchi, H.; Furumoto, M. Manufacture of Benzylbiphenyls. Jpn. Kokai Tokkyo Koho JP
03,170,442, 24 July 1991.
17. Beltrame, P.; Zuretti, G. Benzylation of biphenyl with benzyl chloride over HY zeolites: A kinetic model for
reaction and catalyst deactivation. Ind. Eng. Chem. Res. 1997, 36, 3427–3432. [CrossRef]
18. Miyaura, N.; Yanagi, T.; Suzuki, A. The palladium-catalyzed cross-coupling reaction of phenylboronic acid
with haloarenes in the presence of bases. Synth. Commun. 1981, 11, 513–519. [CrossRef]
19. Miyaura, N.; Suzuki, A. Palladium-catalyzed cross-coupling reactions of organoboron compounds. Chem. Rev.
1995, 95, 2457–2483. [CrossRef]

Molecules 2017, 22, 2168
12 of 13
20. Suzuki, A. Recent advances in the cross-coupling reactions of organoboron derivatives with organic
electrophiles, 1995–1998. J. Organomet. Chem. 1999, 576, 147–168. [CrossRef]
21. Suzuki, A. Cross-coupling reactions via organoboranes. J. Organomet. Chem. 2002, 653, 83–90. [CrossRef]
22. Langle, S.; Abarbri, M.; Duchêne, A. Selective double Suzuki cross-coupling reactions. Synthesis of
unsymmetrical diaryl (or heteroaryl) methanes. Tetrahedron Lett. 2003, 44, 9255–9258. [CrossRef]
23. Henry, N.; Enguehard-Gueiffier, C.; Thery, I.; Gueiffier, A. One-pot dual substitutions of bromobenzyl
chloride, 2-chloromethyl-6-halogenoimidazo [1,2-a] pyridine and-[1,2-b]pyridazine by Suzuki-Miyaura
cross-coupling reactions. Eur. J. Org. Chem. 2008, 2008, 4824–4827. [CrossRef]
24. Zhu, J.; Bienaym, H. (Eds.) Multicomponent Reactions; Wiley-VCH: Weinheim, Germany, 2005.
25. Dömling, A. Recent developments in isocyanide based multicomponent reactions in applied chemistry.
Chem. Rev. 2006, 106, 17–89. [CrossRef] [PubMed]
26. Gu, Y.L. Multicomponent reactions in unconventional solvents: State of the art. Green Chem. 2012, 14,
2091–2128. [CrossRef]
27. Yang, T.; Cui, H.; Zhang, C.H.; Zhang, L.; Su, C.Y. From homogeneous to heterogeneous catalysis of the
three-component coupling of oxysulfonyl azides, alkynes, and amines. ChemCatChem 2013, 5, 3131–3138.
[CrossRef]
28. Fulton, J.R.; Aggarwal, V.K.; de Vicente, J. The use of tosylhydrazone salts as a safe alternative for handling
diazo compounds and their applications in organic synthesis. Eur. J. Org. Chem. 2005, 1479–1492. [CrossRef]
29. Barluenga, J.; Valdés, C. Tosylhydrazones: New uses for classic reagents in palladium-catalyzed
cross-coupling and metal-free reactions. Angew. Chem. Int. Ed. 2011, 50, 7486–7500. [CrossRef] [PubMed]
30. Shao, Z.; Zhang, H. N-tosylhydrazones: Versatile reagents for metal-catalyzed and metal-free cross-coupling
reactions. Chem. Soc. Rev. 2012, 41, 560–572. [CrossRef] [PubMed]
31. Kai, X.; Chong, S.; Shang, S. Progress of cross-coupling reaction with N-tosylhydrazones. Chin. J. Org. Chem.
2015, 35, 294–308. [CrossRef]
32. Liu, Z.; Zhang, Y.; Wang, J. Transition-metal-catalyzed cross-coupling reaction with N-tosylhydrazones.
Chin. J. Org. Chem. 2013, 33, 687–692. [CrossRef]
33. Xiao, Q.; Zhang, Y.; Wang, J. Diazo compounds and N-tosylhydrazones: Novel cross-coupling partners in
transition-metal-catalyzed reactions. Acc. Chem. Res. 2013, 46, 236–247. [CrossRef] [PubMed]
34. Jadhav, A.P.; Ray, D.; BhaskaraRao, V.U.; Singh, R.P. Copper-catalyzed direct cross-coupling of compounds
containing activated C–H/heteroatom–H bonds with N-tosylhydrazones. Eur. J. Org. Chem. 2016, 2369–2382.
