, 2001, 11(5), 171–172
Interaction of trimethylsilyl isocyanate with xenon difluoride and fluoroxenonium
triflate in the presence of alkenes
Namig Sh. Pirkuliev,a,b Valery K. Brel,*a Novruz G. Akhmedov,b Nikolai S. Zefirova,b and Peter J. Stangc
a Institute of Physiologically Active Compounds, Russian Academy of Sciences, Chernogolovka, 142432 Moscow Region,
Russian Federation. Fax: +7 095 913 2113; e-mail: brel@ipac.ac.ru
b Department of Chemistry, M. V. Lomonosov Moscow State University, 119899 Moscow, Russian Federation
c Department of Chemistry, University of Utah, Salt Lake City, UT 84112, USA
10.1070/MC2001v011n05ABEH001492
The title reactions lead to the corresponding β -fluoroisocyanates and β -isocyanatotriflates with the formation of the intermediates
FXeNCO and OCNXeOSO2CF3.
Xenon difluoride and its derivatives have been used in organic
YXeNCO
synthesis for fluorination,1 oxidative decarboxylation,2 fluoro-
,
1 2
deiodination,3 generation of nitrenes,4 mono-2 and biradicals5
and intermolecular rearrangements,6 as well as for the oxidation of
organoelement compounds. The last direction is of great interest
since it opens up possibilities for the synthesis of novel xenon
compounds. In particular, the cleavage reactions of the Si–C,
Si–Cl and Si–N bonds with XeF2 were studied in detail.1(a),7
These reactions are assumed to occur through the formation of
intermediates with Xe–N and Xe–C bonds.7
NCO
Y
BuCH CH2
BuCH CH2
NCO
NCO Y
Y
3
4
5
a Y = OSO2CF3
Y = F
We studied the interaction of trimethylsilyl isocyanate with
XeF2 and FXeOSO2CF3 in the presence of unsaturated com-
pounds. The initial fluoroxenonium triflate as a solution in
CH2Cl2 was obtained from xenon difluoride and triflic acid (or
trimethylsilyl triflate) in accordance with a well-known proce-
dure.8 The subsequent addition of trimethylsilyl isocyanate to
the resulting solution afforded a solution of OCNXeOSO2CF3
1. If at the first step XeF2 was treated with trimethylsilyl iso-
cyanate, highly reactive intermediate FXeNCO 2 was generated.
b
identified by 1H and 19F NMR. The 19F NMR spectrum of regio-
isomer 4b has the F signal as a doublet of triplets (d 220.7 ppm)
with a geminal proton coupling of 47 Hz and a vicinal coupling
of JHF = 23 Hz, while regioisomer 5b exhibited an analogous sig-
nal as multiplets with a chemical shift of 183 ppm.
†
General procedure for the interaction of OCNXeOSO2CF3 1 with
alkenes: TMSNCO (5.52 mmol) was added to a suspension of FXeOTf8
(4.72 mmol) in methylene chloride (20 ml) at –78 °C with stirring. The
reaction mixture was then stirred at –40 °C for 1 h until formation of a
colourless solution. The solution was cooled down to –78 °C, and a
solution of an appropriate alkene (8 mmol) in methylene chloride (5 ml)
was added. The reaction mixture was heated to 10 °C, washed with
30 ml of ice water, extracted with CH2Cl2, dried with Na2SO4, and
concentrated in a vacuum at 10 °C. Products 3a–5a were separated by
column chromatography on silica gel with 2:1 petroleum ether–diethyl
ether as an eluent.
i, CF3SO2OH or
CF3SO2OSiMe3
Me3SiNCO
ii, Me3SiNCO
[FXeNCO]
XeF2
[CF3SO2OXeNCO]
1
2
Intermediates 1 and 2 were obtained at –40 to –30 °C as clear
solutions in CH2Cl2. Our attempts to isolate intermediates 1 and
2 resulted in their fast decomposition at –20 °C with the for-
mation of, presumably, Xe, CO and N2. The formation of a
homogeneous solution during a metathetical reaction at –30 °C
indicated the end of the reaction, and the resulting solution of
compounds 1 and 2 can be used for further transformation in situ.
