Synthesis of a non-peptidic PET tracer
designed for α5β1 integrin receptor
Alessandra Monaco,a,b Olivier Michelin,c John Prior,d Curzio Rüegg,e
Leonardo Scapozza,b and Yann Seimbillea,b
*
Arginine–glycine–aspartic acid (RGD)-containing peptides have been traditionally used as PET probes to noninvasively image
angiogenesis, but recently, small selective molecules for α5β1 integrin receptor have been developed with promising results.
Sixty-one antagonists were screened, and tert-butyl (S)-3-(2-((3R,5S)-1-(3-(1-(2-fluoroethyl)-1H-1,2,3-triazol-4-yl)propanoyl)-5-
((pyridin-2-ylamino)methyl)pyrrolidin-3-yloxy)acetamido)-2-(2,4,6-trimethylbenzamido)propanoate (FPMt) was selected for
the development of a PET tracer to image the expression of α5β1 integrin receptors. An alkynyl precursor (PMt) was initially
synthesized in six steps, and its radiolabeling was performed according to the azide–alkyne copper(II)-catalyzed Huisgen’s
cycloaddition by using 1-azido-2-[18F]fluoroethane ([18F]12). Different reaction conditions between PMt and [18F]12 were
investigated, but all of them afforded [18F]FPMt in 15min with similar radiochemical yields (80–83%, decay corrected). Overall,
the final radiopharmaceutical ([18F]FPMt) was obtained after a synthesis time of 60–70min in 42–44% decay-corrected
radiochemical yield.
Keywords: α5β1 integrin receptor; PET, 1-azide-2-[18F]fluoroethane; click chemistry; peptido-mimetic
reliable and reproducible procedure to radiolabel this pyrrolidine
Introduction
derivative that relies on the following: (i) the preparation and
purification of a widely used radiolabeled synthon 1-azido-2-[18F]
Integrins are an extensive group of transmembrane cell
adhesion receptors, composed by noncovalently linked α and β
fluoroethane and (ii) its subsequent conjugation to our alkynyl
precursor (PMt) via the Huisgen’s 1,3-dipolar cycloaddition.
subunits.1 They mediate cell migration and cell proliferation by
the connection of the extracellular matrix with the intracellular
cytoskeleton.2 Activation of the integrins by ligand binding
Experimental
promotes cell proliferation, migration, and survival, but unligated
or antagonized integrins may activate ‘integrin-mediated
Reagents and instrumentation
death’.3 Integrins are of crucial support for the formation of
capillaries and angiogenesis in physiological and pathological
processes,4 and three of them (αvβ3, αvβ5, and α5β1) have a
prominent role for the development of a new vascular system.5,6
The involvement of these integrins in many diseases such as
tumor, thrombosis, cardiovascular, and inflammatory diseases
makes them an appealing target for the development of
antiangiogenic therapies.7,8 Of them, αvβ3 is the most targeted
integrin, and several antagonists such as monoclonal
antibodies9,10 and arginine–glycine–aspartic acid (RGD)-based
peptides11 are currently in clinical trials.7,12,13 Moreover,
radiolabeled analogs of the RGD peptides have been evaluated
in preclinical and clinical studies, as tracers, to visualize
angiogenesis in growing tumors.14,15
All the solvents and reagents were purchased from Sigma-Aldrich and Fluka
(Basel, Switzerland) or VWR (Nyon, Switzerland) and were used without
further purification. Flash chromatography columns were performed on
VWR silica gel (0.063–0.200 mm). Thin layer chromatography (TLC) was
performed on precoated silica gel 60F254 plastic sheets from VWR. The
compounds were monitored under ultraviolet (UV) light at 254 nm or by
brief immersion in potassium permanganate solution. Radioactive spots
aCyclotron Unit, University Hospital of Geneva, Rue Gabrielle Perret-Gentil 4, 1211
Geneva, Switzerland
bSchool of Pharmaceutical Sciences, University of Geneva and University of
Lausanne, Quai Ernest Ansermet 30, 1211 Geneva, Switzerland
“”In the last years, integrin α5β1 has gained great interest, not
only because of its involvement in tumor angiogenesis but also
for its fundamental role in brain angiogenesis.16 Recently, several
small molecules have been developed to selectively antagonize
this integrin receptor.17–19 The promising biological results
obtained have enhanced the interest in non-αv integrins as target
for new therapies and for imaging to monitor tumor angiogenesis
and neurovascular remodeling after ischemic stroke.16,20
cSwiss Institute of Bioinformatics, University of Lausanne, Quartier Sorge, 1015
Lausanne, Switzerland
dCHUV, Department of Nuclear Medicine, Rue du Bugnon 46, 1011 Lausanne,
Switzerland
eFaculty of Science, Department of Medicine, University of Fribourg, Ch. du Musée
8, 1700 Fribourg, Switzerland
*Correspondence to: Yann Seimbille, Cyclotron Unit, University Hospital of
Geneva, Rue Gabrielle Perret-Gentil 4, 1211 Geneva, Switzerland.
