Yusuf Cakmak,‡ Sundus Erbas-Cakmak,‡ David A. Leigh*
School of Chemistry, University of Manchester, Oxford Road, Manchester, M13 9PL, United Kingdom
Supporting Information Placeholder
chiral centers through mechanical bonding is rare10 and
ABSTRACT: Mechanical point-chirality in a [2]rotaxane is
chiral systems of this type have not previously been investi-
gated for potential applications.
utilized for asymmetric catalysis. Stable enantiomers of the
rotaxane result from a bulky group in the middle of the
thread preventing a benzylic amide macrocycle shuttling
between different sides of a prochiral center, creating point
chirality in the vicinity of a secondary amine group. The
resulting mechanochirogenesis delivers enantioselective
organocatalysis via both enamine (up to 71:29 er) and imini-
um (up to 68:32 er) activation modes.
Distinctive features imparted by the mechanical bonding
in rotaxanes1 (such as their dynamic properties and the abil-
ity of the ring to mask regions of the thread) are beginning to
be investigated in various aspects of catalysis.2-7 The position
of the macrocycle on rotaxane threads has been used to
conceal or expose amine groups that can promote different
aminocatalysis activation modes3 and threaded molecular
structures have been exploited in processive4 and sequence-
specific5 catalysis. A rotaxane has been demonstrated to be
an effective chiral ligand in nickel-catalyzed Michael addi-
tion reactions6 and a rotaxane complex was recently em-
ployed7 in a gold-mediated cyclopropanation. In both of the
latter two cases embedding the coordinated metal ion within
the well-defined binding pocket of the rotaxane resulted in
higher stereoselectivity of the products than when using the
non-interlocked components as ligands (enantioselectivity in
the case of the chiral rotaxane-nickel catalyst;6 diastereose-
lectivity with the achiral rotaxane-gold catalyst7). However,
to date asymmetric catalysis with rotaxanes has only utilized
conventional chiral elements.2b,2f,3b,6,7 Here we report on the
use of a previously unexplored feature of rotaxane architec-
tures in catalysis, that of chirality induced by the mechanical
bond.8,9
Figure 1. Chemical structures of rotaxane (S)-1 and thread T1, show-
ing the mechanically induced chirality of the rotaxane. The carbon
labelled C11 is a prochiral center in the non-interlocked thread (T1)
but a chiral center in the rotaxane ((S)-1) as the 4-tolylamine group
blocks shuttling of the macrocycle to the other side of the thread.
Two rotaxanes, (S)-1 with the 4-tolylamine group and (S)-2
bearing an analogous 3,5-bis(trifluoromethyl)benzylamine
barrier, were prepared in enantioenriched form (84 % ee in
each case, as indicated by chiral HPLC, see Supporting In-
formation) by unambiguous synthetic routes (see Supporting
Information). In each rotaxane synthesis the key steps in-
volve the five-component macrocyclization about a chiral
succinamide thread (e.g. 3) to form a [2]rotaxane intermedi-
ate (e.g. 4), followed by extension of the stopper (with 5) to
form the second, inaccessible, succinamide group of the axle,
shown in Scheme 1 for the synthesis of (S)-1.
Scheme 1. Synthesis of mechanically point-chiral rotaxane
(S)-1.a
The chemical structures of the rotaxane, (S)-1, and its par-
ent thread, T1, are shown in Figure 1. Thread T1 is achiral,
possessing a mirror place through the prochiral center la-
beled C11. In the rotaxane, however, the bulky 4-tolylamine
group (shown in red, Figure 1) prevents macrocycle shuttling
between the two succinamide stations (shown in green)
resulting in a loss of symmetry. Accordingly, rotaxane (S)-1
has a center of point chirality (C11) with the two succinamide
groups of the thread in different chemical environments, one
accessible to the macrocycle and one not. Establishing point
