Direct observation of a cationic gold(I)-bicyclo[3.2.0]hept-1(7)-ene complex generated in the cycloisomerization of a 7-phenyl-1,6-enyne

Article abstract of DOI:10.1002/anie.201301640

The reaction of enyne 1 with a 1:1 mixture of [LAuCl] and AgSbF₆ in CD₂Cl₂ at -20 °C gave the gold complex 2 in 97 % yield (NMR spectroscopy). Warming a solution of 2 at 25 °C led to 1,3-H migration (t_1/2≈16 min) to form the gold complex 3 with 96 % selectivity. ¹³C NMR analysis of 2 and 3 showed predominant metallacyclopropane character of the gold-bicyclo[3.2.0]heptene bond. Copyright

Full text of DOI:10.1002/anie.201301640

Angewandte
Chemie
DOI: 10.1002/anie.201301640
Cycloaddition
Direct Observation of a Cationic Gold(I)–Bicyclo[3.2.0]hept-1(7)-ene
Complex Generated in the Cycloisomerization of a 7-Phenyl-1,6-
enyne**
Rachel E. M. Brooner, Timothy J. Brown, and Ross A. Widenhoefer*
The cycloisomerization of enynes catalyzed by electrophilic
noble-metal complexes,[1] in particular Au and Pt,[2] has
attracted considerable attention owing to the formation of
skeletal rearrangement products, including vinylcyclopen-
tenes (B and C), bicyclo[4.1.0]heptenes (D), and bicyclo-
[3.2.0]hept-6-enes (E) from 1,6-enynes (A; Scheme 1).[3,4]
these cationic complexes, as no organometallic intermediate
has been observed spectroscopically in any of these trans-
formations.[6–10]
Platinum(II),[11] gold(I),[12,13] and rhodium(II)[14] com-
plexes catalyze the cycloisomerization of 7-aryl-1,6-enynes
(A, R = Ar) to form vinylcyclopentenes C and/or bicyclo-
[3.2.0]hept-6-enes E (Scheme 1). Directly implicated in these
and related[15,16] transformations is the strained bicyclo-
[3.2.0]hept-1(7)-ene species I, presumably generated through
6-endo-cyclization followed by 1,2-alkyl migration from
cyclopropyl carbene II and consumed either by ring opening
to form B and/or 1,3-hydrogen migration to form
E
(Scheme 1).[11–14] Possible contributors to I include the meta-
lated cyclobutyl carbenium ion Ia, the p-alkene complex Ib,
and the metallacyclopropane complex Ic. In this context, it
appeared likely that contribution of the latter forms would
engender stability to I not realized in the corresponding
cyclopropyl carbene intermediates II or III, such that I might
represent a local minimum on the reaction coordinate.
Indeed, here we report the selective generation, spectroscopic
characterization, and reactivity analysis of a gold–bicyclo-
[3.2.0]hept-1(7)-ene complex formed in the gold-catalyzed
cycloisomerization of a 7-phenyl-1,6-enyne.
Scheme 1. Ligand- and substrate-dependent pathways for enyne cyclo-
addition catalyzed by electrophilic noble-metal complexes.
Toward detection of a reactive bicyclo[3.2.0]hept-1(7)-ene
complex, we investigated the gold(I)-catalyzed conversion of
the 7-phenyl-1,6-enyne 1 into the 6-phenylbicyclo[3.2.0]hept-
6-ene 2 reported by Echavarren (Scheme 2).[12] In an initial
experiment, a 1:1:1 mixture of 1, [LAuCl] (L = P(tBu)2(o-
biphenyl)), and AgSbF6 in CD2Cl2 was mixed thoroughly at
ꢁ788C. 31P and 1H NMR analysis at ꢁ808C showed formation
of an approximately 9:1 mixture of p-alkene and p-alkyne
Fꢀrstner first posited that these outcomes were consistent
with the intermediacy of metal-stabilized nonclassical cyclo-
propylmethyl-, cyclobutyl-, and homoallylic carbocations/
=
carbenes accessed through attack of the C C moiety on
a metal-complexed C C bond (Scheme 1),[5] and mechanistic
ꢀ
thought in this area has evolved largely within this conceptual
framework. The involvement of nonclassical carbocations/
carbenes is supported by a wealth of indirect experimental
evidence, including trapping experiments, isotopic labeling
studies, and stereochemical analyses, and through numerous
computational studies.[1,2] Absent, however, is direct exper-
imental evidence regarding the structure and reactivity of
[*] R. E. M. Brooner, T. J. Brown, Prof. R. A. Widenhoefer
French Family Science Center, Duke University
Durham, NC 27708–0346 (USA)
E-mail: rwidenho@chem.duke.edu
[**] We thank the NSF (CHE-0555425) for support of this research.
