M.K.A. Yonekawa et al.
Bioorganic & Medicinal Chemistry Letters 47 (2021) 128206
Fig. 4. Cell viability of normal human cells (HaCaT) treated with NEOBr. (A) Effect of different concentrations of NEOBr on HaCaT cells. (B) Comparison of the
effects of NEOBr on cell viability in 24 h and 48 h. DTIC: dacarbazine. Different letters denote a significant difference between the treatments (ANOVA/Tukey, p
< 0.05).
Previously, studies with racemic mixtures and pure enantiomers
were conducted to evaluate the inhibition of AChE activity, and the
results revealed that enantiomers may have different effects.36 Studies
show that AChE activities can vary in different brain structures due to
various AChE isoforms. A plausible biological mechanism by which the
same AChEi could act selectively on different brain structures remains
unanswered.17 The biological mechanism by which the same AChEi can
act selectively on various brain areas is currently unknown.17 The
striatum is the most AChE brain structure due to the dense intrinsic
cholinergic neurons20 that can be linked to several factors such as: age37
stresses,38 malnourishment,39 hypothyroidism,40 and ethanol intake.41
Consequently, ideal AChE inhibitors should be highly specific for the
various brain structures, have minimal effects on the peripheral
cholinergic system, and cause no toxicity in other organs. The use of
specific AChEis could lead to the development of more effective cogni-
tive stimulants.42,43 The survey of biological activity of pure enantio-
mers is important since studies show that the use of pure drugs has the
advantage that the total dose administered is reduced, the dos-
e–response ratio is simplified and the toxicity due to the inactive isomer
is lessened.44 This is also critical in drug development, in order to
enhance clinical benefit while minimizing pharmacological adverse
effects.19
keratinocytes.45,47 This explains in part the multiplication of cells
observed in our experiments.
The results of the cell viability experiment for NEOBr (Fig. 4) showed
that the compound exhibited cytotoxicity at concentrations of 10,000
µM (24 h), 5000 and 10,000 µM (48 h) (Fig. 4A). In the comparison
between the two time periods, an increase (p < 0.05) in cytotoxicity was
observed for the doses of 5000 and 10,000 µM (Fig. 4B).
When we compared the cytotoxic effects of L-HYP⋅HCl, D-HYP⋅HCl,
and NEOBr, we discovered that the enantiomers were not cytotoxic and
performed better than NEOBr. It is worth noting that NEO is one of the
most commonly used AChE inhibitor drugs in perioperative medicine,
especially after the administration of neuromuscular blockers.48 More
detailed studies of the increase in cell proliferation in response to AChE
inhibition in keratinocytes are needed to confirm the suggested hy-
pothesis comprising inhibitors such as NEOBr. The cytotoxicity, as well
as genotoxic and apoptotic effects of NEOBr exhibited on HaCaT were
also observed in human embryonic renal cells (HEK-293).49 These toxic
effects of NEO may account for the increased cell proliferation not
observed on HaCaT upon treatment with NEOBr.
The differences in potency and selectivity demonstrated by L-HYP
and D-HYP among the tested brain structures is an attractive result.
However, these results are not rare in literature. Although chiral
bioactive isomers, they have markedly different pharmacologic, toxi-
cologic, pharmacokinetic and, metabolic behavior. One enantiomer may
produce the aimed therapeutic effect and, the other may be inactive,
exhibit lower potency and, even toxic effects.50 The different biological
properties of each enantiomer may be due to distinct binding modes at
the active site of the target. Therefore, molecular modeling is an excel-
lent tool for better understanding our biological outcomes.
Cell viability assays in the presence of L-HYP⋅HCl, D-HYP⋅HCl (Fig. 3)
and, NEOBr (Fig. 4) were performed in normal human cells (HaCaT).45
Dacarbazine (DTIC) was used as a positive control and was cytotoxic to
29.74 and 44.46% of the cells treated for 24 and 48 h, respectively. L-
HYP⋅HCl and D-HYP⋅HCl showed no cytotoxic effect on HaCaT in the two
periods analyzed (24 and 48 h) and did not alter the cell viability rate
after 24 h of experiment (p < 0.05). The enantiomers promoted an in-
crease in cell number after 48 h of the experiment (Fig. 3A and C). The
comparison between the two periods demonstrated an increase (p <
0.05) in cell proliferation for the 19.5 and 5000 µM concentrations of L-
HYP⋅HCl after 48 h (Fig. 3B) and, 19.5–156.2 and 625 µM concentra-
tions of D-HYP⋅HCl after 48 h (Fig. 3D). The increased cell proliferation
in the experiments observed with L-HYP⋅HCl and D-HYP⋅HCl may be
associated with the concentration of ACh on HaCaT cells. HaCaT are
keratinocytes and have a functional nonneuronal cholinergic system,
including AChE, ChAT and, cholinergic receptors.46 The result led us to
assume L-HYP⋅HCl and D-HYP⋅HCl inhibit HaCaT’s AChE activity and
increase ACh concentration, which is related to increased cell viability,
proliferation and, migration by the presence of this neurotransmitter in
The position of the ligand at the active site of AChE is crucial for its
inhibitory capacity. The AChE has two main binding sites: one is a hy-
drophobic pocket with Ser, His and, Glu as the more significant amino
acid residues and, the other, composed of Tyr, Trp and, Asp, is known as
a peripheral anionic site of AChE.51,52 The literature vastly reports these
two pockets and, an array of binding modes are observed as a conse-
quence of the structural diversity of the studied inhibitors. The differ-
ences between the structural features make difficult the description of a
structure–activity relationship for the compounds. However, some
amino acids are considered a key to the AChE inhibition as His440,
Glu327, Ser200, Trp84, Trp279 and, Tyr121. Most of the inhibitors can
interact with more than one site.4 Due to the quantity of AChEis, the
4