[CrossRef]
35. Barluenga, J.; Tomás-Gamasa, M.; Aznar, F.; Valdés, C. Metal-free carbon–carbon bond-forming reductive
coupling between boronic acids and tosylhydrazones. Nat. Chem. 2009, 1, 494–499. [CrossRef] [PubMed]
36. Zhou, L.; Shi, Y.; Xiao, Q.; Liu, Y.; Ye, F.; Zhang, Y.; Wang, J. CuBr-Catalyzed coupling of N-tosylhydrazones
and terminal alkynes: Synthesis of benzofurans and indoles. Org. Lett. 2011, 13, 968–971. [CrossRef]
[PubMed]
37. Ye, F.; Shi, Y.; Zhou, L.; Xiao, Q.; Zhang, Y.; Wang, J. Expeditious synthesis of phenanthrenes via
CuBr2-catalyzed coupling of terminal alkynes and N-tosylhydrazones derived from O-formyl biphenyls.
Org. Lett. 2011, 13, 5020–5023. [CrossRef] [PubMed]
38. Zhou, L.; Xiao, T.; Dong, X. Benzofuran and indole synthesis via Cu(I)-catalyzed coupling of
N-tosylhydrazone and o-hydroxy or o-amino phenylacetylene. Org. Biomol. Chem. 2013, 11, 1490–1497.
39. Zhou, L.; Ye, F.; Zhang, Y.; Wang, J. Pd-catalyzed three-component coupling of N-tosylhydrazone, terminal
alkyne, and aryl halide. J. Am. Chem. Soc. 2010, 132, 13590–13591. [CrossRef] [PubMed]
40. Roche, M.; Hamze, A.; Brion, J.-D.; Alami, M. Catalytic three-component one-pot reaction of hydrazones,
dihaloarenes, and amines. Org. Lett. 2013, 15, 148–151. [CrossRef] [PubMed]
41. Naret, T.; Retailleau, P.; Bignon, J.; Brion, J.-D.; Alami, M.; Hamze, A. Palladium-catalyzed one-pot synthesis
of 5-(1-arylvinyl)-1H-benzimidazoles: Overcoming the limitation of acetamide partners. Adv. Synth. Catal.
2016, 358, 1833–1847. [CrossRef]
42. Shen, X.; Gu, N.; Liu, P.; Ma, X.; Xie, J.; Liu, Y.; He, L.; Dai, B. A simple and efficient synthesis of 9-arylfluorenes
via metal-free reductive coupling of arylboronic acids and N-tosylhydrazones in situ. RSC Adv. 2015, 5,
63726–63731. [CrossRef]

Molecules 2017, 22, 2168
13 of 13
43. Shen, X.; Gu, N.; Liu, P.; Ma, X.; Xie, J.; Liu, Y.; Dai, B. One-pot synthesis of triarylmethanes via metal-free
reductive coupling of diaryl ketones, tosylhydrazide, and arylboronic acids. Chin. J. Chem. 2016, 34,
1033–1038. [CrossRef]
44. Shen, X.; Liu, P.; Liu, Y.; Liu, Y.; Dai, B. One-pot reductive coupling reactions of acetyl naphthalene derivatives,
tosylhydrazide, with arylboronic acids. Tetrahedron 2017, 73, 785–793. [CrossRef]
45. Liu, Y.; Liu, P.; Liu, Y.; Wei, Y. Pd(0)-catalyzed tandem one-pot reaction of biphenyl ketones/aldehydes to the
corresponding di-substituted aryl olefins. Chin. J. Chem. 2017, 35, 1141–1148. [CrossRef]
46. López-Pérez, A.; Adrio, J.; Carretero, J.C. Palladium-catalyzed cross-coupling reaction of secondary benzylic
bromides with Grignard reagents. Org. Lett. 2009, 11, 5514–5517. [CrossRef] [PubMed]
47. Zhang, Y.; Feng, M.T.; Lu, J.M. N-Heterocyclic carbine-palladium (ii)-1-methylimidazole complex catalyzed
Suzuki-Miyaura coupling of benzylic chlorides with arylboronic acids or potassium phenyltrifluoroborate in
neat water. Org. Biomol. Chem. 2013, 11, 2266–2272. [CrossRef] [PubMed]
48. Anselmi, S.E.; Abarbri, M.; Duchêne, A.; Langle-Lamande, S.; Thibonnet, J. Efficient synthesis of substituted
styrenes and biaryls (or heteroaryls) with regioselective reactions of ortho-, meta-, and para-bromobenzyl
bromide. Synthesis 2012, 44, 2023–2040. [CrossRef]
Sample Availability: Samples of the compounds are not available from the authors.
©
2017 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