The conclusions concerning the structure of 1 and 2 were made
on the basis of published data1(a),9 and the results of the sub-
sequent chemical transformations, particularly, the reactions with
alkenes.
The reactions of compounds 1 and 2 with cyclohexene and
hex-1-ene were investigated.† The addition of an alkene to a
solution of fluoroxenonium isocyanate 2 in CH2Cl2 at –78 °C
resulted in rapid darkening of the reaction mixture. However,
xenon evolution and concomitant reactions were observed only
upon warming the reaction mixture to –30 °C. The products were
isolated by column chromatography on silica gel. The ratio of
the regioisomers in the reaction mixture and their structure were
determined by NMR spectroscopy. In general, β -
fluoroisocyanate 3b–5b and β -isocyanotriflate 3a–5a were
relatively unstable and slowly decomposed in storage at room
temperature.
1
cis-1-Trifyloxy-2-isocyanatocyclohexane 3a: oil, yield 53%. H NMR
(CDCl3) d: 1.2–2.3 (m, 8H, 4CH2), 4.4–4.7 [m, 2H, CH(OTf)CHNCO].
19F NMR (CDCl3) d: –74.9 (CF3SO3).
1
1-Trifyloxy-2-isocyanatohexane 4a: unstable oil, yield 45%. H NMR
(CDCl3) d: 0.9–1.8 (m, 9H, Bu), 4.1–4.7 [m, 3H, CH(NCO)CH2OTf].
19F NMR (CDCl3) d: –73.9 (CF3SO3).
1
1-Isocyanato-2-trifyloxyhexane 5a: unstable oil, yield 11%. H NMR
(CDCl3) d: 0.9–1.9 (m, 9H, Bu), 4.2–4.9 [m, 3H, CH(OTf)CH2NCO].
19F NMR (CDCl3) d: –74.7 (CF3SO3).
General procedure for reactions of FXeNCO 2 with alkenes: TMSNCO
(5.52 mmol) was added to a suspension of XeF2 (4.72 mmol) in dichloro-
methane (20 ml) at –78 °C with stirring. The reaction mixture was then
stirred at –40 °C for 1 h. The resulting solution was cooled down to –78 °C,
and a solution of an appropriate alkene (8 mmol) in CH2Cl2 (5 ml) was
added. The mixture was allowed to warm to 10 °C with stirring. When
the evolution of xenon gas ceased (0.5–1 h), the mixture was poured into
solution of ice water, then extracted three times with CH2Cl2, dried
(MgSO4), and concentrated in a vacuum at 10 °C. Products 3b–5b were
isolated by column chromatography on silica gel with 2:1 petroleum
ether–diethyl ether as an eluent.
cis-1-Fluoro-2-isocyanatocyclohexane 3b: oil, yield 47%. 1H NMR
(CDCl3) d: 1.4–2.1 (m, 8H, 4CH2), 4.54 (m, 1H, CHNCO), 4.82 (dddd,
The reactions of isocyanatoxenonium triflate 1 and fluoro-
xenonium isocyanate 2 with cyclohexene lead to only product
3. The cis configuration of 3 was established by the vicinal H–H
and H–F couplings in the 1H NMR spectra. The sum of JHH for
H1 and H2 is 13–14 Hz, which is typical of cis substituted cyclo-
hexanes.10
The reactions of xenonium compounds 1 and 2 with hex-
1-ene resulted in the mixture of products 4 and 5 with domina-
tion of regioisomers 4. Each of the regioisomers was isolated and
1H, CHF, JHF 48 Hz, JHH 8, 2.5 and 2.5 Hz). 19F NMR (CDCl3) d:
1
2
–74.6 (CF3SO3), –193.4 (CHF).
1-Fluoro-2-isocyanatohexane 4b: unstable oil, yield 51%. 1H NMR
(CDCl3) d: 1.2–2.1 (m, 9H, Bu), 4.2–4.8 [m, 3H, CH(NCO)CH2F].
19F NMR (CDCl3) d: –74.8 (CF3SO3), –220.7 (dt, CH2F, JHF 47 Hz,
1
2JHF 47 Hz, 2JHF 23 Hz).
