Journal of the American Chemical Society
1
2
3
4
5
6
7
8
NꢀHeterocyclic CarbeneꢀCatalyzed δꢀCarbon LUMO Activation
of Unsaturated Aldehydes
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Tingshun Zhu1,2, Chengli Mou1,2, Baosheng Li2, Marie Smetankova2, BaoꢀAn Song1*, Yonggui Robin
Chi 1,2*
1Laboratory Breeding Base of Green Pesticide and Agricultural Bioengineering, Key Laboratory of Green Pesticide and Agꢀ
ricultural Bioengineering, Ministry of Education, Guizhou University, Huaxi District, Guiyang 550025, China.2 Nanyang
Technological University, Division of Chemistry & Biological Chemistry, School of Physical & Mathematical Sciences,
Singapore 637371, Singapore.
Supporting Information Placeholder
selectivity issue between the βꢀ and δꢀcarbons is addressed by
introducing a substituent to block the reactivity of the βꢀcarbon
(Scheme1)
ABSTRACT:An Nꢀheterocyclic carbene (NHC) catalyzed domꢀ
ino reaction triggered by aδꢀLUMO activation of α,βꢀγ,δꢀ
diunsaturatedenal has been developed for theformal [4+2] conꢀ
struction of multiꢀsubstitutedarenesand3ꢀylidenephthalide. These
two products, formed in a highly chemoꢀ and regioꢀselective
manner, were obtained via different catalytic pathways due to a
simple change of the substrate. The activation of the remoteδꢀ
carbon of unsaturated aldehydes expands the synthetic potentials
of NHC organocatalysis.
Figure 1. NHC Catalyzed δꢀCarbon Activation
Nꢀheterocyclic carbene (NHC) organocatalysts enable unique
reaction modes which allow for the development of highly selecꢀ
tive and effective reactions.1 To date, the carbonyl,2α,3β,4 and γꢀ
carbons5 of (unsaturated) aldehydes and esters have been successꢀ
fully activated by NHC catalysts for a diverse set of reactions
(Figure 1).For example, addition of NHC catalyst to α,βꢀ
unsaturated ester6 or aldehyde7 under oxidative conditions affords
an α,βꢀunsaturated azolium ester intermediate that can undergo
formal 1,4ꢀaddition reactions. The three carbons (carbonyl, α, and
βꢀcarbons) of the α,βꢀunsaturated aldehydes/esters can participate
in the formation of new molecules. In principle, the synthetic
potential of NHCꢀcatalyzed reactions of aldehydes can be signifiꢀ
cantly expanded by introducing additional conjugated C=C bonds
to the aldehydes. However, in enals conjugated with an additional
C=C bond (e.g., α,βꢀγ,δꢀdiunsaturated aldehydes), the activation
of the δꢀcarbon to participate in new bond formation is challengꢀ
ing and remains undeveloped under NHC catalysis.8 Typically, the
βꢀcarbon (or carbonyl carbon) is more reactive, and the δꢀcarbon
remains untouched in NHCꢀcatalyzed reactions, as reported by
Glorius,4f Ma,7d and in our previous work.6c In addition, when
nucleophiles such as enols and enamides were used to react with
unsaturated azolium ester intermediates, 1,2ꢀaddition of the enol
(oxygen) or enamide (nitrogen) to the azolium ester carbonyl
carbon could occur. This 1,2ꢀaddition followed by [3,3]ꢀ
rearrangement, as proposed by Bode,7bꢀc would favor reaction on
the βꢀcarbon.
A postulated reaction pathway is illustrated in Scheme 1. Key
catalytic steps include oxidative7a conversion of unsaturated aldeꢀ
hyde to unsaturated acyl azolium intermediate I; 1,6ꢀaddition of
1,3ꢀdiketone substrate 2 (through its enol isomer) to I, followed
by aldol reaction and intramolecular βꢀlactone formation leading
to bicyclic adduct IV, with the regeneration of NHC catalyst.
Decarboxylation followed by spontaneous oxidative aromatization
finally affords the multiꢀsubstituted benzene product 3. When R is
a reactive aryl ester unit (Scheme 1, path b), intramolecular transꢀ
esterification forms 5ꢀmember lactone (II’ to VI). Isomerization
(VI to VII)9 followed by aldol reaction then produces VIII, which
undergoes further transformations to eventually form the 3ꢀ
ylidenephthalide product 4 via a process similar to the conversion
of III to 3. Notably, the synthesis of multiꢀsubstituted arenes typiꢀ
cally starts with a preꢀexisting benzene unit and the introduction
of substituents requires long steps with rather tedious functional
group manipulations. We previously reported an NHCꢀcatalyzed
formal [3+3] reaction for the synthesis of substituted benꢀ
zenes.5d,10 Our present reaction, built upon a newly developed δꢀ
carbon activation and formal [4+2] reaction, provides a highly
effective and scalable approach in constructing the benzene unit
and preparing multiꢀsubstituted arenes by using readily available
substrates. The direct construction of benzene should find unique
applications, for example, as recently demonstrated in Li’s elegant
synthesis11 of natural products daphniphyllum, rubriflordilactone
and xiamycin via a 6πꢀelectrocyclization/aromatization strategy.
Here we report the first NHCꢀcatalyzed activation of the δꢀ
carbon of α,βꢀγ,δꢀdiunsaturated aldehydes (Figure 1). The chemoꢀ