REMB was supported in part through Charles Bradsher and Joe
Taylor Adams Fellowships (Duke University) and T.J.B. was
supported in part through a C. R. Hauser fellowship (Duke
University).
Supporting information for this article is available on the WWW
under http://dx.doi.org/10.1002/anie.201301640.
Scheme 2. Gold-mediated conversion of 1 into 4.
Angew. Chem. Int. Ed. 2013, 52, 1 – 4
ꢀ 2013 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1
These are not the final page numbers!

.
Angewandte
Communications
complexes 3a and 3b that together constituted around 90%
of the reaction mixture (Scheme 2).[17–19] When this solution
was warmed at ꢁ208C for 8 h, 3a and 3b were consumed to
form the gold–7-phenylbicyclo[3.2.0]hept-1(7)-ene complex 4
in 97% yield (1H NMR spectroscopy).[17] Complex 4 was
likewise the only phosphine-containing species observed by
31P NMR spectroscopy (d = 65.4) during the catalytic con-
version of 1 into 2 (Scheme 2).
without detectable formation of vinylcyclopentene
(Scheme 3).[24]
1
As was the case with 4, the JC6C7 coupling constant of 6
(1JC6C7 = 35 Hz) was diminished significantly relative to that of
free 2 (1JC6C7 = 63 Hz).[25] The strain of 2, although attenuated
relative to 5,[23] is apparently sufficient to significantly bias the
ꢁ
gold alkene bond of 6 toward the metallacyclopropane
structure. However, the lower strain of 2 relative to 5 was
evidenced by the about 60-fold lower binding affinity of 2 to
the [LAu]+ fragment relative to that of 5, determined by
Complex 4 was thermally unstable and was characterized
in solution at or below ꢁ208C by NMR spectroscopy and by
comparison with free 7-phenylbicyclo[3.2.0]hept-1(7)-ene 5
displacement of the weak s-donor ligand NCArF (NCArF =
(see below).[20] Coordination of gold to the C1 C7 bond of the
NC-3,5-C6H3(CF3)2)
from
[LAu(NCArF)]+
SbF6
ꢁ
ꢁ
bicyclo[3.2.0]heptene ligand was established by the large
upfield shift (Dd = ꢁ20) of the C1 carbon atom of 4 relative to
5 and by the presence of phosphorous coupling to both the C1
(d = 126.9; JCP = 13.8 Hz) and C7 carbon atom (d = 141.2;
(Scheme 4).[26] The higher binding affinity of 5 relative to 2
is significant, considering that the binding affinity of the
trisubstituted alkene 2-methyl-2-butene to [LAu]+ is approx-
imately 350 times greater than is that of the tetrasubstituted
alkene 2,3-dimethyl-2-butene.[18]
J
CP = 7.5 Hz) of the bicycloheptene ligand of 4 in the
13C NMR spectrum. 1H–1H NOESY analysis established
binding of the [LAu]+ fragment to the convex face of the
bicycloheptene ligand. Regarding the electronic structure of
4, the C7 (d = 141.2) and C7-phenyl resonances (d = 131.8,
129.1, 127.2) of 4 were shifted downfield only slightly relative
to those of free 5 (d = 137.59 (C7), 128.6, 127.7, 125.0 (Ph)) in
the 13C NMR spectrum;[21] this observation points to modest
accumulation of positive charge at the C7 carbon atom of 4
and hence nominal contribution of the cyclobutyl cation
structure 4a. Rather, the 1JC1C7 coupling constant of 4 (1JC1C7
=
Scheme 4. Equilibrium binding affinities of 2 and 5 to [LAu]+ relative
to NCArF (NCArF =NC-3,5-C6H3(CF3)2).