1-Isocyanato-2-fluorohexane 5b: unstable oil, yield 15%. 1H NMR
(CDCl3) d: 1.0–2.1 (m, 9H, Bu), 4.2–4.8 (m, 3H, CHFCH2NCO). 19F NMR
(CDCl3) d: –73.5 (CF3SO3), –183 (CHF).
– 171 –

, 2001, 11(5), 171–172
3
4
E. W. Della and N. J. Head, J. Org. Chem., 1992, 57, 778.
S. V. Kovalenko, V. K. Brel, N. S. Zefirov and P. J. Stang, Mendeleev
Commun., 1998, 68.
V. K. Brel, V. I. Uvarov, N. S. Zefirov, P. J. Stang and R. Caple. J. Org.
Chem., 1993, 58, 6922.
(a) T. B. Patrick and L. Zhang, Tetrahedron Lett., 1997, 38, 8925; (b)
T. B. Patrick, L. Zhang and Q. Li, J. Fluorine Chem., 2000, 102, 11; (c)
T. B. Patrick and S. Qian, Org. Lett., 2000, 2, 3359.
(a) J. A. Gibson, R. K. Marat and A. F. Janzen, Can. J. Chem., 1975, 53,
3044; (b) M. Patersson, J. Khriachtchev, E. Isoniemi and M. Rasanen,
J. Am. Chem. Soc., 1998, 120, 7979.
(a) M. Wechsberg, P. A. Bulliner, F. O. Sladky, R. Mews and N. Bartlett,
Inorg. Chem., 1972, 11, 3063; (b) T. M. Kasumov, N. Sh. Pirguliyev,
V. K. Brel, Y. K. Grishin, N. S. Zefirov and P. J. Stang, Tetrahedron, 1997,
53, 13139.
In the light of these observations, we can suggest a mecha-
nism1(a) that involves the initial electrophilic addition of the
xenonium ion to the double bond leading to an organoxenonium
intermediate. At the second step, nucleophilic substitution of Xe
with the neighbouring fluorine or triflate anion occurs. This is
an SN2 type process, which is analogous to the reactions of
iodine(III) with olefins.11
Thus, we found that the reactions of xenon difluoride and
fluoroxenonium triflate with trimethylsilylisocyanate in the pres-
ence of alkenes lead to the corresponding β -fluoroisocyanates
and β -isocyanatotriflates. This fact indirectly confirms the forma-
tion of the intermediates FXeNCO and OCNXeOSO2CF3.
5
6
7
8
We are grateful to NIH, FIRCA (2R03 TW00437) for finan-
cial support.
9
A. Schulz and T. M. Klapotke, Inorg. Chem., 1997, 36, 1929.
10 N. S. Zefirov, V. V. Samoshin, O. A. Subbotin, I. V. Baranenkov and
S. Wolf, Tetrahedron, 1978, 34, 2553.
References
11 N. S. Zefirov, V. V. Zhdankin and A. S. Kozmin, Tetrahedron Lett., 1986,
27, 1845.
1 (a) V. K. Brel, N. Sh. Pirkuliev and N. S. Zefirov, Usp. Khim., 2001, 70,
262 (Russ. Chem. Rev., 2001, 70, 231); (b) New Fluorinating Agents in
Organic Synthesis, eds. L. German and S. Zemskov, Springer-Verlag,
Berlin, 1989.
2 (a) Y. Tanabe, N. Matsuo and N. Ohno, J. Org. Chem., 1988, 53, 4582;
(b) V. K. Brel, A. S. Koz’min, I. V. Martynov, V. I. Uvarov, N. S. Zefirov,
V. V. Zhdankin and P. J. Stang, Tetrahedron Lett., 1990, 31, 4789; (c)
I. V. Martynov, V. K. Brel, V. I. Uvarov, I. A. Pomutkin, N. N. Aleinikov
and S. A. Kashtanov, Izv. Akad. Nauk SSSR, Ser. Khim., 1988, 466 (Bull.
Acad. Sci. USSR, Div. Chem. Sci., 1988, 37, 386).
Received: 3rd July 2001; Com. 01/1818
– 172 –