E-mail: Yann.Seimbille@hcuge.ch
In this manuscript, we advance a novel nonpeptidic PET tracer
designed to image the α5β1 integrin receptor. We report herein a
J. Label Compd. Radiopharm 2014
Copyright © 2014 John Wiley & Sons, Ltd.

A. Monaco et al.
were detected with a Cyclone Phosphorimager from PerkinElmer (Waltham, concentrated, and 20 mL of water was added. The aqueous layer was
Massachusetts). The radiochemical yields were determined by TLC analysis extracted with ethyl acetate (3 × 30 mL). The organic layer was dried over
of reaction mixture samples taken at specified times. High-performance
Na2SO4, filtered, and concentrated under vacuum. The crude product
liquid chromatography (HPLC) was performed on an UltiMate 3000 Rapid was purified by chromatography on silica gel using EtOAc/hexane (1:1)
Separation LC system (Dionex, Basel, Switzerland) with Chromeleon 6.8 to obtain light yellow oil. Yield: 88%. 1H-NMR (300 MHz, CDCl3) δ: 4.96
software package. The UV detector was set at four different wavelengths (1H, d, J = 8.1 Hz), 4.30 (1H, q, J = 8.5 Hz), 4.20 (1H, t, J = 1,8 Hz), 3.95 (2H,
(215nm, 220nm, 254nm, and 280 nm). Radioactivity was detected with a d, J = 5.4 Hz), 3.76–3.5 (4H, m), 2.62–2.47 (4H, m), 2.26–2.18 (1H, m),
NaI scintillation detector (Nuclear Interface, Munich, Germany) connected 1.73–1.64 (2H, m), and 1.46 (9H, s). 13C-NMR (300 MHz, CDCl3) δ: 172.07,
on the outflow of the UV detector. The HPLC column used for the 169.25, 82.08, 77.42, 77.21, 69.00, 68.70, 66.68, 60.13, 53.61, 34.12, 33.86,
purification of the product and the characterization of radioactive 28.07 (3C), and 14.86. MS (ESI): m/z 312.1 [M + H]+.
compounds against standards was a Phenomenex Gemini 5-μ C18 110-Å
tert-Butyl 2-((3R,5S)-5-((tert-butyldimethylsilyl)oxy)methyl)-1-(pent-
4-ynoyl)pyrrolidin-3-yl)oxy)acetate (5)
(250× 4.60 mm) column operated at a flow rate of 1 mL/min using a
gradient of 5% acetonitrile in water containing 0.1% trifluoroacetic acid
(TFA) to CH3CN/TFA (99.9:0.1) over 20min. The radiochemical purities were
determined by HPLC analyses. NMR data were recorded with a Varian
Gemini 2000 NMR Spectrometer and Oxford 300 Nuclear Magnetic
Instrument (Oxfordshire, UK). The samples were dissolved either in CDCl3
or in acetone-d6 (Cambridge Isotope Laboratories Inc., Burgdorf,
Switzerland), and the data were processed by MestRe-C 4.8 software.
Chemical shifts (δ) are expressed in ppm relative to the signals of the
solvents and coupling constants (J) in Hz. Mass spectrometry (MS) analyses
were performed using an ESI-MS instrument, API 150EX from AB/MDS
(Sciex, Framingham, Massachusetts), or ES TQ-detector Aqui™ (Waters,
Baden-Dättwil, Switzerland). High-resolution mass spectrometry (HRMS)
spectra were recorded by ESI/nanoESI-IT Esquire 3000 plus (Bruker,
Fällanden, Switzerland).
4 (0.80 g, 2.57 mmol), imidazole (0.44 g, 6.42 mmol), and tert-butyldimethylsilyl
chloride (0.43 g, 2.83 mmol) were dissolved in 15 mL of dimethylformamide
(DMF) and stirred for 3 h at room temperature. The solvent was removed
by evaporation, and 20 mL of EtOAc was added and extracted with water,
saturated NaHCO3, and dried over Na2SO4, then filtered. The solvent was
removed by evaporation, and the product was purified by chromatography
on silica gel using EtOAc to obtain colorless oil. Yield: 82%. 1H-NMR
(300 MHz, CDCl3) δ: 4.37–4.24 (2H, m), 3.96–3.89 (3H, m), 3.68–3.63 (1H,
dd, Jd = 4.2, Jd = 6 Hz), 3.58–3.51 (2H, m), 2.59–2.41 (4H, m), 2.26–2.17
(1H, m), 2.07–1.95 (2H, m), 1.47 (9H, s), 0.85 (9H, s), and 0.04–0.01 (6H, m).
13C-NMR (300 MHz, CDCl3) δ: 169.40, 156.50, 81.88, 78.43, 78.35, 68.60,
67.08 (2C), 63.11, 57.73, 52.91, 33.91, 33.27, 28.21 (3C), 25.85 (3C), 14.06,
and À5.50 (2C). MS (ESI): m/z 426.5 [M+ H]+.
tert-Butyl (S)-3-(2-((3R,5S)-5-(hydroxymethyl)-1-(pent-4-ynoyl)pyrrolidin-3-