33 Hz) was diminished significantly relative to that of 5
(1JC1C7 = 61 Hz),[21] consistent with sp3 hybridization of the C1
and C7 carbon atoms of the bicycloheptene ligand of 4. This
observation points to significant d!p* back-bonding and the
predominant contribution of the metallacyclopropane struc-
ture 4c (Scheme 2).[22] The metallacyclopropane character of
4 stands in sharp contrast to the predominant s-bonding
character of extant gold–p-alkene complexes,[18] a discrepancy
attributed to the strain associated with free 5.[23]
In summary, the stoichiometric reaction of 1,6-enyne
1 with [LAuCl]/AgSbF6 at ꢁ208C led to selective (97%)
formation of the gold–bicyclo[3.2.0]hept-1(7)-ene complex 4,
which is the only phosphine-containing species observed in
the gold-catalyzed conversion of 1 into 2. Complex 4 under-
goes rapid 1,3-hydrogen migration at room temperature (t1/2
ꢂ 16 min) to form the gold–bicyclo[3.2.0]hept-1(7)-ene com-
plex 6 with more than 90% selectivity. 13C NMR analysis of
both 4 and 6 established the dominant metallacyclopropane
character of these complexes, which differs markedly from the
predominant s-donating character of known cationic, two-
coordinate gold–p-alkene complexes.[18]
Treatment of 4 with pyridine or nBu4N+ Brꢁ (1 equiv) at
ꢁ208C led to quantitative formation of free 5 and [LAu(py)]+
ꢁ
SbF6 or [LAuBr], respectively (Scheme 3); warming the
latter solution at 258C led to the slow (t1/2 ꢂ 9 h) decompo-
sition of 5 without detectable formation of 2 or vinylcyclo-
pentene. Conversely, warming a solution of 4 at 258C led to
rapid (t1/2 ꢂ 16 min) 1,3-hydrogen migration to form the
thermally sensitive gold–6-phenylbicyclo[3.2.0]hept-6-ene
complex 6 in 82% yield at 85% conversion (96% selectivity)
Received: February 26, 2013
Published online: && &&, &&&&
Keywords: alkene ligands · cycloaddition · gold ·
.
homogeneous catalysis · metallacycles
[1] a) V. Michelet, P. Y. Toullec, J.-P. GenÞt, Angew. Chem. 2008,
120, 4338 – 4386; Angew. Chem. Int. Ed. 2008, 47, 4268 – 4315;
b) S. T. Diver, A. J. Giessert, Chem. Rev. 2004, 104, 1317 – 1382;
c) G. C. Lloyd-Jones, Org. Biomol. Chem. 2003, 1, 215 – 236;
d) A. Marinetti, H. Jullien, A. Voituriez, Chem. Soc. Rev. 2012,
41, 4884 – 4908; e) I. D. G. Watson, F. D. Toste, Chem. Sci. 2012,
3, 2899 – 2919.
[2] a) P. Y. Toullec, V. Michelet, Top. Curr. Chem. 2011, 302, 31 – 80;
b) A. Fꢀrstner, P. W. Davies, Angew. Chem. 2007, 119, 3478 –
3519; Angew. Chem. Int. Ed. 2007, 46, 3410 – 3449; c) C. Nieto-
Scheme 3. Isomerization and ligand displacement reactions of 4.
2
www.angewandte.org
ꢀ 2013 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2013, 52, 1 – 4
These are not the final page numbers!

Angewandte
Chemie
Oberhuber, S. Lopez, E. Jimꢁnez-NfflÇez, A. M. Echavarren,
Chem. Eur. J. 2006, 12, 5916 – 5923; d) E. Jimꢁnez-NfflÇez, A. M.
Echavarren, Chem. Rev. 2008, 108, 3326 – 3350; e) L. Zhang, J.
Sun, S. A. Kozmin, Adv. Synth. Catal. 2006, 348, 2271 – 2296.
[3] Enyne cycloisomerization with skeletal rearrangement is also
catalyzed by electrophilic post-transition metals.[4] However,
enyne cycloisomerizations catalyzed by PdII–, RhI–hydride, and
stable RuII–carbene complexes occur through mechanistically
distinct pathways.[1]
[4] a) N. Chatani, H. Inoue, T. Kotsuma, S. Murai, J. Am. Chem. Soc.
2002, 124, 10294 – 10295; b) Y. Miyanohana, N. Chatani, Org.
Lett. 2006, 8, 2155 – 2158.
[5] A. Fꢀrstner, H. Szillat, B. Gabor, R. Mynott, J. Am. Chem. Soc.
1998, 120, 8305 – 8314.
[17] The major species (31P NMR: d = 62.2) was assigned as the p-
alkene complex 3a on the basis of the large upfield shift of the
terminal-vinyl proton resonance of 3a (Dd ꢂ 1) relative to 1 in
the 1H NMR spectrum at ꢁ808C.[18] The minor species was
assigned as the p-alkyne complex 3b, owing to the presence of
carbon–phosphorous coupling in the 31P NMR spectrum of the
13C-labeled isotopomer 3b-5,6,7-13C3 (d = 62.6, dd, J = 4.9,
27.5 Hz) generated from the 13C-labeled enyne 1-5,6,7-13C3.
Significant broadening of both the 31P and 1H NMR resonances
of 3a and 3b at ꢁ208C, presumably as a result of facile p-ligand
exchange, precluded accurate determination of the 3a/3b ratio
as a function of conversion. Preferential formation of 3a relative
to 3b is in accord with the relative binding affinities of a terminal
alkene and an internal aryl alkyne to gold.[18,19]
[6] For reviews of intermediates generated in gold-catalyzed
reactions, see: a) A. S. K. Hashmi, Angew. Chem. 2010, 122,
5360 – 5369; Angew. Chem. Int. Ed. 2010, 49, 5232 – 5241; b) H.
