100
L. Zhu et al. / Dyes and Pigments 105 (2014) 97e104
76.81; H, 5.48; N, 7.46. Found: C, 76.93; H, 5.21; N, 7.16. IR, n
(cmꢀ1):
2222 (C^N), 1704 (C]O), 1597, 1573 (aromatic rings).
2.2. Photophysical measurements
UVevis absorption of samples was measured using a spectro-
photometer (UV-2450, Shimadzu). For transient absorption spec-
troscopy and time-resolved emission experiments, an LP920-KS
instrument from Edinburgh Instruments, equipped with an iCCD
camera from Andor and a photomultiplier tube.
2.3. Fabrication and characterization of p-DSSCs
Before fabricating NiO nanoparticle films onto FTO glass, a
compact p-type photocathode blocking layer (compact NiO layer)
was deposited by spin-coating nickel acetate (þ98%, aldrich) in
ethanol (ꢂ99.7%, Merck) solution (0.2 M) at 2000 rpm on FTO glass
and sintered at 150 ꢁC for 15 min. The nickel acetate layer was
thermally decomposed by the following reaction during the high
temperature sintering process: Ni(CH3COO)2 þ 4O2 / NiO þ
4CO2 þ 3H2O, and formed a compact NiO layer to improve the
contact between FTO and the NiO nanoparticle film. The p-type NiO
nanoparticle film was prepared by two cycle “doctor-blading” the
precursor solution onto the substrate, and after each “doctor-blad-
ing” process the filmwas sintered at 450 ꢁC for 30 min. NiO precursor
solution was prepared by dissolving anhydrous NiCl2 (1 g) and F108
(1 g) into a mixture of Mill-Q water (3 mL) and ethanol (6 mL). The
Fig. 1. UVevis absorption of dyes T1, T3 and T4 measured in CH2Cl2 solution
(0.03 mM).
transition in T4 as a result of the shorter conjugation length of
fluorene group in comparison to ter-thiophene groups in T3.
Generally, the molar extinction coefficient of T3 and T4 is higher
than T1, indicating more photons harvested (Table 1). Cyclic vol-
tammograms (CVs) were performed in CH2Cl2 solution, using 0.1 M
tetrabutylammonium hexafluorophosphate (TBAPF6) as the sup-
porting electrolyte. The HOMO orbitals of all the dyes studied are
below the top of NiO valence band (ꢀ5.04 eV), and the LUMO or-
bitals are above that of the redox mediator (ꢀ4.15 eV), suggesting
sufficient driving force for hole injection and dye regeneration of
these dyes. The optical band gap of T1, T3 and T4 were determined
from the intersection of absorption and emission spectra in CH2Cl2
film thickness measured by FE-SEM was about 1.6
mm. The NiO
electrode with a 0.25 cm2 geometric area was immersed in a 0.3 mM
dye solution at room temperature for 16 h, followed by rinsing with
dichloromethane and drying in air.
The solar cells were assembled with a platinized FTO counter
electrode using a thermoplastic frame (Surlyn, SX1170-25
mm
(E0-0 ¼ 1240/
l). Detailed optical parameters and electrochemical
properties obtained from the measured CVs are summarized in
Table 1.
thick). The redox electrolyte (containing 0.8 M LiI and 0.15 M I2 in
acetonitrile) was introduced through a pre-drilled hole at the
counter electrode, which was sealed afterwards. The current den-
sity (J)-voltage (V) characteristics were measured using a Keithley
2420 m in dark and under illumination of a sun 2000 solar simu-
lator (Abet) with 100 mW cmꢀ2 AM 1.5G spectrum. The intensity of
the solar simulator was calibrated by standard Si photovoltaic cell.
Incident photon-to-electron conversion efficiency (IPCE) mea-
surements were performed without bias illumination with respect
to a calibrated silicon diode. The monochromic light was supplied
3.2. Theoretical calculations
Density functional theory (DFT) calculations were performed in
Gaussian 09 at B3LYP/6-31þG(d) level to analyze the electron
density distribution of the frontier orbitals of the dye molecules
[29]. The molecular-orbital energy diagram of T1, T3 and T4 were
shown in Fig. 2. The HOMO orbitals are mainly located on the tri-
phenylamine part, and the LUMO orbitals are mainly distributed on
the dicyanovinylene groups and the neighboring bridge ligands.
Notably, the calculated results reveal that the HOMO orbital dis-
tribution in dye T3 is more evenly and efficiently to ensure fast
intramolecular hole transfer from the acceptor to the donor as
observed in dye T1. Contrarily, in T4, the HOMO orbital is located on
most of the conjugation moieties but only slightly distributed on
the fluorene part, leading spatially a little far distance from NiO
semiconductor for more difficult hole injection from HOMO orbital
of T4 to NiO. Therefore, upon photoexcitation, T3 could offer better
charge injection at the metal oxide/dye interface.
by xenon light illuminating through
a Cornerstone mono-
chromator. A chopper was placed after the monochromator and the
signal was collected by Merlin lock-in radiometry after amplifica-
tion by the current preamplifier. Electrochemical impedance
spectroscopy (EIS) was carried out with Solartron 1260 þ 1294
impedance analyzer under illumination at open-circuit potential in
dark with AC amplitude of 10 mV over a range from 20000 to
0.02 Hz.
3. Results and discussion
3.1. Photophysical properties of T3 and T4
The UVevis absorption of T1, T3 and T4 in dichloromethane
3.3. Photovoltaic performances
(CH2Cl2) are shown in Fig 1, and exhibiting two bands, the one at
around 380 nm corresponding to the
p
e
p
* transition of the whole
Typical currentevoltage characteristics of p-DSSCs sensitized
with T3 and T4 on double-layered NiO film with Iꢀ/I3- electrolyte
measured under standard AM 1.5 G conditions (100 mW cmꢀ2) are
shown in Fig 3. Dye T1 was also evaluated under the same condition
for comparison. It turned out that dyes dissolved in the DMF-CH2Cl2
mixture (V:V ¼ 1:5) showed the best performance with Iꢀ/I3ꢀ
electrolyte. Dye T3 sensitized cells exhibits a power conversion
conjugation system, and the one located at longer wavelength
(w500 nm) ascribed to the charge transfer process. The absorbance
of T3 and T4 in the visible region is at longer wavelength than that
of T1, due to their increased conjugation length. However, the
absorbance of T4 in the region around 410 nm is particularly lower
than that of T3, which probably comes from the blue shift of pep*