Schmidbaur, A. Schier, Organometallics 2010, 29, 2 – 23.
[7] Organometallic intermediates have been detected in TiII–[8] and
RuII–carbene-catalyzed enyne cycloisomerization.[9]
[8] S. J. Sturla, N. M. Kablaoui, S. L. Buchwald, J. Am. Chem. Soc.
1999, 121, 1976 – 1977.
[9] a) T. R. Hoye, S. M. Donaldson, T. J. Vos, Org. Lett. 1999, 1,
277 – 280; b) M. P. Schramm, D. S. Reddy, S. A. Kozmin, Angew.
Chem. 2001, 113, 4404 – 4407; Angew. Chem. Int. Ed. 2001, 40,
4274 – 4277.
[10] Echavarren has observed the inactive gold – p-alkene complex
from stoichiometric reaction of 5,5-bis(methoxycarbonyl)-1,7-
enyne with [LAu(NCMe)]+ SbF6ꢁ. M. García-Mota, N. Cabello,
F. Maseras, A. M. Echavarren, J. Pꢁrez-Ramírez, N. Lopez,
ChemPhysChem 2008, 9, 1624 – 1629.
[18] a) T. J. Brown, M. G. Dickens, R. A. Widenhoefer, J. Am. Chem.
Soc. 2009, 131, 6350 – 6351; b) T. J. Brown, M. G. Dickens, R. A.
Widenhoefer, Chem. Commun. 2009, 6451 – 6453.
[19] T. J. Brown, R. A. Widenhoefer, J. Organomet. Chem. 2011, 696,
1216 – 1220.
[20] 1H NMR for 4 (ꢁ208C, 500 MHz, aliphatic resonances only): d =
3.74 (s, 3H), 3.28 (s, 3H), 3.24 (d, J = 14.9 Hz, 1H), 3.12 (d, J =
14.9 Hz, 1H), 3.07 (dtd, J = 1.5, 4.3,15 Hz, 1H), 2.84 (ddd, J =
4.0, 5.2, 9.4 Hz, 1H), 2.77 (dd, J = 3.2, 14.9 Hz, 1H), 2.51 (dd, J =
9, 14.2 Hz, 1H), 2.22 (dd, J = 5.8, 14.2 Hz, 1H), 1.35 (d, J =
16.2 Hz, 9H), 1.24 ppm (d, J = 16.2 Hz, 9H).
[21] The phenyl 13C resonances of 4 and 5 were identified by
comparison to the corresponding C6D5 isotopomers [D5]-4 and
[D5]-5, respectively. The 1JC1C7 coupling constants of 4 and 5 were
determined by analysis of the 13C-labeled isotopomers 4-1,2,7-
13C3 and 5-1,2,7-13C3, respectively.
1
[22] For discussions of JCC coupling constants and the electronic
[11] a) A. Fꢀrstner, P. W. Davies, T. Gress, J. Am. Chem. Soc. 2005,
127, 8244 – 8245; b) T. Matsuda, S. Kadowaki, T. Goya, M.
Murakami, Synlett 2006, 575 – 578.
[12] a) C. Nieto-Oberhuber, S. López, A. M. Echavarren, J. Am.
Chem. Soc. 2005, 127, 6178 – 6179; b) C. Nieto-Oberhuber, P.
Pꢁrez-Galµn, E. Herrero-Gómez, T. Lauterbach, C. Rodríguez,
S. López, C. Bour, A. Rosellón, D. J. Cµrdenas, A. M. Echavar-
ren, J. Am. Chem. Soc. 2008, 130, 269 – 279.
[13] A. Escribano-Cuesta, P. Perez-Galan, E. Herrero-Gomez, M.
Sekine, A. A. C. Braga, F. Maseras, A. M. Echavarren, Org.
Biomol. Chem. 2012, 10, 6105 – 6111.
[14] K. Ota, S. I. Lee, J.-M. Tang, M. Takachi, H. Nakai, T. Morimoto,
H. Sakurai, K. Kataoka, N. Chatani, J. Am. Chem. Soc. 2009, 131,
15203 – 15211.
[15] a) F. Marion, J. Coulomb, C. Courillon, L. Fensterbank, M.
Malacria, Org. Lett. 2004, 6, 1509 – 1511; b) S. Couty, C. Meyer, J.
Cossy, Angew. Chem. 2006, 118, 6878 – 6882; Angew. Chem. Int.
Ed. 2006, 45, 6726 – 6730; c) J. Blum, H. Beer-Kraft, Y. Badrieh,
J. Org. Chem. 1995, 60, 5567 – 5569; d) S. I. Lee, S. M. Kim, M. R.
Choi, S. Y. Kim, Y. K. Chung, W.-S. Han, S. O. Kang, J. Org.
Chem. 2006, 71, 9366 – 9372.
structure of transition metal–alkene complexes, see: a) B. R.
Bender, J. R. Norton, M. M. Miller, O. P. Anderson, A. K.
Rappꢁ, Organometallics 1992, 11, 3427 – 3434; b) R. Benn, A.
RufiÇska, J. Organomet. Chem. 1982, 238, C27 – C30; c) J. W.
Fitch, E. B. Ripplinger, B. A. Shoulders, S. D. Sorey, J. Organo-
met. Chem. 1988, 352, C25 – C28; d) L. Krivdin, G. Kalabin,
Prog. Nucl. Magn. Reson. Spectrosc. 1989, 21, 293 – 448.
[23] a) W. F. Maier, P. v. R. Schleyer, J. Am. Chem. Soc. 1981, 103,
1891 – 1900; b) G. Oba, G. Moreira, G. Manuel, M. Koenig, J.
Organomet. Chem. 2002, 643, 324 – 330; c) J. F. Liebman, A.
Greenberg, Chem. Rev. 1976, 76, 311 – 365.
[24] The 1H NMR resonances corresponding to 6 became obscured at
more than 85% conversion.
[25] Determined by analysis of the 13C-labeled isotopomers 6-6-13C1
and 2-6-13C1. 1H NMR for
6
(ꢁ208C, 500 MHz, aliphatic
resonances only): d = 4.66 (d, J = 4.8 Hz, 1H), 3.99 (dd, J = 2.9,
7.9 Hz, 1H), 3.67 (s, 3H), 3.21 (ddd, J = 1.4, 3.0, 7.6 Hz, 1H), 3.15
(s, 3H), 2.69 (d, J = 14.0 Hz, 1H), 2.55 (d, J = 14.4 Hz, 1H), 2.29
(dd, J = 8.2, 14.4 Hz, 1H), 2.08 (dd, J = 7.8, 14.0 Hz, 1H), 1.30 (d,
J = 16.6 Hz, 9H), 0.86 ppm (d, J = 16.6 Hz, 9H).
[26] Enhanced p-backbonding and increased bond strength with
increasing alkene strain has been calculated for platinum –
alkene complexes: J. Uddin, S. Dapprich, G. Frenking, B. F.
Yates, Organometallics 1999, 18, 457 – 465.
=
[16] Stable bicyclo[n.2.0]alkenes (n ꢃ 4) possessing a bridgehead C
C bond have been isolated from the cycloisomerization of 1,m-
enynes (m ꢃ 7): Y. Odabachiana, F. Gagosz, Adv. Synth. Catal.
2009, 351, 379 – 386, and references therein.
Angew. Chem. Int. Ed. 2013, 52, 1 – 4
ꢀ 2013 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
3
These are not the final page numbers!

.
Angewandte
Communications
Communications
Cycloaddition
R. E. M. Brooner, T. J. Brown,
R. A. Widenhoefer*
&&&& — &&&&
Direct Observation of a Cationic Gold(I)–
Bicyclo[3.2.0]hept-1(7)-ene Complex
Generated in the Cycloisomerization of
a 7-Phenyl-1,6-enyne
The reaction of enyne 1 with a 1:1 mixture
of [LAuCl] and AgSbF6 in CD2Cl2 at ꢁ208C
gave the gold complex 2 in 97% yield
(NMR spectroscopy). Warming a solution
of 2 at 258C led to 1,3-H migration (t1/
2ꢂ16 min) to form the gold complex 3
with 96% selectivity. 13C NMR analysis of
2 and 3 showed predominant metalla-
ꢁ
cyclopropane character of the gold
bicyclo[3.2.0]heptene bond.
4
www.angewandte.org
ꢀ 2013 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2013, 52, 1 – 4
These are not the final page numbers!
